ThinkCentre

Hardware Maintenance Manual

Machine Types: 7570, 7577, 7578, 7580, 7583, 7584, 7589, 7594,
7595, 7597, and 7598

ThinkCentre
Hardware Maintenance Manual

Machine Types: 7570, 7577, 7578, 7580, 7583, 7584, 7589, 7594,
7595, 7597, and 7598

Note: Before using this information and the product it supports, be sure to read and understand the
ThinkCentre Safety and Warranty Guide and Appendix A Notices on page 197.

Fourth Edition (June 2011)

Copyright Lenovo 2010, 2011.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software are delivered pursuant a General Services
Administration GSA contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No.
GS-35F-05925.

Contents
Chapter 1. About this manual . . . . . 1
Important Safety Information . . . . . . . . . .
Important information about replacing RoHS
compliant FRUs . . . . . . . . . . . . . . .

1
1

Chapter 2. Safety information . . . . . 3

General safety . . . . . . . . . . . .
Electrical safety . . . . . . . . . . .
Safety inspection guide . . . . . . . .
Handling electrostatic discharge-sensitive
devices . . . . . . . . . . . . . .
Grounding requirements . . . . . . . .
Safety notices (multi-lingual translations) .

. . . .
. . . .
. . . .

3
3
5

. . . .
. . . .
. . . .

5
6
6

Chapter 3. General information. . . .

Lenovo ThinkVantage Tools . .
Lenovo Welcome. . . . . . .
Lenovo ThinkVantage Toolbox .
Additional information resources
Specifications . . . . . . . .

.
.
.
.
.

.
.
.
.
.

.
.
.
.
.

.
.
.
.
.

.
.
.
.
.

.
.
.
.
.

29
29
29
29
29

Chapter 4. General Checkout. . . . .

31

Problem determination tips . . . . . . . . . .

31

Chapter 5. Diagnostics . . . . . . . .

33

Lenovo ThinkVantage Toolbox . . . . . .

PC-Doctor for DOS . . . . . . . . . . .
Creating a diagnostic disc . . . . . .
Running the diagnostic program from the
diagnostic disc . . . . . . . . . . .
Navigating through the diagnostics
programs . . . . . . . . . . . . .
Running tests . . . . . . . . . . .
Viewing the test log . . . . . . . . .

.
.
.
.
.

29

. .
. .
. .

33
33
33

. .

34

. .
. .
. .

34
34
36

Chapter 6. Using the Setup Utility

program . . . . . . . . . . . . . . . .

37

Starting the Setup Utility program . . . . .

Viewing or changing settings . . . . . . .
Using passwords. . . . . . . . . . . .
Password considerations . . . . . . .
Administrator password . . . . . . .
Power-on password . . . . . . . . .
Hard disk drive password . . . . . .
Setting, changing, or deleting a password
Enabling or disabling a device . . . . . .
Selecting a startup device . . . . . . . .
Selecting a temporary startup device . .

Copyright Lenovo 2010, 2011

.
.
.
.
.
.
.
.
.
.
.

.
.
.
.
.
.
.
.
.
.
.

37
37
37
38
38
38
38
38
39
39
39

Viewing or changing the startup device

sequence . . . . . . . . . . . . . . .
Exiting the Setup Utility program . . . . . . .

40
40

Chapter 7. Symptom-to-FRU Index .

41

Hard disk drive boot error . .

Power Supply Problems . . .
Diagnostic error codes . . .
Beep symptoms . . . . . .
POST error codes . . . . .
Miscellaneous error conditions
Undetermined problems . . .

.
.
.
.
.
.
.

.
.
.
.
.
.
.

.
.
.
.
.
.
.

.
.
.
.
.
.
.

.
.
.
.
.
.
.

.
.
.
.
.
.
.

.
.
.
.
.
.
.

.
.
.
.
.
.
.

41
41
42
59
59
60
62

Chapter 8. Replacing FRUs. . . . . .

63

Locating connectors, controls, and indicators on

the front of your computer . . . . . . . . . .
Using your computer in monitor mode . . .
Locating connectors and parts on the rear of your
computer . . . . . . . . . . . . . . . . .
FRU locations . . . . . . . . . . . . . . .
System board parts and connectors . . . . . .
Removing or reinstalling the frame stand . . . .
Removing the computer cover . . . . . . . .
Replacing the hard disk drive . . . . . . . . .
Replacing the optical drive . . . . . . . . . .
Replacing the right I/O assemblies . . . . . . .
Replacing the card reader . . . . . . . . . .
Replacing the inverter . . . . . . . . . . . .
Replacing the power supply . . . . . . . . .
Removing or reinstalling the wall mount . . . . .
Replacing the system fan . . . . . . . . . .
Replacing the microprocessor fan assembly . . .
Replacing the heat sink . . . . . . . . . . .
Replacing the microprocessor . . . . . . . .
Replacing the PS2 COM Port . . . . . . . . .
Installing or replacing a memory module . . . .
Replacing the battery . . . . . . . . . . . .
Replacing the WI-FI card. . . . . . . . . . .
Replacing the Bluetooth module. . . . . . . .
Replacing the multi-touch board. . . . . . . .
Replacing the ambient light sensor. . . . . . .
Replacing the internal speakers . . . . . . . .
Replacing the integrated camera with
microphone . . . . . . . . . . . . . . . .
Replacing the rear I/O assembly . . . . . . . .
Replacing the power switch module . . . . . .
Replacing the front panel control board . . . . .

64
65
66
67
69
70
71
72
74
75
77
78
79
80
82
84
85
87
90
91
93
94
95
96
97
99
100
102
103
105

iii

Replacing the system board . . . . . . . . .

Replacing the LCD panel. . . . . . . . . . .
Completing the parts replacement . . . . . . .

Chapter 9. FRU lists . . . . . . . .

Overall: MT 7570, 7577, 7578, 7580, 7583, 7584,
7589, 7594, 7595, 7597, and 7598 . . . . . . .
Mechanical FRUs . . . . . . . . . . . . .
Keyboard and Mouse . . . . . . . . . . . .
Adapters and miscellaneous FRUs . . . . . . .
Power Cords . . . . . . . . . . . . . . .
Recovery discs . . . . . . . . . . . . . .
Windows 7 Home Basic 32 Recovery CD . .
Windows 7 Home Premium 32 Recovery
CD . . . . . . . . . . . . . . . . .
Windows 7 Professional 32 Recovery CD . .
Windows 7 Professional 64 Recovery CD . .
Windows XP Professional 32 Recovery CD . .
Windows 7 Starter 32 Recovery CD . . . .
Windows 7 Ultimate 32 Recovery CD . . . .

Chapter 10. Additional Service

Information . . . . . . . . . . . . .

iv

ThinkCentre Hardware Maintenance Manual

106
109
111

113
113
131
137
169
170
178
178
179
181
183
189
189
191

193

Security features . . . . . . . . . . . . .
Hardware controlled Passwords . . . . .
Operating system password . . . . . .
Vital product data. . . . . . . . . . .
BIOS levels . . . . . . . . . . . . . . .
Flash update procedures . . . . . . . . .
Updating (flashing) the BIOS from a disc . . .
Updating (flashing) the BIOS from your operating
system . . . . . . . . . . . . . . . . .
Recovering from a POST/BIOS update failure .
Power management . . . . . . . . . . .
Automatic configuration and power interface
(ACPI) BIOS . . . . . . . . . . . . .
Automatic Power-On features . . . . . .

.
.
.
.
.
.
.

193
193
193
193
193
193
193

.
.
.

194
194
195

.
.

195
195

Appendix A. Notices . . . . . . . .
Television output notice . . . . . . . . . . .
European conformance CE mark . . . . . . .
Trademarks . . . . . . . . . . . . . . . .

Index. . . . . . . . . . . . . . . . .

197
198
198
198

199

Chapter 1. About this manual

This manual contains service and reference information for ThinkCentre computers listed on the cover. It is
intended only for trained servicers who are familiar with Lenovo computer products.
Before servicing a Lenovo product, be sure to read the Safety Information in Chapter 2 Safety information
on page 3.
The Symptom-to-FRU Index and Additional Service Information chapters are not specific to any machine
type and are applicable to all ThinkCentre computers.
This manual includes a complete FRU part number listing for each machine type and model listed on the
cover. If you have Internet access, FRU part numbers are also available at:
http:/www.lenovo.com/support

Important Safety Information

Be sure to read all caution and danger statements in this book before performing any of the instructions.
Veuillez lire toutes les consignes de type DANGER et ATTENTION du prsent document avant d'excuter
les instructions.
Lesen Sie unbedingt alle Hinweise vom Typ "ACHTUNG" oder "VORSICHT" in dieser Dokumentation, bevor
Sie irgendwelche Vorgnge durchfhren
Leggere le istruzioni introdotte da ATTENZIONE e PERICOLO presenti nel manuale prima di eseguire una
qualsiasi delle istruzioni
Certifique-se de ler todas as instrues de cuidado e perigo neste manual antes de executar qualquer
uma das instrues
Es importante que lea todas las declaraciones de precaucin y de peligro de este manual antes de seguir
las instrucciones.

Important information about replacing RoHS compliant FRUs

RoHS, The Restriction of Hazardous Substances in Electrical and Electronic Equipment Directive
(2002/95/EC) is a European Union legal requirement affecting the global electronics industry. RoHS
requirements must be implemented on Lenovo products placed on the market and sold in the
European Union after June 2006. Products on the market before June 2006 are not required to
have RoHS compliant parts. If the parts are not compliant originally, replacement parts can also

Copyright Lenovo 2010, 2011

be noncompliant, but in all cases, if the parts are compliant, the replacement parts must also be
compliant.
Note: RoHS and non-RoHS FRU part numbers with the same fit and function are identified with unique
FRU part numbers.
Lenovo plans to transition to RoHS compliance well before the implementation date and expects its suppliers
to be ready to support Lenovo's requirements and schedule in the EU. Products sold in 2005 will contain
some RoHS compliant FRUs. The following statement pertains to these products and any product Lenovo
produces containing RoHS compliant parts.
RoHS compliant ThinkCentre parts have unique FRU part numbers. Before or after June 2006, failed RoHS
compliant parts must always be replaced using RoHS compliant FRUs, so only the FRUs identified as
compliant in the system hardware maintenance manual or direct substitutions for those FRUs can be used.
Products marketed before June 2006

Products marketed after June 2006

Current or original part

Replacement FRU

Current or original part

Replacement FRU

Non-RoHS

Can be Non-RoHS

Must be RoHS

Must be RoHS

Non-RoHS

Can be RoHS

Non-RoHS

Can sub to RoHS

RoHS

Must be RoHS

Note: A direct substitution is a part with a different FRU part number that is automatically shipped by the
distribution center at the time of order.

ThinkCentre Hardware Maintenance Manual

Chapter 2. Safety information

This chapter contains the safety information that you need to be familiar with before servicing a computer.

General safety
Follow these rules to ensure general safety:
Observe good housekeeping in the area of the machines during and after maintenance.
When lifting any heavy object:
1. Ensure you can stand safely without slipping.
2. Distribute the weight of the object equally between your feet.
3. Use a slow lifting force. Never move suddenly or twist when you attempt to lift.
4. Lift by standing or by pushing up with your leg muscles; this action removes the strain from the
muscles in your back.
Do not attempt to lift any objects that weigh more than 16 kg (35 lb) or objects that you think are
too heavy for you.
Do not perform any action that causes hazards to the customer, or that makes the equipment unsafe.
Before you start the machine, ensure that other service representatives and the customer's personnel are
not in a hazardous position.
Place removed covers and other parts in a safe place, away from all personnel, while you are servicing
the machine.
Keep your tool case away from walk areas so that other people will not trip over it.
Do not wear loose clothing that can be trapped in the moving parts of a machine. Ensure that your sleeves
are fastened or rolled up above your elbows. If your hair is long, fasten it.
Insert the ends of your necktie or scarf inside clothing or fasten it with a nonconductive clip, approximately
8 centimeters (3 inches) from the end.
Do not wear jewelry, chains, metal-frame eyeglasses, or metal fasteners for your clothing.
Remember: Metal objects are good electrical conductors.
Wear safety glasses when you are: hammering, drilling, soldering, cutting wire, attaching springs, using
solvents, or working in any other conditions that might be hazardous to your eyes.
After service, reinstall all safety shields, guards, labels, and ground wires. Replace any safety device
that is worn or defective.
Reinstall all covers correctly before returning the machine to the customer.

Electrical safety

CAUTION:
Electrical current from power, telephone, and communication cables can be hazardous. To avoid
personal injury or equipment damage, disconnect the attached power cords, telecommunication
systems, networks, and modems before you open the computer covers, unless instructed otherwise
in the installation and configuration procedures.
Observe the following rules when working on electrical equipment.
Copyright Lenovo 2010, 2011

Important: Use only approved tools and test equipment. Some hand tools have handles covered with a soft
material that does not insulate you when working with live electrical currents. Many customers have, near
their equipment, rubber floor mats that contain small conductive fibers to decrease electrostatic discharges.
Do not use this type of mat to protect yourself from electrical shock.
Find the room emergency power-off (EPO) switch, disconnecting switch, or electrical outlet. If an electrical
accident occurs, you can then operate the switch or unplug the power cord quickly.
Do not work alone under hazardous conditions or near equipment that has hazardous voltages.
Disconnect all power before:
Performing a mechanical inspection
Working near power supplies
Removing or installing Field Replaceable Units (FRUs)
Before you start to work on the machine, unplug the power cord. If you cannot unplug it, ask the customer
to power-off the wall box that supplies power to the machine and to lock the wall box in the off position.
If you need to work on a machine that has exposed electrical circuits, observe the following precautions:
Ensure that another person, familiar with the power-off controls, is near you.
Remember: Another person must be there to switch off the power, if necessary.
Use only one hand when working with powered-on electrical equipment; keep the other hand in your
pocket or behind your back.
Remember: There must be a complete circuit to cause electrical shock. By observing the above rule,
you may prevent a current from passing through your body.
When using a tester, set the controls correctly and use the approved probe leads and accessories for
that tester.
Stand on suitable rubber mats (obtained locally, if necessary) to insulate you from grounds such as
metal floor strips and machine frames.
Observe the special safety precautions when you work with very high voltages; these instructions are in
the safety sections of maintenance information. Use extreme care when measuring high voltages.
Regularly inspect and maintain your electrical hand tools for safe operational condition.
Do not use worn or broken tools and testers.
Never assume that power has been disconnected from a circuit. First, check that it has been powered-off.
Always look carefully for possible hazards in your work area. Examples of these hazards are moist floors,
nongrounded power extension cables, power surges, and missing safety grounds.
Do not touch live electrical circuits with the reflective surface of a plastic dental mirror. The surface is
conductive; such touching can cause personal injury and machine damage.
Do not service the following parts with the power on when they are removed from their normal operating
places in a machine:
Power supply units
Pumps
Blowers and fans
Motor generators
and similar units. (This practice ensures correct grounding of the units.)
If an electrical accident occurs:
Use caution; do not become a victim yourself.
Switch off power.
Send another person to get medical aid.

ThinkCentre Hardware Maintenance Manual

Safety inspection guide

The intent of this inspection guide is to assist you in identifying potentially unsafe conditions on these
products. Each machine, as it was designed and built, had required safety items installed to protect users
and service personnel from injury. This guide addresses only those items. However, good judgment should
be used to identify potential safety hazards due to attachment of features or options not covered by this
inspection guide.
If any unsafe conditions are present, you must determine how serious the apparent hazard could be and
whether you can continue without first correcting the problem.
Consider these conditions and the safety hazards they present:
Electrical hazards, especially primary power (primary voltage on the frame can cause serious or fatal
electrical shock).
Explosive hazards, such as a damaged CRT face or bulging capacitor
Mechanical hazards, such as loose or missing hardware
The guide consists of a series of steps presented in a checklist. Begin the checks with the power off, and
the power cord disconnected.
Checklist:
1. Check exterior covers for damage (loose, broken, or sharp edges).
2. Power-off the computer. Disconnect the power cord.
3. Check the power cord for:
a. A third-wire ground connector in good condition. Use a meter to measure third-wire ground
continuity for 0.1 ohm or less between the external ground pin and frame ground.
b. The power cord should be the appropriate type as specified in the parts listings.
c. Insulation must not be frayed or worn.
4. Remove the cover.
5. Check for any obvious alterations. Use good judgment as to the safety of any alterations.
6. Check inside the unit for any obvious unsafe conditions, such as metal filings, contamination, water or
other liquids, or signs of fire or smoke damage.
7. Check for worn, frayed, or pinched cables.
8. Check that the power-supply cover fasteners (screws or rivets) have not been removed or tampered with.

Handling electrostatic discharge-sensitive devices

Any computer part containing transistors or integrated circuits (ICs) should be considered sensitive to
electrostatic discharge (ESD). ESD damage can occur when there is a difference in charge between objects.
Protect against ESD damage by equalizing the charge so that the machine, the part, the work mat, and the
person handling the part are all at the same charge.
1. Use product-specific ESD procedures when they exceed the requirements noted here.
2. Make sure that the ESD protective devices you use have been certified (ISO 9000) as fully effective.
When handling ESD-sensitive parts:
Keep the parts in protective packages until they are inserted into the product.
Avoid contact with other people while handling the part.
Wear a grounded wrist strap against your skin to eliminate static on your body.
Chapter 2. Safety information

 Prevent the part from touching your clothing. Most clothing is insulative and retains a charge even when
you are wearing a wrist strap.
Use the black side of a grounded work mat to provide a static-free work surface. The mat is especially
useful when handling ESD-sensitive devices.
Select a grounding system, such as those listed below, to provide protection that meets the specific
service requirement.
Note: The use of a grounding system is desirable but not required to protect against ESD damage.
Attach the ESD ground clip to any frame ground, ground braid, or green-wire ground.
Use an ESD common ground or reference point when working on a double-insulated or
battery-operated system. You can use coax or connector-outside shells on these systems.
Use the round ground-prong of the ac plug on ac-operated computers.

Grounding requirements
Electrical grounding of the computer is required for operator safety and correct system function. Proper
grounding of the electrical outlet can be verified by a certified electrician.

Safety notices (multi-lingual translations)

The caution and danger safety notices in this section are provided in the following languages:
English
Arabic
Brazilian/Portuguese
Chinese (simplified)
Chinese (traditional)
French
German
Hebrew
Italian
Korean
Spanish

DANGER
Electrical current from power, telephone and communication cables is hazardous.
To avoid a shock hazard:
Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm.
Connect all power cords to a properly wired and grounded electrical outlet.
Connect to properly wired outlets any equipment that will be attached to this product.
When possible, use one hand only to connect or disconnect signal cables.
6

ThinkCentre Hardware Maintenance Manual

 Never turn on any equipment when there is evidence of fire, water, or structural damage.
Disconnect the attached power cords, telecommunications systems, networks, and modems
before you open the device covers, unless instructed otherwise in the installation and configuration
procedures.
Connect and disconnect cables as described in the following tables when installing, moving, or
opening covers on this product or attached devices.
To Connect

To Disconnect

1. Turn everything OFF.

1. Turn everything OFF.

2. First, attach all cables to devices.

2. First, remove power cords from outlet.

3. Attach signal cables to connectors.

3. Remove signal cables from connectors.

4. Attach power cords to outlet.

4. Remove all cables from devices.

5. Turn device ON.

CAUTION:
When replacing the lithium battery, use only Part Number 45C1566 or an equivalent type battery
recommended by the manufacturer. If your system has a module containing a lithium battery, replace
it only with the same module type made by the same manufacturer. The battery contains lithium and
can explode if not properly used, handled, or disposed of. Do not:
Throw or immerse into water
Heat to more than 100C (212F)
Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.

CAUTION:
When laser products (such as CD-ROMs, DVD-ROM drives, fiber optic devices, or transmitters) are
installed, note the following:
Do not remove the covers. Removing the covers of the laser product could result in exposure to
hazardous laser radiation. There are no serviceable parts inside the device.
Use of controls or adjustments or performance of procedures other than those specified herein
might result in hazardous radiation exposure.
DANGER
Some laser products contain an embedded Class 3A or Class 3B laser diode. Note the following:
Laser radiation when open. Do not stare into the beam, do not view directly with optical
instruments, and avoid direct exposure to the beam.

Chapter 2. Safety information

18 kg (37 lbs)

32 kg (70.5 lbs)

55 kg (121.2 lbs)

CAUTION:
Use safe practices when lifting.

CAUTION:
The power control button on the device and the power switch on the power supply do not turn off
the electrical current supplied to the device. The device also might have more than one power
cord. To remove all electrical current from the device, ensure that all power cords are disconnected
from the power source.

2
1

ThinkCentre Hardware Maintenance Manual

Chapter 2. Safety information

18 kg (37 lbs)

32 kg (70.5 lbs)

55 kg (121.2 lbs)

2
1

PERIGO

10

ThinkCentre Hardware Maintenance Manual

A corrente eltrica proveniente de cabos de alimentao, de telefone e de comunicaes perigosa.

Para evitar risco de choque eltrico:
No conecte nem desconecte nenhum cabo ou execute instalao, manuteno ou reconfigurao
deste produto durante uma tempestade com raios.
Conecte todos os cabos de alimentao a tomadas eltricas corretamente instaladas e aterradas.
Todo equipamento que for conectado a este produto deve ser conectado a tomadas corretamente
instaladas.
Quando possvel, utilize apenas uma das mos para conectar ou desconectar cabos de sinal.
Nunca ligue nenhum equipamento quando houver evidncia de fogo, gua ou danos estruturais.
Antes de abrir tampas de dispositivos, desconecte cabos de alimentao, sistemas de telecomunicao,
redes e modems conectados, a menos que especificado de maneira diferente nos procedimentos de
instalao e configurao.
Conecte e desconecte os cabos conforme descrito na tabela apresentada a seguir ao instalar, mover ou
abrir tampas deste produto ou de dispositivos conectados.
Para Conectar:

Para Desconectar:

1. DESLIGUE Tudo.

1. DESLIGUE Tudo.

2. Primeiramente, conecte todos os cabos aos

dispositivos.

2. Primeiramente, remova os cabos de alimentao das

tomadas.

3. Conecte os cabos de sinal aos conectores.

3. Remova os cabos de sinal dos conectores.

4. Conecte os cabos de alimentao s tomadas.

4. Remova todos os cabos dos dispositivos.

5. LIGUE os dispositivos.

CUIDADO:
Ao substituir a bateria de ltio, utilize apenas uma bateria com Nmero de Pea 45C1566 ou um tipo
de bateria equivalente recomendado pelo Se o seu sistema possui um mdulo com uma bateria de
ltio, substitua-o apenas por um mdulo do mesmo tipo e do mesmo fabricante. A bateria contm ltio
e pode explodir se no for utilizada, manuseada ou descartada de maneira correta.
No:
Jogue ou coloque na gua
Aquea a mais de 100C (212F)
Conserte nem desmonte
Descarte a bateria conforme requerido pelas leis ou regulamentos locais.

PRECAUCIN:
Quando produtos a laser (como unidades de CD-ROMs, unidades de DVD-ROM, dispositivos de fibra tica
ou transmissores) estiverem instalados, observe o seguinte:

Chapter 2. Safety information

11

 No remova as tampas. A remoo das tampas de um produto a laser pode resultar em exposio
prejudicial radiao de laser. No existem peas que podem ser consertadas no interior do dispositivo.
A utilizao de controles ou ajustes ou a execuo de procedimentos diferentes dos especificados aqui
pode resultar em exposio prejudicial radiao.
PERIGO
Alguns produtos a laser contm diodo de laser integrado da Classe 3A ou da Classe 3B. Observe o seguinte:
Radiao a laser quando aberto. No olhe diretamente para o feixe a olho nu ou com instrumentos pticos e
evite exposio direta ao feixe.

18 kg (37 lbs)

32 kg (70.5 lbs)

55 kg (121.2 lbs)

CUIDADO:
Utilize procedimentos de segurana para levantar equipamentos.

CUIDADO:
O boto de controle de alimentao do dispositivo e o boto para ligar/desligar da fonte de alimentao
no desligam a corrente eltrica fornecida ao dispositivo. O dispositivo tambm pode ter mais de um cabo
de alimentao. Para remover toda a corrente eltrica do dispositivo, assegure que todos os cabos de
alimentao estejam desconectados da fonte de alimentao.

2
1

12

ThinkCentre Hardware Maintenance Manual

Chapter 2. Safety information

13

2
1

14

ThinkCentre Hardware Maintenance Manual

Chapter 2. Safety information

15

2
1

DANGER
Le courant lectrique provenant de l'alimentation, du tlphone et des cbles de transmission peut prsenter
un danger.
Pour viter tout risque de choc lectrique :
Ne manipulez aucun cble et n'effectuez aucune opration d'installation, d'entretien ou de reconfiguration
de ce produit au cours d'un orage.
Branchez tous les cordons d'alimentation sur un socle de prise de courant correctement cbl et mis la
terre.
Branchez sur des socles de prise de courant correctement cbls tout quipement connect ce produit.
Lorsque cela est possible, n'utilisez qu'une seule main pour connecter ou dconnecter les cbles
d'interface.
Ne mettez jamais un quipement sous tension en cas d'incendie ou d'inondation, ou en prsence de
dommages matriels.
Avant de retirer les carters de l'unit, mettez celle-ci hors tension et dconnectez ses cordons
d'alimentation, ainsi que les cbles qui la relient aux rseaux, aux systmes de tlcommunication et aux
modems (sauf instruction contraire mentionne dans les procdures d'installation et de configuration).
Lorsque vous installez, que vous dplacez, ou que vous manipulez le prsent produit ou des priphriques
qui lui sont raccords, reportez-vous aux instructions ci-dessous pour connecter et dconnecter les
diffrents cordons.

16

ThinkCentre Hardware Maintenance Manual

Connexion

Dconnexion

1. Mettez les units HORS TENSION.

1. Mettez les units HORS TENSION.

2. Commencez par brancher tous les cordons sur les

units.

2. Dbranchez les cordons d'alimentation des prises.

3. Branchez les cbles d'interface sur des connecteurs.

4. Dbranchez tous les cbles des units.

3. Dbranchez les cbles d'interface des connecteurs.

4. Branchez les cordons d'alimentation sur des prises.

5. Mettez les units SOUS TENSION.

ATTENTION:
Remplacer la pile au lithium usage par une pile de rfrence identique exclusivement, (rfrence
45C1566), ou suivre les instructions du fabricant qui en dfinit les quivalences. Si votre systme est
dot d'un module contenant une pile au lithium, vous devez le remplacer uniquement par un module
identique, produit par le mme fabricant. La pile contient du lithium et peut exploser en cas de
mauvaise utilisation, de mauvaise manipulation ou de mise au rebut inapproprie.
Ne pas :
la jeter l'eau,
l'exposer des tempratures suprieures 100C,
chercher la rparer ou la dmonter.
Ne pas mettre la pile la poubelle. Pour la mise au rebut, se reporter la rglementation en vigueur.

ATTENTION:
Si des produits laser (tels que des units de CD-ROM, de DVD-ROM, des units fibres optiques, ou
des metteurs) sont installs, prenez connaissance des informations suivantes :
Ne retirez pas le carter. En ouvrant l'unit de CD-ROM ou de DVD-ROM, vous vous exposez au
rayonnement dangereux du laser. Aucune pice de l'unit n'est rparable.
Pour viter tout risque d'exposition au rayon laser, respectez les consignes de rglage et
d'utilisation des commandes, ainsi que les procdures dcrites dans le prsent manuel.

DANGER
Certains produits laser contiennent une diode laser intgre de classe 3A ou 3B. Prenez
connaissance des informations suivantes:
Rayonnement laser lorsque le carter est ouvert. Evitez toute expositiondirecte au rayon laser. Evitez
de regarder fixement le faisceau ou del'observer l'aide d'instruments optiques.

Chapter 2. Safety information

17

18 kg (37 lbs)

32 kg (70.5 lbs)

55 kg (121.2 lbs)

ATTENTION:
Soulevez la machine avec prcaution.

ATTENTION:
L'interrupteur de contrle d'alimentation de l'unit et l'interrupteur dubloc d'alimentation ne coupent
pas le courant lectrique alimentantl'unit. En outre, le systme peut tre quip de plusieurs
cordonsd'alimentation. Pour mettre l'unit hors tension, vous devez dconnectertous les cordons
de la source d'alimentation.

2
1

VORSICHT
An Netz-, Telefon- und Datenleitungen knnen gefhrliche Spannungen anliegen.
Aus Sicherheitsgrnden:
Bei Gewitter an diesem Gert keine Kabel anschlieen oder lsen. Ferner keine Installations-,
Wartungs- oder Rekonfigurationsarbeiten durchfhren.
Gert nur an eine Schutzkontaktsteckdose mit ordnungsgem geerdetem Schutzkontakt
anschlieen.
Alle angeschlossenen Gerte ebenfalls an Schutzkontaktsteckdosen mit ordnungsgem
geerdetem Schutzkontakt anschlieen.
Die Signalkabel nach Mglichkeit einhndig anschlieen oder lsen, um einen Stromschlag durch
Berhren von Oberflchen mit unterschiedlichem elektrischem Potenzial zu vermeiden.
Gerte niemals einschalten, wenn Hinweise auf Feuer, Wasser oder Gebudeschden vorliegen.

18

ThinkCentre Hardware Maintenance Manual

 Die Verbindung zu den angeschlossenen Netzkabeln, Telekommunikationssystemen, Netzwerken

und Modems ist vor dem ffnen des Gehuses zu unterbrechen, sofern in den Installations- und
Konfigurationsprozeduren keine anders lautenden Anweisungen enthalten sind.
Zum Installieren, Transportieren und ffnen der Abdeckungen des Computers oder der
angeschlossenen Einheiten die Kabel gem der folgenden Tabelle anschlieen und abziehen.
Zum Anschlieen der Kabel gehen Sie wie folgt vor

Zum Abziehen der Kabel gehen Sie wie folgt vor

1. Schalten Sie alle Einheiten AUS.

1. Schalten Sie alle Einheiten AUS.

2. Schlieen Sie erst alle Kabel an die Einheiten an.

3. Schlieen Sie die Signalkabel an die Buchsen an.

2. Ziehen Sie zuerst alle Netzkabel aus den

Netzsteckdosen.

4. Schlieen Sie die Netzkabel an die Steckdose an.

3. Ziehen Sie die Signalkabel aus den Buchsen.

5. Schalten Sie die Einheit EIN.

4. Ziehen Sie alle Kabel von den Einheiten ab.

CAUTION:
Eine verbrauchte Lithiumbatterie nur durch eine Batterie mit der Teilenummer 45C1566 oder eine
gleichwertige, vom Hersteller empfohlene Batterie ersetzen. Enthlt das System ein Modul mit einer
Lithiumbatterie, dieses nur durch ein Modul desselben Typs und von demselben Hersteller ersetzen.
Die Batterie enthlt Lithium und kann bei unsachgemer Verwendung, Handhabung oder Entsorgung
explodieren.
Die Batterie nicht:
mit Wasser in Berhrung bringen.
ber 100 C erhitzen.
reparieren oder zerlegen.
Die rtlichen Bestimmungen fr die Entsorgung von Sondermll beachten.

ACHTUNG:
Bei der Installation von Lasergerten (wie CD-ROM-Laufwerken, DVD- aufwerken, Einheiten mit
Lichtwellenleitertechnik oder Sendern) Folgendes beachten:
Die Abdeckungen nicht entfernen. Durch Entfernen der Abdeckungen des Lasergerts knnen
gefhrliche Laserstrahlungen freigesetzt werden. Das Gert enthlt keine zu wartenden Teile.
Werden Steuerelemente, Einstellungen oder Durchfhrungen von Prozeduren anders als hier
angegeben verwendet, kann gefhrliche Laserstrahlung auftreten.

VORSICHT
Einige Lasergerte enthalten eine Laserdiode der Klasse 3A oder 3B. Beachten Sie Folgendes:

Chapter 2. Safety information

19

Laserstrahlung bei geffneter Verkleidung. Nicht in den Strahl blicken. Keine Lupen oder Spiegel
verwenden. Strahlungsbereich meiden.

18 kg

32 kg

55 kg

ACHTUNG:
Arbeitsschutzrichtlinien beim Anheben der Maschine beachten.

ACHTUNG:
Mit dem Netzschalter an der Einheit und am Netzteil wird die Stromversorgung fr die Einheit
nicht unterbrochen. Die Einheit kann auch mit mehreren Netzkabeln ausgestattet sein. Um die
Stromversorgung fr die Einheit vollstndig zu unterbrechen, mssen alle zum Gert fhrenden
Netzkabel vom Netz getrennt werden.

2
1

20

ThinkCentre Hardware Maintenance Manual

Chapter 2. Safety information

21

2
1

PERICOLO
La corrente elettrica proveniente dai cavi di alimentazione, del telefono e di comunicazione pu essere
pericolosa.
Per evitare il rischio di scosse elettriche:
Non collegare o scollegare qualsiasi cavo oppure effettuare l'installazione, la manutenzione o la
riconfigurazione del prodotto durante un temporale.
Collegare tutti i fili elettrici a una presa di alimentazione correttamente cablata e dotata di messa a
terra.
Collegare alle prese elettriche appropriate tutte le apparecchiature che verranno utilizzate per
questo prodotto.

22

ThinkCentre Hardware Maintenance Manual

 Se possibile, utilizzare solo una mano per collegare o scollegare i cavi di segnale.
Non accendere assolutamente apparecchiature in presenza di incendi, perdite d'acqua o danno
strutturale.
Scollegare i cavi di alimentazione, i sistemi di telecomunicazione, le reti e il modem prima di
aprire i coperchi del dispositivo, salvo istruzioni contrarie relative alle procedure di installazione e
configurazione.
Collegare e scollegare i cavi come descritto nella seguente tabella quando vengono effettuate
operazioni di installazione, spostamento o apertura dei coperchi di questo prodotto o delle unit
collegate.
Per collegarsi

Per scollegarsi

1. SPEGNERE le apparecchiature.

1. SPEGNERE le apparecchiature.

2. Innanzitutto, collegare tutti i cavi alle unit.

3. Collegare i cavi di segnale ai connettori.

2. Innanzitutto, rimuovere i cavi di alimentazione dalla

presa.

4. Collegare i cavi di alimentazione alla presa.

3. Rimuovere i cavi di segnale dai connettori.

5. Accendere l'unit.

4. Rimuovere tutti i cavi dalle unit.

ATTENZIONE:
Quando si sostituisce la batteria al litio, utilizzare solo il Numero parte 45C1566 o un tipo di batteria
equivalente consigliato dal produttore. Se sul sistema presente un modulo che contiene una batteria
al litio, sostituirlo solo con un tipo di modulo dello stesso tipo della stessa casa di produzione. La
batteria contiene litio e pu esplodere se usata, maneggiata o smaltita in modo non corretto.
Non:
Gettare o immergere la batteria nell'acqua
Riscaldarla ad una temperatura superiore ai 100 gradi C (212 gradi F)
Smontarla, ricaricarla o tentare di ripararla
Le batterie usate vanno smaltite in accordo alla normativa in vigore (DPR 915/82 e successive
disposizioni e disposizioni locali).

ATTENZIONE:
Quando vengono installati prodotti laser (quali CD-ROM, unit DVD-ROM, unit a fibre ottiche o
trasmittenti), tener presente quanto segue:
Non rimuovere gli sportelli. L'apertura di un'unit laser pu determinare l'esposizione a radiazioni
laser pericolose. All'interno dell'unit non vi sono parti su cui effettuare l'assistenza tecnica.
L'utilizzo di controlli, regolazioni o l'esecuzione di procedure non descritti nel presente manuale
possono provocare l'esposizione a radiazioni pericolose.

Chapter 2. Safety information

23

PERICOLO
Alcune unit laser contengono un diodo laser di Classe 3A o Classe 3B. Tener presente quanto segue:
Aprendo l'unit vengono emesse radiazioni laser. Non fissare il fascio, non guardarlo direttamente
con strumenti ottici ed evitare l'esposizione al fascio.

18 kg

32 kg

55 kg

ATTENZIONE:
Prestare attenzione nel sollevare l'apparecchiatura.

ATTENZIONE:
Il pulsante di controllo dell'alimentazione presente sull'unit e l'interruttore dell'alimentatore non
disattivano l'alimentazione corrente fornita all'unit. E' possibile che l'unit disponga di pi cavi di
alimentazione. Per disattivare l'alimentazione dall'unit, accertarsi che tutti i cavi di alimentazione
siano scollegati dalla fonte di alimentazione.

2
1

24

ThinkCentre Hardware Maintenance Manual

Chapter 2. Safety information

25

2
1

PELIGRO
La corriente elctrica procedente de cables de alimentacin, telfonos y cables de comunicacin puede
ser peligrosa.
Para evitar el riesgo de descarga elctrica:
No conecte ni desconecte los cables ni realice ninguna tarea de instalacin, mantenimiento o
reconfiguracin de este producto durante una tormenta elctrica.
Conecte todos los cables de alimentacin a tomas de corriente debidamente cableadas y
conectadas a tierra.
Cualquier equipo que se conecte a este producto tambin debe conectarse a tomas de corriente
debidamente cableadas.
Siempre que sea posible, utilice una sola mano para conectar o desconectar los cables de seal.
No encienda nunca un equipo cuando hay seales de fuego, agua o daos estructurales.

26

ThinkCentre Hardware Maintenance Manual

 Desconecte los cables de alimentacin, los sistemas de telecomunicaciones, las redes y los
mdems conectados antes de abrir las cubiertas de los dispositivos, a menos que se indique lo
contrario en los procedimientos de instalacin y configuracin.
Conecte y desconecte los cables, como se describe en la tabla siguiente, cuando instale, mueva o
abra las cubiertas de este producto o de los dispositivos conectados.
Para conectar

Para desconectar

1. APGUELO todo.

1. APGUELO todo.

2. En primer lugar, conecte todos los cables a los

dispositivos.

2. En primer lugar, desenchufe los cables de alimentacin

de las tomas de corriente.

3. Conecte los cables de seal a los conectores.

3. Desconecte los cables de seal de los conectores.

4. Enchufe los cables de alimentacin a las tomas de

corriente.

4. Desconecte todos los cables de los dispositivos.

5. Encienda el dispositivo.

PRECAUCIN:
Cuando sustituya una batera de litio, utilice solamente una batera nmero de pieza 45C1566 u otra
de tipo equivalente recomendada por el fabricante. Si su sistema dispone de un mdulo que contiene
una batera de litio, reemplcelo slo con el mismo tipo de mdulo, del mismo fabricante. La batera
contiene litio y puede explotar si no se utiliza, manipula o desecha correctamente.
No debe:
Arrojarla al agua o sumergirla en ella
Exponerla a temperaturas superiores a 100C (212F)
Repararla o desmontarla
Deshgase de la batera segn especifiquen las leyes o normas locales.

PRECAUCIN:
Cuando haya productos lser (como unidades de CD-ROM, unidades de DVD, dispositivos de fibra
ptica o transmisores) instalados, tenga en cuenta lo siguiente:
No quite las cubiertas. Si quita las cubiertas del producto lser, podra quedar expuesto a radiacin
lser peligrosa. Dentro del dispositivo no existe ninguna pieza que requiera servicio tcnico.
Si usa controles o ajustes o realiza procedimientos que no sean los especificados aqu, podra
exponerse a radiaciones peligrosas.

PELIGRO

Chapter 2. Safety information

27

Algunos productos lser tienen incorporado un diodo lser de clase 3A o clase 3B. Tenga en cuenta lo
siguiente:
Cuando se abre, queda expuesto a radiacin lser. No mire directamente al rayo lser, ni siquiera con
instrumentos pticos, y evite exponerse directamente al rayo lser.

18 kg

32 kg

55 kg

PRECAUCIN:
Adopte procedimientos seguros al levantar el equipo.

PRECAUCIN:
El botn de control de alimentacin del dispositivo y el interruptor de alimentacin de la fuente de
alimentacin no desconectan la corriente elctrica suministrada al dispositivo. Adems, el dispositivo
podra tener ms de un cable de alimentacin. Para suprimir toda la corriente elctrica del dispositivo,
asegrese de que todos los cables de alimentacin estn desconectados de la toma de corriente.

2
1

28

ThinkCentre Hardware Maintenance Manual

Chapter 3. General information

This chapter provides general information that applies to all machine types supported by this publication.

Lenovo ThinkVantage Tools

The Lenovo ThinkVantage Tools program guides you to a host of information sources and provides easy
access to various tools to help you work more easily and securely.
Note: The Lenovo ThinkVantage Tools program is only available on computers with the Windows 7 operating
system from Lenovo.

Lenovo Welcome
The Lenovo Welcome program introduces some innovative built-in features of Lenovo to you and guides you
through some important setup tasks to help you make the most of your computer.
Note: The Lenovo Welcome program is only available on computers preinstalled with the Windows 7
operating system from Lenovo.

Lenovo ThinkVantage Toolbox

The Lenovo ThinkVantage Toolbox program helps you maintain your computer, improve computing security,
diagnose computer problems, get familiar with the innovative technologies provided by Lenovo, and get more
information about your computer. For more information, see Lenovo ThinkVantage Toolbox on page 33.

Additional information resources

If you have Internet access, the most up-to-date information for your computer is available from the World
Wide Web.
You can find the following information:
CRU removal and installation instructions
Publications
Troubleshooting information
Parts information
Downloads and drivers
Links to other useful sources of information
To access this information, go to:
http://www.lenovo.com/support

Specifications
This section lists the physical specifications for your computer.

Copyright Lenovo 2010, 2011

29

Computer dimensions (with a stand and frame foot)

Width: 560 mm (22.05 inches)
Maximum height:
421.9 mm (16.61 inches) (with a frame stand and frame foot)
566.9 mm (22.32 inches) (with a lift stand)
Depth: ranges from 109 mm (4.29 inches) to 250 mm (9.84 inches) (varies by configuration)
Touch screen dimensions
Width: 531.4 mm (20.92 inches)
Height: 311.6 mm (12.27 inches)
Depth: 2 mm (0.08 inch)
Computer weight
Maximum configuration as shipped: 14.1 kg (31.09 lbs)
Lift stand
Height adjustment: 110 mm (4.33 inches)
Tilt adjustment: -5 degrees to 25 degrees from the vertical
Frame stand
Tilt adjustment: 15 degrees to 45 degrees from the vertical
Environment
Air temperature:
Operating: 10 to 35 (50 to 95)
Non-operating: -20 to 60 (-4 to 140) (with package)
Humidity:
Operating: 20% to 80% (10% per hour, non-condensing)
Non-operating: 20% to 80% (10% per hour, non-condensing)
Altitude:
Operating: -50 to 10 000 ft (-15.2 to 3 048 m)
Non-operating: -50 to 35 000 ft (-15.2 to 10 668 m)
Electrical input
Input voltage:
Low range:
Minimum: 100 V ac
Maximum: 127 V ac
Input frequency range: 50 to 60 Hz
Voltage-selection switch setting: 115 V ac
High range:
Minimum: 200 V ac
Maximum: 240 V ac
Input frequency range: 50 to 60 Hz
Voltage-selection switch setting: 230 V ac

30

ThinkCentre Hardware Maintenance Manual

Chapter 4. General Checkout

Attention
The drives in the computer you are servicing might have been rearranged or the drive startup sequence
changed. Be extremely careful during write operations such as copying, saving, or formatting. Data or
programs can be overwritten if you select an incorrect drive.
General error messages appear if a problem or conflict is found by an application program, the operating
system, or both. For an explanation of these messages, refer to the information supplied with that software
package.
Before replacing any FRUs, ensure that the latest level of BIOS is installed on the system. A down-level BIOS
might cause false errors and unnecessary replacement of the system board. For more information on how to
determine and obtain the latest level BIOS, see BIOS levels on page 193.
Use the following procedure to help determine the cause of the problem:
1. Power-off the computer and all external devices.
2. Check all cables and power cords.
3. Set all display controls to the middle position.
4. Power-on all external devices.
5. Power-on the computer.
Look for displayed error codes
Listen for beep codes
Look for readable instructions or a main menu on the display.
If you did not receive the correct response, proceed to step 6 on page 31.
If you do receive the correct response, proceed to step 7 on page 31.
6. Look at the following conditions and follow the instructions:
If you hear beep codes during POST, go to Beep symptoms on page 59.
If the computer displays a POST error, go to POST error codes on page 59.
If the computer hangs and no error is displayed, continue at step 7 on page 31.
7. Run the Diagnostic programs. See Chapter 5 Diagnostics on page 33.
If you receive an error, replace the part that the diagnostic program calls out or go to Diagnostic
error codes on page 42.
If the test stops and you cannot continue, replace the last device tested.

Problem determination tips

Due to the variety of hardware and software combinations that can be encountered, use the following
information to assist you in problem determination. If possible, have this information available when
requesting assistance from Service Support and Engineering functions.
Machine type and model
Processor or hard disk drive upgrades
Failure symptom
Do diagnostics indicate a failure?
What, when, where, single, or multiple systems?
Is the failure repeatable?
Copyright Lenovo 2010, 2011

31

 Has this configuration ever worked?

If it has been working, what changes were made prior to it failing?
Is this the original reported failure?
Diagnostics version
Type and version level
Hardware configuration
Print (print screen) configuration currently in use
BIOS level
Operating system software
Type and version level
Notes: To eliminate confusion, identical systems are considered identical only if they:
1. Are the exact machine type and models
2. Have the same BIOS level
3. Have the same adapters/attachments in the same locations
4. Have the same address jumpers/terminators/cabling
5. Have the same software versions and levels
6. Have the same Diagnostic Diskettes (version)
7. Have the same configuration options set in the system
8. Have the same setup for the operating system control files
Comparing the configuration and software set-up between working and non-working systems will often
lead to problem resolution.

32

ThinkCentre Hardware Maintenance Manual

Chapter 5. Diagnostics
Diagnostic programs are used to test hardware components of your computer. Diagnostic programs can
also report operating-system-controlled settings that interfere with the correct operation of your system.
There are two programs preinstalled on your computer to help you diagnose computer problems:
Lenovo ThinkVantage Toolbox (used when you are running the Windows operating system)
PC-Doctor for Rescue and Recovery (used when you cannot start the Windows operating system)
Notes:
1. You can also download the PC-Doctor for DOS diagnostic program from
http://www.lenovo.com/support. See PC-Doctor for DOS on page 33 for detailed information.
2. If you are unable to isolate and repair the problem yourself after running the programs, save and print
the log files created by the programs. You will need the log files when you speak to a Lenovo technical
support representative.

Lenovo ThinkVantage Toolbox

The Lenovo ThinkVantage Toolbox program helps you maintain your computer, improve computing security,
diagnose computer problems, get familiar with the innovative technologies provided by Lenovo, and get
more information about your computer. You can use the diagnostics feature of the Lenovo ThinkVantage
Toolbox program to test devices, diagnose computer problems, create bootable diagnostic media, update
system drivers, and view system information.
To run the Lenovo ThinkVantage Toolbox program on the Windows 7 operating system, click Start All
Programs Lenovo ThinkVantage Tools System Health and Diagnostics. Follow the instructions on
the screen.
For additional information about running the Lenovo ThinkVantage Toolbox program, refer to the Lenovo
ThinkVantage Toolbox help system.

PC-Doctor for DOS

You can also download the latest version of the PC-Doctor for DOS diagnostic program from
http://www.lenovo.com/support. The PC-Doctor for DOS diagnostic program runs independently of the
Windows operating system. Use the PC-Doctor for DOS diagnostic program if you are unable to start the
Windows operating system. You can run the PC-Doctor for DOS diagnostic program from a diagnostic
disc that you created.

Creating a diagnostic disc

This section provides instructions on how to create a diagnostic disc.
To create a diagnostic disc, do the following:
1. Download a self-starting bootable disc image (known as an ISO image) of the diagnostic program from:
http://www.lenovo.com/support
2. Use any disc burning software to create a diagnostic disc with the ISO image.

Copyright Lenovo 2010, 2011

33

Running the diagnostic program from the diagnostic disc

This section provides instructions on how to run the diagnostic program from the diagnostic disc that
you created.
To run the diagnostic program from the diagnostic disc that you created, do the following:
1. Make sure your computer is turned off.
2. Repeatedly press and release the F12 key when turning on the computer. When the Startup Device
Menu opens, release the F12 key.
3. Insert the diagnostic disc into the optical drive.
4. Select the optical drive with the diagnostic disc as the startup device and press Enter. The diagnostic
program opens.
5. Follow the instructions on the screen to run the desired diagnostic test. For additional help, press
the F1 key.
6. Remove the diagnostic disc from the optical drive after completing the diagnostic test.

Navigating through the diagnostics programs

Use the cursor movement keys to navigate within the menus.
The Enter key is used to select a menu item.
The Esc key is used to back up to the previous menu.
For online help, select F1.

Running tests
There are four ways to run the diagnostic tests.
Using the cursor movement keys, highlight Run Normal Test or Run Quick Test from the Diagnostics
menu and then press Enter. This automatically runs a pre-defined group of tests from each test category.
Run Normal Test runs a more extensive set of tests than does Run Quick Test and takes longer to
complete.
Press F5 to automatically run all selected tests in all categories.
From within a test category, press Ctrl-Enter to automatically run only the selected tests in that category.
Using the cursor movement keys, highlight a single test within a test category, and then press Enter.
This runs only that test.
Press Esc at any time to stop the testing process.
Test results (N/A, PASSED, FAILED, ABORTED) are displayed in the field beside the test description and in
the test log. See Viewing the test log on page 36.
To select one or more tests, use the following procedure.
1. Open the corresponding test category.
2. Using the cursor movement keys, highlight the desired test.
3. Press the space bar. A selected test is marked by >>. Pressing the space bar again de-selects a test
and removes the >>.
4. Repeat steps 2 and 3 above to select all desired tests.

Test results
Diagnostics test results produce the following error code format:

34

ThinkCentre Hardware Maintenance Manual

Function Code

Failure Type

DeviceID

Date

Text

ChkDigits

Function Code:
Represents the feature or function within the PC.
Failure Type:
Represents the type of error encountered.
DeviceID:
Contains the component's unit-ID that corresponds to either a fixed disk drive, removable media drive,
serial or parallel port, processor, specific RIMM, or a device on the PCI bus.
Date:
Contains the date when the diagnostic test was run. The date is retrieved from CMOS and displayed
using the YYYYMMDD format.
ChkDigits:
Contains a 2-digit check-digit value to ensure the following:
Diagnostics were run on the specified date.
Diagnostics were run on the specified computer.
The diagnostic error code is recorded correctly.
Text:
Description of the error.
Note: See Diagnostic error codes on page 42 for error code listings.

Quick and Full erase - hard drive

The diagnostics program offers two hard drive format utilities:
Quick Erase Hard Drive
Full Erase Hard Drive
Quick Erase Hard Drive provides a DOS utility that performs the following:
Destroys the Master Boot Record (MBR) on the hard drive.
Destroys all copies of the FAT Table on all partitions (both the master and backup).
Destroys the partition table.
Provides messages that warn the user that this is a non-recoverable process.
Full Erase Hard Drive provides a DOS utility that performs the following:
Performs all the steps in Quick Erase.
Provides a DOS utility that writes random data to all sectors of the hard drive.
Provides an estimate of time to completion along with a visual representation of completion status.
Provides messages that warn the user about non-recoverable process.
Important: Make sure that all data is backed up before using the Quick or Full Erase functions.

To select the Quick Erase or Full Erase Hard Drive utility. Do the following:
1. Select the UTILITY option on the toolbar and press Enter.
2. Select either the QUICK ERASE or FULL ERASE HARD DISK option and follow the instructions.

Chapter 5. Diagnostics

35

Viewing the test log

Errors reported by the diagnostic test will be displayed by the program as a failed test.
To view details of a failure or to view a list of test results, use the following procedure from any test category
screen:
1. Press F3 to activate the log file.
2. Press F3 again to save the file to diskette or press F2 to print the file.

36

ThinkCentre Hardware Maintenance Manual

Chapter 6. Using the Setup Utility program

You can use the Setup Utility program to view and change the configuration settings of your computer,
regardless of which operating system you are using. However, the operating system settings might override
any similar settings in the Setup Utility program.
This chapter provides information about the following topics to help you use the Setup Utility program:

Starting the Setup Utility program on page 37

Viewing or changing settings on page 37

Using passwords on page 37

Enabling or disabling a device on page 39

Selecting a startup device on page 39

Exiting the Setup Utility program on page 40

Starting the Setup Utility program

This section provides instructions on how to start the Setup Utility program.
To start the Setup Utility program, do the following:
1. Make sure your computer is turned off.
2. Repeatedly press and release the F1 key when turning on the computer. When you see a logo screen,
release the F1 key. The Setup Utility program opens.
Note: If a password has been set, the Setup Utility program menu will not be displayed until you type
the correct password. For more information, see Using passwords on page 37.

Viewing or changing settings

The Setup Utility program menu lists various items about the system configuration settings. To view or
change the settings, start the Setup Utility program. See Starting the Setup Utility program on page
37. Then, follow the instructions on the screen.
When working with the Setup Utility program, you must use the keyboard. The keys used to perform various
tasks are displayed at the bottom of each screen.

Using passwords
By using the Setup Utility program, you can set a password to prevent unauthorized access to your
computer and data. The following options are available to help you set an administrator password, a
power-on password, or a hard disk drive password:
Set Administrator Password
Set Power-On Password
Hard Disk Password
You do not have to set a password to use your computer. However, using a password improves computing
security. If you decide to set a password, read the following sections.

Copyright Lenovo 2010, 2011

37

Password considerations
A password can be any combination of up to 64 (1 to 64) alphabetic and numeric characters. For security
reasons, it is recommended to use a strong password that cannot be easily compromised. To set a strong
password, use the following guidelines:
Note: The Setup Utility program passwords are not case sensitive.
Have at least eight characters in length
Contain at least one alphabetic character and one numeric character
Not be your name or your user name
Not be a common word or a common name
Be significantly different from your previous passwords

Administrator password
The Set Administrator Password option enables you to set an administrator password, which deters
unauthorized users from changing configuration settings. If you are responsible for maintaining the settings
of several computers, you might want to set an administrator password. For more information on how to set
a password, see Setting, changing, or deleting a password on page 38.
After you have set an administrator password, a password prompt is displayed each time you try to access
the Setup Utility program. You cannot access the Setup Utility program until a valid password is typed in.
If you have set both a user password and an administrator password, you can type either password to use
your computer. However, to change any configuration settings, you must use your administrator password.

Power-on password
After you have set a power-on password using the Set Power-On Password option, a password prompt is
displayed each time you turn on the computer. You cannot use the computer until a valid password is typed
in. For more information about how to set a password, see Setting, changing, or deleting a password
on page 38.

Hard disk drive password

The Hard Disk Password option enables you to set a hard disk drive password, which prevents unauthorized
access to the data on the hard disk drive. When a hard disk drive password is set, you are prompted to type
a valid password each time you try to access the hard disk drive. For more information on how to set a hard
disk drive password, see Setting, changing, or deleting a password on page 38.

Setting, changing, or deleting a password

This section provides instructions on how to set, change, or delete a password.
To set, change, or delete a password, do the following:
1. Start the Setup Utility program. See Starting the Setup Utility program on page 37.
2. From the Setup Utility program main menu, select Security.
3. Depending on the password type, select Set Administrator Password, Set Power-On Password, or
Hard Disk Password.
4. Follow the instructions on the screen to set, change, or delete a password.
Note: A password can be any combination of up to 64 (1 to 64) alphabetic and numeric characters.
For more information, see Password considerations on page 38.

38

ThinkCentre Hardware Maintenance Manual

Enabling or disabling a device

This section provides instructions on how to enable or disable user access to a device.
SATA Controller

When this option is set to Disabled, all devices connected to the SATA connectors
(such as the hard disk drive and the optical drive) are disabled and will not be
displayed in the system configuration.

USB Support

Use this option to enable or disable a USB connector. When a USB connector is
disabled, the device connected to the USB connector cannot be used.

To enable or disable a device, do the following:

1. Start the Setup Utility program. See Starting the Setup Utility program on page 37.
2. From the Setup Utility program main menu, select Devices.
3. Depending on the device you want to enable or disable, do one of the following:
Select ATA Drive Setup SATA Controller to enable or disable the devices connected to the
SATA connectors on the system board.
Select USB Setup and follow the instructions on the screen to enable or disable the USB connector(s)
of your choice.
4. Select the desired settings and press Enter.
5. Press Esc to return to the Setup Utility program main menu. You might have to press Esc several times.
6. Press F10 to save the new settings and exit the Setup Utility program.
Notes:
a. If you do not want to save the new settings, select Exit Discard Changes and Exit.
b. If you want to return to the default settings, press F9 or select Exit Load Optimal Defaults.

Selecting a startup device

If your computer does not start up from a device (such as a hard disk drive or the disc in an optical drive) as
expected, do one of the following to select the desired startup device.

Selecting a temporary startup device

This section provides instructions on how to select a temporary startup device. You can use the instructions
in this section to start up from any startup device.
Note: Not all discs and hard disk drives are bootable.
To select a temporary startup device, do the following:
1. Turn off your computer.
2. Repeatedly press and release the F12 key when turning on the computer. When the Startup Device
Menu opens, release the F12 key.
3. Select the desired startup device on the Startup Device Menu and press Enter.
Note: Selecting a startup device on the Startup Device Menu does not permanently change the startup
device sequence.

Chapter 6. Using the Setup Utility program

39

Viewing or changing the startup device sequence

This section provides instructions on how to view or permanently change the configured startup device
sequence.
To view or permanently change the configured startup device sequence, do the following:
1. Start the Setup Utility program. See Starting the Setup Utility program on page 37.
2. Select Startup Primary Boot Sequence. Read the information displayed on the right side of the
screen.
3. Select the first boot device, second boot device, and so on.
4. Press Esc to return to the Startup menu. Then, select the devices for the Automatic Boot Sequence
and Error Boot Sequence.
5. Press Esc to return to the Setup Utility program main menu. You might have to press Esc several times.
6. Press F10 to save the new settings and exit the Setup Utility program.
Notes:
a. If you do not want to save the new settings, select Exit Discard Changes and Exit.
b. If you want to return to the default settings, press F9 or select Exit Load Optimal Defaults.

Exiting the Setup Utility program

After you finish viewing or changing settings, press Esc to return to the Setup Utility program main menu.
You might have to press Esc several times. Then, you can do one of the following:
If you want to save the new settings and exit the Setup Utility program, press F10 or select Exit Save
Changes and Exit. Otherwise, your changes will not be saved.
If you do not want to save the new settings, select Exit Discard Changes and Exit.
If you want to return to the default settings, press F9 or select Exit Load Optimal Defaults.

40

ThinkCentre Hardware Maintenance Manual

Chapter 7. Symptom-to-FRU Index

The Symptom-to-FRU index lists error symptoms and possible causes. The most likely cause is listed first.
Always begin with Chapter 4 General Checkout on page 31. This index can also be used to help you
decide which FRUs to have available when servicing a computer. If you are unable to correct the problem
using this index, go to Undetermined problems on page 62.
Notes:
If you have both an error message and an incorrect audio response, diagnose the error message first.
If you cannot run the diagnostic tests or you get a diagnostic error code when running a test, but did receive a
POST error message, diagnose the POST error message first.
If you did not receive any error message, look for a description of your error symptoms in the first part of this index.

Hard disk drive boot error

A hard disk drive boot error can have the following causes.
Error

FRU/Action

The start-up drive is not in the boot sequence in

configuration.

Check the configuration and ensure the start-up drive is

in the boot sequence.

No operating system installed on the boot drive.

Install an operating system on the boot drive.

The boot sector on the startup drive is corrupted.

The drive must be formatted. Do the following:

1. Attempt to back up the data on the failing hard disk
drive.
2. Using the operating system programs, format the
hard disk drive.

The drive is defective.

Replace the hard disk drive.

Power Supply Problems

If you suspect a power problem, use the following procedures.
Check/Verify

FRU/Action

Check the following for proper installation.

Reseat connectors

Power cord
On/Off switch connector
On/Off switch power supply connector
System board power supply connectors
Microprocessor(s) connection
Check the power cord for continuity.

Power cord

Check the power-on switch for continuity.

Power-on switch

Copyright Lenovo 2010, 2011

41

Diagnostic error codes

Refer to the following diagnostic error codes when using the diagnostic tests. See Running tests on page
34 for the specific type for information about the diagnostic programs.
In the following index, X can represent any number.
Diagnostic Error Code

FRU/Action

000-000-XXX BIOS Test Passed

No action

000-002-XXX BIOS Timeout

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-024-XXX BIOS Addressing test failure

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-025-XXX BIOS Checksum Value error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-026-XXX FLASH data error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-027-XXX BIOS Configuration/Setup error

1. Run the Setup Utility program.

2. Flash the system. See Flash update procedures
on page 193.
3. System board

000-034-XXX BIOS Buffer Allocation failure

1. Reboot the system.

2. Flash the system. See Flash update procedures
on page 193.
3. Run memory test
4. System board

000-035-XXX BIOS Reset Condition detected

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-036-XXX BIOS Register error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-038-XXX BIOS Extension failure

1. Flash the system. See Flash update procedures

on page 193.
2. Adapter card
3. System board

000-039-XXX BIOS DMI data error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-195-XXX BIOS Test aborted by user

000-196-XXX BIOS test halt, error threshold exceeded

Information only Restart the test, if necessary

1. Press F3 to review the log file.
2. Restart the test to reset the log file.

42

ThinkCentre Hardware Maintenance Manual

Diagnostic Error Code

000-197-XXX BIOS test warning

FRU/Action
1. Make sure the component that is called out is
connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement
4. Replace the component under test.

000-198-XXX BIOS test aborted

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and retest. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

000-199-XXX BIOS test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test.
3. Replace component under function test.

000-250-XXX BIOS APM failure

1. Flash the system. See Flash update procedures

on page 193.
2. System board

000-270-XXX BIOS ACPI failure

1. Flash the system. See Flash update procedures

on page 193.
2. System board

001-000-XXX System Test Passed

No action

001-00X-XXX System Error

System board

001-01X-XXX System Error

System board

001-024-XXX System Addressing test failure

System board

001-025-XXX System Checksum Value error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

001-026-XXX System FLASH data error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

001-027-XXX System Configuration/Setup error

1. Run the Setup Utility program.

2. Flash the system. See Flash update procedures
on page 193.
3. System board

001-032-XXX System Device Controller failure

001-034-XXX System Device Buffer Allocation failure

System board
1. Reboot the system.
2. Flash the system. See Flash update procedures
on page 193.
3. Run memory test.
4. System board

001-035-XXX System Device Reset condition detected

System board

001-036-XXX System Register error

System board

Chapter 7. Symptom-to-FRU Index

43

Diagnostic Error Code

001-038-XXX System Extension failure

FRU/Action
1. Adapter card
2. System board

001-039-XXX System DMI data structure error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

001-040-XXX System IRQ failure

1. Power-off/on system and re-test.

2. System board

001-041-XXX System DMA failure

1. Power-off/on system and re-test.

2. System board

001-195-XXX System Test aborted by user

001-196-XXX System test halt, error threshold exceeded

Information only Restart the test, if necessary

1. Press F3 to review the log file
2. Restart the test to reset the log file

001-197-XXX System test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

001-198-XXX System test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and retest. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

001-199-XXX System test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test.
3. Replace component under function test.

001-250-XXX System ECC error

System board

001-254-XXX 001-255-XXX 001-256-XXX 001-257-XXX

System DMA error

System board

001-260-XXX 001-264-XXX System IRQ error

System board

001-268-XXX System IRQ1 failure

1. Device on IRQ1
2. System board

001-269-XXX System IRQ2 failure

1. Device on IRQ2
2. System board

001-270-XXX System IRQ3 failure

1. Device on IRQ3
2. System board

001-271-XXX System IRQ4 failure

1. Device on IRQ4
2. System board

001-272-XXX System IRQ5 failure

1. Device on IRQ5
2. System board

44

ThinkCentre Hardware Maintenance Manual

Diagnostic Error Code

001-273-XXX System IRQ6 (diskette drive) failure

FRU/Action
1. Diskette Cable
2. Diskette drive
3. System board

001-274-XXX System IRQ7 failure

1. Device on IRQ7
2. System board

001-275-XXX System IRQ8 failure

1. Device on IRQ8
2. System board

001-276-XXX System IRQ9 failure

1. Device on IRQ9
2. System board

001-277-XXX System IRQ10 failure

1. Device on IRQ10
2. System board

001-278-XXX System IRQ11 failure

1. Device on IRQ11
2. System board

001-279-XXX System IRQ12 failure

1. Device on IRQ12
2. System board

001-280-XXX System IRQ13 failure

1. Device on IRQ13
2. System board

001-281-XXX System IRQ14 (hard disk drive) failure

1. Hard disk drive cable

2. Hard disk drive
3. System board

001-282-XXX System IRQ15 failure

1. Device on IRQ15
2. System board

001-286-XXX 001-287-XXX 001-288-XXX System Timer

failure
001-292-XXX System CMOS RAM error

System board
1. Run the Setup Utility program and re-test.
2. System board

001-293-XXX System CMOS Battery

1. CMOS Battery
2. System board

001-298-XXX System RTC date/time update failure

1. Flash the system. See Flash update procedures

on page 193.
2. System board

001-299-XXX System RTC periodic interrupt failure

System board

001-300-XXX System RTC Alarm failure

System board

001-301-XXX System RTC Century byte error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

005-000-XXX Video Test Passed

005-00X-XXX Video error

No action
1. Video card, if installed
2. System board

005-010-XXX 005-011-XXX 005-012-XXX 005-013-XXX

Video Signal failure

1. Video card, if installed

2. System board

Chapter 7. Symptom-to-FRU Index

45

Diagnostic Error Code

005-016-XXX Video Simple Pattern test failure

FRU/Action
1. Video Ram
2. Video card, if installed
3. System board

005-024-XXX Video Addressing test failure

1. Video card, if installed

2. System board

005-025-XXX Video Checksum Value error

1. Video card, if installed

2. System board

005-027-XXX Video Configuration/Setup error

1. Run the Setup Utility program.

2. Video drivers update
3. Video card, if installed
4. System board

005-031-XXX Video Device Cable failure

1. Video cable
2. Monitor
3. Video card, if installed
4. System board

005-032-XXX Video Device Controller failure

1. Video card, if installed

2. System board

005-036-XXX Video Register error

1. Video card, if installed

2. System board

005-038-XXX System BIOS extension failure

1. Video card, if installed

2. System board

005-040-XXX Video IRQ failure

1. Video card, if installed

2. System board

005-195-XXX Video Test aborted by user

005-196-XXX Video test halt, error threshold exceeded

Information only Restart the test, if necessary

1. Press F3 to review the log file.
2. Restart the test to reset the log file.

005-197-XXX Video test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test
3. Replace the component called out in warning
statement.
4. Replace the component under test.

005-198-XXX Video test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

005-199-XXX Video test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

46

ThinkCentre Hardware Maintenance Manual

Diagnostic Error Code

005-2XX-XXX 005-3XX-XXX Video subsystem error

FRU/Action
1. Video card, if installed
2. System board

006-000-XXX Diskette interface Test Passed

006-0XX-XXX Diskette interface error

No action
1. Diskette drive Cable
2. Diskette drive
3. System board

006-195-XXX Diskette interface Test aborted by user

Information only Restart the test, if necessary

006-196-XXX Diskette interface test halt, error threshold

exceeded

1. Press F3 to review the log file.

006-197-XXX Diskette interface test warning

1. If a component is called out, make sure it is

connected and/or enabled.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
006-198-XXX Diskette interface test aborted

1. If a component is called out, make sure it is

connected and/or enabled.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

006-199-XXX Diskette interface test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test.
3. Replace component under function test.

006-25X-XXX Diskette interface Error

1. Diskette drive cable

2. Diskette drive
3. System board

011-000-XXX Serial port Interface Test Passed

011-001-XXX Serial port Presence

No action
1. Remove external serial device, if present.
2. Run the Setup Utility program, enable port.
3. System board

011-002-XXX 011-003-XXX Serial port Timeout/Parity

error

System board

011-013-XXX 011-014-XXX Serial port Control

Signal/Loopback test failure

System board

011-015-XXX Serial port External Loopback failure

1. Wrap plug
2. System board

011-027-XXX Serial port Configuration/Setup error

1. run the Setup Utility program, enable port

2. Flash the system. See Flash update procedures
on page 193.
3. System board

011-03X-XXX 011-04X-XXX Serial port failure

System board

011-195-XXX Serial port Test aborted by user

Information only Restart the test, if necessary.

Chapter 7. Symptom-to-FRU Index

47

Diagnostic Error Code

011-196-XXX Serial port test halt, error threshold exceeded

FRU/Action
1. Press F3 to review the log file.
2. Restart the test to reset the log file.

011-197-XXX Serial port test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

011-198-XXX Serial port test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

011-199-XXX Serial port test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

011-2XX-XXX Serial port signal failure

1. External serial device

2. System board

014-000-XXX Parallel port Interface Test Passed

014-001-XXX Parallel port Presence

No action
1. Remove external parallel device, if present.
2. Run the Setup Utility program, enable port
3. System board

014-002-XXX 014-003-XXX Parallel port Timeout/Parity

error

System board

014-013-XXX 014-014-XXX Parallel port Control

Signal/Loopback test failure

System board

014-015-XXX Parallel port External Loopback failure

1. Wrap plug
2. System board

014-027-XXX Parallel port Configuration/Setup error

1. Run the Setup Utility program, enable port

2. Flash the system. See Flash update procedures
on page 193.
3. System board

014-03X-XXX 014-04X-XXX Parallel port failure

System board

014-195-XXX Parallel port Test aborted by user

Information only Restart the test, if necessary.

014-196-XXX Parallel port test halt, error threshold

exceeded

48

ThinkCentre Hardware Maintenance Manual

1. Press F3 to review the log file.

2. Restart the test to reset the log file.

Diagnostic Error Code

014-197-XXX Parallel port test warning

FRU/Action
1. Make sure the component that is called out is
connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

014-198-XXX Parallel port test aborted

1. If a component is called out, make sure it is

connected and/or enabled.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

014-199-XXX Parallel port test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

014-2XX-XXX 014-3XX-XXX Parallel port failure

1. External parallel device

2. System board

015-000-XXX USB port Interface Test Passed

015-001-XXX USB port Presence

No action
1. Remove USB device(s) and re-test.
2. System board

015-002-XXX USB port Timeout

1. Remove USB device(s) and re-test.

2. System board

015-015-XXX USB port External Loopback failure

1. Remove USB device(s) and re-test.

2. System board

015-027-XXX USB port Configuration/Setup error

1. Flash the system. See Flash update procedures

on page 193.
2. System board

015-032-XXX USB port Device Controller failure

015-034-XXX USB port buffer allocation failure

System board
1. Reboot the system
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Run memory test.
4. System board

015-035-XXX USB port Reset condition detected

1. Remove USB device(s) and re-test.

2. System board

015-036-XXX USB port Register error

015-040-XXX USB port IRQ failure

System board
1. Run the Setup Utility program and check for
conflicts.
2. Flash the system. See Flash update procedures
on page 193.
3. System board

015-195-XXX USB port Test aborted by user

Information only Restart the test, if necessary.

Chapter 7. Symptom-to-FRU Index

49

Diagnostic Error Code

015-196-XXX USB port test halt, error threshold exceeded

FRU/Action
1. Press F3 to review the log file.
2. Restart the test to reset the log file.

015-197-XXX USB port test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

015-198-XXX USB port test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

015-199-XXX USB port test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

018-000-XXX PCI Card Test Passed

018-0XX-XXX PCI Card Failure

No action
1. Riser card, if installed.
2. System board

018-195-XXX PCI Card Test aborted by user

1. PCI card
2. Information only Restart the test, if necessary

018-196-XXX PCI Card test halt, error threshold exceeded

1. Press F3 to review the log file

2. Restart the test to reset the log file

018-197-XXX PCI Card test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

018-198-XXX PCI Card test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

018-199-XXX PCI Card test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

50

ThinkCentre Hardware Maintenance Manual

Diagnostic Error Code

018-250-XXX PCI Card Services error

FRU/Action
1. PCI card
2. Riser card, if installed.
3. System board

020-000-XXX PCI Interface Test Passed

020-0XX-XXX PCI Interface error

No action
1. PCI card
2. Riser card, if installed.
3. System board

020-195-XXX PCI Test aborted by user

020-196-XXX PCI test halt, error threshold exceeded

Information only Restart the test, if necessary

1. Press F3 to review the log file.
2. Restart the test to reset the log file.

020-197-XXX PCI test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

020-198-XXX PCI test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

020-199-XXX PCI test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

020-262-XXXPCI system error

1. PCI card
2. Riser card, if installed.
3. System board

025-000-XXXIDE interface Test Passed

025-00X-XXX 025-01X-XXX IDE interface failure

No action
1. IDE signal cable
2. Check power supply voltages.
3. Reseat IDE signal cable.
4. IDE device
5. System board

025-027-XXX IDE interface Configuration/Setup error

1. IDE signal cable

2. Flash the system. See Flash update procedures
on page 193.
3. Reseat IDE signal cable.
4. IDE device
5. System board

Chapter 7. Symptom-to-FRU Index

51

Diagnostic Error Code

025-02X-XXX 025-03X-XXX 025-04X-XXX IDE Interface
failure

FRU/Action
1. IDE signal cable
2. Check power supply.
3. Reseat IDE signal cable.
4. IDE device
5. System board

025-195-XXX IDE interface Test aborted by user

Information only Restart the test, if necessary.

025-196-XXX IDE interface test halt, error threshold

exceeded

1. Press F3 to review the log file.

025-197-XXX IDE interface test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
025-198-XXX IDE interface test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

025-199-XXX IDE interface test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

030-000-XXX SCSI interface Test Passed

030-00X-XXX 030-01X-XXX SCSI interface failure

No action
1. SCSI signal cable
2. Check power supply
3. SCSI device
4. SCSI adapter card, if installed.
5. System board

030-027-XXX SCSI interface Configuration/Setup error

1. SCSI signal cable

2. Flash the system. See Flash update procedures
on page 193.
3. SCSI device
4. SCSI adapter card, if installed.
5. System board

030-03X-XXX 030-04X-XXX SCSI interface error

1. SCSI signal cable

2. Check power supply
3. SCSI device
4. SCSI adapter card, if installed.
5. System board

030-195-XXX SCSI interface Test aborted by user

52

ThinkCentre Hardware Maintenance Manual

Information only Restart the test, if necessary.

Diagnostic Error Code

FRU/Action

030-196-XXX SCSI interface test halt, error threshold

exceeded

1. Press F3 to review the log file.

030-197-XXX SCSI interface test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
030-198-XXX SCSI interface test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

030-199-XXX SCSI interface test failed, cause unknown

1. Go to Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

035-000-XXX RAID interface Test Passed

035-0XX-XXX RAID interface Failure

No action
1. RAID signal cable
2. RAID device
3. RAID adapter card, if installed
4. System board

035-195-XXX RAID interface Test aborted by user

Information only Restart the test, if necessary.

035-196-XXX RAID interface test halt, error threshold

exceeded

1. Press F3 to review the log file.

035-197-XXX RAID interface test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
035-198-XXX RAID interface test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

035-199-XXX RAID interface test failed, cause unknown

1. See Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

071-000-XXX Audio port Interface Test Passed

No action

Chapter 7. Symptom-to-FRU Index

53

Diagnostic Error Code

071-00X-XXX 071-01X-XXX 071-02X-XXXAudio port error

FRU/Action
1. Run the Setup Utility program.
2. Flash the system. See Flash update procedures
on page 193.
3. System board

071-03X-XXX Audio port failure

1. Speakers
2. Microphone
3. Audio card, if installed.
4. System board

071-04X-XXX Audio port failure

1. Run the Setup Utility program.

2. Audio card, if installed.
3. System board

071-195-XXX Audio port Test aborted by user

071-196-XXX Audio port test halt, error threshold exceeded

Information only Restart the test, if necessary.

1. Press F3 to review the log file.
2. Restart the test to reset the log file.

071-197-XXX Audio port test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

071-198-XXX Audio port test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

071-199-XXX Audio port test failed, cause unknown

1. See Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

071-25X-XXX Audio port failure

1. Speakers
2. Audio card, if installed
3. System board

080-000-XXX Game Port interface Test Passed

080-XXX-XXX Game Port interface Error
080-195-XXX Game Port interface Test aborted by user
080-196-XXX Game Port interface test halt, error threshold
exceeded

54

ThinkCentre Hardware Maintenance Manual

No action
1. Remove the game port device and re-test the
system.
Information only Restart the test, if necessary.
1. Press F3 to review the log file.
2. Restart the test to reset the log file.

Diagnostic Error Code

080-197-XXX Game Port interface test warning

FRU/Action
1. Make sure the component that is called out is
connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.

080-198-XXX Game Port interface test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

080-199-XXX Game Port interface test failed, cause

unknown

1. See Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

086-000-XXX Mouse Port interface Test Passed

086-001-XXX Mouse Port interface Presence

No action
1. Mouse
2. System board

086-032-XXX Mouse Port interface Device controller failure

1. Mouse
2. System board

086-035-XXX Mouse Port interface Reset

1. Mouse
2. System board

086-040-XXX Mouse Port interface IRQ failure

1. Run the Setup Utility program.

2. Mouse
3. System board

086-195-XXX Mouse Port interface Test aborted by user

Information only Restart the test, if necessary.

086-196-XXX Mouse Port interface test halt, error

threshold exceeded

1. Press F3 to review the log file.

086-197-XXX Mouse Port interface test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
086-198-XXX Mouse Port interface test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

Chapter 7. Symptom-to-FRU Index

55

Diagnostic Error Code

086-199-XXX Mouse Port interface test failed, cause
unknown

FRU/Action
1. See Undetermined problems on page 62.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

089-000-XXX Microprocessor Test Passed

089-XXX-XXX Microprocessor failure

No action
1. Microprocessor(s)
2. System board

089-195-XXX Microprocessor Test aborted by user

Information only Restart the test, if necessary.

089-196-XXX Microprocessor test halt, error threshold

exceeded

1. Press F3 to review the log file.

089-197-XXX Microprocessor test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
089-198-XXX Microprocessor test aborted

1. Flash the system. See Flash update procedures

on page 193.
2. Go to Undetermined problems on page 62.

089-199-XXX Microprocessor test failed, cause unknown

1. See Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

170-000-XXX Voltage Sensor(s) Test Passed

170-0XX-XXX Voltage Sensor(s) failure

No action
1. Flash system
2. System board

170-195-XXX Voltage Sensor(s) Test aborted by user

Information only Restart the test, if necessary.

170-196-XXX Voltage Sensor(s) test halt, error threshold

exceeded

1. Press F3 to review the log file.

170-197-XXX Voltage Sensor(s) test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
170-198-XXX Voltage Sensor(s) test aborted

1. If a component is called out, make sure it is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

56

ThinkCentre Hardware Maintenance Manual

Diagnostic Error Code

170-199-XXX Voltage Sensor(s) test failed, cause unknown

FRU/Action
1. See Undetermined problems on page 62.
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

170-250-XXX 170-251-XXX Voltage Sensor(s) Voltage

limit error

1. Power supply

170-254-XXX Voltage Sensor(s) Voltage Regulator Module

error

1. Voltage Regulator Module (VRM)

2. System board

2. Microprocessor
3. System board

175-000-XXX Thermal Sensor(s) Test Passed

175-0XX-XXX Thermal Sensor(s) failure

No action
1. Flash system
2. System board

175-195-XXX Thermal Sensor(s) Test aborted by user

Information only Restart the test, if necessary.

175-196-XXX Thermal Sensor(s) test halt, error threshold

exceeded

1. Press F3 to review the log file.

175-197-XXX Thermal Sensor(s) test warning

1. Make sure the component that is called out is

connected and/or enabled. See Chapter 6 Using
the Setup Utility program on page 37.

2. Restart the test to reset the log file.

2. Re-run test.
3. Replace the component that is called out in warning
statement.
4. Replace the component under test.
175-198-XXX Thermal Sensor(s) test aborted

1. If a component is called out, make sure it is

connected and/or enabled .
2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Go to Undetermined problems on page 62.

175-199-XXX Thermal Sensor(s) test failed, cause

unknown

1. See Undetermined problems on page 62.

2. Flash the system and re-test. See Flash update
procedures on page 193.
3. Replace component under function test.

175-250-XXX 175-251-XXX Thermal Sensor(s) limit error

1. Check fans
2. Check power supply voltages.
3. Microprocessor
4. System board

185-000-XXX Asset Security Test Passed

185-XXX-XXX Asset Security failure

No action
1. Flash system
2. System board

185-278-XXX Asset Security Chassis Intrusion

1. Assure Asset Security Enabled

2. C2 Cover Switch
3. System board

201-000-XXX System Memory Test Passed

No action

Chapter 7. Symptom-to-FRU Index

57

Diagnostic Error Code

201-XXX-XXX System Memory error

FRU/Action
1. Replace the memory module called out by the test.
2. System board

202-000-XXX System Cache Test Passed

202-XXX-XXX System Cache error

No action
1. Cache, if removable
2. System board
3. Microprocessor

206-000-XXX Diskette Drive Test Passed

206-XXX-XXX Diskette Drive error

No action
1. Diskette Drive Cable
2. Check power supply voltages
3. Diskette drive
4. System board

215-000-XXX CD-ROM Drive Test Passed

215-XXX-XXX CD-ROM Drive error

No action
1. CD-ROM Drive Cable
2. Check power supply voltages
3. CD-ROM drive
4. System board

217-000-XXX Hard Disk Drive Test Passed

217-25X-XXX 217-26X-XXX Hard Disk Drive (IDE) error

No action
1. Hard Disk Drive Cable
2. Check power supply voltages
3. Reseat the hard disk drive cable
4. Hard Disk drive (IDE)
5. System board

217-28X-XXX 217-29X-XXX Hard Disk Drive (SCSI) error

1. Hard Disk Drive Cable

2. Check power supply voltages
3. Reseat the hard disk drive cable
4. Hard Disk drive (SCSI)
5. SCSI adapter card
6. System board

220-000-XXX Hi-Capacity Cartridge Drive Test Passed

No action

220-XXX-XXX Hi-Capacity Cartridge Drive error

1. Remove the Hi-Capacity Cartridge Drive and re-test

the system.

301-XXX-XXX Keyboard error

1. Keyboard
2. Check and test mouse.
3. System board

301-000-XXX Keyboard Test Passed

No action

302-000-XXX Mouse Test Passed

No action

302-XXX-XXX Mouse error

1. Mouse
2. Check and test Keyboard.
3. System board

303-000-XXX Joystick Test Passed

No action

303-XXX-XXX Joystick error

Remove the Joystick and re-test the system.

58

ThinkCentre Hardware Maintenance Manual

Diagnostic Error Code

FRU/Action

305-000-XXX Monitor DDC Test Passed

No action

305-250-XXX Monitor DDC self test failure

1. Run the Setup Utility program to enable DDC.

2. Cable
3. Monitor
4. Video card
5. System board

415-000-XXXModem Test Passed

No action

415-XXX-XXX Modem error

Remove the Modem and re-test the system.

Beep symptoms
Beep symptoms are tones or a series of tones separated by pauses (intervals without sound) during POST.
The following tables describes beep symptoms.
Beep Symptom

FRU/Action

2 short beeps CMOS setting error

Common error code, see the detail failure information in

POST error codes on page 59.

3 short and 1 long beeps DRAM memory error

Perform the following actions in order.

1. Make sure the memory module(s) are properly seated
in the connector(s).
2. Replace the memory module(s).
3. Replace the system board.

POST error codes

Each time you power-on the system, it performs a series of tests that check the operation of the system
and some options. This series of tests is called the Power-On Self-Test, or POST. POST does the following
operations.
Checks some basic system-board operations
Checks the memory operation
Starts the video operation
Verifies that the boot drive is working
If the POST detects a problem, an error message appears on the screen. A single problem can cause several
error messages to appear. When you correct the cause of the first error message, the other error messages
probably will not appear on the screen the next time you turn on the system.

Chapter 7. Symptom-to-FRU Index

59

Error code

POST Error Message

Description/Action

0210

Stuck key

When a key is kept pressed for a

long time, the error message will be
displayed during the POST.

0135

Fan failure

The system might be overheating.

Press F10 to exit.
Note: If the problem is caused by the
microprocessor fan, press F10 will
not solve the problem.

0211

Keyboard not found

When there is no keyboard detected,

the error message will be displayed.

0164

Memory size decreased

Press F10 to exit.

1762

Configuration change has occurred

This error message is displayed when

a hard disk drive or optical drive
change has been made.
Press F10 to exit.

0662

Configuration change has occurred

This error message is displayed when

a floppy drive change has been made.
Press F10 to exit.

1820

More than one external fingerprint

reader are attached. Power off and
remove all but the reader that you set
up within your main operating system.

If more than one external fingerprint

reader are connected to a computer,
this error message will be displayed
to inform you to remove all of the
fingerprint keyboards except the
one compatible with the fingerprint
application on your computer.

1962

No operating system found. Press

any key to repeat boot sequence.

This error occurs only after the POST

is completed.
Press any key to repeat boot
sequence.

Miscellaneous error conditions

Message/Symptom

FRU/Action

Changing display colors

Display/Monitor

Computer will not power-off. See Hard disk drive boot

error on page 41.

1. Power Switch
2. System Board
3. Riser card, if installed.

Computer will not RPL from server

1. Ensure that network is in startup sequence as first

device or first device after diskette.
2. Ensure that network adapter is enabled for RPL.
3. Network adapter (Advise network administrator of
new MAC address)

60

ThinkCentre Hardware Maintenance Manual

Message/Symptom
Computer will not perform a Wake On LAN (if applicable)

FRU/Action
1. Check power supply and signal cable connections
to network adapter.
2. Ensure that the operating system settings are set to
enable Wake on LAN.
3. Ensure Wake On LAN feature is enabled in
Setup/Configuration (see Starting the Setup Utility
program on page 37)
4. Ensure network administrator is using correct MAC
address.
5. Ensure no interrupt or I/O address conflicts.
6. Network adapter (advise network administrator of
new MAC address)

Dead computer. See Hard disk drive boot error on page

41.

1. Power Supply

Diskette drive in-use light remains on or does not light

when drive is active.

1. Diskette Drive

2. System Board
2. System Board
3. Diskette Drive Cable

Blank screen except for flashing cursor.

1. System Board
2. Primary Hard Disk Drive
3. Hard Disk Drive Cable

Incorrect memory size during POST

1. Run the Memory tests.

2. Memory Module
3. System Board

"Insert a Diskette" icon appears with a known-good

diagnostics diskette in the first 3.5-inch diskette drive.

1. System Board
2. Diskette Drive Cable
3. Network Adapter

Intensity or color varies from left to right of characters

and color bars

1. Display
2. Video adapter (if present)
3. System Board

No power or fan not running

1. See Hard disk drive boot error on page 41.

Non-system disk or disk error-type message with a

known-good diagnostic diskette.

1. Diskette Drive
2. System Board
3. Diskette Drive Cable

Other display symptoms not listed above (including blank

or illegible display)

1. Display

Power-on indicator or hard disk drive in-use light not on,

but computer works correctly

1. Power switch/LED assembly

Printer problems

1. Printer

2. System Board

2. System Board
2. System Board

Chapter 7. Symptom-to-FRU Index

61

Message/Symptom
Program loads from the hard disk with a known-good
diagnostics diskette in the first 3.5-inch diskette drive

FRU/Action
1. Run the Setup Utility program and check Startup
sequence.
2. Diskette Drive
3. Diskette Drive Cable
4. System Board
5. Power Supply

RPL computer cannot access programs from its own hard

disk.

1. If network administrator is using LCCM Hybrid RPL,

check startup sequence:
a. First device - network
b. Second device - hard disk
2. Hard disk drive

RPL computer does not RPL from server

1. Check startup sequence.

2. Check the network adapter LED status.

Serial or parallel port device failure (system board port)

1. External Device Self-Test OK?

2. External Device
3. Cable
4. System Board

Serial or parallel port device failure (adapter port)

1. External Device Self-Test OK?

2. External Device
3. Cable
4. Alternate Adapter
5. System Board

Some or all keys on the keyboard do not work

1. Keyboard
2. Keyboard Cable
3. System Board

Undetermined problems
This section provides instructions on how to find out the failing devices or adapters.
1. Power-off the computer.
2. Remove or disconnect the following components (if installed) one at a time.
a. External devices (modem, printer, or mouse)
b. Any adapters
c. Memory modules
d. Extended video memory
e. External Cache
f. External Cache RAM
g. Hard disk drive
h. Diskette drive
3. Power-on the computer to re-test the system.
4. Repeat steps 1 through 3 until you find the failing device or adapter.
If all devices and adapters have been removed, and the problem continues, replace the system board.

62

ThinkCentre Hardware Maintenance Manual

Chapter 8. Replacing FRUs

This chapter provides removal or replacement procedures for major FRUs. Not all FRUs are documented.
Important
Before you replace any FRU, read Chapter 2 Safety information on page 3. These precautions and
guidelines will help you work safely.
FRU replacements are to be done by trained service technicians only.

Copyright Lenovo 2010, 2011

63

Locating connectors, controls, and indicators on the front of your

computer
Figure 1 Front connector, control, and indicator locations on page 64 shows the locations of the
connectors, controls, and indicators on the front of your computer.

Figure 1. Front connector, control, and indicator locations

1 Integrated camera with MIC (microphone)
(available in some models)

8 Wireless activity indicator

2 Integrated camera on/off button

9 Menu/Enter

3 Liquid crystal display (LCD) panel

10 Brightness control /Right

4 Power switch

11 Image setup control /Left

5 Power indicator

12 Monitor mode control /Exit

6 Hard disk drive activity indictor

13 Microphone mute/on control

7 Bluetooth activity indicator

64

ThinkCentre Hardware Maintenance Manual

Using your computer in monitor mode

Your computer can work in two modes: computer mode or monitor mode. This section provides instructions
on how to use your computer in monitor mode.
To use your computer in monitor mode, you need to have a second computer. Connect one end of the
VGA cable to the VGA IN connector on the rear of your computer, and connect the other end to the VGA
connector on the second computer. Use the monitor mode control
on the front of your computer to
switch your computer between computer mode and monitor mode.
The following table explains the functions of each control when your computer works in computer mode
or monitor mode.
Icon

Control

Description

Menu

Open the main On-Screen Display (OSD) menu.

Enter

Confirm a selection.

Brightness control
Right
Image setup control
Left
Cancel/Exit
Monitor mode control

Adjust overall monitor brightness.

Move to the right.
Automatically optimize the image.
Move to the left.
Cancel an operation or exit the main OSD menu.
Switch your computer between computer mode and monitor mode.

Chapter 8. Replacing FRUs

65

Locating connectors and parts on the rear of your computer

Figure 2 Rear connector and part locations on page 66 shows the locations of the connectors and parts
on the rear of your computer. Some connectors on the rear of your computer are color-coded to help you
determine where to connect the cables on your computer.

Figure 2. Rear connector and part locations

1 Card reader (available in some models)

8 PS/2 keyboard connector (available in some models)

2 USB connectors (2)

9 Power cord connector

3 Slim optical drive

10 Ethernet connector

4 Headphone connector

11 USB connectors (4)

5 Microphone connector

12 DisplayPort out connector

6 Serial port (available in some models)

13 VGA IN connector

7 PS/2 mouse connector (available in some models)

14 Integrated cable lock slot

66

ThinkCentre Hardware Maintenance Manual

FRU locations
The following illustration shows the locations of the FRUs.

35

34
33

32

31

Figure 3. FRU locations

1 Frame stand

19 Power cord connector bracket

2 Computer cover

20 Front panel control board

3 Fan duct

21 Power switch module

Chapter 8. Replacing FRUs

67

4 Wall mount

22 Internal speaker

5 Thermal sensor

23 PS2 COM Port

6 Multi-touch board*

24 Computer main bracket

7 Heat sink

25 Right I/O assembly

8 Microprocessor

26 Inverter

9 Memory

27 LCD panel

10 WI-FI card

28 Right I/O assembly

11 Battery

29 Card reader*

12 Microprocessor fan

30 Power supply

13 System board

31 Optical drive*

14 Internal speaker

32 Hard disk drive

15 Rear I/O assembly cover

33 Integrated camera with microphone*

16 Bluetooth module*

34 Ambient light sensor*

17 Frame foot

35 Handle bar

18 System fan

68

ThinkCentre Hardware Maintenance Manual

System board parts and connectors

The following illustration shows the locations of the system board parts and connectors.

Figure 4. System board part and connector locations

1 Microprocessor

15 Rear I/O assembly connector

2 Multi-touch board cable connector

16 COM connector

3 Integrated camera cable connector

17 Thermal sensor connector

4 Memory slots (2)

18 Right I/O assembly cable connector

5 Mini PCI Express slot

19 Hard disk drive power connector

6 Ambient light sensor cable connector

20 PS/2 keyboard and mouse connector

7 Bluetooth module cable connector

21 SATA connector

8 Wireless keyboard and mouse connector

22 SATA connector

9 Clear CMOS (Complementary Metal Oxide

Semiconductor) /Recovery jumper

23 Optical drive power connector

10 Battery

24 Low-voltage differential signaling (LVDS) cable connector

11 Internal speaker cable connector

25 System fan connector

12 Power switch cable connector

26 Inverter connector

13 Microprocessor fan connector

27 Power supply fan connector

14 PIR sensor connector

28 Power supply connector

Chapter 8. Replacing FRUs

69

Removing or reinstalling the frame stand

Your computer comes with either a frame stand or a lift stand. This section provides instructions on how
to remove or reinstall the frame stand.
To remove or reinstall the frame stand, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Loose the four screws 1 that secure the frame stand.
Note: Do not try to remove the four screws, because they are integrated parts of the frame stand.

Figure 5. Removing the frame stand

4. Lift the frame stand off the computer and put it in a safe place.
5. To reinstall the frame stand, position the frame stand so that the four screw holes align with those in the
computer wall mount and then tighten the four screws 1 to secure the frame stand.
6. Go to Completing the parts replacement on page 111.

70

ThinkCentre Hardware Maintenance Manual

Removing the computer cover

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to remove the computer cover.
CAUTION:
Turn off the computer and wait three to five minutes to let the computer cool before
removing the computer cover.
To remove the computer cover, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove any locking device that secures the computer cover, such as an integrated cable lock.
4. Remove the frame stand, and then remove the two screws at the bottom of the computer.
5. Lift the computer cover up to remove it from the chassis.
Note: Your computer cover might be very tight, in which case, you need to use more strength to loose
it, and then lift it up.

Figure 6. Removing the computer cover

Chapter 8. Replacing FRUs

71

Replacing the hard disk drive

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the hard disk drive.
To replace the hard disk drive, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Remove the computer cover. See Removing the computer cover on page 71.
3. Locate the hard disk drive in the computer. See FRU locations on page 67.
4. Remove the two screws that secure the hard disk drive. Then, disconnect the hard disk drive cable
and slide the hard disk drive out of the chassis.

Figure 7. Removing the hard disk drive

5. Remove the four screws on the hard disk drive bracket, then get the hard disk drive out of the bracket.
Do not touch the circuit board on the bottom of the hard disk drive.

72

ThinkCentre Hardware Maintenance Manual

Figure 8. Removing the hard disk drive out of the bracket

6. To install the new hard disk drive into the bracket, position the hard disk drive so that the four screw
holes align with those in the bracket.
7. Install the four screws that secure the hard disk drive to the hard disk drive bracket.
8. Connect the hard disk drive cable.
9. Slide the new hard disk drive with the bracket into the hard disk drive bay.

Figure 9. Installing the hard disk drive

10. Install the two screws to secure the hard disk drive bracket.

Chapter 8. Replacing FRUs

73

Figure 10. Installing the hard disk drive

11. Go to Completing the parts replacement on page 111.

Replacing the optical drive

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the optical drive.
Note: The optical drive is available only in some models.
To replace the optical drive, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the optical drive. See FRU locations on page 67.
5. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
6. Remove the screw 1 that secures the optical drive. Then, disconnect the optical drive cable 2 . Slide
the optical drive out of the optical drive bay.

74

ThinkCentre Hardware Maintenance Manual

Figure 11. Removing the optical drive

7. To install a new optical drive, slide the new optical drive into the optical drive bay. Then connect the
cable 2 to the optical drive.

Figure 12. Installing the optical drive

8. Install the screw 1 to secure the optical drive.

9. Go to Completing the parts replacement on page 111.

Replacing the right I/O assemblies

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
Chapter 8. Replacing FRUs

75

This section provides instructions on how to replace the right I/O assemblies.
To replace the right I/O assemblies, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the right I/O assemblies. See FRU locations on page 67.
Note: The right I/O assemblies are located on both sides of the optical drive bay. See Figure 13
Removing the right I/O assemblies on page 76.
5. Disconnect all the right I/O assembly cables.
6. Remove the four screws ( 1 and 2 ) that secure the right I/O assemblies, and then remove the right I/O
assemblies from the computer.

Figure 13. Removing the right I/O assemblies

7. To install the new right I/O assemblies into the computer, position the new right I/O assemblies into
place, and then align the screw holes with the corresponding holes in the computer main bracket.
8. Install the four screws ( 1 and 2 ) to secure the right I/O assemblies to the computer main bracket.
9. Connect all the removed right I/O assembly cables to the new right I/O assemblies.

76

ThinkCentre Hardware Maintenance Manual

10. Go to Completing the parts replacement on page 111.

Replacing the card reader

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the card reader.
Note: The card reader is available only in some models.
To replace the card reader, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the card reader in the computer. See FRU locations on page 67.
5. Disconnect the card reader cable from the card reader.
6. Remove the two screws 1 that secure the card reader, and then lift the card reader out of the computer.

Figure 14. Removing the card reader

7. To connect the card reader, align the screw holes in the new card reader with those in the computer, and
then install the two screws to secure the card reader.

Chapter 8. Replacing FRUs

77

8. Connect the card reader cable to the new card reader.

9. Go to Completing the parts replacement on page 111.

Replacing the inverter

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the inverter.
To replace the inverter, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
5. Remove the optical drive. See Replacing the optical drive on page 74.
6. Remove the right I/O assemblies. See Replacing the right I/O assemblies on page 75.
7. Locate the inverter in the computer. See FRU locations on page 67.
8. Remove the two screws 1 that secure the inverter to the main bracket, and disconnect the three cables.

9. Lift the inverter off the system board, and then remove the inverter cover that came with the inverter.
10. Place the new inverter in the inverter cover.
Note: The inverter cover only fits one way to the inverter.
78

ThinkCentre Hardware Maintenance Manual

11. Position the new inverter on the main bracket and align the two screw holes in the new inverter with
those in the main bracket.
12. Connect the three cables to the new inverter.
13. Install the two screws 1 that secure the new inverter to the main bracket.
14. Reinstall the right I/O assemblies. See Replacing the right I/O assemblies on page 75.
15. Reinstall the optical drive. See Replacing the optical drive on page 74.
16. Reinstall the hard disk drive. See Replacing the hard disk drive on page 72.
17. Go to Removing the computer cover on page 71.

Replacing the power supply

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the power supply.
To replace the power supply, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
5. Remove the optical drive. See Replacing the optical drive on page 74.
6. Remove the PS2 COM Port. See Replacing the PS2 COM Port on page 90.
7. Locate the power supply. See FRU locations on page 67.
8. Disconnect the power supply cables from the system board. See System board parts and connectors
on page 69.
9. Remove the four screws 1 that secure the power supply. Then remove the two screws 3 that secure
the power cord connector bracket. Note the routing of the power cord connector cable 2 . Lift the
power supply up to remove it from the computer main bracket.

Chapter 8. Replacing FRUs

79

Figure 15. Removing the power supply

10. Remove the three screws 4 that secure the power cord connector, and then remove the power cord
connector from the power cord connector bracket.
11. Install the three screws to secure the new power cord connector to the power cord connector bracket.
12. Position the new power supply in the computer and align the four screw holes in the new power supply
with those in the computer main bracket. Install the four screws to secure the new power supply.
13. Route the new power cord connector cable, and then position the power cord connector bracket on the
bottom of the computer main bracket.
14. Align the two screw holes in the power cord connector bracket with those in the computer main bracket
and install the two screws to secure the power cord connector bracket.
15. Connect the new power supply cables to the power supply connectors on the system board. See
System board parts and connectors on page 69.
16. Reinstall the PS2 COM Port. See Replacing the PS2 COM Port on page 90.
17. Reinstall the optical drive. See Replacing the optical drive on page 74.
18. Reinstall the hard disk drive. See Replacing the hard disk drive on page 72.
19. Go to Completing the parts replacement on page 111.

Removing or reinstalling the wall mount

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy

80

ThinkCentre Hardware Maintenance Manual

of the ThinkCentre Safety and Warranty Guide, go to:

http://www.lenovo.com/support
To remove or reinstall the wall mount, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
5. Remove the three screws ( 1 and 3 ) that secure the wall mount to the computer main bracket.

Figure 16. Removing the computer wall mount

6. Note the routing of the thermal sensor cable. Then disconnect the thermal sensor cable 2 from the
system board. See System board parts and connectors on page 69. Then lift the wall mount off
the computer main bracket
7. To reinstall the computer wall mount, position the wall mount on the computer main bracket and align
the screw holes in the wall mount with those in the computer main bracket.
8. Reinstall the three screws to secure the wall mount to the computer main bracket.

Chapter 8. Replacing FRUs

81

Figure 17. Removing the computer wall mount

9. Connect the thermal sensor cable to the system board. See System board parts and connectors
on page 69.
10. Go to Completing the parts replacement on page 111.

Replacing the system fan

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the system fan.
To replace the system fan, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the system fan in the computer. See FRU locations on page 67.
5. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
6. Remove the wall mount to gain access to the system fan. See Removing or reinstalling the wall mount
on page 80.
7. Remove the three screws 1 that secure the system fan to the main bracket.

82

ThinkCentre Hardware Maintenance Manual

8. Note the routing of the system fan cable, and then disconnect the system fan cable from the system
board. Lift the system fan off the main bracket.
9. Connect the new system fan cable to the system board. Position the new system fan on the main
bracket and align the screw holes in the new system fan with those in the main bracket.
10. Install the three screws that secure the system fan to the main bracket.

11. Reinstall the wall mount. See Removing or reinstalling the wall mount on page 80.
12. Reinstall the hard disk drive. See Replacing the hard disk drive on page 72.
13. Go to Completing the parts replacement on page 111.

Chapter 8. Replacing FRUs

83

Replacing the microprocessor fan assembly

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the microprocessor fan assembly.
To replace the microprocessor fan assembly, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
5. Remove the wall mount. See Removing or reinstalling the wall mount on page 80.
6. Note the routing of the microprocessor fan assembly cable, and then disconnect the microprocessor fan
assembly cable from the system board.
7. Loose, but not remove, the three screws 1 that secure the microprocessor fan assembly, and then lift
the microprocessor fan assembly off the system board.

Figure 18. Removing the microprocessor fan assembly

84

ThinkCentre Hardware Maintenance Manual

8. To reinstall the microprocessor fan assembly, position the new microprocessor fan assembly on the
system board and align the three screw holes in the new microprocessor fan assembly with those
in the system board.
9. Tighten the three screws to secure the microprocessor fan assembly to the system board.

Figure 19. Removing the microprocessor fan assembly

10. Connect the microprocessor fan assembly cable to the system board. See System board parts and
connectors on page 69.
11. Reinstall the wall mount. See Removing or reinstalling the wall mount on page 80.
12. Reinstall the hard disk drive. See Replacing the hard disk drive on page 72.
13. Go to Completing the parts replacement on page 111.

Replacing the heat sink

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the heat sink.
CAUTION:
The heat sink might be very hot. Turn off the computer and wait three to five minutes to
let the computer cool before removing the computer cover.
To replace the heat sink, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.

Chapter 8. Replacing FRUs

85

3. Remove the computer cover. See Removing the computer cover on page 71.
4. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
5. Remove the wall mount. See Removing or reinstalling the wall mount on page 80.
6. Locate the heat sink on the system board. See FRU locations on page 67.
7. Remove the fan duct by pressing the two tabs 1 inward, and then pivoting the fan duct upward.

Figure 20. Removing the fan duct

8. Follow the sequence on the heat sink to loose the four screws that secure the heat sink to the system
board.
Note: Carefully loose the four screws from the system board to avoid any possible damage to the
system board. The four screws cannot be removed from the heat sink.

86

ThinkCentre Hardware Maintenance Manual

Figure 21. Removing the heat sink

9. Lift the failing heat sink off the system board.

Notes:
a. You might have to gently twist the heat sink to free it from the microprocessor.
b. Do not touch the thermal grease while handling the heat sink.
10. Position the new heat sink on the system board so that the four screws are aligned with the
corresponding holes in the system board.
11. Follow the sequence on the heat sink to tighten the four screws to secure the heat sink to the system
board, as shown in Figure 21 Removing the heat sink on page 87.
12. To reinstall the fan duct, position the fan duct on the heat sink, and then press the fan duct downward
until the two tabs on the fan duct are secured into place.
13. Go to Completing the parts replacement on page 111.

Replacing the microprocessor

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the microprocessor.

Chapter 8. Replacing FRUs

87

CAUTION:
The heat sink and microprocessor might be very hot. Turn off the computer and wait
three to five minutes to let the computer cool before removing the computer cover.
To replace the microprocessor, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
5. Remove the wall mount. See Removing or reinstalling the wall mount on page 80.
6. Remove the heat sink to gain access to the microprocessor. See Replacing the heat sink on page 85.
7. Press the small handle 1 and open the retainer 2 to access the microprocessor 3 .

8. Lift the microprocessor straight up and out of the socket.

Notes:
a. Your microprocessor and socket might look different from the one illustrated.
b. Note the orientation of the microprocessor in the socket. You can either look for the small triangle 1
on one corner of the microprocessor or note the orientation of the notches 2 on the microprocessor.
This is important when installing a new microprocessor on the system board.

88

ThinkCentre Hardware Maintenance Manual

c. Touch only the sides of the microprocessor. Do not touch the gold contacts on the bottom.
d. Do not drop anything onto the microprocessor socket while it is exposed. The socket pins must be
kept as clean as possible.

Figure 22. Removing the microprocessor

9. Make sure that the small handle is in the raised position and the microprocessor retainer is fully open.
10. Hold the new microprocessor and align the notches 2 on it with the alignment keys in the
microprocessor socket, or align the small triangle 1 on one corner of the new microprocessor with the
corresponding beveled corner of the microprocessor socket.

Chapter 8. Replacing FRUs

89

Figure 23. Installing the microprocessor

11. Lower the new microprocessor straight down into the microprocessor socket on the system board.
12. Close the microprocessor retainer and lock it into position with the small handle to secure the new
microprocessor in the socket.
13. Reinstall the heat sink. See Replacing the heat sink on page 85.
14. Reinstall the wall mount. See Removing or reinstalling the wall mount on page 80.
15. Reinstall the hard disk drive. See Replacing the hard disk drive on page 72.
16. Reinstall any other parts or connect any other cables you removed.
17. Go to Completing the parts replacement on page 111.

Replacing the PS2 COM Port

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the PS2 COM Port.
To replace the PS2 COM Port, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the PS2 COM Port. See FRU locations on page 67.

90

ThinkCentre Hardware Maintenance Manual

5. Remove the three screws ( 2 , 3 and 4 ) that secure the PS2 COM Port, and then disconnect the PS2
COM Port cable from the system board. Lift the PS2 COM Port out of the computer.

Figure 24. Removing the PS2 COM Port

6. Remove the two screws 1 that secure the PS2 Port. Then get the PS2 Port out of the PS2 COM Port.
7. To install a new PS2 port, install the two screws 1 that secure the PS2 Port to the PS2 COM Port.
8. To install a new PS2 COM Port into the computer, position the new PS2 COM Port into place, and then
align the screw holes with the corresponding holes in the computer main bracket.
9. Install the three screws ( 2 , 3 and 4 ) that secure the PS2 COM Port to the computer main bracket.
10. Connect the PS2 COM Port cable to the system board.
11. Go to Completing the parts replacement on page 111.

Installing or replacing a memory module

Attention:
Do not open your computer or attempt any repair before reading and understanding the Important safety information
in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy of the ThinkCentre
Safety and Warranty Guide, go to:
http://www.lenovo.com/support

This section provides instructions on how to install or replace a memory module.

Your computer has two memory slots for installing or replacing DDR3 SDRAM DIMMs (small outline dual
inline memory modules). When installing or replacing a memory module, use 1 GB, 2 GB or 4 GB DDR3
SDRAM DIMMs in any combination up to a maximum of 8 GB of system memory.
To install or replace a memory module, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.

Chapter 8. Replacing FRUs

91

2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the memory slots on the system board. See FRU locations on page 67.
5. Remove any parts and disconnect any cables that might prevent your access to the memory slots.
6. Do one of the following:
If you are replacing a memory module, open the retaining clips and remove the old memory module
that is currently installed.

Figure 25. Removing the memory module

If you are installing a memory module, open the retaining clips of the memory slot into which you
want to install the memory module.
7. Insert the notched end 1 of the new memory module into the slot. Press the memory module firmly
and pivot the memory module until it snaps into place. Make sure that the memory module is secured
in the slot and does not move easily.

Figure 26. Installing the memory module

8. Go to Completing the parts replacement on page 111.

92

ThinkCentre Hardware Maintenance Manual

Replacing the battery

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the battery.
Your computer has a special type of memory that maintains the date, time, and settings for built-in features,
such as parallel-port assignments (configuration). A battery keeps the information active when you turn
off the computer.
The battery normally requires no charging or maintenance throughout its life. However, if the battery fails,
the date, time, and configuration information (including passwords) are lost. An error message will be
displayed when you turn on the computer.
Refer to the Lithium battery notice in the ThinkCentre Safety and Warranty Guide for information about
replacing and disposing of the battery.
To replace the battery, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the battery on the system board. See FRU locations on page 67.
5. Remove the battery.

Figure 27. Removing the battery

6. Install a new battery.

Figure 28. Installing a new battery

Chapter 8. Replacing FRUs

93

7. Reinstall the computer cover and connect the cables. See Completing the parts replacement on
page 111.
8. Turn on the computer and all attached devices.
Note: When the computer is turned on for the first time after replacing the battery, an error message
might be displayed. This is normal after replacing the battery.
9. Use the Setup Utility program to set the date, time, and any passwords. See Chapter 6 Using the Setup
Utility program on page 37.

Replacing the WI-FI card

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the WI-FI card.
Note: The WI-FI card is available only in some models.
To replace the WI-FI card, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the WI-FI card on the system board. See FRU locations on page 67.
5. Disconnect the two cables from the WI-FI card.
6. Carefully remove the two screws 1 that secure the WI-FI card to the system board. Then, pivot the
WI-FI card upward and lift the WI-FI card out of the mini PCI Express slot.

94

ThinkCentre Hardware Maintenance Manual

Figure 29. Removing the WI-FI card

7. Insert the notched end of the new WI-FI card into the mini PCI Express slot. Press the new WI-FI
card firmly, and then pivot the WI-FI card to align the screw holes in the new WI-FI card with those
in the system board.
8. Install the two screws to secure the new WI-FI card to the system board.
9. Connect the two cables to the new WI-FI card.
10. Go to Completing the parts replacement on page 111.

Replacing the Bluetooth module

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the Bluetooth module.
Note: The Bluetooth module is available only in some models.
To replace the Bluetooth module, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the Bluetooth module in the computer. See FRU locations on page 67.
5. Note the Bluetooth module cable routing and disconnect the cable from the system board.

Chapter 8. Replacing FRUs

95

6. Carefully release the Bluetooth module and lift the Bluetooth module out of the computer.

Figure 30. Removing the Bluetooth module

7. Position the new Bluetooth module into the computer front bezel, and then press the new Bluetooth
module downward until it is secured into place.
8. Connect the new Bluetooth module cable to the system board. See System board parts and
connectors on page 69.
9. Go to Completing the parts replacement on page 111.

Replacing the multi-touch board

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the multi-touch board.
Note: The multi-touch board is available only in some models.
To replace the multi-touch board, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the multi-touch board in the computer. See FRU locations on page 67.
5. Note the multi-touch board cable routing and disconnect the three multi-touch board cables from
the system board and the multi-touch screen.
6. Carefully remove the two screws 1 that secure the multi-touch board, and then lift the multi-touch
board off the computer main bracket.

96

ThinkCentre Hardware Maintenance Manual

Figure 31. Removing the multi-touch board

7. Align the screw holes in the new multi-touch board with those in the computer main bracket, and then
install the two screws to secure the multi-touch board.
8. Connect the new multi-touch board cables to the system board and the multi-touch screen. See
System board parts and connectors on page 69.
9. Go to Completing the parts replacement on page 111.

Replacing the ambient light sensor

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the ambient light sensor.
Note: The ambient light sensor is available only in some models.
To replace the ambient light sensor, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.

Chapter 8. Replacing FRUs

97

4. Locate the ambient light sensor in the computer. See FRU locations on page 67.
5. Remove the four screws ( 1 and 2 ) that secure the handle bar.

Figure 32. Removing the handle bar

6. Carefully remove the two screws 1 that secure the ambient light sensor, and then lift the ambient light
sensor out of the computer.

Figure 33. Removing the ambient light sensor

98

ThinkCentre Hardware Maintenance Manual

7. Disconnect the ambient light sensor cable from the system board.
8. Align the screw holes in the new ambient light sensor with the corresponding holes in the computer,
and then install the two screws to secure the ambient light sensor.
9. Connect the new ambient light sensor cable to the system board. See System board parts and
connectors on page 69.
10. Position the handle bar so that the screw holes can align with the corresponding holes in the computer,
and then install the four screws to secure the handle bar.
11. Go to Completing the parts replacement on page 111.

Replacing the internal speakers

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the internal speakers.
To replace the internal speakers, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the internal speakers in the computer. See FRU locations on page 67.
5. Note the location of the internal speaker cable connection. Note the routing of the internal speaker
cables. Disconnect the internal speaker cables from the system board.
6. Remove the two screws 1 that secure each internal speaker to the front bezel, and then remove the
internal speakers from the computer.

Chapter 8. Replacing FRUs

99

Figure 34. Removing the internal speakers

7. Route the new internal speaker cables, and then position the new internal speakers on the front bezel so
that the two screw holes in each internal speaker align with those in the front bezel.
8. Reinstall the two screws to secure each of the internal speakers to the front bezel.
9. Connect the internal speaker cables to the system board. See System board parts and connectors
on page 69.
10. Go to Completing the parts replacement on page 111.

Replacing the integrated camera with microphone

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the integrated camera with microphone.
Note: The integrated camera with microphone is available only in some models.
To replace the integrated camera with microphone, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the integrated camera with microphone in the computer. See FRU locations on page 67.
5. Remove the handle bar at the top of the computer by removing the four screws that secure the handle
bar.

100

ThinkCentre Hardware Maintenance Manual

Figure 35. Removing the handle bar

6. Note the routing of the integrated camera with microphone cable, and then disconnect the cable from
the system board. See System board parts and connectors on page 69.
7. Remove the two screws 1 that secure the integrated camera with microphone to the front bezel, and
then remove the integrated camera with microphone from the computer.

Figure 36. Removing the integrated camera with microphone

Chapter 8. Replacing FRUs

101

8. Route the new integrated camera with microphone cable, and then position the new integrated camera
with microphone in place. Align the two screw holes in the new integrated camera with microphone
with those in the front bezel.
9. Reinstall the two screws to secure the new integrated camera with microphone to the front bezel.
10. Connect the integrated camera with microphone cable to the system board. See System board parts
and connectors on page 69.
11. Position the handle bar so that the screw holes can align with the corresponding holes in the computer,
and then install the four screws to secure the handle bar.
12. Go to Completing the parts replacement on page 111.

Replacing the rear I/O assembly

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the rear I/O assembly.
To replace the rear I/O assembly, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the rear I/O assembly. See FRU locations on page 67.
5. Remove the four screws 1 that secure the rear I/O assembly, and then remove the rear I/O assembly
from the computer.

102

ThinkCentre Hardware Maintenance Manual

Figure 37. Removing the rear I/O assembly cover

6. To reinstall the rear I/O assembly, position the new rear I/O assembly into place, and then align the
screw holes with corresponding holes in the computer main bracket. Install the four screws to secure
the rear I/O assembly.
7. Go to Completing the parts replacement on page 111.

Replacing the power switch module

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the power switch module.
To replace the power switch module, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the power switch module in the computer. See FRU locations on page 67.

Chapter 8. Replacing FRUs

103

5. Remove the 21 screws that secure the computer main bracket to the front bezel.

6. Note the locations of all cable connections that prevent you from lifting the computer main bracket, and
disconnect all cables. See System board parts and connectors on page 69.
7. Lift the computer main bracket off the front bezel.
8. Remove the screw that secures the power switch module to the front bezel.

9. Disconnect the power switch module cable from the system board, and then lift the power switch
module off the front bezel.
10. Position the new power switch module on the front bezel and align the screw hole in the new power
switch module with that in the front bezel.
11. Connect the power switch module cable to the system board.

104

ThinkCentre Hardware Maintenance Manual

12. Install the screw that secures the new power switch module to the front bezel.
13. Install the 21 screws to secure the main bracket to the front bezel.
14. Reconnect all the cables that were disconnected.
15. Go to Completing the parts replacement on page 111.

Replacing the front panel control board

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the front panel control board.
To replace the front panel control board, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the front panel control board in the computer. See FRU locations on page 67.
5. Remove the 21 screws that secure the main bracket to the front bezel.

6. Note the locations of all cable connections that prevent you from lifting the computer main bracket, and
disconnect all cables. See System board parts and connectors on page 69.
7. Lift the main bracket off the front bezel.
8. Remove the three screws 1 that secure the front panel control board to the front bezel.

Chapter 8. Replacing FRUs

105

9. Disconnect the front panel control board cable from the system board. Lift the front panel control
board off the front bezel.
10. Position the new front panel control board on the front bezel and align the screw holes in the new
power switch module with those in the front bezel.
11. Connect the new front panel control board cable to the system board.
12. Install the three screws that secure the new front panel control board to the front bezel.
13. Install the 21 screws to secure the main bracket to the front bezel.
14. Connect all the cables that were disconnected. See System board parts and connectors on page 69.
15. Go to Completing the parts replacement on page 111.

Replacing the system board

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the system board.
To replace the power system board, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the system board in the computer. See FRU locations on page 67.
5. Remove the hard disk drive. See Replacing the hard disk drive on page 72.
6. Remove the wall mount. See Removing or reinstalling the wall mount on page 80.

106

ThinkCentre Hardware Maintenance Manual

7. Remove the system fan. See Replacing the system fan on page 82.
8. Remove the heat sink. See Replacing the heat sink on page 85.
9. Remove the microprocessor fan. See Replacing the microprocessor fan assembly on page 84.
10. Remove the microprocessor. See Replacing the microprocessor on page 87.
11. Remove the memory module. See Installing or replacing a memory module on page 91.
12. Remove the WI-FI card. See Replacing the WI-FI card on page 94.
13. Remove the battery. See Replacing the battery on page 93.
14. Remove the rear I/O assembly to gain access to the system board. See Replacing the rear I/O
assembly on page 102.
15. Note the locations of all cable connections on the system board and disconnect all cables. See System
board parts and connectors on page 69.
16. Remove the nine screws that secure the system board to the main bracket. Carefully lift the system
board out of the chassis.

17. Place the new system board into the chassis and align the screw holes with those in the chassis.
18. Install the nine screws that secure the system board to the main bracket.
19. Reinstall the rear I/O assembly. See Replacing the rear I/O assembly on page 102.
20. Reinstall the battery. See Replacing the battery on page 93.
21. Reinstall the WI-FI card. See Replacing the WI-FI card on page 94.
22. Reinstall the memory module. See Installing or replacing a memory module on page 91.
23. Reinstall the microprocessor. See Replacing the microprocessor on page 87.
24. Reinstall the microprocessor fan. See Replacing the microprocessor fan assembly on page 84.
25. Reinstall the heat sink. See Replacing the heat sink on page 85.
26. Reinstall the system fan. See Replacing the system fan on page 82.

Chapter 8. Replacing FRUs

107

27. Reinstall the wall mount. See Removing or reinstalling the wall mount on page 80.
28. Reinstall the hard disk drive. See Replacing the hard disk drive on page 72.
29. Connect all cables that were disconnected from the system board. See System board parts and
connectors on page 69.
30. Go to Completing the parts replacement on page 111.
The failing system board must be returned with a microprocessor socket cover to protect the pins during
shipping and handling.
To install the microprocessor socket cover, do the following:
1. Release the lever securing the microprocessor retainer and open the retainer to access the
microprocessor.
2. Grasp the microprocessor on the sides and lift it straight up and out of the socket. Do not touch the
contacts on the microprocessor socket.
3. Note the orientation of the socket cover. Align the notches 1 of the microprocessor socket cover with
the alignment keys 2 of the microprocessor socket.
4. Install one side of the socket cover into the microprocessor socket as shown.

Figure 38. Installing the socket cover

Note: Your microprocessor socket and cover might look slightly different from the illustration.
5. Carefully press the other side of the socket cover downwards until the socket cover snaps into place.

108

ThinkCentre Hardware Maintenance Manual

Figure 39. Securing the socket cover

6. Carefully check the four corners of the socket cover to make sure that the cover is secured in the
microprocessor socket.
7. Lower the microprocessor retainer, and then lower the lever to secure the retainer. Make sure the
lever is locked into position.
8. Follow any additional instructions included with the replacement part you received.
Note: If your system board has two microprocessor sockets, be sure to install a socket cover for each
microprocessor socket.

Replacing the LCD panel

Attention
Do not open your computer or attempt any repair before reading and understanding the Important safety
information in the ThinkCentre Safety and Warranty Guide that came with your computer. To obtain a copy
of the ThinkCentre Safety and Warranty Guide, go to:
http://www.lenovo.com/support
This section provides instructions on how to replace the LCD panel.
To replace the LCD panel, do the following:
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Place a soft, clean towel or cloth on the desk or surface. Hold the sides of your computer and gently lay
it down so that the screen is against the surface and the cover is facing up.
3. Remove the computer cover. See Removing the computer cover on page 71.
4. Locate the LCD panel in the computer. See FRU locations on page 67.
5. Remove all the 21 screws that secure the main bracket to the front bezel.

Chapter 8. Replacing FRUs

109

6. Note the locations of all cable connections that prevent you from lifting the computer main bracket, and
disconnect all cables. See System board parts and connectors on page 69.
7. Lift the computer main bracket off the front bezel.
8. Gently rip the three pieces of black tape 1 , and then lift the LCD bezel out of the computer.
Note: Do not break the tape or remove the tape from the computer. You will need the tape when
installing the new LCD panel.

9. Place the new LCD panel into the front bezel, and then stick the three pieces of black tape back to
the LCD panel.
10. Position the computer main bracket over the LCD panel. Make sure the screw holes in the computer
main bracket align with those in the front bezel.
11. Reinstall all the 21 screws that secure the main bracket to the front bezel.

110

ThinkCentre Hardware Maintenance Manual

12. Connect all the cables that were disconnected. See System board parts and connectors on page 69.
13. Go to Completing the parts replacement on page 111.

Completing the parts replacement

After completing the installation or replacement for all parts, you need to reinstall the computer cover
and reconnect cables.
To reinstall the computer cover and reconnect cables, do the following:
1. Make sure that all components have been reassembled correctly and that no tools or loose screws are
left inside your computer. See FRU locations on page 67 for the locations of various components in
your computer.
2. Make sure that the cables are routed correctly before reinstalling the computer cover. Keep cables clear
of the hinges and sides of the computer chassis to avoid interference with reinstalling the computer
cover.
3. Lower and position the computer cover into place and then install the two screws to secure the
computer cover.

Chapter 8. Replacing FRUs

111

Figure 40. Installing the computer cover

4. Position the frame stand so that the four screw holes in the frame stand align with those in the computer
cover, and then tighten the four screws to secure the frame stand to the computer cover.
5. Lock the computer cover if you have an integrated cable lock.
6. Reconnect the external cables and power cord to the computer.
7. Depending on the parts you installed or replaced, you might need to confirm the updated information in
the Setup Utility program. Refer to Chapter 6 Using the Setup Utility program on page 37.
Note: In most areas of the world, Lenovo requires the return of the defective Customer Replaceable Unit
(CRU). Information about this will come with the CRU or will come a few days after the CRU arrives.

112

ThinkCentre Hardware Maintenance Manual

Chapter 9. FRU lists

This chapter lists the information on the field replaceable units (FRUs).
Attention: Be sure to read and understand all the safety information before replacing any FRUs.
Note: In the following tables, a customer replaceable unit (CRU) is identified as 1, 2, or N in the CRU
column. N means that the part is not a CRU, 1 means that the part is a Self-service CRU, and 2
means that the part is an Optional-service CRU.

Overall: MT 7570, 7577, 7578, 7580, 7583, 7584, 7589, 7594, 7595, 7597,
and 7598
The Fru list below is for MTs:
Standard MTs: 7577, 7580, 7583, 7584, 7589, 7597, and 7598.
Special Bid MTs: 7570, 7578, 7594, and 7595

Copyright Lenovo 2010, 2011

113

35

34
33

32

31

1 Frame stand

19 Power cord connector bracket

2 Computer cover

20 Front panel control board

3 Fan duct

21 Power switch module

4 Wall mount

22 Internal speaker

5 Thermal sensor

23 PS2 COM Port

6 Multi-touch board*

24 Computer main bracket

7 Heat sink

25 Right I/O assembly

8 Microprocessor

26 Inverter

9 Memory

27 LCD panel

114

ThinkCentre Hardware Maintenance Manual

10 WI-FI card

28 Right I/O assembly

11 Battery

29 Card reader*

12 Microprocessor fan

30 Power supply

13 System board

31 Optical drive*

14 Internal speaker

32 Hard disk drive

15 Rear I/O assembly cover

33 Integrated camera with microphone*

16 Bluetooth module*

34 Ambient light sensor*

17 Frame foot

35 Handle bar

18 System fan

Item #

FRUs

FRU #

CRU

03T9550

03T9555

45K6400

Frame stand
MT 7577: all models
MT 7580: all models
MT 7583: all models
1

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Computer cover, rear cover sub assembly
MT 7577: all models
MT 7580: all models
MT 7583: all models

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Fan duct , microprocessor fan duct
MT 7577: all models
MT 7580: all models
MT 7583: all models

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

115

Item #

FRUs

FRU #

CRU

03T9563

03T9572

03T9530

71Y5303

Thermal sensor, thermal sensor

MT 7577: all models
MT 7580: all models
MT 7583: all models
5

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Multi-touch control board
MT 7577: all models
MT 7580: all models
MT 7583: all models

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Heat sink, L2-Intel 73W thermal cooler kit
MT 7577: all models
MT 7580: all models
MT 7583: all models

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Microprocessor, Clarkdale Pentium G6950 2.80G 1066MHz Dual
core\3M\73W LGA 1156 (Gfx core speed 533MHz )
MT 7577:
MT 7580:
MT 7583: A5J A6J B1J B2J B8J B9J

MT 7584:
MT 7589: A2S A2D A2Y
MT 7597: CTO C2S C2D C2Y C3D C3Y B4J B5J B0J C1J A1P E3T
E4A E4T C3S G9J H1J H2J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

116

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

71Y5304

89Y9195

71Y6961

71Y6962

Microprocessor, Clarkdale Core i3-540 3.06G 1333MHz 4T\Dual

core\4M\73W LGA 1156 (Gfx core speed 733MHz )
MT 7577: B8B B5A B5T D7A D8G D8T E4J E5J D4V
MT 7580: A0G
MT 7583: B3J B4J B6J B7J
8

MT 7584:
MT 7589: B3G
MT 7597: CTO G5J G6J G7J G8J
MT 7598: B3G
MT 7570, 7578, 7594, and 7595_SB
Microprocessor, Clarkdale Core i3-550 3.20G 1333MHz Dual core \4M
\73W (Gfx core speed 733MHz)
MT 7577: G3J G4J
MT 7580:
MT 7583: A3J A4J

MT 7584: BIS BID BIY B4G B6J

MT 7589: A1S A1D A1Y A3D A3Y A3S B2V
MT 7597: CTO A7B C7B C9B C4S C4D C4Y C5S C5D C5Y B2J B3J
B8J B9J A2P A3P D3T D4A D4T D8T A5G D3A D8A
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Microprocessor, Clarkdale Core i5-650 3.20G 1333MHz 4T\Dual
core\4M\73W\Turbo LGA 1156 (Gfx core speed 733MHz)
MT 7577: B7B D1B B3A B3T B4A B4T B6A B6T E2J E3J D2V D3V
G1J G2J
MT 7580: A1G
MT 7583: A2J A1J B5J

MT 7584: B2S B2D B2Y B3G B5J B7J

MT 7589: B1V B4G
MT 7597: CTO A9B C6S C6D C6Y A0J B1J B6J B7J A4P D1P D1B
D1J D2P D2B D2J D5A D5T D6T D0A D0T E1A E1T A8B A6G D1S D1A
D1Q E5Q E6Q D2S D2A D2Q D6A E8S E8D E8Y G1J G2J G3J G4J
MT 7598: B1G B2G B4G
MT 7570, 7578, 7594, and 7595_SB
Microprocessor, Clarkdale Core i5-660 3.33G 1333MHz 4T\Dual
core\4M\73W\Turbo LGA 1156 (Gfx core speed 733MHz)
MT 7577: B9B B1A B1T B2A B2T D9A D9T E1G E1A E1T D5V D6V
MT 7580:
MT 7583:

MT 7584:
MT 7589:
MT 7597: CTO C8B D7T D9T E2A E2T D7A D9A
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

117

Item #

FRUs

FRU #

CRU

71Y6963

89Y9196

03T7035

46R3325

Microprocessor, Clarkdale Core i5-670 3.46G 1333MHz 4T\Dual

core\4M\73W\Turbo LGA 1156 (Gfx core speed 733MHz)
MT 7577:
MT 7580:
MT 7583:
8

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Microprocessor, Clarkdale Core i5-680 3.46G 1333MHz 4T\Dual
core\4M\73W\Turbo LGA 1156 (Gfx core speed 733MHz)
MT 7577:
MT 7580:
MT 7583:

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Microprocessor, Clarkdale Core i3-560 3.30G 1333MHz Dual core \4M
\73W (Gfx core speed 733MHz)
MT 7577:
MT 7580:
MT 7583:

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Memory module, 1GB PC3-8500 1066MHz DDR3 SoDIMM
MT 7577:
MT 7580:
MT 7583:

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

118

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

46R3326

64Y6650

64Y6651

Memory module, 2GB PC3-8500 1066MHz DDR3 SoDIMM

MT 7577:
MT 7580:
MT 7583:
9

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Memory module, 1GB PC3-10600 1333MHz DDR3 SoDIMM
MT 7577:
MT 7580:
MT 7583: A6J B2J B9J

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Memory module, 2GB PC3-10600 1333MHz DDR3 SoDIMM
MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T
B5A B5T B6A B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J
E5J D2V D3V D4V D5V D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J B1J B3J B4J B5J B6J B7J B8J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B7J

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G
B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S
C4D C4Y C5S C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J
B6J B7J B8J B9J B0J C1J A1P A2P A3P A4P D1P D1B D1J D2P D2B
D2J D3T D4A D4T D5A D5T D6T D7T D8T D9T D0A D0T E1A E1T E2A
E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q E5Q E6Q D2S
D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

119

Item #

FRUs

FRU #

CRU

89Y9225

89Y6220

60Y3233

Memory module, 4GB PC3-10600 1333MHz DDR3 SoDIMM

MT 7577:
MT 7580:
MT 7583:
9

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
WI-FI card, Intel Puma Peak WiFi card antenna kit
MT 7577: all models
MT 7580: all models
MT 7583: all models

10

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
WI-FI card, Intel Puma Peak WiFi card
MT 7577:
MT 7580:
MT 7583:

10

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

120

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

89Y1688

45K6403

03T9005

Battery, L1- battery in system board

MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T
B5A B5T B6A B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J
E5J D2V D3V D4V D5V D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J
B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J
11

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G
B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S
C4D C4Y C5S C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J
B6J B7J B8J B9J B0J C1J A1P A2P A3P A4P D1P D1B D1J D2P D2B
D2J D3T D4A D4T D5A D5T D6T D7T D8T D9T D0A D0T E1A E1T E2A
E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q E5Q E6Q D2S
D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Microprocessor fan, 4 Pin PWM blower microprocessor fan
MT 7577: all models
MT 7580: all models
MT 7583: all models

12

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
System board, H57 Planar in barebone
MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T
B5A B5T B6A B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J
E5J D2V D3V D4V D5V D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J
B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J

13

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G
B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S
C4D C4Y C5S C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J
B6J B7J B8J B9J B0J C1J A1P A2P A3P A4P D1P D1B D1J D2P D2B
D2J D3T D4A D4T D5A D5T D6T D7T D8T D9T D0A D0T E1A E1T E2A
E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q E5Q E6Q D2S
D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

121

Item #

FRUs

FRU #

CRU

03T6438

03T9562

03T9536

System board, Q57 Planner in barebone (Non ACL Cap)

MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T
B5A B5T B6A B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J
E5J D2V D3V D4V D5V D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J
B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J
13

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G
B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S
C4D C4Y C5S C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J
B6J B7J B8J B9J B0J C1J A1P A2P A3P A4P D1P D1B D1J D2P D2B
D2J D3T D4A D4T D5A D5T D6T D7T D8T D9T D0A D0T E1A E1T E2A
E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q E5Q E6Q D2S
D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Internal speaker, speaker module
MT 7577: all models
MT 7580: all models
MT 7583: all models

14

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Rear I/O board kit
MT 7577: all models
MT 7580: all models
MT 7583: all models

15

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

122

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

89Y6230

03T9551

03T9531

89Y1175

Bluetooth module
MT 7577: all models
MT 7580: all models
MT 7583: all models
16

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Frame foot
MT 7577: all models
MT 7580: all models
MT 7583: all models

17

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
System fan, 4 pin PWM blower system fan
MT 7577: all models
MT 7580: all models
MT 7583: all models

18

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Power cord connector bracket, plugs
MT 7577: all models
MT 7580: all models
MT 7583: all models

19

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

123

Item #

FRUs

FRU #

CRU

Refer to
Mechanical
FRUs on
page 131.

03T9539

03T9562

03T9571

Front panel control board (included in front bezel kit)

MT 7577: all models
MT 7580: all models
MT 7583: all models
20

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Power switch module with cable
MT 7577: all models
MT 7580: all models
MT 7583: all models

21

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Internal speaker
MT 7577: all models
MT 7580: all models
MT 7583: all models

22

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
PS2 and COM module with mechanical parts
MT 7577: all models
MT 7580: all models
MT 7583: all models

23

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

124

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

03T9532

03T9535

03T9573

89Y6192

Computer main bracket, LCD shielding sub assembly

MT 7577: all models
MT 7580: all models
MT 7583: all models
24

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Right I/O assembly with cable kit
MT 7577: all models
MT 7580: all models
MT 7583: all models

25

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Inverter, Inverter PCBA
MT 7577: all models
MT 7580: all models
MT 7583: all models

26

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
LCD panel, Samsung 19" CCFL panel
MT 7577: all models
MT 7580: all models
MT 7583: all models

27

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

125

Item #

FRUs

FRU #

CRU

03T9011

03T9533

03T9534

03T9535

LCD panel, LG 19" CCFL panel

MT 7577: all models
MT 7580: all models
MT 7583: all models
27

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
LCD panel, Samsung LCD touch assembly
MT 7577: all models
MT 7580: all models
MT 7583: all models

27

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
LCD panel, LG LCD touch assembly
MT 7577: all models
MT 7580: all models
MT 7583: all models

27

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Right I/O assembly with cable kit
MT 7577: all models
MT 7580: all models
MT 7583: all models

28

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

126

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

03T6002

89Y1686

45K0433

Card reader board kit with bracket/EMI shielding

MT 7577: all models
MT 7580: all models
MT 7583: all models
29

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Power supply, 150Watt power supply (85 plus) (auto sensing)
MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T
B5A B5T B6A B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J
E5J D2V D3V D4V D5V D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J
B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J

30

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G
B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S
C4D C4Y C5S C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J
B6J B7J B8J B9J B0J C1J A1P A2P A3P A4P D1P D1B D1J D2P D2B
D2J D3T D4A D4T D5A D5T D6T D7T D8T D9T D0A D0T E1A E1T E2A
E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q E5Q E6Q D2S
D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Optical drive, SATA - Slim ODD Rambo
MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T
B5A B5T B6A B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E4J
D3V D5V G1J G3J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J B1J B3J B4J B5J B6J B7J B8J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J

31

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S
C4D C4Y C5S C5D C5Y C6S C6D C6Y A0J B2J B4J B6J B8J B0J
A1P A2P A3P A4P D1P D1B D1J D2P D2B D2J D3T D4A D4T D5A
D5T D6T D7T D8T D9T D0A D0T E1A E1T E2A E2T A8B C3S A5G A6G
D1S D1A D1Q E5Q E6Q D2S D2A D2Q D3A D6A D7A D8A D9A E7S
E7D E7Y E8S E8D E8Y G1J G3J G5J G7J G9J H2J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

127

Item #

FRUs

FRU #

CRU

71Y5848

40Y9035

53Y6837

45K0408

Optical drive, SATA - Slim ODD DVD ROM

MT 7577: E3J E5J D2V D4V D6V G2J G4J
MT 7580:
MT 7583: A6J B2J B9J
31

MT 7584:
MT 7589: B1V B2V
MT 7597: CTO B1J B3J B5J B7J B9J C1J E4A E4T G2J G4J G6J
G8J H1J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, SATA 160GB 7200RPM/3Gb/8M
MT 7577:
MT 7580:
MT 7583:

32

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, SATA 160GB 7200RPM/3Gb/8M
MT 7577:
MT 7580:
MT 7583:

32

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, SATA 250GB 7200RPM/3Gb/8M
MT 7577: G3J G4J
MT 7580:
MT 7583: A3J A4J A5J A6J B1J B2J B3J B4J B6J B7J B8J B9J

32

MT 7584: B6J
MT 7589:
MT 7597: CTO B2J B3J B4J B5J B8J B9J B0J C1J D3T D8T E3T E4A
E4T D3A D8A G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

128

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

40Y9036

45K0409

87H4891

Hard disk drive, SATA 250GB 7200RPM/3Gb/8M

MT 7577: G3J G4J
MT 7580:
MT 7583: A3J A4J A5J A6J B1J B2J B3J B4J B6J B7J B8J B9J
32

MT 7584: B6J
MT 7589:
MT 7597: CTO B2J B3J B4J B5J B8J B9J B0J C1J D3T D8T E3T E4A
E4T D3A D8A G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, SATA 320GB 7200 RPM/3Gb/8M
MT 7577: B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T D7A D8G
D8T D9A D9T E2J E3J D2V D4V D6V G1J G2J
MT 7580: A0G
MT 7583: A2J A1J B5J
MT 7584: BIS BID BIY B2S B2D B2Y B4G B5J B7J

32

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V
MT 7597: CTO A7B C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S C5D
C5Y C6S C6D C6Y A0J B1J B6J B7J A1P A2P A3P A4P D1P D1B
D1J D2P D2B D2J D4A D4T D5A D5T D6T D9T D0A D0T E1A E1T
E2A E2T C3S A5G D1S D1A D1Q E5Q E6Q D2S D2A D2Q D6A D9A
G1J G2J G3J G4J
MT 7598: B1G B2G
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, SATA 320GB 7200 RPM/3Gb/8M
MT 7577: B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T D7A D8G
D8T D9A D9T E2J E3J D2V D4V D6V G1J G2J
MT 7580: A0G
MT 7583: A2J A1J B5J
MT 7584: BIS BID BIY B2S B2D B2Y B4G B5J B7J

32

MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V
MT 7597: CTO A7B C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S C5D
C5Y C6S C6D C6Y A0J B1J B6J B7J A1P A2P A3P A4P D1P D1B
D1J D2P D2B D2J D4A D4T D5A D5T D6T D9T D0A D0T E1A E1T
E2A E2T C3S A5G D1S D1A D1Q E5Q E6Q D2S D2A D2Q D6A D9A
G1J G2J G3J G4J
MT 7598: B1G B2G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

129

Item #

FRUs

FRU #

CRU

45K0410

41X5582

45K0412

46R6400

Hard disk drive, SATA 500GB 7200RPM/3Gb/16M

MT 7577: B7B B8B B9B D1B B6A B6T E1G E1A E1T E4J E5J D3V D5V
MT 7580: A1G
MT 7583:
32

MT 7584: B3G
MT 7589: B3G B4G
MT 7597: CTO A9B C7B C8B C9B D7T A8B A6G D7A E7S E7D E7Y
E8S E8D E8Y
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, SATA 500GB 7200RPM/3Gb/16M
MT 7577: B7B B8B B9B D1B B6A B6T E1G E1A E1T E4J E5J D3V D5V
MT 7580: A1G
MT 7583:

32

MT 7584: B3G
MT 7589: B3G B4G
MT 7597: CTO A9B C7B C8B C9B D7T A8B A6G D7A E7S E7D E7Y
E8S E8D E8Y
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, SATA 1TB 7200RPM/3Gb/32M
MT 7577:
MT 7580:
MT 7583:

32

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hard disk drive, 2.5 inch 150G 10K RPM HDD
MT 7577:
MT 7580:
MT 7583:

32

MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

130

ThinkCentre Hardware Maintenance Manual

Item #

FRUs

FRU #

CRU

03T9540

03T9541

89Y6232

FRU #

CRU

89Y1175

Integrated camera with microphone, camera module with angled bracket

MT 7577: all models
MT 7580: all models
MT 7583: all models
33

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Integrated camera with microphone, camera module with normal bracket
MT 7577: all models
MT 7580: all models
MT 7583: all models

33

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Ambient light sensor, light sensor board with cable kit
MT 7577: all models
MT 7580: all models
MT 7583: all models

34

MT 7584: all models

MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Mechanical FRUs
The FRUs listed in the following tables are not illustrated.
FRUs
Mechanical cap without PS2 and COM, no frame stand hole plug
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

131

FRUs

FRU #

CRU

45K6544

60Y3241

89Y6223

03T9547

3.5 HDD to 2.5" conversion kit, no bezel /1.8 to 2.5 universal HDD converter bracket kit
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
L2-1000 condor peak
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Intrusion switch with cable kit
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, 1.8 SSD to 2.5 HDD conversion kit
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

132

ThinkCentre Hardware Maintenance Manual

FRUs

FRU #

CRU

03T9552

03T9553

03T9554

03T9557

FRU, touch bezel kit (with front panel control board)

MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, non-touch bezel kit (with front panel control board)
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, non-touch without camera bezel kit (with front panel control board)
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, LVDS cable
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

133

FRUs

FRU #

CRU

03T9558

03T9559

03T9560

03T9561

FRU, HDD tray assembly

MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, HDD cable assembly
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, ODD retainer
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, ODD cable assembly
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

134

ThinkCentre Hardware Maintenance Manual

FRUs

FRU #

CRU

03T9574

03T9575

03T9576

03T9556

FRU, inverter cable

MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, ODD blank bezel
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
FRU, card reader bezel
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Wall mount cover sub assembly
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

135

FRUs

FRU #

CRU

03T9544

03T9545

03T9546

03T9549

Mechanical kit, multi-touch with camera

MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Mechanical kit, non-touch with camera
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Mechanical kit, non-touch without camera
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB
Lift stand
MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

136

ThinkCentre Hardware Maintenance Manual

FRUs

FRU #

CRU

03T9577

FRU #

CRU

41A5289

41A5290

41A5291

FRU, card reader blank bezel

MT 7577: all models
MT 7580: all models
MT 7583: all models
MT 7584: all models
MT 7589: all models
MT 7597: all models
MT 7598: all models
MT 7570, 7578, 7594, and 7595_SB

Keyboard and Mouse

Keyboard (Lenovo Preferred Pro USB )
US English/Chinese-Simplified
MT 7577: B1A B2A B3A B4A B5A B6A D7A D8G D9A E1G E1A
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589:
MT 7597: CTO D4A D5A D0A E1A E2A E4A A5G A6G D1A D1Q E5Q E6Q D2A
D2Q D3A D6A D7A D8A D9A
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Arabic
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Arabic/French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

137

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5292

41A5293

41A5294

41A5295

Belgium French
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Belgium English
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Brazilian Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO A1P A2P A3P A4P D1P D2P
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Bulgarian
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

138

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5296

41A5297

41A5298

41A5299

Chinese/US
MT 7577: B7B B8B B9B D1B D2V D3V D4V D5V D6V
MT 7580:
MT 7583:
MT 7584:
MT 7589: B1V B2V
MT 7597: CTO A7B A9B C7B C8B C9B D1B D2B A8B
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Czech (ABB)
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Danish
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Dutch
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

139

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5300

41A5301

41A5302

41A5303

French
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
French Canadian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
French Canadian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
German
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

140

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5304

41A5305

41A5306

41A5307

Greek
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Greek/US
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Hebrew
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Hungarian
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

141

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5308

41A5309

41A5310

41A5311

Iceland
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Italy
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Japanese
MT 7577: E2J E3J E4J E5J G1J G2J G3J G4J
MT 7580:
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: B5J B6J B7J
MT 7589:
MT 7597: CTO A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J D1J D2J G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Korean
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

142

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5312

41A5313

41A5314

41A5315

LA Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584: BIS BID BIY B2S B2D B2Y
MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S
MT 7597: CTO C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S C5D C5Y C6S C6D C6Y
C3S D1S D2S E7S E7D E7Y E8S E8D E8Y
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Norwegian
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Polish
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Portuguese
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

143

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5317

41A5316

41A5318

41A5319

Romanian
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Romanian
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Russian/Cyrillic
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Serbian/Cyrillic
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

144

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5320

41A5321

41A5322

41A5323

Slovak
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Spanish
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Swedish/Finnish
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Swiss French/German
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

145

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5324

41A5325

41A5326

41A5327

Thailand
MT 7577: B1T B2T B3T B4T B5T B6T D8T D9T E1T
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO D3T D4T D5T D6T D7T D8T D9T D0T E1T E2T E3T E4T
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Turkish
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Turkish
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
UK English
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

146

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

41A5328

41A5329

45J4880

45J4896

US European
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Slovenian
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Arabic (New)
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Lithuanian
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

147

Keyboard (Lenovo Preferred Pro USB )

FRU #

CRU

54Y8381

FRU #

CRU

03X8001

03X8002

03X8003

India
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597:
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Keyboard (Lenovo Fingerprint Reader USB)
US English/Chinese-Simplified
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Arabic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Arabic/French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

148

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8004

03X8005

03X8006

03X8007

Belgium French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Belgium English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Brazilian Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Bulgarian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

149

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8008

03X8009

03X8010

03X8011

Chinese/US
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Czech (ABB)
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Danish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Dutch
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

150

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8012

03X8013

03X8014

03X8015

French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
French Canadian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
French Canadian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
German
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

151

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8016

03X8017

03X8018

03X8019

Greek
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Greek/US
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hebrew
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hungarian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

152

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8020

03X8021

03X8022

03X8023

Iceland
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Italy
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Japanese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Korean
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

153

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8024

03X8025

03X8026

03X8027

LA Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Norwegian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Polish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

154

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8038

03X8039

03X8028

03X8040

Romanian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Romanian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Russian/Cyrillic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Serbian/Cyrillic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

155

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8029

03X8030

03X8031

03X8032

Slovak
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Swedish/Finnish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Swiss French/German
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

156

ThinkCentre Hardware Maintenance Manual

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8033

03X8041

03X8034

03X8035

Thailand
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Turkish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Turkish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
UK English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

157

Keyboard (Lenovo Fingerprint Reader USB)

FRU #

CRU

03X8036

03X8037

FRU #

CRU

57Y4740

57Y4741

US European
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Slovenian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Ultra slim Wireless
Wireless--US English/Chinese-Simplified
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Arabic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

158

ThinkCentre Hardware Maintenance Manual

Ultra slim Wireless

FRU #

CRU

57Y4742

57Y4743

57Y4744

57Y4745

Wireless--Arabic/French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Belgium French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Belgium English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Brazilian Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

159

Ultra slim Wireless

FRU #

CRU

57Y4746

57Y4747

57Y4748

57Y4749

Wireless--Bulgarian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Chinese/US
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Czech (ABB)
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Danish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

160

ThinkCentre Hardware Maintenance Manual

Ultra slim Wireless

FRU #

CRU

57Y4750

57Y4751

57Y4752

57Y4753

Wireless--Dutch
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--French Canadian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--French Canadian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

161

Ultra slim Wireless

FRU #

CRU

57Y4754

57Y4755

57Y4756

57Y4757

Wireless--German
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Greek
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Greek/US
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Hebrew
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

162

ThinkCentre Hardware Maintenance Manual

Ultra slim Wireless

FRU #

CRU

57Y4758

57Y4759

57Y4760

57Y4761

Wireless--Hungarian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Iceland
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Italy
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Japanese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

163

Ultra slim Wireless

FRU #

CRU

57Y4762

57Y4763

57Y4764

57Y4765

Wireless--Korean
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--LA Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Norwegian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Polish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

164

ThinkCentre Hardware Maintenance Manual

Ultra slim Wireless

FRU #

CRU

57Y4766

57Y4767

57Y4768

57Y4769

Wireless--Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Russian/Cyrillic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Slovak
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

165

Ultra slim Wireless

FRU #

CRU

57Y4770

57Y4771

57Y4772

57Y4773

Wireless--Swedish/Finnish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Swiss French/German
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Thailand
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Turkish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

166

ThinkCentre Hardware Maintenance Manual

Ultra slim Wireless

FRU #

CRU

57Y4774

57Y4775

57Y4776

Wireless--UK English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--US European
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Wireless--Slovenian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

167

Mice

FRU #

CRU

41U3013

41U3030

89Y1273

Optical wheel mouse (400DPI, USB)

MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T B6A
B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J E5J D2V D3V D4V D5V
D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J
MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S
C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J A1P
A2P A3P A4P D1P D1B D1J D2P D2B D2J D3T D4A D4T D5A D5T D6T D7T D8T
D9T D0A D0T E1A E1T E2A E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q
E5Q E6Q D2S D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Optical wheel mouse (400DPI, USB)
MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T B6A
B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J E5J D2V D3V D4V D5V
D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J
MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S
C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J A1P
A2P A3P A4P D1P D1B D1J D2P D2B D2J D3T D4A D4T D5A D5T D6T D7T D8T
D9T D0A D0T E1A E1T E2A E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q
E5Q E6Q D2S D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Optical wheel mouse (400DPI, USB)
MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T B6A
B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J E5J D2V D3V D4V D5V
D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J
MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S
C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J A1P
A2P A3P A4P D1P D1B D1J D2P D2B D2J D3T D4A D4T D5A D5T D6T D7T D8T
D9T D0A D0T E1A E1T E2A E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q
E5Q E6Q D2S D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

168

ThinkCentre Hardware Maintenance Manual

Mice

FRU #

CRU

89Y1274

89Y1275

FRU #

CRU

43N9160

Optical wheel mouse (400DPI, USB)

MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T B6A
B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J E5J D2V D3V D4V D5V
D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J
MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S
C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J A1P
A2P A3P A4P D1P D1B D1J D2P D2B D2J D3T D4A D4T D5A D5T D6T D7T D8T
D9T D0A D0T E1A E1T E2A E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q
E5Q E6Q D2S D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Optical wheel mouse (400DPI, USB)
MT 7577: B7B B8B B9B D1B B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T B6A
B6T D7A D8G D8T D9A D9T E1G E1A E1T E2J E3J E4J E5J D2V D3V D4V D5V
D6V G1J G2J G3J G4J
MT 7580: A0G A1G
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: BIS BID BIY B2S B2D B2Y B3G B4G B5J B6J B7J
MT 7589: A1S A1D A1Y A2S A2D A2Y A3D A3Y A3S B1V B2V B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B C2S C2D C2Y C3D C3Y C4S C4D C4Y C5S
C5D C5Y C6S C6D C6Y A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J A1P
A2P A3P A4P D1P D1B D1J D2P D2B D2J D3T D4A D4T D5A D5T D6T D7T D8T
D9T D0A D0T E1A E1T E2A E2T E3T E4A E4T A8B C3S A5G A6G D1S D1A D1Q
E5Q E6Q D2S D2A D2Q D3A D6A D7A D8A D9A E7S E7D E7Y E8S E8D E8Y G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Adapters and miscellaneous FRUs

Adapters and miscellaneous FRUs
L1-DP to DVI-D-S dongle
MT 7577: B7B B8B B9B D1B E2J E3J E4J E5J G1J G2J G3J G4J
MT 7580:
MT 7583: B1J B3J B4J B5J B6J B7J B8J
MT 7584: B5J B6J B7J
MT 7589:
MT 7597: CTO G1J G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598: B1G B2G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

169

Power Cords
Power Cords --primary

FRU #

CRU

41R3184

41R3256

41R3248

45J9595

Line cord-US, (Thailand)

MT 7577: B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T B6A B6T D7A D8T D9A
D9T E1A E1T
MT 7580:
MT 7583:
MT 7584: BIS BID B2S B2D
MT 7589: A1S A1D A2S A2D A3D A3S
MT 7597: CTO C2S C2D C3D C4S C4D C5S C5D C6S C6D D3T D4A D4T D5A D5T
D6T D7T D8T D9T D0A D0T E1A E1T E2A E2T E3T E4A E4T C3S D1S D1A D1Q D2S
D2A D3A D6A D7A D8A D9A E7S E7D E8S E8D
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-China
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Japan
MT 7577: E2J E3J E4J E5J G1J G2J G3J G4J
MT 7580:
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: B5J B6J B7J
MT 7589:
MT 7597: CTO A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J D1J D2J G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Brazil
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO A1P A2P A3P A4P D1P D2P
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

170

ThinkCentre Hardware Maintenance Manual

Power Cords --primary

FRU #

CRU

41R3176

41R3196

41R3260

41R3278

Line cord- LA (High Voltage) Argentina, Paraguay and Uruguay

MT 7577:
MT 7580:
MT 7583:
MT 7584: BIY B2Y
MT 7589: A1Y A2Y A3Y
MT 7597: CTO C2Y C3Y C4Y C5Y C6Y E7Y EE8Y
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord- ANZ
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Korea
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Taiwan
MT 7577: D2V D3V D4V D5V D6V
MT 7580:
MT 7583:
MT 7584:
MT 7589: B1V B2V
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

171

Power Cords --primary

FRU #

CRU

41R3232

41R3212

41R3228

41R3236

Line cord-Italy
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: BIS BIY B2S B2Y B3G B4G
MT 7589: A1S A1Y A2S A2Y A3Y A3S B3G B4G
MT 7597: CTO C2S C2Y C3Y C4S C4Y C5S C5Y C6S C6Y C3S A5G D1S E7S
E7Y E8S E8Y
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-Denmark
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-Switzerland
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-Israel
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

172

ThinkCentre Hardware Maintenance Manual

Power Cords --primary

FRU #

CRU

41R3220

41R3341

41R3208

41R3224

Line cord-South Africa

MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO D4A D5A D0A E1A E2A E4A A5G D1A D2A D3A D6A D7A D8A D9A
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-India
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO E5Q E6Q D2Q
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Indonesia, Laos, Cambodia and Vietnam, Austria, Belgium, Croatia,
Czechoslovakia, Finland, France, Germany, Hungary, Netherlands, Norway, Poland,
Portugal, Romania, Spain, Sweden
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Hong Kong, Singapore, Malaysia, Brunei, UK, Ireland
MT 7577: B7B B8B B9B D1B D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B D1B D2B D4A D5A D0A E1A E2A E4A
A8B A5G D1A
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

173

Power Cords --secondary

FRU #

CRU

41R3185

41R3257

41R3249

41R3271

Line cord-US, (Thailand)

MT 7577: B1A B1T B2A B2T B3A B3T B4A B4T B5A B5T B6A B6T D7A D8T D9A
D9T E1A E1T
MT 7580:
MT 7583:
MT 7584: BIS BID B2S B2D
MT 7589: A1S A1D A2S A2D A3D A3S
MT 7597: CTO C2S C2D C3D C4S C4D C5S C5D C6S C6D D3T D4A D4T D5A D5T
D6T D7T D8T D9T D0A D0T E1A E1T E2A E2T E3T E4A E4T C3S D1S D1A D1Q D2S
D2A D3A D6A D7A D8A D9A E7S E7D E8S E8D
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-China
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Japan
MT 7577: E2J E3J E4J E5J G1J G2J G3J G4J
MT 7580:
MT 7583: A2J A3J A4J A5J A1J A6J B1J B2J B3J B4J B5J B6J B7J B8J B9J
MT 7584: B5J B6J B7J
MT 7589:
MT 7597: CTO A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J D1J D2J G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Brazil
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO A1P A2P A3P A4P D1P D2P
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

174

ThinkCentre Hardware Maintenance Manual

Power Cords --secondary

FRU #

CRU

41R3177

41R3197

41R3261

41R3279

Line cord- LA (High Voltage) Argentina, Paraguay and Uruguay

MT 7577:
MT 7580:
MT 7583:
MT 7584: BIY B2Y
MT 7589: A1Y A2Y A3Y
MT 7597: CTO C2Y C3Y C4Y C5Y C6Y E7Y EE8Y
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord- ANZ
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Korea
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Taiwan
MT 7577: D2V D3V D4V D5V D6V
MT 7580:
MT 7583:
MT 7584:
MT 7589: B1V B2V
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

175

Power Cords --secondary

FRU #

CRU

41R3233

41R3213

41R3229

41R3237

Line cord-Italy
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: BIS BIY B2S B2Y B3G B4G
MT 7589: A1S A1Y A2S A2Y A3Y A3S B3G B4G
MT 7597: CTO C2S C2Y C3Y C4S C4Y C5S C5Y C6S C6Y C3S A5G D1S E7S
E7Y E8S E8Y
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-Denmark
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-Switzerland
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-Israel
MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A5G A6G
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

176

ThinkCentre Hardware Maintenance Manual

Power Cords --secondary

FRU #

CRU

41R3221

41R3175

41R3209

41R3225

Line cord-South Africa

MT 7577: D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO D4A D5A D0A E1A E2A E4A A5G D1A D2A D3A D6A D7A D8A D9A
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Line cord-India
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO E5Q E6Q D2Q
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Indonesia, Laos, Cambodia and Vietnam, Austria, Belgium, Croatia,
Czechoslovakia, Finland, France, Germany, Hungary, Netherlands, Norway, Poland,
Portugal, Romania, Spain, Sweden
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Line cord-Hong Kong, Singapore, Malaysia, Brunei, UK, Ireland
MT 7577: B7B B8B B9B D1B D8G E1G
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589: B3G B4G
MT 7597: CTO A7B A9B C7B C8B C9B D1B D2B D4A D5A D0A E1A E2A E4A A8B
A5G D1A
MT 7598: B1G B2G B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

177

Recovery discs
Windows 7 Home Basic 32 Recovery CD
Windows 7 Home Basic 32

FRU #

CRU

03T1184

03T1189

03T1188

03T1190

Arabic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Turkish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Serbian-Latin
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

178

ThinkCentre Hardware Maintenance Manual

Windows 7 Home Basic 32

FRU #

CRU

03T1187

03T1185

03T1186

FRU #

CRU

03T1194

Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Brazilian Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
India English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Windows 7 Home Premium 32 Recovery CD

Windows 7 Home Premium 32
Japanese
MT 7577:
MT 7580:
MT 7583: A6J B2J B9J
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

179

Windows 7 Home Premium 32

FRU #

CRU

03T1191

03T1193

03T1195

03T1197

Chinese Traditional
MT 7577: D1B D5V
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Hong Kong
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Korean
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

180

ThinkCentre Hardware Maintenance Manual

Windows 7 Home Premium 32

FRU #

CRU

03T1196

03T1192

FRU #

CRU

03T1202

03T1199

Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
India English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Windows 7 Professional 32 Recovery CD

Windows 7 Professional 32
Japanese
MT 7577: E2J E3J E4J E5J G1J G2J G3J G4J
MT 7580:
MT 7583: A2J A3J A4J A5J A1J B1J B3J B4J B5J B6J B7J B8J
MT 7584: B5J B6J B7J
MT 7589:
MT 7597: CTO A0J B1J B2J B3J B4J B5J B6J B7J B8J B9J B0J C1J D1J D2J G1J
G2J G3J G4J G5J G6J G7J G8J G9J H1J H2J H3J
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Chinese - Traditional (Taiwan)
MT 7577: B8B D2V D3V D4V D6V
MT 7580:
MT 7583:
MT 7584:
MT 7589: B1V B2V
MT 7597: CTO D3T D4T D5T D6T D7T D8T D9T D0T E1T E2T E3T E4T
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

181

Windows 7 Professional 32

FRU #

CRU

03T1203

03T1201

03T1205

03T1204

Korean
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598: B1G B2G
MT 7570, 7578, 7594, and 7595_SB
Hong Kong
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
English
MT 7577: B1A B2A B3A B4A B5A B6A D7A D8G D9A E1G E1A
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589:
MT 7597: CTO A5G A6G
MT 7598: B1G B2G
MT 7570, 7578, 7594, and 7595_SB
Spanish
MT 7577: D8G E1A
MT 7580: A0G A1G
MT 7583:
MT 7584: B3G B4G
MT 7589:
MT 7597: CTO A1P A2P A3P A4P D1P D2P
MT 7598: B1G B2G
MT 7570, 7578, 7594, and 7595_SB

182

ThinkCentre Hardware Maintenance Manual

Windows 7 Professional 32

FRU #

CRU

03T1198

03T1200

FRU #

CRU

03T1213

03T1215

Brazilian Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO D4A D5A D0A E1A E2A E4A A5G A6G D1A D1Q E5Q E6Q D2A
D2Q D3A D6A D7A D8A D9A
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
India English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Windows 7 Professional 64 Recovery CD

Windows 7 Professional 64
Hong Kong
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Japanese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

183

Windows 7 Professional 64

FRU #

CRU

03T1211

03T1208

03T1206

03T1209

French
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Chinese-Traditional
MT 7577: B7B B9B
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Arabic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Czech
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB

184

ThinkCentre Hardware Maintenance Manual

Windows 7 Professional 64

FRU #

CRU

03T1212

03T1214

03T1216

03T1217

Greek
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Hungary
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Korean
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Polish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

185

Windows 7 Professional 64

FRU #

CRU

03T1218

03T1219

03T1220

03T1221

Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Romanian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Russian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Slovakian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB

186

ThinkCentre Hardware Maintenance Manual

Windows 7 Professional 64

FRU #

CRU

03T1222

03T1224

03T1225

03T1227

Slovenian
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Sebian- Latin
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Turkish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
C&L EMEA: NL/FR/GR/IT/EN
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

187

Windows 7 Professional 64

FRU #

CRU

03T1226

03T1223

03T1207

03T1210

English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB
Brazilian Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
India English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589: B3G B4G
MT 7597: CTO
MT 7598: B3G B4G
MT 7570, 7578, 7594, and 7595_SB

188

ThinkCentre Hardware Maintenance Manual

Windows XP Professional 32 Recovery CD

Windows XP Professional 32

FRU #

CRU

03T0589

03T0588

FRU #

CRU

03T1178

03T1182

English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597:
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Japanese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597:
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Windows 7 Starter 32 Recovery CD

Windows 7 Starter 32
Arabic
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Turkish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

189

Windows 7 Starter 32

FRU #

CRU

03T1179

03T1180

03T1181

03T1183

Brazilian Portuguese
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
India English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
Spanish
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB
US English
MT 7577:
MT 7583:
MT 7584:
MT 7589:
MT 7597: CTO
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

190

ThinkCentre Hardware Maintenance Manual

Windows 7 Ultimate 32 Recovery CD

Windows 7 Ultimate 32

FRU #

CRU

03T1228

English
MT 7577:
MT 7580:
MT 7583:
MT 7584:
MT 7589:
MT 7597:
MT 7598:
MT 7570, 7578, 7594, and 7595_SB

Chapter 9. FRU lists

191

192

ThinkCentre Hardware Maintenance Manual

Chapter 10. Additional Service Information

This chapter provides additional information that the service representative might find helpful.

Security features
Security features in this section include the following:
Passwords
Vital Product Data
Management Information Format (MIF)

Hardware controlled Passwords

Hardware controlled passwords are set using the Setup Utility program. For more information about
passwords, see Using passwords on page 37.

Operating system password

An operating system password is very similar to a power-on password and denies access to the computer
by an unauthorized user when the password is activated. The computer is unusable until the password is
entered and recognized by the computer.

Vital product data

Each computer has a unique Vital Product Data (VPD) code stored in the nonvolatile memory on the system
board. After you replace the system board, the VPD must be updated. To update the VPD, see Flash
update procedures on page 193.

BIOS levels
An incorrect level of BIOS can cause false errors and unnecessary FRU replacement. Use the following
information to determine the current level of BIOS installed in the computer, the latest BIOS available for the
computer, and where to obtain the latest level of BIOS.
To determine the current Level of BIOS:
Start the Setup Utility.
Select Standard CMOS Features.
Sources for obtaining the latest level BIOS available
1. Lenovo support web site: http://www.lenovo.com/support/
2. Lenovo Customer Support Center
3. Levels 1 and 2 Support
To update (flash) the BIOS, see Flash update procedures on page 193.

Flash update procedures

This section details how to flash (update) the BIOS.

Updating (flashing) the BIOS from a disc

This section provides instructions on how to update (flash) the BIOS from a disc.
Copyright Lenovo 2010, 2011

193

Note: You can download a self-starting bootable disc image (known as an ISO image) with the system
program updates to create a system-program-update disc. Go to:
http://www.lenovo.com/support
To update (flash) the BIOS from a disc, do the following:
1. Turn off your computer.
2. Repeatedly press and release the F12 key when turning on the computer. When the Startup Device
Menu opens, release the F12 key.
3. On the Startup Device Menu, select the desired optical drive as the startup device. Then, insert the
disc into this optical drive and press Enter. The update begins.
4. When prompted to change the serial number, it is suggested that you do not make this change by
pressing N. However, if you do want to change the serial number, press Y, then type in the serial number
and press Enter.
5. When prompted to change the machine type and model, it is suggested that you do not make this
change by pressing N. However, if you do want to change the machine type and model, press Y, then
type in the machine type and model and press Enter.
6. Follow the instructions on the screen to complete the update. After the update is completed, remove the
disc from the optical drive.

Updating (flashing) the BIOS from your operating system

Note: Because Lenovo makes constant improvements to its Web sites, the Web page contents are subject
to change without notice, including the contents referenced in the following procedure.
To update (flash) the BIOS from your operating system, do the following:
1. Go to
http://www.lenovo.com/support.
2. Do the following to locate the downloadable files for your machine type:
a. In the Enter a product number field, type your machine type and click Go.
b. Click Downloads and drivers.
c. Select BIOS from the Refine results drop-down list box to easily locate all the BIOS related links.
d. Click the BIOS update link.
3. Click the TXT file that contains the instructions for updating (flashing) the BIOS from your operating
system.
4. Print these instructions. This is very important because these instructions will not be displayed on
the screen after the download begins.
5. Follow the printed instructions to download, extract, and install the update.

Recovering from a POST/BIOS update failure

If the power to your computer is interrupted while the POST/BIOS is being updated (flash update), your
computer might not restart correctly. If this happens, perform the following procedure commonly called
Boot-block Recovery.
1. Remove all media from the drives and turn off all attached devices and the computer. Then, disconnect
all power cords from electrical outlets and disconnect all cables that are connected to the computer.
2. Remove the computer cover. See Removing the computer cover on page 71.
3. Locate the Clear CMOS /Recovery jumper on the system board. See System board parts and
connectors on page 69.

194

ThinkCentre Hardware Maintenance Manual

4. Move the jumper from the standard position (pin 1 and pin 2) to the maintenance position (pin 2 and
pin 3).
5. Install the computer cover and reconnect all cables and power cords that were disconnected. See
Completing the parts replacement on page 111.
6. Repeatedly press and release the F12 key when turning on the computer. When the Startup Device
Menu opens, release the F12 key.
7. Insert the POST/BIOS update (flash) disc into the optical drive. Then, select the optical drive as the
startup device and press Enter. The recovery session begins.
Note: The recovery session will take two to three minutes. During this time you will hear a series
of beeps.
8. After the recovery session is completed, the series of beeps will end, and the system will automatically
turn off. Remove the disc from the optical drive before the system completely turns off.
9. Repeat steps 1 through 3.
10. Move the Clear CMOS /Recovery jumper back to the standard position (pin 1 and pin 2).
11. Install the computer cover and reconnect all cables and power cords that were disconnected. See
Completing the parts replacement on page 111.
12. Turn on the computer to restart the operating system.

Power management
Power management reduces the power consumption of certain components of the computer such as the
system power supply, processor, hard disk drives, and some monitors.

Automatic configuration and power interface (ACPI) BIOS

Being an ACPI BIOS system, the operating system is allowed to control the power management features
of the computer and the setting for Advanced Power Management (APM) BIOS mode is ignored. Not
all operating systems support ACPI BIOS mode.

Automatic Power-On features

The Automatic Power-On features within the Power Management menu allow you to enable and disable
features that turn on the computer automatically.
Wake from Serial Port Ring: With this feature set to Primary or Automatic and an external modem
connected to serial port (COM1), the computer will turn on automatically when a ring is detected on the
modem following the Primary boot sequence or the Automatic boot sequence.
Wake Up on Alarm: You can specify a date and time at which the computer will be turned on
automatically. This can be either a single event or a daily event.
Wake on LAN: If the computer has a properly configured token-ring or Ethernet LAN adapter card that is
Wake on LAN-enabled and there is remote network management software, you can use the Wake on LAN
feature. When you set Wake on LAN to Enabled, the computer will turn on when it receives a specific
signal from another computer on the local area network (LAN).

Chapter 10. Additional Service Information

195

196

ThinkCentre Hardware Maintenance Manual

Appendix A. Notices
Lenovo may not offer the products, services, or features discussed in this document in all countries. Consult
your local Lenovo representative for information on the products and services currently available in your
area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that
Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service
that does not infringe any Lenovo intellectual property right may be used instead. However, it is the user's
responsibility to evaluate and verify the operation of any other product, program, or service.
Lenovo may have patents or pending patent applications covering subject matter described in this
document. The furnishing of this document does not give you any license to these patents. You can send
license inquiries, in writing, to:
Lenovo (United States), Inc.
1009 Think Place - Building One
Morrisville, NC 27560
U.S.A.
Attention: Lenovo Director of Licensing
LENOVO PROVIDES THIS PUBLICATION AS IS WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow
disclaimer of express or implied warranties in certain transactions, therefore, this statement may not apply
to you.
This information could include technical inaccuracies or typographical errors. Changes are periodically
made to the information herein; these changes will be incorporated in new editions of the publication.
Lenovo may make improvements and/or changes in the product(s) and/or the program(s) described in this
publication at any time without notice.
The products described in this document are not intended for use in implantation or other life support
applications where malfunction may result in injury or death to persons. The information contained in this
document does not affect or change Lenovo product specifications or warranties. Nothing in this document
shall operate as an express or implied license or indemnity under the intellectual property rights of Lenovo
or third parties. All information contained in this document was obtained in specific environments and is
presented as an illustration. The result obtained in other operating environments may vary.
Lenovo may use or distribute any of the information you supply in any way it believes appropriate without
incurring any obligation to you.
Any references in this publication to non-Lenovo Web sites are provided for convenience only and do not in
any manner serve as an endorsement of those Web sites. The materials at those Web sites are not part of
the materials for this Lenovo product, and use of those Web sites is at your own risk.
Any performance data contained herein was determined in a controlled environment. Therefore, the result
obtained in other operating environments may vary significantly. Some measurements may have been
made on development-level systems and there is no guarantee that these measurements will be the same
on generally available systems. Furthermore, some measurements may have been estimated through
extrapolation. Actual results may vary. Users of this document should verify the applicable data for their
specific environment.

Copyright Lenovo 2010, 2011

197

Television output notice

The following notice applies to models that have the factory-installed television-output feature.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.

European conformance CE mark

Trademarks
Lenovo, the Lenovo logo, Rescue and Recovery, ThinkCentre, and ThinkVantage are trademarks of Lenovo
in the United States, other countries, or both.
Microsoft and Windows are trademarks of the Microsoft group of companies.
Intel, Intel Core, and Pentium are trademarks of Intel Corporation in the United States, other countries, or
both.
Linux is a trademark of Linus Torvalds in the United States, other countries, or both.
Other company, product, or service names may be trademarks or service marks of others.

198

ThinkCentre Hardware Maintenance Manual

Index
A

Administrator password 38
ambient light sensor, replacing

LCD panel, replacing 109

Lenovo ThinkVantage Toolbox
Lenovo Welcome 29

97

B
battery, replacing 93
Bluetooth module, replacing
boot-block recovery 194

M
95

memory module 91
installing, replacing 91
microprocessor fan assembly, replacing
multi-touch board, replacing 96

C
card reader, replacing 77
changing
startup device sequence 40
computer cover
removing 71
computer cover, reinstalling 111
connectors
rear 66
connectors, controls, indicators
front 64
considerations, password 38
CRU
completing the installation 111

notice, television output

notices 197

optical drive, replacing

parts replacement, completing 111

password
Administrator password 38
considerations 38
Hard disk drive password 38
setting, changing, deleting 38
PC-Doctor for DOS 33
physical specifications 29
power supply, replacing 79
power switch module, replacing 103
power-on password 38

flashing the BIOS 193

frame stand 70
removing 70
front
connectors, controls, indicators 64
front panel control board, replacing 105

H
72

Copyright Lenovo 2010, 2011

74

40

information
resources 29
installing, replacing
memory module 91
integrated camera with microphone, replacing
internal speakers, replacing 99
inverter, replacing 78

198

hard disk drive, replacing

heat sink, replacing 85

84

E
environment, operating 30
exiting, Setup Utility program

33

100

rear connectors 66
rear I/O assembly, replacing 102
recovering
a POST/BIOS update failure 194
recovery
boot-block 194
Removing
wall mount 80
removing computer cover 71
replacing
ambient light sensor 97
battery 93
Bluetooth module 95
card reader 77
front panel control board 105
hard disk drive 72
heat sink 85

199

integrated camera with microphone

internal speakers 99
inverter 78
LCD panel 109
microprocessor fan assembly 84
multi-touch board 96
power supply 79
power switch module 103
rear I/O assembly 102
right I/O assembly 75, 90
system board 106
system fan 82
WI-FI card 94
resources, information 29
right I/O assembly, replacing 75, 90

100

S
security
enabling or disabling 39
selecting
startup device 39
temporary startup device 39
Set Administrator Password 38
Set Power-On Password 38
settings
changing 37
viewing 37
Setup Utility program 37
Setup Utility program, exiting 40
Setup Utility program, starting 37
starting the Setup Utility program 37
startup device 39
sequence, changing 40
temporary, selecting 39
system board, replacing 106
system fan, replacing 82

T
television output notice 198
temporary startup device 39
the BIOS, updating (flashing) 193194
trademarks 198

U
updating
(flashing) the BIOS 193
updating (flashing) the BIOS 194
using
passwords 37
Setup Utility program 37

V
viewing and changing settings

200

37

ThinkCentre Hardware Maintenance Manual

W
wall mount
Removing 80
WI-FI card, replacing

94

Part Number: 0A22568

Printed in USA

(1P) P/N: 0A22568

*0A22568*
