SUN2000-(20KTL, 29.

9KTL, 30KTL, 36KTL, 40KTL)-

M3 Series

User Manual

Issue 23
Date 2025-07-15

HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2025. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.

Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees
or representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China

Website: https://e.huawei.com

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. i

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual About This Document

About This Document

Purpose
This document describes the following inverter models (also referred to as
SUN2000) in terms of the safety precautions, product introduction, installation,
electrical connections, power-on and commissioning, maintenance, and technical
specifications. Read this document carefully before installing and operating the
inverter.

● SUN2000-20KTL-M3
● SUN2000-20KTL-BRM3
● SUN2000-29.9KTL-M3
● SUN2000-30KTL-M3
● SUN2000-30KTL-BRM3
● SUN2000-36KTL-M3
● SUN2000-40KTL-M3
● SUN2000-40KTL-BRM3

Intended Audience
This document is intended for:

● Installers
● Users

Symbol Conventions
The symbols that may be found in this document are defined as follows.

Symbol Description

Indicates a hazard with a high level of risk which, if not

avoided, will result in death or serious injury.

Indicates a hazard with a medium level of risk which, if not

avoided, could result in death or serious injury.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. ii

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual About This Document

Symbol Description

Indicates a hazard with a low level of risk which, if not

avoided, could result in minor or moderate injury.

Indicates a potentially hazardous situation which, if not

avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.

Supplements the important information in the main text.

NOTE is used to address information not related to personal
injury, equipment damage, and environment deterioration.

Change History
Changes between document issues are cumulative. The latest document issue
contains all the changes made in earlier issues.

Issue 23 (2025-07-15)
Updated 5.5 Connecting DC Input Power Cables.

Issue 22 (2025-03-10)
Updated A Grid Codes.

Issue 21 (2025-01-21)
Updated 2.3 Label Description.

Issue 20 (2024-12-17)
Updated A Grid Codes.

Issue 19 (2024-08-20)
Updated About This Document.

Updated 1.2 Electrical Safety.

Updated 2.1 Product Introduction.

Updated 2.3 Label Description.

Updated 3 Inverter Storage.

Updated 4.3 Determining the Installation Position.

Updated 5.2 Preparing Cables.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. iii

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual About This Document

Updated 10 Technical Specifications.

Updated A Grid Codes.
Updated G Setting Dry Contact Scheduling.
Updated H Setting the Current Threshold for Triggering RCD Protection.

Issue 18 (2024-03-10)
Added 7.3.2 Setting Feed-in at Limited Current.
Updated A Grid Codes.

Issue 17 (2024-02-02)
Updated 10 Technical Specifications.

Issue 16 (2024-01-12)
Updated 2.2 Appearance.
Updated 3 Inverter Storage.
Updated 4.4 Moving the Inverter.
Updated 5.1 Precautions.
Updated 5.2 Preparing Cables.
Updated 5.4 Connecting an AC Output Power Cable.
Updated 5.5.1 Cable Connection Description.
Updated 8.3 Alarm Reference.
Updated 10 Technical Specifications.
Updated A Grid Codes.
Updated M Contact Information.
Added N Digital Power Customer Service.

Issue 15 (2023-11-08)
Updated 4.3 Determining the Installation Position.
Updated 5.3 Connecting the PE Cable.
Updated 5.7.1 Communication Modes.
Updated 7 Human-Machine Interaction.
Updated 10 Technical Specifications.

Issue 14 (2023-09-20)
Updated 5.5.1 Cable Connection Description.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. iv

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual About This Document

Issue 13 (2023-04-28)
Updated A Grid Codes.

Added L Locating Insulation Resistance Faults.

Updated M Contact Information.

Issue 12 (2023-02-28)
Updated 2.1 Product Introduction.

Updated 5.2 Preparing Cables.

Updated 5.6 (Optional) Installing the Smart Dongle.

Updated 10 Technical Specifications.

Issue 11 (2023-01-10)
Updated 1 Safety Information.

Updated 2.3 Label Description.

Updated 4.2 Tools.

Updated 7 Human-Machine Interaction.

Updated 8.3 Alarm Reference.

Updated 10 Technical Specifications.

Added M Contact Information.

Issue 10 (2022-09-26)
Updated 5.2 Preparing Cables.

Updated 5.4 Connecting an AC Output Power Cable.

Issue 09 (2022-06-30)
Updated 5.2 Preparing Cables.

Updated 5.4 Connecting an AC Output Power Cable.

Updated 5.5 Connecting DC Input Power Cables.

Updated 5.7.1 Communication Modes.

Updated 7 Human-Machine Interaction.

Updated 7.1.3 SmartLogger Networking.

Updated 8.3 Alarm Reference.

Updated 10 Technical Specifications.

Added J PV String Access Detection.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. v

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual About This Document

Issue 08 (2022-04-14)
Updated 5.2 Preparing Cables.
Updated 5.7.1 Communication Modes.
Updated D Rapid Shutdown.

Issue 07 (2022-01-30)
Updated 4.3 Determining the Installation Position.
Updated 8.2 Routine Maintenance.

Issue 06 (2022-01-04)
Updated 5.2 Preparing Cables.
Updated 7.1.2 Creating a PV Plant and a User.
Updated 7.3.1 Grid-tied Point Control.
Updated 7.3.3 Apparent Power Control on the Inverter Output Side.
Updated 10 Technical Specifications.
Updated A Grid Codes.

Issue 05 (2021-11-25)
Updated 5.4 Connecting an AC Output Power Cable.

Issue 04 (2021-07-25)
Updated 5.2 Preparing Cables.
Updated 10 Technical Specifications.

Issue 03 (2021-04-15)
Updated 2.1 Product Introduction.
Updated 5.2 Preparing Cables.
Updated 5.5 Connecting DC Input Power Cables.
Updated 10 Technical Specifications.

Issue 02 (2020-11-20)
Updated 2.3 Label Description.
Updated 4.3 Determining the Installation Position.
Updated 5.2 Preparing Cables.
Updated 5.7.1 Communication Modes.
Updated 10 Technical Specifications.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. vi

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual About This Document

Issue 01 (2020-10-15)
This issue is the first official release.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. vii

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual Contents

Contents

About This Document................................................................................................................ ii

1 Safety Information.................................................................................................................. 1
1.1 Personal Safety.........................................................................................................................................................................2
1.2 Electrical Safety........................................................................................................................................................................ 4
1.3 Environment Requirements................................................................................................................................................. 7
1.4 Mechanical Safety................................................................................................................................................................... 8

2 Overview................................................................................................................................. 13
2.1 Product Introduction............................................................................................................................................................ 13
2.2 Appearance............................................................................................................................................................................. 15
2.3 Label Description.................................................................................................................................................................. 16
2.4 Working Principles................................................................................................................................................................ 19
2.4.1 Circuit Diagram.................................................................................................................................................................. 19
2.4.2 Working Modes.................................................................................................................................................................. 19

3 Inverter Storage..................................................................................................................... 21
4 Installation..............................................................................................................................23
4.1 Checking Before Installation............................................................................................................................................. 23
4.2 Tools.......................................................................................................................................................................................... 24
4.3 Determining the Installation Position............................................................................................................................ 25
4.4 Moving the Inverter............................................................................................................................................................. 30
4.5 Installing the Mounting Bracket...................................................................................................................................... 31
4.5.1 Support Mounting............................................................................................................................................................. 32
4.5.2 Wall Mounting....................................................................................................................................................................33
4.6 Installing the Inverter.......................................................................................................................................................... 34

5 Electrical Connections.......................................................................................................... 37
5.1 Precautions.............................................................................................................................................................................. 37
5.2 Preparing Cables................................................................................................................................................................... 38
5.3 Connecting the PE Cable.................................................................................................................................................... 41
5.4 Connecting an AC Output Power Cable........................................................................................................................ 43
5.5 Connecting DC Input Power Cables................................................................................................................................50
5.5.1 Cable Connection Description....................................................................................................................................... 50
5.5.2 Connecting Cables to Amphenol Helios H4 Terminals.........................................................................................52

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. viii

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual Contents

5.5.3 Connecting Cables to Staubli MC4 Terminals......................................................................................................... 54

5.6 (Optional) Installing the Smart Dongle........................................................................................................................ 56
5.7 Connecting Signal Cables................................................................................................................................................... 59
5.7.1 Communication Modes................................................................................................................................................... 61
5.7.2 (Optional) Connecting the RS485 Communications Cables to the Inverter.................................................63
5.7.3 (Optional) Connecting the RS485 Communications Cable to the Power Meter.........................................64
5.7.4 (Optional) Connecting the Power Grid Scheduling Signal Cable..................................................................... 65
5.7.5 (Optional) Connecting the Rapid Shutdown Signal Cable................................................................................. 66

6 Commissioning....................................................................................................................... 68
6.1 Checking Before Power-On................................................................................................................................................68
6.2 System Power-On................................................................................................................................................................. 69

7 Human-Machine Interaction.............................................................................................. 72
7.1 Scenario in Which SUN2000s Are Connected to the FusionSolar Smart PV Management System.........73
7.1.1 (Optional) Registering an Installer Account............................................................................................................ 73
7.1.2 Creating a PV Plant and a User.................................................................................................................................... 75
7.1.3 SmartLogger Networking............................................................................................................................................... 76
7.2 Scenario in Which Inverters Connect to Other Management Systems.............................................................. 76
7.3 Energy Control....................................................................................................................................................................... 76
7.3.1 Grid-tied Point Control.................................................................................................................................................... 76
7.3.2 Setting Feed-in at Limited Current.............................................................................................................................. 81
7.3.2.1 Connecting the App to the Inverter or Smart Dongle.......................................................................................81
7.3.2.2 Scenario Where the App Connects to the SmartLogger...................................................................................82
7.3.3 Apparent Power Control on the Inverter Output Side..........................................................................................84

8 Maintenance........................................................................................................................... 85
8.1 System Power-Off................................................................................................................................................................. 85
8.2 Routine Maintenance.......................................................................................................................................................... 86
8.3 Alarm Reference.................................................................................................................................................................... 87

9 Handling the Inverter...........................................................................................................88

9.1 Removing the SUN2000..................................................................................................................................................... 88
9.2 Packing the SUN2000.......................................................................................................................................................... 88
9.3 Disposing of the SUN2000................................................................................................................................................ 88

10 Technical Specifications.....................................................................................................89
A Grid Codes............................................................................................................................ 101
B Device Commissioning....................................................................................................... 123
C Built-in PID Recovery......................................................................................................... 126
D Rapid Shutdown................................................................................................................. 128
E NS Protection....................................................................................................................... 129
F Resetting a Password......................................................................................................... 130

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. ix

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual Contents

G Setting Dry Contact Scheduling...................................................................................... 131

H Setting the Current Threshold for Triggering RCD Protection................................ 133
I AFCI......................................................................................................................................... 135
J PV String Access Detection................................................................................................137
K Smart I-V Curve Diagnosis................................................................................................140
L Locating Insulation Resistance Faults............................................................................ 141
M Contact Information......................................................................................................... 145
N Digital Power Customer Service..................................................................................... 147
O Acronyms and Abbreviations...........................................................................................148

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. x

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

1 Safety Information

Statement
Before transporting, storing, installing, operating, using, and/or maintaining
the equipment, read this document, strictly follow the instructions provided
herein, and follow all the safety instructions on the equipment and in this
document. In this document, "equipment" refers to the products, software,
components, spare parts, and/or services related to this document; "the Company"
refers to the manufacturer (producer), seller, and/or service provider of the
equipment; "you" refers to the entity that transports, stores, installs, operates,
uses, and/or maintains the equipment.

The Danger, Warning, Caution, and Notice statements described in this

document do not cover all the safety precautions. You also need to comply with
relevant international, national, or regional standards and industry practices. The
Company shall not be liable for any consequences that may arise due to
violations of safety requirements or safety standards concerning the design,
production, and usage of the equipment.

The equipment shall be used in an environment that meets the design

specifications. Otherwise, the equipment may be faulty, malfunctioning, or
damaged, which is not covered under the warranty. The Company shall not be
liable for any property loss, personal injury, or even death caused thereby.

Comply with applicable laws, regulations, standards, and specifications during

transportation, storage, installation, operation, use, and maintenance.

Do not perform reverse engineering, decompilation, disassembly, adaptation,

implantation, or other derivative operations on the equipment software. Do not
study the internal implementation logic of the equipment, obtain the source code
of the equipment software, violate intellectual property rights, or disclose any of
the performance test results of the equipment software.

The Company shall not be liable for any of the following circumstances or
their consequences:

● The equipment is damaged due to force majeure such as earthquakes, floods,

volcanic eruptions, debris flows, lightning strikes, fires, wars, armed conflicts,
typhoons, hurricanes, tornadoes, and other extreme weather conditions.
● The equipment is operated beyond the conditions specified in this document.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 1

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

● The equipment is installed or used in environments that do not comply with

international, national, or regional standards.
● The equipment is installed or used by unqualified personnel.
● You fail to follow the operation instructions and safety precautions on the
product and in the document.
● You remove or modify the product or modify the software code without
authorization.
● You or a third party authorized by you cause the equipment damage during
transportation.
● The equipment is damaged due to storage conditions that do not meet the
requirements specified in the product document.
● You fail to prepare materials and tools that comply with local laws,
regulations, and related standards.
● The equipment is damaged due to your or a third party's negligence,
intentional breach, gross negligence, or improper operations, or other reasons
not related to the Company.

1.1 Personal Safety

DANGER

Ensure that power is off during installation. Do not install or remove a cable with
power on. Transient contact between the core of the cable and the conductor will
generate electric arcs or sparks, which may cause a fire or personal injury.

DANGER

Non-standard and improper operations on the energized equipment may cause

fire, electric shocks, or explosion, resulting in property damage, personal injury, or
even death.

DANGER

Before operations, remove conductive objects such as watches, bracelets, bangles,

rings, and necklaces to prevent electric shocks.

DANGER

During operations, use dedicated insulated tools to prevent electric shocks or short
circuits. The dielectric withstanding voltage level must comply with local laws,
regulations, standards, and specifications.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 2

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

WARNING

During operations, wear personal protective equipment such as protective

clothing, insulated shoes, goggles, safety helmets, and insulated gloves.

Figure 1-1 Personal protective equipment

General Requirements
● Do not stop protective devices. Pay attention to the warnings, cautions, and
related precautionary measures in this document and on the equipment.
● If there is a likelihood of personal injury or equipment damage during
operations, immediately stop, report the case to the supervisor, and take
feasible protective measures.
● Do not power on the equipment before it is installed or confirmed by
professionals.
● Do not touch the power supply equipment directly or with conductors such as
damp objects. Before touching any conductor surface or terminal, measure
the voltage at the contact point to ensure that there is no risk of electric
shock.
● Do not touch operating equipment because the enclosure is hot.
● Do not touch a running fan with your hands, components, screws, tools, or
boards. Otherwise, personal injury or equipment damage may occur.
● In the case of a fire, immediately leave the building or the equipment area
and activate the fire alarm or call emergency services. Do not enter the
affected building or equipment area under any circumstances.

Personnel Requirements
● Only professionals and trained personnel are allowed to operate the
equipment.
– Professionals: personnel who are familiar with the working principles and
structure of the equipment, trained or experienced in equipment
operations and are clear of the sources and degree of various potential
hazards in equipment installation, operation, maintenance

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 3

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

– Trained personnel: personnel who are trained in technology and safety,

have required experience, are aware of possible hazards on themselves in
certain operations, and are able to take protective measures to minimize
the hazards on themselves and other people
● Personnel who plan to install or maintain the equipment must receive
adequate training, be able to correctly perform all operations, and understand
all necessary safety precautions and local relevant standards.
● Only qualified professionals or trained personnel are allowed to install,
operate, and maintain the equipment.
● Only qualified professionals are allowed to remove safety facilities and inspect
the equipment.
● Personnel who will perform special tasks such as electrical operations,
working at heights, and operations of special equipment must possess the
required local qualifications.
● Only authorized professionals are allowed to replace the equipment or
components (including software).
● Only personnel who need to work on the equipment are allowed to access
the equipment.

1.2 Electrical Safety

DANGER

Before connecting cables, ensure that the equipment is intact. Otherwise, electric
shocks or fire may occur.

DANGER

Non-standard and improper operations may result in fire or electric shocks.

DANGER

Prevent foreign matter from entering the equipment during operations. Otherwise,
equipment short-circuits or damage, load power derating, power failure, or
personal injury may occur.

WARNING

For the equipment that needs to be grounded, install the ground cable first when
installing the equipment and remove the ground cable last when removing the
equipment.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 4

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

WARNING

During the installation of PV strings and the inverter, the positive or negative
terminals of PV strings may be short-circuited to ground if the power cables are
not properly installed or routed. In this case, an AC or DC short circuit may occur
and damage the inverter. The resulting device damage is not covered under any
warranty.

CAUTION

Do not route cables near the air intake or exhaust vents of the equipment.

General Requirements
● Follow the procedures described in the document for installation, operation,
and maintenance. Do not reconstruct or alter the equipment, add
components, or change the installation sequence without permission.
● Obtain approval from the national or local electric utility company before
connecting the equipment to the grid.
● Observe the power plant safety regulations, such as the operation and work
ticket mechanisms.
● Install temporary fences or warning ropes and hang "No Entry" signs around
the operation area to keep unauthorized personnel away from the area.
● Before installing or removing power cables, turn off the switches of the
equipment and its upstream and downstream switches.
● Before performing operations on the equipment, check that all tools meet the
requirements and record the tools. After the operations are complete, collect
all of the tools to prevent them from being left inside the equipment.
● Before installing power cables, check that cable labels are correct and cable
terminals are insulated.
● When installing the equipment, use a torque tool of a proper measurement
range to tighten the screws. When using a wrench to tighten the screws,
ensure that the wrench does not tilt and the torque error does not exceed
10% of the specified value.
● Ensure that bolts are tightened with a torque tool and marked in red and blue
after double-check. Installation personnel mark tightened bolts in blue.
Quality inspection personnel confirm that the bolts are tightened and then
mark them in red. (The marks must cross the edges of the bolts.)

● If the equipment has multiple inputs, disconnect all the inputs and wait until
the equipment is completely powered off before performing operations on the
equipment.
● Before maintaining a downstream electrical or power distribution device, turn
off the output switch on the power supply equipment.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 5

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

● During equipment maintenance, attach "Do not switch on" labels near the
upstream and downstream switches or circuit breakers as well as warning
signs to prevent accidental connection. The equipment can be powered on
only after troubleshooting is complete.
● Do not open equipment panels.
● Check equipment connections periodically, ensuring that all screws are
securely tightened.
● Only qualified professionals can replace a damaged cable.
● Do not scrawl, damage, or block any labels or nameplates on the equipment.
Promptly replace labels that have worn out.
● Do not use solvents such as water, alcohol, or oil to clean electrical
components inside or outside of the equipment.
● The surge protection of the PV system and the building where the PV system
is installed shall comply with local standards.

Grounding
● Ensure that the grounding impedance of the equipment complies with local
electrical standards.
● Ensure that the equipment is connected permanently to the protective
ground. Before operating the equipment, check its electrical connection to
ensure that it is reliably grounded.
● Do not work on the equipment in the absence of a properly installed ground
conductor.
● Do not damage the ground conductor.

Cabling Requirements
● When selecting, installing, and routing cables, follow local safety regulations
and rules.
● When routing power cables, ensure that there is no coiling or twisting. Do not
join or weld power cables. If necessary, use a longer cable.
● Ensure that all cables are properly connected and insulated, and meet
specifications.
● Ensure that the slots and holes for routing cables are free from sharp edges,
and that the positions where cables are routed through pipes or cable holes
are equipped with cushion materials to prevent the cables from being
damaged by sharp edges or burrs.
● Ensure that cables of the same type are bound together neatly and straight
and that the cable sheath is intact. When routing cables of different types,
ensure that they are away from each other without entanglement and
overlapping.
● Secure buried cables using cable supports and cable clips. Ensure that the
cables in the backfill area are in close contact with the ground to prevent
cable deformation or damage during backfilling.
● If the external conditions (such as the cable layout or ambient temperature)
change, verify the cable usage in accordance with the IEC-60364-5-52 or local
laws and regulations. For example, check that the current-carrying capacity
meets requirements.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 6

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

● When routing cables, reserve at least 30 mm clearance between the cables

and heat-generating components or areas. This prevents deterioration or
damage to the cable insulation layer.

1.3 Environment Requirements

DANGER

Do not expose the equipment to flammable or explosive gas or smoke. Do not

perform any operation on the equipment in such environments.

DANGER

Do not store any flammable or explosive materials in the equipment area.

DANGER

Do not place the equipment near heat sources or fire sources, such as smoke,
candles, heaters, or other heating devices. Overheat may damage the equipment
or cause a fire.

WARNING

Install the equipment in an area far away from liquids. Do not install it under
areas prone to condensation, such as under water pipes and air exhaust vents, or
areas prone to water leakage, such as air conditioner vents, ventilation vents, or
feeder windows of the equipment room. Ensure that no liquid enters the
equipment to prevent faults or short circuits.

WARNING

To prevent damage or fire due to high temperature, ensure that the ventilation
vents or heat dissipation systems are not obstructed or covered by other objects
while the equipment is running.

General Requirements
● Store the equipment according to the storage requirements. Equipment
damage caused by unqualified storage conditions is not covered under the
warranty.
● Keep the installation and operating environments of the equipment within the
allowed ranges. Otherwise, its performance and safety will be compromised.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 7

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

● The operating temperature range provided in the equipment's technical

specifications refers to the ambient temperatures in equipment's installation
environment.
● Do not install, use, or operate outdoor equipment and cables (including but
not limited to moving equipment, operating equipment and cables, inserting
connectors to or removing connectors from signal ports connected to outdoor
facilities, working at heights, performing outdoor installation, and opening
doors) in harsh weather conditions such as lightning, rain, snow, and level 6
or stronger wind.
● Do not install the equipment in an environment with dust, smoke, volatile or
corrosive gases, infrared and other radiations, organic solvents, or salty air.
● Do not install the equipment in an environment with conductive metal or
magnetic dust.
● Do not install the equipment in an area conducive to the growth of
microorganisms such as fungus or mildew.
● Do not install the equipment in an area with strong vibration, noise, or
electromagnetic interference.
● Ensure that the site complies with local laws, regulations, and related
standards.
● Ensure that the ground in the installation environment is solid, free from
spongy or soft soil, and not prone to subsidence. The site must not be located
in a low-lying land prone to water or snow accumulation, and the horizontal
level of the site must be above the highest water level of that area in history.
● Do not install the equipment in a position that may be submerged in water.
● If the equipment is installed in a place with abundant vegetation, in addition
to routine weeding, harden the ground underneath the equipment using
cement or gravel (the area shall be greater than or equal to 3 m x 2.5 m).
● Do not install the equipment outdoors in salt-affected areas because it may
be corroded. A salt-affected area refers to the region within 500 m of the
coast or prone to sea breeze. Regions prone to sea breeze vary with weather
conditions (such as typhoons and monsoons) or terrains (such as dams and
hills).
● Before installation, operation, and maintenance, clean up any water, ice, snow,
or other foreign objects on the top of the equipment.
● When installing the equipment, ensure that the installation surface is solid
enough to bear the weight of the equipment.
● After installing the equipment, remove the packing materials such as cartons,
foam, plastics, and cable ties from the equipment area.

1.4 Mechanical Safety

WARNING

Ensure that all necessary tools are ready and inspected by a professional
organization. Do not use tools that have signs of scratches or fail to pass the
inspection or whose inspection validity period has expired. Ensure that the tools
are secure and not overloaded.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 8

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

WARNING

Do not drill holes into the equipment. Doing so may affect the sealing
performance and electromagnetic containment of the equipment and damage
components or cables inside. Metal shavings from drilling may short-circuit boards
inside the equipment.

General Requirements
● Repaint any paint scratches caused during equipment transportation or
installation in a timely manner. Equipment with scratches must not be
exposed for an extended period of time.
● Do not perform operations such as arc welding and cutting on the equipment
without evaluation by the Company.
● Do not install other devices on the top of the equipment without evaluation
by the Company.
● When performing operations over the top of the equipment, take measures to
protect the equipment against damage.
● Use correct tools and operate them in the correct way.

Moving Heavy Objects

● Be cautious to prevent injury when moving heavy objects.

● If multiple persons need to move a heavy object together, determine the

manpower and work division with consideration of height and other
conditions to ensure that the weight is equally distributed.
● If two persons or more move a heavy object together, ensure that the object
is lifted and landed simultaneously and moved at a uniform pace under the
supervision of one person.
● Wear personal protective gears such as protective gloves and shoes when
manually moving the equipment.
● To move an object by hand, approach to the object, squat down, and then lift
the object gently and stably by the force of the legs instead of your back. Do
not lift it suddenly or turn your body around.
● Do not quickly lift a heavy object above your waist. Place the object on a
workbench that is half-waist high or any other appropriate place, adjust the
positions of your palms, and then lift it.
● Move a heavy object stably with balanced force at an even and low speed. Put
down the object stably and slowly to prevent any collision or drop from
scratching the surface of the equipment or damaging the components and
cables.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 9

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

● When moving a heavy object, be aware of the workbench, slope, staircase,

and slippery places. When moving a heavy object through a door, ensure that
the door is wide enough to move the object and avoid bumping or injury.
● When transferring a heavy object, move your feet instead of turning your
waist around. When lifting and transferring a heavy object, ensure that your
feet point to the target direction of movement.
● When transporting the equipment using a pallet truck or forklift, ensure that
the tynes are properly positioned so that the equipment does not topple.
Before moving the equipment, secure it to the pallet truck or forklift using
ropes. When moving the equipment, assign dedicated personnel to take care
of it.
● Choose sea, roads in good conditions, or airplanes for transportation. Do not
transport the equipment by railway. Avoid tilt or jolt during transportation.

Using Ladders
● Use wooden or insulated ladders when you need to perform live-line working
at heights.
● Platform ladders with protective rails are preferred. Single ladders are not
recommended.
● Before using a ladder, check that it is intact and confirm its load bearing
capacity. Do not overload it.
● Ensure that the ladder is securely positioned and held firm.

● When climbing up the ladder, keep your body stable and your center of
gravity between the side rails, and do not overreach to the sides.
● When a step ladder is used, ensure that the pull ropes are secured.
● If a single ladder is used, the recommended angle for the ladder against the
floor is 75 degrees, as shown in the following figure. A square can be used to
measure the angle.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 10

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

● If a single ladder is used, ensure that the wider end of the ladder is at the
bottom, and take protective measures to prevent the ladder from sliding.
● If a single ladder is used, do not climb higher than the fourth rung of the
ladder from the top.
● If you use a single ladder to climb up to a platform, ensure that the ladder is
at least 1 m higher than the platform.

Hoisting
● Only trained and qualified personnel are allowed to perform hoisting
operations.
● Install temporary warning signs or fences to isolate the hoisting area.
● Ensure that the foundation where hoisting is performed on meets the load-
bearing requirements.
● Before hoisting objects, ensure that hoisting tools are firmly secured onto a
fixed object or wall that meets the load-bearing requirements.
● During hoisting, do not stand or walk under the crane or the hoisted objects.
● Do not drag steel ropes and hoisting tools or bump the hoisted objects
against hard objects during hoisting.
● Ensure that the angle between two hoisting ropes is no more than 90
degrees, as shown in the following figure.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 11

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 1 Safety Information

Drilling Holes
● Obtain consent from the customer and contractor before drilling holes.
● Wear protective equipment such as safety goggles and protective gloves when
drilling holes.
● To avoid short circuits or other risks, do not drill holes into buried pipes or
cables.
● When drilling holes, protect the equipment from shavings. After drilling, clean
up any shavings.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 12

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

2 Overview

2.1 Product Introduction

Function
The SUN2000 is a three-phase grid-tied PV string inverter that converts the DC
power generated by PV strings into AC power and feeds the power into the power
grid.

Model
This document involves the following product models:

● SUN2000-20KTL-M3
● SUN2000-20KTL-BRM3
● SUN2000-29.9KTL-M3
● SUN2000-30KTL-M3
● SUN2000-30KTL-BRM3
● SUN2000-36KTL-M3
● SUN2000-40KTL-M3
● SUN2000-40KTL-BRM3
NOTE

The SUN2000-20KTL-M3 and SUN2000-20KTL-BRM3 support 220 V (line voltage)

power grids.

Figure 2-1 Model number (using SUN2000-30KTL-M3 as an example)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 13

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

Table 2-1 Model description

No. Meaning Description

1 Product family SUN2000: grid-tied solar inverter

identifier

2 Power level ● 20K: The rated power is 20 kW.

identifier ● 29.9K: The rated power is 29.9 kW
● 30K: The rated power is 30 kW.
● 36K: The rated power is 36 kW.
● 40K: The rated power is 40 kW.

3 Topology TL: transformerless

identifier

4 Product series M3: product series with an input voltage level

identifier of 1100 V DCa

5 Region identifier BR: Brazil

Note a: The maximum DC input voltage for the SUN2000-20KTL-M3 and

SUN2000-20KTL-BRM3 is 800 V. For details, see 10 Technical Specifications.

Networking Application
The SUN2000 applies to grid-tied systems for commercial and industrial (C&I)
rooftop projects and small-sized ground-mounted plants. The system consists of
PV strings, grid-tied inverters, AC switches, and power distribution units (PDUs).

Figure 2-2 Networking application – single inverter scenario

(1) PV string (2) SUN2000 (3) AC PDU

(4) Isolation transformer (5) Power grid

Supported Earthing Systems

The SUN2000 supports the TN-S, TN-C, TN-C-S, TT, and IT earthing systems.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 14

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

Figure 2-3 Earthing systems

2.2 Appearance
Figure 2-4 Appearance

(1) LED indicators (2) Front panel

(3) Heat sink (4) Screw holes for fixing the sunshade

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 15

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

(5) Communications port (COM) (6) Hole for the DC switch locking
screw
(7) DC switch (DC SWITCH) (8) Smart Dongle port (4G/WLAN-FE)
(9) Ventilation valves (10) DC input terminals (PV1–PV8)
(11) AC output ports (12) Ground point

2.3 Label Description

Symbol Name Meaning

Delayed discharge ● High voltage exists

after the inverter is
powered on. Only
qualified and
trained electrical
technicians are
allowed to perform
operations on the
inverter.
● Residual voltage
exists after the
inverter is powered
off. It takes 5
minutes for the
inverter to
discharge to a safe
voltage.

High temperature Do not touch the

hazard inverter when it is
running because its
enclosure is hot.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 16

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

Symbol Name Meaning

Electric shock warning ● High voltage exists

after the inverter is
powered on. Only
qualified and
trained electrical
technicians are
allowed to perform
operations on the
inverter.
● High touch current
exists after the
inverter is powered
on. Before powering
on the inverter,
ensure that it is
properly grounded.

Refer to Reminds operators to

documentation refer to the
documentation
provided with the
device. Losses caused
by operations that do
not comply with the
requirements of site
selection, storage, or
mounting specified in
the user manual are
not covered under the
warranty.

Protective earthing Indicates the position

for connecting the
protective earthing
(PE) cable.

Operation warning Do not remove the DC

input connector or AC
output connector with
power on.

Device weight The inverter is heavy

and must be carried by
three persons.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 17

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

Symbol Name Meaning

Inverter handle Do not touch the

scalding warning handles until 10
minutes after the
inverter is shut down.

Indicators Indicates the inverter

operating information.

Inverter SN Indicates the inverter

serial number.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 18

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

Symbol Name Meaning

QR code for inverter Scan the QR code to

WLAN connection connect to the inverter
WLAN.

2.4 Working Principles

2.4.1 Circuit Diagram

The SUN2000 receives inputs from eight PV strings. Then the inputs are grouped
into four MPPT circuits inside the SUN2000, with each MPPT circuit tracking the
maximum power point of two PV strings. The DC power is then converted into
single-phase AC power through an inverter circuit. Surge protection is supported
on both the DC and AC sides.

Figure 2-5 Schematic diagram

2.4.2 Working Modes

The SUN2000 can work in Standby, Operating, or Shutdown mode.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 19

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 2 Overview

Figure 2-6 Working modes

Table 2-2 Working mode description

Working Description
Mode

Standby The SUN2000 enters Standby mode when the external

environment does not meet the operating requirements. In
Standby mode:
● The SUN2000 continuously performs status check and enters
the Operating mode once the operating requirements are met.
● The SUN2000 enters Shutdown mode after detecting a
shutdown command or a fault after startup.

Operating In Operating mode:

● The SUN2000 converts DC power from PV strings into AC power
and feeds the power to the power grid.
● The SUN2000 tracks the maximum power point to maximize
the PV string output.
● If the SUN2000 detects a fault or a shutdown command, it
enters the Shutdown mode.
● The SUN2000 enters Standby mode after detecting that the PV
string output power is not suitable for connecting to the power
grid for generating power.

Shutdown ● In Standby or Operating mode, the SUN2000 enters Shutdown

mode after detecting a fault or shutdown command.
● In Shutdown mode, the SUN2000 enters Standby mode after
detecting a startup command or that the fault is rectified.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 20

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 3 Inverter Storage

3 Inverter Storage

NOTICE

● Store devices according to the storage requirements. Device damage caused by

unqualified storage conditions is not covered under the warranty.
● Do not store the devices without outer packaging.

The following requirements shall be met if inverters are not put into use
immediately:
● Do not remove the outer packaging. Check the packaging regularly
(recommended: once every three months). Replace any packaging that is
damaged during storage.
● If an inverter is unpacked but will not be used immediately, put it back to the
original packaging with the desiccant, and seal it with tape.
● Inverters must be stored in a clean and dry environment with appropriate
temperature and humidity. The air must not contain corrosive or flammable
gases.

Figure 3-1 Storage temperature and humidity

● When temporarily storing inverters outdoors, do not stack them on a pallet.

Take rainproof measures such as using tarpaulins to protect inverters from
rain and water.
● Do not tilt a packing case or place it upside down.
● To avoid personal injury or device damage, stack inverters with caution to
prevent them from falling over.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 21

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 3 Inverter Storage

Figure 3-2 Maximum number of stacking layers (In the figure, N indicates the
maximum number of stacking layers.)

● Do not store inverters for more than two years. If inverters have been stored
for two years or longer, they must be checked and tested by professionals
before being put into use.
● If an inverter has not been running for six months or longer after being
mounted, it may have failed and must be checked and tested by professionals
before being put into operation.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 22

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

4 Installation

4.1 Checking Before Installation

Outer Packing Materials
Before unpacking the inverter, check the outer packing materials for damage, such
as holes and cracks, and check the inverter model. If any damage is found or the
inverter model is not what you requested, do not unpack the package and contact
your supplier as soon as possible.

NOTE

You are advised to remove the packing materials within 24 hours before installing the
inverter.

Package Contents

NOTICE

● After placing the equipment in the installation position, unpack it with care to
prevent scratches. Keep the equipment stable during unpacking.

After unpacking the inverter, check that the contents are intact and complete. If
any damage is found or any component is missing, contact your supplier.

NOTE

For details about the number of contents, see the Packing List in the packing case.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 23

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

4.2 Tools
Type Tools and Instruments

Install
ation

Insulated torque socket Insulated torque socket Phillips insulated torque

wrench (including an wrench (including an screwdriver
extension bar) extension socket)

Hammer drill Hammer drill bit Rubber mallet

Utility knife Marker Hydraulic pliers

Cable cutter Wire stripper Diagonal pliers

Crimping tool Open-end wrench Heat shrink tubing

H4TC0003 (Amphenol) H4TW0001 (Amphenol)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 24

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

Type Tools and Instruments

Crimping tool (model: Open-end wrench (model: Heat gun

PV-CZM-22100) PV-MS-HZ or PV-MS)

Steel measuring tape Level Multimeter

Cable tie Vacuum cleaner

Person
al
protec
tive
equip
ment
(PPE) Goggles Protective shoes Dust mask

Protective gloves Insulated gloves

4.3 Determining the Installation Position

Installation Environment Requirements
● Keep the inverter out of reach of children.
● The inverter is protected to IP66 and can be installed indoors or outdoors.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 25

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

● Do not install the inverter in working or living areas to avoid personal injury
or property loss caused by accidental contact by non-professionals or other
reasons during device operation.
● Do not install the inverter in noise-sensitive areas (such as residential areas,
office areas, and schools) to avoid complaints. If the preceding areas are
unavoidable, the distance between the installation position and noise-
sensitive areas must be greater than 40 m. Alternatively, use other low-noise
models.
● If the device is installed in public places (such as parking lots, stations, and
factories) other than working and living areas, install a protective net outside
the device and set up a safety warning sign to isolate the device. This is to
avoid personal injury or property loss caused by accidental contact by non-
professionals or other reasons during device operation.
● If the equipment is installed in a place with abundant vegetation, in addition
to routine weeding, harden the ground underneath the equipment using
cement or gravel (the area shall be greater than or equal to 3 m x 2.5 m).
● Do not install the equipment in an area with strong vibration, noise, or
electromagnetic interference. The equipment shall be installed in an
environment with a magnetic field strength less than 4 Gauss. If the magnetic
field strength is greater than or equal to 4 Gauss, the equipment may fail to
work properly. If the magnetic field strength is high, for example, in a
smeltery, you are advised to use a gauss meter to measure the magnetic field
strength of the equipment installation position when the smelting equipment
is running normally.
● Do not install the inverter in areas containing flammable materials (such as
sulfur, phosphorus, liquefied petroleum gas, marsh gas, flour, and cotton) to
avoid personal injury or property loss caused by fire or other reasons.
● Do not install the inverter in areas containing explosives (such as blasting
agents, display shells, fireworks, and firecrackers) to avoid personal injury or
property loss caused by explosion or other reasons.
● Do not install the inverter in areas with corrosive substances (such as sulfuric
acid, hydrochloric acid, nitric acid, hydrogen sulfide, and chlorine) to avoid
inverter failure caused by corrosion, which is not covered under the warranty.
● Avoid installing inverters in easily accessible locations, as they operate at a
high voltage and their enclosures and heat sinks become hot during use.
● The inverter provides self-protection in high-temperature environments. Its
energy yield may decrease as the ambient temperature increases. Ensure that
the following installation requirements are met:
– Install the inverter in a well-ventilated environment to ensure good heat
dissipation.
– If the inverter is installed in an enclosed environment, the heat
dissipation equipment or ventilation equipment shall be installed. The
indoor ambient temperature must not be higher than the outdoor
ambient temperature.
– You are advised to install the device in a sheltered place or install an
awning over it to avoid direct sunlight.
– Reserve sufficient clearance around the inverter for installation and heat
dissipation.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 26

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

● The inverter will become corroded if installed in areas exposed to salt. Before
installing the inverter outdoors in such areas, consult with the Company. A
salt-affected area refers to the region within 500 m of the coast or prone to
sea breeze. Regions prone to sea breeze vary with weather conditions (such as
typhoons and monsoons) or terrains (such as dams and hills).
NOTE

The inverter shall be physically separated from residential environments or radio receivers
by distance greater than 30 m.

CAUTION

The SUN2000-20KTL-BRM3, SUN2000-30KTL-BRM3, and SUN2000-40KTL-BRM3

shall be installed in compliance with the technical standards for PV electrical
installation (NBR 16690) and the technical standards for PV system fire risk
management (IEC 63226).

Mounting Structure Requirements

● The mounting structure for the inverter must be fireproof. Do not install the
inverter on flammable building materials to avoid personal injury or property
loss caused by fire or other reasons.
● Ensure that the installation surface is solid enough to bear the weight of the
inverter to avoid personal injury or property loss caused by the collapse of the
mounting structure or other reasons.
● In residential areas, do not install the inverter on plaster board walls or walls
made of similar materials with a weak sound insulation performance because
the noise generated by the inverter may interfere with residents.

Installation Angle Requirements

The inverter can be wall-mounted or support-mounted. The installation angle
requirements are as follows:
● Install the inverter vertically or at a maximum back tilt of 15 degrees to
facilitate heat dissipation.
● Do not install the inverter at forward tilted, excessive backward tilted, side
tilted, horizontal, or upside down positions.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 27

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

Figure 4-1 Installation angle

Installation Clearances
● Reserve enough clearances around the inverter to ensure sufficient space for
installation and heat dissipation.

Figure 4-2 Clearances

● When installing multiple inverters, install them in horizontal mode if sufficient

space is available and install them in triangle mode if no sufficient space is
available. Stacked installation is not recommended.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 28

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

Figure 4-3 Horizontal installation mode (recommended)

Figure 4-4 Two-layer triangle installation mode (recommended)

Figure 4-5 Three-layer triangle installation mode (not recommended)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 29

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

Figure 4-6 Stacked installation mode (not recommended)

Figure 4-7 Back-to-back installation mode (not recommended)

NOTE

The installation figures are for reference only and are irrelevant to the inverter
cascading scenario.

4.4 Moving the Inverter

Procedure
Step 1 Lift the inverter out of the packing case and move it to the installation position.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 30

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

CAUTION

● Move the inverter with care to prevent device damage and personal injury.
● Do not use the wiring terminals and ports at the bottom to support any weight
of the inverter.
● When you need to temporally place the inverter on the ground, use foam,
cardboard, or other protection material to prevent damage to its enclosure.

Figure 4-8 Moving the inverter

----End

4.5 Installing the Mounting Bracket

Installation Precautions
Before installing the mounting bracket, remove the torx key and keep it for later
use.

Figure 4-9 Position for binding the torx key

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 31

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

(1) Torx key

Figure 4-10 shows the dimensions of mounting holes for the inverter.

Figure 4-10 Mounting bracket dimensions

4.5.1 Support Mounting

Procedure
Step 1 Secure the mounting bracket.

Figure 4-11 Securing the mounting bracket

NOTE

You are advised to apply anti-rust paint on the hole positions for protection.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 32

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

4.5.2 Wall Mounting

Prerequisites
You have prepared expansion bolts. M12x60 stainless steel expansion bolts are
recommended.

Procedure
Step 1 Determine the hole positions and mark them using a marker.

Step 2 Secure the mounting bracket.

DANGER

Avoid drilling holes into the water pipes or power cables buried in the wall.

Figure 4-12 Expansion bolt structure

(1) Bolt (2) Nut (3) Spring washer

(4) Flat washer (5) Expansion sleeve

NOTICE

● To prevent dust inhalation or contact with eyes, wear safety goggles and a dust
mask when drilling holes.
● Use a vacuum cleaner to clean up dust in and around the holes, and measure
the spacing. If the holes are inaccurately positioned, drill the holes again in
correct positions.
● Level the top of the expansion sleeve with the concrete wall after removing the
nut, spring washer, and flat washer. Otherwise, the mounting bracket will not
be securely installed on the concrete wall.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 33

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

Figure 4-13 Installing an expansion bolt

----End

4.6 Installing the Inverter

Step 1 (Optional) Install the DC switch locking screw.
NOTE

● The DC switch locking screw is used to lock the DC switch (DC SWITCH) to prevent the
inverter from being started by mistake.
● For models used in Australia, install the DC switch locking screw according to local
standards. The DC switch locking screw is delivered with the inverter.

Figure 4-14 Installing the DC switch locking screw

Step 2 Install the inverter on the mounting bracket.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 34

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

Figure 4-15 Installing the inverter

Step 3 Tighten the screws on both sides of the inverter.

Figure 4-16 Tightening the screws

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 35

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 4 Installation

NOTICE

Secure the screws on the sides before connecting cables.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 36

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

5 Electrical Connections

5.1 Precautions

DANGER

When exposed to sunlight, the PV arrays supply DC voltage to the inverter. Before
connecting cables, ensure that all DC SWITCH on the inverter are OFF. Otherwise,
the high voltage of the inverter may result in electric shocks.

DANGER

● The site must be equipped with qualified fire fighting facilities, such as fire sand
and carbon dioxide fire extinguishers.
● Wear personal protective equipment and use dedicated insulated tools to avoid
electric shocks or short circuits.

WARNING

● The equipment damage caused by incorrect cable connections is beyond the

warranty scope.
● Only certified electricians are allowed to connect cables.
● Operation personnel must wear PPE when connecting cables.
● Before connecting cables to ports, leave enough slack to reduce the tension on
the cables and prevent poor cable connections.
● Cables must be vertically routed into combiner boxes, PV terminals, and other
wiring terminals to avoid damage caused by horizontal stress on the terminals,
which is not covered under the warranty.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 37

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

CAUTION

● Stay away from the equipment when preparing cables to prevent cable scraps
from entering the equipment. Cable scraps may cause sparks and result in
personal injury and equipment damage.

NOTE

The cable colors shown in the electrical connection diagrams provided in this section are for
reference only. Select cables in accordance with local cable specifications (green-and-yellow
cables are only used for protective earthing).

5.2 Preparing Cables

Figure 5-1 SUN2000 cable connections (the components in dashed boxes are
optional)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 38

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Table 5-1 Component description

No. Componen Description Source
t

A PV string ● A PV string consists of PV Prepared by the

modules connected in series. customer
● The inverter supports eight PV
string inputs.

B AC switch To ensure that the inverter can be Prepared by the

safely disconnected from the power customer
grid when an exception occurs,
connect an AC switch to the AC side
of the inverter. Select an
appropriate AC switch in
accordance with local industry
standards and regulations. Huawei
recommends the following switch
specifications:
Three-phase AC circuit breaker with
a rated voltage greater than or
equal to 500 V AC and a rated
current of:
● 63 A (SUN2000-29.9KTL/30KTL)
● 80 A (SUN2000-20KTL)
● 100 A (SUN2000-36KTL/40KTL)

C Power Supported meter models: DTSU666- Purchased from

meter[1] H, DTSU666-HW, YDS60-80, YDS60- Huawei
C24, DTSU71, DHSU1079-CT,
DHSU1079-ZT, and DTSU71C [2]

D SUN2000 Select a proper model as required. Purchased from

Huawei

E SmartLogg SmartLogger3000 Purchased from

er Huawei

F Smart Select a proper model as required. Purchased from

Dongle Huawei

G Smart PV MERC-1300W-P, MERC-1100W-P Purchased from

Optimizer[3 Huawei
]

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 39

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

No. Componen Description Source

t

Note [1]: For details about how to operate the power meter, see DTSU666-HW
Smart Power Sensor Quick Guide, YDS60-80 Smart Power Sensor Quick
Guide, YDS60-C24 Smart Power Sensor Quick Guide, DTSU666-H 100 A and
250 A Smart Power Sensor User Manual, DHSU1079-ZT Smart Power Sensor
Quick Guide, or DTSU71C Smart Power Sensor Quick Guide.
Note [2]: SUN2000MA V100R001C20SPC116 and later versions can connect to
DTSU666-HW power meters.
Note [3]: For details about optimizer operations, see MERC Smart PV
Optimizer User Manual.

NOTICE

Cable specifications must meet the requirements in local standards.

Table 5-2 Cable description

No. Cable Type Recommended Source
Specifications

1 DC input PV cable that meets the ● Conductor cross- Prepare

power 1100 V standard sectional area: 4–6 d by
cable mm2 the
● Cable outer custom
diameter: 5.5–9 er
mm

2 AC Outdoor copper-core/ ● Conductor cross- Prepare

output aluminum-core cable sectional area: 16– d by
power 50 mm2 outdoor the
cable copper-core custom
cable/35–50 mm2 er
outdoor aluminum-
core cablea
● Cable outer
diameter: 16–38
mm

3 (Option Outdoor shielded twisted ● Conductor cross- Prepare

al) pair (recommended sectional area: 0.2– d by
Signal model: 1 mm2 the
cable DJYP2VP2-2x2x0.75) ● Cable outer custom
diameter: 4–11 mm er

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 40

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

No. Cable Type Recommended Source

Specifications

4 PE cable Outdoor single-core Conductor cross- Prepare

copper cable sectional area: ≥ 16 d by
mm2 the
custom
er

Note a: Five-core cables with a cross-sectional area of 5 x 35 mm2 or 5 x 50

mm2 are not supported.

NOTICE

If the inverter is used with an optimizer, route AC and DC power cables separately
to prevent AC power cables from interfering with optimizer communication.

5.3 Connecting the PE Cable

DANGER

● Ensure that the PE cable is securely connected. Otherwise, electric shocks may
occur.
● Do not connect the neutral wire to the enclosure as a PE cable. Otherwise,
electric shocks may occur.

NOTE

● The PE point at the AC output port is used only as a PE equipotential bonding point,
and cannot substitute for the PE point on the enclosure.
● It is recommended that silicone grease or paint be applied around the ground terminal
after the PE cable is connected.
● You can enable or disable phase-to-ground short-circuit protection on the app (choose
Settings > Feature parameters > Phase-to-ground short-circuit protection) to
address the situation in which a phase wire is short-circuited to PE. If this function is
disabled, the inverter detects the alarm and can connect to the power grid and generate
power normally.

Procedure
Step 1 Crimp an OT terminal.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 41

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

NOTICE

● Avoid scratching the core wire when stripping a cable.

● The cavity formed after the conductor crimp strip of the OT terminal is crimped
must wrap the core wire completely. The core wire must make close contact
with the OT terminal.
● Wrap the wire crimping area with heat shrink tubing or insulation tape. The
heat shrink tubing is used as an example.
● Use a heat gun carefully to avoid heat damage to the equipment.

Figure 5-2 Crimping an OT terminal

(1) Cable (2) Core wire (3) Heat shrink tubing

(4) OT terminal (5) Crimping tool (6) Heat gun

Step 2 Connect the PE cable.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 42

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-3 Connecting the PE cable

(1) Standby PE point

----End

5.4 Connecting an AC Output Power Cable

Precautions
An AC switch must be installed on the AC side of the inverter to ensure that the
inverter can be safely disconnected from the power grid.

WARNING

● Do not connect loads between an inverter and an AC switch that directly

connects to the inverter. Otherwise, the switch may trip by mistake.
● If an AC switch is used with specifications beyond local standards, regulations,
or the Company's recommendations, the switch may fail to turn off in a timely
manner in case of exceptions, causing serious faults.

CAUTION

Each inverter shall be equipped with an AC output switch. Multiple inverters shall
not connect to the same AC switch.
Cables must be vertically routed into the maintenance compartment, PV terminals,
and other wiring terminals to avoid damage caused by horizontal stress on the
terminals, which is not covered under the warranty.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 43

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

NOTICE

● If the external AC switch provides the leakage protection function, the rated
residual operating current must be greater than or equal to 300 mA.
● If multiple inverters are connected to the master leakage protection device
through their external AC switches, the rated residual operating current of the
device must be greater than or equal to the number of inverters x 300 mA.
● Use a socket wrench and extension rod to connect the AC power cable. The
extension rod must be longer than 100 mm.
● Reserve sufficient slack for the PE wire to ensure that the PE wire is the last
cable bearing the force when the AC output power cable is subject to a pulling
force due to force majeure.
● Do not install third-party devices in the AC connection box.
● You need to prepare M8 OT terminals by yourself.
● If the AC MBUS is used, multi-core cables are recommended, supporting a
maximum communication distance of 1000 m. To use other types of AC power
cables, contact the Company's technical support.

Requirements for the OT or DT Terminal

● If a copper cable is used, use copper wiring terminals.
● If a copper-clad aluminum cable is used, use copper wiring terminals.
● If an aluminum alloy cable is used, use copper-aluminum transition wiring
terminals, or aluminum wiring terminals along with copper-aluminum
transition spacers.

NOTICE

● Do not connect aluminum wiring terminals to the AC terminal block. Otherwise

the electrochemical corrosion will occur and affect the reliability of cable
connections.
● Comply with the IEC61238-1 requirements when using copper-aluminum
transition wiring terminals, or aluminum wiring terminals along with copper-
aluminum transition spacers.
● If copper-aluminum transition spacers are used, pay attention to the front and
rear sides. Ensure that the aluminum sides of spacers are in contact with
aluminum wiring terminals, and copper sides of spacers are in contact with the
AC terminal block.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 44

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-4 Requirements for the OT/DT terminal

Procedure
Step 1 Remove the AC terminal box and install partition boards.

NOTICE

To remove the AC terminal box, do as follows:

Method 1: Press the two buckles at the front of the AC terminal box respectively
with both thumbs. Rotate the AC terminal box counterclockwise and remove it.
Method 2: Press either of the buckles at the front of the AC terminal box with
your thumbs, and then press the other buckle. Rotate the box counterclockwise
and remove it.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 45

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-5 Removing the AC terminal box

Step 2 Connect the AC output power cable.

NOTE

● Do not route a cable with a crimped OT terminal directly through the rubber liner.
Otherwise, the liner may be damaged.
● Reserve sufficient slack for the PE wire to ensure that the PE wire is the last cable
bearing the force when the AC output power cable is subject to a pulling force due to
force majeure. It is recommended that the stripping length of the PE cable be 15 mm
longer than that of other cables.
● The cable colors shown in the figures are for reference only. Select an appropriate cable
according to the local standards.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 46

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-6 Stripping an AC power cable (using a five-core cable as an example)

Figure 5-7 Five-core cable (L1, L2, L3, N, and PE)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 47

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-8 Four-core cable (L1, L2, L3, and PE)

Figure 5-9 Four-core cable (L1, L2, L3, and N)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 48

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-10 Three-core cable (L1, L2, and L3)

Figure 5-11 Wiring requirements

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 49

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

5.5 Connecting DC Input Power Cables

CAUTION

● There are two models of PV connectors delivered with the device: Amphenol
Helios H4 and Staubli MC4. PV connectors of different models cannot be used
together. Device damage caused by mixed use of different PV connectors is not
covered by the warranty.
● Take waterproof and insulation measures for unused DC power cables to avoid
personal injury or property loss caused by accidental contact with high voltage
or other reasons.

5.5.1 Cable Connection Description

Precautions

DANGER

● Before connecting the DC input power cables, ensure that the DC voltage is
within the safe range (lower than 60 V DC) and that the DC switch on the
inverter is OFF. Failing to do so may result in electric shocks.
● When the inverter is running, it is not allowed to work on the DC input power
cables, such as connecting or disconnecting a PV string or a PV module in a PV
string. Failing to do so may cause electric shocks.
● If no PV string connects to a DC input terminal of the inverter, do not remove
the watertight cap from the DC input terminals. Otherwise, the IP rating of the
inverter will be affected.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 50

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

WARNING

Ensure that the following conditions are met. Otherwise, the inverter may be
damaged or even a fire may occur.
● PV modules connected in series in each PV string are of the same specifications.
● The DC input voltage of the SUN2000-29.9KTL/30KTL/36KTL/40KTL-M3 shall
not exceed 1100 V DC under any conditions.
● The DC input voltage of the SUN2000-20KTL-M3 shall not exceed 800 V DC
under any conditions.
● The polarities of electrical connections must be correct on the DC input side.
The positive and negative terminals of a PV string must be connected to
corresponding positive and negative DC input terminals of the inverter.
● If a DC input power cable is reversely connected, do not immediately operate
on the DC SWITCH or positive and negative connectors. Wait until the night
when solar irradiance declines and the PV string current drops to below 0.5 A.
Then set the DC SWITCH to OFF, remove the positive and negative connectors,
and correct the polarities of the DC input power cable.

WARNING

During the installation of PV strings and the inverter, the positive or negative
terminals of PV strings may be short-circuited to ground if the power cables are
not properly installed or routed. In this case, an AC or DC short circuit may occur
and damage the inverter. The resulting device damage is not covered under any
warranty.

NOTICE

● The inverter does not support power supplies other than PV strings. The output
of the PV string connected to the inverter cannot be grounded. Ensure that the
PV module output is well insulated to ground.
● To maximize energy yield, the voltage difference between MPPTs shall be less
than 85 V if no optimizer is configured. If optimizers are configured, refer to the
optimizer user manual.

Figure 5-12 DC input terminals

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 51

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

If the DC input terminals are not fully configured with PV strings, the DC input
terminals must meet the following requirements:

1. Evenly distribute the DC input power cables on the four MPPTs and
preferentially connect them from MPPT 1 to MPPT 4.
2. Maximize the number of connected MPPT circuits.

Quantity Terminal Selection Quantity Terminal Selection

of PV of PV
Strings Strings

1 PV1 2 PV1, PV7

3 PV1, PV3, PV7 4 PV1, PV3, PV5, PV7

5 PV1, PV2, PV3, PV5, PV7 6 PV1, PV2, PV3, PV5, PV7,
PV8

7 PV1, PV2, PV3, PV4, PV5, 8 PV1, PV2, PV3, PV4, PV5,
PV7, PV8 PV6, PV7, PV8

5.5.2 Connecting Cables to Amphenol Helios H4 Terminals

CAUTION

Use the Amphenol Helios H4 positive and negative metal terminals and DC
connectors delivered with the inverter. Using incompatible positive and negative
metal terminals and DC connectors may result in serious consequences. The
resulting device damage is not covered by the product warranty.

NOTICE

● You are advised to use the H4TC0003 (Amphenol) crimping tool and do not use
it with the positioning block. Otherwise, the metal terminals may be damaged.
● The H4TW0001 (Amphenol) open-end wrench is recommended.
● Cables with high rigidity, such as armored cables, are not recommended as DC
input power cables, because poor contact may be caused by the bending of the
cables.
● Before assembling DC connectors, label the cable polarities correctly to ensure
correct cable connections.
● After the positive and negative connectors snap into place, try to pull the DC
input power cables back to check that they are secure.
● If the inverter is used with optimizers, the number of optimizers in a single PV
string cannot exceed 25.
● If PV strings are configured with optimizers, check the cable polarities by
referring to the Smart PV Optimizer Quick Guide.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 52

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Procedure
Step 1 Connect DC power cables.

Figure 5-13 Connecting DC power cables

NOTICE

When installing DC input power cables, leave at least 150 mm of slack. The axial
tension on PV connectors must not exceed 80 N. Radial stress or torque must not
be generated on PV connectors.

Step 2 Use sealing plugs to seal the DC input terminals that are not connected to PV
strings. Device damage caused by the absence of sealing plugs is not covered by
warranty.

Figure 5-14 Sealing plugs

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 53

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Table 5-3 Sealing plug models

PV+ Sealing Plug PV– Sealing Plug

CT75A-FJB9-01 CT75A-FJB8-01

HH4SPM HH4SPF

102-01-00064 102-01-00065

HY050-FCG-2 HY050-FCG-3

----End

5.5.3 Connecting Cables to Staubli MC4 Terminals

CAUTION

Use the Staubli MC4 positive and negative metal terminals and DC connectors
delivered with the inverter. Using incompatible positive and negative metal
terminals and DC connectors may result in serious consequences. The resulting
device damage is not covered by the product warranty.

NOTICE

● You are advised to use the PV-CZM-22100 (Staubli) crimping tool and do not
use it with the positioning block. Otherwise, the metal terminals may be
damaged.
● The PV-MS (Staubli) or PV-MS-HZ (Staubli) open-end wrench is recommended.
● Cables with high rigidity, such as armored cables, are not recommended as DC
input power cables, because poor contact may be caused by the bending of the
cables.
● Before assembling DC connectors, label the cable polarities correctly to ensure
correct cable connections.
● After the positive and negative connectors snap into place, try to pull the DC
input power cables back to check that they are secure.
● If the inverter is used with optimizers, the number of optimizers in a single PV
string cannot exceed 25.
● If PV strings are configured with optimizers, check the cable polarities by
referring to the Smart PV Optimizer Quick Guide.

Procedure
Step 1 Connect DC power cables.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 54

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-15 Connecting DC power cables

NOTICE

When installing DC input power cables, leave at least 150 mm of slack. The axial
tension on PV connectors must not exceed 80 N. Radial stress or torque must not
be generated on PV connectors.

Step 2 Use sealing plugs to seal the DC input terminals that are not connected to PV
strings. Device damage caused by the absence of sealing plugs is not covered by
warranty.

Figure 5-16 Sealing plugs

Table 5-4 Sealing plug models

PV+ Sealing Plug PV– Sealing Plug

CT75A-FJB9-01 CT75A-FJB8-01

HH4SPM HH4SPF

102-01-00064 102-01-00065

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 55

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

PV+ Sealing Plug PV– Sealing Plug

HY050-FCG-2 HY050-FCG-3

----End

5.6 (Optional) Installing the Smart Dongle

Procedure
NOTE

The Smart Dongle is not provided in standard configuration.

● 4G Smart Dongle

NOTICE

● If your Smart Dongle is not configured with a SIM card, you need to
prepare one (dimensions: 25 mm x 15 mm; capacity: ≥ 64 KB).
● When installing the SIM card, determine its installation direction based on
the silk screen and arrow on the card slot.
● Press the SIM card in place to lock it, indicating that the SIM card is
correctly installed.
● When removing the SIM card, push it inward to eject it.
● When reinstalling the enclosure of the Smart Dongle, ensure that the snap-
fits click into place.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 56

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-17 Installing the 4G Smart Dongle (SDongleB-06)

● WLAN-FE Smart Dongle (WLAN communication)

Figure 5-18 Installing the WLAN-FE Smart Dongle (WLAN communication)

● WLAN-FE Smart Dongle (FE communication)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 57

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-19 Installing the WLAN-FE Smart Dongle (FE communication)

NOTICE

Install the network cable before installing the Smart Dongle on the inverter.

NOTE

● For details about how to use the WLAN-FE Smart Dongle SDongleA-05, see
SDongleA-05 Smart Dongle Quick Guide (WLAN-FE). You can scan the QR code
below to obtain the document.

● For details about how to use the 4G Smart Dongle SDongleB-06, see SDongleB-06
Smart Dongle Quick Guide (4G). You can scan the QR code below to obtain the
document.

The quick guide is delivered with the Smart Dongle.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 58

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

5.7 Connecting Signal Cables

COM Port Pin Definitions

NOTICE

When laying out signal cables, separate them from power cables and keep them
away from strong interference sources to prevent communication interruption.

Figure 5-20 Pin definitions

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 59

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Pin Definitio Function Description Pin Definitio Function Descripti

n n on

1 485A1_1 RS485 For inverter 2 485A1_2 RS485 For

differential cascading or differential inverter
signal + connecting to signal + cascading
the RS485 or
3 485B1_1 RS485 signal port of 4 485B1_2 RS485 connectin
differential a differential g to the
signal – SmartLogger signal – RS485
signal
port of a
SmartLog
ger

5 PE Shield layer - 6 PE Shield layer -

grounding grounding

7 485A2 RS485 For 8 DIN1 Dry contact for -

differential connecting to grid scheduling
signal + the RS485
signal port for
9 485B2 RS485 controlling 10 DIN2
differential the power
signal – meter at the
grid
connection
point.

11 - - - 12 DIN3

13 GND GND - 14 DIN4

15 DIN5 Rapid For the rapid 16 GND

shutdown/NS shutdown DI
protection signal or
connecting to
the signal
cable of an
NS protection
device

Scenario Where No Signal Cable Is Connected

NOTICE

If no signal cable is connected to the inverter, use a waterproof plug to seal the
cable hole of the signal cable connector and connect the signal cable connector to
the communications port on the inverter for better waterproof performance.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 60

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-21 Connecting the signal cable connector

5.7.1 Communication Modes

RS485 communication
● Smart Dongle networking

Figure 5-22 Smart Dongle networking

NOTE

If the inverter is connected to the Smart Dongle, it cannot be connected to the

SmartLogger.
● SmartLogger networking

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 61

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-23 SmartLogger networking

NOTE

● If the inverter is connected to the SmartLogger, it cannot be connected to the

Smart Dongle.
● You are advised to connect fewer than 30 devices to each RS485 route.

MBUS Communication
The MBUS technology transmits communication signals over power cables
through a communications board.

NOTE

● You can determine whether the MBUS is supported based on the nameplate on the
device.
● Inverters manufactured after July 20, 2022 do not support AC MBUS.
● The built-in MBUS module in the inverter does not need to be connected with cables.
● In utility-scale scenarios, an isolation transformer must be connected between the
inverter and loads.
● C&I scenarios are supported only in China.

Figure 5-24 MBUS communication (utility-scale scenario)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 62

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-25 MBUS communication (C&I scenario in China)

5.7.2 (Optional) Connecting the RS485 Communications

Cables to the Inverter
Procedure
Step 1 Connect the signal cables to the signal cable connector.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 63

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-26 Installing the cables

Step 2 Connect the signal cable connectors to the COM port.

Figure 5-27 Securing the signal cable connector

----End

5.7.3 (Optional) Connecting the RS485 Communications Cable

to the Power Meter
Procedure
Step 1 Connect the signal cable to the signal cable connector.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 64

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-28 Installing the cable

Step 2 Connect the signal cable connector to the COM port.

Figure 5-29 Securing the signal cable connector

----End

5.7.4 (Optional) Connecting the Power Grid Scheduling Signal

Cable
Procedure
Step 1 Connect the signal cable to the signal cable connector.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 65

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-30 Installing the cable

Step 2 Connect the signal cable connector to the COM port.

Figure 5-31 Securing the signal cable connector

----End

5.7.5 (Optional) Connecting the Rapid Shutdown Signal Cable

Procedure
Step 1 Connect the signal cable to the signal cable connector.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 66

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 5 Electrical Connections

Figure 5-32 Installing the cable

Step 2 Connect the signal cable connector to the COM port.

Figure 5-33 Securing the signal cable connector

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 67

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 6 Commissioning

6 Commissioning

DANGER

● Wear personal protective equipment and use dedicated insulated tools to avoid
electric shocks or short circuits.

NOTICE

Before the equipment is put into operation for the first time, ensure that the
parameters are set correctly by professional personnel. Incorrect parameter
settings may result in noncompliance with local grid connection requirements and
affect the normal operations of the equipment.

6.1 Checking Before Power-On

Table 6-1 Checklist
No. Check Item Acceptance Criteria

1 SUN2000 installation The SUN2000 is installed correctly and

securely.

2 Smart Dongle The Smart Dongle is installed correctly

and securely.

3 Cable routing The cables are routed properly as

required by the customer.

4 Cable ties Cable ties are evenly distributed and no

burr exists.

5 Reliable grounding The PE cable is connected correctly and

securely.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 68

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 6 Commissioning

No. Check Item Acceptance Criteria

6 Switch DC switches and all the switches

connecting to the SUN2000 are OFF.

7 Cable connection The AC output power cable, and DC

input power cables are connected
correctly and securely.

8 Unused terminals and ports Unused terminals and ports are locked
by watertight caps.

9 Installation environment The installation space is proper, and

the installation environment is clean
and tidy.

6.2 System Power-On

Prerequisites

DANGER

● Wear personal protective equipment and use dedicated insulated tools to avoid
electric shocks or short circuits.

NOTICE

● Before turning on the AC switch between the inverter and the power grid,
check that the AC voltage is within the specified range using a multimeter.
● If the DC power supply is connected but the AC power supply is disconnected,
the inverter will report a Grid Loss alarm. The inverter can start properly only
after the power grid recovers.

Procedure
Step 1 Turn on the AC switch between the inverter and the power grid.
Step 2 (Optional) Remove the locking screw next to the DC SWITCH.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 69

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 6 Commissioning

Figure 6-1 Removing the DC SWITCH locking screw

Step 3 Turn on the DC SWITCH at the bottom of the inverter.

Step 4 Observe the LED indicators to check the operating status of the inverter.

Table 6-2 LED indicator description

Category Status Description

Running LED1 LED2 –

indicator
Steady green Steady green The inverter is
running in on-grid
state.

Blinking green Off The DC is on and

slowly (on for 1s the AC is off.
and off for 1s)

Blinking green Blinking green Both the DC and

slowly (on for 1s slowly (on for 1s AC are on, and the
and off for 1s) and off for 1s) inverter is off-grid.

Off Blinking green The DC is off and

slowly the AC is on.

Off Off Both the DC and

AC are off.

Blinking red fast – There is a DC

(on for 0.2s and environmental
off for 0.2s) alarm.

– Blinking red fast There is an AC

(on for 0.2s and environmental
off for 0.2s) alarm.

Steady red Steady red A fault exists.

Communication LED3 –
indicator
Blinking green fast (on for 0.2s and off Communication is
for 0.2s) in progress.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 70

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 6 Commissioning

Category Status Description

Blinking green slowly (on for 1s and off A mobile phone is

for 1s) connected to the
inverter.

Off There is no
communication.

Note: If LED1, LED2, and LED3 are steady red, the inverter is faulty and needs to
be replaced.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 71

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

7 Human-Machine Interaction

NOTE

● The FusionSolar app is recommended if the inverter connects to the FusionSolar Smart
PV Management System. In areas where the FusionSolar app is unavailable or a third-
party management system is used, only the SUN2000 app can be used for
commissioning.
● Access Huawei AppGallery, search for FusionSolar or SUN2000, and download the app
installation package. You can also scan a QR code below to download the app. You are
advised to use a browser to scan a QR code.

NOTICE

● The screenshots are for reference only.

● The initial password for connecting to the inverter WLAN can be obtained from
the label on the side of the inverter.
● Set the password upon the first login. You are advised to change the password
periodically. After changing the password, remember the new password to
ensure account security. Your password might be stolen or cracked if it is left
unchanged for extended periods. If a password is lost, devices cannot be
accessed. In these cases, the Company shall not be liable for any loss caused to
the plant.
● Set the correct grid code based on the application area and scenario of the
inverter.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 72

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

7.1 Scenario in Which SUN2000s Are Connected to the

FusionSolar Smart PV Management System

7.1.1 (Optional) Registering an Installer Account

NOTE

● If you have an installer account, skip this step.

● You can register an account only using a mobile phone only in China.
● The mobile number or email address used for registration is the user name for logging
in to the FusionSolar app.

Create the first installer account and create a domain named after the company
name.

Figure 7-1 Creating the first installer account

NOTICE

To create multiple installer accounts for a company, log in to the FusionSolar app
and tap Add User to create an installer account.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 73

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

Figure 7-2 Creating multiple installer accounts for the same company

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 74

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

7.1.2 Creating a PV Plant and a User

Figure 7-3 Creating a PV plant and a user

NOTE

● In the quick settings for SUN2000-29.9KTL/36KTL/40KTL, the grid code is N/A by default
(automatic startup is not supported). Set the grid code based on the area where the PV
plant is located.
● Before the equipment is put into operation for the first time, ensure that the parameters
are set correctly by professional personnel. Incorrect parameter settings may result in
noncompliance with local grid connection requirements and affect the normal
operations of the equipment.
● For details about how to use the site deployment wizard, see FusionSolar App Quick
Guide.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 75

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

7.1.3 SmartLogger Networking

For details, see PV Plants Connecting to Huawei Hosting Cloud Quick Guide
(Inverters + SmartLogger3000), PV Plants Connecting to SmartPVMS Quick
Guide (Inverters + SmartLogger3000 + RS485 Networking), or PV Plants
Connecting to SmartPVMS Quick Guide (Inverters + SmartLogger3000 +
MBUS Networking).

NOTE

Inverters manufactured after July 20, 2022 do not support AC MBUS. You can determine
whether the MBUS is supported based on the nameplate on the device.

7.2 Scenario in Which Inverters Connect to Other

Management Systems
Step 1 Open the SUN2000 app, scan the QR code of the inverter or manually connect to
the WLAN hotspot to access the device commissioning screen.

Step 2 Select Installer and enter the login password.

Step 3 Tap Log in to access the quick settings screen or the inverter home screen.

Figure 7-4 Logging in to the app

----End

7.3 Energy Control

7.3.1 Grid-tied Point Control

Function
The output power of the PV power system can be limited or reduced to ensure
that the output power is within the specified range.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 76

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

Procedure
Step 1 On the home screen, choose Power adjustment > Grid-tied point control.

Figure 7-5 Grid-tied point control

Table 7-1 Grid-tied point control

Parameter Description

Active Unlimite - If this parameter is set to Unlimited, the output power

power d of the inverter is not limited and the inverter can
connect to the power grid at the rated power.

Grid Closed-loop ● If multiple inverters are cascaded, set this parameter

connecti controller to Controller.
on with ● If there is only one inverter, set this parameter to
zero Inverter.
power
Limitation mode ● Total power indicates export limitation of the total
power at the grid-tied point. (When a single-phase
power meter is connected, only Total power can be
selected. When a three-phase meter is connected in
three-phase three-wire mode, only Total power can
be selected.)
● Single-phase power indicates export limitation of
the power in each phase at the grid-tied point.
Single-phase power can be selected only if a three-
phase meter is connected in three-phase four-wire
mode.

Power Specifies the shortest interval for a single export

adjustment limitation adjustment.
period

Power control Specifies the deadband for adjusting the inverter output
hysteresis power. If the power fluctuates within the power control
hysteresis, the power is not adjusted.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 77

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

Parameter Description

Active power Specifies the derating value of the inverter active power
output limit for by percentage. If the Smart Dongle does not detect any
fail-safe power meter data or the communication between the
Smart Dongle and the inverter is disconnected, the
Smart Dongle delivers the derating value of the inverter
active power by percentage.

Communication In the inverter export limitation scenario, if this

disconnection parameter is set to Enable, the inverter will derate
fail-safe according to the active power derating percentage when
the communication between the inverter and the Smart
Dongle is disconnected for a period longer than
Communication disconnection detection time.

Communication Specifies the fail-safe detection time in case of

disconnection disconnection between the inverter and the Smart
detection time Dongle.
This parameter is displayed when Communication
disconnection fail-safe is set to Enable.

Grid Closed-loop ● If multiple inverters are cascaded, set this parameter

connecti controller to Controller.
on with ● If there is only one inverter, set this parameter to
limited Inverter.
power
(kW) Limitation mode ● Total power indicates export limitation of the total
power at the grid-tied point. (When a single-phase
power meter is connected, only Total power can be
selected. When a three-phase meter is connected in
three-phase three-wire mode, only Total power can
be selected.)
● Single-phase power indicates export limitation of
the power in each phase at the grid-tied point.
Single-phase power can be selected only if a three-
phase meter is connected in three-phase four-wire
mode.

Maximum grid Specifies the maximum active power transmitted from

feed-in power the grid-tied point to the power grid.

Power Specifies the shortest interval for a single export

adjustment limitation adjustment.
period

Power control Specifies the deadband for adjusting the inverter output
hysteresis power. If the power fluctuates within the power control
hysteresis, the power is not adjusted.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 78

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

Parameter Description

Active power Specifies the derating value of the inverter active power
output limit for by percentage. If the Smart Dongle does not detect any
fail-safe power meter data or the communication between the
Smart Dongle and the inverter is disconnected, the
Smart Dongle delivers the derating value of the inverter
active power by percentage.

Communication In the inverter export limitation scenario, if this

disconnection parameter is set to Enable, the inverter will derate
fail-safe according to the active power derating percentage when
the communication between the inverter and the Smart
Dongle is disconnected for a period longer than
Communication disconnection detection time.

Communication Specifies the fail-safe detection time in case of

disconnection disconnection between the inverter and the Smart
detection time Dongle.
This parameter is displayed when Communication
disconnection fail-safe is set to Enable.

Grid Closed-loop ● If multiple inverters are cascaded, set this parameter

connecti controller to Controller.
on with ● If there is only one inverter, set this parameter to
limited Inverter.
power
(%) Limitation mode ● Total power indicates export limitation of the total
power at the grid-tied point. (When a single-phase
power meter is connected, only Total power can be
selected. When a three-phase meter is connected in
three-phase three-wire mode, only Total power can
be selected.)
● Single-phase power indicates export limitation of
the power in each phase at the grid-tied point.
Single-phase power can be selected only if a three-
phase meter is connected in three-phase four-wire
mode.

PV plant Specifies the total maximum active power in the

capacity inverter cascading scenario.

Maximum grid Specifies the percentage of the maximum active power

feed-in power at the grid-tied point to the PV plant capacity.

Power Specifies the shortest interval for a single export

adjustment limitation adjustment.
period

Power control Specifies the deadband for adjusting the inverter output
hysteresis power. If the power fluctuates within the power control
hysteresis, the power is not adjusted.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 79

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

Parameter Description

Active power Specifies the derating value of the inverter active power
output limit for by percentage. If the Smart Dongle does not detect any
fail-safe power meter data or the communication between the
Smart Dongle and the inverter is disconnected, the
Smart Dongle delivers the derating value of the inverter
active power by percentage.

Communication In the inverter export limitation scenario, if this

disconnection parameter is set to Enable, the inverter will derate
fail-safe according to the active power derating percentage when
the communication between the inverter and the Smart
Dongle is disconnected for a period longer than
Communication disconnection detection time.

Communication Specifies the fail-safe detection time in case of

disconnection disconnection between the inverter and the Smart
detection time Dongle.
This parameter is displayed when Communication
disconnection fail-safe is set to Enable.

Shutdo Shutdown at high feed-in ● The default value is Disable.

wn at power ● If this parameter is set to Enable, the inverter shuts
high down for protection when the power at the grid-tied
feed-in point exceeds the threshold and remains in this
powera condition for the specified time threshold.

Upper feed-in power The default value is 0. This parameter specifies the
threshold for inverter power threshold of the grid-tied point for triggering
shutdown (kW) inverter shutdown.

High feed-in power duration The default value is 20. This parameter specifies the
threshold for triggering duration threshold of high feed-in power for triggering
inverter shutdown (s) inverter shutdown.
● When High feed-in power duration threshold for
triggering inverter shutdown is set to 5, Shutdown
at high feed-in power takes precedence.
● When High feed-in power duration threshold for
triggering inverter shutdown is set to 20, Grid
connection with limited power takes precedence
(when Active power control is set to Grid
connection with limited power).

Note a: This parameter is supported only for the AS4777 or G99-TYPEA-LV grid code.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 80

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

7.3.2 Setting Feed-in at Limited Current

Function
The output current of the PV power system can be limited or reduced to ensure
that the output current is within the specified range.

This function applies only to the commercial and industrial (C&I) scenarios in the
UK where the grid code is G99-TYPEA-LV, G99-TYPEB-LV, G99-TYPEB-HV, G99-
TYPEB-HV-MV480, or G99-TYPEA-HV. The SUN2000 app version must be later
than 6.24.00.563.

7.3.2.1 Connecting the App to the Inverter or Smart Dongle

NOTICE

If a single inverter is connected to the power grid, a Smart Dongle must be used
for networking.

Procedure
Step 1 On the home screen, choose Power adjustment > Feed-in at limited current.

Figure 7-6 Feed-in at limited current

Table 7-2 Feed-in at limited current

Parameter Description

Feed-in Feed-in at limited current The default value is Disable.

at ● If this parameter is set to Disable, feed-in at limited
limited current will be unavailable.
currenta
● If this parameter is set to Enable, feed-in at limited
current will be available.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 81

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

Parameter Description

Max. feed-in currentb Value range: [0, 30000 A]

● Due to external disturbances, the feed-in current
may exceed the specified value by 2%. In this case,
the inverter will adjust the current to a value within
the range limit.
● After the user changes the maximum feed-in current,
the inverter will adjust the current to a value within
the range limit.

Max. grid supply current Value range: [0, 30000 A]

If the grid supply current exceeds the specified value by
2%, the inverter will adjust the current to a value within
the range limit.

Current adjustment interval Value range: [1, 5s]

You are advised to keep the default value. A larger
value indicates a lower current adjustment speed.
If this parameter is set to 2s and the current at the grid
connection point exceeds the threshold, the inverter
adjusts the current every 2s.

Note a: If the inverter shuts down because the feed-in current adjustment is not complete within
the specified time, the user needs to manually start the inverter. By default, the number of
manual startups cannot exceed three within 30 days. If this limit is reached, it is not allowed to
manually start the inverter again.
Note b: If the maximum feed-in current is not adjusted to a value within the range limit within
15s, the inverter will shut down and report a Power Control Abnormal at Grid Connection Point
alarm.

----End

7.3.2.2 Scenario Where the App Connects to the SmartLogger

NOTICE

If multiple inverters are cascaded, the SmartLogger must be used.

Procedure
Step 1 On the home screen, choose Power adjustment > Feed-in at limited current.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 82

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

Figure 7-7 Feed-in at limited current

Table 7-3 Feed-in at limited current

Parameter Description

Feed-in Feed-in at limited current The default value is Disable.

at ● If this parameter is set to Disable, feed-in at limited
limited current will be unavailable.
currenta
● If this parameter is set to Enable, feed-in at limited
current will be available.

Max. feed-in currentb Value range: [0, 30000 A]

● Due to external disturbances, the feed-in current
may exceed the specified value by 2%. In this case,
the inverter will adjust the current to a value within
the range limit.
● After the user changes the maximum feed-in current,
the inverter will adjust the current to a value within
the range limit.

Max. grid supply current Value range: [0, 30000 A]

If the grid supply current exceeds the specified value by
2%, the inverter will adjust the current to a value within
the range limit.

Array startup If devices in the array shut down because the feed-in
current at the grid connection point is not complete,
you can start all inverters in the array by one click.

Note a: If the inverter shuts down because the feed-in current adjustment is not complete within
the specified time, the user needs to manually start the inverter. By default, the user needs to wait
for at least 4 hours before starting the inverter.
Note b: If the maximum feed-in current is not adjusted to a value within the range limit within
15s, the inverter will shut down and report a Power Control Abnormal at Grid Connection Point
alarm.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 83

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 7 Human-Machine Interaction

7.3.3 Apparent Power Control on the Inverter Output Side

On the home screen, tap Settings > Power adjustment and set inverter
parameters.

Figure 7-8 Apparent power control

Table 7-4 Apparent power control

Parameter Description Value Range

Maximum apparent power Specifies the output upper [Maximum

(kVA) threshold for the maximum active power,
apparent power to adapt to Smax]
the capacity requirements of
standard and customized
solar inverters.

Highest active power (kW) Specifies the output upper [0.1, Pmax]
threshold for the maximum
active power to adapt to
different market
requirements.

NOTE

The lower threshold for the maximum apparent power is the maximum active power. To
lower the maximum apparent power, lower the maximum active power first.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 84

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 8 Maintenance

8 Maintenance

DANGER

● Wear personal protective equipment and use dedicated insulated tools to avoid
electric shocks or short circuits.

WARNING

● Before performing maintenance, power off the equipment, follow the

instructions on the delayed discharge label, and wait for a period of time as
specified to ensure that the equipment is not energized.

8.1 System Power-Off

Precautions

WARNING

After the system is powered off, the inverter is still energized and hot, which may
cause electric shocks or burns. Therefore, wait for at least 5 minutes after system
power-off and put on protective gloves before working on the inverter.

Procedure
Step 1 Send a shutdown command on the app.

Step 2 Turn off the AC switch between the inverter and the power grid.

Step 3 Set the DC SWITCH at the bottom of the inverter to OFF.

Step 4 (Optional) Install the DC switch locking screw.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 85

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 8 Maintenance

Figure 8-1 Installing the DC switch locking screw

Step 5 Turn off the DC switch (if any) between the inverter and PV strings.

----End

8.2 Routine Maintenance

To ensure that the inverter can operate properly for a long term, you are advised
to perform routine maintenance on it as described in this section.

CAUTION

Power off the system before cleaning the system, connecting cables, and checking
grounding reliability.

Table 8-1 Maintenance checklist

Check Item Check Method Maintenance

Interval

System Check whether the heat sinks are Once every 6 to 12

cleanliness blocked or dirty. months

System ● Check whether the inverter is Once every 6

running status damaged or deformed. months
● Check whether the inverter
generates abnormal sound during
operation.
● Check whether all inverter
parameters are correctly set during
operation.

Electrical ● Check whether cables are 6 months after the

connections disconnected or loose. first commissioning
● Check whether cables are damaged, and once every 6 to
especially whether the cable sheath 12 months after that
that contacts a metal surface is
damaged.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 86

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 8 Maintenance

Check Item Check Method Maintenance

Interval

Grounding Check whether ground cables are 6 months after the

reliability securely connected. first commissioning
and once every 6 to
12 months after that

Sealing Check whether all terminals and ports Once 12 months

are properly sealed.

Vegetation ● Perform inspection and weeding as Based on the local

around the required. wilting season
inverter ● Clean the site promptly after
weeding.

8.3 Alarm Reference

For details about alarms, see Inverter Alarm Reference.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 87

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 9 Handling the Inverter

9 Handling the Inverter

9.1 Removing the SUN2000

NOTICE

Before removing the SUN2000, disconnect both AC and DC connections.

Perform the following operations to remove the SUN2000:

1. Disconnect all cables from the SUN2000, including RS485 communications
cables, DC input power cables, AC output power cables, and PGND cables.
2. Remove the SUN2000 from the mounting bracket.
3. Remove the mounting bracket.

9.2 Packing the SUN2000

● If the original packing materials are available, put the SUN2000 inside them
and then seal them by using adhesive tape.
● If the original packing materials are not available, put the SUN2000 inside a
suitable cardboard box and seal it properly.

9.3 Disposing of the SUN2000

If the SUN2000 service life expires, dispose of it according to the local disposal
rules for electrical equipment waste.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 88

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

10 Technical Specifications

Efficiency
Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200
0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Maximu 97.1% 98.65%/ 98.65%/400 V 98.65%/ 98.65%/400 V

m 400 V 98.75%/480 V 400 V 98.75%/480 V
efficienc 98.75%/ 98.75%/
y 480 V 480 V

Europea 96.7% 98.4%/4 98.4%/400 V 98.4%/4 98.4%/400 V

n 00 V 98.45%/480 V 00 V 98.5%/480 V
efficienc 98.45%/ 98.5%/4
y 480 V 80 V

Input
Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200
0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Recomm 30,000 W 44,850 45,000 W 54,000 60,000 W

ended W W
maximu
m input
DC
power

Maximu 800 V 1100 V

m input
voltagea

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 89

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200

0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Maximu 27 A
m input
current
per
MPPT
circuit

Maximu 40 A
m short-
circuit
current
per
MPPT
circuit

Minimu 200 V
m
startup
voltage

Operatin 200–750 V 200–1000 V

g
voltage
rangeb

Full-load 300–550 V 500–800 500–800 V/(380 V 520–800 540–800 V/(380 V

MPPT V/400 V AC, 400 V AC) V/(380 V AC, 400 V AC)
voltage AC 625–850 V/440 V AC, 400 625–850 V/440 V
rangec 625–850 AC V AC) AC
V/480 V 625–850 V/480 V 625–850 625–850 V/480 V
AC AC V/440 V AC
AC
625–850
V/480 V
AC

Rated 350 V 600 600 V/(380 V AC, 600 V/ 600 V/(380 V AC,
input V/400 V 400 V AC) (380 V 400 V AC)
voltage AC 650 V/440 V AC AC, 400 650 V/440 V AC
720 V AC)
720 V/480 V AC 720 V/480 V AC
V/480 V 650
AC V/440 V
AC 720
V/480 V
AC

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 90

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200

0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Maximu 8
m
number
of inputs

Number 4
of MPPT
circuits

Note a: The maximum input voltage is the maximum DC input voltage that the inverter can
withstand. If the input voltage exceeds this value, the inverter may be damaged.
Note b: If the input voltage is beyond the operating voltage range, the inverter cannot work
properly.
Note c: The PV strings connecting to the same MPPT circuit shall use the same model and
quantity of PV modules. It is recommended that the PV string voltage be higher than the lower
threshold of the full-load MPPT voltage.

Output
Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200
0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Rated 20,000 W 29,900 30,000 W 36,000 40,000 W

output W W
power

Maximu 22,000 VA 29,900 33,000 VAa 40,000 44,000 VA

m VA VA
apparen
t power

Maximu 22,000 W 29,900 33,000 Wa 40,000 44,000 W

m active W W
power
(cosφ =
1)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 91

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200

0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Rated 127 V AC/220 V AC, 230 V 220 V AC/380 V AC, 220 V 220 V AC/380 V AC,
output 230 V AC/400 V AC, AC/400 230 V AC/400 V AC, AC/380 230 V AC/400 V AC,
voltageb V AC, V AC,
3W+(N)c+PE 254 V AC/440 V AC, 254 V AC/440 V AC,
277 V 230 V
AC/480 277 V AC/480 V AC, AC/400 277 V AC/480 V AC,
V AC, 3W+(N)c+PE V AC, 3W+(N)c+PE
3W+(N)c 254 V
+PE AC/440
V AC,
277 V
AC/480
V AC,
3W+(N)c
+PE

Maximu Refer to the local power grid standards.

m
output
voltage
at long-
term
operatio
n

Rated 52.5 A/220 V AC 43.2 45.6 A/380 V AC 54.7 60.8 A/380 V AC

output 28.9 A/400 V AC A/400 V 43.3 A/400 V AC A/380 V 57.8 A/400 V AC
current AC AC
39.4 A/440 V AC 52.5 A/440 V AC
36.0 52.0
A/480 V 36.1 A/480 V AC A/400 V 48.1 A/480 V AC
AC AC
47.3
A/440 V
AC
43.3
A/480 V
AC

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 92

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200

0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Maximu 58.0 A/220 V AC 43.2 50.4 A/380 V AC 61.1 67.2 67.2

m 31.9 A/400 V AC A/400 V 47.9 A/400 V AC A/380 V A/380 V A/380 V
output AC AC AC AC
current 43.5 A/440 V AC
36.0 58.0 63.8 63.8
A/480 V 39.9 A/480 V AC A/400 V A/400 V A/400 V
AC AC AC AC
52.8 58.0 58.0
A/440 V A/440 V A/440 V
AC AC AC
(Mexico) (Mexico) (Mexico)
48.4 53.2 53.2
A/480 V A/480 V A/480 V
AC AC AC

Output 50 Hz/60 Hz
voltage
frequenc
y

Power 0.8 leading to 0.8 lagging

factor

Output < 0.5% of the rated output

DC
compon
ent
(DCI)

Maximu < 3% under rated conditions. Single harmonic meets the VDE 4105 requirements.
m total
harmoni
c
distortio
n
AC THDi

Note a: Under the German VDE-AR-N-4105, Belgium C10/11, and Austrian TOR grid codes, the
SUN2000-30KTL-M3 has a maximum apparent power of 30000 VA and a maximum active power
(cosφ=1) of 30000 W.
Note b: The rated output voltage is determined by Grid Codes, which can be set on the SUN2000
app, SmartLogger, or management system.
Note c: You can determine whether to connect the N wire based on the application scenario. In
scenarios without N wires, set Output mode to Three-phase three-wire. In scenarios with N
wires, set Output Mode to Three-phase four-wire.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 93

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Protection
Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200
0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Overvolt PV II/AC III

age
category

Input DC Supported
switch

Anti- Supported
islandin
g
protectio
n

Output Supported
overcurr
ent
protectio
n

Input Supported
reverse
connecti
on
protectio
n

PV Supported
string
fault
detectio
n

DC Type II Type II Type II Type II/ Type II Type II/ Type II/ Type II
surge Type I Type I Type I
protectio (optiona (optiona (optiona
n l) l) l)

AC surge Type II
protectio
n

Insulatio Supported
n
resistanc
e
detectio
n

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 94

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200

0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Residual Supported
current
monitori
ng unit
(RCMU)

Display and Communication

Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200
0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Display LED indicators; WLAN+App

RS485 Supported

Built-in Supported
WLAN

AC Not supported. Certain spare part models support this function. For details, contact the
MBUS dealer.

DC Supported
MBUS

AFCI Supported

PID Supported
recovery

General Specifications
Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200
0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Dimensi 640 mm x 530 mm x 270 mm

ons (W x
H x D)

Net 43 kg
weight

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 95

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200 SUN200

0-20KTL 0-20KTL 0-29.9K 0-30KTL 0-30KTL 0-36KTL 0-40KTL 0-40KTL
-M3 -BRM3 TL-M3 -M3 -BRM3 -M3 -M3 -BRM3

Operatin –25°C to +60°C (input derated when the temperature is above +45°C)
g
ambient
tempera
ture

Relative 0%–100%
humidity

Cooling Natural convection

mode

Maximu 4000 m
m
operatin
g
altitude

Storage –40°C to +70°C

tempera
ture

IP rating IP66

Topolog Transformerless
y

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 96

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Wireless Communication Specifications

Item Inverter Built-in WLAN-FE Smart 4G Smart Dongle
WiFi Dongle

Frequenc 2400–2483.5 SDongleA-05: SDongleB-06-EU (WiFi):

y MHz 2400–2483.5 MHz 2400–2483.5 MHz
SDongleB-06-EU (4G):
● Supports LTE FDD: B1/B3/B5/B8.
● Supports LTE TDD:
B7/B20/B28/B38/B40/B41.
● Supports GSM/GPRS/EDGE: 900 MHz/
1800 MHz.
SDongleB-06-AU (WiFi):
2400–2483.5 MHz
SDongleB-06-AU (4G):
● LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28
● LTE-TDD: B40
● WCDMA: B1/B2/B5/B8
● GSM: 850 MHz/900 MHz/1800 MHz/
1900 MHz
Note: The SDongleB-06-EU applies only
to Europe. The SDongleB-06-EU applies
only to Australia.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 97

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item Inverter Built-in WLAN-FE Smart 4G Smart Dongle

WiFi Dongle

Protocol WLAN SDongleA-05: SDongleB-06-EU (WiFi):

standard 802.11b/g/n WLAN 802.11b/g/n WLAN 802.11b/g/n
SDongleB-06-EU (4G):
● Supports LTE FDD (with receive
diversity): B1/B3/B5/B8.
● Supports LTE TDD (with receive
diversity): B7/B20/B28/B38/B40/B41.
● Supports GSM: 900 MHz/1800 MHz.
● Supports digital audio.
SDongleB-06-AU (WiFi):
WLAN 802.11b/g/n
SDongleB-06-AU (4G):
● Supports LTE FDD (with receive
diversity): B1/B2/B3/B4/B5/B7/B8/B28/
B66.
● Supports LTE-TDD (with receive
diversity): B40.
● Supports WCDMA: B1/B2/B4/B5/B8.
● Supports GSM: 850/900/1800/1900
MHz.
● Supports digital audio.
Note: The SDongleB-06-EU applies only
to Europe. The SDongleB-06-EU applies
only to Australia.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 98

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item Inverter Built-in WLAN-FE Smart 4G Smart Dongle

WiFi Dongle

Bandwidt 20 MHz/40 MHz 20 MHz/40 MHz LTE features:

h (optional) (optional) ● Supports a maximum of 3GPP R8 non-
CA Cat 4 FDD and TDD.
● Supports 1.4 MHz/3 MHz/5 MHz/10
MHz/15 MHz/20 MHz RF bandwidth.
● Supports MIMO in the downlink.
● LTE FDD: maximum downlink rate of
150 Mbit/s and maximum uplink rate
of 50 Mbit/s
● LTE TDD: maximum downlink rate of
130 Mbit/s and maximum uplink rate
of 30 Mbit/s
UMTS features:
● Supports 3GPP R7 HSDPA+, HSDPA,
HSUPA, and WCDMA.
● Supports QPSK and 16QAM
modulation.
● HSDPA+: maximum downlink rate of
21 Mbit/s
● HSUPA: maximum uplink rate of 5.76
Mbit/s
● WCDMA: maximum downlink rate of
384 kbit/s and maximum uplink rate
of 384 kbit/s
GSM features:
GPRS:
● Supports GPRS multislot class 12.
● Coding schemes: CS-1, CS-2, CS-3, and
CS-4
● Maximum downlink rate: 85.6 kbit/s;
maximum uplink rate: 85.6 kbit/s
EDGE:
● Supports EDGE multislot class 12.
● Supports GMSK and 8-PSK modulation
and coding schemes.
● Downlink coding format: MCS 1–9
● Uplink coding format: MCS 1–9
● Maximum downlink rate: 236.8 kbit/s;
maximum uplink rate: 236.8 kbit/s

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 99

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual 10 Technical Specifications

Item Inverter Built-in WLAN-FE Smart 4G Smart Dongle

WiFi Dongle

Maximu ≤ 20 dBm EIRP ≤ 20 dBm EIRP ● Class 4 (33 dBm±2 dB), EGSM900
m frequency band
transmit ● Class 1 (30 dBm±2 dB), DCS1800
power frequency band
● Class E2 (27 dBm±3 dB), EGSM900 8-
PSK
● Class E2 (26 dBm±3 dB), DCS1800 8-
PSK
● Class 3 (24 dBm+1/–3 dB), WCDMA
frequency band
● Class 3 (23 dBm±2 dB), LTE FDD
frequency band
● Class 3 (23 dBm±2 dB), LTE TDD
frequency band

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 100

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

A Grid Codes

NOTE

The grid codes are subject to change. The listed codes are for reference only.

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

1 VDE-AR- Germany - - - Suppo Suppo Suppo Suppo Suppo

N-4105 low- rted rted rted rted rted
voltage
power
grid

2 NB/T China - - - Suppo Suppo Suppo Suppo Suppo

32004 low- rted rted rted rted rted
voltage
power
grid

3 UTE C France - - - Suppo Suppo Suppo Suppo Suppo

15-712-1( mainland rted rted rted rted rted
A) power
grid

4 UTE C France - - - Suppo Suppo Suppo Suppo Suppo

15-712-1( island rted rted rted rted rted
B) power
grid

5 UTE C France - - Suppo Suppo Suppo Suppo Suppo Suppo

15-712-1( island rted rted rted rted rted rted
C) power
grid

6 VDE Bulgaria - - - Suppo Suppo Suppo Suppo Suppo

0126-1-1- power rted rted rted rted rted
BU grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 101

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

7 VDE Greece - - - Suppo Suppo Suppo Suppo Suppo

0126-1-1- mainland rted rted rted rted rted
GR(A) power
grid

8 VDE Greece - - - Suppo Suppo Suppo Suppo Suppo

0126-1-1- island rted rted rted rted rted
GR(B) power
grid

9 BDEW- Germany - - - Suppo Suppo Suppo Suppo Suppo

MV medium- rted rted rted rted rted
voltage
power
grid

10 G59- England - - - Suppo Suppo Suppo Suppo Suppo

England 230 V rted rted rted rted rted
power
grid (I >
16 A)

11 G59- Scotland - - - Suppo Suppo Suppo Suppo Suppo

Scotland 240 V rted rted rted rted rted
power
grid (I >
16 A)

12 G83- England - - - Suppo Suppo Suppo Suppo Suppo

England 230 V rted rted rted rted rted
power
grid (I <
16 A)

13 G83- Scotland - - - Suppo Suppo Suppo Suppo Suppo

Scotland 240 V rted rted rted rted rted
power
grid (I <
16 A)

14 CEI0-21 Italy - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

15 RD1699/6 Spain low- - - - Suppo Suppo Suppo Suppo Suppo

61 voltage rted rted rted rted rted
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 102

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

16 RD1699/6 Spain - - - Suppo Suppo Suppo Suppo Suppo

61- medium- rted rted rted rted rted
MV480 voltage
power
grid

17 EN50438- Netherlan - - - Suppo Suppo Suppo Suppo Suppo

NL ds power rted rted rted rted rted
grid

18 C10/11 Belgium - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

19 AS4777 Australia - - Suppo Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted rted
grid

20 AS4777- Australia - - Suppo Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted rted
voltage
power
grid

21 AUSTRALI Australia - - Suppo Suppo Suppo Suppo Suppo Suppo

A-NER NER rted rted rted rted rted rted
standard
power
grid

22 AUSTRALI Australia - - Suppo Suppo Suppo Suppo Suppo Suppo

A-NER- NER rted rted rted rted rted rted
MV480 standard
power
grid

23 AS4777- Australia - - Suppo Suppo Suppo Suppo Suppo Suppo

WP power rted rted rted rted rted rted
grid

24 AS4777_A Australia - - Suppo - - Suppo Suppo Suppo

CT power rted rted rted rted
grid

25 AS4777_ Australia - - Suppo - - Suppo Suppo Suppo

NSW_ESS power rted rted rted rted
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 103

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

26 AS4777_ Australia - - Suppo - - Suppo Suppo Suppo

NSW_AG power rted rted rted rted
grid

27 AS4777_ Australia - - Suppo - - Suppo Suppo Suppo

QLD power rted rted rted rted
grid

28 AS4777_S Australia - - Suppo - - Suppo Suppo Suppo

A power rted rted rted rted
grid

29 AS4777_V Australia - - Suppo - - Suppo Suppo Suppo

IC power rted rted rted rted
grid

30 AUSTRALI Australia - - Suppo - - Suppo Suppo Suppo

A- power rted rted rted rted
AS4777_A grid
-LV230

31 AUSTRALI Australia - - Suppo - - Suppo Suppo Suppo

A- power rted rted rted rted
AS4777_B grid
-LV230

32 AUSTRALI Australia - - Suppo - - Suppo Suppo Suppo

A- power rted rted rted rted
AS4777_C grid
-LV230

33 AUSTRALI Australia - - Suppo - - Suppo Suppo Suppo

A- power rted rted rted rted
AS4777_ grid
NZ-LV230

34 IEC61727 IEC 61727 Suppo Suppo - Suppo Suppo Suppo Suppo Suppo
low- rted rted rted rted rted rted rted
voltage
grid-
connectio
n (50 Hz)

35 Custom Reserved - - - Suppo Suppo Suppo Suppo Suppo

(50 Hz) rted rted rted rted rted

36 Custom Reserved - - - Suppo Suppo Suppo Suppo Suppo

(60 Hz) rted rted rted rted rted

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 104

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

37 CEI0-16 Italy - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

38 CHINA- China - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
standard
power
grid

39 CHINA- China - - - Suppo Suppo Suppo Suppo Suppo

MV medium- rted rted rted rted rted
voltage
standard
power
grid

40 TAI-PEA Thailand - - - Suppo Suppo Suppo Suppo Suppo

grid- rted rted rted rted rted
connectio
n standard

41 TAI-MEA Thailand - - - Suppo Suppo Suppo Suppo Suppo

grid- rted rted rted rted rted
connectio
n standard

42 BDEW- Germany - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
standard
power
grid

43 Custom Reserved - - - Suppo Suppo Suppo Suppo Suppo

MV480 rted rted rted rted rted
(50 Hz)

44 Custom Reserved - - - Suppo Suppo Suppo Suppo Suppo

MV480 rted rted rted rted rted
(60 Hz)

45 G59- UK 480 V - - - Suppo Suppo Suppo Suppo Suppo

England- medium- rted rted rted rted rted
MV480 voltage
grid
connectio
n (I > 16
A)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 105

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

46 IEC61727- IEC 61727 - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
grid-
connectio
n (50 Hz)

47 UTE C France - - - Suppo Suppo Suppo Suppo Suppo

15-712-1- island rted rted rted rted rted
MV480 power
grid

48 TAI-PEA- Thailand - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
grid-
connectio
n (PEA)

49 TAI-MEA- Thailand - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
grid-
connectio
n (MEA)

50 EN50438- Denmark - - - Suppo Suppo Suppo Suppo Suppo

DK- medium- rted rted rted rted rted
MV480 voltage
grid-
connectio
n

51 EN50438- Türkiye - - - Suppo Suppo Suppo Suppo Suppo

TR- medium- rted rted rted rted rted
MV480 voltage
power
grid

52 EN50438- Türkiye - - - Suppo Suppo Suppo Suppo Suppo

TR low- rted rted rted rted rted
voltage
power
grid

53 C11/C10- Belgium - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 106

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

54 Philippine Philippines - - - Suppo Suppo Suppo Suppo Suppo

s low- rted rted rted rted rted
voltage
power
grid

55 Philippine Philippines - - - Suppo Suppo Suppo Suppo Suppo

s-MV480 medium- rted rted rted rted rted
voltage
power
grid

56 NRS-097- South - - - Suppo Suppo Suppo Suppo Suppo

2-1 Africa rted rted rted rted rted
standard
power
grid

57 NRS-097- South - - - Suppo Suppo Suppo Suppo Suppo

2-1- Africa rted rted rted rted rted
MV480 medium-
voltage
standard
power
grid

58 KOREA South - - - Suppo Suppo Suppo Suppo Suppo

Korea rted rted rted rted rted
power
grid

59 IEEE IEEE 1547- - - - Suppo Suppo Suppo Suppo Suppo

1547- MV480 rted rted rted rted rted
MV480

60 IEC61727- IEC 61727 - - - Suppo Suppo Suppo Suppo Suppo

60Hz low- rted rted rted rted rted
voltage
grid-
connectio
n (60 Hz)

61 IEC61727- IEC 61727 - - - Suppo Suppo Suppo Suppo Suppo

60Hz- medium- rted rted rted rted rted
MV480 voltage
grid-
connectio
n (60 Hz)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 107

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

62 CHINA_M China - - - Suppo Suppo Suppo Suppo Suppo

V500 medium- rted rted rted rted rted
voltage
standard
power
grid

63 ANRE Romania - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid (Type
A)

64 PO12.3- Spain - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

65 EN50438_ Ireland - - - Suppo Suppo Suppo Suppo Suppo

IE-MV480 medium- rted rted rted rted rted
voltage
power
grid

66 EN50438_ Ireland - - - Suppo Suppo Suppo Suppo Suppo

IE low- rted rted rted rted rted
voltage
power
grid

67 IEC61727- India 500 - - - Suppo Suppo Suppo Suppo Suppo

50Hz- V rted rted rted rted rted
MV500 medium-
voltage
power
grid

68 CEI0-16- Italy - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

69 PO12.3 Spain low- - - - Suppo Suppo Suppo Suppo Suppo

voltage rted rted rted rted rted
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 108

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

70 CEI0-21- Italy - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

71 KOREA- South - - - Suppo Suppo Suppo Suppo Suppo

MV480 Korea rted rted rted rted rted
medium-
voltage
power
grid

72 Egypt Egypt - - - Suppo Suppo Suppo Suppo Suppo

ETEC low- rted rted rted rted rted
voltage
power
grid

73 Egypt Egypt - - - Suppo Suppo Suppo Suppo Suppo

ETEC- medium- rted rted rted rted rted
MV480 voltage
power
grid

74 EN50549- Ireland - - - Suppo Suppo Suppo Suppo Suppo

LV power rted rted rted rted rted
grid

75 EN50549- Ireland - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

76 Jordan- Jordan - - - Suppo Suppo Suppo Suppo Suppo

Transmiss low- rted rted rted rted rted
ion voltage
power
grid

77 Jordan- Jordan - - - Suppo Suppo Suppo Suppo Suppo

Transmiss medium- rted rted rted rted rted
ion- voltage
MV480 power
grid

78 NAMIBIA Namibia - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 109

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

79 ABNT Brazil - - - Suppo Suppo Suppo Suppo Suppo

NBR power rted rted rted rted rted
16149 grid

80 ABNT Brazil - - - Suppo Suppo Suppo Suppo Suppo

NBR medium- rted rted rted rted rted
16149- voltage
MV480 power
grid

81 SA_RPPs South - - - Suppo Suppo Suppo Suppo Suppo

Africa rted rted rted rted rted
low-
voltage
power
grid

82 SA_RPPs- South - - - Suppo Suppo Suppo Suppo Suppo

MV480 Africa rted rted rted rted rted
medium-
voltage
power
grid

83 INDIA India low- - - - Suppo Suppo Suppo Suppo Suppo

voltage rted rted rted rted rted
power
grid

84 INDIA- India - - - Suppo Suppo Suppo Suppo Suppo

MV500 medium- rted rted rted rted rted
voltage
power
grid

85 ZAMBIA Zambia - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid

86 ZAMBIA- Zambia - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 110

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

87 Chile Chile low- - - - Suppo Suppo Suppo Suppo Suppo

voltage rted rted rted rted rted
power
grid

88 Chile- Chile - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

89 Mexico- Mexico - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

90 Malaysia Malaysia - - - Suppo Suppo Suppo Suppo Suppo

n low- rted rted rted rted rted
voltage
power
grid

91 Malaysia Malaysia - - - Suppo Suppo Suppo Suppo Suppo

n-MV480 medium- rted rted rted rted rted
voltage
power
grid

92 KENYA_E Kenya - - - Suppo Suppo Suppo Suppo Suppo

THIOPIA low- rted rted rted rted rted
voltage
power
grid and
Ethiopia
power
grid

93 KENYA_E Kenya - - - Suppo Suppo Suppo Suppo Suppo

THIOPIA- low- rted rted rted rted rted
MV480 voltage
power
grid and
Ethiopia
medium-
voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 111

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

94 NIGERIA Nigeria - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid

95 NIGERIA- Nigeria - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

96 DUBAI Dubai - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid

97 DUBAI- Dubai - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

98 Northern Northern - - - Suppo Suppo Suppo Suppo Suppo

Ireland Ireland rted rted rted rted rted
low-
voltage
power
grid

99 Northern Northern - - - Suppo Suppo Suppo Suppo Suppo

Ireland- Ireland rted rted rted rted rted
MV480 medium-
voltage
power
grid

100 Cameroo Cameroon - - - Suppo Suppo Suppo Suppo Suppo

n low- rted rted rted rted rted
voltage
power
grid

101 Cameroo Cameroon - - - Suppo Suppo Suppo Suppo Suppo

n-MV480 medium- rted rted rted rted rted
voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 112

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

102 Jordan- Jordan - - - Suppo Suppo Suppo Suppo Suppo

Distributi power rted rted rted rted rted
on distributio
n network
low-
voltage
power
grid

103 Jordan- Jordan - - - Suppo Suppo Suppo Suppo Suppo

Distributi power rted rted rted rted rted
on- distributio
MV480 n network
medium-
voltage
power
grid

104 NAMIBIA Namibia - - - Suppo Suppo Suppo Suppo Suppo

_MV480 power rted rted rted rted rted
grid

105 LEBANO Lebanon - - - Suppo Suppo Suppo Suppo Suppo

N low- rted rted rted rted rted
voltage
power
grid

106 LEBANO Lebanon - - - Suppo Suppo Suppo Suppo Suppo

N-MV480 medium- rted rted rted rted rted
voltage
power
grid

107 ARGENTI Argentina - - - Suppo Suppo Suppo Suppo Suppo

NA- medium- rted rted rted rted rted
MV500 voltage
power
grid

108 Jordan- Jordan - - - Suppo Suppo Suppo Suppo Suppo

Transmiss high- rted rted rted rted rted
ion-HV voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 113

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

109 Jordan- Jordan - - - Suppo Suppo Suppo Suppo Suppo

Transmiss high- rted rted rted rted rted
ion- voltage
HV480 power
grid

110 TUNISIA Tunisia - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

111 TUNISIA- Tunisia - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

112 SAUDI Saudi - - - Suppo Suppo Suppo Suppo Suppo

Arabia rted rted rted rted rted
power
grid

113 SAUDI- Saudi - - - Suppo Suppo Suppo Suppo Suppo

MV480 Arabia rted rted rted rted rted
power
grid

114 Ghana- Ghana - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

115 Israel Israel - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

116 Israel- Israel - - - Suppo Suppo Suppo Suppo Suppo

MV400 power rted rted rted rted rted
grid

117 Israel- Israel - - - Suppo Suppo Suppo Suppo Suppo

MV480 power rted rted rted rted rted
grid

118 Chile- Chile - - - Suppo Suppo Suppo Suppo Suppo

PMGD PMGD rted rted rted rted rted
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 114

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

119 Chile- Chile - - - Suppo Suppo Suppo Suppo Suppo

PMGD- PMGD rted rted rted rted rted
MV480 power
grid

120 VDE-AR- VDE 4120 - - - Suppo Suppo Suppo Suppo Suppo

N4120- standard rted rted rted rted rted
HV power
grid

121 VDE-AR- VDE 4120 - - - Suppo Suppo Suppo Suppo Suppo

N4120- standard rted rted rted rted rted
HV480 power
grid

122 CHINA- China - - - Suppo Suppo Suppo Suppo Suppo

LV220/38 low- rted rted rted rted rted
0 voltage
power
grid

123 Vietnam Vietnam - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

124 Vietnam- Vietnam - - - Suppo Suppo Suppo Suppo Suppo

MV480 power rted rted rted rted rted
grid

125 TAIPOWE Taiwan - - - Suppo Suppo Suppo Suppo Suppo

R Power rted rted rted rted rted
low-
voltage
power
grid

126 TAIPOWE Taiwan - - - Suppo Suppo Suppo Suppo Suppo

R-MV480 Power rted rted rted rted rted
medium-
voltage
power
grid (480
V)

127 ARGENTI Argentina - - - Suppo Suppo Suppo Suppo Suppo

NA- medium- rted rted rted rted rted
MV480 voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 115

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

128 OMAN Oman - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid

129 OMAN- Oman - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

130 KUWAIT Kuwait - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid

131 KUWAIT- Kuwait - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

132 BANGLA Banglades - - - Suppo Suppo Suppo Suppo Suppo

DESH h low- rted rted rted rted rted
voltage
power
grid

133 BANGLA Banglades - - - Suppo Suppo Suppo Suppo Suppo

DESH- h rted rted rted rted rted
MV480 medium-
voltage
power
grid

134 Chile- Chile Net - - - Suppo Suppo Suppo Suppo Suppo

Net_Billin Billing rted rted rted rted rted
g power
grid

135 EN50438- Netherlan - - - Suppo Suppo Suppo Suppo Suppo

NL- ds rted rted rted rted rted
MV480 medium-
voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 116

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

136 BAHRAIN Bahrain - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid

137 BAHRAIN Bahrain - - - Suppo Suppo Suppo Suppo Suppo

-MV480 medium- rted rted rted rted rted
voltage
power
grid

138 Fuel_Engi Genset - - - Suppo Suppo Suppo Suppo Suppo

ne_Grid hybrid rted rted rted rted rted
power
grid

139 Fuel- Genset - - - Suppo Suppo Suppo Suppo Suppo

Engine- hybrid rted rted rted rted rted
Grid-60H power
z grid

140 ARGENTI Argentina - - - Suppo Suppo Suppo Suppo Suppo

NA power rted rted rted rted rted
grid

141 Mauritius Mauritius - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

142 Mauritius Mauritius - - - Suppo Suppo Suppo Suppo Suppo

-MV480 medium- rted rted rted rted rted
voltage
power
grid

143 EN50438- Sweden - - - Suppo Suppo Suppo Suppo Suppo

SE low- rted rted rted rted rted
voltage
power
grid

144 Pakistan Pakistan - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

145 Austria Austria - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 117

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

146 Austria- Austria - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

147 G99- UK G99- - - - Suppo Suppo Suppo Suppo Suppo

TYPEA-LV TYPEA-LV rted rted rted rted rted

148 G99- UK G99- - - - Suppo Suppo Suppo Suppo Suppo

TYPEB-LV TYPEB-LV rted rted rted rted rted

149 G99- UK G99- - - - Suppo Suppo Suppo Suppo Suppo

TYPEB- TYPEB-HV rted rted rted rted rted
HV

150 G99- UK G99- - - - Suppo Suppo Suppo Suppo Suppo

TYPEB- TYPEB-HV rted rted rted rted rted
HV- medium-
MV480 voltage

151 G99- UK G99- - - - Suppo Suppo Suppo Suppo Suppo

TYPEA- TYPEA-HV rted rted rted rted rted
HV

152 EN50549- Ireland - - - Suppo Suppo Suppo Suppo Suppo

MV400 new rted rted rted rted rted
standard
power
grid

153 VDE-AR- Germany - - - Suppo Suppo Suppo Suppo Suppo

N4110 medium- rted rted rted rted rted
voltage
power
grid (230
V)

154 VDE-AR- Germany - - - Suppo Suppo Suppo Suppo Suppo

N4110- medium- rted rted rted rted rted
MV480 voltage
standard
power
grid

155 NTS Spain - - - Suppo Suppo Suppo Suppo Suppo

power rted rted rted rted rted
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 118

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

156 NTS- Spain - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

157 CEA India CEA - - - Suppo Suppo Suppo Suppo Suppo

low- rted rted rted rted rted
voltage
power
grid

158 CEA- India CEA - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

159 SINGAPO Singapore - - - Suppo Suppo Suppo Suppo Suppo

RE low- rted rted rted rted rted
voltage
power
grid

160 SINGAPO Singapore - - - Suppo Suppo Suppo Suppo Suppo

RE- medium- rted rted rted rted rted
MV480 voltage
power
grid

161 HONGKO Hong - - - Suppo Suppo Suppo Suppo Suppo

NG Kong low- rted rted rted rted rted
voltage
power
grid

162 HONGKO Hong - - - Suppo Suppo Suppo Suppo Suppo

NG- Kong rted rted rted rted rted
MV480 medium-
voltage
power
grid

163 C10/11- Belgium - - - Suppo Suppo Suppo Suppo Suppo

MV400 medium- rted rted rted rted rted
voltage
power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 119

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

164 EN50549- Sweden - - - Suppo Suppo Suppo Suppo Suppo

SE low- rted rted rted rted rted
voltage
power
grid

165 EN50549- Poland - - - Suppo Suppo Suppo Suppo Suppo

PL power rted rted rted rted rted
grid

166 DANMAR Denmark - - - Suppo Suppo Suppo Suppo Suppo

K- power rted rted rted rted rted
EN50549- grid
DK1-
LV230

167 DANMAR Denmark - - - Suppo Suppo Suppo Suppo Suppo

K- power rted rted rted rted rted
EN50549- grid
DK2-
LV230

168 SWITZERL Switzerlan - - - Suppo Suppo Suppo Suppo Suppo

AND-NA/ d power rted rted rted rted rted
EEA:2020 grid
-LV230

169 ABNT Brazil low- Suppo Suppo - - - - - -

NBR voltage rted rted
16149- power
LV127 grid

170 Mexico- Mexico Suppo Suppo - - - - - -

LV220 low- rted rted
voltage
power
grid

171 Philippine Philippines Suppo Suppo - - - - - -

s- low- rted rted
LV220-50 voltage
Hz power
grid (50
Hz)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 120

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

172 Philippine Philippines Suppo Suppo - - - - - -

s- low- rted rted
LV220-60 voltage
Hz power
grid (60
Hz)

173 TAIPOWE Taiwan Suppo Suppo - - - - - -

R-LV220 Power rted rted
low-
voltage
power
grid

174 NC2022 New - - - Suppo Suppo Suppo Suppo Suppo

Caledonia rted rted rted rted rted
power
grid

175 AUSTRIA- Austria - - - Suppo Suppo Suppo Suppo Suppo

TYPEB- power rted rted rted rted rted
LV400 grid

176 AUSTRIA- Austria - - - Suppo Suppo Suppo Suppo Suppo

TYPEB- power rted rted rted rted rted
LV480 grid

177 AUSTRIA- Austria - - - Suppo Suppo Suppo Suppo Suppo

TYPEB- power rted rted rted rted rted
MV400 grid

178 AUSTRIA- Austria - - - Suppo Suppo Suppo Suppo Suppo

TYPEB- power rted rted rted rted rted
MV480 grid

179 EN50438- Czech - - - Suppo Suppo Suppo Suppo Suppo

CZ Republic rted rted rted rted rted
power
grida

180 CZECH- Czech - - - Suppo Suppo Suppo Suppo Suppo

EN50549- Republic rted rted rted rted rted
LV230 power
grida

181 BRAZIL- Brazil - - - Suppo Suppo - Suppo Suppo

P140- P140 rted rted rted rted
LV220 power
grid

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 121

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual A Grid Codes

No. Grid Descriptio SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2 SUN2
Code n 000-2 000-2 000-2 000-3 000-3 000-3 000-4 000-4
0KTL- 0KTL- 9.9KT 0KTL- 0KTL- 6KTL- 0KTL- 0KTL-
M3 BRM3 L-M3 M3 BRM3 M3 M3 BRM3

182 BRAZIL- Brazil Suppo Suppo - - - - - -

P140-127 P140 rted rted
/220 power
grid

183 BRAZIL- Brazil - - - Suppo Suppo - Suppo Suppo

P140-480 P140 rted rted rted rted
power
grid

184 ANRE- Romania - - - Suppo Suppo Suppo Suppo Suppo

MV480 medium- rted rted rted rted rted
voltage
power
grid

185 FINLAND Finland - - - Suppo Suppo - Suppo Suppo

- power rted rted rted rted
EN50549- grid
LV230

186 ANRE- Romania - - - Suppo Suppo Suppo Suppo Suppo

TYPEB power rted rted rted rted rted
grid (type
B)

187 ANRE- Romania - - - Suppo Suppo Suppo Suppo Suppo

TYPEB- power rted rted rted rted rted
MV480 grid (type
B)

188 CHINA- China - - - Suppo - Suppo - -

GBT1996 Region rted rted
4-500 power
gridb

189 CHINA- China - - - Suppo - Suppo - -

GBT1996 Region rted rted
4-480 power
gridb

190 FRANCE- France FD - - - Suppo - Suppo Suppo -

EN50549- C11-519-1 rted rted rted
230 1

Note a: The Czech Republic grid code requires that the inverter be subject to dispatching by the
electric power company through DI. For details, see G Setting Dry Contact Scheduling.
Note b: Only certain models support this grid code. For details, contact your vendor.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 122

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual B Device Commissioning

B Device Commissioning

Step 1 Access Device commissioning screen.

Figure B-1 Method 1: before login (not connected to the Internet)

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 123

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual B Device Commissioning

Figure B-2 Method 2: after login (connected to the Internet)

Step 2 Connect to the solar inverter WLAN and log in to the device commissioning screen
as the installer user.

NOTICE

● When connecting to the SUN2000 directly from the mobile phone, keep the
mobile phone visible within 3 meters of the SUN2000 to ensure the
communication quality between the app and SUN2000. The distances are for
reference only and may vary with mobile phones and shielding conditions.
● When connecting the SUN2000 to the WLAN over a router, ensure that the
mobile phone and SUN2000 are in the WLAN coverage of the router and the
SUN2000 is connected to the router.
● The router supports WLAN (IEEE 802.11 b/g/n, 2.4 GHz) and the WLAN signal
reaches the SUN2000.
● The WPA, WPA2, or WPA/WPA2 encryption mode is recommended for routers.
Enterprise-level encryption is not supported (for example, public hotspots
requiring authentication such as airport WLAN). WEP and WPA TKIP are not
recommended because these two encryption modes have serious security
defects. If the access fails in WEP mode, log in to the router and change the
encryption mode of the router to WPA2 or WPA/WPA2.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 124

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual B Device Commissioning

NOTE

● Obtain the initial password for connecting to the solar inverter WLAN from the label on
the side of the solar inverter.
● Use the initial password upon first power-on and change it immediately after login. To
ensure account security, change the password periodically and keep the new password
in mind. Not changing the initial password may cause password disclosure. A password
left unchanged for a long period of time may be stolen or cracked. If a password is lost,
devices cannot be accessed. In these cases, the user is liable for any loss caused to the
PV plant.
● When you access the Device commissioning screen of the SUN2000 for the first time,
you need to manually set the login password because the SUN2000 does not have an
initial login password.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 125

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual C Built-in PID Recovery

C Built-in PID Recovery

NOTICE

Ensure that the inverter PE cable is securely connected. Otherwise, the built-in PID
recovery function may be unavailable and electric shocks may occur.

Procedure
Step 1 On the home screen, choose Settings > Feature parameters and set related
parameters.

Figure C-1 Setting PID suppression parameters

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 126

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual C Built-in PID Recovery

NOTE

● Set Built-in PID running mode to Repair (Disable by default).

● Set Nighttime off-grid repair to . (This parameter is displayed when Built-in

PID running mode is set to Repair.)

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 127

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual D Rapid Shutdown

D Rapid Shutdown

If optimizers are configured for all PV modules, the PV system can perform a rapid
shutdown to decrease the output voltage to below 30 V within 30s. The rapid
shutdown function is supported only if optimizers are configured for all PV
modules.
Perform the following steps to trigger a rapid shutdown:
● Method 1 (recommended): Turn off the AC switch between the inverter and
the power grid.
● Method 2: Turn off the DC switch at the bottom of the inverter.
● Method 3: If the DIN5 port (pin 15) of the inverter communications terminal
is connected to a rapid shutdown switch, press the switch to trigger a rapid
shutdown.
NOTE

Log in to the FusionSolar app as an installer, choose Services > Device

commissioning, and connect to the WLAN hotspot of the inverter. Log in to the local
commissioning system as an installer, choose Settings > Feature parameters > Dry
contact function, and set Dry contact function to DI rapid shutdown.
● Method 4: If AFCI is enabled, the inverter automatically performs arc fault
detection and triggers a rapid shutdown when AFCI lock protection is
implemented.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 128

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual E NS Protection

E NS Protection

Connecting NS Protection Signal Cables to Inverters

NOTE

● The NS protection function applies to areas complying with the VDE 4105 standard. The
grid code must be set to VDE-AR-N-4105.
● Connect the NS protection switch to GND (pin 13) and DIN5 (pin 15). The switch is
turned on by default. When the switch is turned off, NS protection is triggered.
● Rapid shutdown and NS protection use the same pins, which are GND (pin 13) and
DIN5 (pin 15). Therefore, you can use only either of the functions.
● The cable connection method for a single inverter is the same as that for cascaded
inverters. For a single inverter, connect GND and DIN5 to the same cable.
● Log in to the FusionSolar app as an installer, choose Services > Device commissioning,
and connect to the WLAN hotspot of the inverter. Log in to the local commissioning
system as an installer, choose Settings > Feature parameters > Dry contact function,
and set Dry contact function to NS protection. To enable NS protection for multiple
inverters, set Dry contact function to NS protection for each inverter.

Figure E-1 Connecting cascaded inverters to the NS protection switch

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 129

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual F Resetting a Password

F Resetting a Password

Step 1 Check that the AC and DC sides of the inverter are both powered on, and
indicators and are steady green or blinking slowly for more than 3 minutes.

Step 2 Turn off the AC switch, set the DC SWITCH at the bottom of the inverter to OFF,
and wait until all LED indicators on the inverter panel are off.

Step 3 Complete the following operations within 3 minutes:

1. Turn on the AC switch and wait until the inverter indicator blinks.
2. Turn off the AC switch and wait until all LED indicators on the inverter panel
are off.
3. Turn on the AC switch and wait until all LED indicators on the inverter panel
blink and then are off after about 30s.

Step 4 Wait until the three LED indicators on the inverter panel blink green fast and then
blink red fast, which indicates that the password is restored.

Step 5 Reset the password within 10 minutes. (If no operation is performed within 10
minutes, all parameters of the inverter remain unchanged.)
1. Wait until the indicator blinks.
2. Connect to the app using the initial WLAN hotspot name (SSID) and initial
password (PSW), which can be obtained from the label on the side of the
inverter.
3. On the login screen, set a new password and log in to the app.

Step 6 Set router and management system parameters to implement remote

management.

----End

NOTICE

You are advised to reset the password in the morning or at night when the solar
irradiance is low.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 130

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual G Setting Dry Contact Scheduling

G Setting Dry Contact Scheduling

NOTICE

In the inverter parallel connection scenario, log in to the inverter connected to the
Smart Dongle to set parameters.

Function
This function applies to scenarios where the grid company performs remote
scheduling through dedicated ripple control receivers. The grid company remotely
sends a scheduling command (%) to the plant with a wireless transmitting
apparatus. Then, the wireless receiving apparatus receives the scheduling
command and converts it into a DI signal. The plant monitoring device controls
the inverter to output the corresponding power.
Ensure that the inverter is correctly connected to the ripple control receiver when
setting this function. (In Germany and some other European areas, the grid
company uses the ripple control receiver to convert a power grid scheduling signal
to a dry contact signal, and the power plant uses a dry contact to receive the
signal.)

NOTE

When the functions of the limited feed-in and scheduling via the DI port are enabled at the
same time, the system calculates the output power thresholds for both functions
respectively, and then sends the smaller value to the inverter.

Procedure
1. Connect to the inverter on the app and log in to the local commissioning
screen of the device.
2. Choose Settings > Power adjustment > Dry contact scheduling settings.
3. Enable Dry contact scheduling and set related parameters as prompted.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 131

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual G Setting Dry Contact Scheduling

Parameter Description

DI active Sets the DI scheduling signals and the corresponding

scheduling active output power percentage levels.

DI reactive Sets the DI scheduling signals and the corresponding

power reactive output power percentage levels.
scheduling

NOTE

● The two scheduling modes support 16 levels of percentages. The percentage levels
of DI1–DI4 must differ from each other. Otherwise, an exception will occur during
command parsing.
● If the actual input DI signal is inconsistent with the setting, an Abnormal DI
Instruction alarm will be generated.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 132

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series H Setting the Current Threshold for Triggering RCD
User Manual Protection

H Setting the Current Threshold for

Triggering RCD Protection

Function
A residual current device (RCD) detects residual current (that is, leakage current of
an electrical system to ground), and automatically disconnects a circuit from its
power supply when residual current exceeds the preset threshold.

NOTICE

● If the current threshold for triggering RCD protection is set to a smaller value,
the device is more likely to be shut down due to RCD protection. Exercise
caution when setting this parameter.
● Adjusting the current threshold for triggering RCD protection may cause the
device to frequently trigger the protection mechanism. In this case, you can
increase the threshold to disable the protection mechanism. Exercise caution
when setting this parameter. If you have any questions, contact the vendor or
manufacturer.

Procedure
1. Connect to the inverter on the app and log in to the local commissioning
screen of the device.
2. Choose Settings > Feature parameters > Current Threshold for Triggering
RCD Protection. Set Current Threshold for Triggering RCD Protection as
required.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 133

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series H Setting the Current Threshold for Triggering RCD
User Manual Protection

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 134

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual I AFCI

I AFCI

Function
If PV modules or cables are not properly connected or damaged, electric arcs may
occur, which may cause fire. Huawei inverters provide unique arc detection in
compliance with UL 1699B-2018 to ensure the safety of users' lives and property.
This function is enabled by default. The inverter automatically detects arc faults.
To disable this function, log in to the FusionSolar App, enter the Device
Commissioning screen, choose Settings > Feature parameters, and disable AFCI.

NOTE

The AFCI function works only with Huawei optimizers or ordinary PV modules, but does not
support third-party optimizers or intelligent PV modules.

Clearing Alarms
The AFCI function involves the DC arc fault alarm.
The inverter has the AFCI alarm automatic clearance mechanism. If an alarm is
triggered for less than five times within 24 hours, the inverter automatically clears
the alarm. If the alarm is triggered for five times or more within 24 hours, the
inverter locks for protection. You need to manually clear the alarm on the inverter
so that it can work properly.
You can manually clear the alarm as follows:
● Method 1: FusionSolar App
Log in to the FusionSolar App and choose Services > Device commissioning.
On the Device commissioning screen, connect and log in to the inverter that
generates the AFCI alarm, tap Alarm management, and tap Clear on the
right of the DC arc fault alarm to clear the alarm.

Figure I-1 Alarm management

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 135

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual I AFCI

● Method 2: FusionSolar Smart PV Management System

Log in to the FusionSolar Smart PV Management System using a non-owner
account, choose Maintenance > Alarm Management, select the DC arc fault
alarm, and click Clear to clear the alarm.

Figure I-2 Clearing alarms

Switch to the owner account with PV plant management rights. On the home
page, click the PV plant name to go to the PV plant page, and click OK as
prompted to clear the alarm.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 136

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual J PV String Access Detection

J PV String Access Detection

This function is used to detect and identify the operating status of PV strings
connected to an inverter. The status can be Unidentified, Not connected, Single
string, 2-in-1 string, Lost string, 2-in-1 string – full loss, or 2-in-1 string –
single string loss. Enable this function if you need to detect the PV string status.
Otherwise, disable this function.

Function
● PV string access detection applies to large-scale commercial and utility-scale
PV plants with PV strings facing the same direction.
● In AC or DC power limiting scenarios:
– If the PV string access type is not identified, PV Status will be displayed
as Not connected. The PV string access type can be identified only when
the inverter restores to the non-power limiting state and the current of
all connected PV strings reaches Startup current.
– After setting parameters, you can view the PV string access status on the
Running Info screen.

Procedure
Step 1 Log in to the FusionSolar app and choose Services > Device Commissioning. The
Device Commissioning screen is displayed.
Step 2 Choose Maintenance > PV string access detection. The parameter setting screen
is displayed.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 137

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual J PV String Access Detection

Figure J-1 PV string access detection

No. Parameter Description Remarks

1 PV string access The default value of PV string access detection is -

detection Disabled. After the inverter connects to the power
grid properly, you can set this parameter to Enabled.

2 Startup current When the current of all connected PV strings reaches This
the preset value, the PV string access detection parameter
function is enabled. is
NOTE displayed
Startup current setting rules: when PV
● Startup current = Isc (Stc) x 0.6 (rounded up). For details string
about Isc (Stc), see the PV module nameplate. access
detection
● Default startup current (5 A): applicable to the scenarios
where the short-circuit current Isc (Stc) is greater than 8 A
is set to
for the monocrystalline and polycrystalline PV modules. Enabled.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 138

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual J PV String Access Detection

No. Parameter Description Remarks

3 Startup current for When the current of a PV string reaches the threshold
2-in-1 detection specified by Startup current for 2-in-1 detection, the
PV string is automatically identified as 2-in-1.
The default value is recommended.

4 PV string N access Set this parameter based on the type of the PV string
type connected to DC input terminal N of the inverter.
NOTE Currently, the options are as follows: Automatic
N is the DC input identification (default value), Not connected, Single
terminal number of string, and 2-in-1 string.
the inverter.
The default value is recommended. If the value is
incorrectly set, the PV string access type may be
incorrectly identified and false alarms may be
generated for the PV string access status.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 139

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual K Smart I-V Curve Diagnosis

K Smart I-V Curve Diagnosis

For details, see iMaster NetEco V600R023C00 Smart I-V Curve Diagnosis User
Manual.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 140

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual L Locating Insulation Resistance Faults

L Locating Insulation Resistance Faults

If the ground impedance of a PV string connected to the inverter is too low, the
inverter generates a Low insulation resistance alarm.
The possible causes are as follows:
● A short circuit has occurred between the PV array and the ground.
● The ambient air of the PV array is damp and the insulation between the PV
array and the ground is poor.
After the Low insulation resistance alarm is reported by the inverter, insulation
resistance fault location is automatically triggered. If the fault location is
successful, the location information is displayed on the Alarm details screen of
the Low insulation resistance alarm on the FusionSolar app.
Log in to the FusionSolar app, choose Alarm > Active alarm, select Low
insulation resistance to enter the Alarm details screen.

Figure L-1 Alarm details

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 141

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual L Locating Insulation Resistance Faults

NOTE

● The positive and negative terminals of a PV string are respectively connected to the PV+
and PV– terminals of the inverter. The PV– terminal represents a possibility of 0% for the
short-circuit position and the PV+ terminal represents a possibility of 100% for the
short-circuit position. Other percentages indicate that the fault occurs on a PV module
or cable in the PV string.
● Possible fault position = Total number of PV modules in a PV string x Percentage of
possible short-circuit positions. For example, if a PV string consists of 14 PV modules
and the percentage of the possible short-circuit position is 34%, the possible fault
position is 4.76 (14 x 34%), indicating that the fault is located near PV module 4,
including the previous and the next PV modules and the cables. The inverter has a
detection precision of ±1 PV module.
● The possible faulty PV string MPPT1 corresponds to PV1 and PV2, and the possible
faulty PV string MPPT2 corresponds to PV3 and PV4. The fault can be located only to
the MPPT level. Perform the following steps to connect the PV strings corresponding to
the faulty MPPT to the inverter one by one to further locate and rectify the fault.
● When a non-short-circuit fault occurs, the possible short-circuit percentage is not
displayed. If the insulation resistance is greater than 0.001 MΩ, the fault is not related
to short circuit. Check all PV modules in the faulty PV string one by one to locate and
rectify the fault.

Figure L-2 Percentage of short-circuit positions

Procedure

NOTICE

If the irradiance or the PV string voltage is too high, the insulation resistance fault
location may fail. In this case, the fault location status on the Alarm details
screen is Conditions not met. Perform the following steps to connect PV strings to
the inverter one by one to locate the fault. If the system is not configured with
any optimizer, skip the corresponding optimizer operations.

Step 1 Ensure that the AC connections are normal. Log in to the FusionSolar app, choose
Maintenance > Inverter ON/OFF on the home screen, and send a shutdown
command. Set DC SWITCH to OFF.

Step 2 Connect one PV string to the inverter, and set DC SWITCH to ON. If the inverter
status is Shutdown: Command, log in to the app, choose Maintenance >
Inverter ON/OFF on the home screen, and send a startup command.

Step 3 Choose Alarm on the home screen, enter the Active alarm screen, and check
whether a Low insulation resistance alarm is reported.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 142

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual L Locating Insulation Resistance Faults

● If no Low insulation resistance alarm is reported 1 minute after the DC side

is powered on, choose Maintenance > Inverter ON/OFF on the home screen,
and send a shutdown command. Set DC SWITCH to OFF. Go to Step 2 and
check rest of the PV strings one by one.
● If a Low insulation resistance alarm is reported 1 minute after the DC side is
powered on, check the percentage of possible short-circuit positions on the
Alarm details screen and calculate the location of the possible faulty PV
module based on the percentage. Then go to Step 4.

Step 4 Log in to the app, choose Maintenance > Inverter ON/OFF on the home screen,
and send a shutdown command. Set DC SWITCH to OFF. Check whether the
connectors or DC power cables between the optimizer and PV module, between
adjacent PV modules, or between adjacent optimizers on the possible fault
position are damaged.
● If yes, replace the damaged connectors or DC power cables, and then set DC
SWITCH to ON. If the inverter status is Shutdown: Command, choose
Maintenance > Inverter ON/OFF, and send a startup command. View alarm
information.
– If no Low insulation resistance alarm is reported 1 minute after the DC
side is powered on, troubleshoot the insulation resistance fault of the PV
string. Log in to the app, choose Maintenance > Inverter ON/OFF on the
home screen, and send a shutdown command. Set DC SWITCH to OFF.
Go to Step 2 and check rest of the PV strings one by one. Then, go to
Step 8.
– If the DC side is powered on 1 minute later, the Low insulation
resistance alarm is still reported. Log in to the app, choose Maintenance
> Inverter ON/OFF on the home screen, and send a shutdown command.
Set DC SWITCH to OFF and go to Step 5.
● If no, go to Step 5.

Step 5 Disconnect the possible faulty PV module and the paired optimizer from the PV
string, and use a DC extension cable with an MC4 connector to connect the PV
module or optimizer adjacent to the possible faulty PV module. Set DC SWITCH to
ON. If the inverter status is Shutdown: Command, choose Maintenance >
Inverter ON/OFF on the home screen, and send a startup command. View alarm
information.
● If no Low insulation resistance alarm is reported 1 minute after the DC side
is powered on, the fault occurred on the disconnected PV module and
optimizer. Choose Maintenance > Inverter ON/OFF, send a shutdown
command, and set DC SWITCH to OFF. Go to Step 7.
● If the Low insulation resistance alarm is reported 1 minute after the DC side
is powered on, the fault did not occur on the disconnected PV module and
optimizer. Go to Step 6.

Step 6 Log in to the app, choose Maintenance > Inverter ON/OFF on the home screen,
and send a shutdown command. Set DC SWITCH to OFF, reconnect the
disconnected PV module and optimizer, and repeat Step 5 to check the PV
modules and optimizers adjacent to the possible fault location.

Step 7 Determine the position of the ground insulation fault:

● Disconnect the possible faulty PV module from the optimizer.

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 143

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual L Locating Insulation Resistance Faults

● Connect the possible faulty optimizer to the PV string.

● Set DC SWITCH to ON. If the inverter status is Shutdown: Command, choose
Maintenance > Inverter ON/OFF, and send a startup command. View alarm
information.
– If no Low insulation resistance alarm is reported 1 minute after the DC
side is powered on, the fault is on the possible faulty PV module.
– If the Low insulation resistance alarm is reported 1 minute after the DC
side is powered on, the fault is on the possible faulty optimizer.
● Log in to the app, choose Maintenance > Inverter ON/OFF on the home
screen, and send a shutdown command. Set DC SWITCH to OFF, replace the
faulty component, and complete troubleshooting the insulation resistance
fault. Go to Step 2 and check rest of the PV strings one by one. Then, go to
Step 8.
Step 8 Set DC SWITCH to ON. If the inverter status is Shutdown: Command, choose
Maintenance > Inverter ON/OFF, and send a startup command.

----End

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 144

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual M Contact Information

M Contact Information

If you have any questions about this product, please contact us.

https://digitalpower.huawei.com
Path: About Us > Contact Us > Service Hotlines

To ensure faster and better services, we kindly request your assistance in providing
the following information:
● Model
● Serial number (SN)
● Software version
● Alarm ID or name
● Brief description of the fault symptom

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 145

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual M Contact Information

NOTE

EU Representative Information: Huawei Technologies Hungary Kft.

Add.: HU-1133 Budapest, Váci út 116-118., 1. Building, 6. floor.
Email: [email protected]

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 146

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual N Digital Power Customer Service

N Digital Power Customer Service

https://digitalpower.huawei.com/robotchat/

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 147

SUN2000-(20KTL, 29.9KTL, 30KTL, 36KTL, 40KTL)-
M3 Series
User Manual O Acronyms and Abbreviations

O Acronyms and Abbreviations

A
AFCI arc-fault circuit interrupter

L
LED light emitting diode

M
MBUS monitoring bus
MPP maximum power point
MPPT maximum power point tracking

P
PE protective earthing
PID potential induced degradation
PV photovoltaic

R
RCD residual current device

Issue 23 (2025-07-15) Copyright © Huawei Technologies Co., Ltd. 148
