AUTOMOTIVE TOOLS / QUALITY MADE BY GEDORE

MERCEDES BENZ EN

Copyright GEDORE Automotive GmbH, Germany 1

Mercedes

KL-0080-1 K
KL-0080-1 K

(Code 3429814)
Wiring Harness Repair Kit with Contact
Assortment
Universally suitable for standard wire/terminal connections on passenger cars,
commercial vehicles, vans, buses, construction machinery, agricultural
machinery, trailers, and semi-trailers.
Especially for wire/terminal connections with and without single conductor seal
(ELA), such as MCP-2.8, JPT, MQS, DTM/DT-twisted, SuperSeal-1.5, as well as for
conventional crimp connections such as wire lugs, flat spade wire terminals,
female flat spade wire terminals, butt connectors, etc.

UNLOCKING, STRIPPING and CRIMPING, everything ready to hand in a clearly

arranged case system, developed for fast, organised and efficient repair work in the
everyday workshop.

Defective, oxidised or provisionally repaired cable/plug connections can lead to

serious system failures on the vehicle. For this purpose, the repair kit for professionals
offers a comprehensive and robust assortment for quick and professional repair of
almost all common cable/plug connections on the vehicle. Thanks to the unique and
compact basic tool/interchangeable insert system, this can also be expanded as
required in the future. The scope of delivery already includes a generous assortment
of the most common contact and seals.

UNLOCKING: Unlocking tool with matching interchangeable inserts for damage-free

release of a wide variety of cable/plug connections from the connector housing.

STRIPPING: Stripping tool with razor-sharp interchangeable inserts for precise

stripping, especially for cables with extremely slippery PVC insulation.

CRIMPING: Crimping tool with interchangeable inserts for a perfect crimping result
as ex works, guaranteed by the special cable/plug positioners. The tool can only be
opened again when the pressure required for the crimping process has been fully
applied.

Technical Data:
Unlocking inserts: 7 pcs
Stripping inserts: 2 pairs
Crimping inserts: 11 pcs
MCP-2.8: 0.2 - 1.0mm² diameter
JPT: 0.2 - 2.5mm² diameter
MQS: 0.08 - 0.75mm² diameter
DTM/DT twisted: 0.5 - 2.1mm² diameter
SuperSeal-1.5: 0.35 - 2.5mm² diameter
Pinch connections: 0.35 - 6mm² diameter / AWG 10 - 22
Stripping: 0.03 to 16 mm² diameter
Menge pro Kontakt: 25 pcs

Scope of Delivery
Part No. Description Qty
KL-0080-10 K Wiring harness repair kit 1
KL-0080-104 K Contactor assortment in the case 1
KL-0080-1090-5 GEDORE i-BOXX Rack 1

2 Copyright GEDORE Automotive GmbH, Germany

KL-0080-11 K
KL-0080-11 K

(Code 3424634)
Repair kit for FAKRA plug connection
Universal fit for cars, commercial vehicles, and vans with FAKRA cable/plug
connections (RTK031 and RG174). Installed, for example, on GSM mobile radio
antennas, GPS antennas, and in rear-view camera systems.

For stripping, crimping, and repairing FAKRA cable/plug connections. Time-

consuming replacement of the entire FAKRA coaxial cable, usually across the vehicle,
is not required!
Defective, oxidised, or provisionally repaired FAKRA cable/plug connections can lead
to system failures on GSM mobile radios, GPS systems, and rear view camera systems.

Technical Data:
Cable diameter (RTK031): 3.2mm
Cable diameter (RG174): 2.8mm

Scope of Delivery
Part No. Description Qty
KL-0080-111 Fakra RTK031-Tool kit 1
KL-0080-112 Fakra RG174-Tool kit 1
KL-0080-1011 Crimping pliers handle 1
KL-0080-1130 Cable testing gauge 1
KL-0080-1190 Case with inserts 1

1100-1094
1100-1094

(Code 2979063)
VDE Tool assortment HYBRID,
in GEDORE L-BOXX® 136
• The perfect range of tools for repair and maintenance work on hybrid and electric
vehicles
• For vehicles of all the manufacturers
• All tools insulated on the basis of EN 60900/EC 60900
• GEDORE L-BOXX® 136 compatible with the Sortimo® vehicle interior fittings in your
service mobile

Contents:
• 3/8" VDE Socket No. VDE 30, SW 6 8 9 10 11 12 13 14 15 16 17 18 19 20 22mm
• 3/8" VDE Screwdriver bit socket No. VDE INX 30, AF 8 10 12mm
• 3/8" VDE Extension No. VDE 3090 -3 -6, 75 150mm
• 3/8" VDE Reversible ratchet No. VDE 3093 U
• VDE Screwdriver slotted No. VDE 2170, 2.5 3.5 4 5.5mm
• VDE Screwdriver cross-slotted No. VDE 2160 PH 1 2 3
• VDE Screwdriver TX No. VDE 2163 TX T20 T25 T30
• VDE Cable shears No. VDE 8094, 200mm
• VDE Universal pliers No. VDE 146 10, 10"
• VDE Power combination pliers No. VDE 8250-200 H, 200mm, 2C handle
• VDE Power side cutter No. VDE 8314-180 H, 180mm
• VDE Bent nose pliers No. VDE 8132 AB-200 JC, 200mm angled 2C handle
• VDE Flat nose pliers No. VDE 8120-160 H, 160mm, 2C handle
• VDE Cable knife No. VDE 4522, 180mm
• Meter connection fitting No. V 914, Size 1 2 3

Technical Data:
Width: 444mm
Depth: 357mm
Height: 152mm
Weight: 8.3kg

Copyright GEDORE Automotive GmbH, Germany 3

Mercedes

KL-4600-100 K
KL-4600-100 K

(Code 3413659)
VDE Supplementary Kit
Fits universally for hybrid and electric vehicles.

The unique VDE supplementary kit offers the possibility to secure hybrid and electric
vehicles ideally for working on them.
Perfect addition to the GEDORE VDE tool range - 1100-1094.

Contents:
1x V 912 10 - Electrician’s protective gloves incl. undergloves,
1x VDE 910 25 - Rubber cloth cover 250 x 350,
1x V 911 100 - ISO Insulation mat,
1x KL-4600-1001 - Barrier tape,
1x KL-4600-1002 - Warning sign "Flash",
1x KL-4600-1003 - Voltage tester 1.000 V,
1x KL-4600-1005 - Safety padlock,
1x KL-4600-1006 - Warning sigh High voltage "Switched on",
1x KL-4600-1007 - Warning sigh High voltage "Switched off"
+ GEDORE L-BOXX®

KL-4600-3002
K L-4600-3002

(Code 3433129)

Assembly Tweezers Bent, Insulated,

Technical Data: 150mm
Length: 150mm
Insulation: RED dip insulated Universally used for hybrid and electric vehicles.
Standard: IEC 60900 For safe working on the vehicle. Provide protection when accidentally touching live
Approval: 1000 V (double triangle) parts.
Unit-tested: 10-way safety

KL-4600-3003
K L-4600-3003

(Code 3433137)

Assembly Tweezers Straight, Insulated,

Technical Data: 145mm
Length: 145mm
Universally used for hybrid and electric vehicles.Provides protection when
Insulation: RED dip insulated
accidentally touching live parts.
Standard: IEC 60900
Approval: 1000 V (double triangle) For safe working on the vehicle. Provides protection when accidentally touching live
Unit-tested: 10-way safety parts.

KL-4600-3004
K L-4600-3004

(Code 3433145)

Technical Data:
Self-Clamping Cap Ø 20mm,Insulated,
Diameter: 20mm Length of 85mm
Length: 85mm
Insulation: RED dip insulated
Universally used for hybrid and electric vehicles. Provides protection against
Standard: IEC 60900
accidental touches.
Approval: 1000 V (double triangle) For easy putting on and securing of live cable ends.
Unit-tested: 10-way safety

4 Copyright GEDORE Automotive GmbH, Germany

KL-4600-200
K L-4600-200

(Code 3415740)
Tool Trolley High-Voltage Assortment
with 103-Piece
Fits universally for hybrid and electric vehicles.

With its unique kit assembly, the high-voltage tool trolley offers the possibility to
secure hybrid and electric vehicles ideally and to work on them. Perfect for repair and
maintenance work on vehicles of all manufacturers.
All tools are insulated with protection according to EN 60900/EC 60900. The tool
trolley has side panels with Euro perforations, a heavy-duty chassis with external
bearings, ball-bearing guide rails, and central locking.
Inklusive: digitalem Spannungsprüfer, 3/8" VDE-Drehmomentschlüssel,
Sicherungsschloss, Steckschlüssel und Knarre in 3/8" und 1/2", uvm.

Content:
• 3/8" VDE-tool assortment with SW 6 - 22; XZN M8 - M12
• 3/8" VDE torque spanner 5 - 25 Nm
• 1/2" VDE workshop assortment with SW 10 - 24; IN 5 - 8 mm;
• VDE single open-end spanner SW 9 - 24
• VDE single end ring spanner SW 8 - 22
• VDE slotted and cross-head screwdriver; TX T8 - T30
• VDE cable shear
• VDE universal pliers
• VDE power combination pliers
• VDE power diagonal cutter
• VDE flat nose-round pliers, angled
• VDE flat pliers
• VDE cable stripping knife
• Meter connection fittings
• Digital voltage tester 1.000 V
• Electrician's protective gloves
• Undergloves
• Rubberised cloth cover 250 x 350 mm
• ISO insulation mat
• Barrier tape
• Warning sign "Flash"
• Warning sign high voltage "Switched ON", Warning sign "Switched OFF"
• Safety padlock
• Plastic clamp 80 mm; 160 mm
• Cable splitting wedge
• Rubber hammer

Technical Data:
Design
Height
Width
Depth
Number of drawers
Load capacity (mobile)
Load capacity (static)
Load capacity (per drawer)

Copyright GEDORE Automotive GmbH, Germany 5

Mercedes

KL-0104-21 KB
KL-0104-21 KB

(Code 3269396) (Pat.)

Spreader Tool Kit (adjustable),
with Wedge No.1 + 2 + 4 + 5
Applicable to strut clamping bores as found in: Audi A3 (8P, 8V), Audi TT (8S);
VW Arteon (3H), Golf IV (1J), Golf V (1K), Golf VI (1K), Golf VII (AU), Passat (3C,
362, 365), T5 (7H, 7J), T6 (7H, 7J); BMW 2 Series (F45); Citroën; Fiat Panda (312);
Ford Tourneo Connect, Galaxy (CK); Kia Sportage; Mercedes GLA (X156), Vito, V-
Class; Nissan Qashqai (J10, 2006-2013); Seat; Škoda Kodiq; Renault Clio (IV),
Kadjar (2015-2018), Megane (IV); Peugeot; Jeep; Volvo V70; Japanese vehicles etc.

Also suitable for spreading the slot (clamp) in the front wheel bearing housing
(steering knuckle) to allow for proper removal of the lower ball joint from the
following vehicles: Audi A4 (8K), A5 (8T, 8F), A6 (4G), A7 (4G), A8 (4H), Q5 (8R) etc.

Alternative tools: VAG 3424; VAG T20040; BMW 312230

The spreader tool kit is designed to professionally expand the strut clamping bore in
steering knuckles. It can also be used to spread the slot (clamp) on the front wheel
bearing housing (steering knuckle) to allow for the damage-free removal of the lower
ball joint. This procedure is an absolute must to ensure the proper removal of tight-
fitting or stuck spring/shock absorber units and lower suspension ball joints
respectively.
Special features of the tool are the floating bolts that prevent the tool from jamming
and the special spreader wedge which is provided with a limit stop to avoid excessive
knuckle widening.
Prevents expensive damage to the cast iron or aluminium steering knuckle or other
chassis components that may be caused by unprofessional removal/installation
attempts. Thanks to its variably adjustable spreader tip, this tool is also ideal for use
on vehicles with steering knuckles having a non-centralised slot! An indispensable
tool when changing springs, shock absorber units as well as suspension ball joints.
Technical Data:
Spreader wedge No.1: a: 5.5mm; b: 12mm
Spreader wedge No.2: a: 2.0mm; b: 8.0mm
Spreader wedge No.4: a: 5.5mm; b: 9.5mm
Spreader wedge No.5: a: 12.5mm; b: 17mm

Scope of Delivery:
Part No. Description Qty
KL-0104-21-1 B Spreader Tool (adjustable), with Wedge No.1 + 2 1
KL-0104-2124 Pressure Screw, with Wedge No.4 1
KL-0104-2125 Pressure Screw, with Wedge No.5 1
KL-0104-2141 Bolt with M10 Thread 1
KL-0104-2190 Plastic Storage Case with Insert 1

KL-0145-120 A
KL-0145-120 A

(Code 3041247)
Support Device
Universally fitting for wheel hubs with a hole circle diameter of 5x130 mm,
5x120 mm, 5x112 mm, 5x100 mm and many others.
A loose or sagging wheel suspension can damage the brake hose, the vehicle level
sensor, cable connections, and the drive shaft.
The engine transverse strut, in combination with a gearbox lifting jack, enables the
wheel suspension to be properly supported and fixed; for example, when removing
and installing the suspension strut or replacing the axle suspension arms. The
support is provided by the wheel hub and thus ensures a reliable hold in the
respective position. Due to its special design, the engine transverse strut is adjustable
inthe camber angle. This allows the wheel suspension to be lowered and raised
precisely at different angles.
Recommended accessory:
KL-0040-2571 Adaptor Sleeve, Ø 25mm
KL-0040-2588 - Adapter reception sleeve for VW, Ø 35mm
Technical Data:
Retaining Ø: 30mm
Overall height: 205mm
Inclination angle: +/- 45°
Max. load capacity: 300kg

6 Copyright GEDORE Automotive GmbH, Germany

KL-5501 B
KL-5501 B

(Code 3230503) (Pat.)

Spring Compressor, Stationary
Universally applicable to virtually all MacPherson suspension strut and shock
absorber designs with coil springs, such as right-hand-coiled springs, left-hand-
coiled springs, eccentric springs/spring plates, conical springs, springs with a
small number of windings, long-pitch springs or variable-pitch springs.
Also suitable for use on shock absorber designs with rebound buffer springs,
shock absorbers on which the hardness is electronically adjustable as well as
magnetorheological shock absorbers.
Alternative tool: VAS 6908/1

The stationary spring compressor is the ultimate solution when it comes to compressing
the MacPherson-type struts/shock absorbers that are commonly used in today’s vehicle
suspension systems. Special features, such as the variable spring plate-clamping device,
the adjustable support column assembly, and the strut-holding device with one-hand
operation, make the KL-5501 B a very versatile spring compressor that satisfies the
highest Health and Safety Standards. Thanks to a special technique, the spring is
compressed via the upper spring plate against the lower spring plate, hence spring
shape and spring pitch are no longer an issue. Comes with a mounting plate that
allows the spring compressor to be easily fixed to an appropriate workshop trolley or
workbench.
Recommended Accessory: KL-5501-40 - Hand Crank, size (waf) 24 mm
1993 U-20 - Reversible Ratchet 1/2", KL-0056-11 E - Shock Absorber Piston Rod Tool Set
Advantages:
Universal application!
Thanks to the wide range of adjustment possibilities, the spring compressor is applicable
to virtually any MacPherson suspension strut and shock absorber design commonly used
in today’s vehicle suspension systems.
Maximum safety!
The sophisticated and solid overall design of the stationary spring compressor as well as
its simple and user-friendly operation provide a maximum level of safety.
Applicable to many different spring designs!
With this spring compressor, the design of the spring - no matter whether it is about
right-hand-coiled springs, left-hand-coiled springs, conical springs, eccentric springs,
springs with a small number of windings, long-pitch springs or variable-pitch springs - is
no longer an issue. This is thanks to the special compression technique which allows the
spring to be compressed via the upper spring plate against the lower spring plate.
Applicable to shock absorbers with rebound buffer spring!
Thanks to the large opening width of 570mm and a compression force of up to max. 15
000N, even shock absorbers with rebound buffer springs that require a high pre-load on
the spring are not an issue.
No damage to the strut/shock tube!
The clamping bars of the strut-holding device can properly and quickly be aligned and
adjusted to the respective strut tube diameter by means of a knurled nut. Plastic
clamping jaws prevent damage to the strut tube.
Allows for one-person operation!
Thanks to the strut-holding device with quick-action clamping and one-hand-operation
mechanism, the entire process can be carried out by just one person.
Technical Data:
Mobile use - in conjunction with a workshop trolley/workbench!
Drive: 24mm waf
The stationary spring compressor comes with a mounting plate that enables it to be fixed to
Breaking point: 60 000N
an appropriate workshop trolley/workbench. To attach the spring compressor to the
Max. load capacity: 15 000N
MODULO KL-4999-120 A, KL-4999-121 A workshop trolley/workbench or to a vertical
wall, the special MODULO mounting kit KL-5501-211 is needed. This allows the user to Weight without trolley: 46kg
carry out repairs more quickly, more efficiently and more flexibly, also next to the vehicle. Max. span (opening width): 570mm
For spring plate Ø: 125 - 220mm

KL-5501-1435 A
K L-5501-1435 A

(Code 3406199)
Adapter for Shock Absorber with Fork
Mount
Fits struts with fork mount. For example, installed on Mercedes M-Class (W164,
W166), R-Class (W251); Audi Q7 (4LB); VW Touareg (7L, 7P); Porsche Cayenne
(9PA, 92A), Panamera (970); etc.
The adapter KL-5501-1435 A enables the safe reception of suspension struts with Technical Data:
fork mounting on the lower support on the stationary spring compressor KL-5501 /
Adaptor Ø: 57mm
KL-5501 B. The adapter is mounted on the spring-compressing device instead of the
LengthThickness 20mm
plastic support KL-5501-1431.

Copyright GEDORE Automotive GmbH, Germany 7

Mercedes

KL-5501-212
KL-5501-212

(Code 3402169)
Wall Bracket, long
Suitable for KL-5501 B (NOT for KL-5501).
The long wall bracket enables stable mounting of the stationary spring compressor -
KL-5501 B on a vertical wall. Here, the using the hand ratchet as well as the hand
crank - KL-5501-40 is possible without problems.

Recommended Accessories:
KL-5501-40 Hand crank
Technical Data:
Distance to the wall: 245mm (middle drive)
Weight: 3.5kg

KL-5501-40
KL-5501-40

(Code 3402444)
Hand Crank, size (waf) 24mm
The hand crank enables an amazingly simple and fast drive of the stationary spring
compressor - KL-5501 or KL-5501 B when tensioning and releasing a McPherson
strut. For this purpose, the crank handle is simply attached to the spring compressor
via the 24 mm drive hexagon.
Technical Data:
Drive: Hexagonal / 24mm
Length: 195mm

KL-0056-11 E
KL-0056-11 E

(Code 3401472)
Shock Absorber Piston Rod Tool Kit,
in Foam Insert
Fits universally for MacPherson struts on passenger cars.
For quick loosening and tightening of the piston rod nut on MacPherson struts.
Required, for example, when replacing the shock absorber or the suspension spring.
The special holders and the large number of interchangeable screwdriver bits and
sockets also allow the shock absorber piston rod to be properly held in place through
the open sockets. The ring ratchet wrench included in the kit facilitates and speeds
up this work.
Recommended Accessories: 1993 U-20 SK - Reversible ratchet
Tool Storage System: KL-4990-9372 - Plastic Storage Case

Scope of Delivery
Part No. Description Qty
KL-0056-1116 Socket, open, size (waf) 16mm 1
KL-0056-1117 Socket, open, size (waf) 17mm 1
KL-0056-1118 Socket, open, size (waf) 18mm 1
KL-0056-1119 Socket, open, size (waf) 19mm 1
KL-0056-1121 Socket, open, size (waf) 21mm 1
KL-0056-1131 Holder for screwdriver bits 5/16" 1
KL-0056-1132 Holder for sockets 1/4" 1
KL-0056-1141 Screwdriver bit, size (waf) 5mm 1
KL-0056-1142 Screwdriver bit, size (waf) 6mm 1
KL-0056-1143 Screwdriver bit, size (waf) 7mm 1
Technical Data: KL-0056-1144 Screwdriver bit T50 1
Sockets: Size (waf) 16/17/18/19/21mm KL-0056-1145 Screwdriver bit XZN12 1
Screwdriver bits: Size (waf)5/6/7mm/T50/XZN12 KL-0056-1151 Socket, 2- flat, 6mm 1
Pluggable insert, double flat: Size (waf) 6/7/8mm KL-0056-1152 Socket, 2- flat, 7mm 1
Socket drive: Size (waf)19mm KL-0056-1153 Socket, 2- flat, 8mm 1
Holder drive: Size (waf) 10mm 7 R 19 Open-ended spanner with ring ratchet, 19mm 1
Holder for screwdriver bits: 5/16" 7 XL 10 Combination spanner, 10mm 1
Holder for pluggable inserts: 1/4" KL-0056-1190-1 Foam insert 1

8 Copyright GEDORE Automotive GmbH, Germany

KL-0033-10 E
KL-0033-10 E

(Code 3276317) (Pat.)

Compact Internal Coil Spring
Compressor, Size 2A, in a Foam Insert
Universally applicable to wishbone and independent, multi-link suspension
systems as found in vehicles from VW-Audi, Seat, Porsche, Mercedes, BMW,
Ford and in many more.

The internal coil spring compressor allows you to quickly and safely remove and
install coil springs on wishbone and independent, multi-link suspensions in situ on
the vehicle.
Thanks to the particularly compact design, the compressor base body can be easily
inserted into the spring from below, through the wishbone - even with VAG vehicles
having a very small lower wishbone access hole (of approx. 34mm Ø).
As a result, the loosening of axle components and follow-up wheel alignments are no
longer necessary.
Sturdy and robust design ensures a high level of operational safety.
The unique 3-point safety interlock mechanism and the special anti-rotation profile
prevent the pressure plates from twisting during the compression process and, thus,
the coil spring from coming loose and falling off the spring compressor.
Simple and safe mounting of the spring compressor - no need for additional locking,
awkward or cumbersome installation work is avoided!
Another special feature of the pressure plates are the anti-slip protective inserts
which prevent the spring from unwinding itself out of the spring compressor and also
avoid damage to the sensitive coating of the spring.

Advantages:
• Particularly compact design.
• Universally applicable to coil springs on wishbone and independent, multi-link
suspension systems.
• THE ideal tool for VAG vehicles having a very small access hole in the wishbone.
• Eliminates the need for loosening axle components and follow-up wheel
alignments.
• Substantial time savings.
• High level of safety when compressing the spring - thanks to the unique 3-point
safety interlock mechanism.
• No additional locking necessary - thanks to the safe and simple lock mechanism!
• No risk of the pressure plates twisting - thanks to the special anti-rotation profile.
• No risk of damaging the sensitive spring surface finish - thanks to the anti-slip
protective inserts.
• No risk of the spring unwinding itself out of the spring compressor - thanks to the
anti-slip protective inserts.

Recommended Accessory:
KL-0033-300 E Holding-Down Tool Kit, in a Foam Insert

Tool Storage System:

KL-4990-9372 - Plastic Storage Case

Technical Data:
Max. load capacity: 30,000N
Breaking point: 120,000N
Working travel: 100mm
Opening width: 116 - 216mm
Overall length: 178 - 278mm
Drive: 19mm external hex + 8mm internal hex
Weight: 3.5kg
*NO* *NO*
*NO* *NO*

Scope of Delivery:
KL-0033-10 E Compact Internal Coil Spring Compressor, Size 2A, in a Foam Insert
Part No. Description Qty
KL-0033-100 A Compressor Base Body 1
KL-0033-1101 Pressure Plate with Lock 1
KL-0033-1102 Presssure Plate with Anti-Rotation Profile 1
IN 19 LK 8-140 Screwdriver bit socket 1
KL-0033-1090-1 Foam Insert 1

Copyright GEDORE Automotive GmbH, Germany 9

Mercedes

KL-0033-16
KL-0033-16

(Code 3279642)
Pair of Pressure Plates, Size 0A
Universal application. Particularly suitable for use on Mercedes-Benz E-Class
(W211, W212), C-Class (W204, on the rear axle), GLA (X156), GLK (X204); Ford
Focus III (MK3); BMW 1 Series (E81); VW Passat (B8/3G).
The pair of pressure plates, in conjunction with the necessary accessories, allows you
to quickly and safely remove and install coil springs on wishbone and independent,
multi-link suspensions in situ on the vehicle.The unique 3-point safety interlock
mechanism and the special anti-rotation profile prevent the pressure plates from
twisting during the compression process and, thus, the coil spring from coming loose
and falling off the spring compressor.

Necessary Accessories (included in KL-0033-10 E):

KL-0033-100 Compact Compressor Base Body, IN19LK8-140 Bit Socket, 8mm waf
Technical Data:
For spring Ø from: 80mm (inside))
For spring Ø up to: 110mm (outside)
Gradient of pressure plate to 240°: 6mm
*NO* *NO*

Scope of Delivery:
Part No. Description Qty
KL-0033-1601 Pressure Plate, Size 0A, with interlock mechanism 1
KL-0033-1602 Pressure Plate, Size 0A, with anti-rotation profile 1

KL-0033-300 E
KL-0033-300 E

(Code 3275205)
Holding-Down Tool Kit, in a Foam Insert
Universally applicable to wishbone and independent, multi-link suspension
systems as found in vehicles from VW-Audi, Seat, Porsche, Mercedes, BMW,
Ford and in many more. Essential tool for use on the rear axle of VW-Audi,
Porsche and Mercedes-Benz vehicles.
For example: Audi A4 (8K), A5 (8T), A6 (C6), Q5 (8R), Q7 (4M); Seat Exeo (3R); VW
Touareg; Porsche Cayenne (PO536), Macan; Mercedes-Benz E-Klasse (W211,
W212), C-Klasse (W204), GLA (X156), GLK (X204); etc.
The holding-down tool kit is intended to ease the removal and installation of coil
springs on wishbone and independent, multi-link suspensions. Particularly
recommended for use with our KL-0033-10 E Compact Internal Coil Spring
Compressor.

Insert the holding-down tool between the upper control arm and the vehicle body.
Then, pre-tighten it slightly. The tool is designed to keep the suspension in position
while the coil spring is being compressed. This reduces the compression travel and
greatly facilitates the removal of the spring.

Tool Storage System:

KL-4990-9224 Plastic Storage Case
Technical Data:
Drive: 22mm waf
Diameter of support: Ø 40/50mm
E With holdingdown clamp Clamping range (short adjusting nut): 80 - 113mm
Clamping range (long adjusting nut): 105 - 138mm

Scope of Delivery:
Part No. Description Qty
KL-0033-3001 Support Bracket 1
KL-0033-3002 Support, Ø 50mm 1
KL-0033-3003 A Support, Ø 40mm 1
KL-0033-3004 Adjusting Nut, short 1
KL-0033-3005 Adjusting Nut, long 1
KL-0033-3090-1 Foam Insert 1

E Without holdingdown clamp

10 Copyright GEDORE Automotive GmbH, Germany

KL-0025-20 E
KL-0025-20 E

(Code 3402495) (Pat.)

Spring Compressor (Short Design) with
Pressure Plates Size 1+2, in a Foam Insert
Suitable for Chrysler, Mercedes C-Class (W202), CLK (W208), E-Class (W210,
W211), S-Class (W140), SL (R107, R129, R170), W114, W115, W116, W123, W124,
W126 and W201 rear axle springs. Also applicable to BMW 1 Series (E87) and 3
Series (E90) if used with the pair of pressure plates KL-0025-16.
Alternative tool: 99415V, W 140 589 00 31 00, W 202 589 02 31 00

Allows the removal of rear axle springs in very confined spaces without having to
lower the rear sub-frame.
• Automatic 3-point safety interlock mechanism
• Automatic freewheel at end of stroke
• Anti-rotation profile
• Spindle overload protection

Tool Storage System:

KL-4990-9374 - Plastic Storage Case
Technical Data
Max. load capacity: 30,000N
Span width (Jaw opening): 110-287mm
Working travel: 177mm
Overall length: 233mm
Drive: Size (waf) 19mm hex
Breaking point: 120,000N

Scope of Delivery:
Part no. Description Qty
KL-0025-200 Compressor Base Body 1
KL-0025-11 Pair of Pressure Plates, Size 1 1
KL-0025-12 Pair of Pressure Plates, Size 2 1
KL-0025-2091-2 Foam Insert 1

KL-0169-1 B
KL-0169-1 B

(Code 3283674)
Track Rod Adjustment Tool
Universally suitable for track rods with tube Ø of approx. 11 to 23mm as found
in passenger cars.
Designed to facilitate the loosening and adjustment of stiff track rods with tube Ø of
approx. 11 to 23mm as found in passenger cars.
Thanks to the detachable tube handle, the tool length can be reduced from 420 to
250mm. This allows for convenient working even in confined space conditions in the
wheel arch. The broad serrated jaws are designed to prevent damage to the track rod.

Technical Data:
For track rod tube Ø: approx. 11-23mm
Overall length: 420mm
Length without tube handle: 250mm

Scope of Delivery:
Part No. Description Qty
KL-0169-100 Adjustment Tool 1
KL-0169-101 Tube Handle 1
KL-0169-1001 Adaptor 1

Copyright GEDORE Automotive GmbH, Germany 11

Mercedes

KL-0167-30 A
KL-0167-30

(3427900) (DE-GM)
Excentric Spanner to Remove / Install
the Inner Track Rod Joint
Universally suitable for cars and vans, e.g. Audi, BMW, Citroen, Dacia, Ford,
Hyundai, Kia, Mazda, Mercedes, Mini, Nissan, Opel/Vauxhall, Peugeot, Porsche,
Renault, Seat, Skoda, Toyota, Volvo, VW and many more.
For a quick removal and installation of internal track rod joint or axial joints with a
diameter of 30 to 43 mm, directly on the vehicle without removing the steering gear.

The unique open design makes it easy to fit the spanner directly onto the track rod
without first having to dismantle the outer, usually seized part of the track rod. Due
to the special eccentric, the outer profile on the track rod or axial joint (e.g. 2-sided, 4-
sided, 6-sided or round) is irrelevant. The robust profile of the eccentric spanner
reliably prevents the tool from slipping. The track rod eccentric spanner is driven by
a 1/2” square socket.

Technical Data:
Drive: 1/2“
For Ø: 30 ... 43mm

KL-0121-96 B
KL-0121-96 B

(Code 3410129)
Clamping Pliers for Steering and Axle
+ Boots
Universal fit for VW-Audi , Seat, Skoda, BMW, Citroën, Mazda, Honda, Nissan,
Ford, Opel and many more.

Alternative tools: VAG1682, VAG1682A, BMW 315200, Opel MKM-804

The clamping pliers permit proper compression of lug clamps as required by the
tightening torque, as well as damage-free sealing of continuous anchor clamps.
Required, for example, for axle boots, steering boots, coolant hoses, fuel lines, etc.

The design of the clamping pliers makes it easy to change the pliers jaws required for
the respective application. Depending on the space available on the vehicle, these
jaws can be mounted on the pliers either from the FRONT or from the SIDE.

Recommended accessories:
4549-05 - Torque spanner (10-50Nm)

Technical Data: Scope of delivery

Length: 260mm Part No. Description Qty
Weight: 490g KL-0121-9600 B Hose clamp pliers Hose clamp pliers 1
Drive: 3/8" KL-0121-9611-1 Hook (pliers jaw) 2

KL-0049-300
KL-0049-300

(Code 2379228)

Slide Hammer Puller Base Tool, 4.8kg

The ideal tool for extracting stuck or tight-fitting components such as half shafts,
universally jointed drive shafts, injector nozzles etc. It is used in conjunction with the
respective adaptors and puller bolts.

Recommended Accessory:
KL-0049-3020 Hook
Technical Data:
Hammer weight: 4.8kg
Length: 680mm
Connection thread: M18

12 Copyright GEDORE Automotive GmbH, Germany

KL-0049-360 A
KL-0049-360 A

(Code 3411001)
Hook for Impact Extractor
Particularly suitable for quickly pulling the wishbone axle with support joint out of
the clamping hole on the steering knuckle. The profiled shape of the hook allows it to
be placed very closely to the support joint.

Required drive parts:

KL-0049-31 / KL-0049-300 - Impact extractor 4.8kg

Technical Data:
Dimensions a: 95mm
Dimensions b: 100mm
Dimensions c: 25mm

KL-0326-170
KL-0326-170

(Code 3427633)
Suspension Joint Release Tool Kit
Suitable for suspension joint bolts on multi-link axles, for example, Mercedes
C-Class (W205), E-Class (W213), EQC (N293), GLC (X253), and many others.
For professional loosening and tightening with simultaneous counter-holding of the
suspension joint screw connections on the upper and lower axle control arms. By
inserting the special inlay ring (24mm (waf)) into the socket spanner (32mm (waf)) as
well as the interchangeable screwdriver bits (T45 + T50), the release tool kit can be
individually adapted to the suspension joint screw connections. Required, for
example, when replacing axle control arms, suspension springs, or shock absorbers.

Scope of Delivery
Part No. Description Qty Technical Data:
KL-0326-1701 Socket spanner 32mm (waf) 1 Suspension joint nut: SW24 + SW32
KL-0326-1702 Inlay ring 32mm to 24mm (waf) 1 Profile for suspension joint nut: Double hexagon
KL-0056-1131 Holder for screwdriver bit 1 Suspension joint: T45 + T50
887 TX T50 Screwdriver bit T50 1 Profile for suspension joint: Female Torx
887 TX T45 Screwdriver bit T45 1 Drive: SW19 + SW13
KL-4990-2002 Plastic box 1

KL-0356-141
KL-0356-141

(Code 3268071)
Sleeve Kit (W204)
Applicable to the front and rear silentblocs at the rear axle carrier as found in:
Mercedes C-Class (W204, S204, C204 [up to vehicle identification number
A116835], X204), E-Class (W212, S212) + (C207), CLS (W218), SL (R231 [front
silentbloc only]).
Alternative tools: W 204 589 00 43 00, W 205 589 00 43 00

The sleeve kit allows for the quick removal and installation of the front and rear Technical Data:
silentblocs from/to the rear axle carrier in situ on the vehicle.Thanks to this tool, the Max. load capacity: 7t
rear axle carrier only needs to be lowered slightly, thus eliminating the need for the
time-consuming dismantling of the rear axle carrier.
Required drive parts:
Hydraulic drive: KL-0215-35 M25 Hydraulic Pump, KL-0040-2500 Hydraulic
Cylinder (17t), KL-0039-1912-1 Pull Spindle (M12), KL-0039-2112-2 Quick-Action
Clamping Nut (M12), KL-0039-1003 Retaining Adaptor, for Hydraulic Cylinder
Mechanical drive: KL-0039-2012-1 Pull Spindle (M12), KL-0039-1912-2 Shoulder
Nut (M12), KL-0039-2112-2 Quick-Action Clamping Nut (M12), KL-0039-1011
Retaining Adaptor

Scope of Delivery:
Part No. Description Qty
KL-0356-1411 Thrust Piece, Ø 99mm 1
KL-0356-1412 Thrust Piece, Ø 87mm 1
KL-0356-1413 Press/Support Sleeve, Ø 105mm/Ø 85mm 1
KL-0356-1414 Thrust Piece, Ø 80mm 1
KL-0356-1415 Counter-Holder, 93mm 1
KL-0039-1674 Press/Support Sleeve, short, Ø 74mm/Ø 66mm 1

Copyright GEDORE Automotive GmbH, Germany 13

Mercedes

KL-0356-142
KL-0356-142

(Code 3274209)
Upgrade Kit, Rear Axle Carrier (W204)
Applicable to the lower spring link silentblocs at the rear axle carrier as found in:
Mercedes C-Class (W204, S204, C204, X204), E-Class (W212, S212) + (C207), CLS
(W218), SL (R231).
Alternative Tools: W 204 589 04 43 00, W 220 589 01 43 00

Used in conjunction with the KL-0326-1000 press frame and the necessary drive parts,
the upgrade kit allows for the quick removal and installation of the lower spring link
silentbloc from/to the rear axle carrier in situ on the vehicle. Thanks to this tool, the
time-consuming dismantling of the rear axle carrier is not necessary.
When dismantling the spring link, it occurs quite often that the fixing bolt breaks off
inside the silentbloc. As a result, the removal by means of a pull spindle is no longer
feasible. The use of our special KL-0326-1000 press frame in conjunction with the
appropriate pressure spindle dispenses with the need for a pull spindle when
Scope of Delivery: removing the silentbloc.
Part No. Description Qty Note: Alternatively, the removal of the spring link silentbloc can also be carried out
KL-0356-1421 Press Sleeve, removal, Ø 50/42mm 1 without the use of the KL-0326-1000 press frame and KL-0039-1930 Pressure
KL-0039-1672 Press Sleeve, installation, Ø 72/64mm 1 Spindle. In this case, however, the silentbloc must feature a clearance hole and the
KL-0326-1111 Adaptor Ring 1, with O-Ring 1 KL-0039-1772 support sleeve (accessory) will be needed in addition.
For required drive parts, see KL-0356-141.

KL-0414-2
KL-0414-2

(Code 3421171)
Drive Shafts Disassembly Lever
Universally suitable for passenger cars and vans with plugged-in drive shafts on
the gearbox. Installed e.g. in Alfa Romeo, BMW, Citroen, Dacia, Ford, Fiat,
Hyundai, Kia, Mazda, Mercedes, Mini, Nissan, Opel, Peugeot, Renault, Toyota,
Volvo and many more.

Alternative tools: BMW 315110, Opel DT-51329-A, Ford 204-226

For quick and easy pressing out of plugged-in drive shafts on the gearbox. The
articulated foot on the disassembly lever which can be adjusted in length, position
and angle, enables an optimal and damage-free support by the gearbox.

Technical Data:
Length: 610mm
Blade width: 40mm
Weight: 1.5kg

KL-0140-2 A
KL-0140-2 A

(Code 3251632)
Friction Gauge, 0.3 - 6Nm
Applicable to passenger cars and HGVs. For example from: Mercedes and VW.
Alternative tools: W 001 589 49 21 00, VAS 6523

The friction gauge allows you to accurately determine the friction torque in the range
of 0.3 - 6Nm on differentials, manual or automatic transmissions and steering gears.
Required to check and adjust the bearing preload when removing/installing the
propshaft flange, after changing the shaft seal or when performing transmission
repairs.
Input takes place via the13mm hexagon, output via the 1/2" square.
Recommended accessory:
1993 U-20 Reversible Ratchet 1/2"
Technical Data:
Measuring range: 0.3 - 6 Nm
Input: 13mm waf
Output: 1/2"
Diameter: 64mm
Height: 66mm

14 Copyright GEDORE Automotive GmbH, Germany

 (Code 3413349)
KL-4999-250

KL-4999-250
Modular Workstation „MODULO 250“
Universally applicable for repairs on wheel bearings, steering and axle systems
on passenger cars and vans.
The robust assembly trolley "MODULO 250" in its unique composition offers the ideal
mobile workstation for the fast, organised and efficient replacement of wheel
bearings, silent bearings, support joints, bushings, etc.

Included in the modulo:

• Various drive parts such as hydraulic cylinder 17t KL-0040-2500, ring ratchet/
open-end spanners, impact extractors 4.8 kg - KL-0049-31 as well as pull/thrust
spindles (mechanical, hydraulic), quick-clamping nuts and adapters of the
KL-0039-..Series for driving the tool kits.
• Articulated handle - KL-4007-411 as well as power spanner/socket spanner sockets
(SK / TX / XZN) for loosening and tightening of wheel bearing central screws.
• Locking ring pliers - KL-0192-5 for the disassembly and assembly of wheel bearing
locking rings.
• Wire brush for derusting and cleaning various components.
• Wheel hub puller - KL-0041-38.. as well as wheel bearing tool kits of the
KL-0041-4.. Series for pressing out and in of wheel hubs and wheel bearing units,
for example on VW, Audi, Seat, Škoda.
• Pullers of the KL-0174-.. Series for pulling standard wheel bearings as well as
pressing out bonded and stuck cardan shafts.
• Hook for impact extractors - KL-0049-360 A for pulling of wishbones from the
suspension joint clamping hole.
Techniscal Data Assembly Trolley: See KL-4999-270 MODULO Assembly Trolley
Required Drive Parts: KL-0215-35 M25 - Hydraulic-Pump
Technical Data: See KL-4999-270 MODULO Assembly Trolley

KL-4999-260
KL-4999-260

(Code 3423468)
Modular Workstation "MODULO 260"
Universally applicable for repairs on wheel bearings, steering and axle systems
on passenger cars and vans.

The assembly trolley "MODULO 260" with its unique composition is the ideal, mobile
workstation for fast, organised, and efficient repairs.

Contents / Scope of application same as KL-4999-250 plus additionally:

• Wheel bearing tool kits of the KL-0039-.. Series for pressing out and in of nearly all
standard wheel bearings and wheel hubs.
• Silent block tool kits of the KL-0039-.. Series for pressing out and in of silent blocks
and joints bearings.
• Pressing devices of the KL-0326-1.. Series for pressing out and in support/guide
joints; for example, on Mercedes and VW T4.
• Pressing devices of the KL-0610-1.. Series for pressing out and in silent blocks on
rear axle trailing arms; for example, on Ford, Mazda, Volvo.
• Wheel bearing tool - KL-2211-111.. for pulling stuck screwed wheel bearing units;
for example, on Subaru.

Techniscal Data Assembly Trolley: See KL-4999-270 MODULO Assembly Trolley

Required Drive Parts: KL-0215-35 M25 - Hydraulic-Pump

Technical Data: See KL-4999-270 MODULO Assembly Trolley

Copyright GEDORE Automotive GmbH, Germany 15

Mercedes

KL-4999-270
KL-4999-270

(Code 3418340)
Modular Workstation „MODULO 270“
Universally applicable for repairs on wheel bearings, steering and axle systems
on passenger cars and vans.

The assembly trolley "MODULO 270" with its unique composition is the ideal, mobile
workstation for fast, organised, and efficient repairs.

Contents / Scope of application same as KL-4999-250/-260 plus additionally:

• Holding device KL-0115 for counterholding wheel hubs when loosening and
tightening the wheel bearing central bolt.
• Pullers of the KL-0042-9.. Series for pulling stuck wheel bearing inner races on the
wheel hub.
• Clamping KL-0121-96.. To compress lug clamps and locking of stepless hose clips.
• Forcing tool of the KL-0165-.. Series for separating ball joint connections on
steering and axle systems.
• Excentric spanner KL-0167-30 for loosening and tightening inner tie bar joints or
axial joints.
• Disassembly fork KL-0190-12 to check bearing and joint connections on vehicle
axes, and to disassemble various parts.

Techniscal Data Assembly Trolley:

• Dimensions: H 985 x W 1200 x D 635 mm
• Beech multiplex worktop, 30 mm thick, oiled
• Total load carrying capacity: 1000 kg / mobile operation: 750 kg
• 2 fixed castors Ø 200 mm and 2 swivel castors Ø 125 mm with total brake
• Sheet steel, corrosion-resistant, scratch-resistant powder-coated in GEDORE blue
• Wide drawers (W 998 x D 474 mm) with full extension, max. load 70 kg
• Automatic drawer retraction with single pull-out stop and central locking system
• Side walls with Euro perforation 10 x 38 mm for attaching hooks and tools

Required Drive Parts: KL-0215-35 M25 - Hydraulic-Pump

Technical Data:
Width: 985mm
Height: 1,200mm
Depth: 635mm
Total load-bearing capacity (mobile): 750kg
Total load-bearing capacity (static): 1.000kg
Max. load per drawer: 70kg

KL-4999-1280
K L-4999-1280

(Code 3428001)
Surface-Mount Worktop for KL-4999
Series / 1507 XL
Fits the MODULO workshop trolley KL-4999-..series and GEDORE 1507 XL.
Extremely robust surface-mount worktop made of impact-resistant and oil-resistant
ABS hard plastic. For easy mounting on the already existing wooden worktop. Two
can shelves and eight storage compartments for orderly storage of various small
parts.
Technical Data:
Inner plate dimension: 1202 x 639mm
Weight: 3.2kg
Material Impact-resistand and oil-resistant ABS hard plastic

16 Copyright GEDORE Automotive GmbH, Germany

 (Code 3435717)
KL-0380-753 K

KL-0380-753 K
Locking Tool Kit for Mercedes 1.3
Suitable for Mercedes, Renault, Dacia, and Nissan 1.3 petrol engines. Installed in
Mercedes Benz A-Class (177) (18-), B-Class (247) (19-), CLA Coupé (118) (19-),
CLA S/Brake (118) (19-), GLA (247) (20-), GLB (247) (19-); Renault Arkana (XJC)
(19-), Captur (J87) (13-19), Clio V (XJA) (19-), Kadjar (HFE), Koleos II (HZG) (17-),
Captur II (XJB) (19-), Megane IV (BFB/KFB/LFF) (16-), Scenic/Grand Scenic IV
(JFA/RFA) (16-), Talisman (KFD/LFD) (15-); Dacia Duster (HJD) (17-), Dokker (F/
K67), Lodgy (J92); Nissan Qashqai (J11) (14-), X-Trail (T32) (14-), for example.
Engine codes: OM282.914, H5H450, 470, 480, 490, HR13DDT.
Alternative tools: MOT.2188, MOT.2203; W 282 589 00 23 01, W 282 589 00 23 02, W
282 589 00 23 03, W 282 589 00 40 00

For professional locking of the camshafts, crankshaft, flywheel, and timing belt
tensioning unit. Required when changing the timing belt or repairing the engine, for
example.

Scope of Delivery
Part No. Description Qty
KL-0380-7531 Locking tool for flywheel 1
KL-0380-7532 Locking tool for crankshaft 1
KL-0380-7533 Camshaft adjustment tool 1 Technical Data:
KL-0380-7534 Staking pin 1 For engine type: Petrol
KL-0380-7539-1 Foam insert 1 Storage: in case
KL-4990-9274 Plastic case 1

KL-1280-704 K
KL-1280-704 K

(Code 3435911)
Locking Tool Kit for Renault 1.6 dci
Suitable for Renault, Fiat, Mercedes-Benz, Nissan, and Opel 1.6 (R9M) diesel
engines. Installed on Renault Megane III, Talisman, Scenic III, Espace V, Grand
Scenic, Trafic III; Fiat Talento; Mercedes-Benz C180 (205), C200 (205), Vito (447);
Nissan Qashqai (J10/J11), X-Trail (T32), NV300; OPEL Vivaro B, for example.
Engine codes: R9M402, R9M404, R9M408, R9M410, R9M414, R9M450,
OM622.951, OM626.951, LWU, LWX, LWY, LWZ
Alternative tool: MOT.1770, MOT.1773, MOT.1969, MOT.1970

For professional locking of the camshafts, crankshaft, V-belt and timing belt
tensioning unit. For counterholding the crankshaft when loosening and tightening
the central crankshaft bolt, and for aligning the split camshaft gear. Required when
changing the timing belt or repairing the engine, for example.
Necessary accessories: KL-1780-1501 A - Lever

Scope of Delivery
Part No. Description Qty
KL-0380-7531 Arretierwerkzeug für Schwungrad 1
KL-0380-7532 Arretierwerkzeug für Kurbelwelle 1
KL-0380-7533 Arretierwerkzeug für Nockenwelle 1
KL-0380-7534 Absteckstift 1
KL-0380-7539-1 Schaumstoffeinlage 1
KL-4990-9274 Kunststoffkoffer 1 Technical Data:
KL-0380-7531 Arretierwerkzeug für Schwungrad 1 For engine type: Diesel
KL-0380-7532 Arretierwerkzeug für Kurbelwelle 1 Storage: in case

KL-1280-7047
KL-1280-7047

(Code 3435814)

Socket Spanner 8-edge for

Turbocharger Exhaust Housing
Suitable for 8-edge special profile bolts on Renault, Fiat, Mercedes-Benz,
Nissan, and Vauxhall/Opel 1.6 (R9M) diesel engines. Installed on Renault
Technical Data:
Megane III, Talisman, Scenic III, Espace V, Grand Scenic, Trafic III; Fiat Talento;
Special profile: 8-edge
Mercedes-Benz C180 (205), C200 (205), Vito (447); Nissan Qashqai (J10/J11), X-
Size: 10mm
Trail (T32), NV300; Vauxhall/OPEL Vivaro-B etc.
Length: 50mm
Also suitable for 8-edge special profile bolts on the bonnet of Renault Master, Drive: 1/4"
Traffic; Nissan Primastar Turbo; Vauxhall/Opel Movano etc.

Copyright GEDORE Automotive GmbH, Germany 17

Mercedes

KL-0186-14 KB
KL-0186-14 KB

(Code 3420124)
Universal Injector Puller Kit
Universally suitable for diesel injectors, for example for BOSCH injectors with
M17x1 internal thread, and also for BOSCH and DELPHI injectors with M14x1.5
external thread.

The injector puller kit enables fast and powerful pulling of severely stuck injectors
directly on the vehicle without having to remove the cylinder head. Depending on
the injector, the special 2-part pull spindles with pull adapter can be universally
combined in terms of length and connection diameter.
The injector puller can also be universally used for many other common rail diesel
engines by using the optionally available support bolts, pull adapters, and
supplementary kits.

Recommended accessories:
Set of Vacuum Line Plugs - KL-0121-75

Alternative drive parts:

Hydraulic Cylinder, short, 17t - KL-0040-175 C,
Hydr. Hand Pump with Pressure Gauge - KL-0215-35 M25

Scope of Delivery
Part No. Description Qty
KL-0186-121 A Pull-off bridge (basic tool) 1
KL-0186-1231-11 Support pin 110mm, M6 4
KL-0186-1235-3 Grub screw M6 x 45mm 4
KL-0186-1235-2 Grub screw M6 x 25mm 4
KL-0583-1005 B Pull adapter, M17x1, with Union Nut 1
KL-0583-1032 A Pull adapter M14x1.5mm 1
KL-0186-1401 Pull spindle 115mm 1
KL-0186-1402 Pull spindle 170mm 1
KL-0186-1215 Collar nut M16x1.5mm 1
KL-0369-4505 A Special insert size 10mm 1
KL-0369-461 A Socket spanner size 29mm 1
KL-0186-1251 Set of Spacer Nuts, 5mm (4-piece) 1
KL-0186-1252 Set of Spacer Nuts, 10mm (4-piece) 1
KL-0186-1253 Set of Spacer Nuts, 15mm (4-piece) 1
KL-0126-221 Magnetic lifter, flexible 1
KL-4990-2001 Plastic box 53 x 107 x 18mm 2
KL-0186-1492 B Foam insert 1
KL-4990-9474 Plastic case 1
Recommended Supplements:
Set of Support Bars - KL-0186-122,
Pull Spindle Adapter Sets - KL-0186-1281 A / -1282 A / -1283 A /
-1284 A / -1285 A,
Support Bolt Kit - KL-0186-130 A / -132 / -1233 / -1234 / -1236 / -
1238 / -1239 / -1240

KL-0186-1233
K L-0186-1233

(Code 2411199)

Set of Support Bolts, M6, 145mm

Applicable to VW-Audi, Seat, Škoda 2.0 TDI (CFFB) Common Rail Diesel en-gines
and Opel/Vauxhall 2.0 CDTi, VCDi (Z 20 DM, Z 20 DMH, Z 20 S) Common Rail
Diesel engines; as found in: VW Golf VI (5K), Eos (1F), Sharan (7N), Passat V (3C),
Passat VI (36), Jetta (16), Passat CC (35), Tiguan (5N); Audi A3 (8P), Q3 (8U); Seat
Alhambra (71); Škoda Su-perb II (3T); Opel/Vauxhall Antara, Chevro-let Captiva,
Nubria estate car and Lacetti etc.
By using the support bolt kit, the injector extractor - KL-0186-14 EA also fits the
above-mentioned engines.
Necessary Accessories:
KL-0186-14 EA Injector Extractor Kit; depending on the injector, the Supplementary
Kit KL-0186-128.. may be required.
Scope of Delivery:
Part No. Description Qty
KL-0186-1233-11 Support Bolt, 145mm 4
KL-0186-1235-2 Set Screw, M6x25mm 4

18 Copyright GEDORE Automotive GmbH, Germany

KL-0186-1281 A
K L-0186-1281 A

(Code 3420132)
Supplementary Kit, Siemens Injector M25x1
Fits Siemens injectors with an internal thread of M25x1 and a spanner size of 25
mm. Particularly suitable, for example, for VW, Audi, Seat, Škoda 1.6 TDI (CAYA,
CAYB, CAYC, CAYD, CAYE, CLNA) and PSA 2.0 HDI (DW10) etc. Particularly
suitable, for example, for W, Audi, Seat, Škoda 1.6 TDI (CAYA, CAYB, CAYC, Technical Data:
CAYD, CAYE, CLNA) For injectors Siemens/VDO
By using the supplementary kit, the injector extractor KL-0186-14 KB also fits the Drive 1/2"
above-mentioned injectors and engines. Spanner size 25 mm

Necessary accessories:
Universal injector puller kit - KL-0186-14 KB, depending on the injector, the
Scope of Delivery
supporting pin kit KL-0186-12../13.. may be required.
Part No. Description Qty
Alternative drive parts: KL-1383-1021 A Pull adapter M25x1 1
Injector extractor adapter - KL-0369-4111 KL-1383-1022 Socket spanner size 25mm 1
and impact extractor KL-0049-300 (4.8kg) or KL-0369-4100 (1.5kg)

KL-0186-1282 A
K L-0186-1282 A

(Code 3420140)
Supplementary Kit, Siemens Injector M27x1
Fits Siemens injectors with an internal thread of M27x1 and a spanner size of 27 mm.
Particularly suitable e.g. for PSA 2.0 HDI 90 HP (DW10 TD), etc.
By using the supplementary kit, the injectorpuller kit KL-0186-14 KB also fits the Technical data:
above-mentioned injectors and engines. For injectors Siemens/VDO
Drive 1/2"
Recommended accessory: Spanner size: 27 mm
Universal injector puller kit - KL-0186-14 KB, depending on the injector, the
supporting pin kit - KL-0186-12../-13.. may be required.
Alternative drive parts: Scope of Delivery
Injector extractor adapter - KL-0369-4111 Part No. Description Qty
and impact extractor KL-0049-300 (4.8kg) or KL-0369-4100 (1.5kg) KL-1383-1221 A Pull adapter M27x1 1
KL-1383-1222 A Socket spanner size 27mm 1

KL-0186-1283 A
K L-0186-1283 A

(Code 3420159)

Supplementary Kit, Denso Injector M16x1

Fits Denso injectors with an internal thread of M16x1 and a spanner size of 17mm.
Particularly suitable, for example, for Toyota and Lexus 2.2, 2.5 and 3.0 common Technical Data:
rail diesel engines (1KD-FTV, 2AD-FHV, 2AD-FTV, 2KD-FTV H, 2KD-FTV L), etc.
For injectors: Denso
By using the supplementary kit, the injectorpuller kit KL-0186-14 KB also fits the Drive: 3/8"
above-mentioned injectors and engines. Size: 17mm
Necessary accessories: Weight: 250g
Universal injector puller kit- KL-0186-14 KB, depending on the injector, the
supporting pin kit - KL-0186-12../-13.. may be required. Scope of Delivery
Alternative drive parts: Part No. Description Qty
Injector extractor adapter - KL-0369-4111 KL-0186-1612 A Pull adapter M16x1 1
and impact extractor KL-0049-300 (4.8kg) or KL-0369-4100 (1.5kg) KL-4417-17 A Socket spanner size 17mm 1

KL-0186-1284 A
K L-0186-1284 A

(Code 3420175)

Supplementary Kit, Denso Injector M20x1

Fits Denso injectors with an internal thread of M20x1 and an external thread of
M25x0.5 / M25x0.75 and a spanner size of 27 mm. Particularly suitable, for Technical Data:
example, for Toyota and Lexus 2.2, 2.5 and 3.0 common rail diesel engines (1KD- For injectors: Denso
FTV, 2AD-FHV, 2AD-FTV, 2KD-FTV H, 2KD-FTV L), etc. Drive: 1/2"
By using the supplementary kit, the injectorpuller kit KL-0186-14 KB also fits the Size: 27mm
above-mentioned injectors and engines. Weight: 600g
Necessary accessories:
Universal injector puller kit- KL-0186-14 KB, depending on the injector, the Scope of Delivery
supporting pin kit - KL-0186-12../-13.. may be required. Part No. Description Qty
KL-0186-1611 B Pull adapter M20x1 Pull adapter M20x1 1
Alternative drive parts:
KL-1383-1222 A Socket spanner size 27mm 1
Injector extractor adapter - KL-0369-4111
KL-0186-2201 Special insert 1
and impact extractor KL-0049-300 (4.8kg) or KL-0369-4100 (1.5kg)

Copyright GEDORE Automotive GmbH, Germany 19

Mercedes

KL-0186-1285 A
KL-0186-1285 A

(Code 3420183)
Supplementary Kit, Delphi / Bosch
Injectors with M18x2 Internal Thread
Technical Data Suitable for Delphi / Bosch injectors with lateral fuel connection (90° angle to
For injectors Delphi and Bosch the injector). Particularly suitable, for example, for Mercedes-Benz 1.8 and 2.1
Weight 600 g Common Rail diesel engines (OM651), etc.
By using the supplementary kit, the injectorpuller kit KL-0186-14 KB also fits the
above-mentioned injectors and engines.
Scope of Delivery
Part No. Description Qty Necessary accessories:
KL-0186-1711 A Pull adapter M18x2.5 1 Universal injector puller kit- KL-0186-14 KB, depending on the injector, the
KL-0369-420 Nozzle extractor Nozzle extractor 1 supporting pin kit - KL-0186-12../-13.. may be required.
Alternative drive parts:
Injector extractor adapter - KL-0369-4111
and impact extractor KL-0049-300 (4.8kg) or KL-0369-4100 (1.5kg)

KL-0186-50 B
KL-0186-50 B

(Code 2917459)

Cleaning Tool (Universal) for Injector

Nozzle Seat
Universally suitable for the VW-Audi, Seat, Škoda, Citroën, BMW, Ford, Land
Rover, Mazda, Mercedes, Opel/Vauxhall, Peugeot, Renault, Toyota, Volvo Diesel
engines having an injector nozzle seat Ø of 17mm.
The tool allows for the quick and professional cleaning of injector nozzle seats.
Before installing/re-installing an injector nozzle, it is absolutely necessary to clean the
seal seat in order to avoid leakage between the cylinder head and injector nozzle.
The spring-loaded centring cone sleeve ensures that the cleaning tool is accurately
guided in the injector nozzle bore, thus enabling the seal seat to be cleaned properly
and without any trouble.
Recommended accessory: KL-0186-501 Extension (150mm)
Technical Data:
Drive: T-Handle
Length: 238mm
Cleaning tool Ø: 7.3/17mm

KL-0186-54 E
KL-0186-54 E

(Code 3415228)

Injector Bore Cleaning Kit

Universal fit for diesel engines; for example, VW-Audi, Seat, Škoda, Citroën,
BMW, Ford, Land Rover, Mazda, Mercedes, Opel, Peugeot, Renault, Toyota,
Volvo, and many others.

The injector bore brushes allow simple and quick cleaning of the injector bore in
conjunction with a cordless screwdriver, for example. To prevent leaks between the
injector and the seal seat, flat injector seal seats with 17mm in diameter can be
quickly and precisely cleaned from stubborn combustion residues by using the
cleaning tool.
Recommended accessories:
Compressed-air adapter set - KL-0369-54 A, Glow plug brush set - KL-0369-24
Storage system:
Plastic case - KL-4990-9274

Scope of Delivery

Technical Data: Part No. Description Qty

KL-0186-50 B Cleaning tool, universal 1
Injector bore brushes (length): 200mm
KL-0186-5401 Injector bore brush, 18mm diameter 1
Injector bore brushes 18 / 19 /
(diameter): 24mm KL-0186-5402 Injector bore brush, 19mm diameter 1
Cleaning tool (length): 238mm KL-0186-5403 Injector bore brush, 24mm diameter 1
Cleaning tool (diameter): 7.3 / 17mm KL-0186-5490 Foam insert 1

20 Copyright GEDORE Automotive GmbH, Germany

KL-0186-540 E
KL-0186-540 E

(Code 3415252)
Tubular brush kit for injector bores
Universal fit for diesel engines; for example, VW-Audi, Seat, Škoda, Citroën,
BMW, Ford, Land Rover, Mazda, Mercedes, Opel, Peugeot, Renault, Toyota,
Volvo, and many others.

Scope of Delivery
Part No. Description Qty
KL-0186-5401 Injector bore brush, 18mm diameter 1
KL-0186-5402 Injector bore brush, 19mm diameter 1
Technical Data:
KL-0186-5403 Injector bore brush, 24mm diameter 1
Injector bore brushes (length): 200mm
KL-0186-5490 Foam insert 1
Injector bore brushes (diameter): 18 / 19 / 24mm diameter

KL-0187-100 E
KL-0187-100 E

(Code 3283798)

Injector Extractor Kit for Direct Injection

Petrol Engines, in Foam Insert
Fits universally for passenger cars and vans with direct injection petrol engines
with BOSCH, SIEMENS VDO, CONTINENTAL, MAGNETI-MARELLI, and DENSO
injectors. Installed for example on VW-Audi, Seat, Škoda (FSI, TSI, TFSI), Alfa
Romeo, BMW, Ford, Hyundai, Nissan, Mercedes, Opel, and many more.

For quick and professional removal of injectors on direct injection petrol engines.
Required, for example, when replacing the injectors and when dismantling the valve
cover. For this, the injector is loosened and pulled out using the impact extractor. The
different extractors allow safe operation on the respective injector.
Recommended Accessories:
KL-0187-101 Injector repair kit
Storage System:
KL-4990-9274 Plastic Case

Scope of Delivery
Part No. Description Qty
KL-0187-1001 Extractor for impact hammer size 1 1
KL-0187-1002 Extractor for impact hammer size 2 1
KL-0187-1003 Extractor for impact hammer size 3 1 Technical Data:
KL-0187-1004 Extractor for impact hammer size 4 1 Impact weight: 0.9kg
KL-0187-1005 Extractor for impact hammer size 5 1 Length of impact
KL-0049-1205 Plastic sleeve 1 300mm
extractor:
KL-0049-101 Impact extractor base unit 1 Mounting thread for
M10
KL-0187-1090 Foam insert 1 impact extractor:

KL-0187-101
KL-0187-101

(Code 3283828)

Injector Repair Kit for Direct Injection

Petrol Engines
Fits universally for passenger cars and vans with direct injection petrol engines
with BOSCH, SIEMENS VDO, CONTINENTAL, MAGNETI-MARELLI, and DENSO
injectors. Installed for example on VW-Audi, Seat, Škoda (FSI, TSI, TFSI), Alfa
Romeo, BMW, Ford, Hyundai, Nissan, Mercedes, Opel, and many more.
Alternative tools: BMW 130280, 130281, 130282, 130283, 130190, 130192, 130193,
130194, 130195
Recommended Accessories:
KL-0187-100 E Injector extractor kit for direct injection petrol engines
For damage-free assembly of combustion chamber sealing rings (Teflon sealing
rings), and O-rings (fuel side) on direct injection petrol injectors. Storage System:
Before reinstalling a used injector, replace the sealing rings as specified by the KL-4990-9274 Plastic case, KL-0187-1090 Foam insert
manufacturer. The new sealing rings are simply pushed on the injector via the
assembly cone with the aid of the calibration tool. Scope of Delivery
The sealing ring for the combustion chamber is additionally constricted (calibrated) Part No. Description Qty
in 2 stages at the seal-seat. KL-0187-1011 Calibration tool 1
A new combustion chamber sealing ring which was not constricted during the KL-0187-1012 Mounting cone 1
installation will most probably be damaged when re-installing the injector. KL-0187-1013 Mounting cone 1

Copyright GEDORE Automotive GmbH, Germany 21

Mercedes

KL-0369-512
KL-0369-512

(Code 3293734)
Set of Taps (M6 - M8)
Universally suitable for common rail Diesel engines such as by VW, Audi,
Citroën, Fiat, Jeep, Mercedes, Peugeot, Smart, Seat, Škoda, and many others.
This set of taps enables professional re-cutting and cleaning of the threaded holes for
the clamping screws on the injection nozzle holder or the injector fastening. These
extra-long taps make it easy to reach the deep threads in the cylinder head without
having to dismantle the valve cover.

Recommended Drive Parts:

Scope of Delivery
GEDORE 8551 TG-2 Tool holder for taps
Part No. Description Qty
KL-0369-51 A Tap M6 with drilling head 1 Technical Data:
KL-0369-511 A Tap M7 with drilling head 1 Thread: M6 / M7 / M8
KL-0369-5121 Tap M8 with drilling head 1 Length: 100mm

KL-0369-25 KA
KL-0369-25 KA

(Code 2802929)
Reamer Set (adjustable) for Glow Plug
Aperture, in a Plastic Storage Case
Universally suitable for use on Diesel engines with either an M8x1, M9x1 or
M10x1 glow plug retaining thread.
The ideal tool set for BMW 1.6 and 2.0 Diesel engines as fitted to: BMW 1 Series
(E81/E82/E87/E88), 3 Series (E90/E91/E92/E93), 5 Series (E60/E61/F10), X1 (E84),
X3 (E83); MiniHatch (R56), Countryman (R60), Clubman (R55), Coupé (R58).
(Engine codes: N47; N47 C16K1; N47 C16U1; N47 C20K1; N47 C20U1; N47 D20A;
N47 D20C; N47 D20D; N47 D20K0; N47 D20K1; N47 D20O0; N47 D20O1; N47
D20U0; N47 D20U1; N47S D20B; N47S D20D; N47S D20T0; N47T D20K1; N47T
D20O1; N47T D20U1)
The set of adjustable reamers is designed to clean out glow plug apertures and glow
plug retaining threads. Thanks to the possibility to combine the different holders
(glow plug retaining threads) with the necessary reamers (glow plug aperture Ø), and
to precisely adjust the length of the reamers as needed, this tool set is virtually
universal in its field of application, since the reamers can be accurately adapted to the
respective engine type. The special design of the tool and the cleaning groove in the
holder allow carbon deposits to be removed from glow plug retaining threads and
glow plug apertures carefully and effectively.

Scope of Delivery
Part No. Description Qty
KL-0369-2510 A Holder, M8x1, with Set Screw 1
KL-0369-2610 A Holder, M9x1, with Set Screw 1
KL-0369-2710 A Holder, M10x1, with Set Screw 1
KL-0369-2512 A Reamer, Ø 4.8mm (Glow plug Ø D = Ø 4.0mm) 1
KL-0369-2522 A Reamer, Ø 5.2mm (Glow plug Ø D = Ø 4.4mm) 1
KL-0369-2732 A Reamer, Ø 5.8mm (Glow plug Ø D = Ø 5.0mm) 1
Kl-0369-2590 Plastic Storage Case 1

KLANN Information System

Auch mit Ihrem Handy haben Sie bequem Zugriff auf unser „KIS“.
Somit können Sie zu jeder Zeit und wo immer Sie sich befinden
OE-Werkzeugnummern auf unsere Artikel Nummern umschlüsseln.

KIS goes mobile ...

22 Copyright GEDORE Automotive GmbH, Germany

KL-0120-81 K
KL-0120-81 K

(Code 3125580)
Fuel Tank Sender Spanner Kit
Universally suitable for use on fuel tank sender lock rings as found on: VW-Audi,
Seat, Skoda, BMW, Mercedes-Benz, Porsche, Opel/Vauxhall, Mini, PSA, Citroën,
Peugeot, Renault, Alfa Romeo, Fiat, Volvo and Honda etc.
Alternative tool: T10202, 16 1 020, EN-48279, 999 5720, 310-118, I-1618, J-1618-A

An indispensable tool kit for the professional loosening and tightening of fuel sender
lock rings on fuel tanks.
Thanks to the adjustable design of the base tool and the universal and vehicle-
specific adaptor sets supplied with the kit, the spanner can be assembled to work on
virtually all commonly used fuel sender lock rings - safely and without any risk of
damage.
Note: The adaptors can also be attached to the base tool from the inside - ideal when
space is at a premium.
Technical Data:
Adjustment range: 110-180mm

Scope of Delivery:
Part No. Description Qty
KL-0120-811 Fuel Tank Sender Spanner Base Tool 1
KL-0120-812 Adaptor Set (2.8mm) 1
KL-0120-813 Adaptor Set (3.5mm) 1
KL-0120-814 Adaptor Set (5.5mm) 1
KL-0120-815 Adaptor Set (BMW/Mercedes/Honda) 1
KL-0120-816 Adaptor Set (VW-Audi) 1
7 7 (6089630) Combination Spanner, Size (waf) 7mm 1
KL-0120-8190 Plastic Storage Case 1

KL-0124-59
KL-0124-59

(Code 2961830)
Removal Tool for HENN® Clamps
Universally suitable for HENN® clamps as found on coolant hoses/charge air
hoses. Installed, for example, in the following vehicles: VW-Audi, Seat, Škoda,
BMW, Peugeot, Citroën, Dacia, Fiat, Ford, Kia, Lexus, Mazda, Mercedes, Nissan,
Opel/Vauxhall, Porsche, Renault, Toyota, Volvo etc.
Designed for the professional loosening/opening of HENN® Clamps as found on
coolant hoses/charge air hoses in passenger cars. An indispensable tool when
removing/installing coolant hoses/charge air hoses etc. The handle of the tool can be
unscrewed and repositioned by 90 degrees. This allows even HENN® Clamps which
are difficult to access to be loosened/opened with ease.

KL-0121-21 A
KL-0121-21 A

(Code 3406350)
Hose Clamp Pliers with Remote Control
(semi-rigid)
Universell passend für PKW und NKW.
• To easily clamp and release spring-loaded band clamps, for example to remove and
install hoses for oil, fuel and cooling water.
• The special It can be bent into almost any position and remains there, similar to a wire.
• This makes it possible to reach spring-loaded band clamps even in extremely hard-
to-reach places, such as EGR coolers.feature of these pliers is the semi-rigid design of
the Bowden cable.
• The automatic retaining function of the pliers holds the spring-loaded band clamp
securely in this state after it has been pre-tensioned once.
Technical Data:
For Ø : 18 - 53mm
Length: 680mm
Weight: 640g

Copyright GEDORE Automotive GmbH, Germany 23

Mercedes

KL-0132-14 K
KL-0132-14 K

(Code 3430847)
Thread Repair Kit for Exhaust Sensor
Universal fit for passenger cars, commercial vehicles and vans, especially for
NOx sensors, lambda sensors, and injection units for soot/particle filter
regeneration with mounting threads M20x1.5 and M22x1.5.
For quick recutting of coked or damaged M20x1.5 and M22x1.5 mounting threads on
the exhaust pipe. The extremely short taps and the special ring ratchet spanner with
joint make it easy to work even in very confined spaces. This saves time-consuming
removal of the entire exhaust pipe. The open double ring spanner included in the kit
allows easy loosening and tightening of the exhaust sensors and units.

Scope of Delivery:
Part No. Description Qty
1720.0130 Ring ratchet spanner SW13 with joint 1
400 22x24 Open double ring spanner 1
KL-0132-1411 GTap M20x1.5 with SW13 1
Technical Data: KL-0132-1412 Tap M22x1.5 with SW13 1
Taps: M20x1.5 + M22x1.5 KL-0132-1490 Foam insert 1
Tap length: 45mm KL-4990-9224 Plastic Storage Case 1
Tap drive: 13mm
Double ring spanner: SW22 + 24 (open)

KL-0130-3
KL-0130-3

(Code 3254437)

Exhaust Hanger Removal Pliers

Universally suitable.
Particularly sturdy design.
Allows for the quick, easy and damage-free separation of exhaust brackets from
rubber hangers. Even very stiff or tight rubber hanger supports are no longer an issue.
Thanks to this tool, struggling with screwdrivers or assembly levers has now become
a thing of the past.
Hand injuries as well as damage to the vehicle caused by improper removal methods
can be prevented by using our KL-0130-3 removal pliers.
Technical Data:
Length: 300mm

KL-0131-51
KL-0131-51

(Code 1753118)
Chain Pipe Cutter
Universal application.
Alternative tool: VAS 6254

This tool is used to cut exhaust pipes having a wall thickness of up to 2.5mm and a Ø
of 70mm.
Also suitable for stainless steel pipes.
Thanks to the special design of the tool, only a minimum expenditure of force is
required throughout the whole cutting operation.
The wing screw allows for the necessary adjustment while cutting.
Technical Data:
Length: 250mm
For wall thickness: max. 2.5mm
For pipe Ø: max. 70mm
Note: By attaching a second chain, the cutter can be used on pipes with larger diameters.

KL-0131-5101
K L-0131-5101

(Code 1753126)
Spare Chain
Techncial Data:
Length: 270mm

24 Copyright GEDORE Automotive GmbH, Germany

4550-..
4550-20

Torque wrench TORCOFIX K

• Robust, silk-matt chrome-plated steel tube construction
• With chrome-plated ratchet head and glass-fibre-reinforced plastic parts
• For controlled bi-directional tightening by simply switching the square
• Classified to DIN EN ISO 6789:2003 Type II Class A, with a factory certificate. Working
accuracy: +/- 3% tolerance of scale set torque. The specification of the standard
(+/- 4%) is exceeded.

4550-20 (Code 7601610)

Torque wrench TORCOFIX K
Technical Data:
Nm: 20-200
lbf•ft: 15-150
Scale: 1 N•m
Length: 485 mm
Weight: 1100 g

4550-30 (Code 7601880)

Torque wrench TORCOFIX K
Technical Data:
Nm: 60-300
lbf•ft: 45-220
Scale: 1 N•m
Length: 577
Weight: 1400 g

3550-UK-LS4
3550-UK-LS4

(Code 3107027)
Torque wrench TORCOFLEX UK Set 1/2"
• Tried-and-tested torque wrench in the 40-200N·m tightening range with test
certificate
• Controlled clockwise tightening; bi-directional reversible ratchet; 1/2” output drive
• Classified as per DIN EN ISO 6789-2:2017; adjusted to a maximum permissible +/-3%
deviation and thus with a greater precision than the standard-stipulated +/-4%
• Highly suited for car tyre changing given its 1/2” extension and impact sockets with
protective sleeve in the 17, 19 and 21mm sizes
• Made in Germany
Technical Data:
Drive 1/2"
Nm 40-200
Scale division 1 Nm
Length 499mm

K 19 LS-004
K 19 LS-004

Impact socket set 1/2" with protective

sleeve
• Machine-operated, suitable for all standard electric and air tools
• Square drive as per DIN 3121 - G 12.5, ISO 1174
• Thin-walled to protect the alloy wheels
• GEDORE special steel, manganese-phosphated
Technical Data:
Drive 1/2"
Spanner size 17 / 19 / 21 / 22mm

Copyright GEDORE Automotive GmbH, Germany 25

Mercedes

TTB 0321
TTB 0321

(Code 3411435)
Tool trolley with 6 drawers
Body:
• Dimensions: H 985 x W 775 x D 475 mm
• Sheet steel, corrosion-resistant and scratch-resistant powder-coated
• Working platform in ABS, with 3 compartments for small parts
• Manoeuvrable and easy to control with the driving and steering handle
• Side walls with Euro perforation 10 x 38 mm to fix hooks and tools
• Safety through heel protection for persons

Drawers:
• Central locking with cylinder lock
• Ball-bearing guide rails
• Can be individually equipped with lengthwise and crosswise dividers
• Load capacity per drawer 40 kg

GEDORE High-performance chassis:

• Total static load capacity: 900 kg / dynamic load capacity: 650 kg
• 2 roller-bearing GEDORE high-performance wheels (fixed castors Ø 200 mm)
• 2 ball-bearing mounted GEDORE smooth-running wheels
(swivel castors Ø 125 mm), both with total brakes
Options: • The GEDORE trapezoidal axle construction secures smooth running,
• Can be extended as required using GEDORE tool modules manoeuvrability and track-keeping also in case of maximum loads
(No. 1500 ES/1500 CT or 2005 CT)
• Optionally extendable with GEDORE tool chests, rear panels
and tool holders Techncial Data:
Weight 78kg

2004 0620
2004 0620

(Code 1640720)
Tool trolley with 8 drawers
Body:
Dimensions: H 985 x W 775 x D 475 mm
• Working platform in ABS, with 3 compartments for small parts
• Storage compartment with perforated sheet (Euro perforation 10 x 38 mm), two
removable drawers for small parts and door on the handle side
• With handle for easy pushing, pulling and turning
• Front side with Euro perforation 10 x 38 mm to fix hooks and tools
• Heel and impact protection for your safety
• Sheet steel, corrosion resistant and scratch-proof powder-coated, GEDORE blue

Drawers:
• Central locking with cylinder lockWide drawers (W 480 x D 400 mm) fully extendable,
removable
• Each drawer and storage compartment with safety locking, single-hand operation
• Ball-bearing guide rails
• Can be individually equipped with lengthwise and crosswise dividers
(can be ordered individually)
• Load capacity per drawer 40 kg, bottom heavy-duty drawer 60 kg
(not for No. 2004 1000)
• Sheet steel, corrosion resistant and scratch-proof powder-coated, GEDORE blue

GEDORE high-performance chassis:

• Total load capacity 1000 kg static (750 kg dynamic)
• 2 roller-bearing GEDORE high-performance wheels (fixed castors Ø 200 mm)
Options: • 2 ball-bearing mounted GEDORE smooth-running wheels
• Can be equipped with GEDORE tool modules (1500 ES/1500 CT) (swivel castors Ø 125 mm), both with total brakes
• Optionally extendable with GEDORE tool chests, rear panels and • Even under maximum loads, the GEDORE axle design ensures: smooth running,
tool holders maneuverability and directional stability
• Rear panel R 1504 XL-L can be added
• Further drawer combinations on request
• Delivery without tools and accessories
Techncial Data:
Weight 88kg

26 Copyright GEDORE Automotive GmbH, Germany

TS-308
TS-308

(Code 2956535)
Tool assortment in Check-Tool-Modules
308 pcs
• Metric dimension tools
• GEDORE Check-Tool-System: 2-colour foam insert to check that the set is complete
• Each tool is securely held in its own pocket, grip recesses facilitate removal of the
tools
• Resistant to oil and grease

(Code 3421147)
KL-4998-400

KL-4998-400
Workshop trolley, passenger car hand
tools
Universally applicable for maintenance and repair work on cars and vans.

The tool trolley offers a very extensive and extremely robust range of metric hand
tools especially for professionals. Every tool has its place thanks to the high-quality
foam inserts.
This makes the tool trolley the perfect, mobile workplace for fast, organized and
efficient maintenance and repair, especially in everyday workshop work.
With 8 fully equipped drawers and an empty large drawer at the bottom. The trolley
has side walls with Euro perforations, central locking with a cylinder lock, wide
drawers that can be pulled out fully and each drawer has a safety lock.
Techncial Data:
Number of drawers 9
Dimensions drawers W 640 x D 400mm
Load capacity, drawer 40kg
Drawer type Full extension
Dimensions trolley: H 812 x W 771 x D 478 mm
Load capacity (static) 1,000kg
Load capacity (dynamic) 750kg

2093 HR-94
2093 HR-94

(Code 6069870)
Hand ratchet 1/4"
• Push-through square
• Return angle 18 degrees
Techncial Data:
• Facilitates working quickly in confined spaces where other ratchets or tools do not fit
• Especially suitable for servicing work in conjunction with extension 2090-12 Drive: 1/4"
• Chrom-Vanadium-Steel Return angle: 18°
Dimensions Ø26mm x 20mm

Copyright GEDORE Automotive GmbH, Germany 27

Mercedes

2093 U-3
2093 U-3

(Code 6170590)
Reversible ratchet 1/4"
• Particularly suitable for work in confined spaces
• Acc. to DIN 3122, ISO 3315
• With non-slip metal disc change, fine-toothed (72 teeth) and robust
Techncial Data: • Return angle 5 degrees
Drive: 1/4" • Non-slip 2-component handle with hanging hole
Length: 129 mm • For hand-operated sockets and accessories with square drive as per DIN 3120 - C 6.3,
Return angle: 5° ISO 1174, ball locking device
Weight: 100 g • GEDORE vanadium steel 31CrV3, chrome-plated

3093 U-20
3093 U-20

(Code 1556800)

Reversible ratchet 3/8"

• Universal use in industry and automotive, even in confined spaces
• Acc. to DIN 3122, ISO 3315
• Small, drop shaped head for confined areas
• Fine-toothed (60 teeth), with lever change and push-button release
Techncial Data: • Return angle 6 degrees
Drive: 3/8" • Non-slip 2-component handle with hanging hole
Length: 200mm • For hand-operated sockets and accessories with square drive as per DIN 3120 - C 10,
Return angle: 6° ISO 1174, ball locking device
Weight: 295g • GEDORE vanadium steel 31CrV3, chrome-plated

1993 U-20
1993 U-20

(Code 1436686)
Reversible ratchet 1/2"
• Universal use in industry and automotive, even in confined spaces
• Acc. to DIN 3122, ISO 3315
• Small, drop shaped head for confined areas
Techncial Data: • Fine-toothed (60 teeth), with lever change and push-button release
Drive: 1/2" • Return angle 6 degrees
Length: 270 mm • Non-slip 2-component handle with hanging hole
Return angle: 6° • For hand-operated sockets and accessories with square drive as per DIN 3120 - C 10,
Weight: 536 g ISO 1174, ball locking device
• GEDORE vanadium steel 31CrV3, chrome-plated

KL-4007-500
KL-4007-500

(Code 3406504)
Key Extension, universal, 380mm
Fits universally for hand tools.
For easy extension of open-end spanners, combination spanners, offset combination
spanners, and angled pin spanners. Required, for example, when loosening stuck
screw connections in places which are difficult to access.
Technical Data:
Length: 380mm
Weight: 650g

7 UR-005
7 UR-005

(Code 2327651)
Combination ratchet spanner set,
reversible 5 pcs 8 - 19 mm
• Ring 13° offset from shaft, reversible.
• UD profile.
• High torque transfer.
• In plastic case.

Technical Data:
Spanner size: 8 / 10 / 13 / 17 / 19 mm
Dimensions: 275 x 150 x 42 mm

28 Copyright GEDORE Automotive GmbH, Germany

1 B-08
1 B -08

(Code 6011870)
Combination spanner set 8 pcs 10-24 mm
• Acc. to DIN 3113, Form B, ISO 3318, ISO 7738
• Vanadium steel 31CrV3, chrome-plated
• Carefully forged and professionally machined
• Ring: 10° offset from shaft, with UD profile for gentle transmission of force
• Overloading indicated by deformation
• The offset ring ensures a better grip on deep-seated or inset nuts or bolts
• Top-grade industrial quality for the hardest of continuous use Technical Data:
• Glare-free appearance due to matt chrome Spanner size: 10 / 12 / 13 / 14 / 17 / 19 / 22 / 24 mm
• Jaw: ground precisely to exact nominal size for optimum contact areas Dimensions: 2,6 kg
• Slim ribbed open end for added strength guarantees maximum torques

7 XL-0111
7 XL-0111

(Code 6104960)
Combination spanner set, extra long,
11 pcs 8-22 mm
• Acc. to DIN 3113, Form A, ISO 3318, ISO 7738
• Vanadium steel 31CrV3, chrome-plated
• Carefully forged and professionally machined
• Slim jaws and slender jaw walls make the spanner lighter overall
• Overloading indicated by deformation
• Secure grip thanks to hollow shaft - very ergonomic and handy Technical Data:
• Glare-free appearance due to matt chrome Spanner size: 8 / 10 / 11 / 12 / 13 / 14 / 16 / 17 / 18 / 19 / 22 mm
• Carefully forged and professionally machined Dimensions: 1,7 kg
• Jaw: ground precisely to exact nominal size for optimum contact areas
• Ring: 15° offset from shaft, with UD profile for gentle transmission of force
• Extra long shaft for deep range of use and more torque

(Code 6030740)
2-10

2-10
Double ended ring spanner set
• Rings deep offset, strong but thin walls, UD profile
• Acc. to DIN 838, ISO 3318, ISO 1085, ISO 10104
• Vanadium steel 31CrV3, chrome-plated
• Satin non-glare finish
• Carefully forged and professionally machined:
• Ring: thin-walled, 5° deep offset from shaft, with UD profile for gentle transmission
of force Techncial Data:
• High bending strength - does not fracture or splinter when overloaded, thus 6x7 / 8x9 / 10x11 / 12x13 / 14x15 / 16x17 / 18x19 /
minimising the risk of injury Length:
20x22 / 21x23 / 24x27mm
• Overloading indicated by deformation Weight: 2,2kg
• For extremely deep or inset bolts
• Top-grade industrial quality for the hardest of continuous use

600 H Serie
600 H Serie

Engineer’s hammer ROTBAND-PLUS

with hickory handle
• Forged hammer head DIN 1041
• With contoured ash (No. E 600 E) or hickory (No. E 600 H) handle DIN 5111,
additionally shaped with a long hardened handle protective steel sleeve
• The sleeve, tapered collar, fixing plate and wood screw bond the hammer head and
wood handle into one unit
• ROTBAND-PLUS handle join, high working safety, long service life, best price-
Available sizes:
performance ratio
Part No. Description Qty Weight
600 H-300 300mm 300g 8583070
600 H-500 320mm 500g 8583230
600 H-800 350mm 800g 8583580

Copyright GEDORE Automotive GmbH, Germany 29

Mercedes

247 H-35
247 H-35

(Code 1603396)
Combination hammer KOMBI-PLUS R
• Reduced expense due to versatile use as an engineer’s and recoilless hammer
• Universal use for service and assembly work
• With all advantages of a recoilless hammer with higher impact
• Less energy necessary, easier working
Techncial Data: • With exchangeable splinter-proof, shatter-proof and wear-resistant polyamide head
Length: 310mm (No. E 247), 75 Shore D, tested to -20 °C
Head-Ø: 35mm • With hickory handle (No. E 247 H)
Weight: 0.7kg

(Code 3292002)
KL-4043-100

KL-4043-100
Screwdriver Bit Socket Set, TX-Plus
Fits universally with cars with TX-Plus screw connections such as VW, Audi, Seat
Škoda, Renault, Nissan, Opel, Fiat, Toyota, GM, Ford, and many others.
For loosening and tightening TorxPlus® screw connections with internal profile, e.g.
Recommended Accessories: on timing belt and timing chain housing covers as well as on engines and gearboxes
GEDORE 2093 U-20 Reversible Socket Spanner 1/4", in general.
GEDORE 3093 U-20 Reversible Socket Spanner 3/8" Techncial Data:
Spanner size IP 10/ 15/ 20/ 25/ 30/ 40/ 45/ 50/ 55/ 60
Drive 1/4" + 3/8"

(Code 3292118)
KL-4043-200

KL-4043-200
Socket Set, 3/8", EP TX-Plus, 6-pc
Fits universally with cars with TX-Plus screw connections such as VW, Audi, Seat
Škoda, Renault, Nissan, Opel, Fiat, Toyota, GM, Ford, and many others.
For loosening and tightening TorxPlus® screw connections with external profile, e.g.
Recommended Accessories:
on timing belt and timing chain housing covers as well as on engines and gearboxes
3093 U-20 Reversible Ratchet, 3/8" in general.

Techncial Data:
Spanner size EP 10/ 12/ 14/ 16/ 18/ 20
Drive 3/8"

(Code 3292207)
KL-4043-300

KL-4043-300
Socket Set, 1/2", EP TX-Plus, 6-pc
For loosening and tightening TorxPlus® screw connections with external
profile, e.g. on axle parts, flywheel and generally on engine and gearbox.
Recommended Accessories: For loosening and tightening TorxPlus® screw connections with external profile, e.g.
on axle parts, flywheel and generally on engine and gearbox.
1993 U-20 Reversible Ratchet, 1/2"
Techncial Data:
Spanner size EP 22/ 24 / 26 / 28 / 30 / 32
Drive 1/2"

KL-4043-400
KL-4043-400

(Code 3409112)

Socket Set, 1/4", EP TX-Plus

Fits universally with cars with TX-Plus screw connections such as VW, Audi, Seat
Škoda, Renault, Nissan, Opel, Fiat, Toyota, GM, Ford, and many others.
For loosening and tightening TorxPlus® screwed connections with external profile
Recommended Accessories: such as on timing belt or control housing covers, control units as well as on various
2093 U-20 Reversible Ratchet, 1/4" body and covering pieces.

Techncial Data:
Spanner size EP 6 / 7 / 8 / 10 / 11 / 12
Drive 1/4"

30 Copyright GEDORE Automotive GmbH, Germany

KL-4084-200
KL-4084-200

(Code 3241130)
Mortorq® Super (MTS) Bit Socket Set
Universally applicable to Mortorq® Super fasteners as found on Alfa Romeo,
BMW, Chrysler, Fiat, GM, Honda, Jeep, Nissan, Tesla etc.
Designed for the professional loosening and tightening of screws with Mortorq®
Super (MTS) Profile.
Applications include transmission, differential, hybrid and chassis components as
well as car seats, seat rails, interior trims, restraint systems etc.
The bit socket set is supplied on a handy storage rail.
Recommended accessory: 3093 U-20 Reversible Ratchet, 3/8"

Technical Data:
Drive: 3/8"
Length: 50mm
Sizes (waf): MTS0, MTS1, MTS2, MTS3, MTS4
Profile: For Mortorq® Super (MTS) Profiles

2150-2160 PH-06
2150-2160 PH-06

(Code 1482319)
3C-Screwdriver set 6 pieces IS 4-8 PH 1-2
• Practical set composition in environmentally-friendly cardboard box
• For slotted and cross-head screws PH
• 3-component handles Power-Grip3 with hanging hole
• Ergonomic handle design enables precise and fatigue-free working
• Positive-fit joint of handle and blade for optimum transmission of force
• Type of drive marked at end of the handle
• Blade from GEDORE molybdenum-vanadium-Plus tempered steel
Techncial Data:
Slot: 4 / 5,5 / 6,5 / 8
Phillips PH: 1/2
Weight: 660g

2163 TX-010
2163 TX-010

(Code 1482335)

3C-Screwdriver set 10 pcs TX T7-T40

• Practical set composition in environmentally-friendly cardboard box
• For recessed TX head screws
• 3-component handles Power-Grip3 with hanging hole
• Ergonomic handle design enables precise and fatigue-free working
• Positive-fit joint of handle and blade for optimum transmission of force
• Type of drive marked at end of the handle
• Blade from GEDORE molybdenum-vanadium-Plus tempered steel
Techncial Data:
Spanner size (TX-Profil): T7 / T8 / T9 / T10 / T15 / T20 / T25 / T27 / T30 / T40
Weight: 740 g

KL-4500-100
KL-4500-100

(Code 3412938)
Pliers set automotive
Universally suitable.
Convenient Sentence Compilation.
Techncial Data:
Weight 800g

Scope of Delivery
Part No. Description Qty
KL-4503-301 Multi-function pliers 1
142-10 TL Water pump pliers 1
8316-180 TL Power side cutter 1

Copyright GEDORE Automotive GmbH, Germany 31

 Mercedes

133 K
133 K

(Code 6535190)
Gasket scraper
• For removing seal residues
• With blue plastic handle
Techncial Data
Length: 240mm
Blade width: 22.5mm
Weight: 150g

905
905

(Code 1823698)
Creeper
• The stable assembly/workshop couch is a good helper wherever work has to be
done lying down
• With practical transport handle
• Made of skin-friendly PP (polypropylene) - resistant to oils, greases and brake fluid
• Due to the 6 ball bearing 360° rollers and the low installation height, the workshop
couch can easily be rolled into narrow and inaccessible working areas
• Fatigue-free working, with head/neck cushion for maximum comfort
• Bucket moulding gives additional hold and allows maximum freedom of movement
• 2 troughs (right/left) in optimal hand reach for direct access to the working tool and
small parts
• Temperature resistance -30 to +60 °C
• Comfortable lying position due to the ergonomically shaped and pleasantly
structured surface of the stable plastic body
Technical Data:
• High-grade and durable castors
Weight: 5kg • The blow-moulding used in board surface production ensures impact resistance and
Carrying capacity: 130g durability
Dimensions: W 480 - H 115 - L 1000 mm • The ergonomically shaped board surface prevents any back ache or muscle
Wheel-Ø: 77mm tensioning. The storage tray to the right and left ensures that tools are always to hand
• Load capacity 130 kg

900 20
900 20

(Code 3108678)
Lamp LED Li-MH USB charging
connection
• Versatile deployable LED/UV lamp of a slim design with extra functions
• In particular for the automotive and industrial fields but also for a variety of uses in
leisure-time pursuits
• Continuously dimmable and switchable in blue-violet from LED to UV light (for
tracking leaks.g. in air-conditioners and heat pumps).
• Swing-out hooks on both sides, strong magnet at the 45° adjustable foot and strong
tip mini-magnet for bringing up lost incidental parts where space is at a premium
• Charging either via the supplied power pack or a USB interface
• 620 lumen
Technical Data:
Length: 477mm
Brightness: 620 Lumen
Lamp power: 16 W
Battery: 3.350 mAh
Weight: 295g

GEDORE Automotive GmbH T +49 (0) 771 - 83223 - 0 Brands of the GEDORE Group
Breslauer Straße 41 F +49 (0) 771 - 83223 - 90 gedore.com · ochsenkopf.com
78166 Donaueschingen [email protected]
GERMANY www.gedore-automotive.com

32 Copyright GEDORE Automotive GmbH, Germany
