Cisco Secure Network Analytics

System Configuration Guide 7.5.1

Table of Contents
Introduction 13
Overview 13
Audience 13
Installation Requirements 14
Hardware 14
Virtual Edition (VE) Appliances 14
Quick Reference Overview 15
Before You Begin 20
Terminology 20
Abbreviations 20
Configuration Details 21
Downloading Software 21
Password Requirements 21
Licensing 22
TLS Versions 23
Third Party Applications 23
Browsers 23
Host Name 23
Domain Name 23
NTP Server 23
IPv6 Support 23
Time Zone 25
Planning Your System Configuration 26
System Configuration Requirements 26
Secure Network Analytics with Data Store 26
Secure Network Analytics without Data Store 27
Secure Network Analytics Hybrid Deployment 27
Appliance Configuration Requirements 29

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -2-
Connecting to Your Hardware (Physical) Appliances 31
CIMC Access 31
Connecting to Your Virtual Edition Appliances 31
1. Configuring Your Environment Using First Time Setup 33
Preparation 33
Appliance Configuration Overview 33
Appliance Console (SystemConfig) Requirements 34
Managed Appliances 34
Manager Failover 35
Secure Network Analytics Domain 35
Best Practices 35
1. Configure the Appliances in Order 36
2. Configure your Appliances 38
Configuring a Manager 38
1. Log in to the Manager 38
2A. Select Your Network Mode and Enter Your Network and Server Information
(IPv4 Only) 40
2B. Select Your Network Mode and Enter Your Network and Server Information
(IPv6 and Dual Stack Only) 42
3. Enter Your Domain Name and Select Your Domain Type 46
4. Change Your Passwords and Reboot Your Appliance 47
Configuring a Data Node 50
1. Log in to the Data Node 50
2. Select Your Network Mode and Enter Your Network, Server, and Physical Port
Information 51
3. Change Your Passwords 56
4. Connect to the Manager and Reboot Your Appliance 57
Configuring a Flow Collector with Data Store 60
1. Log in to the Flow Collector 60
2. Select Your Network Mode and Enter Your Network and Server Information 61
3. Select Your Data Store Deployment Option 64

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -3-
4. Select Your Flow Collector Telemetry Types 66
5. Change Your Passwords 69
6. Connect to the Manager and Reboot Your Appliance 70
Configuring a Flow Collector without Data Store 74
1. Log in to the Flow Collector 74
2. Select Your Network Mode and Enter Your Network and Server Information 75
3. Select Your Data Store Deployment Option 78
4. Select Your Flow Collector Telemetry Types 80
5. Change Your Passwords 82
6. Connect to the Manager and Reboot Your Appliance 83
Configuring a Flow Sensor or UDP Director 87
1. Log in to the Flow Sensor or UDP Director 87
2. Select Your Network Mode and Enter Your Network and Server Information 88
3. Change Your Passwords 91
4. Connect to the Manager and Reboot Your Appliance 93
3. Confirm the Appliance Status 96
2. Defining a Manager Failover Relationship 97
Data Store 97
Configuring Failover 97
Primary and Secondary Roles 98
3. Configuring Site Redundancy 99
Redundant Site Requirements 99
Adding Certificates to Trust Stores 100
Trust Store Requirements 100
Certificate Chain 100
Uploading Certificates to the Trust Store 100
1. Download the Appliance Identity Certificates 100
2. Add Certificates to the Manager Trust Stores 101
Open Site Redundancy Configuration 102
Configuring a Redundant Site 102

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -4-
Disabling a Redundant Site 103
Troubleshooting 103
4. Installing v7.5.1 Patches 104
5. Initializing the Data Store 105
6. Installing the Desktop Client 106
Install the Desktop Client Using Windows 107
Install the Desktop Client Using macOS 109
7. Verifying Communications 111
1. Review the Flow Collection Trend 111
2. Verify the Data Store Database Status 111
3. Run Reports in Report Builder 112
8. Finishing Appliance Configurations 113
Changing the Flow Settings in a Flow Collector 114
Configuring UDP Directors for High Availability (Hardware Only) 115
Configuring Forwarding Rules 115
Configuring High Availability 116
Primary Node and Secondary Node 116
Requirements 117
1. Configure the Primary UDP Director High Availability 117
2. Configure the Secondary UDP Director High Availability 119
Configuring the Flow Sensor 120
1. Configure the Application ID and Payload 120
2. Configure the Flow Sensor to Identify Applications (optional) 124
3. Restart the Appliance 125
BIOS Settings for 40 Gbps or 100 Gbps interfaces 125
9. Configuring Telemetry 127
Network Visibility Module 127
Firewall Logs 127
Updating Telemetry Settings 127
Cisco Telemetry Broker 128

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -5-
10. Licensing Secure Network Analytics 129
Evaluation Mode 129
11. Managing Secure Network Analytics 130
Configuring Host Groups 130
Creating and Managing Policies 130
Building Flow Searches 130
Running Reports in Report Builder 130
Managing User Permissions 130
Investigating Behavior (Alarms, Security Events, etc.) 130
Responding to Threats 131
Packet Capture 131
Analytics 132
Apps 133
Authentication/Authorization 134
Enabling SSO Only in the Appliance Console 135
Enabling SSO Only in User Management 135
Domains 136
Data Store Domains and Non-Data Store Domains 136
Adding and Configuring Domains 136
1. Add a Domain 137
Creating a Data Store Domain by Importing an Existing Non-Data Store Domain
Configuration (Optional) 138
2. Configure Domain Settings 139
Synchronizing Data Store and Non-Data Store Domains 141
Before You Begin 141
Synchronized Properties 141
Recommended Synchronization Frequency 141
Synchronizing Domains Procedure 142
Removing a Domain Synchronization Target Domain 143
Deleting a Domain 144

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -6-
1. Remove Flow Collectors from Central Management 144
2. Delete a Domain 144
Deleting a Desktop Client Domain 145
Integrations and Additional Configurations 146
Passwords 147
Resetting Passwords to Default Settings 147
Resetting the Admin Password on Your Appliance 147
Resetting Sysadmin Passwords to Default 148
Changing Passwords 148
Changing the Sysadmin Password 148
Changing the Admin Password on the Manager 148
Changing the Admin Password on All Other Appliances 149
Changing the Data Store Database Passwords 149
Changing the Flow Collector Database Password (Non-Data Store Domains) 150
SSL/TLS Appliance Identity and Additional SSL/TLS Client Identities 151
TLS Versions 151
Appliance Identity 151
Client Identity 151
Reviewing Certificates 152
Changing the Host Name, Network Domain Name, or IP Address 152
Reviewing Trust Store Certificates 153
Threat Feed 154
Licensing 154
Enabling 154
Reviewing Alarms and Security Events 154
Central Management (Managing your Appliances) 156
Central Management and Appliance Administration Interface 156
Opening Central Management 157
Opening Appliance Admin 157
Opening Appliance Admin through Central Management 157

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -7-
Opening Appliance Admin through Direct Login 157
Editing the Appliance Configuration 158
Viewing Appliance Statistics 159
Removing an Appliance from Central Management 159
Removing Data Store Appliances from Central Management 160
Adding an Appliance to Central Management 160
Creating an Appliance Configuration Backup 162
Enabling/Disabling SSH 162
Enabling/Disabling SSH from the Web UI/Central Management 162
Access the SSH Configuration 162
Enable SSH 163
Disable SSH 163
Enable/Disable SSH from the Appliance Console (SystemConfig) 163
Enabling/Disabling Sysadmin User 163
Access the Sysadmin User Configuration 163
Enable Sysadmin User 164
Disable Sysadmin User 164
Creating a Database Backup (Non-Data Store Domains) 165
1. Trim the Flow Collector Database 165
1. Review your Database Storage Statistics 165
2. Trim the Interface Details 166
3. Trim Flow Details and CI Event Data 167
2. Back Up to Remote File System 167
Restoring a Database Backup (Non-Data Store Domains) 170
Data Store Database 171
Data Store Tab 171
Opening the Data Store Tab 171
Viewing the Data Store Database Status 171
Starting the Database 172
Stopping the Database 172

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -8-
Starting a Data Node 172
Stopping a Data Node 173
Reviewing Last Action Results 173
Viewing Database Retention 173
Opening the Data Store - Database Retention Tab 174
Database Fullness Chart 174
Per Telemetry Contribution Chart 174
Daily Storage 174
Oldest Data in Data Store 175
Changing the Flow Interface Data Storage 175
Monitoring the Data Node Update Status 176
Opening the Data Store - Database Update Status Tab 176
Monitoring the Database Update Status 176
Creating a Data Store Backup 178
1. Estimate Backup Host Storage Requirements 178
2. Prepare a Backup Host 180
3. Ensure Connectivity for SSH Backup 181
4. Initialize the Backup Directory on the Backup Host 181
5. Configure the Remote Host 182
1. Log in to Your Appliance Console 182
2. Configure Your Data Store Backup 182
3. Copy the SSH Public Key to the Backup Server 184
4. Initialize the Remote Backup Location 188
6. Perform a Dry Run of Your Backup and Estimate Backup Size 188
7. Back Up the Data Store Database 191
Managing Your Data Store Backups 193
Check Backups 193
List Backups 196
Remove Backups 198
Repair Backups 202

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. -9-
Collect Garbage 205
Remove Known Host 208
Restoring a Data Store Backup 211
Data Store Maintenance 212
Enabling Data Compression in the Data Store 212
Adding a Data Store Domain 213
Adding a Secondary Manager or Flow Collectors after the Data Store is Initialized 213
Adding Data Nodes to the Data Store 213
Requirements 213
Before you Begin 213
Procedures 214
1. Create a Data Store Backup 214
2. Configure the Data Node and Add it to Central Management 214
3. Add Data Nodes to the Data Store 214
4. Rebalance Data in the Data Store 215
Replacing a Data Node (Hardware Only) 216
1. Prepare the New (Spare) Data Node 216
2. Create a Data Store Backup 217
3. Contact Cisco Support 217
Adding Data Store to a Non-Data Store Deployment 218
Adding Data Store 218
Adding New Flow Collectors to a Data Store 219
Adding a Data Store to a Non-Data Store Deployment and Transitioning Your
Flow Collectors 220
Preparation 221
Backing up Configuration Files 221
Flow Collector Transition Requirements 221
Initiating a Flow Collector Transition to Data Store 221
1. Review Your Data Store Domains 222
2. Check Your Appliance Status 222

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 10 -
3. Transition Your Flow Collector 223
4. Verify Communications 225
Running Flow Searches 226
Removing a Transitioning Flow Collector From your Central Manager Inventory 226
Transitioning Flow Collectors Behavior 227
Synchronizing Data Store and Non-Data Store Domains 227
Synchronized Properties 227
Recommended Synchronization Frequency 228
Synchronizing Domains Procedure 228
Completing your Flow Collector Transition 229
Completing your Data Store Flow Collector Transition 230
Requirements 230
Completing a Flow Collector Transition to Data Store 230
Post Completion Notes 231
Troubleshooting 233
Analytics jobs are lagging 233
The secondary Manager has been promoted to primary Manager 233
An appliance went down due to degradation 233
Appliance Status: Config Channel Down 233
Appliance Status: Data Store Not Initialized 234
Appliance Status: Data Store Not Configured 234
Opening the Appliance Administration Interface 234
Replacing the Appliance Identity 234
Removing Data Store Appliances from Central Management 235
Changing the Host Name, Network Domain Name, or IP Address 235
Changing the Network Mode of an Appliance 236
1. Remove Your Appliances from Inventory 237
2. Change the Network Mode of Your Appliances 237
3. Add Your Appliances Back to Central Management 238
Changing the Network Mode of Managers in a Failover Configuration 238

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 11 -
Opening Domain Properties 238
Deleting a Desktop Client Domain 239
System Configuration Overview 239
Changing the Trusted Hosts 240
Configuring the Maximum Transmission Unit (MTU) 240
Creating a Diagnostic Pack 241
Resetting Factory Defaults 241
Enabling/Disabling Admin Users 242
Editing Your Appliance Configuration in the Appliance Console (SystemConfig) 242
Logging In to the Appliance Console (SystemConfig) 243
Changing the Network IP Mode 243
Data Store Deployment Troubleshooting 245
Hardware Deployment Troubleshooting 245
Virtual Appliance Deployment Troubleshooting 245
First Time Setup and Data Nodes Virtual Edition 245
Data Store Troubleshooting 245
Vertica Analytics Platform does not automatically restart after a Data Node loses
power and reboots 245
Data Store Does Not Start After Power Failure 245
Patches and Software Updates 246
Contacting Support 247
Change History 248

Introduction
Overview
Use this guide to configure the following Cisco Secure Network Analytics (formerly
Stealthwatch) hardware and Virtual Edition appliances to one managed system in v7.5.1:
l Cisco Secure Network Analytics Manager (formerly Stealthwatch Management
Console)
l Cisco Secure Network Analytics Data Node
l Cisco Secure Network Analytics Flow Collector
l Cisco Secure Network Analytics Flow Sensor
l Cisco Secure Network Analytics UDP Director

For more information about Secure Network Analytics, refer to the following online
resources:
l Overview:
https://www.cisco.com/c/en/us/products/security/stealthwatch/index.html
l Appliances:
https://www.cisco.com/c/en/us/products/security/stealthwatch/datasheet-
listing.html
l Release Notes: For details, refer to the Release Notes.

Audience
The intended audience for this guide includes network administrators and other personnel
who are responsible for installing and configuring Secure Network Analytics products.
If you prefer to work with a professional installer, please contact your local Cisco Partner
or Cisco Support.

Installation Requirements
Before you configure Secure Network Analytics into a managed system using this guide,
install your hardware and virtual appliances using the following guides:

Hardware
l Hardware Installation: Install your appliance hardware (physical appliances) using
the Secure Network Analytics x2xx Series Hardware Installation Guide or the Secure
Network Analytics x3xx Series Hardware Installation Guide before you start this
configuration.
l Specifications: Hardware specifications are available on Cisco.com.
l Supported Platforms: To view the supported hardware platforms for each system
version, refer to the Hardware and Software Version Support Matrix on Cisco.com.

Virtual Edition (VE) Appliances

l Virtual Edition Installation: Install your virtual appliances using the Secure Network
Analytics Virtual Edition Installation Guide before you start this configuration.

Quick Reference Overview

For a successful installation, follow these procedures in order. For detailed instructions,
click the procedure link.

Before You Begin and Planning Your System Configuration

Make sure you have all required information to configure your
appliances and deploy Secure Network Analytics with a Data Store or
without a Data Store.

1. Configuring Your Environment Using First Time Setup

l Log In: Log in to each appliance through the console as sysadmin
(password: lan1cope).
l Required Appliances: Manager and Flow Collector are required
for all deployments. For deployments with a Data Store, you also
need to configure Data Nodes (with inter-Data Node
communications).
l Configure your appliances in order. Check the Central
Management inventory and confirm each appliance status is
Connected (or
Data Store Not Initialized) before you start configuring the next
appliance in your cluster.

1. Primary Manager (Central Management)

2. Data Nodes
3. Flow Collector 5000 Series Database
4. Flow Collector 5000 Series Engine
5. All Other Flow Collectors
6. UDP Directors
7. Flow Sensors
8. Secondary Manager

2. Defining a Manager Failover Relationship

l This procedure is required if you've configured a primary Manager
and a secondary Manager.
l Use Failover to establish a failover pair between two Managers so
that one of them serves as a backup console to the other.
l Follow the instructions in the Secure Network Analytics Failover
Configuration Guide.

3. Configuring Site Redundancy

l This procedure is optional and requires you to have a Data Store.
l Use site redundancy to establish near-redundancy across
clusters in two Cisco Secure Network Analytics sites that contain
separate deployments with similar appliances.

4. Installing v7.5.1 Patches

l Download the latest v7.5.1 patches from your Cisco Smart
Account on Cisco Software Central at
https://software.cisco.com.
l Follow the instructions in the patch readme file to install each
patch.

5. Initializing the Data Store

Required for Data Store deployments only.
1. Log in to your Manager appliance console (SystemConfig) as
sysadmin.
2. Select Data Store > SSH.
3. Select Data Store > Initialization.

6. Installing the Desktop Client

Required for Non-Data Store deployments only.
l Desktop Client requires a 64-bit operating system. It cannot run
on a 32-bit operating system or Linux.
l
Log in to your Manager. Click the icon.

7. Verifying Communications
l Log in to your Manager. Review the Flow Collection Trend.
l Review the Data Store database status to confirm it is Up.
(Configure > Global > Central Management > Data Store tab)
l Run reports in Report Builder to confirm flows are received at the
Flow Collector and Data Store. (Report > Report Builder > Flow
Collection Trend by Flow Collector Report, Flow Database Ingest
Trend Report)

8. Finishing Appliance Configurations

l Flow Sensor Application ID and Payload (required for all Flow
Sensors)
l UDP Director High Availability
l Other optional appliance configurations

9. Configuring Telemetry
Required for Data Store deployments with additional telemetry types
enabled.
l NVM Flows: Follow the instructions in the Endpoint License and
Network Visibility Module (NVM) Configuration Guide
l Firewall Logs: Follow the instructions in the Security Analytics
and Logging: Firewall Event Integration Guide and install the app
on your Manager.

10. Licensing Secure Network Analytics

l Register your product instance in your Cisco Smart Account at
https://software.cisco.com before the 90-day evaluation period
expires.
l Follow the instructions in the Secure Network Analytics Smart
Software Licensing Guide.

11. Managing Secure Network Analytics

Log in to your Manager and select:
l Host Groups: Configure > Detection > Host Group Management.
l Policies: Configure > Detection > Policy Management.
l Flow Searches: Investigate> Flow Search.
l Reports: Dashboards > Report Builder.
l User Management: Configure > Global > User Management
l
Instructions: Select the (Help) icon > Help from any page.
Also, refer to Managing Your Environment, Investigating Behavior,
and Responding to Threats.

Review the guide for additional configurations, maintenance, and

troubleshooting, including:
l Analytics
l Apps
l Authentication/Authorization
l Domains
l Passwords
l SSL/TLS Appliance Identity and Additional SSL/TLS Client
Identities
l Threat Feed
l Central Management (Managing your Appliances)
l Data Store Database
l Data Store Maintenance
l Adding a Data Store to a Non-Data Store Deployment and
Transitioning Your Flow Collectors
l Troubleshooting

Before You Begin

Before you begin the configuration process, review this guide to understand the process
as well as the preparation, time, and resources you'll need to plan for the configuration.

Terminology
This guide uses the term “appliance” for any Secure Network Analytics product,
including virtual products such as the Flow Sensor Virtual Edition (VE).
A "cluster" is your group of Secure Network Analytics appliances that are managed by
the Manager.

Abbreviations
The following abbreviations may appear in this guide:

Abbreviations Definition

DNS Domain Name System (Service or Server)

dvPort Distributed Virtual Port

ESX Enterprise Server X

GB Gigabyte

IDS Intrusion Detection System

IPS Intrusion Prevention System

ISO International Standards Organization

IT Information Technology

KVM Kernel-based Virtual Machine

MTU Maximum Transmission Unit

NTP Network Time Protocol

TB Terabyte

Abbreviations Definition

UUID Universally Unique Identifier

VDS vNetwork Distributed Switch

VE Virtual Edition

VLAN Virtual Local Area Network

VM Virtual Machine

Configuration Details
The Secure Network Analytics system configuration includes the following:
l Requirements: You can configure Secure Network Analytics with a Data Store,
without a Data Store, or as a hybrid deployment (both Data store and Non-Data
Store domains). Refer to Planning Your System Configuration to review the
appliance configuration and domain requirements.
l Configuration Order: Make sure you configure the appliances following the
instructions in this guide and using the specified order.
l Certificates: Appliances are installed with a unique, self-signed appliance identity
certificate.
l Central Management: You can manage your appliances from the primary
Manager/Central Manager.

Downloading Software
Use Cisco Software Central to download virtual appliance (VE) installation files, patches,
and software update files. Log in to your Cisco Smart Account at
https://software.cisco.com or contact your administrator.

Password Requirements
During the system configuration, you will replace the default passwords and create new
passwords for the following:

User Default Password

admin lan411cope

sysadmin

Only one terminal user is

supported. You will not be lan1cope
allowed to add additional terminal
users.

You will assign the password when you

dbadmin
initialize the Data Store.

You will assign the password when you

readonlyuser
initialize the Data Store.

For remote access to your hardware

appliances, log in to the CIMC. If you
haven't already configured the CIMC,
follow the instructions in the Cisco UCS C-
CIMC admin Series Integrated Management Controller
GUI Configuration Guide.
The default password is password. Make
sure you change it when you first log in.

Licensing
For licensing Secure Network Analytics, you will use your Smart Account to register your
product instance, manage licenses, run reports, and configure notifications. Log in to your
Cisco Smart Account at https://software.cisco.com or contact your administrator.
When you use Secure Network Analytics in Evaluation mode, you can use selected
features for 90 days. To use Secure Network Analytics with maximum default
functionality, and to add licenses and features to your account, register your product
instance for Smart Software Licensing. Refer to 10. Licensing Secure Network
Analytics for more information.

Make sure you register your product instance before the 90-day evaluation
period expires. When the evaluation period expires, flow collection will stop. To
start flow collection again, register your product instance.

TLS Versions
TLS versions 1.2 and 1.3 are supported by default when you install Secure Network
Analytics v7.5.0 or later. You can choose the configuration for your appliances as follows:
l TLS 1.2 and 1.3 (default)
l TLS 1.3 only (not supported for Data Store)

To change the configuration, follow the instructions in the SSL/TLS Certificates for
Managed Appliances Guide.

Third Party Applications

Secure Network Analytics does not support installing third party applications on
appliances.

Browsers
Secure Network Analytics supports the latest version of Chrome, Firefox, and Edge.

Host Name
A unique host name is required for each appliance. We cannot configure an appliance
with the same host name as another appliance. Also, make sure each appliance host
name meets the Internet standard requirements for Internet hosts.

Domain Name
A fully qualified domain name is required for each appliance. We cannot install an
appliance with an empty domain.

NTP Server
l Configuration: At least 1 NTP server is required for each appliance.
l Problematic NTP: Remove the 130.126.24.53 NTP server if it is in your list of
servers. This server is known to be problematic and it is no longer supported in our
default list of NTP servers.

IPv6 Support
IPv6 and Dual Stack is supported on Managers and Flow Collectors in v7.5.0 and later.
The only supported network mode for Data Nodes is IPv4 only. When configuring a UDP
Director, your options are IPv4 and Dual Stack. If you select the Dual Stack option, UDP
will only forward over IPv4. You can, however use IPv6 for management. For information
on IPv6 forwarding for UDP directors, refer to the Cisco Telemetry Broker User Guide.For

information on changing the network mode of your appliance, refer to the System
Configuration Guide.

IPv6 is not supported on the Desktop Client.

Time Zone
All Secure Network Analytics appliances use Coordinated Universal Time (UTC).
l Virtual Host Server: Make sure your virtual host server is set to the correct time.

Make sure the time setting on the virtual host server (where you will be installing
the virtual appliances) is set to the correct time. Otherwise, the appliances may
not be able to boot up.

Planning Your System Configuration

Before you start the configuration, review the instructions so you understand the planning,
time, and requirements for configuring your appliances in First Time Setup and
configuring them into one managed system in the appliance console (SystemConfig).

System Configuration Requirements

Consult with your network architect and administrator to confirm the details of your v7.5.1
Secure Network Analytics deployment. Refer to each section for configuration
requirements:
l Secure Network Analytics with Data Store
l Secure Network Analytics without Data Store
l Secure Network Analytics Hybrid Deployment

Secure Network Analytics with Data Store

In Secure Network Analytics with a Data Store, the Flow Collector sends its telemetry to
the Data Store Data Nodes for storage.
l Number of Data Nodes: The Data Store can include 1 Data Node (Single Data Node
deployment) or 3 or more Data Nodes (Multi-Data Node deployment). A Data Store
with only 2 Data Nodes is not supported.
l Hardware or Virtual: Make sure your Data Nodes are the same type: all hardware or
all Virtual Edition.
l Size: Make sure your Data Nodes Virtual Edition use the same profile size so they
have the same RAM, CPU, and disk space. Refer to the Virtual Appliance Installation
Guide for details.
l Telemetry Ingest: In addition to NetFlow, you can configure telemetry ingest for
NVM flows (Network Visibility Module) and firewall logs.

For a successful configuration, note the following:

1. In the appliance console (SystemConfig), configure your appliances for a Data Store
configuration. Make sure you configure the following appliances:

l Manager: Refer to Configuring a Manager

l Flow Collector: Refer to Configuring a Flow Collector with Data Store
l Data Nodes: Refer to Configuring a Data Node

2. In First Time Setup, make sure you create a Data Store domain for your Secure
Network Analytics appliances.
3. To enable telemetry ingest for NVM flows and firewall logs, make sure you complete
the additional configuration instructions in 9. Configuring Telemetry.

Secure Network Analytics without Data Store

In Secure Network Analytics without a Data Store, the Flow Collector stores its telemetry
locally on the Flow Collector or on the Flow Collector database (5000 Series only).
For a successful configuration, note the following:

1. In the appliance console (SystemConfig), make sure you configure the following
appliances:

l Manager: Refer to Configuring a Manager

l Flow Collector: Refer to Configuring a Flow Collector without Data Store

2. In First Time Setup, make sure you create a Non-Data Store domain for your Secure
Network Analytics appliances.

After you finish configuring your managed system, you can add a Data Store to your
deployment in the future (for instructions, refer to Adding Data Store to a Non-Data
Store Deployment).
You can also transition your existing Flow Collectors to use the Data Store database
without losing pre-transition data or visibility. Doing so allows you to take advantage of
features only available in Data Store. For more information, refer to Adding a Data Store
to a Non-Data Store Deployment and Transitioning Your Flow Collectors

Secure Network Analytics Hybrid Deployment

In Secure Network Analytics with a hybrid configuration, you can configure specific Flow
Collectors to send telemetry to the Data Store Data Nodes for storage, and you can
configure other Flow Collectors to store telemetry locally on the Flow Collector or the
Flow Collector database (5000 Series only).

For a successful configuration, configure your appliances and domains in the following
order:

1. In the appliance console (SystemConfig), configure your appliances without Data

Store. Make sure you configure the following appliances:

l Manager: Refer to Configuring a Manager

l Flow Collector: Refer to Configuring a Flow Collector without Data Store

2. In First Time Setup, make sure you create a Non-Data Store domain for your Secure
Network Analytics appliances.
3. Complete all procedures through 8. Finishing Appliance Configurations to finish
your initial system configuration with a Non-Data Store domain.
4. Follow the instructions in Adding Data Store to a Non-Data Store Deployment.
You will create a Data Store domain and add Flow Collectors and Data Nodes to it.

Appliance Configuration Requirements

You need the following information to configure each appliance in First Time Setup. You
will also use this information to configure your appliances into a managed system with the
appliance console (SystemConfig).

Configuration Requirement Details Appliance

Assign a routable IP address to the eth0

IP Address
management port.

Netmask

Gateway

A unique host name is required for each

appliance. We cannot configure an
appliance with the same host name as
Host Name
another appliance. Also, make sure each
appliance host name meets the Internet
standard requirements for Internet hosts.

A fully qualified domain name is required

Domain Name for each appliance. We cannot install an
appliance with an empty domain.

DNS Servers Internal DNS server for name resolution

Internal Time server for synchronization

between servers. At least 1 NTP server is
required for each appliance.

NTP Servers Remove the 130.126.24.53 NTP server if

it is in your list of servers. This server is
known to be problematic and it is no
longer supported in our default list of NTP
servers.

SMTP Mail server to send alerts and

Mail Relay Server
notifications

Flow Collector Required for Flow Collectors only.

Export Port NetFlow Default: 2055

Required for Data Nodes only.

l Hardware eth2 or bond of eth2 and
eth3. Creating an LACP eth2/eth3
bonded port channel for up to 20G
Configure the interface or throughput enables faster
port channel as an access communication between and
port on the dedicated VLAN among Data Nodes, and quicker
meant for inter-Data Node Data Node addition or replacement
communication. to the Data Store. Note that
LACP port bonding is the only
bonding option available for
hardware Data Nodes.
l Virtual eth1

Required for Data Nodes only.

IP Address: You can use the provided IP
address or enter a value that meets the
following requirements for inter-Data
Node communications.
l Non-routable IP Address from the
169.254.42.0/24 CIDR block,
between 169.254.42.2 and
Non-routable IP Address 169.254.42.254
within a private LAN or VLAN
l First Three Octets: 169.254.42
(for inter-Data Node
communication) l Subnet: /24
l Sequential: For ease of
maintenance, select sequential
IP addresses (such as
169.254.42.10, 169.254.42.11, and
169.254.42.12).

Netmask:
The Netmask is hard coded to
255.255.255.0 and cannot be modified.

Connecting to Your Hardware (Physical) Appliances

Connect to your appliance with Cisco Integrated Management Controller (CIMC), a
keyboard and monitor, or serial cable or serial console. For instructions, refer to the x2xx
Series Hardware Installation Guide or the Secure Network Analytics x3xx Series
Hardware Installation Guide.

CIMC Access
For remote access, log in to the CIMC. If you haven't already configured the CIMC, follow
the instructions in the Cisco UCS C-Series Integrated Management Controller GUI
Configuration Guide.
The default password is password. Make sure you change it when you first log in.

Connecting to Your Virtual Edition Appliances

1. Connect to your Hypervisor host (virtual machine host).
2. In the Hypervisor host, locate your virtual machine.
3. Confirm the virtual machine is powered on.

If the virtual machine does not power on, and you receive an error message about
insufficient available memory, do one of the following:

l Resources: Increase the available resources on the system where the

appliance is installed. Refer to Resource Requirements in the Virtual Edition
Appliance Installation Guide for details.
l VMware Environment: Increase the memory reservation limit for the
appliance and its resource pool.

Review Resource Requirements to allocate sufficient resources. This step is

critical for system performance.

If you choose to deploy Cisco Secure Network Analytics appliances without the
required resources, you assume the responsibility to closely monitor your
appliance resource utilization and increase resources as needed to ensure
proper health and function of the deployment.

4. Access the virtual machine console. Allow the virtual appliance to finish booting up.

Depending on the speed of your VM host, it may take approximately 30 minutes

for all services to boot up.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 32 -
1. Configuring Your Environment Using First Time Setup

1. Configuring Your Environment Using First

Time Setup
When you log in to the appliance for the first time, you will use the First Time Setup tool to
configure each appliance so it is managed by your Manager.

Preparation
Before you start the configuration, review the instructions so you understand the
appliance configuration order, best practices, and additional requirements.
Use the following instructions to configure the environment for each appliance.

Review Planning Your System Configuration before you start these

configuration procedures.

Appliance Configuration Overview

Required
Appliance Instructions for Notes
Data Store

A Manager is required for deployments

Configuring a Manager yes
with Data Store and without Data Store.

You can deploy 1 Data Node (Single

Data Node deployment) or 3 or more
Data Nodes (Multi-Data Node
deployment).
Deploying only 2 Data Nodes is not
supported.
Configuring a Data Node yes Make sure your Data Nodes are all
hardware or all Virtual Edition. Also,
make sure your Data Nodes Virtual
Edition use the same profile size so
they have the same RAM, CPU, and
disk space. Refer to the Virtual
Appliance Installation Guide for details.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 33 -
1. Configuring Your Environment Using First Time Setup

The Flow Collector sends its telemetry

Configuring a Flow Collector to the Data Store Data Nodes for
yes
for Data Store storage. You will also confirm telemetry
types to ingest.

The Flow Collector stores its telemetry

Configuring a Flow Collector locally on the Flow Collector or on the
without Data Store Flow Collector database (5000 Series
only).

Flow Sensors and UDP Directors are

optional.
To install Cisco Telemetry Broker
Configuring a Flow Sensor or instead of the UDP Director, finish the
UDP Director instructions in this guide to finish your
system configuration. Then, follow the
instructions in the Cisco Telemetry
Broker Virtual Appliance Deployment
and Configuration Guide.

Appliance Console (SystemConfig) Requirements

l Confirm your firewalls and ACLs (Access Control List) will allow access.
l Gather the host name for the appliance and IP addresses for the following:

l appliance
l subnet mask
l default and broadcast gateways
l NTP and DNS servers
l Manager IP address for Central Management

For details, refer to Appliance Configuration Requirements.

Managed Appliances
As part of the First Time Setup process, you will configure your appliance to be managed
by your primary Manager.
When your appliances are managed by your Manager, you can use Central Management
to edit appliance configurations, update software, reboot, shut down, and more.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 34 -
1. Configuring Your Environment Using First Time Setup

Manager Failover
If you have more than one Manager, you can set up a Manager failover pair so that one of
them serves as backup console to the other.
l Use the appliance console (SystemConfig) to configure each individual Manager.
l Plan which Manager will be primary and secondary.
l Define the Manager failover relationship after you configure both Managers and all
other appliances with the appliance console (SystemConfig). Refer to 2. Defining a
Manager Failover Relationship for details.

Secure Network Analytics Domain

When you configure your Manager, you will create a Data Store domain or Non-Data
Store domain for your Secure Network Analytics appliances. When you configure your
other appliances in First Time Setup, you will add them to the domain you created. Refer
to Planning Your System Configuration for details.
After you finish your system configuration with your first domain, you can add domains to
your configuration (refer to Domains). If you configure Secure Network Analytics with a
Non-Data Store domain, you can add a Data Store to your deployment after you finish the
system configuration. Follow the instructions in Adding Data Store to a Non-Data Store
Deployment).

Best Practices
To configure your system successfully, make sure you follow the instructions in this guide.
Make sure you review the following:
l One at a Time: Configure one appliance at a time. Confirm the appliance is
Connected (or Data Store Not Initialized) before you start configuring the next
appliance in your cluster.
l Order: Follow the appliance configuration order.
l Multiple Central Managers: Unless you are using multiple clusters, you can not
configure more than one Central Manager in your system. However, each appliance
can be managed by only one primary Manager/Central Manager.
l Access: You need administrator privileges to access Central Management.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 35 -
1. Configuring Your Environment Using First Time Setup

1. Configure the Appliances in Order

Configure your appliances in the following order, and note the details for each appliance:

Order Appliance Details

Your primary Manager is your Central

Manager.
Make sure the Manager is shown as
Connected before you start configuring
the next appliance in the system.
1. Configuring a Manager
When you configure your Manager, you
will create a Secure Network Analytics
domain with a Data Store (Data Store
domain) or without a Data Store (Non-
Data Store domain).

Required for Data Store deployments.

Make sure the Data Node appliance
2. Configuring a Data Node status is Data Store Not Initialized
before you configure the next appliance
in your cluster.

Make sure the database appliance status

is Connected before you start the engine
configuration.
Database and Engine Pair: If you have
more than one database and engine pair,
configure each pair one at a time. For
example, configure pair1 (database1 and
Flow Collector 5000
3. engine1) before you configure pair2
Series Database
(database2 and engine2). In each pair,
confirm the database is shown as
Connected before you start the engine
configuration.
Also, when you configure unique host
names, name each database and engine
pair so you can identify them in Central

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 36 -
1. Configuring Your Environment Using First Time Setup

Management.
After you've completed the system
configuration, you can review the
appliance identity certificates in the trust
stores for each pair. Refer to Reviewing
Trust Store Certificates for details.

Make sure the Flow Collector 5000

Flow Collector 5000
4. series database is shown Connected
Series Engine
before you start the engine configuration.

Flow Collectors with Data Store: Make

sure the appliance status is Data Store
Not Initialized before you configure the
Configuring a Flow Collector next appliance in your cluster.
5.
with Data Store Flow Collectors without Data Store:
Make sure the appliance status is
Connected before you configure the
next appliance in your cluster.

Make sure the UDP Director appliance

status is Connected before you
configure the next appliance in your
cluster.

Configuring a Flow Sensor or If you are installing Cisco Telemetry

6. Broker instead of the UDP Director, finish
UDP Director
the Secure Network Analytics system
configuration. Then, follow the
instructions in the Cisco Telemetry
Broker Virtual Appliance Deployment and
Configuration Guide.

Make sure your Flow Sensor appliance

Configuring a Flow Sensor or
7. status is Connected before you start the
UDP Director
Flow Sensor configuration.

Make sure the primary Manager

8. Configuring a Manager
appliance status is shown as Connected

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 37 -
1. Configuring Your Environment Using First Time Setup

before you start the secondary Manager

configuration.
The secondary Manager selects itself as
Central Manager. Configure Failover after
all appliances are configured using the
appliance console (SystemConfig). Refer
to 2. Defining a Manager Failover
Relationship for details.

Your system might not have all the appliances shown here.

2. Configure your Appliances

Configure your appliances using the instructions below. After configuring each appliance,
confirm that your appliance is shown on the Inventory tab of your Central Manager by
following the instructions in 3. Confirm the Appliance Status.

Configuring a Manager
Follow the steps below to configure a Manager.

1. Log in to the Manager

1. Log in to the Manager through the console.

l Login: sysadmin
l Default Password: lan1cope
l You will change the default password when you configure the system.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 38 -
1. Configuring Your Environment Using First Time Setup

2. Review the failed login attempts information. Select OK to continue.

3. Review the First Time Setup introduction. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 39 -
1. Configuring Your Environment Using First Time Setup

2A. Select Your Network Mode and Enter Your Network and Server
Information (IPv4 Only)
1. Network IP Mode: Choose one of the following, and then select OK to continue:
l IPv4: Use only IPv4.
l IPv6: Use only IPv6. Skip to 2B. Select Your Network Mode and Enter Your
Network and Server Information (IPv6 and Dual Stack Only) for more
information.
l Dual Stack: Use IPv4 and IPv6. Skip to 2B. Select Your Network Mode and
Enter Your Network and Server Information (IPv6 and Dual Stack Only) for
more information.

2. Enter the management interface Host Name, Domain, IP Address (eth0),

Netmask, and Gateway, and then select OK to continue.

A unique host name is required for each appliance. We cannot configure an

appliance with the same host name as another appliance. Also, make sure each
appliance host name meets the Internet standard requirements for Internet
hosts.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 40 -
1. Configuring Your Environment Using First Time Setup

3. Confirm your settings. Select Yes to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 41 -
1. Configuring Your Environment Using First Time Setup

2B. Select Your Network Mode and Enter Your Network and Server
Information (IPv6 and Dual Stack Only)

SLAAC Patch Installation: In order to access the SLAAC options for IPv6, you
will first have to ensure that patch ROLLUP20240222-01.swu (or the latest,
most recent patch) has been installed on this appliance before proceeding with
this procedure. Follow the patch readme instructions to install patch
ROLLUP20240222-01.swu There is a separate patch readme for each
appliance posted to Patch Readmes.

4. Network IP Mode: Choose one of the following, and then select OK to continue:
l IPv6: Use only IPv6.
l Dual Stack: Use IPv4 and IPv6.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 42 -
1. Configuring Your Environment Using First Time Setup

5. Choose an IPv6 address type, and then select OK to continue.

l Static IPv6: Configuring a static IPv6 address ensures that each device is
manually assigned a unique IPv6 address. This method is often used for
servers or network infrastructure devices where a constant address is
necessary.
l SLAAC (EUI-64): EUI-64 is the name of the method to generate the 64 bit
interface Identifier, which is used for auto-generated addresses.
l SLAAC (Opaque): Configuring an IPv6 address using this method serves as
an alternative to generating Interface Identifiers based on hardware addresses
such as IEEE LAN Media Access Control (MAC) addresses. In doing so, the
benefits of stable addresses can be achieved without sacrificing the security
and privacy of users.

6. One of the following options will apply depending on which IPv6 address type you
select:
l If you select Static IPv6, enter the management interface Host Name,
Domain, IPv6 Address (eth0), IPv6 Prefix Length, and IPv6 Gateway, and
then select OK to continue.
l If you select SLAAC (EUI-64) or SLAAC (Opaque) then enter the management
interface Host Name and Domain. The other IPv6 fields will be auto-
configured. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 43 -
1. Configuring Your Environment Using First Time Setup

A unique host name is required for each appliance. We cannot configure an

appliance with the same host name as another appliance. Also, make sure each
appliance host name meets the Internet standard requirements for Internet
hosts.

7. Confirm your settings. Select Yes to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 44 -
1. Configuring Your Environment Using First Time Setup

8. DNS Settings: Enter your domain server IP address. Select Confirm to continue.

9. NTP Settings: Enter the IP address or FQDN of your NTP servers. Select Confirm to
continue.

Multiple NTP Servers: We recommend setting up multiple NTP servers for

redundancy and accuracy.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 45 -
1. Configuring Your Environment Using First Time Setup

3. Enter Your Domain Name and Select Your Domain Type

1. Enter a name for your Secure Network Analytics domain. You can change this name
later in Central Management. Select OK to continue.

2. Choose your domain type. For this example, we are selecting a Data Store. Select
OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 46 -
1. Configuring Your Environment Using First Time Setup

3. Confirm your domain type settings are correct. Select Yes to continue.

4. Change Your Passwords and Reboot Your Appliance

1. Change your admin password by entering your current and new admin passwords.
To create a system generated password, click Generate Password. Select OK to
continue.

Use the following criteria:

l Length: 8 to 256 characters
l Change: Make sure the new password is different from the default
password by at least 4 characters.

User Default Password

admin lan411cope

sysadmin lan1cope

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 47 -
1. Configuring Your Environment Using First Time Setup

2. Change your sysadmin password by entering your current and new sysadmin
passwords. To create a system generated password, click Generate Password.
Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 48 -
1. Configuring Your Environment Using First Time Setup

3. Your password changes will be saved and the system will initialize Central
Management. If successful, you will see the following message. Select OK to
continue.

4. A message appears notifying you that you have completed First Time Setup and
your appliance will be rebooted in approximately 5-15 minutes.

Make sure the primary Manager appliance status is shown as Connected before
you start configuring the next appliance in your cluster using the configuration
order and details.

If you've configured all Managers in First Time Setup, return to Appliance Configuration
Overview and configure your Flow Collectors and other appliances.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 49 -
1. Configuring Your Environment Using First Time Setup

Configuring a Data Node

You can deploy 1 Data Node (Single Data Node deployment) or 3 or more Data Nodes
(Multi-Data Node deployment). Deploying only 2 Data Nodes is not supported.

A Data Node is only required if you are configuring a Data Store. If you are not
configuring a Data Store, your next step is to configure a Flow Collector without a
Data Store.

1. Log in to the Data Node

1. Log in to a Data Node through the console.

l Login: sysadmin
l Default Password: lan1cope
l You will change the default password when you configure the system.

2. Review the failed login attempts information. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 50 -
1. Configuring Your Environment Using First Time Setup

3. Review the First Time Setup introduction. Select OK to continue.

2. Select Your Network Mode and Enter Your Network, Server, and
Physical Port Information
1. Network IP Mode: Choose one of the following, and then select OK to continue:
l IPv4: Use only IPv4.
l Dual Stack: Use IPv4 and IPv6.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 51 -
1. Configuring Your Environment Using First Time Setup

2. Enter the management interface Host Name, Domain, IP Address (eth0),

Netmask, and Gateway, and then select OK to continue.

A unique host name is required for each appliance. We cannot configure an

appliance with the same host name as another appliance. Also, make sure each
appliance host name meets the Internet standard requirements for Internet
hosts.

3. Confirm your settings. Select Yes to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 52 -
1. Configuring Your Environment Using First Time Setup

4. DNS Settings: Enter your domain server IP address. Select Confirm to continue.

5. NTP Settings: Enter the IP address or FQDN of your NTP servers. Select Confirm to
continue.
Multiple NTP Servers: We recommend setting up multiple NTP servers for
redundancy and accuracy.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 53 -
1. Configuring Your Environment Using First Time Setup

6. Configure the physical port (eth2) or port channel (eth2 and eth3) for inter-Data
Node communications.

For hardware Data Nodes, configuring an eth2 port for 10G throughput is
sufficient for normal inter-Data Node communication. Creating an LACP
eth2/eth3 bonded port channel for up to 20G throughput enables faster
communication between and among Data Nodes, and quicker Data Node
addition or replacement to the Data Store, as each new Data Node receives
traffic from adjacent Data Nodes to populate its data. Note that LACP port
bonding is the only bonding option available for hardware Data Nodes.

Enter the following:

Field Requirements

Use the provided IP address or enter a value that meets

the following requirements for the eth2 and eth3 interface
for inter-Data Node communications.
l Non-routable IP Address from the 169.254.42.0/24
CIDR block, between 169.254.42.2 and
IP Address 169.254.42.254.
l First Three Octets: 169.254.42
l Subnet: /24
l Sequential: For ease of maintenance, select
sequential IP addresses (such as 169.254.42.10,
169.254.42.11, and 169.254.42.12).

Netmask 255.255.255.0

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 54 -
1. Configuring Your Environment Using First Time Setup

7. Select OK to continue.
8. Confirm your changes are correct. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 55 -
1. Configuring Your Environment Using First Time Setup

3. Change Your Passwords

1. Change your admin password by entering your current and new admin passwords.
To create a system generated password, click Generate Password. Select OK to
continue.

Use the following criteria:

l Length: 8 to 256 characters
l Change: Make sure the new password is different from the default
password by at least 4 characters.

User Default Password

admin lan411cope

sysadmin lan1cope

2. Change your sysadmin password by entering your current and new sysadmin
passwords. To create a system generated password, click Generate Password.
Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 56 -
1. Configuring Your Environment Using First Time Setup

4. Connect to the Manager and Reboot Your Appliance

1. Enter your Manager information to register your appliance with Central
Management. User credentials are not saved. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 57 -
1. Configuring Your Environment Using First Time Setup

2. Review your Manager identify certificate. Select Yes to trust the certificate and
move to the next step.

3. A success message appears when you have successfully registered your appliance
with Central Management. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 58 -
1. Configuring Your Environment Using First Time Setup

4. A message appears notifying you that you have completed First Time Setup and
your appliance will be rebooted in approximately 5-15 minutes.

5. Repeat all the steps in Configuring a Data Node for the next Data Node in your
system.

If you've configured all Data Nodes in First Time Setup, go to the next section and
configure your Flow Collectors with Data Store or return to Appliance
Configuration Overview and configure your other appliances.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 59 -
1. Configuring Your Environment Using First Time Setup

Configuring a Flow Collector with Data Store

If you configure your Flow Collector for use with the Data Store, the Flow Collector sends
its telemetry to the Data Store Data Nodes for storage. You will also confirm telemetry
types to ingest.

Starting in v7.4.2, you can transition Non-Data Store Flow Collectors to Data
Store Flow Collectors. Refer to Adding a Data Store to a Non-Data Store
Deployment and Transitioning Your Flow Collectors for more information.

1. Log in to the Flow Collector

1. Log in to the Flow Collector through the console.
l Login: sysadmin
l Default Password: lan1cope
l You will change the default password when you configure the system.
2. Review the failed login attempts information. Select OK to continue.

3. Review the First Time Setup Introduction. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 60 -
1. Configuring Your Environment Using First Time Setup

2. Select Your Network Mode and Enter Your Network and Server
Information
1. Network IP Mode: Choose one of the following, and then select OK to continue:
l IPv4: Use only IPv4.
l IPv6: Use only IPv6.
l Dual Stack: Use IPv4 and IPv6.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 61 -
1. Configuring Your Environment Using First Time Setup

2. Enter the management interface Host Name, Domain, IP Address (eth0),

Netmask, and Gateway, and then select OK to continue.

A unique host name is required for each appliance. We cannot configure an

appliance with the same host name as another appliance. Also, make sure each
appliance host name meets the Internet standard requirements for Internet
hosts.

Flow Collector 5000 Series Database and Engine Pair: Name each database
and engine pair with unique host names that will help you identify the pair in
Central Management. For example, database1 and engine1, database2 and
engine2.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 62 -
1. Configuring Your Environment Using First Time Setup

3. Confirm your settings. Select Yes to continue.

4. DNS Settings: Enter your domain server IP address. Select Confirm to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 63 -
1. Configuring Your Environment Using First Time Setup

5. NTP Settings: Enter the IP address or FQDN of your NTP servers. Select Confirm to
continue.
Multiple NTP Servers: We recommend setting up multiple NTP servers for
redundancy and accuracy.

3. Select Your Data Store Deployment Option

1. Do you want to deploy this Flow Collector as part of a Data Store? Select Yes.

After you choose to configure your Flow Collector for use with Data Store, you
cannot change this configuration. Select Yes only if you plan to deploy a Data
Store to your network.

If you need to deploy Secure Network Analytics without a Data Store, do not
follow the instructions in this section. Follow the instructions in Configuring a
Flow Collector without Data Store.

If you select the wrong choice, deploy a new virtual appliance or RFD your
appliance.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 64 -
1. Configuring Your Environment Using First Time Setup

2. Review the message below. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 65 -
1. Configuring Your Environment Using First Time Setup

4. Select Your Flow Collector Telemetry Types

1. Select which telemetry types to ingest.

l Default: All telemetry types are selected by default. The asterisk (*) indicates
the selected telemetries.
l Deselecting: To deselect a telemetry, select the telemetry type and click it (or
press the space key on your keyboard).

More Information:

l Network Visibility Module - NVM: If you select Network Visibility Module -

NVM, the Flow Collector will ingest and store NVM flows. Refer to the Cisco
Secure Network Analytics Endpoint License and Network Visibility Module
(NVM) Configuration Guide for more information.
l Firewall Logs: If you select Firewall Logs, the Flow Collector will ingest and
store firewall event logs for Cisco Security Analytics and Logging (On
Premises). Refer to the Security Analytics and Logging: Firewall Event
Integration Guide for more information.

If you configure the Flow Collector to have NetFlow disabled, updating

configuration options, such as altering Exporters, Host Groups, Security Events,
Host Reports, etc., will have no effect.

2. Enter the UDP port for the selected telemetry types. Select OK.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 66 -
1. Configuring Your Environment Using First Time Setup

Make sure your telemetry ports are unique. If you configure duplicate telemetry
ports, the ports will be reset to their internal defaults to avoid loss of flow data.
For example, if NetFlow and NVM are exported to the same telemetry port, each
device exporting NVM data will create an exporter on the Flow Collector and
exhaust the exporter resources in the Flow Collector engine, resulting in loss of
flow data.

3. Confirm your settings. Select Yes to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 67 -
1. Configuring Your Environment Using First Time Setup

4. Port Order Configuration for eth0 (Flow Collector 4210 Hardware Only): Choose
one of the following:

l SFP+: Configure your appliance to use a 10G SFP+/DAC fiber port for eth0.
l BASE-T: Configure your appliance to use a 100Mbs/1GbE/10GbE
BASE-T copper port for eth0. BASE-T is the default.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 68 -
1. Configuring Your Environment Using First Time Setup

5. Change Your Passwords

1. Change your admin password by entering your current and new admin passwords.
To create a system generated password, click Generate Password. Select OK to
continue.

Use the following criteria:

l Length: 8 to 256 characters
l Change: Make sure the new password is different from the default
password by at least 4 characters.

User Default Password

admin lan411cope

sysadmin lan1cope

2. Change your sysadmin password by entering your current and new sysadmin
passwords. To create a system generated password, click Generate Password.
Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 69 -
1. Configuring Your Environment Using First Time Setup

6. Connect to the Manager and Reboot Your Appliance

1. Enter your Manager information to register your appliance with Central
Management. User credentials are not saved. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 70 -
1. Configuring Your Environment Using First Time Setup

2. Review your Manager identify certificate. Select Yes to trust the certificate and
move to the next step.

3. Select the Data Store domain you want to use for your Flow Collector. Select OK to
continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 71 -
1. Configuring Your Environment Using First Time Setup

4. A success message appears when you have successfully registered your appliance
with Central Management. Select OK to continue.

5. A message appears notifying you that you have completed First Time Setup and
your appliance will be rebooted in approximately 5-15 minutes.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 72 -
1. Configuring Your Environment Using First Time Setup

6. Repeat all the steps in Configuring a Flow Collector with Data Store for the next
Flow Collector in your system.

If you've configured all Flow Collectors for Data Store in First Time Setup, return to
Appliance Configuration Overview to configure your other appliances.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 73 -
1. Configuring Your Environment Using First Time Setup

Configuring a Flow Collector without Data Store

If you configure your Flow Collector for use without a Data Store, the Flow Collector
stores its telemetry locally on the Flow Collector or on the Flow Collector database (5000
Series only).

Before configuring your Flow Collector without Data Store, ensure that you have
first configured a Manager without Data Store. Failure to do so will result in an
inability to register your Flow Collector with the Manager.

1. Log in to the Flow Collector

1. Log in to the Flow Collector through the console.

l Login: sysadmin
l Default Password: lan1cope
l You will change the default password when you configure the system.

2. Review the failed login attempts information. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 74 -
1. Configuring Your Environment Using First Time Setup

3. Review the First Time Setup introduction. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 75 -
1. Configuring Your Environment Using First Time Setup

2. Enter the management interface Host Name, Domain, IP Address (eth0),

Netmask, and Gateway, and then select OK to continue.

A unique host name is required for each appliance. We cannot configure an

appliance with the same host name as another appliance. Also, make sure each
appliance host name meets the Internet standard requirements for Internet
hosts.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 76 -
1. Configuring Your Environment Using First Time Setup

3. Confirm your settings. Select Yes to continue.

4. DNS Settings: Enter your domain server IP address. Select Confirm to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 77 -
1. Configuring Your Environment Using First Time Setup

5. NTP Settings: Enter the IP address or FQDN of your NTP servers. Select Confirm to
continue.
Multiple NTP Servers: We recommend setting up multiple NTP servers for
redundancy and accuracy.

3. Select Your Data Store Deployment Option

1. Do you want to deploy this Flow Collector as part of a Data Store? Select No.

Make sure you select No. If you need to deploy Secure Network Analytics with a
Data Store, do not follow the instructions in this section. Follow the instructions
in Configuring a Flow Collector with Data Store.
If you select the wrong choice, deploy a new virtual appliance or RFD your virtual
appliance.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 78 -
1. Configuring Your Environment Using First Time Setup

2. Review the message stating that your Flow Collector will not work with a Data Store.
Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 79 -
1. Configuring Your Environment Using First Time Setup

4. Select Your Flow Collector Telemetry Types

1. Select which telemetry types to ingest.

More Information:

l Network Visibility Module - NVM: If you select Network Visibility Module -

NVM, the Flow Collector will ingest and store NVM flows. Refer to the Cisco
Secure Network Analytics Network Visibility Module (NVM) Configuration
Guide for more information.

If you configure the Flow Collector to have NetFlow disabled, updating

configuration options, such as altering Exporters, Host Groups, Security Events,
Host Reports, etc., will have no effect.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 80 -
1. Configuring Your Environment Using First Time Setup

2. Enter the UDP port for the selected telemetry types. Select OK.

3. Confirm your settings. Select Yes to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 81 -
1. Configuring Your Environment Using First Time Setup

5. Change Your Passwords

1. Change your admin password by entering your current and new admin passwords.
To create a system generated password, click Generate Password. Select OK to
continue.

Use the following criteria:

l Length: 8 to 256 characters
l Change: Make sure the new password is different from the default
password by at least 4 characters.

User Default Password

admin lan411cope

sysadmin lan1cope

2. Change your sysadmin password by entering your current and new sysadmin
passwords. To create a system generated password, click Generate Password.
Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 82 -
1. Configuring Your Environment Using First Time Setup

6. Connect to the Manager and Reboot Your Appliance

1. Enter your Manager information to register your appliance with Central
Management. User credentials are not saved. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 83 -
1. Configuring Your Environment Using First Time Setup

2. Review your Manager identify certificate. Select Yes to trust the certificate and
move to the next step.

3. Select the Non-Data Store domain you want to use for your Flow Collector. Select
OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 84 -
1. Configuring Your Environment Using First Time Setup

4. A success message appears when you have successfully registered your appliance
with Central Management. Select OK to continue.

5. A message appears notifying you that you have completed First Time Setup and
your appliance will be rebooted in approximately 5-15 minutes.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 85 -
1. Configuring Your Environment Using First Time Setup

6. Repeat all steps in Configuring a Flow Collector without Data Store for the next
Flow Collector in your system.

l If you've configured all Flow Collectors without Data Store in First Time Setup,
go to the next section (Configuring a Flow Sensor or UDP Director) or return
to Appliance Configuration Overview to configure other appliances.
l If you've configured all appliances in First Time Setup, go to 2. Defining a
Manager Failover Relationship.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 86 -
1. Configuring Your Environment Using First Time Setup

Configuring a Flow Sensor or UDP Director

Follow the steps below to configure a Flow Sensor or UDP Director.

1. Log in to the Flow Sensor or UDP Director

1. Log in to a Flow Sensor or UDP Director through the console.

l Login: sysadmin
l Default Password: lan1cope
l You will change the default password when you configure the system.

2. Review the failed login attempts information. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 87 -
1. Configuring Your Environment Using First Time Setup

3. Review the First Time Setup introduction. Select OK to continue.

When configuring a UDP Director, your options are IPv4 and Dual Stack. If you
select the Dual Stack option, UDP will only forward over IPv4. You can, however
use IPv6 for management. For information on IPv6 forwarding for UDP directors,
refer to the Cisco Telemetry Broker User Guide.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 88 -
1. Configuring Your Environment Using First Time Setup

2. Enter the management interface Host Name, Domain, IP Address (eth0),

Netmask, and Gateway, and then select OK to continue.

A unique host name is required for each appliance. We cannot configure an

appliance with the same host name as another appliance. Also, make sure each
appliance host name meets the Internet standard requirements for Internet
hosts.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 89 -
1. Configuring Your Environment Using First Time Setup

3. Confirm your settings. Select Yes to continue.

4. DNS SettingsEnter your domain server IP address. Select Confirm to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 90 -
1. Configuring Your Environment Using First Time Setup

5. NTP Settings: Enter the IP address or FQDN of your NTP servers. Select Confirm to
continue.
Multiple NTP Servers: We recommend setting up multiple NTP servers for
redundancy and accuracy.

3. Change Your Passwords

1. Change your admin password by entering your current and new admin passwords.
To create a system generated password, click Generate Password. Select OK to
continue.

Use the following criteria:

l Length: 8 to 256 characters
l Change: Make sure the new password is different from the default
password by at least 4 characters.

User Default Password

admin lan411cope

sysadmin lan1cope

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 91 -
1. Configuring Your Environment Using First Time Setup

2. Change your sysadmin password by entering your current and new sysadmin
passwords. To create a system generated password, click Generate Password.
Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 92 -
1. Configuring Your Environment Using First Time Setup

4. Connect to the Manager and Reboot Your Appliance

1. Enter your Manager information to register your appliance with Central
Management. User credentials are not saved. Select OK to continue.

2. Review your Manager identify certificate. Select Yes to trust the certificate and
move to the next step.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 93 -
1. Configuring Your Environment Using First Time Setup

3. Select the domain you want to use for your Flow Sensor. Select OK to continue.

This step only applies to Flow Sensor configurations. It does not apply to UDP
Director configurations.

4. A success message appears when you have successfully registered your appliance
with Central Management. Select OK to continue.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 94 -
1. Configuring Your Environment Using First Time Setup

5. A message appears notifying you that you have completed First Time Setup and
your appliance will be rebooted in approximately 5-15 minutes.

6. Repeat all steps in Configuring a Flow Sensor or UDP Director to configure the
next Flow Sensor or UDP Director in your system.

If you've configured all appliances in First Time Setup, go to 2. Defining a

Manager Failover Relationship.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 95 -
1. Configuring Your Environment Using First Time Setup

3. Confirm the Appliance Status

After you configure an appliance in First Time Setup, confirm the appliance status in
Central Management.

1. Open the Central Management inventory as follows:

l Log in to your primary Manager.

l Select Configure > Global > Central Management.

2. Review the appliances on the Inventory tab.

l Confirm the appliance is shown in the inventory.

l Appliance Status: Make sure the primary Manager and each appliance is
shown as Connected before you start configuring the next appliance in your
cluster.
l Data Store Not Initialized: For Flow Collectors and Data Nodes in a Data
Store domain, confirm the appliance status is Data Store Not Initialized. They
will be shown as Connected after you complete the initialization in a later
procedure.
l Type: If a Flow Collector has a Data Store tag, it is configured to send flows to
your Data Store database.

Make sure the primary Manager and each appliance is shown as Connected (or
Data Store Not Initialized) before you start configuring the next appliance in your
cluster using the configuration order and details.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 96 -
2. Defining a Manager Failover Relationship

2. Defining a Manager Failover Relationship

Use Failover Configuration to establish a failover pair between two Managers so that one
of them serves as a backup console to the other. If you have Secure Network Analytics
with a Data Store deployment, it is important to configure Failover before you initialize the
Data Store.
If you do not have a secondary Manager, go to 3. Configuring Site Redundancy.
For a successful Failover configuration and operation, review the requirements and follow
the instructions in the Secure Network Analytics Failover Configuration Guide.

If your primary Manager goes offline, please note that the Managers do not swap
roles automatically. Make sure you change the Manager roles in the order shown
in the Secure Network Analytics Failover Configuration Guide.

Data Store
If you've deployed Secure Network Analytics with a Data Store, make sure you configure
Failover before you initialize the Data Store. If you configure Failover after you've
initialized the Data Store, follow the instructions in the Secure Network Analytics Failover
Configuration Guide to configure the secondary Manager for secure communication with
the Data Store.

Configuring Failover
To configure your Managers as a failover pair, follow the instructions in the Secure
Network Analytics Failover Configuration Guide.
The guide includes details that are critical for a successful configuration, including:
l Certificates: To set up trust between appliances so they can communicate, make
sure you save the correct certificates to the required appliance Trust Stores.
l Backup Files: Back up the appliances before you start the failover configuration.
l Configuration Order: You will configure the secondary Manager for failover before
you configure the primary Manager.
l Changing Roles: If your primary Manager goes offline, make sure you change the
Manager roles in the order shown in the guide. The order is critical, and they do not
swap roles automatically.
l Troubleshooting: Refer to the Secure Network Analytics Failover Configuration
Guide for solutions.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 97 -
2. Defining a Manager Failover Relationship

For a successful configuration and operation, follow the instructions in the

Secure Network Analytics Failover Configuration Guide.

Primary and Secondary Roles

As part of the configuration, you will assign a primary Manager and a secondary Manager.
When you save the configuration, the following occurs:
l Primary Manager: The primary Manager pushes its domain configuration, user
settings, and policies to the secondary Manager. Use the primary Manager to
manage your appliances, change appliance configurations, change passwords,
define alarms, apply policies, and more.
l Secondary Manager: The secondary Manager deletes its configuration, so it can
synchronize with the primary Manager configuration and settings. Also, the
secondary Manager changes to read-only for all users, which means that you will
not have access to sections of the secondary Manager and you cannot retrieve files
from the secondary Manager.

3. Configuring Site Redundancy

If you do not have a Data Store configured or you do not want to create a
redundant site, go to 5. Initializing the Data Store.

Site Redundancy allows you to establish near-redundancy across clusters in two Cisco
Secure Network Analytics sites that contain separate deployments with similar
appliances. Site Redundancy enables you to maintain your domain and Analytics
configuration in your primary site and manually synchronize it with the redundant site. It
also provides high availability protection in the event a data center loses power. With site
redundancy, you will be able to log into either of the redundant clusters and see nearly the
same data.

This feature is only available to Admin and Configuration Manager roles.

Site Redundancy configuration synchronization includes the following:

Data Store domain specific configuration as well as alert configuration (if enabled).
Domain configuration includes:

l Host Group Management l Alarm Severity

l Policy Management l Services
l Applications l Domain AS Numbers
l Exporter SNMP profiles (not
including passwords)

Analytics configuration includes the following:

l Priorities
l Country Watchlist
l Alert Expiration

Redundant Site Requirements

Review the following requirements before you begin your redundant site configuration.
l Create redundant Data Store domains in both your primary and redundant site using
identical names. Make sure that both sites have the same number of Data Store
domains and that the Data Store domain names are identical in both sites. For more
information on domains, refer to Domains.

Only Data Store domains are synchronized for site redundancy. Non-Data Store
domains are not synchronized.

l Ensure that the Secure Network Analytics software version is the same at both sites.
l Add your redundant Manager certificates to the primary Manager Trust Store. See
Adding Certificates to Trust Stores for more information.
l Add your primary Manager certificates to the redundant Manager Trust Store. See
Adding Certificates to Trust Stores for more information.

Once you have completed the requirements, you can proceed to the Configuring a
Redundant Site procedure.

Adding Certificates to Trust Stores

Use the following instructions to save the required appliance identity certificates and
chains to the Trust Stores.

Trust Store Requirements

The instructions will guide you through the following requirements:
l Adding the redundant Manager certificates to the primary Manager Trust Store.
l Adding the primary Manager certificates to the redundant Manager Trust Store.

Certificate Chain
If your appliance identity certificate includes a certificate chain, make sure you add the
certificate chain (root and intermediate) to the Trust Stores.

Uploading Certificates to the Trust Store

Upload each file individually.

1. Download the Appliance Identity Certificates

Use the following instructions to download and save your appliance identity certificates.
The steps vary based on the browser you are using.
If your certificates are already saved, you can skip this procedure. Go to 2. Add
Certificates to the Manager Trust Stores.

You can also click the lock/security icon in your browser. Follow the on-screen
prompts to download your certificates. The steps vary based on the browser you
are using.

1. In the browser address bar, replace the path after the IP address with the
following: /secrets/v1/server-identity

For example: https://<IPaddress>/secrets/v1/server-identity

2. Follow the on-screen prompts to save the certificate.

Open: To view the file, select a text file format.

Troubleshooting: If you do not see the prompt to download the certificate, check
your Downloads folder in case it was downloaded automatically, or try a different
browser.

3. Repeat steps 1 and 2 on each Manager.

2. Add Certificates to the Manager Trust Stores

Use the following instructions to save your redundant Manager appliance identity
certificate and chain (if applicable) to the primary Manager Trust Store.

1. Log in to your Manager.

2. Select Configure > Global > Central Management.
3. Confirm the Appliance Status is shown as Connected.
4. Click the Actions menu for the Manager.
5. Select Edit Appliance Configuration.
6. On the Central Management Inventory > General tab, locate the Trust Store
section.
7. Click Add New.

Make sure you upload each appliance identity certificate and chain (root and
intermediate) certificate individually.

8. In the Friendly Name field, enter a name for the certificate.

9. Click Choose File. Select the certificate.
10. Click Add Certificate. Confirm the certificate is shown in the Trust Store list.
11. Repeat steps 6 through 9 to add any other required certificates to the Trust Store.

l If you are logged in to the redundant Manager, add the primary Manager
certificates.

l If you are logged in to the primary Manager, add the redundant Manager
certificates.

12. Click Apply Settings. Follow the on-screen prompts.

13. Connected: On the Central Management Inventory page, confirm the Appliance
Status returns to Connected.
14. Repeat steps 1 through 13 on the other Manager.

Open Site Redundancy Configuration

Use the following instructions to open Site Redundancy Configuration.

1. Log in to your Manager as admin or configuration manager.

2. From the main menu, choose Configure > Global > Manager.
3. Click the Site Redundancy Configuration tab.

Configuring a Redundant Site

Follow these steps to configure a redundant site.

1. Select the Enable Configuration check box.

2. Enter the Fully Qualified Domain Name (FQDN) or IP address for the Manager at your
redundant site in the Name of Manager at Redundant Site field. Note that the
Manager name must match the Common Name or Subject Alternative Name in the
Manager identity certificate.
3. Click the Save button to save your changes.
4. Click the Synchronize button to synchronize your primary site with your remote site.
This will synchronize your domain configuration and analytics configuration
between the two sites.
5. Follow the on-screen prompts to confirm that you want to synchronize your
changes. Click Synchronize to continue.
You will see the "in progress" ellipsis icon indicating the synchronization is in
progress. When it is complete you will see a success or failure banner.

When you perform a synchronization, the Redundant Site Flow Collector

Engine configuration is overwritten in the process. It is not recommended
to synchronize more than once per hour.

Disabling a Redundant Site

Perform the following steps to disable your redundant site.

1. To disable a redundant site, de-select the Enable Configuration check box.

2. Click the Save button to save your changes. This will disable the redundant site as
well as the Synchronize button.
3. (optional) Removing the site certificates of a disabled redundant site can add an
additional layer of protection to your Secure Network Analytics system. If you want
to remove the site certificates that you added during the Configuring a Redundant
Site procedure, you can do so by performing the following steps.
1. Log in to your Manager.
2. Select Configure > Global > Central Management.
3. Confirm the Appliance Status is shown as Connected.
4. Click the Actions menu for the Manager.
5. Select Edit Appliance Configuration.
6. On the Central Management Inventory > General tab, locate the Trust Store
section.
7. Under the Actions column, click Delete for each of the certificates you want
to remove.

Troubleshooting
In the event that you encounter an issue with your site redundancy configuration, ensure
the following:
l Verify your certificates are in the correct Trust Stores. Refer to Adding Certificates
to Trust Stores for more information.
l The Secure Network Analytics software version needs to be the same at both sites.
l The number and names of your Data Store domains at both sites needs to match.

To review the log file for errors, navigate to /lancope/var/smc/log/smc-configuration.log

4. Installing v7.5.1 Patches

Install the latest v7.5.1 patches on your appliances.

1. Download the latest v7.5.1 patches from your Cisco Smart Account on Cisco
Software Central at https://software.cisco.com.
2. Follow the instructions in the patch readme file to install each patch.
3. After you have updated your appliances with the latest patches, go to the next
procedure in this guide:

l Data Store Domains: Follow the instructions in 5. Initializing the Data Store.
l Non-Data Store Domains: Follow the instructions in 6. Installing the
Desktop Client.

5. Initializing the Data Store

Use System Configuration to initialize your Data Store. You will enable SSH temporarily as
part of this procedure.

Before you start this procedure, add all appliances to your Central Management
inventory. Flow Collectors are not required to initialize a Data Store, however you
will need to have at least one Data Node and one Manager in your Central
Management inventory before you begin the initialization process.

1. Log in to your Manager appliance console (SystemConfig) as sysadmin.

2. From the main menu, select Data Store.
3. Select SSH. Follow the on-screen prompts to enable SSH.
4. Select Initialization from the Data Store menu.
5. Follow the on-screen prompts to initialize the Data Store.

When you exit the Data Store menu, the system restores your previous SSH
settings.

6. Go to the next procedure: 7. Verifying Communications.

6. Installing the Desktop Client

Starting with v7.4.0, the SMC has been renamed to Manager. The SMC is
referred to as Manager within this section.

If your Secure Network Analytics system is deployed with only Data Store Flow
Collectors, you will not use the Desktop Client. For a hybrid Data Store/Non-Data
Store system, the Desktop Client will only work with Non-Data Store domains.

The following information applies to installing and using the Desktop Client:
l You can locally install different versions of Desktop Client.
l The Desktop Client includes Stealthwatch terminology such as Stealthwatch
Management Console and SMC (Manager).
l If you want to access multiple versions of Desktop Client, you will need a different
executable file for each Manager.
l If you are using both a primary and a secondary Manager, you will need to log off
one Manager before you can log in to the other Manager.
l You can have different versions of Desktop Client open simultaneously.
l When you update to a later version of Secure Network Analytics, you will need to
install the new version of Desktop Client.
l Use the Web App to monitor and configure your Secure Network Analytics
installation if you deploy a Data Store. The Desktop Client is incompatible with a
Data Store.

Instructions for installing the Desktop Client vary depending on whether you're using
Windows or macOS:
l Install the Desktop Client Using Windows
l Install the Desktop Client Using macOS

You will also change memory size differently, depending on whether you're using
Windows or macOS:
l Change the Memory Size From Windows Explorer
l Change the Memory Size From Finder

Install the Desktop Client Using Windows

l You must have sufficient rights to install Desktop Client.
l Desktop Client requires a 64-bit operating system. It cannot run on a 32-bit
operating system or Linux.

Use the following instructions to install the Desktop Client using Windows:

1. Log in to your Manager.

2. Click the icon.
3. Click the .exe file to begin the installation process.
4. Follow the steps in the wizard to install the Desktop Client.

5. On your desktop, click the Desktop Client icon .

6. In the SMC Server Name field, enter the Manager server name or IP address (IPv4
or IPv6).
7. Follow the on-screen prompts to open the Desktop Client and trust the appliance
identity certificate.
8. Enter the Manager user name and password.

Change the Memory Size From Windows Explorer

You can change how much Random Access Memory (RAM) to allocate on your
client computer to run the Desktop Client interface.

Consider a larger memory allocation if you work with many open documents or large data
sets (such as flow queries with over 100k records).

1. In Windows Explorer, go to your home directory.

2. Open these folders: AppData > Roaming > Stealthwatch.

You may need to search "Stealthwatch" if the folder is hidden.

3. In the Stealthwatch directory, open the folder that contains the desired
Stealthwatch version.
4. Open the application.vmoptions file using an appropriate editing application to
begin editing. (This file is created after you open the Desktop Client for the first
time.)

Minimum Memory Size (Xms): We recommend that you allocate no less than 512
MB. This number is listed in the third line of the file.

For editors that display the content in one continuous line, refer to the number
highlighted in the image below to see which number represents the minimum
memory size.

Maximum Memory (Xmx): You can allocate up to half the size of your computer's
RAM for the maximum memory size. This number is listed in the fourth line of the
file.
For editors that display the content in one continuous line, refer to the number
highlighted in the image below to see which number represents the maximum
memory size.

Use whole numbers. For example, enter Xmx512m, not Xmx0.5m.

l If you notice that the Desktop Client appears to "hang" frequently, try
increasing the memory size.
l If you receive an error message involving Java, try selecting a lower
memory allocation.

Install the Desktop Client Using macOS

l You must have sufficient rights to install Desktop Client.
l Desktop Client requires a 64-bit operating system. It cannot run on a 32-bit
operating system or Linux.

Use the following instructions to install the Desktop Client using macOS:

1. Log in to your Manager.

2. Click the icon.
3. Click the .dmg file to begin the installation process.

An icon and folder are displayed on your monitor, as shown below.

4. Drag the Desktop Client icon ( ) into the Application folder.

The icon is added to the Launchpad.

5. On your desktop, click the Desktop Client icon .

Change the Memory Size From Finder

You can change how much Random Access Memory (RAM) to allocate on your
client computer to run the Desktop Client interface.

Consider a larger memory allocation if you work with many open documents or large data
sets (such as flow queries with over 100k records).

1. In Finder, go to your home directory.

2. Open the Stealthwatch folder.

3. In the Stealthwatch directory, open the folder that contains the

desired Stealthwatch version.
4. Open the application.vmoptions file using an appropriate editing application to
begin editing. (This file is created after you open the Desktop Client for the first
time.)

Minimum Memory Size (Xms): We recommend that you allocate no less than 512
MB. This number is listed in the third line of the file.
For editors that display the content in one continuous line, refer to the number
highlighted in the image below to see which number represents the minimum
memory size.

Maximum Memory Size (Xmx): You can allocate up to half the size of your
computer's RAM for the maximum memory size. This number is listed in the fourth
line of the file.
For editors that display the content in one continuous line, refer to the number
highlighted in the image below to see which number represents the maximum
memory size.

Use whole numbers. For example, enter Xmx512m, not Xmx0.5m.

l If you notice that the Desktop Client appears to "hang" frequently, try
increasing the memory size.
l If you receive an error message involving Java, try selecting a lower
memory allocation.

7. Verifying Communications
1. Review the Flow Collection Trend
1. Log in to your primary Manager.

Failover Configuration: Log in to your primary Manager and secondary Manager.

2. Review the Flow Collection Trend.

2. Verify the Data Store Database Status

If you did not deploy Secure Network Analytics with a Data Store, go to 3. Run
Reports in Report Builder.

1. In your primary Manager dashboard, select Configure > Global > Central
Management.
2. Click the Data Store tab.
3. Confirm the Data Store database status is shown as Up.

If the database status is Down, click the (Ellipsis) icon in the Actions column for
the database. Select Start.

4. Confirm the status for all Data Nodes is shown as Up.

If a Data Node status is Down, click the (Ellipsis) icon in the Actions column for
the Data Node. Select Start.

For more information about the Data Store tab, refer to Data Store Database.

3. Run Reports in Report Builder

1. Return to your Security Insight Dashboard.
2. Select the Report menu.
3. Select Report Builder.
4. Click Create New Report.
5. Click the Flow Collection Trend by Flow Collector template.
6. Select the parameters as needed. Click Run.
7. Review the report to confirm your Flow Collectors are receiving flows.
8. If you have a Flow Collector database (5000 Series only) or a Data Store, return to
the Report Builder dashboard and repeat steps 4 through 7 to run the Flow
Database Ingest Trend Report. Confirm the database or Data Store are receiving
flows.

For more information about Report Builder, refer to the information in the Help.

8. Finishing Appliance Configurations

Make sure you finish any required configurations for your appliances.

Required Optional
Appliance
Configurations Configurations

Data Compression
Data Node none
Flow Interface Statistics

Flow Collectors none Change NetFlow to sFlow

High Availability
UDP Directors none (available on hardware
only)

Application ID and
Flow Sensors Identifying Applications
Payload

Changing the Flow Settings in a Flow Collector

The following steps require a reboot of your Flow Collector to apply these
changes.

Follow the steps below to change the flow settings in a Flow Collector.

1. Log in to the Flow Collector.

2. Click Support > Advanced Settings.
3. In the engine_startup_mode field, enter one of the following values:

l Default value from the model file - 0

l NetFlow -1
l sFlow - 2

If the engine_startup_mode field does not appear in the Advanced Settings list,
you can add it at the bottom of the page by using the Add New Option and
Option Value fields.

4. Click Apply and then click OK.

5. Reboot your Flow Collector to apply your changes.
6. Log in to your Manager.
7. Select Configure > System > Flow Collectors.
8. Enter one of the following numeric values in the Monitor Port field (these are
industry standard default port numbers for NetFlow and sFlow. If your exporters are
configured to use a non-standard port, you must use that port number instead).

l 2055 - NetFlow
l 6343 - sFlow

9. Click Save to save your changes.

Once the mode switch (NetFlow to sFlow or sFlow to NetFlow) completes, the
following items that are based on flows from the previous mode are cleared:
l Caches: host cache, flow cache, security event cache
l Saved baseline files

You can confirm the mode switch by checking the flow trend graph on the dashboard to
see if flows are being processed under the new mode.

Configuring UDP Directors for High Availability (Hardware

Only)
Use the following instructions to configure your UDP Directors as a High Availability pair.

High Availability is only available on UDP Director hardware appliances. High

Availability is not available on virtual appliances.

l Forwarding Rules: Configure at least one forwarding rule if you're planning to set
up High Availability. Refer to Configuring Forwarding Rules
l High Availability: If you have more than one UDP Director, you can set up a High
Availability pair. Configure at least one forwarding rule if you're planning to set up
High Availability (refer to Configuring High Availability).

Configuring Forwarding Rules

SSL is used to send messages from the UDP Director to the Manager.

1. Log in to the Manager.

2. Select Configure> Global > UDP Director.

3. Click the Actions menu for the appliance. Select Configure Forwarding Rules.

4. Click Add New Rule.

5. Description: Enter a brief description that identifies the rule.

6. Source IP Address:Port: Type the IP address of the device that sends data to the
UDP Director and the input port number (where the data will be sent).

l Format: Use the syntax [IP address]:[Port Number].

l Range: You can use Classless Inter-Domain Routing (CIDR) notation to enter a
range of IP addresses.

l All: You can type "All" to accept data from any source IP address on this port.

l Combinations: You can add Source IP Address:Port combinations within a

rule by adding them to a new line.

Examples:

l 10.11.16.38:5322
l 192.168.0.0/16:9000
l All:2055

7. Destination IP Address: Enter the IP address of the device receiving data from the
UDP Director.
8. Destination Port Number: Enter the port number for the receiving device.
9. Click Save.
10. Optional: To sync your changes, click Sync.

11. Repeat the procedure to add forwarding rules as needed.

12. To set up a High Availability pair, go to Configuring High Availability.

High Availability is only available on UDP Director hardware appliances. High

Availability is not available on virtual appliances.

Configuring High Availability

If you have more than one UDP Director, use the Appliance Admin interface to configure
high availability.

High Availability is only available on UDP Director hardware appliances. High

Availability is not available on virtual appliances.

The UDP Director High Availability (HA) allows a user to configure settings for redundant
UDP Directors. Both nodes are fully redundant, however only one node is online at a time.

If you have high availability configured on your UDP Directors and update Secure
Network Analytics to version 7.4.0 or later, reconfigure high availability after the
update using the instructions below.
For more information about updating Secure Network Analytics, refer to the
Update Guide.

Primary Node and Secondary Node

The online node is known as the Primary in the pair, while the offline node is the
Secondary. If the Primary node in the pair should fail, the Secondary node takes over and
becomes the Primary.

Requirements
l Forwarding Rules: Configure at least one forwarding rule for the UDP Director in
the High Availability system.
l Save the Rules Configuration File: If the UDP Director has already been configured
with rules, export (save the rules configuration file) the UDP Director rules. Then,
import the file to the second UDP Director to ensure that the rules for each match.
l Order: Configure the Primary UDP Director and then repeat the configuration on the
Secondary one.
l New or Established: If the both UDP Directors are new, make sure you follow the
procedures for each in this guide. However, if the secondary is already configured
as an appliance on the Secure Network Analytics system, log in to the secondary
UDP Director and configure its High Availability components as described here.

1. Configure the Primary UDP Director High Availability

1. Log in to the primary UDP Director.
2. Click Configuration > High Availability.

3. Check the Enable High Availability Service check box for the High Availability
Settings.

4. Select your Node ID. If this is a primary UDP Director, select 1. If this a secondary
UDP Director, select 2.
5. In the Virtual IP Address field, enter an unused IP adddress that is on the same
subnet as the eth0 interface. Set the Subnet Mask value to the value of the subnet
mask used on the eth0 interface.

Make sure the Virtual IP Address is the same on both nodes.

6. In the Shared Secret field, type a string for both UDP Directors. (This will be
encrypted for secure transfer.)
7. In the fields for Sync Ring #1 (eth2) Unicast IP Address, enter the IP address and
the subnet mask. (A Unicast IP Address identifies a single network destination.)
8. In the fields for Sync Ring #2 (eth3) Unicast IP Address, enter the IP address and
the subnet mask.

Each of the IP addresses--eth0, eth02, eth03--must be on its own separate unicast

subnet.

9. In the Paired Node Host Name field, enter the host name for the secondary UDP
Director.
10. In the Paired Node Sync Ring #1(eth2) IP Address field, enter the Eth2 IP address
for the secondary UDP Director.
11. In the Paired Node Sync Ring #1(eth3) IP Address field, enter the Eth3 IP address
for the secondary UDP Director.
12. After reviewing the setting, click Apply to set the configuration.
13. Continue to the next section to configure the second UDP Director of the cluster.

2. Configure the Secondary UDP Director High Availability

If you selected Node ID 2 in step 4 above, complete the steps below for the
primary UDP Director.

To configure the secondary UDP Director complete the following steps:

1. Log in to the secondary UDP Director.

2. Click Configuration > High Availability.

3. Enter the host name for the secondary UDP Director into the Paired Node Host
Name field.
4. Configure all of the parameters on this screen (including any Advanced Parameters
that you may have changed on the first appliance) exactly as you did on the first
appliance with exactly same values for every field except for the following:

l Sync Ring #1(eth2) Unicast IP Address: Enter a different IP address from

what you configured in this field on the primary, but it must be in the same
subnet as the Sync Ring 1 Unicast address given on the primary.
l Sync Ring #2(eth3) Unicast IP Address: Enter a different IP address from
what you configured in this field on the primary, but it must be in the same
subnet as the Sync Ring 2 Unicast address given on the primary.
l Paired Node Host Name: Enter the host name for the primary UDP Director in
this field.
l Paired Node Sync Ring #1(eth2) IP Address: Enter the Eth2 IP address for
the primary UDP Director in this field.
l Paired Node Sync Ring #1(eth3) IP Address: Enter the Eth3 IP address for
the primary UDP Director in this field.

5. Click Apply to save your changes and to start the clustering services on this
appliance.
6. Click Promote to designate the primary appliance.

Configuring the Flow Sensor

1. Configure the Application ID and Payload
The configuration of a Flow Sensor requires an additional step of configuring the
application ID and payload.

1. Log in to the Flow Sensor Appliance Admin interface.

2. Click Configuration > Advanced Settings.

The Advanced Settings page opens.

3. Select the proper settings for your network:

Item Description

Allows you to specify whether the Flow Sensor includes the first
Export Packet
26 bytes of binary payload data in the data that it sends to the
Payload
collector.

Allows you to specify whether the Flow Sensor attempts to

identify applications before sending data to the collector. In
addition, this setting must be enabled for the following settings to
take affect:
Include IPv6 – Allows you to specify whether or not the Flow
Sensor analyzes both IPv4 and IPv6 packets. When this setting is
disabled, the Flow Sensor analyzes only IPv4 packets.

Export Applications
Identification Export HTTPS Header Data – Allows you to specify whether the
Flow Sensor includes header data from HTTPS flows in the data
that it sends to the collector. The data includes the SSL common
name and SSL organization name. This setting requires that the
Flow Type is set to IPFIX. The maximum is 256 bytes.

Export HTTP Header Data – Allows you to specify whether or not

the Flow Sensor includes header data from HTTP flows in the data

Item Description

that it sends to the collector. When this setting is selected, a

secondary field allows you to specify the maximum length of the
HTTP path (in bytes) that the Flow Sensor includes as part of the
flow data. This setting requires that the Flow Type is set to IPFIX.

Allows you to specify whether the Flow Sensor uses Virtual

Extensible Local Area Network (VXLAN) decapsulation
capabilities. Without VXLAN decapsulation, the Flow Sensor
simply detects VXLAN encapsulated traffic as flows between two
Virtual Tunnel Endpoints (VTEPs). Decapsulation allows for much
Enable VXLAN
richer content by being able to analyze the tunneled traffic and
Decapsulation
thus gain greater insight into the traffic patterns in the network.

The Flow Sensor will only decapsulate VXLAN traffic

which was originally sent to the standard VXLAN port
(4789).

Allows you to specify whether the Flow Sensor uses Generic

Enable GENEVE
Network Virtualization Encapsulation (GENEVE) decapsulation for
Decapsulation
traffic received on its monitoring ports.

Allows you to specify whether to Flow Sensor uses Encapsulated

Remote Switching Port Analyzer (ERSPAN) decapsulation
capabilities to detect the ERSPAN header in packets, and then
Enable ERSPAN decapsulate the header and process the inner packet contents.
Decapsulation
You are required to assign the monitoring interface an IP address
to allow termination of the ERSPAN tunnel on the Flow Sensor.
ERSPAN decapsulation is not supported on the FS 4210.

Allows you to specify whether the Flow Sensor uses X-

Forwarded-For (XFF) processing to identify the originating IP
Enable X- address of a client connecting to a web server through an HTTP
Forwarded-For proxy or a load balancer.
Processing
ETA and X-Forwarded-For Processing cannot be
configured together.

Item Description

Allows you to specify whether the Flow Sensor uses ETA

processing to generate and transmit IDP and SPLT fields to your
Manager.

Enabling ETA increases NetFlow bandwidth usage,

especially when using v9. We recommend using IPFIX for
Enable ETA the Flow Export Format.
Processing
ETA and X-Forwarded-For Processing cannot be
configured together.

ETA cannot be enabled on Dell or PowerEdge Flow

Sensor models.

Allows you to specify whether the Flow Sensor 4000 series can
Enable Load distribute flow data to more than one Flow Collector.
Balancing Use this option if the flow data from the Flow Sensor exceeds the
capacity of one Flow Collector.

Allows you to specify the following:

l Flow Sensor 4240 - 2 x 40G or 4 x 10G (SFP) interfaces
l Flow Sensor 4300 - 2 x 40G/100G or 4 x 10G (SFP)
interfaces
Monitoring You must be using multiple Flow Collectors and have Load
Interface Selection Balancing enabled for this setting to work properly. Go to the Flow
Sensor and Load Balancer Integration Guide for more information.
This option is only available on the Flow Sensor 4240 and Flow
Sensor 4300.
The default setting is 2 x 40G.

Allows you to select one of the following settings:

Cache Mode
Use single, shared, cache for all monitoring ports –

Item Description

l Use when asymmetric routing is present.

l Single state table for application and latency calculations.
l Uses less memory.
l Lower overall pps processing rates.
l Results in one NetFlow event created across multiple
interfaces.
l Use only when the Flow Sensor has only two ports and is
connected by a TAP

Use independent caches for each monitoring port –

l Allows deduplication of packets across each Flow Sensor
interface.
l Uses more memory.
l Higher overall pps processing rates.
l Each interface maintains its own latency and application
database.
l Results in a unique NetFlow record for each interface that
sees a given packet.

You can change the IP mode (IPv4 or IPv6) for your Flow Sensor in
one of two ways:
l Logging into your Flow Sensor, removing the old IP address,
and adding the new IP address.
l Remove the Flow Sensor from Central Management, then
add it back to Central Management and provide the new
IP Mode Flow Collector IP address.

Updating the IP Mode by logging in to the Flow Sensor

Follow these steps to update the IP mode by logging into the Flow
Sensor.

1. Log in to your Flow Sensor.

2. Navigate to Configuration > NetFlow Collectors.

Item Description

3. Add the new IP address in the IP Address field under the

Add New Collector banner.
4. Add the port number in the Port field.
5. Click Add to add the new address.
6. Select the Delete check box next to the IP address you want
to remove.
7. Click Apply to save your changes.

Updating the IP Mode by Removing and Re-Adding the Flow

Sensor to Central Management

1. Log in to your Manager and select Configure > Global >

Central Management.

2. Click the three dots next to the Flow Sensor under Actions,
and then select Remove This Appliance.
3. Log in to your Flow Sensor appliance console
(SytemConfig).
4. Select Recovery > Add Appliance.
5. Follow the steps to add your Flow Sensor back to Central
Management.

4. Click Apply to save your settings.

2. Configure the Flow Sensor to Identify Applications (optional)

If you want the Flow Sensor to identify applications, configure the following settings:

1. Log in to the Flow Sensor Appliance Admin interface.

2. Click Configuration > Advanced Settings
3. Check the Export Application Identification check box. By default, this option is
not selected.

4. If you have more than 1 monitoring NIC, select one of the following options in the
Cache Mode section:

l Use single, shared, cache for all monitoring ports: typically used for
systems that monitor flows using the TAP method.

l Use independent caches for each monitoring port: typically used to

experience better performance and for systems that monitor flows using the
SPAN method.

3. Restart the Appliance

1. Select Operations > Restart Appliance.
2. Confirm the appliance status is Connected in Central Management.

BIOS Settings for 40 Gbps or 100 Gbps interfaces

In order to get optimal performance for 40Gbps or 100Gbps interfaces, you will need to
make a BIOS change to set the Workload Profile to "NIC Latency Sensitive". Follow the
steps below to change your BIOS settings.

1. Enter BIOS by entering F2 on the virtual console of the FS4300 at the Cisco bootup
splash screen.

2. Use your keyboard to navigate to the BIOS setting for Workload Profile by selecting
Advanced > AMD CBS > Workload Tuning > Workload Profile.
3. Select the NIC Latency Sensitive option.

4. Save your changes by navigating to Save & Exit.

9. Configuring Telemetry
If you've deployed Secure Network Analytics with a Data Store, your Flow Collectors can
ingest multiple types of telemetry simultaneously. You can configure your Flow Collectors
during First Time Setup or, if it is an existing Flow Collector, you can update the telemetry
ingest settings using Flow Collector Advanced Settings.

Network Visibility Module

If you select and configure Network Visibility Module - NVM, the Flow Collector will ingest
and store NVM flows. Follow the instructions in the Cisco Secure Network Analytics
Endpoint License and Network Visibility Module (NVM) Configuration Guide to complete
the configuration requirements.

Firewall Logs
If you select and configure Firewall Logs, the Flow Collector will ingest and store firewall
event logs for Cisco Security Analytics and Logging (On Premises). Follow the
instructions in the Security Analytics and Logging: Firewall Event Integration Guide to
complete the configuration requirements.

Updating Telemetry Settings

If you have an existing Flow Collector ingesting NetFlow or any other telemetry, you can
update your telemetry ingest settings using Flow Collector Advanced Settings. To access
Advanced Settings:

1. Log in to your Flow Collector (formerly known as Appliance Administration (Admin)

interface).
2. Select Support > Advanced Settings.

Each telemetry type has two settings. For more information on configuring
telemetry using Advanced Settings, follow the instructions in the Help. Select
(Help) icon > Help.

Cisco Telemetry Broker

Instead of using the UDP Director to send NetFlow to your Flow Collector, you now have
the option to use Cisco Telemetry Broker to ingest network telemetry from many inputs,
transform the telemetry format, and forward that telemetry to one or multiple destinations.
To install Cisco Telemetry Broker, follow the instructions in the Cisco Telemetry Broker
Virtual Appliance Deployment and Configuration Guide.

10. Licensing Secure Network Analytics

Use Cisco Smart Software Licensing to license your Secure Network Analytics appliances
and features. For more information, refer to Smart Licensing on cisco.com.
l Online: To use Smart Licensing and Secure Network Analytics online, please refer
to the Secure Network Analytics Smart Software Licensing Guide. You need Internet
access for this configuration.
l Offline: To discuss your licensing options for closed/airgap networks, contact
Cisco Support.
l Cisco Smart Account: To set up a Cisco Smart Account, register at
https://software.cisco.com or contact your administrator.

Evaluation Mode
When you use Secure Network Analytics in Evaluation mode, you can use selected
features for 90 days. To use Secure Network Analytics with maximum default
functionality, and to add licenses and features to your account, register your product
instance for Smart Software Licensing.

l Admin User: To review Smart Licensing status and usage details in your Manager,
log in as the admin user.
l Days Remaining: To review the days remaining in Evaluation Mode, log in to the
Manager as the admin user. Go to Central Management > Smart Licensing.
Review the License Authorization Status.
l Product Instance: The Product Instance Name is the identifier we use for your
Secure Network Analytics product instance, which includes your Manager and
managed appliances.

11. Managing Secure Network Analytics

After you have finished configuring your appliances, the Help provides instructions for
managing your environment, investigating behavior, responding to threats, and more.

To review the instructions, select the (Help) icon > Help from any page.

Configuring Host Groups

1. Log in to your Manager.
2. Select Configure > Detection > Host Group Management.

Creating and Managing Policies

1. Log in to your Manager.
2. Select Configure > Detection > Policy Management.

Building Flow Searches

1. Log in to your Manager.
2. Select Investigate > Flow Search.

Running Reports in Report Builder

1. Log in to your Manager.
2. Select Report > Report Builder.

Managing User Permissions

1. Log in to your Manager.
2. Select Configure > Global > User Management.

Investigating Behavior (Alarms, Security Events, etc.)

For information about investigating alarms, events, hosts, and more, review the
information in Help.

1. Log in to your Manager.

2. Click the (Help) icon .

3. Select Help.

4. At the top of the page, select the Help menu.

5. Select Investigating Behavior.

Responding to Threats
For policy information, review the information in Help.

1. Log in to your Manager.

2. Click the (Help) icon .

3. Select Help.
4. At the top of the page, select the Help menu.
5. Select Responding to Threats.

Packet Capture
For packet capture information, review the information in Help.

1. Log in to your Manager.

2. Click the (Help) icon .

3. From the top menu, select Resources > System Management > Appliance
Administration > Packet Capture.

Analytics
Secure Network Analytics uses dynamic entity modeling to track the state of your
network. In the context of Secure Network Analytics, an entity is something that can be
tracked over time, such as a host or endpoint on your network. Dynamic entity modeling
gathers information about entities based on the traffic they transmit and activities they
perform on your network. For more information, refer to the Analytics: Detections, Alerts,
and Observations Guide.
To install appliances, follow the instructions in the Virtual Edition Appliance Installation
Guide, the x2xx Series Hardware Appliance Installation Guide, or the x3xx Series
Hardware Appliance Installation Guide.

Apps
Secure Network Analytics apps are optional independently releasable features that
enhance and extend the capabilities of Secure Network Analytics.
The release schedule for Secure Network Analytics apps is independent from the normal
Secure Network Analytics upgrade process. Consequently, we can update Secure
Network Analytics apps as needed without having to link them with a core Secure
Network Analytics release. Occasionally, an app that is designed to correspond with a
new release of Secure Network Analytics may not be immediately available for
installation. You may need to wait a few weeks for the newest version of the app.
For the latest Secure Network Analytics apps information, availability, and compatibility,
refer to the following:
l Secure Network Analytics Apps Version Compatibility Matrix
l Secure Network Analytics Apps Release Notes

Authentication/Authorization
For details about each authentication or authorization configuration with Secure Network
Analytics, refer to the following instructions.

Name Instructions

Follow the instructions in the Help.

1. Log in to your Manager.

2. Select Configure > Global > User
LDAP Management.
3. Click the Configure Authentication and
Authorization link.

4. Select the (Help) icon > Help.

Follow the instructions in the Help.

1. Log in to your Manager.

2. Select Configure > Global > User
Management.
3. Click the Configure Authentication and
Authorization link.

4. Select the (Help) icon > Help.

You can prevent a local login by enabling the

Security Assertion Markup Language
SSO Only option. Use one of the following
Single Sign-On (SAML SSO)
methods to enable SSO Only.
l Appliance Console (SystemConfig)
l User Management

You will need to configure SSO in

User Management before you can
complete either of these
procedures. Refer to the Help for
instructions.

Enabling SSO Only in the Appliance

Console
1. Log in to your appliance console
(SystemConfig).
2. Select Advanced > SSO Only.
3. Enable SSO Only.

Enabling SSO Only in User

Management
1. Log into your Manager.
2. Select Configure > Global > User
Management.
3. Click the Authentication and
Authorization tab.
4. Click the ellipsis under the Actions
menu for your SSO service and select
Enable SSO Only.

TACACS+ Configuration Guide Refer to the TACACS+ Configuration Guide.

Domains
A domain is a grouping of hosts and other devices that you want to monitor and manage. Flow
Collectors exist within domains, and you can have multiple domains within one Secure
Network Analytics system. Domains are completely independent of other domains, and every
domain contains the Host Group tree. For information about which host groups exist in the
Host Group tree, see Managing and Configuring Host Groups in the Help.
This section includes the following topics:

l Data Store Domains and Non-Data Store Domains

l Adding and Configuring Domains
l Synchronizing Data Store and Non-Data Store Domains
l Deleting a Domain

Data Store Domains and Non-Data Store Domains

When you configure your Manager in the appliance console (SystemConfig) and set up your
system, you will create a Secure Network Analytics domain with a Data Store (Data Store
domain) or without a Data Store (Non-Data Store domain).

l Data Store Domain: The Flow Collector sends its telemetry to the Data Store Data
Nodes for storage.
l Non-Data Store Domain: The Flow Collector stores its telemetry locally on the Flow
Collector or on the Flow Collector database (5000 Series only).
l Hybrid Configuration: In Secure Network Analytics with a hybrid configuration, you can
configure a Data Store domain and Non-Data Store domain. When you configure your
Flow Collectors, you can choose which domain they will use, which determines where
they send data.

If you are adding a Data Store domain to a Non-Data Store deployment, review the
instructions in Adding Data Store to a Non-Data Store Deployment.

Adding and Configuring Domains

Use the following instructions to add a domain and define the domain settings. You can also
import a Non-Data Store configuration into a new Data Store domain.

l Role Permissions: You need Admin or Configuration Manager roles to configure

domains. Power Analysts can only view the domains.

l Data Store Domains: If you are adding a Data Store domain to a Non-Data Store
deployment, review the instructions in Adding Data Store to a Non-Data Store
Deployment before you start this procedure.

1. Add a Domain
1. From the main menu, choose [Current domain name] > Add Domain.

2. Configure the following fields:

l Domain Name: The name to be assigned to the domain. This name is shown on
the Host Group tree.
l Select Method: Select one of the methods described in the table below to
designate which host group structure you want to use for the domain you are
adding.

If you select this

Then...
method...

Secure Network Analytics creates the domain with the default host
Default
group structure but without any Flow Collectors.

Secure Network Analytics creates the domain and uses the

appropriate configuration, based on the specific domain content you
exported (host group, domain, or both). For information on exporting
XML files containing the domain configuration, refer to the Export
Import from File Settings section.

l XML files containing the domain configuration are not

backwards compatible. These files are only compatible within
the same system version number (for example, from Flow
Collector v7.0 to Manager v7.0).

If you select this

Then...
method...

l You can also import the entire host group configuration using
the Host Group Management page.
l If you need to import interface groups in the Network Devices
branch of the Host Group tree from another domain, use this
option. You must first export the groupings as an XML file to
your local drive.
l None of the Flow Collectors contained in the XML file is
imported.

If you add a Flow Collector to an existing domain, that domain's specific

configuration (policy, alarm severity, services, exporter SNMP, etc.) is applied to
this Flow Collector.

3. Check the Configure as a Data Store Domain check box if you are adding a Data Store
domain.

Do not turn on Analytics if you have created more than one Data Store domain as this
will cause Analytics to have sub-optimal performance.

4. Click Add to save your configuration.

Creating a Data Store Domain by Importing an Existing Non-Data Store

Domain Configuration (Optional)
If you are currently on a Non-Data Store domain and you want to add a Data Store domain to
your Secure Network Analytics system for a future expansion into Data Store, you can do so by
importing a Non-Data Store configuration into a new Data Store domain.
When you import a existing domain, you won’t have to re-configure items such as alarms, host
groups, and so on. Importing from an existing domain is like creating a new domain but with an
existing configuration.
If the domain is newly created, then you will have to re-configure your Secure Network
Analytics settings.
Follow the steps below to add a new Data Store domain and import all of its configuration from
your Non-Data Store domain.

1. Use the Add a Domain drop-down menu to select your Non-Data Store domain.
2. Select Configure > System > Domain Properties from the top menu.

3. Make sure the Export All configuration radio button is selected. Refer to Configuring
Domain Settings to view a list of the data that is exported.
4. Click the Export button to download the XML file.
5. In the upper left corner of any page, at the left end of the main menu, choose [Current
domain name] > Add Domain.
6. Enter a name for your new domain in the Domain Name field.
7. Click the Select Method drop-down menu and select the Import from File option.
8. Select the XML file you downloaded in step 4.
9. Click the Configure as a Data Store domain check box to select it.
10. Click the Add button to add your new domain.

2. Configure Domain Settings

1. Complete the following settings for the domain you are adding.

Setting Description

Domain Name Name for the domain you are currently in.

Allows you to set the time at which each Flow Collector in the
domain clears all counts. You can enter whole numbers between
0 and 23, where 0 is midnight in your local time zone. The local
time zone is indicated to the right of the Archive hour field.
Archive Hour
At the defined time, the Flow Collector resets all index counts to
0. In addition, the Flow Collector saves the log files and Web files
that it has gathered during the preceding 24 hours and then
begins a new day of data collection.

Click inside the Internal AS Numbers field and type your AS

numbers. Separate multiple entries with commas or by pressing
Enter after each entry to place each one on a separate line.
You can assign internal autonomous system (AS) numbers only to
Internal Autonomous domains that contain Flow Collectors When Secure Network
System (AS) Number Analytics encounters traffic containing these numbers in flow
data, it categorizes the traffic as "origin" traffic on the
Autonomous System Traffic document. Origin traffic signifies
traffic from or within your network as opposed to traffic from an
external network that is passing through your network (transit
traffic).

For information about the Autonomous System Traffic document,

see the "Autonomous System Traffic" topic in the Desktop Client
help.

2. Configure your Export Settings

The Export page on the Domain Properties dialog allows you to export specific domain
content. You may want to use the content as a template for any additional domains you
add in the future.

Refer to the following table for information about the available settings.

If you select this

Secure Network Analytics exports this data...
check box...

All of the data listed in "Export the Domain configuration" below. In

Export All
addition, a list of your flow collectors as well as your exporters and
configurations*
their interfaces are also exported.

Export the Host The entire host group definition structure, including the host group
Group configuration* names and IP address ranges. This output does not include policies.

l Archive hour setting from the Domain Properties dialog.

l All Service definitions. For information about services, see the
"Services" topic in the Desktop Client help.
l All Alarm Configuration settings. For information about
configuring alarms, see the "About Alarm Severities" topic in
the Desktop Client help.
Export the Domain l The entire host group structure, including the host group
configuration* names and IP address ranges. Refer to the Managing and
Configuring Host Groups topic in the Secure Network
Analytics Help for more information.
l All policies. Refer to the Managing Core Policies topic in the
Secure Network Analytics Help for more information.

Mitigation alarm actions are only exported when they have been
manually changed from the defaults (set to Not inherited).

* You can use any of the XML files resulting from these commands to replace the host group
configuration. For more information, see the "How to Replace the Host Group Configuration"
topic in the Desktop Client help.

3. Click Export.

Secure Network Analytics saves the corresponding settings in an XML file that is
downloaded to your Downloads folder.

Exporting a domain is not the same thing as backing up a configuration. To back up

an appliance configuration, refer to Creating an Appliance Configuration Backup

Synchronizing Data Store and Non-Data Store Domains

If you are in the process of transitioning a Non-Data Store Flow Collector to a Data Store Flow
Collector, you may want to keep your configurations and tuning synchronized between your
Non-Data Store domain and your Data Store domain. This section describes the process for
synchronizing your Non-Data Store domain with its associated Data Store domain.

Before You Begin

Ensure that you have already created a Data Store domain that you will be synchronizing with
your Non-Data Store domain. If you have already followed the process outlined in Adding a
Data Store to a Non-Data Store Deployment and Transitioning Your Flow Collectors, your
Data Store domain should already be created. Refer to Adding and Configuring Domains for
instructions on adding a domain.

You need administrator access for this procedure.

Synchronized Properties
The following properties will be synchronized between domains:

l Data Store domain specific configuration as well as alert configuration (if enabled).
Domain configuration includes:
l Host Group Management
l Alarm Severity
l Policy Management
l Services, Applications
l Exporter SNMP profiles (not including passwords)
l Domain AS Numbers.

Recommended Synchronization Frequency

While you can synchronize your domains as often as you like, we recommend that you limit
your synchronizations to only after you perform a group of changes or once a day or week.

This is because the synchronization process requires the use of resources that take away from
daily processing.

Synchronizing Domains Procedure

Follow these steps to synchronize your Non-Data Store domain (Source) with your Data Store
domain (Target).

1. From the menu bar, choose the Non-Data Store domain that you want to synchronize
with your Data Store domain.
2. From the main menu, choose Configure > System > Domain Properties.
3. Select the Edit button.
4. Choose the Data Store domain that you want to synchronize this domain with in the
Target Domain to Synchronize drop-down menu.

You can only synchronize your target Data Store domain with one source Non-Data
Store domain. If you attempt to synchronize your target Data Store domain with more
then one source Non-Data Store domain, you will receive an error.

5. Click the Save button to save your changes. A synchronize button appears next to the
Non-Data Store domain that you selected to synchronize with your Data Store domain.

Removing a Domain Synchronization Target Domain

Follow the steps below to remove a target domain.

1. From the menu bar, choose the Non-Data Store domain that you want to synchronize
with your Data Store domain.
2. From the main menu, choose Configure > Domain Properties.
3. Select the Edit button.
4. Click the Clear Target Domain button.
5. Click the Save button to save your changes.

Deleting a Domain
Before you delete a domain, review these instructions to make sure you understand the
requirements.

When you delete a domain, you will lose access to all data that has been collected for
that domain. Make sure you only delete a domain if you no longer need access to the
collected data in it.

1. Remove Flow Collectors from Central Management

If your domain includes Flow Collectors, remove them from Central Management before you delete
the domain. You can add the Flow Collectors to another domain, but the procedure includes
resetting them to their factory defaults (RFD). For instructions, refer to the following:

1. Removing an Appliance from Central Management

2. Resetting Factory Defaults
3. Adding an Appliance to Central Management

If you remove Flow Collectors from Central Management and delete the domain, you will
lose the associated Flow Collector data.

2. Delete a Domain
1. If you first need to access the domain, choose the [Current domain name] from the drop-
down menu.

2. From the main menu, choose Configure > System > Domain Properties.
3. Click Delete Domain.

When you delete a domain, you will lose access to all data that has been collected for
that domain. Make sure you only delete a domain if you no longer need access to the
collected data in it.

Deleting a Desktop Client Domain

If you are using the Desktop Client in Secure Network Analytics without a Data Store, you can also
delete domains from the Desktop Client.

Use caution when deciding which Desktop Client domains you want to delete as you will
lose access to all data which has been collected for the domain you are deleting.
Workaround: If you accidentally delete all of your domains in the Desktop Client and lock
yourself out of the Manager Web App, create a new Non-Data Store domain in the
Desktop Client. This will allow you to regain access into the Manager Web App. For
information on creating a domain refer to the Add a Domain topic in the Desktop Client
help.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 145 -
Integrations and Additional Configurations

Integrations and Additional Configurations

We have the following additional integrations and configurations available at
https://www.cisco.com/c/en/us/support/security/stealthwatch/products-installation-
and-configuration-guides-list.html. There may be more integrations than the list shown
here.
l Configuring Cisco's ASA for NSEL Export to Stealthwatch
l Customer Success Metrics Configuration Guide
l Enabling Multiple NetFlow Exporters
l Network Visibility Module (NVM) Configuration Guide
l Flow Sensor and Load Balancer Configuration Guide
l ISE and ISE-PIC Configuration Guide
l Secure Network Analytics and SecureX Integration Guide
l SSL/TLS Certificates Guide for Managed Appliances
l TACACS+ Configuration Guide
l Cisco Security Analytics and Logging (On Premises)

Passwords
You can change passwords as follows:
l Resetting Passwords to Default Settings
l Changing Passwords
l Changing the Data Store Database Passwords
l Changing the Flow Collector Database Password (Non-Data Store Domains)

Resetting Passwords to Default Settings

There are a two ways to reset your passwords to their default settings.
l Admin Password: Use Resetting the Admin Password on Your Appliance
l Admin and Sysadmin Passwords: Use Resetting Sysadmin Passwords to
Default.

After you reset your appliance passwords to the default, make sure you change
them. This step is critical for security. Refer to Changing Passwords for
instructions.

Resetting the Admin Password on Your Appliance

Use the following instructions to reset your admin password to the default setting. Then,
change the appliance password for maximum security. This process works on all
appliances.
l Requirements: You need the appliance sysadmin password to complete these
instructions.
l Other Users: These instructions reset the admin user to the default password. The
individual user passwords will not be changed.
l Other Appliances: These instructions do not reset the admin password on other
Secure Network Analytics appliances (Flow Collector, Flow Sensor, or
UDP Director).

1. Log in to the Manager appliance console (SystemConfig) as sysadmin.

2. Select Security > Web Admin Password.
3. Click OK.

This will reset admin password to the default value.

4. Exit the appliance console.

5. Go to Changing Passwords to change the admin password from the default. This
step is critical for security.

Resetting Sysadmin Passwords to Default

Contact Cisco Support for assistance with this process.

Changing Passwords
Use the following instructions to change your passwords from the default password or a
previous password. Make sure you use the following criteria:

l Length: 8 to 256 characters

l Change: Make sure the new password is different from the previous
password by at least 4 characters.

User Default Password

admin lan411cope

sysadmin lan1cope

Changing the Sysadmin Password

1. Log in to the appliance console as sysadmin.
2. Select Security.
3. Select Password.
4. Follow the on-screen prompts to change the sysadmin password.
5. Exit System Configuration.

Changing the Admin Password on the Manager

1. Log in to the Manager as admin.

l URL: https://<IPAddress>
l Login: admin
l Default Password: lan411cope

2. Select Configure > Global > User Management.

3. Locate the admin user in the list.
4. Click the Actions menu. Select Change Password.
5. Follow the on-screen prompts to change the admin password. Use the following
criteria:

l Length: 8 to 256 characters

l Change: Make sure the new password is different from the default password
by at least 4 characters.

Changing the Admin Password on All Other Appliances

Use the following instructions to change the admin user password on a Data Node, Flow
Collector, Flow Sensor, or UDP Director.

1. Log in to the Appliance Administration interface as admin.

l URL: https://<IPAddress>
l Login: admin
l Default Password: lan411cope

2. Select Manage Users > Change Password.

3. Enter the current password and new password.
4. Click Apply. Follow the on-screen prompts to change the password.
5. To change the admin password on another appliance, repeat steps 1 through 4.

Changing the Data Store Database Passwords

Use System Configuration to change your Data Store database passwords (dbadmin and
readonlyuser). You need to enable SSH temporarily as part of this procedure.

1. Log in to your Manager appliance console (SystemConfig) as sysadmin.

2. From the main menu, select Data Store.
3. Select SSH. Follow the on-screen prompts to enable SSH.
4. Select Passwords from the Data Store menu.
5. Follow the on-screen prompts to change the passwords.

Your previous SSH settings are restored when you exit the Data Store menu.

Changing the Flow Collector Database Password (Non-Data

Store Domains)
Use the Database tab on the Central Management page to update your Flow Collector
database password for all Flow Collector databases in a Non-Data Store domain.

Make sure you change the default password. When a new Flow Collector is
added to Central Management, the database password automatically updates to
match the current password.

1. Open Central Management.

2. Click the Database tab.
3. To generate a random password, click the Generate Password button, otherwise
enter your password in the Password and Confirm Password fields.
4. Check the Show Password check box to view your chosen password.
5. Click the Apply Settings button to save your changes.

When you change a database password, only Non-Data Store Flow Collectors
and Transition Flow Collectors will receive the new password.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 150 -
SSL/TLS Appliance Identity and Additional SSL/TLS Client Identities

SSL/TLS Appliance Identity and

Additional SSL/TLS Client Identities
Use SSL/TLS Appliance Identity and Additional SSL/TLS Client Identities to manage your
Secure Socket Layer (SSL) and Transport Layer Security (TLS) Certificates for the
selected appliance. Follow the instructions in the SSL/TLS Certificates for Managed
Appliances Guide for all certificate-related changes.

Your certificates are critical for your system’s security. Improperly modifying
your certificates can stop Secure Network Analytics appliance communications
and cause data loss. Follow the instructions in the SSL/TLS Certificates for
Managed Appliances Guide for all certificate-related changes.

To change the configuration, follow the instructions in the SSL/TLS Certificates for
Managed Appliances Guide.

Appliance Identity
Each Secure Network Analytics version 7.x appliance is installed with a unique, self-
signed appliance identity certificate. To replace the appliance identity certificate, follow
the instructions in the SSL/TLS Certificates for Managed Appliances Guide.
The appliance uses the SSL certificate to verify its identity to other appliances. For
example, when a Manager generates a flow query and communicates to a Flow Collector,
the Manager is authenticated by presenting its server identity certificate. The Flow
Collector checks if this presented server identity certificate is a trusted certificate.

Client Identity
The client identity is used for communication between external services. For details,
follow the instructions in the SSL/TLS Certificates for Managed Appliances Guide.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 151 -
SSL/TLS Appliance Identity and Additional SSL/TLS Client Identities

Reviewing Certificates
Use the following instructions to review the appliance identity certificate or client
certificates for the selected appliance. You can review details such as the friendly name,
issued information, and expiration date.

Make sure you replace your appliance identity certificates before they expire. To
generate new certificates or add custom appliance identity certificates, follow
the instructions in the SSL/TLS Certificates for Managed Appliances Guide.

1. Open Central Management.

2. Click the (Ellipsis) icon for the appliance.
3. Select Edit Appliance Configuration.
4. Select the Appliance tab.
5. To review the appliance identity certificate, go to the SSL/TLS Appliance Identity
section.

To review the client identity certificates, go to the Additional SSL/TLS Client

Identities section.

6. Expiration Date: Review the Valid To column.

Changing the Host Name, Network Domain Name, or IP

Address
To change the appliance host name, network domain name, or IP address after you've
installed and configured your appliances, follow the instructions in the SSL/TLS
Certificates for Managed Appliances Guide.
As part of the procedure, you will remove the appliance from Central Management
temporarily. You will be given the option to regenerate your appliance identity certificate
and in some cases, you can skip the regeneration altogether.

If you are using custom certificates, save your certificates before you change
your network settings in case you accidentally overwrite them. To replace

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 152 -
SSL/TLS Appliance Identity and Additional SSL/TLS Client Identities

appliance identity certificates, follow the instructions in the SSL/TLS Certificates

for Managed Appliances Guide.

Reviewing Trust Store Certificates

When you add a certificate to an appliance trust store, you are allowing communication
with that identity, whether it is another Secure Network Analytics appliance or an external
service.
l Instructions: Follow the instructions in the SSL/TLS Certificates for Managed
Appliances Guide for all trust store changes.
l Upload Individual Files: If your file includes more than one certificate, upload each
certificate individually to the trust store.

For requirements and intsructions, refer to the SSL/TLS Certificates for Managed
Appliances Guide.

Use the following instructions to review the certificates saved to the selected appliance
Trust Store.

1. Open Central Management.

2. Click the Actions menu for the appliance.
3. Select Edit Appliance Configuration.
4. Select the General tab.
5. Review the Trust Store list.

Threat Feed
The Cisco Secure Network Analytics Threat Feed (formerly Stealthwatch Threat
Intelligence Feed) provides data from the global Threat Feed about threats to your
network. The feed updates frequently and includes IP addresses, port number, protocols,
host names, and URLs known to be used for malicious activity. The following host groups
are included in the feed: command-and-control servers, bogons, and Tors.

Licensing
Add the Threat Feed License to your Cisco Smart Account. For instructions, refer to the
Secure Network Analytics Smart Software Licensing Guide.

Enabling
To enable the feed in Central Management, follow the instructions in the help. Please note
that you will configure the DNS server and firewall as part of the instructions. Also, if you
have a failover configuration, you need to enable Threat Feed on your primary Manager
and secondary Manager.

1. Log in to your primary Manager.

2. Select Configure > Global > Central Management.

3. Click the (Help) icon . Select Help.

4. Select Appliance Configuration > Threat Feed.

Reviewing Alarms and Security Events

When the Threat Feed is enabled, the Stealthwatch Labs Intelligence Center icon is
shown in the Desktop Client Enterprise tree with an alarms status, and threats are
displayed in their respective host group branches. For more information, refer to the
Desktop Client User Guide or the Help.

Help: To access the Help, right-click the Stealthwatch Labs Intelligence Center
branch and select Configuration > SLIC Threat Feed Configuration. Click Help.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 155 -
Central Management (Managing your Appliances)

Central Management (Managing your

Appliances)
Use Central Management to manage your appliances from your primary Manager. We've
included an overview of Central Management here, and details for each section are
available in Help.
l About Central Management: When your appliances are managed by Central
Management, you can review their status and manage the following: edit appliance
configuration, update software, reboot, shut down, and more.
l
Help: To open the Help, click the (Help) icon . Select Help.

This section covers the following topics:

l Central Management and Appliance Administration Interface
l Opening Central Management
l Opening Appliance Admin
l Editing the Appliance Configuration
l Viewing Appliance Statistics
l Removing an Appliance from Central Management
l Adding an Appliance to Central Management
l Creating an Appliance Configuration Backup
l Enabling/Disabling SSH

Central Management and

Appliance Administration Interface
When an appliance is managed by Central Management, you will access functions for
your appliance in Central Management and the Appliance Administration interface
(Appliance Admin) as follows:

Central Management Appliance Admin Interface

Edit appliance configuration View system statistics

Review license status (overview)

Back up configuration files Back up database files

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 156 -
Central Management (Managing your Appliances)

View audit logs Create diagnostics packs

Reboot Network Host and IP Lookup

Shut down Packet Capture

Update software Clearing the DNS Cache

Appliance-specific configurations

If you configure a Flow Collector for Data Store compatibility, the Appliance
Administration interface (Appliance Admin) hides certain functionality. Use
Central Management to configure the Flow Collector and other related tasks.

Opening Central Management

1. Log in to your primary Manager.
2. Select Configure > Global > Central Management.

Opening Appliance Admin

You can access the Appliance Admin interface through Central Management or by
logging in to the appliance directly.

Opening Appliance Admin through Central Management

1. On the Central Management Inventory page, click the Actions menu for the
appliance.
2. Select View Appliance Statistics.
3. Log in to the Appliance Administration interface.

Opening Appliance Admin through Direct Login

1. In your browser address bar, type the appliance IP address as follows:

https://<IPAddress>
l Manager: add /Manager/index.html after the IP address.
l For example: https://1.1.1.1/Manager/index.html

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 157 -
Central Management (Managing your Appliances)

2. Press Enter.

Editing the Appliance Configuration

1. On the Central Management Inventory page, click the Actions menu for the
appliance.
2. Select Edit Appliance Configuration.

3. Click the Configuration menu. Select an item from the list.

or
Click each tab to review each configuration category.

4. Make changes to each configuration section as needed. You can edit more than one
configuration category on each configuration tab.

For instructions, click the (User) icon .

5. Click Apply Settings. Follow the on-screen prompts to save your configuration
changes.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 158 -
Central Management (Managing your Appliances)

Some changes require a system reboot. If you prefer to wait, you can revert your
changes and edit your configuration settings and reboot later.

The appliance reboots automatically. Do not force the appliance to reboot while
configuration changes are pending. To confirm the appliance status is
Connected, review Central Management > Inventory.

6. Connected: On the Inventory page, make sure the appliance finishes the
configuration changes and the Appliance Status returns to Connected.

Viewing Appliance Statistics

Hover: For more information about each appliance status, hover your pointer over the
status.
To see system statistics, services, disk usage, and docker services, log in to the
Appliance Admin interface:

1. On the Central Management Inventory page, click the Actions menu for the
appliance.
2. Select View Appliance Statistics.
3. Log in to the Appliance Administration interface.

Removing an Appliance from Central Management

Use the following instructions to remove an appliance from your Central Manager.

1. On the Central Management Inventory page, click the Actions menu for the
appliance.
2. Select Remove This Appliance.

l Data Store Appliances: Go to Removing Data Store Appliances from

Central Management for additional requirements.
l Flow Collectors: If you removed a Flow Collector from Central Management,
it is also removed from the domain. You need to reset the factory defaults
(RFD) if you plan to add it to a different domain. Go to Adding an Appliance to
Central Management and Removing an Appliance from Central
Management for instructions.
l Config Channel Down: If you're removing the appliance because the
configuration channel is down, go to the Config Channel Down procedure in
Troubleshooting for additional instructions.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 159 -
Central Management (Managing your Appliances)

l Troubleshooting: If you log in to the Appliance Admin interface and the

appliance is not removed from Central Management, go to the Config Channel
Down procedure in Troubleshooting to remove it using System Configuration.
l Central Management: To add the appliance to a different Central Manager,
use the appliance console (SystemConfig).

If your appliance has custom certificates, save your certificates in case you
accidentally overwrite them. For instructions, refer to the SSL/TLS Certificates
for Managed Appliances Guide.

Removing Data Store Appliances from Central Management

If you remove Data Store appliances from Central Management (Manager, Flow Collector,
Data Node), it does not remove them from all necessary configuration files . The following
files need to be manually cleaned up.
l Managers and Flow Collectors: For Managers and Flow Collectors removed from
Central Management, you will need to remove the IP addresses of these devices
from the /lancope/var/services/data-store/config-datastore-inventory-
snapshot directory before attempting to re-add them to Central Managenent.
l Data Nodes: If you are attempting to remove/re-add a Data Node appliance
entirely, contact Cisco Support for assistance with the removal Data Nodes as
l that process is more complicated.

Adding an Appliance to Central Management

Use the appliance console (SystemConfig) to add an appliance to Central Management. It
is important to review the following:
l Custom Certificates: If your appliance has custom certificates, save your
certificates in case you accidentally overwrite them. For instructions, refer to the
SSL/TLS Certificates for Managed Appliances Guide.
l Manager Administration Credentials: You need the Manager, user ID and
password to add an appliance to Central Management.
l RFD: If you reset the factory defaults on an appliance, make sure you complete the
First Time Setup process For instructions, refer to 1. Configuring Your
Environment Using First Time Setup.
l New Installations: If this is a new installation, make sure you complete the First
Time Setup process. For instructions, refer to 1. Configuring Your Environment

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 160 -
Central Management (Managing your Appliances)

Using First Time Setup.

1. Log in to the appliance console (SystemConfig).

2. Select Recovery.
3. Select Add Appliance.

If you don't see the Add Appliance menu in the screen above, you will need to
first remove your appliance before you can re-add it.

4. Follow the on-screen prompts to enter the Manager administration credentials and
finish the configuration. Depending on the type of appliance, you may need to enter

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 161 -
Central Management (Managing your Appliances)

additional information.

Creating an Appliance Configuration Backup

Use Central Management to back up an appliance configuration.

Before you back up an appliance, make sure you follow the instructions in the
Help. To back up a Data Store, refer to Creating a Data Store Backup. To back
up a Flow Collector database, refer to Creating a Database Backup (Non-Data
Store Domains).

1. Open Central Management.

2. Click the (Ellipsis) icon for the appliance.
3. Select Support.
4. Select the Configuration Files tab.

5. Select the (Help) icon . Follow the instructions in the Help.

To restore an appliance configuration backup, follow the instructions in the Help.

Enabling/Disabling SSH
Use this section to control the ability to access the appliance using SSH (secure shell).
You can enable/disable SSH from the web UI/Central Management or from the appliance
console (System Config).
Default: disabled

Enabling/Disabling SSH from the Web UI/Central Management

When SSH is enabled, the system’s risk of compromise increases. It is important

to enable SSH only when you need it. When you are finished using SSH, disable
it.

Access the SSH Configuration

Use the following instructions to open SSH for a selected appliance.

1. Open Central Management.

2. Click the Actions menu for the appliance.
3. Select Edit Appliance Configuration.
4. Select the Appliance tab.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 162 -
Central Management (Managing your Appliances)

Enable SSH
1. Locate the SSH section.
2. To allow SSH access on the appliance, check the Enable SSH check box.
3. Click Apply Settings.
4. Follow the on-screen prompts.

Disable SSH
1. To remove SSH access on the appliance, click the Enable SSH check box to clear it.
2. Click Apply Settings.
3. Follow the on-screen prompts.

Enable/Disable SSH from the Appliance Console (SystemConfig)

1. Log in to your appliance console (SystemConfig)
2. Select Advanced > SSH.
3. Select the option to enable or disable SSH and then click OK.

Any change you make to SSH in the appliance console (SystemConfig) will not
sync to Central Management. Be sure to undo your SSH change when finished to
ensure it is in sync with Central Management. If you do not undo your change,
any subsequent configuration changes in Central Management will reset the
SystemConfig SSH state to the current Central Manager configuration state.

Enabling/Disabling Sysadmin User

Use this section to control the ability to access the appliance using the sysadmin user.
The sysadmin user is required to access the Appliance Console (SystemConfig) utility.
Default: enabled

Access the Sysadmin User Configuration

Use the following instructions to access the Sysadmin User for a selected appliance.

1. From the main menu, select Configure > Global > Central Management.
2. From the Inventory tab, click the (Ellipsis) icon for the appliance.
3. Select Edit Appliance Configuration.
4. Select the Appliance tab.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 163 -
Central Management (Managing your Appliances)

Enable Sysadmin User

1. Locate the Sysadmin User section.
2. To allow sysadmin user access on the appliance, check the Sysadmin User check
box.
3. Click Apply Settings.
4. Follow the on-screen prompts.

Disable Sysadmin User

1. To remove sysadmin user access on the appliance, click the Sysadmin User check
box to clear it.
2. Click Apply Settings.
3. Follow the on-screen prompts.

© 2024 Cisco Systems, Inc. and/or its affiliates. All rights reserved. - 164 -
Creating a Database Backup (Non-Data Store Domains)

Creating a Database Backup (Non-Data Store

Domains)
Use the following instructions to back up your Manager and Flow Collector databases. To
back up the Data Store, refer to Creating a Data Store Backup.

Without a backup, you will not be able to recover your files if a problem occurs
during the update process. Make sure you follow the instructions and complete
all procedures for the database backup. Also note that this procedure only
applies to Non-Data Store Flow Collectors. For assistance, contact Cisco
Support.

This process involves completing the following procedures:

1. Trim the Flow Collector Database

2. Back Up to Remote File System

1. Trim the Flow Collector Database

The Flow Collector database backup can take multiple days to finish and will slow your
network speed if the database is large. Before you back up your databases, we
recommend trimming the Flow Collector database. This will free the available disk space
for storing flows and reduce the amount of time it takes to back up the database.
The Flow Collector stores the maximum number of days based on the disk space and the
amount of data collected per day. When the maximum (75% of the /lancope/var partition)
is hit, the database will start to delete the oldest data first to allow new data to come in.

1. Review your Database Storage Statistics

Use the following instructions to check your database storage.

1. Log in to the Flow Collector Appliance Admin interface.

2. Select Support > Database Storage Statistics.
3. Review the days stored in Capacity, Flow Data Summary, and CI Event Data
Summary (or Security Event Data Summary).

2. Trim the Interface Details

The Flow Interface Data is the data related to the interfaces of exporters. Secure Network
Analytics saves flow interface data and flow data.
The Flow Interface default setting causes the system to push out the flow data, so it can
keep all the interface statistics it can. This function uses the Desktop Client as a main tool
which does not apply to Data Store systems. A node may be needed to indicate that the
trimming procedure only applies to Non-Data Store systems.

Backing up this data takes time. If you don't need all of it, shorten the storage limit (for
example: 7 days). Any data older than the limit will be lost.

Use the following instructions to purge the database of the interface statistics data older
than the limit you set, so you can free up the available disk space for storing flows.

1. Log in to Desktop Client as the admin user.

2. Locate the Flow Collector in the Enterprise Tree. Click the plus (+) sign to expand
the container.
3. Right-click the Flow Collector. Select Configuration > Properties.
4. In the Flow Collector Properties dialog box, click Advanced.
5. Select the Store flow interface data.
6. Shorten the storage limit. For example, if you set the limit to Up to 7 days, anything
older than 7 days will be lost.
7. Click OK.
8. Wait 5 minutes to proceed to the next steps.

3. Trim Flow Details and CI Event Data

To reduce the size of the Flow Details and CI Event/Details in the Flow Collector database,
contact Cisco Support. This step is optional, and the trimming process takes only a few
minutes to complete, but the process requires guidance.
When you trim the NetFlow, you will specify the number of days to keep Flow Details & CI
Event/Details in the Flow Collector database. Two things will occur with this configuration:
l The database is trimmed down to the number of days you enter.
l The database starts rolling the older data out based on the oldest day but without
trying to save as much as possible.

2. Back Up to Remote File System

To back up a database to a remote file system, complete the following steps:
l Space: Make sure the remote file system has enough space to store the database
backup.
l Time: After you back up the database once, subsequent backups will be quicker
because the process backs up only what has changed since the last backup. This
process backs up approximately 0.5 GB to 2 GB of data per minute.

1. Return to the Appliance Admin interface (but do not close the Desktop Client).
2. Determine how much space you will need on the remote file system to store the
database backup as follows:

l Click Home.
l Locate the Disk Usage section.
l Review the Used (byte) column for the /lancope/var file system. You will
need at least this much space plus 15% more on the remote file system to
store the database backup.

3. Click Configuration > Remote File System.

4. Complete the fields using the settings for the remote file system where you want to
store the backup files.

The file share uses the CIFS (Common Internet File System) protocol, also known as
SMB (Server Message Block).

5. Click Apply to place the settings in the configuration file.

If the Apply button is not enabled after you enter the password, click once in a blank
area on the Remote File System page to enable it.

6. Click Test to verify that the appliance and the remote file system can communicate
with each other.

You should see the following message at the bottom of the Remote File System
page when the test is complete.

7. Click Support > Backup/Restore Database. The Backup Database page opens as
shown in the following example.

8. Click Create Backup. This process may take a long time.

l After the backup process starts, you can mouse away from the page without
interrupting the process. However, if you click Cancel while the backup is in
progress, you may not be able to resume the backup without restarting the
appliance.
l Follow the on-screen prompts until the backup is completed.
l To view details of the backup process, click View Log.

9. Click Close to close the progress window.

Restoring a Database Backup (Non-Data

Store Domains)
Contact Cisco Support for assistance with planning and implementing these
tasks.

Data Store Database

If you've configured Secure Network Analytics with a Data Store, you can access the Data
Store tab in Central Management.

To add Data Store to your configuration, refer to Adding a Data Store to a Non-
Data Store Deployment and Transitioning Your Flow Collectors and Adding
Data Store to a Non-Data Store Deployment.

Data Store Tab

Use the Data Store tab in Central Management to:
l Status: View the status of your database or any Data Node. For details, refer to
Viewing the Data Store Database Status.
l Start or Stop: You can also start or stop the database or any Data Node. For details,
refer to Viewing the Data Store Database Status.
l Storage Usage: View the current storage usage statistics for your database. You
can also modify retention status for flow interface data. For details, refer to Viewing
Database Retention.
l Update Status: View the status of all Data Nodes during updates. For details, refer
to Monitoring the Data Node Update Status.

Be sure to enable SSH on all Data Nodes. If SSH is not enabled on all Data
Nodes, some database actions will not be able to complete successfully.

Opening the Data Store Tab

1. Log in to your Manager.
2. Select Configure > Global > Central Management.
3. Click the Data Store tab.

Viewing the Data Store Database Status

The Database Control page opens when you click the Data Store tab in Central
Management. This tab displays the status of the database and each Data Node.
l Sorting: The Data Nodes on this tab are sorted by their Private LAN IPs by default.
You can re-sort the Data Nodes nodes by clicking the column header by which you
want to sort.

l Status: Under normal conditions, your database and all Data Nodes will show a
status of Up. Your database may be Up but the status of one of your Data Nodes
could be Down. After recovering a failed Data Node, you may see your database
showing as Up but your newly recovered Data Node will be in a "recovering” state.
l Actions Menu: Make sure you use the Actions menu to start or stop your database
(or a Data Node).

Make sure you use the Actions menu to start or stop your database (or a Data
Node).

Starting the Database

1. Ensure that the Database Control tab is selected.
2. Click the (Ellipsis) icon in the Actions column for the database.
3. Select Start.
4. Confirm the database status is shown as Up.

Stopping the Database

1. Ensure that the Database Control tab is selected.
2. Click the (Ellipsis) icon in the Actions column for the database.
3. Select Stop.
4. Confirm the database status is shown as Down.

Starting a Data Node

Follow the steps below to start a Data Node.

1. Ensure that the Database Control tab is selected.

2. Find the Data Node you want to start. Click the (Ellipsis) icon in the Actions
column.
3. Select Start to start the Data Node.
4. Confirm the Data Node status is shown as Up.

Stopping a Data Node

Follow the steps below to stop a Data Node.

1. Ensure that the Database Control tab is selected.

2. Find the Data Node you want to stop. Click the (Ellipsis) icon in the Actions
column.
3. Select Stop to stop the Data Node.
4. Confirm the Data Node status is shown as Down.

Reviewing Last Action Results

Only one action may be in progress at any time regardless of the number of users. When
an action is in progress, no other actions can be taken. Once an action has completed, the
completion status will be displayed for all users in a banner at the top of the screen.
Follow the steps below to review last action results.

1. Ensure that the Database Control tab is selected.

2. Click the Last Action Results link at the bottom of the screen. The Action Results
banner will remain on screen until you dismiss it.

Viewing Database Retention

The Database Retention tab answers questions such as:
l How full is my database?
l How much is each telemetry type (NetFlow, NVM, firewall log) contributing to this
fullness?
