Samsung Secret

Approval
Model No. :
Parts Code : V33A00031200

Customer : JD
Toshiba DATE : 13. Jan. 2010

SAMSUNG
SAMSUNG TFT-LCD
TFT-LCD

MODEL
MODEL :: LTA460HJ05
LTA460HJ05

NOTE :

hwwyv}lkGi€ DATE
Customer’s Approval 13. Jan. 2010

zpnuh{|yl DATE wylwhylkGi€ DATE

13. Jan. 2010

LCD Business

Samsung Electronics Co . , LTD.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ XVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Contents
Samsung Secret
Revision History -------------------------------------------------------------------------------------------- (3)

General Description --------------------------------------------------------------------------------------- (4)

General Information --------------------------------------------------------------------------------------- (4)

1. Absolute Maximum Ratings -------------------------------------------------------------------------- (5)

2. Optical Characteristics --------------------------------------------------------------------------------- (6)

3. Electrical Characteristics ------------------------------------------------------------------------------- (9)

3.1 TFT LCD Module
3.2 Back Light Unit
3.3 Inverter Input & Specification

4. Input Terminal Pin Assignment --------------------------------------------------------------------- (12)

4.1 Input Signal & Power
4.2 Inverter Input Pin Configuration
4.3 Inverter Input Power Sequence
4.4 LVDS Interface
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color

5. Interface Timing ---------------------------------------------------------------------------------------- (18)

5.1 Timing Parameters (DE only mode)
5.2 Timing Diagrams of interface Signal (DE only mode)
5.3 Power ON/OFF Sequence

6. Outline Dimension -------------------------------------------------------------------------------------- (21)

7. Reliability test ---------------------------------------------------------------------------------------------(23)

8. Packing --------------------------------------------------------------------------------------------------- (24)

9. Marking & Others --------------------------------------------------------------------------------------- (25)

10. General Precaution ----------------------------------------------------------------------------------- (26)

10.1 Handling
10.2 Storage
10.3 Operation
10.4 Operation Condition Guide
10.5 Others

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ YVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
* Revision History
Rev.
Date Page Summary
No

Dec 10,
000 all First Issued
2009
Dec 22,
000 22 Outline Dimension Rear Updated
2009
Dec 30,
001 10 Operating Life Time : Typical 50,000 hr Æ Typical 30,000 hr
2009

Jan 13, 4, 21 Module Size DMAX : 29.9 Æ 30.9mm

002
2010 10 Additional Note (2) : SLED Life time Test condition.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ ZVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

General Description Samsung Secret

Description
LTA460HJ05 is a color active matrix liquid crystal display (LCD) that uses amorphous silicon
TFT(Thin Film Transistor) as switching components. This model is composed of a TFT LCD panel,
a driver circuit and a back light unit. The resolution of a 46.0“ is 1920 x 1080 and this model can
display up to 1.07 Billion colors with wide viewing angle of 89¶ or higher in all directions. This panel
is intended to support applications to provide a excellent performance for Flat Panel Display such
as Home-alone Multimedia TFT-LCD TV and High Definition TV

Features
ƒ RoHS compliance (Pb-free)
ƒ High contrast ratio & aperture ratio with wide color gamut
ƒ SPVA(Super Patterned Vertical Align) mode
ƒ Wide viewing angle (·178¶)
ƒ High speed response ( & Natural Motion (DFR: Double Frame Rate) )
ƒ FHD resolution (16:9)
ƒ Low Power consumption
ƒ Edge Type LED (Light Emitted Diode) BLU
ƒ DE (Data Enable) mode
ƒ 4ch LVDS (Low Voltage Differential Signaling) interface (4pixel/clock)

General Information
Items Specification Unit Note
1076.5(HTYP) x 634.7(VTYP) ·1.0mm
Module Size mm
30.9 (DMAX)
Weight 11,300 (Max) g

Pixel Pitch 0.53025(H) x 0.53025(W) mm

Active Display Area 1018.08(H) x 572.67(V) mm

Surface Treatment Haze 0 %, Hard Coating 3H

Display Colors 8 bit + FRC – 1.07 Billion colors

Number of Pixels 1920 x 1080 pixel

Pixel Arrangement RGB vertical stripe

Display Mode Normally Black

Luminance of White 450 (Typ.) cd/m2

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ [VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
1. Absolute Maximum Ratings
If the condition exceeds maximum ratings, it can cause malfunction or unrecoverable
damage to the device.

Item Symbol Min. Max. Unit Note

Power Supply Voltage VDD GND-0.5 13.2 V

(1)
Dimming Control Max. Lum - 5 V
Storage temperature TSTG -20 60 ୅
(2)
Operating temperature TOPR 0 50 ୅
Surface temperature TSUR 0 60 ୅ (3)
X,Y - 40
Shock ( non - operating ) SNOP G (4)
Z - 30
Vibration ( non - operating ) VNOP - 1.5 G (5)

Note (1) Ta= 25 · 2 ¶C

(2) Temperature and relative humidity range are shown in the figure below.
a. 90 % RH Max. (Ta ˺ 39 ¶C)
b. Relative Humidity is 90% or less. (Ta ஘39 ¶C)
c. No condensation
(3) Although abnormal visual problems can be occurred in TSUR range, the polarizer
is not damaged in this range.
(4) 11ms, sine wave, one time for ·X, ·Y, ·Z axis
(5) 10-300 Hz, Sweep rate 10min, 30min for X,Y,Z axis

Fig. Temperature and Relative humidity range

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ \VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

2. Optical Characteristics Samsung Secret

The optical characteristics should be measured in a dark room or equivalent.

Measuring equipment : TOPCON RD-80S, TOPCON SR-3, ELDIM EZ-Contrast

(Ta = 25 · 2¶C, VDD=12V, fv= 120Hz, fDCLK = 297.0MHz, LED Current = 95mA)

Item Symbol Condition Min. Typ. Max. Unit Note

Contrast Ratio (1)
C/R 4000 5000 -
(Center of screen) SR-3
Response (3)
G-to-G Tg - 6 - msec
Time RD-80S
Luminance of White (4)
YL 360 450 - cd/m2
(Center of screen) SR-3
Rx Normal 0.622
Red qL,R =0
Ry 0.331
qU,D =0
Gx 0.305
Green
Color Gy Viewing 0.631
TYP. TYP. (5),(6)
Chromaticity Angle
Bx -0.03 0.154 +0.03 SR-3
(CIE 1931)
Blue
By 0.050
Wx 0.280
White
Wy 0.290
Color Gamut - - 72 - % (5)
SR-3
Color Temperature - - 10,000 - K
qL 75 89 -
Hor.
Viewing qR 75 89 - (6)
C/R˻10 Degree
Angle qU 75 89 - EZ-Contrast
Ver.
qD 75 89 -
White Brightness
(2)
Uniformity Buni - - 25 %
SR-3
(9 Points)

- Test Equipment Setup

The measurement should be executed in a stable, windless and dark room between
40min and 60min after lighting the back light at the given temperature for stabilization
of the back light. This should be measured in the center of screen.

Environment condition : Ta = 25 · 2 ¶C

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ ]VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret

Photo detector
Photo detector Field

SR-3 2ദ
RD-80S 1ദ Field

SR-3 : 50໅
RD-80S : 50໅

TFT - LCD Module

LCD Panel

The center of the screen

- Definition of test point

320 960 1600

Active Area
180 ྡ ྠ ྟ
Test Point
540 ྞ ྜྷ ྜ

900 ྛ ྚ ྙ

Note (1) Definition of Contrast Ratio (C/R)

: Ratio of gray max (Gmax) & gray min (Gmin) at the center point 㽶 of the panel
G max
C/R
G min
Gmax : Luminance with all pixels white
Gmin : Luminance with all pixels black

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ ^VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret

Note (2) Definition of 9 points brightness uniformity (Test pattern : Full White )

( B max  B min)
Buni 100
B max

Bmax : Maximum brightness

Bmin : Minimum brightness

Note (3) Definition of Response time : Sum of Tr, Tf

Display data Black (data off) White (data on) Black (data off)

TR TF
Optical Instruments
100%
Response
90%

10%
0%
TIME

Note (4) Definition of Luminance of White : Luminance of white at center point 㽶

Note (5) Definition of Color Chromaticity (CIE 1931)

Color coordinate of Red, Green, Blue & White at center point 㽶

Note (6) Definition of Viewing Angle

: Viewing angle range (C/R ı10)

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ _VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
3. Electrical Characteristics

3.1 TFT LCD Module

The connector for display data & timing signal should be connected.
Ta = 25¶C · 2 ¶C
Item Symbol Min. Typ. Max. Unit Note
Voltage of Power Supply VDD 10.8 12.0 13.2 V (1)
(a) Black - 526 - mA
Current of
Power (b) White IDD - 509 - mA (2),(3)
Supply
(c) Sub V-Stripe - 1071 1200 mA
Vsync Frequency fV 95.0 120.0 125.0 Hz
Hsync Frequency fH 120.0 135.0 140.0 kHz
Main Frequency fDCLK 260.0 297.0 305.0 MHz
Rush Current IRUSH - - 6 A (4)

Note (1) The ripple voltage should be controlled under 10% of VDD.
(2) fV=120Hz, fDCLK = 297.0MHz, VDD = 12.0V, DC Current.
(3) Power dissipation check pattern (LCD Module only)

a) Black Pattern b) White Pattern c) Sub V-Stripe

(4) Measurement Conditions

VDD
100%
90%

10%
GND

TRUSH=470༕
Rush Current IRUSH can be measured when TRUSH. is 470༕.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ `VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
3.2 Back Light Unit

The back light unit contains Edge type White LEDs (Light Emitting Diode)

Ta=25 · 2¶C

Control Board

LCD Module

Converter

Item Symbol Min. Typ. Max. Unit Note

Operating Life Time Hr - 30,000 - Hour (1),(2)

Note (1) It is defined as the time to take until the brightness reduces to 50% of its original
value. [Operating condition : Ta = 25·2୅, For LED Package only. ]
(2) SLED Test Condition : 120mA / 2000hr / Tj = 75’C

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ XWVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
3.3 Inverter Input Condition & Specification

Specifications
Items Symbol Conditions Unit Note
Min. Typ. Max.
Input Ta=25·YG¶j
Vin - 22 24 26 V
Voltage OYP

Input IOVER Vin=24.0V - 3.87 4.85 (1)

A
Current ISAT Vdim =3.3V - 3.60 3.91
LED (2)
IO,MAX Vdim =3.3 V 90 95 100 mArms
Current

Backlight ON Vin=24.0 V 2.4 - 5.25

V (3)
On/Off OFF Vin=24.0 V 0 - 0.8

Dimming Max Lum 3.3 - -

VDIM V (3)
Control Min. Lum - - 0

PWM Max 3.0 - 5.0

VPWM V (3)
Voltage Min 0.0 - 0.4
PWM
FPWM Vin=24.0 V 95 - 185 Hz
Frequency
PWM Duty Duty Vin=24.0 V 0 - 100 % (4)

Note) Power Consumption is measured when 450 [cd/m ] of luminance which is the typical
luminance.
Lamp Current is measured at the point before Lamp.

(1) Max Value of the Power Consumption is measured during initial turn on time* of the backlight
(2) Max Value of the Power Consumption is measured after 60 min warm-up.
(3) The ripple voltage should be controlled under 10% of Input Signal
(4) Duty = On/(On+Off) * 100

* Initial turn-on time : From 0sec to 60min after turn-on

On Off
Max

Min

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ XXVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

4. Input Terminal Pin Assignment Samsung Secret

4.1.1 Input Signal & Power Connector : FI-RE41S-HF (JAE/UJU)

Pin Description Pin Symbol Description

1 Vdd(12V) 21 Rx1[3]P

2 Vdd(12V) 22 Rx1[4]N

3 Vdd(12V) 23 Rx1[4]P

4 Vdd(12V) 24 GND

5 Vdd(12V) 25 Rx3[0]N

6 No Connection 26 Rx3[0]P

7 GND 27 Rx3[1]N

8 GND 28 Rx3[1]P

9 GND 29 Rx3[2]N
ODD LVDS
SIGNAL
10 Rx1[0]N 30 Rx3[2]P

11 Rx1[0]P 31 GND

12 Rx1[1]N 32 Rx3CLK-

13 Rx1[1]P 33 Rx3CLK+

14 Rx1[2]N 34 GND
ODD LVDS
15 Rx1[2]P 35 Rx3[3]N
SIGNAL
16 GND 36 Rx3[3]P

17 Rx1CLK- 37 Rx3[4]N

18 Rx1CLK+ 38 Rx3[4]P

19 GND 39 GND

20 Rx1[3]N 40 No Connection

41 No Connection

Note) No Connection: This PINS are only used for SAMSUNG internal using.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ XYVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret

4.1.2 Input Signal & Power Connector : FI-RE51S-HF (JAE/UJU)

Pin Description Pin Description

1 Vdd(12V) 26 Rx4[0]P

2 Vdd(12V) 27 Rx4[1]N

3 Vdd(12V) 28 Rx4[1]P

4 Vdd(12V) 29 Rx4[2]N

5 Vdd(12V) 30 Rx4[2]P

6 No Connection 31 GND
EVEN
7 GND 32 LVDS Rx4CLK-
SIGNAL
8 GND 33 Rx4CLK+

9 GND 34 GND

10 Rx2[0]N 35 Rx4[3]N

11 Rx2[0]P 36 Rx4[3]P

12 Rx2[1]N 37 Rx4[4]N

13 Rx2[1]P 38 Rx4[4]P

14 Rx2[2]N 39 GND

15 Rx2[2]P 40 No Connection

16 GND 41 No Connection

17 EVEN Rx2CLK- 42 No Connection

LVDS
18 SIGNAL Rx2CLK+ 43 No Connection

19 GND 44 No Connection

20 Rx2[3]N 45 LVDS Option * Note(1)

21 Rx2[3]P 46 No Connection

22 Rx2[4]N 47 No Connection

23 Rx2[4]P 48 No Connection

24 GND 49 No Connection

25 Rx4[0]N 50 No Connection

51 No Connection

NOTE) No connection : This Pins are only used for SAMSUNG internal using

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ XZVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
Note) Pin number starts from Right side

PCB
̷ ̷

Pin No. 1 Pin No. 41 Pin No. 1 Pin No. 51

#1 #41 #1 #51

#1 #41 #1 #51

Fig. Connector diagram

a. All GND pins should be connected together and also be connected to the LCD’s
metal chassis.
b. All power input pins should be connected together.
c. All NC pins should be separated from other signal or power.

Note(1) LVDS OPTION : If this PIN HIGH ( 3.3V ) ˧ Normal LVDS format
LOW ( GND ) ˧ JEIDA LVDS format
SEQUENCE : On = VDD(T1) ˧ LVDS Option ˧ Interface Signal(T2)
OFF = Interface Signal(T3) ˧ LVDS Option ˧ VDD

Vin T2 T3

LVDS
Option

LVDS
Signal
LVDS Option Sequence

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ X[VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

4.2. Inverter Input Pin Configuration Samsung Secret

Connector : Yeon-ho, 20022WR-14B1
Pin Configuration(FUNCTION)
Pin No.
Master
1 24 V
2 24 V
3 24 V
4 24 V
5 24 V
6 GND
7 GND
8 GND
9 GND
10 GND
11 Error Out
12 Backlight On /Off [ON:2.4 – 5.25 V, OFF: 0 - 0.8 V]
13 Dimming Control [0V:Min, 3.3V:Max] *Note(1)
14 External PWM [0~100%] *Note(1)

Note(1) If use Dimming Control, Pin 14 Must be N.C

If use External PWM, Pin 13 Must be N.C
4.3. Inverter Input Power Sequence

Vin (24V)

0.02sec [Min]

Dimming Control

External PWM
0.02sec [Min] 0.2sec [Min]

Backlight On/Off

0sec [Min] 0 sec [Min]

Note) SEQUENCE : On = Vin(24V) > Internal or External PWN ˻ Backlight On/off
OFF = Backlight On/Off ˻ Internal or External PWN > Vin(24V)

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ X\VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

4.4 LVDS Interface Samsung Secret

- LVDS Receiver : Tcon (merged)
- Data Format (JEIDA & Normal)
LVDS pin JEIDA -DATA Normal -DATA
TxIN/RxOUT0 R4 R0
TxIN/RxOUT1 R5 R1
TxIN/RxOUT2 R6 R2
TxOUT/RxIN0 TxIN/RxOUT3 R7 R3
TxIN/RxOUT4 R8 R4
TxIN/RxOUT6 R9 R5
TxIN/RxOUT7 G4 G0
TxIN/RxOUT8 G5 G1
TxIN/RxOUT9 G6 G2
TxIN/RxOUT12 G7 G3
TxOUT/RxIN1 TxIN/RxOUT13 G8 G4
TxIN/RxOUT14 G9 G5
TxIN/RxOUT15 B4 B0
TxIN/RxOUT18 B5 B1
TxIN/RxOUT19 B6 B2
TxIN/RxOUT20 B7 B3
TxIN/RxOUT21 B8 B4
TxOUT/RxIN2 TxIN/RxOUT22 B9 B5
TxIN/RxOUT24 HSYNC HSYNC
TxIN/RxOUT25 VSYNC VSYNC
TxIN/RxOUT26 DEN DEN
TxIN/RxOUT27 R2 R6
TxIN/RxOUT5 R3 R7
TxIN/RxOUT10 G2 G6
TxOUT/RxIN3 TxIN/RxOUT11 G3 G7
TxIN/RxOUT16 B2 B6
TxIN/RxOUT17 B3 B7
TxIN/RxOUT23 RESERVED RESERVED
TxIN/RxOUT28 R0 R8
TxIN/RxOUT29 R1 R9
TxIN/RxOUT30 G0 G8
TxOUT/RxIN4 TxIN/RxOUT31 G1 G9
TxIN/RxOUT32 B0 B8
TxIN/RxOUT33 B1 B9
TxIN/RxOUT34 RESERVED RESERVED
tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ X]VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
4.5 Input Signals, Basic Display Colors and Gray Scale of Each Color
DATA SIGNAL
GRAY
DISPLAY
COLOR RED GREEN BLUE SCALE
(8bit)
LEVEL
R0 R1 R2 R3 R4 R5 R6 R7 R8 R9 G0 G1 G2 G3 G4 G5 G6 G7 G8 G9 B0 B1 B2 B3 B4 B5 B6 B7 B8 B9

BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -

BLUE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 -

GREEN 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 -

CYAN 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 -
BASIC
COLOR
RED 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 -

MAGENTA 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 -

YELLOW 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 -

WHITE 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 -

BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R0

1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1

DARK 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R2
GRAY ˦
: : : : : : : : : : : : : : : : : : : : : : : : : : : : : :
SCALE R3~
OF R1020
: : : : : : : : : : : : : : : : : : : : : : : : : : : : : :
RED ˨
LIGHT 1 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1021

0 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1022

RED 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 R1023

BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G0

0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G1

DARK 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 G2
GRAY ˦
: : : : : : : : : : : : : : : : : : : : : : : : : : : : : :
SCALE G3~
OF G1020
: : : : : : : : : : : : : : : : : : : : : : : : : : : : : :
GREEN ˨
LIGHT 0 0 0 0 0 0 0 0 0 0 1 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 G1021

0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 G1022

GREEN 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 G1023

BLACK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 B0

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 B1

DARK 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 B2
GRAY ˦
: : : : : : : : : : : : : : : : : : : : : : : : : : : : : :
SCALE B3~
OF B1020
: : : : : : : : : : : : : : : : : : : : : : : : : : : : : :
BLUE ˨
LIGHT 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 1 1 1 1 1 1 1 1 B1021

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 B1022

BLUE 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 B1023

Note) Definition of Gray :

Rn : Red Gray, Gn : Green Gray, Bn : Blue Gray (n = Gray level)
Input Signal : 0 = Low level voltage, 1 = High level voltage

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ X^VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
5. Interface Timing

5.1 Timing Parameters ( DE mode )

SIGNAL ITEM SYMBOL MIN. TYP. MAX. Unit NOTE

Clock 1/TC 260.0 297.0 305.0 MHz -

Hsync Frequency FH 120.0 135.0 140.0 KHz -

Vsync FV 95.0 120.0 125.0 Hz -

Active
Display TVD - 1080 - Lines -
Vertical Period
Display Term
Vertical
TV 1092 1125 1380 Lines -
Total

Active
Display THD - 1920 - Clocks -
Horizontal Period
Display Term
Horizontal
TH 2090 2200 2350 clocks -
Total

Note) This product is DE mode. But the Hsync & Vsync signal must be inputted

(1) Test Point : TTL control signal and CLK at LVDS Tx input terminal in system
(2) Internal VDD = 3.3V

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ X_VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
5.2 Timing diagrams of interface signal ( DE mode )

TV

TVD TVB

DE

TH

THD

DE

DCLK
TC

DATA
SIGNALS

TC
TCH TCL

DCLK 0.5
VCC

TDS TDH

DISPLAY 0.5
DATA
VCC

TES

DE 0.5
VCC

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ X`VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

5.3 Power ON/OFF Sequence Samsung Secret

To prevent a latch-up or DC operation of the LCD Module, the power on/off

sequence should be as the diagram below.

0msec<T1˺10msec
0<T2˺50msec
0<T3˺50msec
1000msec˺T4

XWWW”šŒŠ˺{\
OyŒŠ–””Œ•‹G}ˆ“œŒP WU\G}ŠŠ
XWW”šŒŠ˺{]
OyŒŠ–””Œ•‹G}ˆ“œŒP

T1 : VDD rising time from 10% to 90%

T2 : The time from VDD to valid data at power ON.
T3 : The time from valid data off to VDD off at power Off.
T4 : VDD off time for Windows restart
T5 : The time from valid data to B/L enable at power ON.
T6 : The time from valid data off to B/L disable at power Off.
ƒ The supply voltage of the external system for the Module input should be the same
as the definition of VDD.
ƒ Apply the lamp voltage within the LCD operation range. When the back light turns on
before the LCD operation or the LCD turns off before the back light turns off,
the display may momentarily show abnormal screen.
ƒ In case of VDD = off level,
please keep the level of input signals low or keep a high impedance.
ƒ T4 should be measured after the Module has been fully discharged between power off
and on period.
ƒ Interface signal should not be kept at high impedance when the power is on.
ƒ In Case T5 is less than 1000msec and T6 is less than 100msec,
Garbage Display can be seen. (It is not related to electrical function issue, Just for
recommendation to prevent Garbage Display )

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ YWVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
6. Outline Dimension- Front

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ YXVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
6. Outline Dimension- Rear

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ YYVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
7. Reliability Test

Item Test condition Quantity

Temperature
-20 ௥ 60ఁ, 40hr, 5 Cycle determination 4EA
Step Stress
HTOL 50ఁ, 500hr determination 4EA

LTOL 0ఁ, 500hr determination 4EA

HTS 70ఁ, 500hr determination 4EA

LTS -30ఁ, 500hr determination 4EA

THB 40ఁ / 95%RH, 500hr determination 4EA

WHTS 60ఁ / 75%RH, 250hr determination 4EA

Thermal Shock -20 ఁ ~ 60 ఁ, 200cycle determination 4EA

contact : ᇹ8 kV ,150Ꮔ/330ᇢ,200Point,1 time/Point

ESD(operation) 3EA
non-contact : ᇹ15 kV,150Ꮔ/330ᇢ,200Point,1 time/Point

Inverter Input
contact : ᇹ2kV,150Ꮔ/330,Input Con.Pin,3 times/Pin 3EA
Con. ESD
Vibration 10~300Hz/1.5G/10minSR, XYZ, 30min/axis 3EA

Shock Half Sine, 11msec, ·X,Y 40G, · Z 30G 1time/axis 3EA

PALLET
1.05Grms 5~200Hz 1hr 1PALLET(16EA)
Vibration

PALLET Drop 4 edge 1face(bottom) 20 cm 1PALLET(16EA)

[ Result Evaluation Criteria]

Under the display quality test conditions with normal operation state, these should
be no change which may affect practical display functions.

* HTOL/ LTOL : High/Low Temperature Operating Life

** THB : Temperature Humidity Bias
*** HTS/LTS : High/Low Temperature Storage
**** WHTS : Wet High Temperature Storage

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ YZVY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
8. PACKING

8.1 CARTON (Internal Package)

(1) Packing Form
Corrugated fiberboard box and corrugated cardboard as shock absorber
(2) Packing Method

Packing
-Pallet Box Direction be able to open it

Cushion-Foam

LCD Module

Cushion-Foam

Pallet-Plastic

8.2 Packing Specification

Item Specification Remark

1. 180.8 kg / LCD (16ea)
16ea / (Packing- 2. 12 Kg / Cushion-pallet (2ea)
LCD Packing
Pallet Box) 3. 8 Kg / Packing-Pallet Box (1ea)
4. Cushion-pallet Material : EPS
5. Packing-Pallet Box Material : DW4
Pallet 1Box / Pallet 1. Pallet weight = 8.8kg

Packing Direction Vertical

Total Pallet Size H x V x height 1270mm(H) x 1150mm(V) x 844mm(height)

Total Pallet Pallet(8.8kg) + Module (180.8 kg) + Cushion

209.6 kg
Weight (up + bottom =12kg) + Pallet-BOX(8kg)

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ Y[VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
9. MARKING & OTHERS

A nameplate bearing followed by is affixed to a shipped product at the specified

location on each product.

(1) Part number : LTA460HJ05

(2) Revision: Three letters
(3) Lot number : X X X X XXX XX X

Cell Position No. (In the Glass)

Glass No. (In the one Lot)
Lot No. (Glass)
Month
Year (Note1)
Product code
Line
(4) Nameplate Indication

TC Week code : 09 25
week
LTA460HJ05
year
0925 40mm
[[[[
[[[[[[[[[[ [[[
Revision code
Lot number

80mm
(5) Packing box attach

100mm
OWD793KM38 Part number

[[[
49

Box serial number

165mm
(6) Others
1. After service part
Lamps cannot be replaced because of the narrow bezel structure.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ Y\VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

10. General Precautions Samsung Secret

10.1 Handling
(a) When the Module is assembled, it should be attached to the system firmly
using all mounting holes. Be careful not to twist and bend the Module.

(b) Because the inverter use high voltage, it should be disconnected from power
before it is assembled or disassembled.

(c) Refrain from strong mechanical shock and / or any force to the Module.
In addition to damage, this may cause improper operation or damage to the Module
and LED back light.

(d) Note that polarizers are very fragile and could be damage easily.
Do not press or scratch the surface harder than a HB pencil lead.

(e) Wipe off water droplets or oil immediately. If you leave the droplets for a long
time, staining or discoloration may occur.

(f) If the surface of the polarizer is dirty, clean it using absorbent cotton or soft cloth.

(g) Desirable cleaners are water, IPA(Isopropyl Alcohol) or Hexane.

Do not use Ketone type materials(ex. Acetone), Ethyl alcohol, Toluene, Ethyl acid
or Methyl chloride. It might permanent damage to the polarizer due to chemical
reaction.

(h) If the liquid crystal material leaks from the panel, it should be kept away
from the eyes or mouth . In case of contact with hands, legs or clothes, it must
be washed away with soap thoroughly.

(i) Protect the module from Electrostatic discharge. Otherwise the ASIC IC or
semiconductor would be damaged.

(j) Use finger-stalls with soft gloves in order to keep display clean during the
incoming inspection and assembly process.

(k) Do not disassemble the Module.

(l) Do not disassemble shield case of inverter & LVDS board

(m) Do not connect N.C pins. (Samsung internal use only)

(n) Protection film for polarizer on the Module should be slowly peeled off just before use
so that the electrostatic charge can be minimized. Must put on antistatic glove while
handling a module
(o) Pins of I/F connector should not be touched directly with bare hands.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ Y]VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

Samsung Secret
10.2 Storage

(a) Do not leave the Module in high temperature, and high humidity for a long time.
It is highly recommended to store the Module with temperature from 0 to 35୅
and relative humidity of less than 70%.

(b) Do not store the TFT-LCD Module in direct sunlight.

(c) The Module should be stored in a dark place. It is prohibited to apply sunlight or
fluorescent light in storing.

10.3 Operation

(a) Do not connect or disconnect the Module in the "Power On" condition.

(b) Power supply should always be turned on/off by the "Power on/off sequence"

(c) Module has high frequency circuits. Sufficient suppression to the electromagnetic
interference should be done by system manufacturers. Grounding and shielding methods
may be important to minimize the interference.

(d) The cable between the back light connector and its inverter power supply should
be connected directly with a minimized length. A longer cable between
the back light and the inverter may cause lower luminance of LED and
may require higher startup voltage(Vs).

10.4 Operation Condition Guide

(a) The LCD product should be operated under normal conditions.

Normal condition is defined as below;
- Temperature : 20·15୅
- Humidity : 55·20%
- Display pattern : continually changing pattern (Not stationary)

(b) If the product will be used in extreme conditions such as high temperature,
humidity, display patterns or operation time etc.., It is strongly recommended
to contact SEC for Application engineering advice. Otherwise, its reliability and
function may not be guaranteed. Extreme conditions are commonly found at
Airports, Transit Stations, Banks, Stock market, and Controlling systems.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ Y^VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
 Global LCD Panel Exchange Center www.panelook.com

10.5 Others Samsung Secret

(a) Ultra-violet ray filter is necessary for outdoor operation.

(b) Avoid condensation of water. It may result in improper operation or disconnection

of electrode.

(c) Do not exceed the absolute maximum rating value. ( supply voltage variation,
input voltage variation, variation in part contents and environmental temperature,
and so on)
Otherwise the Module may be damaged.

(d) If the Module keeps displaying the same pattern for a long period of time,
the image may be "sticked" to the screen.
To avoid image sticking, it is recommended to use a screen saver.

(e) This Module has its circuitry PCB's on the rear side and should be handled
carefully in order not to be stressed.

(f) Please contact SEC in advance when you display the same pattern for a long time.

tvkls s{h[]WoqW\ k–ŠUGu– W]TWWYTzTXWWXXZ wˆŽŒ Y_VY_

One step solution for LCD / PDP / OLED panel application: Datasheet, inventory and accessory! www.panelook.com
