Siemens S7 Plus Ethernet Driver

Help version 1.037

CONTENTS

Overview
What is the Siemens S7 Plus Ethernet Driver?

Optimizing Communications
How do I get the best performance from the driver?

Data Types Description

What data types does this driver support?

Address Descriptions
How do I address a data location on a Siemens device?

Event Log Messages

What messages does the Siemens S7 Plus Ethernet Driver produce?

www. ptc.com
5 Siemens S7 Plus Ethernet Driver

Overview
The Siemens S7 Plus Ethernet Driver provides a reliable way to connect Siemens Ethernet devices to OPC cli-
ent applications, including HMI, SCADA, Historian, MES, ERP, and countless custom applications. It is inten-
ded for use with Siemens S7 1200 and 1500 PLCs supporting symbolic addressing and provides access to
optimized blocks.

The driver requires no additional libraries or hardware. A standard Ethernet card is needed.

www. ptc.com
Siemens S7 Plus Ethernet Driver 6

Setup
This section contains setup information for connecting to the S7-1200 and S7-1500 controllers.

Communication Protocol
S7 Comm Plus

Supported Devices
Device must support symbolic addressing.

l S7-1200
l S7-1500

These devices have a built-in Ethernet module.

The supported devices support the following firmware versions:

Kepware Release S7-1200 S7-1500

FW 3.0.x, 2.9.x, 2.8.1, 2.6, 2.5, SPS 2.0,
6.14 FW 4.6, 4.5, 4.4, 4.2.1, SPS 4.2
<1.7

6.11 - 6.13 FW 4.5, 4.4, 4.2.1, SPS 4.2 FW 2.9.2, 2.8.1, 2.6, 2.5, SPS 2.0, <1.7

Security Protocols
OpenSSL Version 3.0.8
TLS Version 1.2.1.4

Channel and Device Limits

The maximum number of channels supported by this driver is 256. The maximum number of devices sup-
ported by this driver is 16 per channel.

See Also: Channel Properties, Device Properties, Appendix — Siemens and Media-Level Redundancy Sup-
port, and the support Knowledge Base for the article about Migrating from Siemens TCP/IP to Siemens S7 Plus.

www. ptc.com
7 Siemens S7 Plus Ethernet Driver

Channel Properties — General

This server supports the use of simultaneous multiple communications drivers. Each protocol or driver used
in a server project is called a channel. A server project may consist of many channels with the same com-
munications driver or with unique communications drivers. A channel acts as the basic building block of an
OPC link. This group is used to specify general channel properties, such as the identification attributes and
operating mode.

Identification

Name: User-defined identity of this channel. In each server project, each channel name must be unique.
Although names can be up to 256 characters, some client applications have a limited display window when
browsing the OPC server's tag space. The channel name is part of the OPC browser information. The prop-
erty is required for creating a channel.
For information on reserved characters, refer to "How To... Properly Name a Channel, Device, Tag, and Tag
Group" in the server help.

Description: User-defined information about this channel.

Many of these properties, including Description, have an associated system tag.

Driver: Selected protocol / driver for this channel. This property specifies the device driver that was selected
during channel creation. It is a disabled setting in the channel properties. The property is required for cre-
ating a channel.
Note: With the server's online full-time operation, these properties can be changed at any time. This
includes changing the channel name to prevent clients from registering data with the server. If a client has
already acquired an item from the server before the channel name is changed, the items are unaffected. If,
after the channel name has been changed, the client application releases the item and attempts to re-
acquire using the old channel name, the item is not accepted. With this in mind, changes to the properties
should not be made once a large client application has been developed. Utilize the User Manager to prevent
operators from changing properties and restrict access rights to server features.

Diagnostics

Diagnostics Capture: When enabled, this option makes the channel's diagnostic information available to
OPC applications. Because the server's diagnostic features require a minimal amount of overhead pro-
cessing, it is recommended that they be utilized when needed and disabled when not. The default is dis-
abled.
Note: This property is not available if the driver does not support diagnostics.
For more information, refer to "Communication Diagnostics" and "Statistics Tags" in the server help.

Note: View the diagnostic information for this driver in ASCII.

www. ptc.com
Siemens S7 Plus Ethernet Driver 8

Channel Properties — Ethernet Communications

Ethernet Communication can be used to communicate with devices.

Ethernet Settings

Network Adapter: Specify the network adapter to bind. When left blank or Default is selected, the oper-
ating system selects the default adapter.

Channel Properties — Write Optimizations

The server must ensure that the data written from the client application gets to the device on time. Given
this goal, the server provides optimization properties to meet specific needs or improve application respons-
iveness.

Write Optimizations

Optimization Method: Controls how write data is passed to the underlying communications driver. The
options are:

l Write All Values for All Tags: This option forces the server to attempt to write every value to the
controller. In this mode, the server continues to gather write requests and add them to the server's
internal write queue. The server processes the write queue and attempts to empty it by writing data
to the device as quickly as possible. This mode ensures that everything written from the client applic-
ations is sent to the target device. This mode should be selected if the write operation order or the
write item's content must uniquely be seen at the target device.
l Write Only Latest Value for Non-Boolean Tags: Many consecutive writes to the same value can
accumulate in the write queue due to the time required to actually send the data to the device. If the
server updates a write value that has already been placed in the write queue, far fewer writes are
needed to reach the same final output value. In this way, no extra writes accumulate in the server's
queue. When the user stops moving the slide switch, the value in the device is at the correct value at
virtually the same time. As the mode states, any value that is not a Boolean value is updated in the
server's internal write queue and sent to the device at the next possible opportunity. This can greatly
improve the application performance.
Note: This option does not attempt to optimize writes to Boolean values. It allows users to optim-
ize the operation of HMI data without causing problems with Boolean operations, such as a moment-
ary push button.
l Write Only Latest Value for All Tags: This option takes the theory behind the second optimization
mode and applies it to all tags. It is especially useful if the application only needs to send the latest

www. ptc.com
9 Siemens S7 Plus Ethernet Driver

value to the device. This mode optimizes all writes by updating the tags currently in the write queue
before they are sent. This is the default mode.

Duty Cycle: is used to control the ratio of write to read operations. The ratio is always based on one read
for every one to ten writes. The duty cycle is set to ten by default, meaning that ten writes occur for each
read operation. Although the application is performing a large number of continuous writes, it must be
ensured that read data is still given time to process. A setting of one results in one read operation for every
write operation. If there are no write operations to perform, reads are processed continuously. This allows
optimization for applications with continuous writes versus a more balanced back and forth data flow.
Note: It is recommended that the application be characterized for compatibility with the write optim-
ization enhancements before being used in a production environment.

Channel Properties — Advanced

This group is used to specify advanced channel properties. Not all drivers support all properties; so the
Advanced group does not appear for those devices.

Non-Normalized Float Handling: A non-normalized value is defined as Infinity, Not-a-Number (NaN), or as

a Denormalized Number. The default is Replace with Zero. Drivers that have native float handling may
default to Unmodified. Non-normalized float handling allows users to specify how a driver handles non-nor-
malized IEEE-754 floating point data. Descriptions of the options are as follows:

l Replace with Zero: This option allows a driver to replace non-normalized IEEE-754 floating point val-
ues with zero before being transferred to clients.
l Unmodified: This option allows a driver to transfer IEEE-754 denormalized, normalized, non-num-
ber, and infinity values to clients without any conversion or changes.

Note: This property is disabled if the driver does not support floating-point values or if it only supports
the option that is displayed. According to the channel's float normalization setting, only real-time driver tags
(such as values and arrays) are subject to float normalization. For example, EFM data is not affected by this
setting.

For more information on the floating-point values, refer to "How To ... Work with Non-Normalized Floating-Point
Values" in the server help.

Inter-Device Delay: Specify the amount of time the communications channel waits to send new requests to
the next device after data is received from the current device on the same channel. Zero (0) disables the
delay.

Note: This property is not available for all drivers, models, and dependent settings.

www. ptc.com
Siemens S7 Plus Ethernet Driver 10

Device Properties — General

A device represents a single target on a communications channel.

Identification

Name: Specify the name of the device. It is a logical user-defined name that can be up to 256 characters
long and may be used on multiple channels.
Note: Although descriptive names are generally a good idea, some OPC client applications may have a
limited display window when browsing the OPC server's tag space. The device name and channel name
become part of the browse tree information as well. Within an OPC client, the combination of channel name
and device name would appear as "ChannelName.DeviceName".
For more information, refer to "How To... Properly Name a Channel, Device, Tag, and Tag Group" in server help.

Description: Specify the user-defined information about this device.

Many of these properties, including Description, have an associated system tag.

Channel Assignment: Specify the user-defined name of the channel to which this device currently belongs.

Driver: Selected protocol driver for this device.

Model: The driver automatically detects the model.

ID: Specify the device's driver-specific station or node. The type of ID entered depends on the com-
munications driver being used. For many communication drivers, the ID is a numeric value. Drivers that sup-
port a Numeric ID provide users with the option to enter a numeric value whose format can be changed to
suit the needs of the application or the characteristics of the selected communications driver. The format is
set by the driver by default. Options include Decimal, Octal, and Hexadecimal.
Notes:

l If the driver is Ethernet-based or supports an unconventional station or node name, the device's
TCP/IP address may be used as the device ID. TCP/IP addresses consist of four values that are sep-
arated by periods, with each value in the range of 0 to 255. Some device IDs are string based. There
may be additional properties to configure within the ID field, depending on the driver. For more
information, refer to the driver's help documentation.
l The ID for this driver is a string representing the unique network address of the PLC, typically in the
format of an IP address or a configured host name. Maximum length of this string is 63 characters.

www. ptc.com
11 Siemens S7 Plus Ethernet Driver

Operating Mode

Data Collection: This property controls the device's active state. Although device communications are
enabled by default, this property can be used to disable a physical device. Communications are not attemp-
ted when a device is disabled. From a client standpoint, the data is marked as invalid and write operations
are not accepted. This property can be changed at any time through this property or the device system tags.

Simulated: Place the device into or out of Simulation Mode. In this mode, the driver does not attempt to
communicate with the physical device, but the server continues to return valid OPC data. Simulated stops
physical communications with the device, but allows OPC data to be returned to the OPC client as valid data.
While in Simulation Mode, the server treats all device data as reflective: whatever is written to the simulated
device is read back and each OPC item is treated individually. The item's memory map is based on the
group Update Rate. The data is not saved if the server removes the item (such as when the server is rein-
itialized). The default is No.
Notes:

1. This System tag (_Simulated) is read only and cannot be written to for runtime protection. The Sys-
tem tag allows this property to be monitored from the client.

2. In Simulation mode, the item's memory map is based on client update rate(s) (Group Update Rate
for OPC clients or Scan Rate for native and DDE interfaces). This means that two clients that ref-
erence the same item with different update rates return different data.

Simulation Mode is for test and simulation purposes only. It should never be used in a production envir-
onment.

Tag Counts

Static Tags: Provides the total number of defined static tags at this level (device or channel). This inform-
ation can be helpful in troubleshooting and load balancing.

Device Properties — Scan Mode

The Scan Mode specifies the subscribed-client requested scan rate for tags that require device com-
munications. Synchronous and asynchronous device reads and writes are processed as soon as possible;
unaffected by the Scan Mode properties.

Scan Mode: Specify how tags in the device are scanned for updates sent to subscribing clients. Descriptions
of the options are:

l Respect Client-Specified Scan Rate: This mode uses the scan rate requested by the client.
l Request Data No Faster than Scan Rate: This mode specifies the value set as the maximum scan
rate. The valid range is 10 to 99999990 milliseconds. The default is 1000 milliseconds.
Note: When the server has an active client and items for the device and the scan rate value is
increased, the changes take effect immediately. When the scan rate value is decreased, the changes
do not take effect until all client applications have been disconnected.

www. ptc.com
Siemens S7 Plus Ethernet Driver 12

l Request All Data at Scan Rate: This mode forces tags to be scanned at the specified rate for sub-
scribed clients. The valid range is 10 to 99999990 milliseconds. The default is 1000 milliseconds.
l Do Not Scan, Demand Poll Only: This mode does not periodically poll tags that belong to the
device nor perform a read to get an item's initial value once it becomes active. It is the OPC client's
responsibility to poll for updates, either by writing to the _DemandPoll tag or by issuing explicit
device reads for individual items. For more information, refer to "Device Demand Poll" in server help.
l Respect Tag-Specified Scan Rate: This mode forces static tags to be scanned at the rate specified
in their static configuration tag properties. Dynamic tags are scanned at the client-specified scan
rate.

Initial Updates from Cache: When enabled, this option allows the server to provide the first updates for
newly activated tag references from stored (cached) data. Cache updates can only be provided when the
new item reference shares the same address, scan rate, data type, client access, and scaling properties. A
device read is used for the initial update for the first client reference only. The default is disabled; any time a
client activates a tag reference the server attempts to read the initial value from the device.

Device Properties — Timing

The device Timing properties allow the driver's response to error conditions to be tailored to fit the applic-
ation's needs. In many cases, the environment requires changes to these properties for optimum per-
formance. Factors such as electrically generated noise, modem delays, and poor physical connections can
influence how many errors or timeouts a communications driver encounters. Timing properties are specific
to each configured device.

Communications Timeouts

Connect Timeout: This property (which is used primarily by Ethernet based drivers) controls the amount
of time required to establish a socket connection to a remote device. The device's connection time often
takes longer than normal communications requests to that same device. The valid range is 1 to 30 seconds.
The default is typically 3 seconds, but can vary depending on the driver's specific nature. If this setting is not
supported by the driver, it is disabled.
Note: Due to the nature of UDP connections, the connection timeout setting is not applicable when com-
municating via UDP.

Request Timeout: Specify an interval used by all drivers to determine how long the driver waits for a
response from the target device to complete. The valid range is 50 to 9999 milliseconds (167 minutes). The
default is usually 1000 milliseconds, but can vary depending on the driver. The default timeout for most
serial drivers is based on a baud rate of 9600 baud or better. When using a driver at lower baud rates,
increase the timeout to compensate for the increased time required to acquire data.

Attempts Before Timeout: Specify how many times the driver issues a communications request before
considering the request to have failed and the device to be in error. The valid range is 1 to 10. The default is
typically 3, but can vary depending on the driver's specific nature. The number of attempts configured for
an application depends largely on the communications environment. This property applies to both con-
nection attempts and request attempts.

www. ptc.com
13 Siemens S7 Plus Ethernet Driver

Device Properties — Auto-Demotion

The Auto-Demotion properties can temporarily place a device off-scan in the event that a device is not
responding. By placing a non-responsive device offline for a specific time period, the driver can continue to
optimize its communications with other devices on the same channel. After the time period has been
reached, the driver re-attempts to communicate with the non-responsive device. If the device is responsive,
the device is placed on-scan; otherwise, it restarts its off-scan time period.

Demote on Failure: When enabled, the device is automatically taken off-scan until it is responding again.
Tip: Determine when a device is off-scan by monitoring its demoted state using the _AutoDemoted sys-
tem tag.

Timeouts to Demote: Specify how many successive cycles of request timeouts and retries occur before the
device is placed off-scan. The valid range is 1 to 30 successive failures. The default is 3.

Demotion Period: Indicate how long the device should be placed off-scan when the timeouts value is
reached. During this period, no read requests are sent to the device and all data associated with the read
requests are set to bad quality. When this period expires, the driver places the device on-scan and allows for
another attempt at communications. The valid range is 100 to 3600000 milliseconds. The default is 10000
milliseconds.

Discard Requests when Demoted: Select whether or not write requests should be attempted during the
off-scan period. Disable to always send write requests regardless of the demotion period. Enable to discard
writes; the server automatically fails any write request received from a client and does not post a message
to the Event Log.

Device Properties — Tag Generation

The automatic tag database generation features make setting up an application a plug-and-play operation.
Select communications drivers can be configured to automatically build a list of tags that correspond to
device-specific data. These automatically generated tags (which depend on the nature of the supporting
driver) can be browsed from the clients.

Not all devices and drivers support full automatic tag database generation and not all support the same data
types. Consult the data types descriptions or the supported data type lists for each driver for specifics.

If the target device supports its own local tag database, the driver reads the device's tag information and
uses the data to generate tags within the server. If the device does not natively support named tags, the
driver creates a list of tags based on driver-specific information. An example of these two conditions is as fol-
lows:

1. If a data acquisition system supports its own local tag database, the communications driver uses the
tag names found in the device to build the server's tags.

www. ptc.com
Siemens S7 Plus Ethernet Driver 14

2. If an Ethernet I/O system supports detection of its own available I/O module types, the com-
munications driver automatically generates tags in the server that are based on the types of I/O mod-
ules plugged into the Ethernet I/O rack.

Note: Automatic tag database generation's mode of operation is completely configurable. For more
information, refer to the property descriptions below.

On Property Change: If the device supports automatic tag generation when certain properties change, the
On Property Change option is shown. It is set to Yes by default, but it can be set to No to control over
when tag generation is performed. In this case, the Create tags action must be manually invoked to per-
form tag generation.

On Device Startup: Specify when OPC tags are automatically generated. Descriptions of the options are as
follows:

l Do Not Generate on Startup: This option prevents the driver from adding any OPC tags to the tag
space of the server. This is the default setting.
l Always Generate on Startup: This option causes the driver to evaluate the device for tag inform-
ation. It also adds tags to the tag space of the server every time the server is launched.
l Generate on First Startup: This option causes the driver to evaluate the target device for tag
information the first time the project is run. It also adds any OPC tags to the server tag space as
needed.

Note: When the option to automatically generate OPC tags is selected, any tags that are added to the
server's tag space must be saved with the project. Users can configure the project to automatically save
from the Tools | Options menu.

On Duplicate Tag: When automatic tag database generation is enabled, the server needs to know what to
do with the tags that it may have previously added or with tags that have been added or modified after the
communications driver since their original creation. This setting controls how the server handles OPC tags
that were automatically generated and currently exist in the project. It also prevents automatically gen-
erated tags from accumulating in the server.

For example, if a user changes the I/O modules in the rack with the server configured to Always Generate
on Startup, new tags would be added to the server every time the communications driver detected a new
I/O module. If the old tags were not removed, many unused tags could accumulate in the server's tag space.
The options are:

l Delete on Create: This option deletes any tags that were previously added to the tag space before
any new tags are added. This is the default setting.
l Overwrite as Necessary: This option instructs the server to only remove the tags that the com-
munications driver is replacing with new tags. Any tags that are not being overwritten remain in the
server's tag space.

www. ptc.com
15 Siemens S7 Plus Ethernet Driver

l Do not Overwrite: This option prevents the server from removing any tags that were previously
generated or already existed in the server. The communications driver can only add tags that are
completely new.
l Do not Overwrite, Log Error: This option has the same effect as the prior option, and also posts an
error message to the server's Event Log when a tag overwrite would have occurred.

Note: Removing OPC tags affects tags that have been automatically generated by the com-
munications driver as well as any tags that have been added using names that match generated tags.
Users should avoid adding tags to the server using names that may match tags that are automatically
generated by the driver.

Parent Group: This property keeps automatically generated tags from mixing with tags that have been
entered manually by specifying a group to be used for automatically generated tags. The name of the group
can be up to 256 characters. This parent group provides a root branch to which all automatically generated
tags are added.

Allow Automatically Generated Subgroups: This property controls whether the server automatically cre-
ates subgroups for the automatically generated tags. This is the default setting. If disabled, the server gen-
erates the device's tags in a flat list without any grouping. In the server project, the resulting tags are named
with the address value. For example, the tag names are not retained during the generation process.
Note: If, as the server is generating tags, a tag is assigned the same name as an existing tag, the system
automatically increments to the next highest number so that the tag name is not duplicated. For example, if
the generation process creates a tag named "AI22" that already exists, it creates the tag as "AI23" instead.

Create: Initiates the creation of automatically generated OPC tags. If the device's configuration has been
modified, Create tags forces the driver to reevaluate the device for possible tag changes. Its ability to be
accessed from the System tags allows a client application to initiate tag database creation.
Note: Create tags is disabled if the Configuration edits a project offline.

Notes:

1. This driver replaces any backslash in a group name with an underscore.

2. Tags are generated only when all three HMI properties (Accessible, Writable, and Visible) are enabled
or both Accessible and Visible are enabled in the TIA Portal programming software. Those Properties
are:
l Accessible from HMI/OPC UA/Web API.

l Writable from HMI/OPC UA/Web API.

l Visible in HMI Engineering

3. Symbols are reloaded from the controller on each attempt to generate tags.

4. Some Siemens data types are not supported by the driver. No tag is generated for those nodes. An
event log message is posted to warn of nodes with no tag. No message is reported for structures not
supported in a single tag.

www. ptc.com
Siemens S7 Plus Ethernet Driver 16

Device Properties — Communications

If a protection-level password is configured in the PLC, the PLC Password property should be configured
with a password that allows at least read access.
See the PLC programming software for more details on configuring access levels.

Communications

Port Number: Specify the TCP/IP port number configured for the device. The valid range is 1 to 65535. The
default is 102.
Tip: It is recommended that the default port be used for most applications, where the server and the PLC
exist on the same network. For an application using the Internet through firewalls and advanced routers,
the port number can be changed to allow these operations to occur. In most cases, however, the PLC only
accepts a connection on port 102 and may require router forwarding.

Security

PLC Password: Specify the password for the required access level configured in the PLC. The maximum
length supported for a password is 256 characters. Wide characters are supported.

Secure Communications: Specify to establish a secure connection with the PLC. Secure PG / PC / HMI com-
munication is available in PLCs configured with TIA Portal V17 or higher. The default is Disable. However, it
is recommended to Enable secure communications if the PLC supports it. When enabled, all information is
encrypted.

Require Trusted Certificates: Specify that the secure connection requires trusted certificates. This prop-
erty is only available if the Secure Communications is enabled. The default is Enable.
Notes:

l If enabling Require Trusted Certificates, a Siemens PLC certificate must be manually imported into
the Siemens S7 Plus Ethernet Trust Store.
l To manually import and configure certificates, use the Certificate Store tab in the Server Admin-
istration tool. Select the Siemens S7 Plus Ethernet feature. More details may be found in the server
help document under the Administration | Settings | Certificate Store section.
l The server runtime must be restarted when a new certificate is imported.

Symbol Load

Include Instance Data Blocks and Function Blocks: When enabled, symbol load includes symbols for
instance data blocks and function blocks. The default is Disabled.

www. ptc.com
17 Siemens S7 Plus Ethernet Driver

On Invalid Tag: When enabled, invalid tags cause a symbol download from the device when encountered.
The default is Enabled.
Note: The device-level System tag “_ForceSymbolReload” forces a symbol reload from the device when
written to with a non-zero value.

Device Properties — Redundancy

Redundancy is available with the Media-Level Redundancy Plug-In.

Consult the website, a sales representative, or the user manual for more information.

www. ptc.com
Siemens S7 Plus Ethernet Driver 18

Optimizing Communications
The Siemens S7 Plus Ethernet Driver was designed to provide the best performance with the least amount
of impact on the system's overall performance. While the Siemens S7 Plus Ethernet Driver is fast, there are a
couple of guidelines that can be used to optimize the application and gain maximum performance.

This server refers to communications protocols like Siemens S7 Plus Ethernet as a channel. Each channel
defined in the application represents a separate path of execution in the server. Once a channel has been
defined, a series of devices can then be defined under that channel. It is not recommended for the series of
devices to use the same device IP. It is preferred for projects to only have one physical connection per
device. Each of these devices represents a single Siemens Ethernet controller from which data will be col-
lected. Although this approach to defining the application provides a high level of performance, it does not
take full advantage of the Siemens S7 Plus Ethernet Driver or the network. An example of how the applic-
ation may appear when configured using a single channel is shown below.

Each device is defined under a single channel. In this configuration, the driver
must move from one device to the next as quickly as possible to gather inform-
ation at an effective rate. As more devices are added or more information is
requested from a single device, the overall update rate begins to suffer.

If the Siemens S7 Plus Ethernet Driver could only define one channel, the example above would be the only
option available; however, the driver can define up to 256 channels, each with support for 16 devices. Using
multiple channels distributes the data collection workload by simultaneously issuing multiple requests to
the network. An example of how the same application may appear when configured using multiple channels
is shown below.

Each device can be defined under its own channel; however, it is not recom-
mended to create multiple channels with devices using the same IP. It is preferred
for projects to only have one physical connection per device. In this configuration,
a single path of execution is dedicated to the task of gathering data from each
device. The performance will improve even if the application has more than 256
devices. While 256 or fewer devices may be ideal, the application will still benefit
from additional channels. Although spreading the device load across all channels
will cause the server to move from device to device again, it can now do so with far
less devices to process on a single channel.

Although the maximum number of channels is 256, the device ultimately determines the number of
allowed connections. This constraint comes from the fact that some devices cannot support so many con-
nections. For these devices, the maximum number of channels defined should equal the maximum number
of connections allowed. For devices that support more connections, the maximum of 256 channels should
be defined, with devices spread evenly over these channels. If a device’s connection limit is exceeded, bad
tag quality may occur. Refer to Siemens documentation for maximum allowed connections.
Tip: Using arrays can help improve performance.
Tip: For best performance, keep the total number of tags down. Remove tags in the server if the client is
not using them. Memory consumption increases as the number of tags increase. It is recommended to keep

www. ptc.com
19 Siemens S7 Plus Ethernet Driver

server_runtime private bytes from approaching a size of 800 MB. Private bytes exceeding this can result in
bad behavior and “Out of memory” event log error messages.
For more information on device connections, refer to Device Properties.

www. ptc.com
Siemens S7 Plus Ethernet Driver 20

Data Types Description

The following data types are supported when creating tags and for tag reads and writes:

Data Type Description

The tag is assigned one of the data types below based upon the S7 data type. This data
Default type is assigned upon the first successful read from the device.
See Also: Data Type Mapping
Single bit
Boolean
Range: 0 to 1
Unsigned 8-bit value
Byte
Range: 0 to 255
Signed 8-bit value
Char
Range: -128 to 127
Unsigned 16-bit value
Word
Range: 0 to 65,535
Signed 16-bit value
Short
Range: 32,768 to 32,767
Unsigned 32-bit value
DWord
Range: 0 to 4,294,967,295
Signed 32-bit value
Long
Range: -2,147,483,648 to 2,147,483,647
Unsigned 64-bit value
QWord
Range: 0 to 18,446,744,073,709,551,615
Signed 64-bit value
LLong
Range: -9,223,372,036,854,775,808 to 9,223,372,036,854,775,807
32-bit floating point value
Range: ±1.17154943508222875E-38 to ±3.4028234663852886E+38 (normalized)
Float
0
±1.4012984643248170E-38 to ±1.1754942106924411E-38 (denormalized)
64-bit floating point value
Range: ±2.2250738585072014E-308 to ±1.7976931348623157+308 (normalized)
Double
0
±4.9406564584124654E-324 to ±2.2250738585072010E-308 (denormalized)
Null-terminated ASCII string
The minimum size of strings is 1. The maximum size of strings is 254 characters. Strings
String
are considered narrow (8 bits in length). This data type supports ASCII and extended-
ASCII characters.

See Also: Data Type Mapping

www. ptc.com
21 Siemens S7 Plus Ethernet Driver

Data Type Mapping

This table shows data types supported by this driver with data types on the controller on the left and their
server equivalents on the right. If multiple server data types are supported for an S7 Data Type, the default
data type is shown in bold. Unless stated otherwise, these data types are supported by both the S7-1200
and S7-1500 devices. All data types below are also supported as Read / Write unless otherwise indicated.

S7 Data Type Server Data Types

Bool Boolean, Boolean Array
Byte Byte, Byte Array
String, Byte, Char, String Array, Byte Array, Char Array
Notes:

l For the String data type, each Char tag is read in as a 1-character string (ex.
65 is ‘A’). This means it is possible to write a string value to characters (ex. ‘A’
can be written instead of 65), assuming the data type is string. If a string of
Char length greater than 1 is written to the char tag, only the first character is
written to the device (ex. Writing ‘foo’ to a char tag truncates and writes ‘f’).
l For Byte data type, the value is the ASCII / Extended ASCII value in decimal
format, ranging from 0 – 255 (ex. ’A’ is 65).
l For Char data type, the value is the ASCII / Extended ASCII value in decimal
format, ranging from -128 – 127 (ex. ’A’ is 65).
INT Short, Short Array
DINT Long, Long Array
LLong
LINT Notes: This type is only supported by S7-1500 devices. Array of the LINT data type
is not supported (as of this release).
Word Word, Word Array
DWord DWord, DWord Array
QWord
LWord Notes: This type is only supported by S7-1500 devices. Array of the LWORD data
type is not supported (as of this release).
REAL Float, Float Array
LREAL Double
SINT Char, Char Array
UDINT DWord, DWord Array
UINT Word, Word Array
USINT Byte, Byte Array
QWord
ULINT Note: This type is only supported by S7-1500 devices.Array of the ULINT data type
is not supported (as of this release).
STRING String, String Array
String
Date And Time Note: Date_And_Time is a read-only tag. It displays in standard time with the fol-
(DT) lowing format: mm/dd/yyyy hh/min/ss tt. Example of a read on this tag: 05/21/1991
05:30:21 PM. Not including leap years, the minimum value for this type is 01/01/1990

www. ptc.com
Siemens S7 Plus Ethernet Driver 22

S7 Data Type Server Data Types

12:00:00 AM and the maximum value is 12/31/2089 11:59:59 PM.
Note: This type is only supported by S7-1500 devices. Array of the DT data type is
not supported (as of this release).
String
Note: Time_Of_Day indicates the elapsed time from midnight. It displays in the fol-
Time Of Day
lowing format: hh:mm:ss.msc. An example of a read on this tag: 23:31:21.999. The
(TOD)
minimum value for this tag is: 00:00:00.000 and the maximum value for this tag is
23:59:59.999. Array of the TOD data type is not supported (as of this release).
String, Long
Note: Time is displayed as a string in the following format: ddD_hhH_mmM_ssS_
hhhMS. An example of a read on this tag: 21D_15H_12M_60S_333MS. The minimum
Time
value for this tag is -24D_20H_31M_23S_648MS and the maximum value for this tag
is 24D_20H_31M_23S_647MS.
Note: Array of the Time data type is not supported (as of this release).
Long
Note: The range of this type is 0 to 9990000. The value stored in the server rep-
resents S5Time in milliseconds. When writing the value to the server, it should be
S5Time written as a millisecond value. Negative values cannot be written and any value
above the maximum range is automatically set to 9990000. If the value in the PLC is
an invalid S5Time value, the server returns bad quality for tags accessing this type.
Note: This type is only supported by S7-1500 devices.
String
Note: Date is displayed in the following format: yyyy-mm-dd. An example of a
Date read on this tag: 1991-02-03. The minimum value for this tag is 1990-01-01 and the
maximum value for this tag is 2169-06-06. Array of the Date data type is not sup-
ported (as of this release).
OB TOD Short

Notes:

l The number of elements for a client array tag is assigned on the first read of that tag and equals
the total number of elements for that array node in the controller. For example, given a 2D array
node [2,3], the number of elements assigned to the array tag is 6. If the number of elements for the
array node changes in the controller, the driver updates the client array tag with the new element
count. In the example above, if the array node changes from a 2D [2,3] to 1D [5], the array tag is
assigned a new element count of 5. If instead the array node changed from 2D [2,3] to 1D [6], there
is no change in element count so there is no change to the array tag.
l Arrays of server data types are supported for the data types indicated above. The server array max-
imum size is 65535 elements. The controller arrays can be defined with dimensions of 1D to 6D
arrays; these are mapped to a 1-dimensional client array. If arrays in the PLC are defined with more
than 65535 elements, automatic tag generation does not create the array tag itself, but all the array
element tags are generated. An event log message is posted stating that arrays exceeding 65535
elements are not supported. A read or write on this same array tag also fails with an event log mes-
sage.

www. ptc.com
23 Siemens S7 Plus Ethernet Driver

Symbolic Address Descriptions

When manually creating a tag, some restrictions apply to the symbolic address being created. The rules and
data types are below.

Examples:
PLC_1.Blocks.Data_block_1.Tag1
PLC_1.Blocks.Data_block_2.Tag2

Address Syntax Rules

l The length of the address must not exceed 1350 characters.
l The address length cannot be 0.
l The symbolic address cannot contain spaces only.
l The string for the address must come with a valid data type (listed in the Data Types Mapping).
l Symbolic address strings cannot have leading and trailing spaces within the name.
l If the following characters are included in a single node name, the node name must be wrapped in
double quotation marks:
. decimal point
( open parenthesis
) close parenthesis
[ open square bracket
] close square bracket

Examples:
PLC_1.Blocks.Data_block_1.“Tag(“
PLC_1.Blocks.”Data_block.1”.Tag
Tip: If the PLC node name contains a double quotation mark, the double quotation mark must be
escaped with a double quotation mark and the node name must be wrapped in double quotation
marks.

Example:
“PLC””Name”.Blocks.Data_block_1.Tag

Notes:

l Reading or writing to a symbolic address that does not exist in the PLC triggers the driver to load
symbols from the PLC on every read or write request. For best performance, tags that reference
invalid symbolic addresses must be removed to prevent them from being included in read or write
requests and continuously loading symbols.
l There is no syntax for specifying the number of rows and columns for client array tags. Since 1D –
6D array tags in the controller are flattened to 1D (one dimension) client arrays, the number of
rows is fixed at 1. The driver automatically determines and assigns the number of columns to the
tag at runtime.

www. ptc.com
Siemens S7 Plus Ethernet Driver 24

Event Log Messages

The following information concerns messages posted to the Event Log pane in the main user interface. Con-
sult the OPC server help on filtering and sorting the Event Log detail view. Server help contains many com-
mon messages, so should also be searched. Generally, the type of message (informational, warning) and
troubleshooting information is provided whenever possible.

Unable to read tag. | Tag address = '<address>',

Error Type:
Error

Possible Cause:
An error occurred while reading the tag. See reason in event log message.

Possible Solution:
Review the given reason in the Reason Explanations Section.

See Also:
Reason Explanations

Read request failed. |

Error Type:
Error

Possible Cause:
An error occurred during a read request. See reason in event log message.

Possible Solution:
Review the given reason in the Reason Explanations Section.

See Also:
Reason Explanations

Unable to write to tag. | Tag address = '<address>',

Error Type:
Error

Possible Cause:
An error occurred while writing the tag. See reason in event log message.

Possible Solution:
Review the given reason in the Reason Explanations Section.

See Also:
Reason Explanations

www. ptc.com
25 Siemens S7 Plus Ethernet Driver

Write request failed. |

Error Type:
Error

Possible Cause:
An error occurred during a write request. See reason in event log message.

Possible Solution:
Review the given reason in the Reason Explanations Section.

See Also:
Reason Explanations

No tag generated for the node. | Node address = '<address>',

Error Type:
Warning

Possible Cause:
An error occurred while browsing a node. See reason in event log message.

Possible Solution:
Review the given reason in the Reason Explanations Section.

See Also:
Reason Explanations

Array definition updated to match change detected in the controller. | Tag

address = '<address>'.
Error Type:
Warning

Possible Cause:
The total number of elements changed for this array in the controller.

Possible Solution:
No action required; the tag <address> was automatically assigned the new element count.

PLC details | IP = '<address>', Port = '<port>', PLC family = '<family>', Type

= '<type>', MLFB = '<mlfb>', Firmware = '<firmware>'.
Error Type:
Informational

Siemens communication library | Version = '<version>', Build date =

'<build date>'.
Error Type:

www. ptc.com
Siemens S7 Plus Ethernet Driver 26

Informational

Loading symbols from PLC. |

Error Type:
Informational

Possible Cause:
Symbol load from PLC required. See reason in event log message.

Possible Solution:
Review the given reason in the Reason Explanations Section.

See Also:
Reason Explanations

Secure communication certificates loaded but invalid certificate(s) detec-

ted. | Loaded = '<count>', Expired = '<count>', Invalid signature =
'<count>'.
Error Type:
Security

Possible Cause:
1. A certificate in the certificate store is expired.

2. A certificate in the certificate store has an invalid signature.

Possible Solution:
1. Remove the expired certificate. Import a certificate with a future expiration date.

2. Remove the invalid signed certificate. Import a certificate with a valid signature.

Successfully loaded secure communication certificates. | Loaded =

'<count>'.
Error Type:
Security

Connection details |
Error Type:
Security

Possible Cause:
Successful connection established. See details appended to this message in the event log.

www. ptc.com
27 Siemens S7 Plus Ethernet Driver

Reason Explanations
Some event log messages include additional information under a reason field. Click on the link for a descrip-
tion of the reason.

Access to path is denied

Arrays exceeding 65535 elements are not supported
Array range invalid
Could not initialize SSL
Date string contains a syntax error. Expected yyyy-mm-dd format
Device is not responding
Device is not responding; Connection closed by device
Error code = <hex error code>
Failed to resolve host name
Internal driver error occurred
Invalid value encountered on read for S5Time
Invalid value encountered on write for S5Time
New connection
Node path is invalid
Out of connections
Out of memory
Password changed
Password required
Read from this Siemens data type is not supported
Secure communication required
Symbol load setting changed
The data type of the node is not supported
Time of Day string contains a syntax error. Expected hh:mm:ss.hhh format
Time string contains a syntax error. Expected ddD_hhH_mmM_ssS_hhhMS format
Unsupported communication configuration detected
Unsupported data type for this address
Untrusted certificate
User forced reload
Write to this Siemens data type is not supported
Wrong password

Reason = Array range invalid.

Possible Cause:

The array in the controller has fewer elements than the client array and the client attempted to write to the
array tag.

www. ptc.com
Siemens S7 Plus Ethernet Driver 28

Possible Solution:
1. Verify the client is writing the same or fewer number of elements as the array in the controller.

2. If the controller array changed, the client should read the tag before writing to it to synchronize the
array configuration.

Reason = Could not initialize SSL.

Possible Cause:

PLC programmed with TIA Portal version that does not support secure communications. Secure PG/PC and
HMI communication is available in PLCs configured with TIA Portal V17 or higher.

Possible Solution:

To use secure communications the PLC project must be V17 or later.

Reason = Device is not responding: ID = <IP address>.

Possible Cause:
1. The IP address is invalid.

2. The PLC is not configured to respond.

3. The configured connect timeout is too short.

4. The configured request timeout is too short.

5. The device refused the connection due to too many connections.

Possible Solution:
1. Verify the IP address.

2. Verify the PLC is in a state to respond and loaded with a valid program.

3. Increase the configured connect timeout to allow more time for the PLC to accept the connection
request.

4. Increase the configured request timeout to allow more time for the PLC to respond to the request.

5. Verify the number of connections allowed by the PLC.

Reason = Device is not responding. Connection closed by device. ID = <IP

address>.

Possible Cause:

The device refused the connection due to too many connections.

www. ptc.com
29 Siemens S7 Plus Ethernet Driver

Possible Solution:

Verify the number of connections allowed by the PLC.

Reason = Failed to resolve host name. Host name = <host name>.

Possible Cause:
1. The format of IP address does not follow the expected IP address with four octets.

2. The host name provided is invalid and does not resolve to an IP address.

Possible Solution:
1. Verify or correct the format of the IP address.

2. Verify or correct the string is a valid host name that resolves to an IP address.

Reason = Node path is invalid.

Possible Cause:
1. Node path does not exist in the controller.

2. Array element does not exist in the array.

3. Node path is not a member of the UDT.

4. Node path is unavailable.

5. Node path is not applicable.

6. Part of the node path requires quotation marks due to special characters (. [ ] ( )).

7. Invalid characters in array element notation.

8. Node path is an array and missing the index syntax.

9. Node path is to a UDT member, where the UDT is not an instance.

10. Node path changed or was deleted since loading the symbols.

11. Node path data type changed since loading the symbols.

Possible Solution:
1. Verify the path to the node has the correct syntax.

2. Verify the node exists in the controller.

3. Verify the path to the node isn’t a complex type, like an array or UDT.

Reason = Access to path is denied.

www. ptc.com
Siemens S7 Plus Ethernet Driver 30

Possible Cause:
1. Node path is read-only.

2. Node path is not accessible to the HMI.

3. Node path is protected.

Possible Solution:
1. Verify the node is accessible by HMIs.

2. If unable to write, verify the node has write permissions.

Reason = Arrays exceeding 65535 elements are not supported.

Possible Cause:

The array in the controller exceeds 65535 elements.

Possible Solution:

Reduce the array in the controller to a maximum size of 65535 elements.

Reason = Read from this Siemens data type is not supported.

Possible Cause:

Driver does not support reading nodes defined with unsupported Siemens data type.

Possible Solution:

For a list of valid Siemens data types, see Data Type Mapping. If issue can’t be resolved, contact technical
support.

Reason = Write to this Siemens data type is not supported.

Possible Cause:

Driver does not support writing to nodes defined with the Siemens Date and Time data type.

Possible Solution:

For a list of valid Siemens data types, see Data Type Mapping. If issue can’t be resolved, contact technical
support.

www. ptc.com
31 Siemens S7 Plus Ethernet Driver

Reason = Time of Day string contains a syntax error. Expected hh:m-

m:ss.hhh format.

Possible Cause:
1. The syntax of the value is not in the correct format.

2. The hours, minutes, seconds, or milliseconds part is out of range.

Possible Solution:
1. Format the value of the string to be written as hh:mm:ss.hhh and retry the write.

2. Verify the hours, minutes, seconds, and milliseconds are each within their expected range.

Reason = Unsupported data type for this address. Data type = <data type>.

Possible Cause:

The data type on the tag does not match the type of the node.

Possible Solution:

Correct the data type of the tag to match the data type of the node.

See Also: For a list of valid Siemens data types, see Data Type Mapping.

Reason = Date string contains a syntax error. Expected yyyy-mm-dd

format.

Possible Cause:
1. The syntax of the value is not in the correct format.

2. The day, month, or year part is out of range.

Possible Solution:
1. Format the value of the string be written as yyyy-mm-dd and retry the write.

2. Verify the day, month, and year are each within their expected range.

Reason = Time string contains a syntax error. Expected ddD_hhH_mmM_

ssS_hhhMS format.

Possible Cause:
1. The syntax of the value is not in the correct format.

2. The day, hour, minute, second, or milliseconds part is out of range.

www. ptc.com
Siemens S7 Plus Ethernet Driver 32

Possible Solution:
1. Format the value of the string to be written as ddD_hhH_mmM_ssS_hhhMS and retry the write.

2. Verify the day, hours, minutes, seconds, and milliseconds are each within their expected range.

Reason = The data type of the node is not supported; Node type = <node
type>.

Possible Cause:

The driver does not support the Siemens data type.

Possible Solution:

Contact technical support.

See Also: For a list of valid S7 data types, see Data Type Mapping.

Reason = Wrong password

Possible Cause:

The configured device password does not match the protection level password configured in the PLC.

Possible Solution:

Verify the configured password.

Reason = Password changed.

Possible Cause:

The password in the PLC or server project has changed.

Possible Solution:

Verify the password in the PLC and in the server project match, authentication succeeds, and updates con-
tinue.

Reason = Password required.

Possible Cause:

www. ptc.com
33 Siemens S7 Plus Ethernet Driver

The PLC has a protection level password configured.

Possible Solution:

Configure a device password.

Reason = Invalid value encountered on read for S5Time. Valid range for
this type is between 0 and 9990000.

Possible Cause:

The S5Time that is set in the device being accessed is incorrect.

Possible Solution:

Write a valid S5Time value to the device so the information can be read in correctly. If this does not work,
contact technical support.

Reason = Invalid value encountered on write for S5Time. Valid range for
this type is between 0 and 9990000.

Possible Cause:

A negative value is being written to an S5Time tag.

Possible Solution:

Enter a valid S5Time value. If this does not work, contact technical support.

Error Code = <hex error code>.

Possible Cause:

An uncommon error caused the request to fail.

Possible Solution:
1. Verify the item configuration and access rights.

2. Contact technical support.

Reason = Internal driver error occurred.

Possible Cause:

www. ptc.com
Siemens S7 Plus Ethernet Driver 34

An unexpected error within the driver caused the request to fail.

Possible Solution:
1. Verify the item configuration and access rights.

2. Contact technical support.

Unsupported communication configuration detected, ID = <IP address>.

Possible Cause:
1. The PLC returned an error that is not currently handled.

2. The PLC device configuration is not supported.

Possible Solution:

If issue continues, contact technical support.

Reason = New connection.

Possible Cause:
1. A connection to the PLC is successfully established on a client read or write or tag generation
request.

2. The previous connection disconnected due to network issues and a new connection to the PLC is
successfully established.

Possible Solution:

Verify possible issues with network stability.

Reason = Out of connections.

Possible Cause:

The device refused the connection due to too many connections.

Possible Solution:

Verify the number of connections allowed by the PLC.

Reason = Out of memory.

Possible Cause:

www. ptc.com
35 Siemens S7 Plus Ethernet Driver

The runtime process has reached the available memory capacity for an application on the system.

Possible Solution:
1. Restart the runtime.

2. Reduce the number of static tags in the project. All static tags in the project are loaded into the
runtime memory regardless of whether a client accesses them. Therefore, remove any static tags
that are not required.

3. Reduce the number of connections to each controller. Each connection must load the controller
symbols into memory in order to read and write to them.

4. Reduce the number of channels and devices. After starting the runtime, connect a client and see if
all tags with good quality. Verify the private byte size of the runtime to determine if it is near capa-
city for an application on the system. The size is dependent on the number connections as well as
the number of tags in the project and the number of symbols in each controller.

Reason = Secure communication required.

Possible Cause:

PLC is configured to only allow secure PG/PC and HMI communication.

Possible Solution:

Enable Secure Communications Device property.

Reason = Untrusted certificate.

Possible Cause:

Missing a trusted certificate.

Possible Solution:
1. Add or replace certificate for the PLC in the Certificate Store

2. Disable Require Trusted Certificates device property to allow communication with PLC con-
figured in mixed mode.

Reason = Symbol load setting changed.

Possible Cause:

The Include Instance Data Blocks and Function Blocks property has changed (located in the device prop-
erties Symbol Load group.

www. ptc.com
Siemens S7 Plus Ethernet Driver 36

Possible Solution:

Symbol Load includes symbols for Instance Data Blocks and Function Blocks when the property is enabled.

Reason = User-forced reload.

Possible Cause:

A non-zero value was written to the device-level System tag “_ForceSymbolReload”.

Possible Solution:

A symbol reload occurs.

www. ptc.com
37 Siemens S7 Plus Ethernet Driver

Appendix — Siemens and Media-Level Redund-

ancy Support
This section contains information specifically about S7-15xxR and S7-15xxH controllers interacting with Kep-
ware's Media-Level Redundancy Plug-In.

Affected Devices
l S7-15xxH
l S7-15xxR

Known Issues
The redundancy settings for these Siemens devices allow a pair of S7-1500Rs or S7-1500Hs to provide their
own redundancy system (independent of Kepware).
If these redundancy settings are configured, Kepware does not work (and will not override the Siemens
redundancy pair).
If these redundancy settings are not configured and the PLC does not use the Siemens redundancy or IP
address sharing, the controllers behave like other S7-15xx device and should be compatible with Kepware's
Media-Level Redundancy Plug-in.

www. ptc.com
Siemens S7 Plus Ethernet Driver 38

Appendix — Reloading Symbols

If getting bad quality after controller project edits, reload symbols to update. Scenarios where a tag can
change to bad quality because of controller project changes:

l When a tag’s symbolic name in the controller is modified;

l When a tag’s data type in the controller is modified;
l When a tag is removed; or
l If the Access Level of the device is changed to HMI access or below and the password in the server is
not updated.

To make sure all other tags are reporting accurately, the server reloads tag information from the controller
to maintain the accuracy of all other tags. When the server identifies that a tag has been modified, removed,
or if an ATG occurs; it reloads tag information. All other scenarios require a manual reload of tag inform-
ation. This is accomplished by executing a runtime reinitialize, which allows the server to reload tags. If a tag
is still bad quality after the tag information update, consider manually correcting that tag or perform an ATG
to correct tag information for many tags. In cases where tags are added in the controller, but not in the
server; those tags must be manually entered into the server with correct information for it to read or write
properly.

Note: Reading or writing to a symbolic address that does not exist in the PLC triggers the driver to load
symbols from the PLC on every read or write request. For best performance, tags that reference invalid sym-
bolic addresses must be removed to prevent them from being included in read or write requests and con-
tinuously loading symbols.

www. ptc.com
39 Siemens S7 Plus Ethernet Driver

Index

Access Level 38
Address Descriptions 23
Address Syntax 23
Allow Sub Groups 15
Array definition updated to match change detected in the controller. | Tag address = '<address>'. 25
Attempts Before Timeout 12
Auto-Demotion 13

Boolean 20-21
Byte 20-21

Channel Assignment 10
Channel Properties — Advanced 9
Channel Properties — Ethernet Communications 8
Channel Properties — Write Optimizations 8
Char 20-21
Communications 16
Communications Timeouts 12
Connect Timeout 12
Connection details | 26
Create 15

Data Collection 11
Data Type Mapping 21
Data Types Description 20
Date 22
Default 20
Delete 14

www. ptc.com
Siemens S7 Plus Ethernet Driver 40

Demote on Failure 13
Demotion Period 13
Device Properties — Auto-Demotion 13
Device Properties — General 10
Device Properties — Redundancy 17
Device Properties — Tag Generation 13
Device Properties — Timing 12
DINT 21
Discard Requests when Demoted 13
Do Not Scan, Demand Poll Only 12
Double 20-21
Driver 10
Duty Cycle 9
DWord 20-21

Ethernet card 5
Ethernet Settings 8
Event Log Messages 24

Float 20-21

General 10
Generate 14

Help Contents 4

ID 10
Identification 10

www. ptc.com
41 Siemens S7 Plus Ethernet Driver

Initial Updates from Cache 12

INT 21
Inter-Device Delay 9

LINT 21
LLong 20-21
Loading symbols from PLC. | 26
Long 20-21
LREAL 21

Name 10
Network Adapter 8
No tag generated for the node. | Node address = '<address>', 25
Non-Normalized Float Handling 9

On Device Startup 14
On Duplicate Tag 14
On Property Change 14
Operating Mode 11
Optimization Method 8
Optimizing Communications 18
Overview 5
Overwrite 14

Parent Group 15
PLC details | IP = '<address>', Port = '<port>', PLC family = '<family>', Type = '<type>', MLFB = '<mlfb>',
Firmware = '<firmware>'. 25
PLC Password 16
Port Number 16
Protocol 6

www. ptc.com
Siemens S7 Plus Ethernet Driver 42

QWord 20-21

Read request failed. | 24

REAL 21
Reason = New connection 34
Reason = Out of connections 34
Reason = Out of memory 34
Reason = Secure communication required 35
Reason = Symbol load setting changed 35
Reason = Untrusted certificate 35
Reason = User forced reload 36
Reasons 27
Redundancy 17
Reloading Symbols 38
Replace with Zero 9
Request Timeout 12
Respect Tag-Specified Scan Rate 12

S5Time 22
S7-1200 6
S7-1500 6
S7 Comm Plus 6
Scan Mode 11
Secure communication certificates loaded but invalid certificate(s) detected. | Loaded = '<count>',
Expired = '<count>', Invalid signature = '<count>'. 26
Security 16
Short 20-22
Siemens communication library | Version = '<version>', Build date = '<build date>'. 25
Simulated 11
SINT 21
String 20-22
Successfully loaded secure communication certificates. | Loaded = '<count>'. 26

www. ptc.com
43 Siemens S7 Plus Ethernet Driver

Symbol Load 16
symbolic name 38

Tag Counts 11
Tag Generation 13
Time 22
Timeouts to Demote 13
Timing 12
TOD 22

UDINT 21
UINT 21
ULINT 21
Unable to read tag. | Tag address = '<address>', 24
Unable to write to tag. | Tag address = '<address>', 24
Unmodified 9
Unsupported communication configuration detected, ID = '<IP address>', 34
USINT 21

Word 20-21
Write All Values for All Tags 8
Write Only Latest Value for All Tags 9
Write Only Latest Value for Non-Boolean Tags 8
Write request failed. | 25

www. ptc.com
