Spring Boot - AOP After Returning Advice

After Returning Advice runs only after a method executes successfully. It is implemented using the @AfterReturning annotation.
If the method throws an exception, this advice will not execute.

Used to execute logic after successful method completion.
Defined using the @AfterReturning annotation in an aspect class.
Commonly used for logging results, auditing, or monitoring.

Steps to Implement After Returning Advice

Step 1: Create Spring Boot Project

Open Spring Initializr and provide the following details:

Group: com.after_returning_advice
Artifact: aop-after-returning-advice-example
Add dependency: Spring Web

Download the project and extract the ZIP file and import the Project into IDE

Step 2: Add AOP Dependency

Add Spring AOP dependency in pom.xml.

pom.xml

XML

<project xmlns="https://maven.apache.org/POM/4.0.0"
         xmlns:xsi="https://www.w3.org/2001/XMLSchema-instance"
          xsi:schemaLocation="https://maven.apache.org/POM/4.0.0
                             https://maven.apache.org/xsd/maven-4.0.0.xsd">
 <modelVersion>4.0.0</modelVersion>
 <groupId>com.before_advice</groupId>
 <artifactId>aop-before-advice-example</artifactId>
 <version>0.0.1-SNAPSHOT</version>

 <packaging>jar</packaging>

 <name>aop-before-advice-example</name>
 <description>Demo project for Spring Boot</description>

  <parent>
     <groupId>org.springframework.boot</groupId>
     <artifactId>spring-boot-starter-parent</artifactId>
     <version>2.2.2.RELEASE</version>
     <relativePath /> <!-- lookup parent from repository -->
  </parent>

  <properties>
     <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
     <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>
     <java.version>1.8</java.version>
  </properties>

    <dependencies>
       <!-- dependency for spring web -->
       <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-web</artifactId>
       </dependency>

       <!-- added dependency for spring aop -->
       <dependency>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-aop</artifactId>
        </dependency>
    </dependencies>

<build>
 <plugins>
  <plugin>
   <groupId>org.springframework.boot</groupId>
   <artifactId>spring-boot-maven-plugin</artifactId>
  </plugin>
 </plugins>
</build>

</project>

Step 3: Create Model Class

Create package: com.after_returning_advice.model and add Student class to represent student data.

Student class:

Java

package com.after_returning_advice.model;

public class Student {
    private String firstName;
    private String secondName;

    public Student() {
    }

    public String getFirstName() {
        return firstName;
    }

    public void setFirstName(String firstName) {
        this.firstName = firstName;
    }

    public String getSecondName() {
        return secondName;
    }

    public void setSecondName(String secondName) {
        this.secondName = secondName;
    }
}

Step 4: Create Service Class

Create package: com.after_returning_advice.service and Add StudentService class with a method to add students using name arguments

StudentService class:

Java

package com.after_returning_advice.service;

import org.springframework.stereotype.Service;
import com.after_returning_advice.model.Student;

@Service
public class StudentService {
    public Student addStudent(String fname, String sname) {
        System.out.println("Add student service method called");
        Student stud = new Student();
        stud.setFirstName(fname);
        stud.setSecondName(sname);
        if(fname.length()<=3)
            throw new RuntimeException("Length of firstname must be 4 or more" );
        return stud;
    }
}

Step 5: Create Controller Class

Create package: com.after_returning_advice.controller and add StudentController to handle GET requests and call the service method

StudentController class:

Java

package com.after_returning_advice.controller;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.RestController;

import com.after_returning_advice.model.Student;
import com.after_returning_advice.service.StudentService;

@RestController
public class StudentController {

    @Autowired
    private StudentService studentService;

    @GetMapping(value = "/add")
    public Student addStudent(@RequestParam("firstName") String firstName, @RequestParam("secondName") String secondName) {
        return studentService.addStudent(firstName, secondName);
    }
}

Step 6: Create Aspect Class

Create package: com.after_returning_advice.aspect and add StudentServiceAspect class.
Define:

Pointcut expression
Advice method using @AfterReturning
This advice runs only after the service method executes successfully.

StudentServiceAspect class:

Java

package com.after_returning_advice.aspect;

import org.aspectj.lang.JoinPoint;
import org.aspectj.lang.annotation.AfterReturning;
import org.aspectj.lang.annotation.Aspect;
import org.aspectj.lang.annotation.Pointcut;
import org.springframework.stereotype.Component;

@Aspect
@Component
public class StudentServiceAspect {
    // the pointcut expression specifying execution of any
    // method in com.after_returning_advice.service.StudentService
    // class of any return type with 0 or more number of arguments
    @Pointcut("execution(* com.after_returning_advice.service.StudentService.*(..)) ")

      // the pointcut signature
      private void anyStudentService() {}

    @AfterReturning("anyStudentService() && args(fname, sname)")
    public void afterReturningAdvice(JoinPoint joinPoint, String fname, String sname)
    {
        System.out.println("After Returning method:" + joinPoint.getSignature()+"\n "
                + "Added Student with first name - " + fname + ", second name - " + sname );
    }
}
