Block, Object, and File Storage in System Design

Storage is a key part of system design, and understanding the types of storage can help you build efficient systems.

Block, object, and file storage are three common storage methods, each suited for specific use cases.

1. Block storage in System Design

Block storage is a technique for keeping data in chunks or blocks of an exact size. Every block has its own address, functions independently, and can store any kind of data. Block storage lacks a predetermined structure, unlike file storage, which arranges data in a hierarchy. It is frequently utilised in systems like databases and virtual machines that require great performance and scalability.

Block storage doesn’t inherently “understand” the data it stores - it only stores raw bytes. The file system on top of block storage interprets it into files. So block storage itself isn’t aware of formats or data types.

How Block Storage Works

Imagine a warehouse where items aren't organized by category or aisle, but simply placed in numbered bins. Each bin (block) can hold anything, and you access items directly by their bin number. This direct-access model eliminates the overhead of navigating folder hierarchies, resulting in exceptional speed.

It's features are:

• High Performance: Block storage is perfect for high-performance applications since it is designed for quick read/write operations.
• Flexibility: Since it does not impose a particular structure, it allows data to be stored in any format.
• Scalability: Blocks can be added or removed easily to scale the storage up or down.
• Independence: Each block operates independently, enabling precise control and management of data.
• Use in Distributed Systems: Block storage can be distributed across multiple servers for redundancy and improved performance.

Example of Block Storage

Consider a cloud-based database service where you need to store a large amount of structured data. The data is broken into smaller pieces (blocks) and distributed across a storage area network. When you access the database,

• The system retrieves the required blocks and reassembles them into meaningful data for your application.
• Amazon Elastic Block Store (EBS) is a real-world example of block storage.

2. Object Storage in System Design

With object storage, data is kept as discrete units known as "objects." A unique identity, metadata (information about the data), and the actual data are all contained in each item. Object storage is hence very flexible, scalable, and appropriate for storing vast amounts of unstructured data, such as backups, videos, and pictures.

• Object storage doesn't use fixed-sized blocks or a hierarchical file system like file or block storage does.
• Instead, it organizes data into a flat structure, which is easier to scale and manage in distributed environments.

Note: Object storage is ideal for write-once, read-many (WORM) workloads, not for frequently modified data.

Understanding the Object Model

Think of object storage as a vast library where every book has a unique ISBN, a detailed catalog card, and can be retrieved directly without knowing which shelf it's on. The flat structure eliminates hierarchical limitations, allowing the system to scale horizontally across unlimited storage nodes.

Key features of Object Storage

• Scalability: Object storage is perfect for cloud applications because it can manage massive volumes of data.
• Metadata Richness: Metadata is stored in every object to help with data management, indexing, and searching.
• Global Accessibility: Objects can be accessed via HTTP/HTTPS, making it suitable for web-based applications.
• Cost-Effective for Unstructured Data: Large amounts of unstructured data, such as logs, media files, and backups, are ideal for this storage.
• Resilient and Durable: To provide stability and fault tolerance, object storage systems frequently duplicate data across different locations.

Example of Object Storage

• Media Streaming: Netflix and YouTube store billions of video files as objects, serving them to millions of concurrent viewers.
• Backup and Archival: Companies use object storage for long-term data retention, leveraging its durability and low cost per gigabyte.
• Big Data Analytics: Data lakes built on object storage allow analysts to store raw data in any format and process it at scale.
• Static Website Hosting: Web assets like images, CSS, and JavaScript files are served directly from object storage.

3. File Storage in System Design

Similar to how we arrange files on a computer, file storage is a conventional technique of storing data in a hierarchical system of files and folders. Every file has a name and directory path, which helps access and navigation. Applications that need regular updates and organized data management are best suited for it.

The Hierarchical Model

File storage organizes data in a tree structure with directories (folders) containing files and subdirectories. Each file has a path (like /projects/2024/report.pdf) that defines its location, making navigation logical and straightforward.

Key features of File Storage

• Hierarchical Organization: Data is stored in a clear folder-and-file structure, making it easy to locate and manage.
• Simplicity: File storage systems are easy to set up and use for small-scale applications.
• Compatibility: Works well with legacy applications and systems that require traditional file access methods.
• Shared Access: Supports multi-user environments with file permissions and version control.
• Data Integrity: Ensures consistency and integrity through locking mechanisms during file updates but distributed file systems (like NFS) can experience locking issues and performance bottlenecks under concurrency.

Example of File Storage

Amazon EFS, Google Filestore, or Azure Files for cloud file storage analogs

• Corporate File Shares: Departments share documents, spreadsheets, and presentations through networked drives with folder hierarchies mirroring organisational structure.
• Content Management: Web servers host files in organised directories, serving websites through familiar path-based URLs.
• Development Environments: Developers work with codebases organised in folder structures, relying on file storage for source control integration.
• Home Directories: User workspaces on servers maintain personal files in individual, permission-protected directories.

Block Storage vs. Object Storage vs. File Storage in System Design

Differences between them are as follows:
