Drinking Systems

for rearing and heavier poultry

@ @
@
@
@
@
@
@
g
g
gg
gg
@
In modern poultry production, nipple
drinkers have proven to be a reliable and
hygienic solution for the supply of water.
They can be composed of the following
parts:
pressure regulator with rinsing system
and indicator for water column height
side supply for a line length of up to 60 m
pressure regulator with rinsing system
central supply for a line length of up
to 120 m
swivelling aeration unit with indicator
for water column height
pressure regulator with automatic
rinsing system
automatic rinsing aeration unit
slope regulator evens out a 10 to
15 cm incline
aeration nozzle with valve under
normal operation, the valve is open to
allow the air to escape
circular tube with anti-roost wire
aluminium profile with double anti-
roost wire
22 mm nipple tube with SaniStar

... Top Nipple orange with drip cup

... Top Nipple with drip cup
suspension system.
Drinking systems for the correct amount of fresh and
clean drinking water
To achieve the optimum performance
from your birds, it is extremely important
to provide fresh and clean drinking water.
For this, water must be available reliably,
free from contamination and within easy
reach for the birds.
Big Dutchman satisfies all of these
requirements in an ideal way offering
a wide range of drinking systems for
broilers, turkeys, and breeders, as well as
pullets and layers.
Our product range includes:
4 nipple drinkers with and without drip
cup;
4 special broiler and turkey drinkers;
4 round drinkers for open water supply;
4 cable winches;
4 water connection unit with medicator.
The choice of the right drinking system
depends on the type of bird, on the field of
use, on the situation in the house and on
your individual requirements. Please let
our experts advise you.
DuoFlow
for actively circulating drinking water
Nipple drinkers hygienic supply of drinking water
@
@
@
@
@
@
@
@
@
g
g
gg
gg
With DuoFlow, Big Dutchman offers its
customers a new drinking system which
uses a pump to circulate the drinking water
inside the drinker line. This pre vents the
water from stagnating inside the line.
Advantages:
4 constant water temperatures in the
drinker line;
4 even concentration of additives along
the whole length of the drinker line
> no sedimentation;
4 no stagnant water in the drinker line
> less risk of contamination;
4 even water pressure;
4 maximum length of drinker line with
side supply up to 120 m;
4 simple assembly by means of a
patented snap-on system.
@
@
@
@
@
Top Nipple orange Top Nipple 100 ml screw nipple
SaniStar

4.5
hygienic nipple without drip cup
During the development of SaniStar

4.5
with a passage rate of 50 to 55 ml/min*,
we attached great importance to good
hygiene. Summarised, this means:
4 reliable valve > water is dispensed
according to demand and without
spilling or leaking;
4 the saddle is welded onto the square
nipple tube > the inner plug-in and
fixation mechanism ensures maximum
housing hygiene and does not create
any crevices for dirt deposits;
4 precise valve pin with 4.5 mm diameter
and sharp-edged cut > larger water
drops adhere to the pin, allowing the
birds to take in water easily;
4 utilisation of high-quality materials
(stainless steel and special synthetic
material) > long service life.
Saddle is
fixed to the
nipple tube
360 nipple
for vertical and
horizontal
activation
Top Nipple, Top Nipple orange and screw nipple
with drip cup
360 nipple
for vertical and
horizontal activation
Housing made of
resistant synthetic
material
Housing made
of stainless
steel
Housing made
of stainless
steel
Advantages
4 smooth outside surface without
corners and edges > maximum
hygiene;
4 100 % vertical orientation and optimum
resetting features > dry litter;
4 easy horizontal and vertical activation
of the valve pin > optimum water
intake even for day-old birds;
4 vertical activation of the valve pin
> super-proportional increase of
passage rate, also suitable for larger
birds;
4 double-sealed surface > high
operational reliability.
Both Top Nipple and Top Nipple orange
are ideally suited for poultry finishing up to
a live weight of approx. 5 kg. Both nipples
have a passage rate of 80 to 90 ml/min*,
thus providing sufficient water supply
even for heavier poultry. The single-arm
drip cup keeps the litter dry without
hindering the birds from drinking.
Big Dutchman also offers 50 ml and 100 ml
screw nipples for use in layer and breeder
houses.
* at 20 cm water column
The main parts of DuoFlow are the pump
unit with pressure regulator (1), the self-
supporting PVC drinker element with anti-
roost wire (2), the CombiMaster nipple (3)
and the automatic rinsing aeration unit (4).
The drinking water circulates in two pipes
inside the drinker element. The pump
provides the required water flow. A small
float switch (5) in the water tank turns the
main water pump off if the water level is
too low.
Penduval

the hygienic drinker especially made for turkey rearing and finishing
With Penduval

, our product range offers

a drinker specifically designed for turkeys
(patent-no. EP 02023938.0-1260).
It supplies turkeys of every age (even
heavy-weight toms with a live weight of
over 20 kg) with sufficient amounts of
clean drinking water. The drinker consists
of a cup which offers the birds open
water, and a nipple with a pendulum.
PremiumDrinker
optimum water supply specifically for broilers
The new PremiumDrinker was developed
specically for broiler nishing and consists
of three main parts:
4 larger nipple tube;
4 CombiMaster drinking nipple;
4 special drinking nipple protector.
This well thought-out system ensures that
the birds always receive a sufcient amount
of water and at the same time reduces
wastage by splash water signicantly.
Thanks to the use of high-quality materials
(special synthetic material and stainless
steel), the drinker is very resistant to
chemicals. The passage rate amounts to
approx. 45 ml/min at a 20 cm water column.
Drinking nipple protector RingCup CombiMaster 28 mm nipple tube
Advantages
4 large lower pin > big and noticeable
water drop;
4 nipple cannot be activated from the
side > less splash water;
4 drip cup is not attached to the nipple
tube any longer > improved hygiene;
4 maximum length of the drinker line
90 m (side supply).
4 reinforced plastic housing with larger
thread diameter > high solidity
4 greater water passage rate
4 only 4 mm of the nipple extend into the
nipple tube > minimum narrowing of
the tube diameter
4 nipple activation from the side is not
possible
4 very simple assembly: protector is put
over the nipple
Round drinkers open water supply for all kinds of poultry
In addition to nipple drinkers, Big Dutch-
man also offers various round drinkers
which are used depending on the bird
type and bird weight. These drinkers are
usually installed in a suspended position.
The JUMBO-T and JUMBO-98 round
drinkers are ideally suited for heavy
turkeys from 2 to 25 kg live weight. The
JUMBO-B drinker is suitable for turkeys
of up to 12 kg live weight as well as layers
and broiler breeders.
JUMBO-T JUMBO-98 JUMBO-B
Thanks to the narrow water jet running
along its side, the bell remains substan-
tially clear. The water does not splash
over the rim and is thus not wasted. This
reduces ammonia emissions in the house.
Since the ballast body (JUMBO-T and B)
is fitted directly to the suspension, there
is no load on the valve and the water level
can be adjusted precisely.
Penduval

for rearing and hen finishing Penduval

for tom finishing

Each time a bird drinks, the birds head
causes the pendulum to move sideways.
Due to this movement, the nipple valve
opens and water flows into the cup, either
along the pendulum or from its inside. At a
raised water level, the birds drink directly
from the cup without activating the
pendulum, thus preventing the cup from
overflowing.
A float ball facilitates drinking for day-old
birds. At a low water level, the float ball
pushes the pendulum sideways so that
water can flow into the cup.
Cable winches for easy raising of the drinker lines
Cable winch for ceiling or gable suspension
Use of cable winches for optimum height adjustment of the drinker lines in relation with the birds age
Cable winch for wall suspension Electrical cable winch for ceiling suspension
In floor management, it is very important
to adjust the height of the drinker lines in
relation to the birds age. For easy and
sufficient intake of water without
spillages, the animals should have to
stretch when drinking.
Suspended feeder and drinker lines can
easily be winched under the ceiling. This
also significantly facilitates cleaning and
moving birds in and out of the house. The
required suspension system consists of:
4 cable winch, pulley and fixing
material;
4 cable and cable clamp and
4 suspension material.
To allow for easy and secure raising of
the drinker lines, Big Dutchman offers
several cable winches both for manual
and electrical operation:
4 cable winch for ceiling or gable
suspension with a hoisting power of
340 kg;
4 cable winch for wall suspension
including a crank with a hoisting
power of 350, 650 or 900 kg;
4 electrical cable winch, 0.09 kW, 230/
400 V, 50/60 Hz for ceiling suspension
including a limit stop with a hoisting
power of 320/240 kg.
In addition to the described winches, Big
Dutchman offers several other electrical
winches that allow for the raising of
several feeder and drinker lines at the
same time.
@
@
@
@
@
@
The medicator dispenses the correct
amount of vitamins and medicines into
the drinking water. The amount to be
dispensed can be adjusted precisely as
the compounds are admitted to the
drinking system proportionally to the
actual water consumption. The respective
compound and the water are mixed at the
homogeniser outlet. Thus, the motor does
not come into contact with the
medications used > no blockages occur,
longer service life.
Water-soluble medicines are extracted
directly from their original packaging.
In the case of pulverized or viscous
substances, a mixing tank (60 l) with
circulating pump (code no. 30-61-3105)
should be employed.
direction of water flow
Type 1 2
Dosing range % 0.2 - 2.0 1.0 - 5.0
Flow rate l/h 10 - 2500 10 - 2500
Working pressure bar 0.3 - 6.0 0.3 - 6.0
Code no. 30-61-3540 30-61-3545
Code no. (incl. connection set
3
/4") 30-62-3070 30-62-3120
(incl. connection set 1") 30-62-3071 30-62-3121
Technical data of the medicator
Advantages of the medicator
4 precise dispensing for all flow rates;
4 high dosing range;
4 high flow rate;
4 long service life and high operational
safety due to the use of high-quality
materials (low sensitivity to a broad
spectrum of chemicals when cleaned
regularly);
4 selective spare part kits for rapid
replacement of worn parts.
Water connection unit with medicator, available
with nominal widths of
3
/4", 1" and 1
1
/2"
Today, a complete drinking system comes
not only with the actual drinker, but
increasingly with a water connection unit.
This unit is installed between the main
water system and the house water line
and can consist of different modules
which may be composed according to
your requirements.
The correct water pressure is adjusted
via the pressure regulator.
Water connection unit and medicator for poultry houses
filter with manometer to avoid block-
age at the nipples optionally with
reversible flow filter in the event of a
high degree of water contamination
valve for separate drawing off of
water
electronic water meter for connection
to a computer for exact measuring
of the water consumption (optional:
conventional water meter)
bypass with three ball valves for
connection of a medicator
medicator to carry out the pro-
phylaxis easily and reliably
pressure reducer with filter and ball
valve for protection against exces-
sive supply pressure, and simple
rinsing
Advantages of the water
connection unit
4 compact design > also suited for very
small service rooms;
4 easy assembly and easy to extend
> all parts are screwed together,
no sticking joints;
4 all connecting elements are made of
PVC > optimum corrosion protection.
@
@
@
@
@
@
@
@
@
@
@
Planning aid
drinker line
maximum distance between suspensions:
300 cm
water connection unit with medicator
pressure regulator with rinsing system
rinsing outlet
Note:
For broilers, we recommend installing one
drinker line for every 2.5 to 3.5 m house width.
As a matter of principle, there should always
be at least one more drinker line than feed line.
For layers and broiler breeders, we recommend
installing one drinker line for every 5 to 7 m
house width.
SaniStar

Use of max. 450 nipples per pressure regulator

Recommended number of birds per nipple*:
Broilers** 12 - 15
Screw nipples (50 and 100 ml)
Layers (50 ml nipple) 8 - 10
Broiler breeders (100 ml nipple) 10
Top Nipple and Top Nipple orange
Use of max. 300 nipples per pressure regulator
Recommended number of birds per nipple*:
Broilers** 20 - 25
Pullets (up to 1.5 kg)** 10 - 16
Broiler breeders (0-18 weeks) 10
Ducks (up to 3.5 kg)** 8 - 12
Round drinkers* JUMBO-T JUMBO-98 JUMBO-B
Recommended number of birds per round drinker**
Turkeys 2 to 25 kg 80 - 120 80 - 100 -
Turkeys 0 to 12 kg - - 80 - 100
Broiler breeders and layers - - 100 - 150
Broilers - - 100 - 150
Day-old chicks*** - - 300
Code no. 30-03-3170 30-02-3200 30-03-3100
Diameter (mm) 480 305 400
Total height (mm) 650 500 640
Rim height (mm) 70 95 60
Weight without ballast (kg) 1.9 1 1.75
Content of ballast tank (l) 7 - 7
Min. working pressure (bar) 0.2 0.2 0.2
Max. working pressure (bar) 0.5 0.5 0.5
Optimum water level in the rim (mm) 10-20 40-50 10-20
* The number of birds per drinker has to be reduced proportionally for very heavy birds and in a hot climate.
** National or regional regulations may stipulate different bird numbers.
*** With spacer ring only.
In addition to the drinking systems described,
we offer a vast range of fount and cup
drinkers. Our experts will be glad to advise
you. To achieve dry litter and good results,
please follow our assembly, user and
operation manuals.
Note:
Turkey rearing: 2 drinker lines in the poult ring
Hen and tom finishing: 1 drinker line per feed
line
Turkey drinker Penduval

**
Rearing 30-40 birds/cup
Hen finishing 25-30 birds/cup
Tom finishing approx. 20 birds/cup
T
e
c
h
n
i
c
a
l

d
e
t
a
i
l
s

s
u
b
j
e
c
t

t
o

c
h
a
n
g
e
.

e
n

8
/
2
0
1
3
USA: Big Dutchman, Inc.
Tel. +1 616 392 5981 [email protected]
www.bigdutchmanusa.com
Brazil: Big Dutchman (Brasil) Ltda.
Tel. +55 16 2108 5310 [email protected]
www.bigdutchman.com.br
Russia: OOO Big Dutchman
Tel. +7 495 2295 171 [email protected] www.bigdutchman.ru
Asia/Pacific: BD Agriculture (Malaysia) Sdn. Bhd.
Tel. +60 3 33 61 5555 [email protected] www.bigdutchman.com
China: Big Dutchman (Tianjin) Livestock Equipment Co., Ltd.
Tel. +86 10 6476 1888 [email protected]
www.bigdutchman.cn
Germany:
Big Dutchman International GmbH
Postfach 1163 49360 Vechta
Tel. +49(0) 4447 801-0 Fax -237
[email protected]
www.bigdutchman.de
CombiMaster
Use of max. 300 nipples per pressure regulator
Recommended number of birds per nipple*:
Broilers** 12 - 15
@
@
@
@
@
