Halton Marine

HVAC solutions for Oil & Gas industry

Enabling Wellbeing

Photo: courtesy of Harald Pettersen/Statoil

Enabling Wellbeing

Front cover photo: courtesy of Anne-Mette Fjrli/Statoil

Halton is passionate about indoor

environments. We offer business enhancing
solutions for comfortable, energy-efficient and
safe environments, for companies that value
wellbeing and productivity of their customers
and personnel.

DAMPERS

Wellbeing, Safety and Energy Efficiency

A good indoor air quality in demanding conditions
results from paying attention to many details and
their succesful adjustment. Why not to unleash
the potential and see what we can achieve

GALLEYS

PRODUCTS

together. Create comfortable, productive and safe

environments, and let Halton help you with industry
leading solutions and services.

HVAC Dampers

The following pages introduce you to our main

product groups for Oil & Gas industry.
Whenever you have questions regarding a good
indoor environment, dont hesitate to contact us! We
are constantly striving to create new technological
mutually beneficial and lead to financially solid,
reliable and long term partnerships.

Galley Ventilation

The Halton Scope

Cabin Ventilation

Droplet Separators and Outdoor louvres

SERVICES

SEPARATORS

PRODUCTS

CABINS

PRODUCTS

advantages and customer releationships that are

Services

DAMPERS
PRODUCTS

Halton HVAC dampers

for all applications
Safety is the most important in extreme working
conditions, where a fire could put people's life at risk

GALLEYS

unless necessary precautions are taken. Therefore it

is essential that the equipment chosen to prevent fire
progression within a ventilation ductwork is top-class.
Because smoke and other toxic gases can be more
dangerous than the fire itself, it is important that the
fire dampers also prevent smoke from spreading.

SERVICES

SEPARATORS

PRODUCTS

CABINS

PRODUCTS

Halton is the manufacturer supplying smoke-tight fire

dampers.
Halton Marine type-approved A0(A60) fire and gas

Halton Marine non-return and pressure-relief

dampers are widely used in different types of ships

dampers are used to prevent backflow and relieve

and Oil & Gas applications, where they are typically

pressure through ventilation ductwork. The opening

installed to prevent the spread of fire, smoke and gas

pressure of BLD and BRD dampers can be individually

between fire zones. The Halton FDB2 fire and gas

adjusted.

damper patented blade structure, contain special seals

that are effective up to 300 C (572 F) and thermally-

Blast valves are designed for protection of ventilation

activated graphite seals that expand when the heat

systems against destructive blast forces.

rises to 150 C (302 F) in ductwork. These unique

The HV series offers higher air flow capacity and

safety features ensure air tightness and low leakage of

increased level of safety, compared to most of the

Halton FDB2 dampers.

available products on the market, as well as flexibility

for design of duct systems.

Halton type-approved H0(H120) fire dampers

are to be used in demanding applications, where it is

Halton Marine shut-off and airflow control

necessary to ensure the maximum amount of time for

dampers are installed in the ventilation ducts where

people to react to possible fire, or risk of fire. Halton

the dampers are used to control and balance the

FEX dampers are to be installed, for example in the

supply of fresh air for people to live and work in.

external walls of living areas, where fire could become

When necessary, dampers can be used to shut-off the

life-threathening. Halton FEX dampers are developed to

ventilation ducts (possible emergency situation).

meet H-Class integrity.

As a result of good airflow management, temperatures

and air pressures are maintained at the required level.

 BP p.l.c.

We offer

H0(H120)-class fire dampers

A0(A60)-class fire and gas dampers

Non-return dampers

Pressure-relief dampers

Shut-off, balancing and gas dampers

Blast valves

With

Pneumatic, electrical, spring-actuated or

mechanical operation systems

A wide range of accessories for explosive

atmospheres and special steels combined with
structural flexibility

ATEX approved products

Product manufactured according to ISO 15138

standard

Excellent quality recognized by the owners and

the major classification societies worldwide

Halton Marine reserves the right alter products without notice.

DAMPERS

PERFORMANCE OF HALTON FDB2

Halton FDB2 is the successor of FDB - the most widely sold marine fire damper in the world. Why do the owners want
to secure their properties with FDB2?

FDB2 in fire conditions

FDB2 is truly designed for fire. Tightness of FDB2

300

improves substantially under fire conditions.

damper leakage and allows the smoke and other
toxic gases to spread out into the ductwork.

Tightness in normal conditions meets - and is

250
standard fire and gas damper
Leakage (m 3/h)

PRODUCTS

Typically, steel deformation during fire increase the

200

150

substantially better than ISO 15138 requirement of

100

300 m3/h/m2 2000 Pa for gas tight fire dampers.

FDB2

GALLEYS

Closed FDB2 fire damper 1000x1000 fulfils the

50
0

requirements of leakage class 3(EN 1751:1998).

10

15

20

25

30

35

40

45

50

55

60

Minutes (from 20 to 500 C in 5 m inutes)

Arctic Test
FDB2, FEX, UTG, BRD dampers were tested for over three months in cold conditions (-35 C.). The test results show that
the dampers operated normally for the full duration of the test. After the Arctic test, dampers kept their performance level
The test results show that the cold conditions had no affect on fire damper operation.

Dampers

Fire and gas dampers

Fire and gas dampers

Fire dampers

Fire and gas dampers

FEX H0(H120)

FDB2 A0(A60)

FDL A0(A60)

FDD A0(A60)

Frame

AISI 316 L or AISI 316 L

with painted frame

AISI 316 L or painted or

galvanized steel

AISI 316 L or painted or

galvanized steel

AISI 316 L or painted or

galvanized steel

Frame thickness

3 or 3-5 mm

3 or 3-5 mm

3 or 3-5 mm

min. 3 mm

Blades

AISI 316 L

AISI 316 L or galvanized

steel

AISI 316 L or galvanized or

painted steel

AISI 316 L

Blade gaskets

with thermal expansion and

special seals

with thermal expansion and

special seals

without seals

thermal expansion and

glass fibre seals

Sizes

from 100x100 to
1200x1200 mm at 1 mm
intervals

from 100x100 to
1200x1600 mm at 1 mm
intervals

from 100x100 to
1300x1200 at 1 mm
intervals

100, 125, 160, 250, 315 mm

Circular connection pieces

from 100 to 1250 mm

from 100 to 1250 mm

from 100 to 1250 mm

100, 125, 160, 250, 315 mm

Modules possible

no

yes

case by case

no

Special flanges and drilling patterns

available as an option

yes

yes

yes

yes

ATEX

available as an option

available as an option

available as an option

no

SERVICES

SEPARATORS

PRODUCTS

CABINS

PRODUCTS

and the fire dampers were tested in fire conditions. The test chamber was set at 1000 C. with a test pressure of 1000 Pa.

All dampers with automatic electrical, pneumatic or spring actuated operation systems and fusible link.
Special grades of stainless steel available on request. Halton Marine fire dampers are approved by most recognized
classification societies worldwide. Please visit www.haltonmarine.com for valid fire damper certificates.

Non-return dampers / BLD and Pressure relief dampers / BRD

Frame material AISI 316 or galvanized or painted steel. Frame thickness 3 mm. Blades made of AISI 316 L or galvanized
steel. Blades contain special seals. Sizes from 100x100 to 1200x1400 mm at 1 mm intervals. Circular connection pieces
from 100 to 1250 mm. Modules possible. Note: special drilling patterns are available as an option. BRD dampers include
counter weights. ATEX approval available as an option.

Blast valves / HV-Series

Material galvanized steel or AISI 316 L. Blast protection up to 1 bar, 14,5 Psi. HV-Series blast valve closes on
overpressures of 0,1 bar (1,5 psi or higher)Modular construction available for high airflows and large ducts. Fully
maintenance free design. Minimum leakage on pass-through pressure and impulse. Minimum turbulance and pressure
drop.The valve is designed to function within the operating temperature range of -40....+200 C.

Blast valves / PV-KK-SM and PV-KK-SMX

Material galvanized steel or AISI 316 L. The PV-KK-SM/-SMX blast valves are designed for a maximum long duration blast
load with 1.0 bar reflected peak pressure. Modular construction available. The valve is designed to function within the
operating temperature range of -40....+200 C.

Adjustment and measurement units / PRA

Casing and blades galvanized steel. Circular connection 100...315 and 350...1000 mm. Adjustable cone and airflow
measurement taps for differential pressure adjustment. Classification of casing leakage, EN 1751 Class C.

Balancing dampers

Shut-off, balancing
and gas dampers

Balancing dampers

Shut-off, balancing
and gas dampers

UTP (thick model)

UTG (thick model)

UTK

UTT

Frame

AISI 316 L or galvanized

or painted steel

AISI 316 L or galvanized

or painted steel

AISI 316 L or galvanized

steel

AISI 316 L or galvanized

steel

Frame thickness

3 mm (standard) or 5 mm

3 mm (standard) or 5 mm

1 mm

1 mm

Blades

AISI 316 L or galvanized

steel

AISI 316 L or galvanized

steel

AISI 316 L or galvanized

steel

AISI 316 L or galvanized

steel

Blades

without seals

with seals

seals (tightness class 1)

insulated and with seals

Sizes

from 100x100 to
1200x1600 mm at 1 mm
intervals. larger sizes with
modular construction

from 100x100 to
1200x1600 mm at 1 mm
intervals. larger sizes with
modular construction

from 100x100 to
2400x2400 mm at 50 mm
intervals (special sizes
available)

from100x100 to
2400x2400 mm at 50 mm
intervals (special sizes
available)

Circular connection pieces

from 100 to 1250 mm

from 100 to 1250 mm

from 100 to 1250 mm

from 100 to 1250 mm

Modules possible

yes

yes

yes

yes

Special drilling patterns available

as an option

yes

yes

yes

yes

Operation principle

electrical, pneumatical or
manual

electrical, pneumatical or
manual

electrical, pneumatical or
manual

electrical, pneumatical or
manual

ATEX

available as an option

available as an option

available as an option

available as an option

Dampers

DAMPERS
PRODUCTS

Halton high-efficiency
galley ventilation
Halton Marine is the leading suppliers of galley ventila-

GALLEYS

tion equipment.
Water wash system for hoods the best choice for
galleys running at peak performance
Halton Marine KWH and KWT water wash hoods are
equipped with an automatic washing system that
cleans the filters, UV-lamps and the exhaust plenum at

PRODUCTS

the set time without a need to remove the filters and

UV-lamps from the hood. Washing cycle is automated
with a separate control cabinet that can be connected
to several hoods. The Halton Marine water wash hoods

airflow into the hood chamber. The remaining grease is

are especially designed for high capacity utilization

then eliminated with UV-light technology, resulting in a

in marine, offshore and onshore applications where

clean exhaust ductwork. This helps to reduce a serious

improved hygienic conditions, safety and reliability play

CABINS

an important role.
Technological Advances
Halton Capture Jet Technology

fire risk and expensive cleaning of the ducts.

The UV-light technology is an excellent choice not only
for hoods in new-buildings but also for refurbishments as
the equipment do not change the outer dimensions.

exhaust efficiency with reduced airflows

Halton Capture Jet prevents the heat and impurities
PRODUCTS

produced by cooking appliances spreading to the

work area. Compared to conventional exhaust-only
hoods, Capture Jet is up to 30% more efficient and
it reduces required airflows resulting in savings in
weight, space and energy consumption. The Halton
Capture Jet technology does not necessarely require a
SEPARATORS

separate supply air duct. The Capture Jet Fan takes the
required air from the galley. This also saves space as
well as contruction and operational costs.
UV-light technology
the most efficient grease filtration technology

SERVICES

In the UV-light concept, most of the grease particles are

first filtered with mechanical filtration (Halton KSA). The
mesh filter behind the KSA spreads and equalizes the

Halton M.A.R.V.E.L. intelligent demand controlled

ventilation system
Compared to traditional hoods, Halton M.A.R.V.E.L.
system combined with Halton Capture Jet technology
can save up to 50% in galley ventilation energy
consumption. This contributes also to environmental
respect. Read more on this award-winning technology
on the next spread.

We offer

Wide range of options for different applications

Automatic galley water wash hoods, galley hoods,

canopies, Jet Extraction Systems

Control cabinets

Certified wet chemical fire suppression systems

Stainless steel diffusers

UV-light technology the most efficient grease

filtration technology in the market. Improved fire
safety and hygienic conditions

Automatic washing function

Capture Jet technology - enabling low airflow rates

In-built certified fire damper in the exhaust

connection according to SOLAS

Construction according to USPHS

Continuously welded contruction in water wash

hoods and condensate canopies

M.A.R.V.E.L. demand based ventilation

For new-buildings and refurbishments

With UV-light technology

Without UV-light technology

Exhaust duct

Exhaust duct

Hood damper

Hood damper

DAMPERS
PRODUCTS
GALLEYS
PRODUCTS
CABINS
PRODUCTS
SEPARATORS
SERVICES

M.A.R.V.E.L. intelligent demand

controlled ventilation system
Halton offers a unique system that can save significant

In traditional systems, the galley ventilation is

amount of energy in galleys without comprising the

maintained in a constant level. In the Halton system,

comfort and functionality. Halton's patented method of

the ventilation is based on varying the exhaust and

Demand Control Ventilation called M.A.R.V.E.L. adjusts

supply air volumes according real needs.

hood exhaust airflow based on cooking appliance

The system detects the status of cooking equipment

status. This is done automatically and individually for

by using sensors and algorithm designed for galley

each hood.

application. M.A.R.V.E.L. also provides comfortable

conditions by supervising and maintaining humidity and
temperature levels inside galley by adjusting

Air- Handling Unit as well as supply and exhaust fan.

The result of M.A.R.V.E.L. system is optimized energy
consumption according to real needs.

Save this

Airflow

system combined with Halton Capture Jet technology can

save up to 50% in galley ventilation energy consumption.
This contributes also to environmental respect.

and humidity control

Operating

less maintenance

Consume on
ly
what is strict
ly needed

Day

Galley water wash

hoods

Galley hoods
without water wash

Capture Jet hoods

Condensate
canopies

KWT/KWH

KFM

KVI

KVM

Material

stainless steel AISI 304,

AISI 316 L available as an
option

stainless steel AISI 304,

AISI 316 L available as an
option

stainless steel AISI 304,

AISI 316 L available as an
option

stainless steel AISI 304,

AISI 316 L available as an
option

Continously welded construction,

manufacture according to USPHS

yes

yes

no

yes

Capture Jet

yes

as an option

yes

no

Supply air

KWT yes, KWH no

no

no

as an option

Airflow measurement tap

yes

yes

yes

no

Light fitting

yes

yes

yes

yes

Washing system

yes

no

no

no

Personal fresh air nozzle

no

no

as an option

no

Airflow control damper

yes

yes

yes

no

Fire damper or shut-off damper

as an option

as an option

as an option

as an option

Grease collection tray

as an option

yes

yes

no

Grease pipe with tap

no

no

as an option

no

Drain pipe

yes

as an option

as an option

no

KSA grease filters

yes

yes

yes

no

KSA + mesh filters

as an option

no

as an option

no

UV-light system

as an option

no

as an option

no

Fire suppression system

as an option

as an option

as an option

as an option

M.A.R.V.E.L.

as an option

as an option

as an option

as an option

PRODUCTS

Jet Extraction System, JES

SEPARATORS

CABINS

PRODUCTS

GALLEYS

PRODUCTS

DAMPERS

Hoods and canopies

Filtration technology

Specifically designed for the front cooking areas or architectural cooking concepts integrating appliances with medium
input power. Exhaust plenum manufactured of stainless steel. High-efficiency filters of stainless steel. Stainless steel
tube, equipped with an aerodynamic nozzle, shaped to generate a high efficiency cyclonic suction effect. Tempered glass
plate, thickness 10 mm. UV-light technology available as an option.

SERVICES

KSA

KSA multi-cyclone filters are manufactured of stainless steel. The UL-classified KSA filters can extract up to 95%
of grease particles above 8 microns. The pressure loss over the extractor does not exceed 120 Pa at the flow rates
calculated. Independent laboratory tests prove KSA to be the most efficient mechanical grease filter on the market.
The mesh filter behind KSA spreads and equalizes the airflow into the hood chamber. This increases the filtration
efficiency. The remaining grease is eliminated with ultraviolet-light technology.
UV-light system is the most efficient solution for hoods with medium to high utilization rate and for cooking processes
producing all sizes of grease particles. UV-light technology breaks small grease particles into smaller molecular units.
Ozone generated by the UVC lamps reacts with the solid and vaporised greases. The resulting substance will not stick to
the ductwork or fans. When a hood is equipped with automatic washing system, UV-lamps are cleaned automatically at
the set time without a need to remove the lamps from the hood.

Optional features
Wet chemical fire suppression system / K5-Galley
SOLAS requirement for fat fryers. Stainless steel construction. Electrically actuated. Real time monitoring. Audible and
visible alarms. Direct integration to alarm system. Simple and compact design with Halton Marine galley hoods. No high
pressure cartridges, mechanical pulleys, tensioning devices, levels or spring loaded plungers.
(K5-Galley in the picture with galley hood)

Control cabinets / WR and C2W

WR control cabinets for intelligent operations. Casing material stainless steel AISI304. Continuously welded construction.
Manufactured according to USPHS requirements. One serving 1 - 7 hood groups. Fully automatic washing cycle that is
programmable for using different type of operation conditions. Embedded UV-control panel available as an option.

C2W control cabinets for intelligent operations. Casing material stainless steel. One control cabinet can manage up to
8 valves. Extension for up 32 valves is available as an option. Fully automatic washing cycle. LCD touch panel as user
interface.

Control panels / UCS

UCS control panel for UV-light technology. Independent operation for 1 - 12 hood modules. Indication for UV-lamp
functionality, alarms and running hours. Small, user-friendly design that can be integrated in the hood surface or water
wash control cabinet. Interface for handheld computer communication.
PWR

Touch panels / LCD

The touch panel interface has been developed to provide fast and simple approach of galley ventilation features. It can
manage all Halton galley ventilation technologies such as UV-light technology, water wash system and demand based
ventilation (M.A.R.V.E.L.). The touch panel displayes individual hoods with clear pictures allowing the potential alarms
or hood statuses to be displayed visually. The touch panel can manage up to 32 hoods (depending on the integrated
technology).

Galley diffusers
Circular ceiling diffusers for galleys / TDM
Manufactured of stainless steel. For circular duct connections 100, 125, 160, 200, 250 and 315 mm. With solid,
detachable front plate. Specifically designed for low spaces. Manufactured according USPSH requirements.

Low velocity ceiling diffusers for galleys / TCG

e

Manufactured of stainless steel. Rectangular connection of 302x152 mm. Special circular connections available. Low
velocity air supply. Enables a potential saving on extract airflow quantity needed for a hood. Supports comfortable
thermal and good acoustic conditions. Manufactured according to USPHS requirements.

DAMPERS
PRODUCTS

Halton individual
cabin ventilation
The Halton Marine cabin ventilation solution is
a total air-condition package that is specifically

GALLEYS

designed for different types of cabins and other spaces

that require a good air-conditioning. The package
includes a VAV unit with plug-and-play functionality plus
grilles, diffusers and valves. VAV unit with intelligent
automation and room thermostat can operate as standalone units or in a network. A LON or Ethernet network

PRODUCTS

CABINS

PRODUCTS

enables that cabin units can be controlled, monitored

and adjusted by supervision system.
FANCOIL UNITS
The Halton FCU is a vertical fancoil unit for air

The manually operated cabin units include reheater

treatment and control that has been specifically

and control unit or just a manual damper (manual

designed for silent cabin comfort with sophisticated

model) which both allow the manual adjustment of

air treatment and control. The compact design and

airflow quantity,

excellent performance levels makes Halton FCU easily

adaptable for different type of projects.

your needs and decor

CABIN UNITS

The Halton Marine cabin ventilation solution also

Halton pressure-independent cabin units support the

includes a wide selection of diffusers and room

most sophisticated indoor environment in cabins. The

thermostats.

airflow is controlled and maintained individually in each

cabin and thus sound levels and comfort are kept in a
best possible level. The airflow and temperature are
continuously measured so that the controller will cut

SEPARATORS

off the reheat power below the minimum airflow.

Halton Marine cabin ventilation equipment can operate
on a LON or Ethernet network with a dedicated
network adapter. Through intelligent network and
pressure-independent operation systems it is possible
to reach the best benefits of the Halton Energy
Efficiency technology.
Halton cabin units are also available without airflow
SERVICES

Choose diffusers and thermostats according to

measurement as pressure indendent units.

Photo courtesy of Statoil

We offer

Single- and double-duct cabin units (B15)

Airflow units for large volumes with heating

Low sound levels and pressure drop

Cost-efficient commissioning due to plug-and-play

technology

Pressure-independent operation system

Programmable VAV unit controllers

Low surface temperature heating coils

Tailored safety functions for airflow handling

Double-safety (SW & HW) to avoid overheating

Possibility to connect additional sensors, e.g.

pressure and fire detection in cabin units

Network solution opens numerous possibilities

to include additional safety features in cabin units
according to customers needs which can be
operated, adjusted and controlled by HMI (Human
Machine Interface)

Pressure level handling in over pressure areas

Heating control for explosive atmospheres

Advanced energy efficiency solutions

DAMPERS
PRODUCTS

Demand based
cabin ventilation
Connecting a Halton cabin ventilation system to a

Cabin 9226

9213

9215

9217

9219

9221

9214

9216

9218

9220

9222

network offers many advantages:

CABINS

PRODUCTS

GALLEYS

Cabin 9228

Savings in energy consumption

A possibility to control, monitor and adjust cabin

Cabin 9230

indoor climate centralized via network

Improved passenger comfort

Savings in troubleshooting time

In a network, selected cabin ventilation parameters can

be managed through PC software or locally by using a
PDA or a laptop computer. The network also enables

1. Adjusting the fan operation to optimal level

optimization of the cabin ventilation system. Halton

The AHU control calculator monitors and collects data

pressure-independent operation system working in a

of the terminal units, as well as functional details.

network enables the lowest energy consumption. It

Collected data enables the calculator to determine

also gives a possibilityto trace the history of each cabin

the pressure in front of each unit. Pressure data is

on the PC, and even make the necessary adjustments

used to optimize the fan operation, which cuts down

without entering the cabin.

the unnecessary energy consumption. All this is done

without loosing any comfort in the cabins.

PRODUCTS

Advanced energy efficiency

One of the best benefits from the Owners point

2. Minimizing the need to cool down the air inside

of view is the active operation between AHU (Air

the AHU

Handling Unit) and terminal units. Data from terminal

The AHU control calculator collects the re-heater

units is collected and calculated to control the AHU in

information from each terminal unit. Based on the

two ways:

re-heaters utilization rates, AHUs chiller and heater

valves are controlled to cut down unnecessary cooling

SERVICES

SEPARATORS

and prevent unnecessary electrical heating inside

the terminal unit. The supply air is kept actively on
optimum temperature level together with humidity
control. With Halton Marine advanced energy
efficiency technology it is possible to save up to 35%
in cabin HVAC energy consumption.

LON and Ethernet networks

ALARMS

CABIN 9214

Air inlet

For new-buildings and refurbishments

Halton Marine offers two different cabin ventilation
network systems: LON and Ethernet. Haltons new
network adapters are available for new-buildings as
well as for refurbishments. Cabin ventilation products
operating as stand-alone are easy to connect to a

Minimum flow
Overheating
Reheater safety switch
I/O communication fault
Communication fault

ROOM TEMPERATURE CONTROL PANEL ( C.)

Re-heater control
400 W
800 W

Flow control (m3/h)

Room supply

250
300
100

Temp. control
Local
Remote

Energy saving mode ( C.)

Maximum
Minimum

Actual
Maximum
Setpoint
Minimum

Flow ref.
Flow max.
Flow min.
History trends
Optimum

Close

network simply by adding a LON or Ethernet network

adapter.
LON network is one choice to build Halton Marine

Ethernet network is another choice to build Halton

centralized cabin ventilation system. Network is

Marine centralized cabin ventilation system.

normally built by ventilation systems, combining

In principle the operations are the same in the both

cabin units of each system together.These groups

networks. In a LON network, node IDs are used for

are connected to the centralized supervision system

unit identification as in Ethernet network, where

operating in PC software. Communication can be also

IP-addresses are used for the same thing. Network

managed in an Ethernet network or in a combination

devices with with IP-addresses or node IDs can

of both. An automatic Halton Marine LON node

contain multiple exchangeable/readable parameters

replacement software, running on supervision PC,

for adjusting cabin climate conditions. PC supervision

enables easy maintenance of the LON network.

software enables easy maintenance and monitoring of

the system.
Halton Ethernet solution can be embedded to an
existing Ethernet network built on board, which is
normally used for other services such as IP-telephone,
Internet, multimedia, IP-television etc.

DAMPERS
PRODUCTS
GALLEYS
PRODUCTS

Single duct cabin

units

Manual single duct

cabin units

Multi-connection
cabin units

Sound attenuator
and balancing boxes

HMF

HMM

HFR/M

HME

Casing material

galvanized steel

galvanized steel

galvanized steel

galvanized steel

Insulation

mineral wool, thickness 25

mm. MED approved

mineral wool, thickness

25 mm. MED approved

mineral wool, thickness

25 mm

mineral wool, thickness

25 mm. MED approved

Operation principle

automatic with pressure

independent or dependent
operation system.

manually operation.
recommended to be used
with TDM or TBM diffuser

automatic with pressure

independent operation
system

Reheater options

400W, 800W, 400W +

800W, 1200W, 1800W

400W, 800W, 1200W

400W, 800W, 400W +

800W, 1200W, 1800W

400W, 800W, 1200W

Operation pressure range

200...1000 Pa

50...1000 Pa

200...1000 Pa

0...200 Pa

Spigots (male or female)

inlet spigot D100...125 mm,

outlet spigots
D160...250 mm

inlet spigot D80...125 mm,

outlet spigots
D160...250 mm

inlet spigot D125...200 mm,

outlet(s) spigots D125...200
mm (1-3 pcs)

inlet spigot
D100...160 mm, outlet
spigots D160...250 mm

Applicable to B-0 and B-15

installations

yes

yes

no need
(not a terminal unit)

yes

Cabin units and boxes

Double duct cabin units / HMR

CABINS

Casing galvanized steel. Mineral wool insulation, thickness 25 mm. MED approved. Automatic cabin unit with pressure
independent operation system. Operation pressure range 200...1000 Pa.
Spigots (male or female): inlet spigot D100/125 mm, outlet spigots D160...250 mm. Applicable to B-0 and B-15
installations.

Airflow units for large air volumes / HML

SEPARATORS

PRODUCTS

Casing galvanized steel. Mineral wool insulation, thickness 50 mm. MED approved. Automatic CAV/VAV unit with
pressure independent operation system. Electrical reheather options: 0,9...30kW.
Operation pressure range 200...1000 Pa. Sizes from 200x200 to 1000x1000 mm. Larger sizes available on request.
Circular connection pieces available from 200 mm to 1000 mm.

Two different cabin ventilation networks available: LON or Ethernet (or a combination of both). Can be also embedded
into existing network. All needed components, such as routers, switches and repeaters available. Commissioning and
start-up services available.

Manual single duct cabin units for small airflows / HMC

Casing galvanized steel. Mineral wool insulation, thickness 25 mm. MED approved. Manually operating cabin unit.
Operation pressure 50...700 Pa. Spigots: inlet spigot D100 mm (male or female), outlet spigot D160 mm (female).
Applicable to B-0 and B-15 installations. Specifically designed to be used together with TCL diffuser.

SERVICES

Fancoils / FCU
Casing galvanized steel. Mineral wool insulation. Silent and stepless fan operation.
Electrical reheaters: 400W + 800W. Total measured cooling capacity: up to 1470 W.
Airflow range from 150 - 500 m3/h. Quick water connections. Integrated electric connections. Air connections tailored
according to customer needs.

Room thermostats

LCDs

Background pictures

Push buttons

Rotating knobs

Halton Marine offers one of

the four different background
pictures for LCD room
thermostat as a standard.
A customized background
picture is available.

Cabin temperature measurement

yes

yes

yes

Wireless service connection

yes

yes

case by case

Delivered with IC-Cable

yes

yes

yes

Temperature adjustment

by touch buttons

by push buttons

by rotating knob

Self diagnose function

yes

yes

no

LED intensity control and auto

dimming

yes

yes

no

Display for actual and set point

temperatures

yes

no

no

Time display

as an option

no

no

Delivered with IC-cable

yes, 7 m. as standard

yes, 7 m. as standard

yes, 7 m. as standard

Customized background picture

as an option

no

no

Customized labeling

no

as an option

as an option

Different colour options for front

panel

yes

yes

yes

Architectural ceiling
diffuser

Circular ceiling
diffusers

Square ceiling
diffusers

HMC cabin unit

diffusers

DLQ

TDM, TDM/P

TBM, TBM/P

TCL

Material

steel with epoxy paint

finishing in RAL or NCS
colour

steel with epoxy paint

finishing in white RAL9010
as standard colour

steel with epoxy paint

finishing in white RAL9010
as standard colour

steel with epoxy paint

finishing in white RAL9010
as standard colour

Connections

D250 mm

D160, 200, 250 mm

D160, 200, 250 mm

D160 mm (male)

Construction

solid front panel. forms

integral impression when
installed in false ceiling

solid front plate (TDM)

or perforated front plate
(TDM/P)

solid front plate (TBM)

or perforated front plate
(TBM/P)

solid front plate. outer

dimensions 470x275 mm

Manual knob

no

available as an option

available as an option

yes

Note

compatible with Halton

Marine cabin units. to be
installed in false ceiling
(B-0, B-15)

compatible with Halton

Marine cabin units

compatible with Halton

Marine cabin units

specifically designed to be
used togehter with HMC
cabin unit. applicable to
B-15 installations

Grilles AWE, AWU

Grilles WSD, WDD

Grille AGC

Grille WTS

Exhaust Valve URH

anodized or epoxy-painted with

white as a standard colour

aluminium with different

finishing available

aluminium with different

finishing available

steel with epoxy-painted

finishing

painted steel with white as

a standard colour

Diffusers

DAMPERS
PRODUCTS

Droplet separators to protect

ventilation systems
Droplet separators are used to protect e.g. ventilation
systems, air handling units, diesel engines and marine

GALLEYS

gas turbines. Weather conditions vary, no doubt about

it, but even the calmest weather conditions contain
salty spray particles on air. These particles and droplets
must be removed.
Halton Marine droplet separators are designed

CABINS

PRODUCTS

for demanding applications such as marine, oil &

gas, chemical, nuclear and paper industries, where
reliability, easy installation and special design play an
important role. Separator vanes are designed to restrict

Halton DSH droplet separator is available in two

the passage of moisture, salt spray and rain water e.g.

different models: single stage model includes a droplet

into HVAC systems or engine room intakes. Halton

separator and a frame and two stage model includes

Marine droplet separators are used in a wide range

and a droplet separator, a frame and a filter. Net and

of applications, where there are differences in wind

mask louvre are available for both models as an option.

speed and direction, levels of local turbulence, rate and

droplet size, distribution of rainfall and surface water

Halton USM is an external louvre for air exhausts.

flow from the surrounding structure. Unique form of

The louvre is effective in preventing objects entering

separator vanes enables high efficiency separation.

into the ductwork and can be also used in air intakes

when droplet separation is not required.

PRODUCTS

Halton Marine droplet separator DSH has been tested

according to the EN13030 performance test for louvers
subjected to simulated rain. The tests were made at
the VTT Technical Research Centre of Finland, where

SERVICES

SEPARATORS

the droplet separator reached A-Class results.

Droplet separators / DSH

Stainless steel AISI 316 L with a painted finishing as an option or sea water resistant aluminium with a painted finishing
(RAL9010 as standard). Construction: droplet separator and frame (single stage), droplet separator, frame and filter (twostage). Net and mask louvre available as an option. High droplet and moisture efficiency, Class A results (EN 13030:2001),
minimum pressure drop. Tailored sizes and designs according to customers needs. Possibility to connect in conjunction
with Halton Marine dampers.

Droplet separators, DSH optional features

DSH with mask louvre provides aesthetic appearance

Access hatch enables easy access to the filter from the side of the unit. (G4 filter in the picture).

F7 and F8 bag filters. The materials of the synthetic fine filters are high-quality and durable, progressive mounted
synthetic fibres. The filters can be used in example for air purification of intake air. Halton filters are certified with ISO9001
and ISO14001 quality and environmental standards. The fine filters are also certified by Eurovent (EN779) standard.

Halton droplet separator can be connected to Halton Marine dampers with or without a connection piece. In both cases
the construction is modified to fit the damper. Connecting DSH together with a damper must be mentioned when
ordering products. Combining Halton Marine droplet separator to a damper offers customers a compact solution for air
intake that also saves space. The products are recommended to be connected together at Halton Marine factory.

DSH droplet separator for duct installation.

PERFORMANCE DATA
Fractional efficiencies of DSH droplet separator and a combination of droplet separator + G4 panel filter measured at the Independent Research Institute.

EFFICIENCY OF DSH

EFFICIENCY OF DHS + G4 PANEL FILTER





APS/droplets 1 m/s
APS/droplets 1.7 m/s
APS/droplets 3 m/s
APS/droplets 5.2 m/s
APS/droplets 9 m/s




APS (Aerodynamic
Particle Sizer)




Efficiency (%)

Efficiency (%)



APS/droplets 1 m/s
APS 1.7 m/s
APS/droplets 3 m/s
APS 5.2 m/s
APS/droplets 9 m/s




APS (Aerodynamic
Particle Sizer)








Droplet size (m)









Droplet size (m)

Outdoor louvres / USM

e

Material sea water resistant aluminium with painted finishing (white RAL9010 as standard colour) or galvanized steel or
stainless steel AISI 316L. Frame thickness 3 mm as standard, blades 1 mm. For air exhaust or intake. Sizes from 150x150
to 1500x2400 mm at 1 mm intervals. Modular construction for larger sizes available. Non-standard dimensions and flange
drilling available as an option. Can be fitted in conjunction with Halton Marine damper.

DAMPERS
PRODUCTS
GALLEYS
PRODUCTS

At your service

CABINS

According to customers' needs

Halton Marine bases its business on flexibility,

Complete solution packages

reliability and customer-orientation. Production

Flexible, high-tech production with short delivery

emphasizes tailoring, which means that solutions are

times

adapted for each customer's specific needs. Halton

Product training and technical back-up for projects

Marine supplies solutions not only for new-builds, but

Global project support, complete technical and

also for refurbishments of existing ones.

The comprehensive project management includes
product design, delivery, commissioning and testing of
PRODUCTS

Halton Marine offers

product assemblies, plus a spare-part service. Training

services of Halton Marine products and solutions are
available through Halton Marine sales offices.
In addition to Halton Marine's own personnel, an
extensive network of Halton Marine distributors and

installation information
Testing and simulation services from full-scale
mock-ups, leakage tests, fire tests, shock tests to
CFD simulation services
Advanced distribution and logistics concept, just-intime deliveries
Well-established but flexible company offering longterm business relationships and after-sales service

SERVICES

SEPARATORS

agents are at your service.

Certified Quality

For galleys and cabins

In addition to ISO 9001, ISO 14001, quality and

Commissioning services

environmental management certificates, Halton Marine

Design services

has committed itself to the Finnish Energy Efficiency

User training of ventilation systems

Agreement that aims to optimise energy efficiency and

Maintenance services for galley UV-light technology

use renewable energy sources. Halton Marine is also

UV-light technology for hoods as a retrofit

qualified by FPAL and the Achilles Joint Qualification

System, for suppliers to the Oil & Gas industry.

installation
Mock-up installations and verification tests

Galley ventilation design services

The Halton Marine services include a design and
airflow calculations for a complete galley ventilation
system with a functional design for different types of
galleys and open kitchens.
Layout and equipment list from the customer enables
Halton to select most suitable and efficient devices for
supply and exhaust in galleys. When the best-matching
devices are dimensioned and placed on customer
layout, Halton Marine supplies a complete 3D view
model to the customer. The 3D model can be easily
integrated into the ship design drawings, which help
co-ordination and integration on board.
Cabin ventilation design services
Halton Marine offers a unique possibility to test and
verify a wide range of air conditioning solutions for
cabin ventilation.
Halton SEAVIEW with cabins and connecting corridor,
is a complete HVAC installation with extensive range
of air-conditioning solutions and measurement devices.
The installation consists of a fully automatic monitoring
system for energy consumption, comfort and safety,
by continuous measurement. The measurement
laboratories that are located next to SEAVIEW, are
an ideal place for sound generation, attenuation, air
velocity and temperature measurements.
Halton also offers computational fluid dynamics (CFD)
simulation services for optimizing the ventilation

and proper functioning of Halton dampers, are tested

system functions. With CFD it is possible to simulate

in Halton's own facilities and, at regular intervals, in

heat transfer, temperatures, velocities, and verify the

independent research institutes around the world.

comfort in the room.

Typical tests include: leakage tests, fire tests, shock

tests and FAT (Factory Acceptance Test).

HVAC dampers

Structural flexibility, reliability, a wide range of

Halton Marine fire dampers conform to leading

accessories combined with global project support are

classification societies worldwide. The technical quality

a part of what Halton can offer.

Photo courtesy of Total

Photo courtesy of yvind Hagen/Statoil

Photo courtesy of Sevan Marine

Photo courtesy of Total

Halton Marine
Pulttikatu 2
FIN-15700 Lahti, Finland
Tel. +358 (0)2079 2200
Fax +358 (0)2079 22060
[email protected]
www.haltonmarine.com
Halton Marines sales offices,
distributors and agents are listed
at www.haltonmarine.com

Halton Marine, one of the worlds leading suppliers of marine HVAC,

develops, manufacturers and markets reliable, high-quality ventilation
solutions specifically designed for marine, navy and offshore applications.
Our know-how and expertise will support you at every stage of the
build - from the design stage to indoor environment solutions and indoor
environment management.
Halton Group specializes in indoor environment solutions, ranging from
public and commercial buildings to foodservice facilities. Founded in
Finland in 1969, Halton operates today in 23 countries around the world,
with annual sales of 140 million and over 1100 employees. The company
has production facilities in Canada, China, France, Finland, Germany,
Hungary, Malaysia, Norway, United Kingdom and USA.

Enabling Wellbeing
