TR ANSFORMER SERVICE
TXpert™ BM , real-time transformer bushing monitoring
enabled by CoreTec 4
TXpertTM BM is our newest solution for
bushing monitoring, enabled by CoreTec 4.
Reliable real time monitoring provides a
powerful insight into the condition of the
bushing - a critical component in all
electrical networks, as it brings current at
high voltage through a grounded barrier -
and gives you an early warning of
incipient faults developing in a bushing to
assure a transformer continuously
delivers optimal performance.
— CoreTec 4 featuring bushing monitoring Why TXpertTM BM solution?
Online condition moni-
toring with CoreTec™ 4 is Our CoreTec 4 has laid the foundation of our digital journey • Reliable and robust products
a better way to manage that allowed select transformer monitoring features and • Easy to install
your transformers.
plug and play of select sensors. With the newest updates we • Based on an industry standard method
are extending our monitoring functionality also to real time • Improved algorithms using pattern matching to identify
bushing monitoring. bushing faults
• Integration into a single dashboard, the CoreTec 4
What you get? • Scalable system - from the smallest to a complete offer-
With TXpertTM BM solution for bushing monitoring you get ing (Plug-and-play way)
support for 1, 3 or 6 bushing configurations. The bushing • A monitoring system, not a “control system”
monitoring acquisition hardware connects to the CoreTec 4 • Cyber Security compliance
through the ethernet expansion port. Digital sensor imple- • Avoidance of expensive unplanned outages
ments real time monitoring through: • Reduction in time-based inspection costs
• Leakage current analysis • Reduction in human error
• Capacitance • Health and safety benefits
• Dissipation factor (tan δ, Δtan δ)
Why Hitachi ABB Power Grids?
How? • Expertize in bushing technology & transformer monitoring
These parameters are then used by the algorithms in the • Unique understanding of how to set the alarms to maxi-
CoreTec 4 version 2 firmware to give you an early warning of mize the value of the system
incipient faults developing in a bushing. • Expertize in data interpretation, possibility to interpret
collected data through our own APM Edge software
Application: • Rapid response time & local support guaranteed
The TXpert™ BM is available for installation in both new through the largest service organization throughout the
transformer applications as well as retrofit. It is designed for complete lifetime of your transformer
an effective lifetime of 20 years. • Unique one-stop-shop supplier with the broadest
bushings, tap-changers, measurement & safety devices
and insulation offering
Functionalities
Measure Bushing health readings and other parameters depending on device selection:
- TXpert BM SC: Industry standard sum of currents algorithm
- TXpert BM VR: Voltage reference method
Model TXpert BM
All bushing types (oil filled or dry) with tap connector; (some
Application
bushing models may require a custom tap adapter)
Electrical specifications
Voltage input Sensors: 12 VDC ; Evaluation unit: 24 VDC
Max current max 2.0 A
Measurement specifications
Number of bushings 3 – 6 – one evaluation unit, 3 bushing plus 3 reference VT signal
Measured parameters Tand, Leakage current, capacitance
Bushing capacitance Range: 1pF – 100nF with accuracy 1%
Dissipation factor (tan δ, Δtan δ) 10-4 to 1, ±0.00001
Resistance 10MΩ to 100TΩ, ±1%
Communication specifications
Communication protocols MODBUS, OPC UA
CyberSecurity Applicable only with CoreTec 4: EEE 1686, IEC 62443-4-1, IEC 62443-4-2
Environmental specifications
Operating ambient temperature -10°C to 60°C
Operating ambient humidity 5% to 95% RH non-condensing
—
02 TXpert BM - bushing
monitoring solution
—
03 CoreTec 4 - data
aggregator
— —
