LABEL

ew
N
Weatherproof
Quarter-turn Actuators
AQ RANGE
4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 AQ range
The essentials
for quarter-turn electric actuation AQ5 - AQ10 - AQ15 - AQ25 - AQ30 - AQ50 - AQ80 - AQ100 AQ5 - AQ10 - AQ15 - AQ25 - AQ30 - AQ50 - AQ80 - AQ100
AQ150 - AQ280 - AQ430 - AQ610 - AQ830 - AQ1000 AQ150 - AQ280 - AQ430 - AQ610 - AQ830 - AQ1000
SWITCH version LOGIC version

Product overview New mobile application BC App Product benefits

“Set up your actuator and more in a few clicks!”
> Set up & Operate your actuator using your

Mechanical position mobile phone

> Get access to clear descriptions of alarms,

indicator on all models troubleshooting functions, documentation,

Bernard Controls Assistance •C
 ompact & optimized • Easy to use
Check the position of your valve at a glance > Upload & change the full actuator
configuration in one step
design >E  asy commissioning: pre-wired
> Even complex settings are made easier > Super compact design (including version (1-phase only), set up of
integrated controls) travel limitation system with a
New camblock system > Product architecture & torque standard screwdriver…
range >L  arge LCD display on LOGIC
On SWITCH VERSION communication as standard
on new LOGIC adapted to customers’ version for user-friendly
Easy set up of the travel limitation
system with a standard screwdriver requirements: 14 models from commissioning and local
50 to 10000 Nm command. Easily orientable (4-
> Multi-voltage (AC/DC) : suitable way direction) in few clicks
whatever your location on the > Declutch-free manual override:
globe essential for quick intervention
Position signaling > Optimized logistics: short on site
delivery time >B  C APP: Bernard Controls new
by 2 LEDs mobile application for setting,
(green / red configurable LEDs
operating, troubleshooting and
for open / closed) • Reliable design
easy access to documentation
> BERNARD CONTROLS design
methodology built-up on
the nuclear market highly • The main functions of
demanding requirements SMART control with the
Large LCD display > 80+ years of continuous new LOGIC control (v2)
Easily orientable in a few clicks on the
experience and BC inventor > Turn-key, time & cost-saving
BC App or through local commands
of the compact quarter-turn solution
Heavy duty design electric actuator > User-friendly & intuitive
Full aluminium enclosure protected by
durable powder coating !
> Heavy duty design: full > Non-intrusive setting for
aluminium enhanced safety and reliability
enclosure protected by durable > Compatible with common
powder coating, IP68, low fieldbus protocols: Modbus RTU,
temperature option Profibus DPV1.
> 100% of delivered products are > Bluetooth communication (as
tested with automatic process standard) to communicate with
before delivery Bernard Controls’ BC App
> S4 Motor Service Duty on all
models
Cable entries > Suitable for modulating
up to 5 cable entries applications
(BC Class III complying with
EN15714-2 Class C)

User-friendly
Flange local commands Declutch-free handwheel
through 2 buttons &
according to ISO 5211 1 padlockable selector
> with motor priority
with removable socket > with foldable handle

1 2

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com 4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 AQ RANGE
Weatherproof Quarter-turn Actuators

AQ SWITCH AQ LOGIC
AQ5-AQ10-AQ15-AQ25-AQ30-AQ50 - AQ80
AQ100 - AQ150-AQ280-AQ430-AQ610- AQ5-AQ10-AQ15-AQ25-AQ30-AQ50-AQ80-AQ100
AQ830-AQ1000 AQ150-AQ280-AQ430-AQ610-AQ830-AQ1000

1x115/220/230V AC 50/60Hz 1x115/220/230V AC 50/60Hz

3x380-415V AC 50Hz 3x380-415V AC 50Hz
3x440-480V AC 60Hz 3x440-480V AC 60Hz
24V DC (up to AQ80) 24V DC (up to AQ80)

On-Off Class A as standard On-Off Class A as standard

> OPTIONS > OPTIONS
Low temp. -40° Low temp. -40°
Position potentiometer (1000 Ω) Class B (Analog Positioner (input + output signals)
> Class B (POT) Class III (Analog Positioner (input + output signals)
Analog Transmitter (output signal) 4 additional signaling relays
> Class B (TAM) Profibus DPV1
Analog Positioner (input + output signals) Modbus RTU
(1-phase only) Stainless steel name plate
> Class B and Class III Varistor
Stainless steel name plate
Varistor

Contents

Product specifications - AQ SWITCH ............................................................................ 3

Product specifications AQ LOGIC ................................................................................. 5
Product selection .................................. ............................................................. 9

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 AQ SWITCH
PRODUCT SPECIFICATIONS
All AQ actuators include motor with thermal protection, gear case,
emergency handwheel, travel limit switches, torque switches (for torque
Description
>150Nm), output drive with removable socket and anti-condensation
heater.

GENERAL Direct: 50 to 1000 N.m

Torque range
Up to 10 000 N.m with Gearbox

Adapted to process requirements:

Duty Classification • On-Off: Class A actuators complying with EN15714-2
• Inching/Positioning: Class B actuators complying with EN15714-2

• Aluminium die casting

Casing
• Cover fastened by captive and stainless screws

• Type: Epoxy powder coating as standard

External Protection • Protection: C4 according to ISO 12944
• For colors and finishes, please consult us

IP68
ENCLOSURE -
Weatherproofness NEMA 4X as standard
PROTECTION Relative humidity: 0 to 95%.

• -20…+70°C / -4 ... +158°F

Ambient • -40°C (-40°F) as an option
temperature range Other temperatures, please consult us

1g (9.8 m/s²) at 10-200 Hz.

Vibration resistance
(Contact our sales teams for higher vibration levels)

• 3-phase or single-phase asynchronous motor, Class F insulation with

Motor technology integral thermal overload protection.
• DC motors

• On/Off operation (complying with EN15714-2 Class A) and Inching/

MOTOR Positioning (complying with EN15714-2 Class B): S4-30% motor duty
rating. Up to 360 starts per hour at peak of operation. S4-50% as an
Motor duty rating option.
• BC Modulating Class III (complying with EN15714- 2 Class C): S4-50%
motor duty rating. Up to 1 200 starts per hour at peak of operation.
(Voltage ±10%, frequency ±2%)

Gear design Actuator is mechanically self-locking

Manual emergency Manual override handwheel

operation Automatic declutch
MECHANICAL
SPECIFICATIONS Actuator flanges comply with ISO 5211
Output flange

The actuators are lubricated for the product lifetime and do not require
Lubrication
any special service.

The actuators can operate on a wide variety of power supplies:

Power supply • 3-phase, single-phase or DC (except AQ150 to AQ1000)
• 50 or 60 Hz …

Prewired available as an option for AQ5 to AQ80 : single- phase 230V

ELECTRICAL Prewired (option)
50/60Hz, single-phase 115-120V 50/60Hz and DC.
SPECIFICATIONS
Screw-type terminals for controls and power supply. Internal earth
Terminal compartment
grounding post.

Conduit entries 2 x M20 as standard (or 2 x 3/4’’)

• Limit switches actuated by adjustable camblock

Travel limit systems • 2 SPDT switches as standard (Open and Close) + 2 auxiliary switches (for
signaling)

• Torque limitation available from AQ25

POSITION & • The torque limiting system is calibrated at the factory
TORQUE SENSORS Torque limiting system • 2 switches as standard (1 in opening and 1 in closing); SPDT; 250VAC-
5Amax (resistive load)
• Adjustable torque from 40 to 100% of max torque (intrusive setting)

ANALOG TRANSMITTER OPTION:

Analog Transmitter
• 2 wires for 4-20mA Analog Transmitter
(option) • POT 1000Ω
1/2
4

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 AQ SWITCH
PRODUCT SPECIFICATIONS
Visual position indication Mechanical position indicator

ANALOG POSITIONER OPTION: (1-phase only)

CONTROLS Inching/Positioning • Input (setpoint) and output (feedback) signals are fully isolated from
control each other
• Input signal: 4-20 mA - output signal: 4-20mA (4=closed; 20=open)

Easy and quick setting of position and torque camblocks with a standard
Actuator on valve settings screwdriver
BERNARD CONTROLS new mobile application is available as standard.
SETTINGS BERNARD CONTROLS mobile interface allows the user to:
Application for mobile • Access to the documentation relative to the selected actuator (enter the
device Serial number) or scan the QR code on the nameplate of the actuator
• Access to BERNARD CONTROLS contact information according to the area
concerned
AQ actuators comply with:
• directive 2004/108/EC Electromagnetic compatibility
• directive 2006/95/EC Low voltage
CONFORMITY TO Compliance with EC • the following harmonised standards: EN 61000- 6-4: Generic emissions
EC DIRECTIVES Directives standard for industrial environments; EN 61000-6-2: Generic immunity
standard for industrial environments; EN 60034-1: Rotating electrical
machines; EN 60529: Degrees of protection provided by enclosures (IP
ratings code)
2/2

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 AQ LOGIC
PRODUCT SPECIFICATIONS
All AQ actuators include motor with thermal protection, gear case,
emergency handwheel, position sensor, torque sensor (for torque>150Nm),
output drive with removable socket and anti-condensation heater.
Description AQ LOGIC models also include:
• integrated controls
• built-in motor reversing starters
• local commands with large LCD display

GENERAL Direct: 50 to 1000 N.m

Torque range
Up to 10 000 N.m with Gearbox

Adapted to process requirements:

• On-Off: Class A actuators complying with EN15714-2
• Inching/Positioning: Class B actuators complying with EN15714-2
Duty Classification
• Modulating: Class III actuators with higheR duty performance and
specification of additional performance criteria compared to EN15714-2
Class C basic design requirements

• Aluminium die casting

Casing
• Cover fastened by captive and stainless screws

• Type: Epoxy powder coating as standard

External Protection • Protection: C4 according to ISO 12944
• For colors and finishes, please consult us

IP68
ENCLOSURE -
Weatherproofness NEMA 4X as standard
PROTECTION Hygrométrie: 0 to 95%.

• -20…+70°C / -4 ... +158°F

Ambient
• -40°C (-40°F) as an option
temperature range Other temperatures, please consult us

1g (9.8 m/s²) at 10-200 Hz.

Vibration resistance
Contact our sales teams for higher vibration levels

• 3-phase or single-phase asynchronous motor, Class F insulation with

Motor technology integral thermal overload protection
• DC motors

• On/Off operation (complying with EN15714-2 Class A) and Inching/

MOTOR Positioning (complying with EN15714-2 Class B): S4-30% motor duty
rating. Up to 360 starts per hour at peak of operation. S4-50% as an
Motor duty rating option.
• BC Modulating Class III (complying with EN15714- 2 Class C): S4-50%
motor duty rating. Up to 1 200 starts per hour at peak of operation.
(Voltage ±10%, frequency ±2%)

Gear design The gear are mechanically self-locking

• Manual override handwheel

Manual emergency operation
MECHANICAL • Automatic declutch
SPECIFICATIONS Output flange Actuator flanges comply with ISO 5211.

The actuators are lubricated for the product lifetime and do not require
Lubrication
any special service.

The actuators can operate on a wide variety of power supplies:

Power supply • 3-phase , single-phase or DC (except AQ80 to AQ1000)
• 50 or 60 Hz …

Screw-type terminals for controls and power supply. Internal earth

ELECTRICAL Terminal compartment
grounding post
SPECIFICATIONS
Primary: 0,5A-500V
Fuse protection
Secondary: Two automatic resettable fuses

Conduit entries 3 x M20 + 2 x M16 (or 3 x 3/4’’ NPT + 2 x 1/2’’ NPT)

• Position: reading on the output shaft

Travel limit systems
• Position sensor: Absolute encoder (Hall effect sensor)

POSITION & • Torque limitation available from AQ25

TORQUE SENSORS • Absolute encoder sensor (Hall effect sensor)
Torque limiting system • The torque limiting system is calibrated in factory. It remains adjustable
via LOGIC (non intrusive setting)
• Non intrusive setting: Adjustable torque from 40 to 100% of rated torque

1/3

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 AQ LOGIC
PRODUCT SPECIFICATIONS
POSITION & Analog Transmitter In current: maximum acceptable load of 600 Ohms (24VDC), must be
supplied (12 to 32VDC) 2-wire or 3-wire connection
TORQUE SENSORS (option)

• Maintained or pulse command (minimum pulse duration: 100ms)

• Command by dry contacts
Remote Command
• Command by voltage from 10 to 250 VDC
• Isolated by opto-couplers

Visual position indication Mechanical position indicator

• 2 buttons + 1 padlockable selector

Local command • A large LCD screen to display the position, the torque and alarms and to
description perform the settings
• Green/Red: Configurable LED for CLOSED/OPEN

Power circuit Motor reversing starters

Auxiliary power supply With external 24VDC supply

• 3 latching relays
- Contact configuration: normally open or
normally closed
- Minimum current 10mA at 5V
- Maximum current 5A at 250V or 5A at
Signaling relay
30VDC (resistive load)
CONTROLS Relay 1: Valve open
Relay 2: Valve closed
Relay 3: Configurable relay
• Additional 4 relays board as an option

• SPDT non-latching relay, in fault position when not supplied.

Fault relay • Minimum current 10mA at 5V
• Maximum current 5A at 250VAC or 5A at 30VDC (resistive load)

LOGIC Analog Positioner:

Signal configurations (with integrated analogue output):
• Standard input signal: 4-20 mA - output signal: 4-20mA
• Input signal: 0-20 mA - output signal: 0-20 mA
• Input signal: 0-10 V - output signal: 0-20 mA
Inching/Positioning & Modulating
Analogue Input:
control (option) - in current: impedance of 260 Ohms
- In voltage: impedance of 10 kOhms
Analogue Output:
- In current: maximum acceptable load of 600 Ohms (24VDC), must be
supplied (12 to 32VDC) 2-wire or 3-wire connection
This function enables an increase in the operating time of the actuator, i.e.
Timer to avoid water-hammer effect in a pipe. Travel time can be programmed
independently in both opening and closing directions.
Non-Intrusive settings
All actuator settings and parameters are stored in a non-volatile EEPROM
memory. Protection by password.
Settings
Configurable via Local control; Bluetooth available as standard (to keep
a high level of security, Bluetooth range is limited to 10m. With BC App,
communication is encrypted and access is restricted with password.)
The LOGIC can be fully set via its local display and selectors. Does not
Local settings require any specific setting tool. Optionnal padlockable protection against
sandy winds & vandalism.
New BERNARD CONTROLS mobile application is available as standard, with
its bluetooth secured communication interface, and allows the user to:
• Assistance to commissioning on valve
SETTINGS • Simply set every parameters of the actuator (non-intrusive setting)
• Command the actuator (open/close/stop) as a local controls
• Check at a glance an overview of the feedbacks information which are
displayed on a large color screen of the mobile
Application for mobile • Assistance to curative maintenance with a simple and efficient
device troubleshooting
• Access to BERNARD CONTROLS contact information according to the area
concerned
• Access to the documentation relative to the selected and scanned
actuator
• Customize the actuator display
• Log the Systems Alarms and Warnings
...
2/3

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 AQ LOGIC
PRODUCT SPECIFICATIONS
• Duplicate one actuator configuration to another actuator
• Check the actuator life operation
Application for mobile
SETTINGS • Select the suitable language among 14 available languages
device • Identify the actuator operated valve by its valve tag and location process
• Track the last user connexions for traceability and safety reasons

Available Fieldbus • PROFIBUS-DPV1

FIELDBUS • MODBUS RTU
protocols (option)
AQ actuators comply with:
• directive 2004/108/EC Electromagnetic compatibility
• directive 2006/95/EC Low voltage
CONFORMITY TO Compliance with EC • the following harmonised standards:
EC DIRECTIVES Directives EN 61000-6-4: Generic emissions standard for industrial environments;
EN 61000-6-2: Generic immunity standard for industrial environments;
EN 60034-1: Rotating electrical machines; EN 60529: Degrees of
protection provided by enclosures (IP ratings code)
3/3

Notes

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 Product selection

AQ0050 DE 035 S A 0 0 0 E 0 M

Connection Type
M=Metric
I=Imperial NPT

Output Flange
0=Standard Flange
A=Optional F05
B=Optional F10
C=Optional F12
D=Optional F14
E=Optional F16
F=Optional F20
G=Optional F25

Certification
E=EC Standard
L=EC Low Temperature
C=CSA (Low Temperature)
R=EAC (Low Temperature)

Fieldbus Options
0=Without; P=Profibus DP Single;
M=Modbus RTU

LOGIC Options
0=Without; 1=RS4

Analog Signals Options

0=Without; 1=Analog Transmitter (Output Signal);
2=Analog Positioner1; 3= POT

Duty & Modulating Classification

A=Class A; B=Class B; 3=Class III

Control Type
S=SWITCH, P=SWITCH Prewired, L=LOGIC

Operating time (sec)

Voltage
DE=Direct Current 24V ; FB=1Ph 220-230V 50/60Hz ; FC=1Ph 115-120V 50/60Hz ;
TA=3Ph 380-415V 50Hz ; UJ=3Ph 440-480V 60Hz

Actuator Type

1
: single-phase only

4 rue d’Arsonval - CS 70091 - 95505 Gonesse CEDEX France - Tel. : +33 (0)1 34 07 71 00 - Fax : +33 (0)1 07 71 01 - [email protected] - www.bernardcontrols.com
 Open up! E L E C T R I C A C T U AT O R S S P E C I A L I S T
SCANN THE QR CODE

Solutions Overview
& WATCH

NEW RANGES OF ACTUATORS NEW MOBILE APPLICATION BC APP BCAPP VIDEO HERE

The only application that allows not only to set up your actuator in a few clicks, but
AQ, AQL, AQXL, AT & BT also to improve the reliability of your process thanks to key features and data for
preventive maintenance. Compatible with our new controls: LOGIC (v2) & INTELLI+® (v3)

W E AT H E R P R O O F R A N G E S W E AT H E R P R O O F R A N G E S EXPLOSIONPROOF RANGES
Quarter-turn & Multi-turn SQX & STX RANGES
• SQX: 80 to 800 Nm (direct) & up to 1,000,000 Nm on request
• STX: 25 to 2,200 Nm (direct) & up to 20,000 Nm on request
EW

Quarter-turn AQL RANGE

N

• Compliance with international explosionproof standards:

• 15 to 70 Nm (direct mount)
The dedicated solutions FLEXIBLE
ATEX, INMETRO, IEC-Ex, EAC-Ex, NEMA 7 & 9...
& • Type of Controls: > Electromechanical SWITCH
• Type of Controls: > Electromechanical SWITCH
MODULAR > Hardwired
• BC Duty & Modulating Classification

EW
> Smart INTELLI+® (v2)

N
ULTRA Multi-turn BT RANGE > SIL2
COMPACT
On-Off A Inching B
Positioning • 30 to 500 Nm (direct mount) | Up to 32,000 Nm on request • BC Duty & Modulating Classification
On-Off A+ Inching B+ Modulating III
• Environment: • 10 to 127 rpm (direct mount) & high speed: up to 180 rpm (direct) Positioning
> IP 68 / C4 (High paint protection option C5) • Type of Controls: > Smart INTELLI+®(v3) • Environment: IP 68 / C3 up to C5-M / T: -20°C ...+70°C (low T° option: -60°C)
> T: -20°C ...+60°C COMPACT • Wiring: Double-sealing as standard • Special configurations: Corrosion protection, Fire proofing, Extreme temperatures
&
COMPLETE > New terminal plate with pins for easy wiring
FA I LS A F E R A N G E S
EW

Quarter-turn AQ RANGE
N

> Quick Connector

Quarter-turn Failsafe Actuators FQ RANGE
• 50 to 10,000 Nm (up to 1000 Nm direct mount) • Advanced BC Duty & Modulating Classification
Fast and shock-free reliable spring-return technology during emergency operation
Up to 1,000,000 Nm on request • BC Duty & Modulating Classification
On-Off A+ Inching B+ Modulating III+
• Type of Controls: > Electromechanical SWITCH Positioning
COMPACT On-Off A Inching B Modulating III
& > Smart LOGIC (v2) Positioning
SMART
• BC Duty & Modulating Classification • Environment: > IP 68 / C4 ( High paint protection option C5) • Environment: IP 67 / C3 / T: -20°C ...+70°C (low T° option -40°C)
On-Off A Inching B Modulating III > T: -20°C ...+70°C Low T° (Low T° option -40°C) Failsafe Actuators FQX RANGE
Positioning • Linear applications
• Explosionproof versions ATEX-NEMA
• Environment:
> IP 68 / C4 (High paint protection option C5) SPECIAL REQUESTS Quarter-turn & Linear Failsafe FSeX RANGE
> T: -20°C ...+70°C (Low T° option -40°C) The complete combination of modern electrics and power of hydraulics
Quarter-turn SQ RANGE • BC Duty & Modulating Classification
EW

Multi-turn AT RANGE • 45 to 10,000 Nm (up to 800 Nm direct mount) | Up to 1,000,000 Nm on request
N

On-Off A Inching B Modulating III

• With type of Controls: > Smart INTELLI+®(v2) With Fieldbus Redundant ... Positioning
• 30 to 500 Nm (direct mount) | Up to 32,000 Nm on request > SIL2 • Environment: IP 67 / C4 / T: -20°C ...+60°C
• 10 to 127 rpm (direct mount) • Wiring: Double-sealing with INTELLI+ • ATEX-NEMA, SIL3
• Type of Controls: > Electromechanical SWITCH
COMPACT > Smart LOGIC (v2)
& NUCLEAR RANGES
SMART • Wiring: > Screw Type Terminal
• BC Duty & Modulating Classification Multi-turn ST RANGE Nuclear classified Actuators
On-Off A Inching B Modulating III • 60 to 2,200 Nm (direct mount) | up to 20,000 Nm on request
Positioning • SQN & ST & SN &SD Nuclear qualified electric actuators
•10 to 120 rpm (direct mount) | High speed: up to 190 rpm (direct & <300Nm)
+ Full range of other Qualified Solutions: Quarter-turn,
• Environment: > IP 68 / C4 ( High paint protection option C5) • With type of Controls: > Smart INTELLI+®(v2) With Fieldbus Redundant ...
FLEXIBLE Multi-turn and Linear for inside & outside containment
& > SIL2
> T: -20°C ...+70°C (Low T° option -40°C) applications; Failsafe actuators
MODULAR
• Linear applications

EXPLOSIONPROOF RANGES
EW

Quarter-turn AQXL RANGE

N

• 40 Nm and 70 Nm
• Compliance with international explosionproof standards: ATEX, IEC-Ex, CUSTOMIZED DESIGN & PROJECTS: NEW GENERATION OF SMART CONTROLS
ULTRA NEMA 7...
COMPACT
At any time and anywhere on the globe, BERNARD

EW

EW
• Type of Controls: > Electromechanical SWITCH

N
CONTROLS teams are available for dedicated
• BC Duty & Modulating Classification support. From the design stage to installation, LOGIC (v2) INTELLI+® (v3)
commissioning, maintenance and training,
On-Off A Inching B our experts help you to define and implement The main functions you Advanced control
Positioning the most appropriate solution to your specific
needs thanks to our local R&D centers, test
expect from modern solution for your
• Environment: IP 68 / C4 ( C5 on request) / T: -20°C ...+60°C integrated controls critical applications!
labs, calculation tools and training center.
• Linear applications
B E R N A R D C O N T R O L S G R O U P

CORPORATE HEADQUARTERS
4 rue d’Arsonval - CS 70091 / 95505 Gonesse CEDEX France / Tel. : +33 (0)1 34 07 71 00 / Fax : +33 (0)1 34 07 71 01 / [email protected]

CONTACT BY OPERATING AREAS

> AMERICAS > EUROPE UNITED KINGDOM

BERNARD CONTROLS UNITED KINGDOM
NORTH AMERICA BELGIUM [email protected]
BERNARD CONTROLS UNITED STATES BERNARD CONTROLS BENELUX Tel. +44 (0)7435 266310
HOUSTON NIVELLES (BRUSSELS)
[email protected]
[email protected]
[email protected] > INDIA, MIDDLE EAST & AFRICA
Tel. +1 281 578 66 66 Tel. +32 (0)2 343 41 22
SOUTH AMERICA AFRICA
FRANCE BERNARD CONTROLS AFRICA
BERNARD CONTROLS LATIN AMERICA BERNARD CONTROLS FRANCE & ABIDJAN - IVORY COAST
[email protected] BERNARD CONTROLS NUCLEAR FRANCE [email protected]
Tel. +1 281 578 66 66 GONESSE (PARIS) Tel. + 225 21 34 07 82
[email protected]
Tel. +33 (0)1 34 07 71 00 INDIA
BERNARD CONTROLS INDIA
> ASIA GERMANY [email protected]
BERNARD CONTROLS DEUFRA Tel. +971 4 880 0660
CHINA TROISDORF (KÖLN)
BERNARD CONTROLS CHINA & [email protected] MIDDLE-EAST
BERNARD CONTROLS CHINA NUCLEAR Tel. +49 2241 9834 0 BERNARD CONTROLS MIDDLE-EAST
BEIJING DUBAI - U.A.E.
ITALY [email protected]
[email protected] BERNARD CONTROLS ITALIA
Tel. +86 (0) 10 6789 2861 Tel. +971 4 880 0660
RHO (MILANO)
[email protected]
KOREA

This document and the contents here of are proprietary to Bernard Controls. It can be amended
Tel. +39 02 931 85 233
BERNARD CONTROLS KOREA
SEOUL RUSSIA

and changed without prior notice. Any unauthorized reproduction is strictly prohibited.
[email protected] BERNARD CONTROLS RUSSIA
Tel. +82 (0)2 2183 6226 [email protected]
Tel. +33 (0)1 34 07 71 00
SINGAPORE
SPAIN
BERNARD CONTROLS SINGAPORE BERNARD CONTROLS SPAIN
SINGAPORE MADRID
[email protected] [email protected]
Tel. +65 65 654 227 Tel. +34 91 30 41 139

More than 50 agents and distributors worldwide. Contact details on www.bernardcontrols.com

BROCHURE_AQ_ENG_GRP_rev01C
