About this Manual

P/N: 01.54.112597-11
Release Date: July 2013
© Copyright EDAN INSTRUMENTS, INC. 2010-2013. All rights reserved.

Statement
This manual will help you understand the operation and maintenance of the product better. It is
reminded that the product shall be used strictly complying with this manual. User’s operation
failing to comply with this manual may result in malfunction or accident for which EDAN
INSTRUMENTS, INC. (hereinafter called EDAN) can not be held liable.
EDAN owns the copyrights of this manual. Without prior written consent of EDAN, any
materials contained in this manual shall not be photocopied, reproduced or translated into other
languages.
Materials protected by the copyright law, including but not limited to confidential information
such as technical information and patent information are contained in this manual, the user shall
not disclose such information to any irrelevant third party.
The user shall understand that nothing in this manual grants him, expressly or implicitly, any
right or license to use any of the intellectual properties of EDAN.
EDAN holds the rights to modify, update, and ultimately explain this manual.

Responsibility of the Manufacturer

EDAN only considers itself responsible for any effect on safety, reliability and performance of
the equipment if:
Assembly operations, extensions, re-adjustments, modifications or repairs are carried out by
persons authorized by EDAN, and
The electrical installation of the relevant room complies with national standards, and
The instrument is used in accordance with the instructions for use.
Upon request, EDAN may provide, with compensation, necessary circuit diagrams, and other
information to help qualified technician to maintain and repair some parts, which EDAN may
define as user serviceable.

I
Terms Used in this Manual
This guide is designed to give key concepts on safety precautions.

WARNING:
A WARNING label advises against certain actions or situations that could result in personal
injury or death.

CAUTION:
A CAUTION label advises against actions or situations that could damage equipment, produce
inaccurate data, or invalidate a procedure.

NOTE:
A NOTE provides useful information regarding a function or a procedure.

II
 Table of Contents
Chapter 1 Warranty and Service................................................................................................. 1
1.1 Standard Service................................................................................................................. 1
1.2 Limitation of Warranty ...................................................................................................... 1
1.3 Service Procedure............................................................................................................... 1
1.4 Contact Information ........................................................................................................... 3
Chapter 2 Installation and Safety................................................................................................ 4
2.1 Introduction ........................................................................................................................ 4
2.2 General Information ........................................................................................................... 4
2.3 Safety Precautions.............................................................................................................. 5
2.4 Environment Requirements................................................................................................ 6
2.5 Electrical Requirements ..................................................................................................... 7
2.6 Safety Requirements for Installation.................................................................................. 7
2.7 Installing the Monitor......................................................................................................... 7
2.7.1 Install the Monitor on a Flat Surface........................................................................ 7
2.7.2 Mount the Monitor on Wall ..................................................................................... 8
2.7.3 Install the Monitor on Pole Clamp ........................................................................... 8
2.7.4 Install the Monitor on Trolley .................................................................................. 8
Chapter 3 Test and Maintenance................................................................................................. 9
3.1 Routine Test ....................................................................................................................... 9
3.1.1 Visual Inspection...................................................................................................... 9
3.1.2 Power- on Test ......................................................................................................... 9
3.1.3 Key Test ................................................................................................................... 9
3.1.4 Recording Test ......................................................................................................... 9
3.1.5 Alarm Test.............................................................................................................. 10
3.2 Performance Test ............................................................................................................. 10
3.2.1 SpO2 Performance Test .......................................................................................... 10
3.2.2 NIBP Performance Test ......................................................................................... 10
3.2.3 NIBP Leakage Test ................................................................................................ 11
3.2.4 NIBP Calibration.................................................................................................... 11

III
 3.2.5 TEMP Performance Test........................................................................................ 12
3.3 Safety Test........................................................................................................................ 13
3.3.1 Safety Test Procedures........................................................................................... 13
3.3.2 Protective Earth Resistance.................................................................................... 13
3.3.3 Enclosure Leakage Current .................................................................................... 14
3.3.4 Patient Leakage current.......................................................................................... 15
3.3.5 Patient Leakage Current- Single Fault Condition (S.F.C) Mains on Applied Part 16
3.4 Maintenance ..................................................................................................................... 17
3.4.1 Cleaning the Monitor and Accessories .................................................................. 17
3.4.2 Maintaining the Battery.......................................................................................... 17
Chapter 4 System Configuration ............................................................................................... 18
4.1 Enter Factory Maintain .................................................................................................... 18
4.2 Enter Demo Mode ............................................................................................................ 18
4.3 Default Configuration ...................................................................................................... 18
Chapter 5 System Principle........................................................................................................ 19
5.1 Principle ........................................................................................................................... 19
5.1.1 NIBP....................................................................................................................... 20
5.1.2 SpO2 ....................................................................................................................... 20
5.1.3 TEMP ..................................................................................................................... 21
5.2 Principle Block Diagram.................................................................................................. 22
5.2.1 Main Control Board ............................................................................................... 23
5.2.2 Network Interface Board........................................................................................ 32
5.2.3 Power Module ........................................................................................................ 34
Chapter 6 Troubleshooting ........................................................................................................ 36
6.1 Monitor Booting Failure .................................................................................................. 36
6.2 Display Failure ................................................................................................................. 37
6.3 Operation Failure ............................................................................................................. 37
6.4 Network Failure ............................................................................................................... 37
6.5 Power Board Failure ........................................................................................................ 38
6.6 Alarm Failure ................................................................................................................... 38

IV
 6.7 Parameter Failure ............................................................................................................. 38
Chapter 7 Disassembling the Monitor....................................................................................... 41
7.1 Tools Required ................................................................................................................. 41
7.2 Replacing Fuses ............................................................................................................... 41
7.3 Disassembling the Main Unit........................................................................................... 43
7.3.1 Separating Front Housing and Rear Housing......................................................... 43
7.3.2 Taking out the Main Bracket.................................................................................. 45
7.4 Disassembling Rear Panel Assembly............................................................................... 48
7.4.1 Replacing the T2 Module....................................................................................... 48
7.4.2 Replacing the TH Module...................................................................................... 50
7.4.3 Replacing the F3000 Module ................................................................................. 51
7.4.4 Replacing X2 Module ............................................................................................ 53
7.4.5 Replacing Power Module....................................................................................... 54
7.4.6 Replacing Network Module ................................................................................... 55
7.4.7 Replacing Speaker.................................................................................................. 56
7.5 Disassembling Front Panel Assembly.............................................................................. 58
7.5.1 Replacing Main Control Board .............................................................................. 58
7.5.2 Replacing LCD Screen........................................................................................... 60
Chapter 8 Renewal Parts............................................................................................................ 61
Appendix 1 Specifications .......................................................................................................... 62

V
M3A Vital Signs Monitor Service Manual Warranty and Service

Chapter 1 Warranty and Service

1.1 Standard Service
EDAN provides a one-year-warranty for the warranted products (accessories are included). The
warranty period begins on the date the products are shipped to customers. If a customer promptly
notifies EDAN of customer’s warranty claim hereunder, EDAN will either repair, adjust or
replace (with new or exchange replacement parts) EDAN’s products. EDAN warrants that any
service it provides to customers will be performed by trained individuals in a workmanlike
manner.

1.2 Limitation of Warranty

Direct, indirect or final damage and delay caused by the following situations for which EDAN is
not responsible may void the warranty:
♦ Groupware is dismounted, stretched or redebugged.
♦ Unauthorized modification or misuse.
♦ Damage caused by operating beyond the environmental specifications for the medical
product.
♦ Change or remove original serial number label or Manufacturer symbol.
♦ Improper use.

1.3 Service Procedure

(1) Fill in the Service Claim Form (SCF).
Fill in the SCF with detailed information including: Model Name, Serial Number (SN) and
Problem Phenomena.
EDAN should not have any obligation to take over the case without this information. The form
can be downloaded at: http://www.edan.com.cn or obtained from EDAN’s Service Department.
(2) Send EDAN the SCF and Select a Solution.
Once the service department receives the fully filled SCF, EDAN’s engineer will offer a solution
in three working days. EDAN will follow out the case based on the two conditions below:
Within Warranty:
There are two options:
i) After receiving the Return Material Authorization (RMA) form from EDAN service
department, the customer sends EDAN the defective parts and informs about the shipment
tracking number. Then we will dispatch new part (s) to your confirmed address with
confirmed shipping invoice.

-1-
M3A Vital Signs Monitor Service Manual Warranty and Service

ii) The customer signs the Declaration Form and sends it back by email or fax. This form is
legally certificated to make sure the customer or end-user will return the defective parts to
EDAN on time. We will, at this option, dispatch the replacement one (s) with confirmed
shipping invoice.
NOTE:
1 Both Return Material Authorization Form and Declaration Form are offered by EDAN
service department once the SCF is confirmed by service engineer.
2 The customer is responsible for freight & insurance charges when the equipment is
shipped to EDAN for service, including custom charges. EDAN is responsible for the
freight, insurance & custom charges from EDAN to the customer.

Out of Warranty:
After receiving the RMA form from the service department, the customer sends defective parts to
EDAN in advance. We will analyze the problems and discuss with the customer about either
repairing or replacing the part (s). Once the maintenance fee is invoiced and paid, we will make
sure to dispatch good part (s) to the confirmed address.
NOTE:
The customer is responsible for any freight & insurance charge for the returned product.

(3) Obtain the RMA Form.

Before the shipment of the materials, the customer must obtain an RMA form from our service
department, in which the RMA number, description of returning parts and shipping instructions
are included. The RMA number should be indicated on the outside of the shipping container.
NOTE:
EDAN should not have any obligation to the end-user or customer who returns the goods
without the notification by EDAN’s service department. The sender takes full
responsibility for the accounted fee.

(4) Send the Parts to EDAN.

Follow these recommended instructions:

♦ Please disassemble the parts with anti-static facility, do not touch the parts with naked hand.
♦ Please pack the parts safely before return.
♦ Please put the RMA number on the parcel.
♦ Please describe the returned parts as ‘sample of *****’ and put the total value on the invoice,
and note on the invoice as ‘sample, no commercial value’.
♦ Please confirm the invoice with Edan before shipment.
♦ Please send back the parts after EDAN’s confirmation.

-2-
M3A Vital Signs Monitor Service Manual Warranty and Service

1.4 Contact Information

If you have any question about maintenance, technical specifications or malfunctions of devices,
do not hesitate to contact us.
EDAN INSTRUMENTS, INC.
TEL: +86-755-26898321, 26899221
FAX: +86-755-26882223, 26898330
E-mail: [email protected]

-3-
M3A Vital Signs Monitor Service Manual Installation and Safety

Chapter 2 Installation and Safety

2.1 Introduction
This service manual is a reference for periodic preventive maintenance and corrective service
procedures for the M3A monitor.
It provides troubleshooting information, assembly procedures, instructions for functional testing
and performance verification. It is intended for use only by technically qualified service
personnel.

WARNING
When performing a service procedure, follow the instructions exactly as presented in this
manual. Failure to do so might damage the monitor, invalidate the product warranty or
lead to serious personal injury.

2.2 General Information

The M3A Vital Signs Monitor (hereinafter called monitor) is designed in accordance with the
international safety requirements in IEC/ EN 60601-1 for medical electrical equipment.
Classification information of this equipment is as follows:

Anti-electroshock Type Class I equipment and internal powered equipment

Anti-electroshock Degree SpO2, NIBP: BF
TEMP: CF (T2 module)
BF (TH module, F3000 module)
Ingress Protection IPX1
With T2, TH or F3000 TEMP module: Ordinary
equipment (Sealed equipment without liquid proof)
Degree of Safety in Presence of Not suitable for use in presence of flammable gases
Flammable Gases
Working System Continuous operation equipment

-4-
M3A Vital Signs Monitor Service Manual Installation and Safety

2.3 Safety Precautions

To avoid the possibility of injury, observe the following precautions during the operation of the
instrument.

WARNING
1 The monitor must be serviced only by authorized and qualified personnel. EDAN does
not assume any responsibility for damage or injury if modifications or repairs are
carried out by unauthorized personnel.
2 Use and replace the substitutive parts provided or recommended by EDAN only.
3 The service personnel must be familiar with the operation of this monitor. Refer to
M3A Vital Signs Monitor User Manual for details.
4 Perform periodic safety test to ensure patient safety. Safety tests should include
leakage current measurement and insulation testing. It is recommended to perform
the safety test every two years. You are responsible for any requirements specific to
your country.
5 Disconnect the monitor from power before replacing the fuses which are with the
identical specifications.
6 SHOCK HAZARD – Do not remove the top panel cover during operation or while
power is on. The unit cover must be removed only by authorized service personnel.
7 SHOCK HAZARD – Do not attempt to connect or disconnect the power cord with wet
hands. Make sure that your hands are clean and dry before touching the power cord.
8 Only connect the device with accessories supplied or recommenced by EDAN.
9 Accessory equipment connected to the analog and digital interface must be certified
according to the respective IEC/ EN standards (e.g. IEC/ EN 60950 for data
processing equipment and IEC/ EN 60601-1 for medical equipment). Furthermore, all
configurations shall comply with the valid version of the system standard IEC/ EN
60601-1-1.Anybody that connects additional equipment to the signal input connector
or signal output connector to configure a medical system must ensure that the system
complies with the requirements of the valid version of the system standard IEC/ EN
6060-1-1-1. If you have any question, please consult our technical service department
or your local distributor.
10 Do not remove the battery while AC power is on.
11 Do not directly solder the lead wire and the batter terminal.

-5-
M3A Vital Signs Monitor Service Manual Installation and Safety

CAUTION
1 The device is designed for continuous operation. Avoid splashing water over the
device.
2 Do not operate the device when it is damp or wet. Avoid using the device immediately
after relocating it from a cold environment to a warm and humid environment. If the
monitor gets damp or liquid pours on the monitor, please contact the service
personnel of EDAN.
3 While the battery is charged, used or stored, keep it away from objects or materials
with static electric charges.

2.4 Environment Requirements

The environment where M3A Vital Signs Monitor (hereinafter called monitor) will be used
should be reasonably free from vibration, dust, corrosive or explosive gases, extremes of
temperature, humidity, and so on.
Temperature
Working +5 °C ~ +40 °C
With TEMP: +10 °C ~ +40 °C
Transport and storage -20 °C ~ +55 °C
With TH module: -20 °C ~ +50 °C
Humidity
Working 25% ~ 80% (non-condensing)
Transport and storage 25% ~ 93% (non-condensing)
Altitude
Working 860hPa ~ 1060hPa
Transport and storage 700hPa ~ 1060hPa

CAUTION
1 If the monitor is installed in a cabinet, allow at least 2 inches (5 cm) clearance around
the monitor for proper air circulation; allow adequate accessibility for servicing, and
adequate room for visualization and operation.
2 Ensure the monitor is not subjected to any source of strong electromagnetic
interference, such as CT, radio transmitters, mobile phones base stations, etc.
3 Do not install the monitor in a flammable atmosphere where concentrations of
flammable anesthetics or other materials may occur.
4 Keep the environment clean. Avoid vibration. Keep it far from corrosive medicine,
dust area, high-temperature and humid environment.

-6-
M3A Vital Signs Monitor Service Manual Installation and Safety

2.5 Electrical Requirements

Power Supply Voltage: 100V-240V ~

Frequency: 50Hz/60Hz
Pmax: 70VA
Battery: 14.8 V/4.4 Ah; 14.8 V/2.2 Ah.
FUSE: T1.6AL250VP

2.6 Safety Requirements for Installation

WARNING
Only qualified service engineers shall install this equipment.

CAUTION
1 SHOCK HAZARD- the power receptacle must be a three-wire grounded outlet. A
hospital grade outlet is required. Never adapt the three-prong plug from the monitor
to fit a two-slot outlet. If the outlet has only two slots, make sure that it is replaced
with a three-slot grounded outlet before attempting to operate the monitor.
2 Do not touch signal input or output connector and the patient simultaneously.
3 Equipment and devices that connect to the monitor should form an equipotential
body to ensure effective grounding.
4 Do not switch on the monitor until all cables have been properly connected and
verified.

2.7 Installing the Monitor

2.7.1 Install the Monitor on a Flat Surface
Place the monitor on a flat surface. Make sure the surface does not vibrate, and is free of
corrosive medicine and dust.

-7-
M3A Vital Signs Monitor Service Manual Installation and Safety

Figure 2-1 M3A monitor on a flat surface

2.7.2 Mount the Monitor on Wall

To mount the monitor on a wall, you need to order a Wall Mounting Bracket (02.01.109481).
Please refer to that instruction for details of installation.

2.7.3 Install the Monitor on Pole Clamp

An Assembling Instruction will be delivered with the 1-piece/4-piece Pole Clamp (02.01.109592
or 02.01.109636). Please refer to that instruction for details of installation.

2.7.4 Install the Monitor on Trolley

An Assembling Instruction will be delivered with the Trolley (12.01.109480). Please refer to the
instructions for details of installation.

-8-
M3A Vital Signs Monitor Service Manual Test and Maintenance

Chapter 3 Test and Maintenance

3.1 Routine Test
An overall check of the monitor, including safety check and functional check, should be
performed by qualified personnel every 24 months or after service.

3.1.1 Visual Inspection

Before using the monitor:
Inspect the monitor and accessories for obvious signs of damage.
Check the external cables, power socket and power cable.
Do not use the monitor if any damage is detected until the monitor is repaired by the service
engineers of EDAN or professional service personnel of the dealer.

3.1.2 Power- on Test

Switch on the monitor after it is connected to the power source and check:
If the power indicator lights up;
If the alarm indicators flicker and if the alarm tone is heard;
If some images and characters are missing;
If there are bright spots and dark shadows on the LCD screen;
If the waveforms, fonts and symbols displayed on the LCD screen are normal.
If any failure is detected, refer to section Monitor Booting Failures and Display Failures for
details.

3.1.3 Key Test

Press the keys on the front panel in turn to check if they work properly. When pressing a key, a
corresponding functional display is supposed to be seen onscreen. Refer to M3A Vital Signs
Monitor User Manual for details about the key function.

3.1.4 Recording Test

Check if the recorder can perform printing without problem. Also, check if all the printed traces
are correct and clear on the paper.
If any failure is detected, refer to section Recorder Failures for details.
NOTE:
Please make sure paper is well loaded and the setting is correct before printing.

-9-
M3A Vital Signs Monitor Service Manual Test and Maintenance

3.1.5 Alarm Test

Trigger a signal that is higher than the upper limit or lower than the lower limit to activate a
physical alarm. Disconnect one of the accessories from the monitor to activate a technical alarm.
Check if the audible and visible alarms work properly.
If any failure is detected, refer to section Alarm Failures for defective details.

3.2 Performance Test

WARNING
1 Performance tests must only be carried out by qualified service personnel.
2 If performance of the monitor is in question, conduct an overall performance test
according to the instructions offered by the manufacturer.

A functional check should be performed once possible device malfunction emerges or after
servicing the device.
It is unnecessary to open the device case for functional checks.

3.2.1 SpO2 Performance Test

This test checks the performance of the SpO2 measurement. A SpO2 simulator is required for this
test.
1. Connect the monitor and the SpO2 simulator with a SpO2 cable.
2. Switch on the monitor and the simulator.
3. Set the SpO2 output in the simulator to 70(%).
4. Check for the display on the monitor. A difference within the range of ±2% is reasonable.

3.2.2 NIBP Performance Test

This test checks the performance of the NIBP measurement. Tools required for this test are: a
NIBP simulator, a T-fitting, an extension tube and an artificial limb.
1. Connect the NIBP simulator to the monitor.
2. Switch on the monitor and the simulator. Perform calibration prior to using the simulator.
3. Set the patient type both on the monitor and in the simulator to adult; respectively set the
systolic pressure and diastolic pressure (mean pressure) to 255/195(215) mmHg. Start a
NIBP measurement.
4. Check for the display on the monitor. A difference within the range of ±8mmHg is
reasonable.

- 10 -
M3A Vital Signs Monitor Service Manual Test and Maintenance

3.2.3 NIBP Leakage Test

This test checks leakage of the airway. See Figure 3-1 for details about tools required.
1. Connect the cuff securely with the socket for NIBP air hole.
2. Wrap the cuff around the cylinder with an appropriate size.
3. Access Main Menu > Maintenance > User Maintenance by inputting the password 9981.
Start a leakage test by selecting NIBP MAINTAIN > Leak Test.
The system will automatically inflate the pneumatic system to 180 mmHg. After 20 seconds, the
system will automatically open the deflating valve, which marks the completion of a pneumatic
measurement.
If the alarm information of AIR LEAK appears, it indicates that the airway may have air leaks.
In this case, the user should check for loose connection. After confirming secure connections, the
user should re-perform the pneumatic test. If the failure prompt still appears, please contact the
manufacturer for repair.

Figure 3-1 Diagram for NIBP Leakage Test

3.2.4 NIBP Calibration

NIBP calibration must be performed by professional personnel authorized by EDAN.
NOTE:
NIBP calibration is for checking the measurement accuracy and cannot change the
measurement results.
Tools required are: a T-fitting, NIBP extension tubes, a cylinder and a manometer.
Procedure:
1. Connect the equipment as shown below:

Figure 3-2 Diagram for NIBP Calibration

- 11 -
M3A Vital Signs Monitor Service Manual Test and Maintenance

2. Access Main Menu > Maintenance > User Maintenance by inputting the password 9981.
Select NIBP Setup > Calibration.
3. Apply fixed static pressure on the monitor with the help of the manometer. Compare the
displayed values on the monitor with the manometer values.
4. A difference within the range of ±3mmHg is reasonable.

3.2.5 TEMP Performance Test

This test checks the performance of the TEMP measurement.
For T2 TEMP module:
1. Switch on the monitor and the resistance box.
2. Connect the probe with the resistance box.
3. Set the resistance value to (9571Ω) 26℃ in the resistance box.
4. Set the resistance value to (6014Ω) 37℃ in the resistance box.
5. Set the resistance value to (4542Ω) 44℃ in the resistance box.
6. A tolerance of ±0.1℃ is reasonable.

For TH TEMP module:

1. Place the thermometer in the calibration mode follow the steps below:
a Press the ON/MEM button to turn the thermometer on. The display of the thermometer
shows symbols and functions.
b Keep pressing the ON/MEM button for five seconds and you will see the “OFF” symbol on
the display. Do not release the button until you see a dot onscreen.
c The thermometer is now in the Calibration Mode and the display is flashing and showing
the “CAL” symbol.
2. Apply a new probe cover.
3. Position the thermometer making the end of the probe against the cavity inside the
thermostatic water bath whose temperature is set to 37℃. Press the “Scan” button for 1
second until you hear a long beep sound. The measurement is completed. You can read the
result from LCD.
4. The displayed value should be 37℃±0.1℃.

For F3000 TEMP module:

1. Remove the isolation chamber/probe from the monitor unit.
2. Install the calibration plug into the visible connector.
3. Switch on the monitor.
4. Insert the probe into the opening in the top of the unit until the tip of the probe reaches the
bottom and three beeps are sounded.
5. The displayed value should be 37℃±0.1℃

- 12 -
M3A Vital Signs Monitor Service Manual Test and Maintenance

3.3 Safety Test

3.3.1 Safety Test Procedures
Use the test procedures outlined here only for verifying safe installation or service of the product.
These tests are not a substitute for local safety testing where it is required for an installation or a
service event.
When performing a safety test, you must use a standard safety analyzer such as Fluke 601Pro
Series safety analyzer or equivalent, perform the test according to your local regulations, for
example, in Europe according to IEC/EN60601-1, IEC/EN60601-1-1, in USA according to
UL60601-1. For the test setup, please refer to the Instructions for Use of the test equipment used.
Additional test may be required by your local regulations.
You are recommended to document the result of the safety test.
NOTE:
1 When testing according to IEC 60601-1, system must be tested and not individual
devices.
2 Systems must be handled as devices.
3 A system is a combination of several devices of which at least one is a medical
electrical device which is connected to other devices by functional connections or by
a transportable multiple socket outlet.
4 With devices that are connected to other devices by means of a data cable, this
connection must be disconnected prior to performing the electrical safety check, in
order to avoid incorrect measurements.

3.3.2 Protective Earth Resistance

- 13 -
M3A Vital Signs Monitor Service Manual Test and Maintenance

NOTE:
The circuit diagram is based on the Fluke 601Pro series safety analyzer.
This measures impendence of Protective Earth (PE) terminal to accessible metal part of Device
under test (DUT) which is protectively earthed. A current of 25A is passed for 5s to 10s through
the protective terminal and each accessible metal part which is protectively earthed.
Allowable value: without mains cable, maximum impendence: 100 mOhms
(IEC 60601-1 and UL60601-1)

3.3.3 Enclosure Leakage Current

NOTE:
The circuit diagram is based on the Fluke 601Pro series safety Analyzer.
This measures leakage current of exposed metal parts of Device under test (DUT) and parts of the
system within the patient environment; normal and reversed polarity using S2 test performed both
in normal condition and single fault conditions.
Normal condition (NC): with S1, S3, S5 closed, S2, S4 variable.
Single fault condition (SFC): S1, S3 open (one for each time) and S5 closed, S2, S4 variable.
Allowable value:
Normal condition: 100µA (IEC/EN60601-1)
Single fault condition: 500µA (IEC/EN60601-1)
Normal condition: 100µA (UL60601-1)
Single fault condition: 300µA (UL60601-1)

- 14 -
M3A Vital Signs Monitor Service Manual Test and Maintenance

3.3.4 Patient Leakage current

NOTE:
The circuit diagram is based on the Fluke 601Pro series safety Analyzer.
This test measure the leakage current flowing between the selected applied part and the mains PE;
the test with normal and reverse polarity, in normal condition and single fault condition.
Normal condition (NC): with S1, S3, S5 closed, S2, S4 variable.
Single fault condition (SFC): S1, S3 open (one for each time) and S5 closed, S2, S4 variable.
Allowable value:
Normal condition: 10µA (BF applied part), 10µA (CF applied part)
(IEC/EN60601-1, UL60601-1)
Single fault condition: 500µA (BF applied part), 50µA (CF applied part)
(IEC/EN60601-1, UL60601-1)

Leakage Current

Applied Normal Single Fault

Part Condition Condition
Earth Leakage Current <0.5 mA <1 mA
Enclosure Leakage Current <0.1 mA <0.5 mA

- 15 -
M3A Vital Signs Monitor Service Manual Test and Maintenance

Applied Normal Single Fault

Part Condition Condition
AC: <0.01 mA AC: <0.05 mA
CF
DC: <0.01 mA DC: <0.05 mA
Patient Leakage Current
AC: <0.1 mA AC: <0.5 mA
BF
DC: <0.01 mA DC: <0.05 mA

Patient Leakage Current (Mains on CF <0.05 mA

Applied Parts)
BF <5 mA
AC: <0.01 mA AC: <0.05 mA
CF
DC: <0.01 mA DC: <0.05 mA
Patient Auxiliary Current
AC: <0.1 mA AC: <0.5 mA
BF
DC: <0.01 mA DC: <0.05 mA

3.3.5 Patient Leakage Current- Single Fault Condition (S.F.C)

Mains on Applied Part
NOTE:
The following test is based on test with the Fluke 601 pro series safety analyzer. This
device allows applying a 110% mains voltage between the applied part and the device PE.
When testing with other device, you may need to apply the 110% mains voltage manually.

- 16 -
M3A Vital Signs Monitor Service Manual Test and Maintenance

NOTE:
The circuit diagram is based on the Fluke 601Pro series safety Analyzer.
This test measure the current flowing between the applied part and the mains PE in response to an
isolate mains voltage (110% of the mains voltage) applied to applied part. This test is performed
with normal and reverse polarity of the mains voltage using S2, and normal and reverse polarity
of the isolate voltage using S4.
Single fault condition: S1, S3, S5 closed, S2, S4, S6 variable.
Allowable value:
Single fault condition (110% mains voltage on applied part):
5000µA (BF applied part), 50µA (CF applied part)
(IEC/EN 60601-1 UL 60601-1)

3.4 Maintenance
For details about basic cleaning and maintenance methods, refer to relevant sections in M3A Vital
Signs Monitor User Manual. For further technical support, contact service engineers of EDAN.
Users are responsible for preventive maintenance and periodic inspection for the monitor.

3.4.1 Cleaning the Monitor and Accessories

Refer to relevant sections in M3A Vital Signs Monitor User Manual for details.

3.4.2 Maintaining the Battery

Refer to relevant sections in M3A Vital Signs Monitor User Manual for details.

- 17 -
M3A Vital Signs Monitor Service Manual System Configuration

Chapter 4 System Configuration

The end users can not change the system configuration of the monitor. As a service engineer, you
need to change the configuration for them after the monitor is installed and checked properly.

NOTE:
Restart the monitor after changing the settings.

4.1 Enter Factory Maintain

Select Maintenance in Main Menu to open the Maintenance menu. Factory Maintenance is
only available for the service engineers of EDAN or representatives authorized by EDAN.
Input the factory password 9 9 8 0 in the Enter Password box and press Confirm.
Factory Maintenance menu will pop up, in which you can set the following items.
－ Module: you can set the configuration function.
－ Reset All Config: you can reset all the configuration of the monitor by this item.
－ Firmware Update: connect the PC and monitor by network cable, then you can do online
update.

4.2 Enter Demo Mode

Press the MENU button to display Main Menu, then select Maintenance > Demo, Input the
demo password 3 0 4 5 in the Enter Password box and press Confirm to enter Demo mode.

4.3 Default Configuration

Press the MENU button to display Main Menu, select System Setup > Default Configuration
to display the Default Configuration menu.

NOTE:
Select any item in this submenu to cancel the current setup and use the selected default
setup.
♦ Factory Default Config: select the factory default configuration;
♦ User Default Config: select the user-defined default configuration;
♦ Restore Selected Config: select this item to restore the selected configuration;
♦ Save as User Default Config: save the current setup as the user default configuration;
♦ Exit: exit this submenu and return to the previous menu.

- 18 -
M3A Vital Signs Monitor Service Manual System Principle

Chapter 5 System Principle

This chapter introduces the structure and principle of the monitor, as well as the principles and
port definitions of the modules.

5.1 Principle
Parameter module is the basic unit to acquire signals for monitoring parameters in monitor. The
monitoring signals are transmitted to main control board to accomplish processing and displaying
of data and waveforms. The power link board can realize power switching and conversion. The
whole system structure is shown in the following figure:

Medical staff

Key control LCD Recorder

board

Display
driver board

Main control Network

Power supply interface
board
board

NIBP SpO2 TEMP

Patient

Figure 5-1 System structure

As shown in the above figure, the three parameter modules execute real-time monitoring of NIBP,
SpO2, and TEMP respectively by using cuff and measuring cables, the results can be sent to main
control board for processing and displaying. Hereinafter the function details of parameter monitor
will be explained.

- 19 -
M3A Vital Signs Monitor Service Manual System Principle

5.1.1 NIBP
Blood pressure monitors commonly measure arterial pressure, which is produced by the
contraction of the heart and constantly changes over the course of cardiac cycle. Three blood
pressure values, expressed in millimeters of mercury above atmospheric pressure, are obtained.
The systolic pressure is the maximum cycle pressure; which occurs during ventricular contraction.
The diastolic pressure is the minimum cycle pressure, occurring during the ventricle’s filling
stage between contractions. The means arterial pressure (MAP) is the mean value of the blood
pressure over the cardiac cycle.
The monitor measures non-invasive blood pressure using the oscillometry method. The following
are detailed measurement procedures. Inflate the cuff encircling the upper arm until the pressure
in the cuff blocks the blood flow in the artery of the upper arm. Then deflate the cuff gradually
according to the requirement of certain arithmetic. With the decreasing of the pressure in the cuff,
the artery blood will palpitate with the pulse, which results in palpitation in the cuff. Through the
pressure sensor connected with the inflating pipe of the cuff, a palpitation signal palpitating with
the pulse will be generated. After being filtered by a high-pass filter (about 1Hz), this signal
becomes pulsating signal and is amplified. Then the amplified signal is converted into digital
signal by A/D. After using the singlechip to process this digital signal, we may obtain systolic
pressure, diastolic pressure and mean pressure. Be careful to choose appropriate cuffs for
neonatal, pediatric and adult patients so as to avoid generating measurement error. NIBP module
also has protection circuit to prevent the cuff from being inflated to a very high pressure. The
following are the main operating modes of NIBP.
a. Adult/pediatric/neonate: select according to the patient shape, weight and age.
b. Manual measurement/auto measurement/continuous measurement: Manual measurement is
also called single measurement. It means the monitor performs only one measurement each
time. Auto measurement means to perform one measurement within selected cycle. Time
interval can be set to 1, 2, 3, 4, 5, 10, 15, 30, 60, 90, 120, 240 or 480 minutes. Continuous
measurement means after being activated, the monitor will perform quick measurement
continuously within 5 minutes. Continuous measurement is effective in monitoring changes
in blood pressure.

5.1.2 SpO2
SpO2 is based on the absorption of pulse blood oxygen to red and infrared light by means of
finger sensor and SpO2 measuring unit. The light-electronic transducer in finger sensor converts
the pulse red and infrared light modulated by pulse blood oxygen into electrical signal, the signal
is processed by hardware and software of the unit. The PLETH curve and numeral value of SpO2
will be obtained.
By tracing the pulse waveform in the fingertip, using specified arithmetic and consulting the
clinical data table, we can obtain the SpO2 value. The SpO2 sensor consists of two LEDs and a
photodetector. The two LEDs are respectively red diode and infrared diode, which are lighted on
according to certain time sequence. When the capillary vessel of the fingertip congests repeatedly,
the light of the LED is absorbed by blood vessels and organs and then projected onto the
photodetector. The photodetector can detect the light intensity varying with pulse changes and

- 20 -
M3A Vital Signs Monitor Service Manual System Principle

display the changing light intensity in the form of changing electronic signals. The ratio between
the DC and AC of the two types of signals for light is the proportion of oxygen in the blood. Then
we can calculate correct SpO2 value by using specified arithmetic and also calculate pulse rate
according to the SpO2 waveform.
The SpO2 module mainly consists of the following four parts: sensor, signal processing, control
unit of LED driving sequence, singlechip.

5.1.3 TEMP
Three optional modules are available for TEMP measurement. They are T2 module, TH module
and F3000 module.
Regarding the T2 module and F3000 module, the temperature of human body is first converted
into electronic signals, which are then amplified by amplifier and processed. In this way we can
obtain the TEMP value. The circuit includes proportional amplifier constructed by operational
amplifiers. The temperature passes the thermal sensor, producing pressure signals, which are
amplified and transmitted to A/D converter for further processing.
The TH module works on the principle of infrared radiation. It can quickly take a temperature in
the ear in a non-contact way. The measurement value will be displayed on the LCD of the
thermometer within one second and transmitted to the monitor via communication wire. The
monitor consequently displays and stores the measurement value.

- 21 -
M3A Vital Signs Monitor Service Manual System Principle

5.2 Principle Block Diagram

The following figure shows the hardware structure of the whole monitor and the connection
relationships between different parts. The boards displayed in the figure are the core part of the
monitor, i.e. main control board and parameter board.

Figure 5-2 Block diagram of monitor

NOTE:
The nurse call board and the network board are optional configurations; they can not be
installed at the same time. If you want to use the nurse call function, you should install the
nurse call board; otherwise you should install the network board.

- 22 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.1 Main Control Board

The block diagram of main control board is displayed as follows:

7-segment
数码管+LED显示
+LED display

7-segment Communication
数码管显示驱动
display driver 通信接口
port

LCD display
LCD显示
Main control
主控制器
unit
LCD display
LCD显示驱动
driver

Power Keyboard
电源管理
management 按键

Figure 5-3 Block diagram of main control board

Main control board is the core module of the system; it can realize the functions of display,
keyboard input, alarm control, module control, etc.
According to the function, main control board consists of main control unit, power management,
LCD display driver, 7-segment display driver, communication port and keyboard. The main
control unit adopts Cortex-M3 core, the display adopts 7-segment and LCD and the keyboard can
realize the basic information input.
There are different ports on main control board, the port definitions are displayed as follows.

- 23 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.1.1 Power Input Port

Pin NO. Definition

Power input 1 +5V
2 GND
3 GND
4 +12V

5.2.1.2 Input Port of Power Control Signal

Pin NO. Definition

Power control 1 PWR_TXD
2 PWR_RXD
3 GND
4 PWR_CHARGE
5 PWR_ACON
6 PWR_SWITCH
7 GND

- 24 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.1.3 X2 Module Port

Pin NO. Definition

X2 module 1 NC
2 +5V
3 +12V
4 GND
5 X2_TXD
6 X2_RXD

5.2.1.4 T2 Module Port

Pin NO. Definition

T2 Module 1 5V
2 GND
3 T2_TXD
4 T2_RXD

- 25 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.1.5 TH module Port

Pin NO. Definition

TH Module 1 5V
2 GND
3 T2_TXD
4 T2_RXD

5.2.1.6 F3000 Module Port

Pin NO. Definition

F3000 Module 1 5V
2 GND
3 T2_TXD
4 T2_RXD

- 26 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.1.7 Network Interface Board Port

J5

Pin NO. Definition

Network module 1 3.3V
2 GND
3 LAN_TXD
4 LAN_RXD

5.2.1.8 Recorder Port

- 27 -
M3A Vital Signs Monitor Service Manual System Principle

Pin NO. Definition

Recorder 1 PPRT_STB
2 PPRT_D0
3 PPRT_D1
4 PPRT_D2
5 PPRT_D3
6 PPRT_D4
7 PPRT_D5
8 PPRT_D6
9 PPRT_D7
10 PPRT_ACK
11 PPRT_BUSY
12 PPRT_PE
13 PPRT_ERR
14 GND
15 GND
16 NC
17 NC
18 NC
19 NC
20 GND

5.2.1.9 Speaker Port

J7

Pin NO. Definition

Speaker 1 AUDIO_IN
2 AUDIO_OUT

- 28 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.1.10 FPC Port of LCD Screen

- 29 -
M3A Vital Signs Monitor Service Manual System Principle

Pin NO. Definition

FPC port of LCD 1 BL_FB
screen
2 BL_FB
3 V_BACKLIGHT
4 V_BACKLIGHT
5 NC
6 NC
7 NC
8 LCD_RESET
9 NC
10 NC
11 NC
12 BB0
13 BB1
14 BB2
15 BB3
16 BB4
17 BB5
18 BB6
19 BB7
20 GG0
21 GG1
22 GG2
23 GG3
24 GG4
25 GG5
26 GG6
27 GG7
28 RR0
29 RR1
30 RR2
31 RR3
32 RR4
33 RR5

- 30 -
M3A Vital Signs Monitor Service Manual System Principle

34 RR6
35 RR7
36 HSYNC
37 VSYNC
38 DCLK1
39 NC
40 NC
41 +3V3
42 +3V3
43 NC
44 NC
45 NC
46 NC
47 NC
48 GND
49 GND
50 GND
51 NC
52 GND
53 GND
54 GND

5.2.1.11 Nurse Call Port

J9

Pin NO. Definition

Nurse call 1 +12V
2 NURSE_CALL
3 GND

- 31 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.1.12 JTAG Port

Pin NO. Definition

Nurse call 1 +3V3
2 TDI
3 TMS
4 TCK
5 TDO
6 GND

5.2.2 Network Interface Board

5.2.2.1 Nurse Call Port

Pin NO. Definition

Nurse call 1 +12V
2 NURSE_CALL
3 GND

- 32 -
M3A Vital Signs Monitor Service Manual System Principle

5.2.2.2 Communication Port

Pin NO. Definition

Communication 1 3.3V
port
2 GND
3 TXD
4 RXD

5.2.2.3 Network Port

- 33 -
M3A Vital Signs Monitor Service Manual System Principle

Pin NO. Definition

Network port 1 ETN_TX+

2 ETN_TX-
3 ETN_RX+
4 NC
5 GND1
6 ETN_RX-
7 T1
8 T2

5.2.3 Power Module

The power module can provide DC power supply to other boards.

Principle Block Diagram

Battery

Fan

Power
module

Power control
board

Figure 5-4 Block diagram of power board

Principle Introduction
This module converts +220 V AC mains power supply or battery power into +5 V and +12 V DC
supplies to power other boards. If AC mains and battery coexist, the former take the priority to
power the system and charge the latter at the same time.

AC/DC
Converts high-voltage AC supply into low-voltage DC supply to power subsequent circuits and
charge the battery.

- 34 -
M3A Vital Signs Monitor Service Manual System Principle

Battery Control Circuit

If AC supply and battery coexist, this circuit controls the output from AC/DC part to charge the
battery. If AC supply is disconnected, this circuit controls the battery to power the subsequent
circuits.

+5 V DC
Convert the DC supply from the previous circuit into stable +5 V DC supply to power other
boards.

+12 V DC
Convert the DC supply from the previous circuit into stable +12 V DC supply to power other
boards.

Power Switch Circuit

Control the working status of +5 V DC and +12 V DC in order to control ON/OFF action of the
monitor.

Voltage Detection Circuit

Detects the output voltage of every part in detection circuit, converts analogue signals to digital
signals and then send them to main control board for processing.

- 35 -
M3A Vital Signs Monitor Service Manual Troubleshooting

Chapter 6 Troubleshooting
In transportation, storage and use of monitor, various factors such as unstable network voltage,
changing environmental temperature, falling-down or impact, component aging may all result in
monitor failures and therefore affect normal application of the device. In failure conditions,
professional personnel with the experience of repairing electronic medical devices should
perform component-level upkeep for the failure classification listed in the table below.
Component-level upkeep means based on analyzing, replacing or trial-operating the component,
we can pinpoint the failure on a certain component of the device, such as power board, main
control board, LCD assembly, measuring cable or parameter module, etc. Repair of only some
components means component-level repair. The repair operation must be conducted by a service
engineer with abundant experience and with the assistance of special equipment and in specific
environment and conditions.

6.1 Monitor Booting Failure

Phenomenon Possible Cause Solution

After switching on, LCD ① Fuse damage (If it has fuse ① Replace fuse
has no display; the power on)
② Replace power board
indicator is off.
② Power board damage
③ Anchor the short-circuited
③ Component short-circuits. component.

No display after power-on Main control board failure or Refer to section 6.2 Display
or black screen during display failure. Failure.
operation, however,
power indicator lights.

Operation or Main control board or Examine the main control

measurement function is corresponding component board and the corresponding
disabled. damage. components.

Device is occasionally ① Moment intensive ① Check power supply and

stoned. interference of network. grounding system.
② Poor performance of power ② Replace power board.
board.
③ Replace main control
③ Poor performance of main board.
control board.
④ Replace or repair
④ Bad connection of power connectors.
supply or main control board.

- 36 -
M3A Vital Signs Monitor Service Manual Troubleshooting

6.2 Display Failure

Phenomenon Possible Cause Solution

Characters are displayed Data communication error Replace the main control
normally, however between main control board and board or parameter module
waveforms are displayed parameter module. based on the error prompt.
intermittently.

When powering on the ① The wire for connecting ① Repair or replace

device, power supply is in display screen is damaged. connecting wire.
normal operation, however,
② Damage of main control board. ② Replace main control
there is no display or the
board.
screen goes black during ③ Damage of power board.
normal operation. ③ Replace power board.

LCD displays improper

LCD screen has failure. Replace the LCD screen.
character.

6.3 Operation Failure

Phenomenon Possible Cause Solution

Buttons or the rotary Main control board has failure. Replace buttons or main control
knob is disabled. board.
Sound of speaker is ① Audio part of main control ① Replace main control board.
raucous or there is no board has failure.
② Replace speaker or connecting
sound.
② Speaker or connecting wire wire.
has failure.

6.4 Network Failure

Phenomenon Possible Cause Solution

① Network linking wire is ① Check and repair network linking

The monitor can not damaged wire.
be linked to the
② Network bed NO. conflicts ② Change bed NO.
network.
③ Main control board failure ③ Replace main control board

- 37 -
M3A Vital Signs Monitor Service Manual Troubleshooting

6.5 Power Board Failure

Phenomenon Possible Cause Solution

Fuse is burned upon power-on. Short circuit occurs in power Check after power on the
supply or other parts. monitor.

Fuse is burned although all loads Power board failure. Replace power board.
are disconnected.

Fuse is burned after connecting a Short circuit occurs in this Replace this part.
part. part.

6.6 Alarm Failure

Phenomenon Possible Cause Solution

No audible alarm is ① Audio alarm is ① Switch on the audible alarm.

activated. temporarily disabled.
② Replace the speaker or the
② Speaker and its wire.
connecting wire has
failure.

The alarm indicator stays Alarm indicator has failure. Replace the alarm indicator; if
off. there is no alarm indicator for
replacing, change main control
board.

No audible alarm or visual Program failure Update the software.

alarm is activated.

6.7 Parameter Failure

Phenomenon Possible Cause Solution

NIBP function of X2 ① The connection of X2 ① Check the connection

module communication module and main control between boards.
stops. board has failure.
② Replace X2 module.
② NIBP function of X2 module
③ Replace main control board.
has failure.

③ Main control board has

failure.

- 38 -
M3A Vital Signs Monitor Service Manual Troubleshooting

NIBP cuff can not be Airway is folded or has leakage. Adjust or repair the airway.
inflated.

Blood pressure can not Cuff becomes loose or patient is Keep the patient quiet, bind the
be measured moving. cuff correctly and safely.
occasionally.

Error of NIBP ① Cuff size does not fit the ① Use the cuff of appropriate
measurement is too big. patient. size.
② X2 module has bad ② Replace NIBP module.
performance.

SpO2 function of X2 ① The connection of X2 ① Check the connection

module communication module and main control between boards.
stops. board has failure.
② Replace X2 module.
② SpO2 function of X2 module
③ Replace main control board.
has failure.
③ Main control board has
failure.

No SpO2 waveform Sensor or SpO2 module is Replace the sensor.

damaged.

SpO2 waveform has ① Patient is moving. ① Keep the patient quiet.

strong interference.
② Environment light is very ② Weaken the light intensity in
intensive. the environment.

SpO2 value is inaccurate Coloring agent has been injected Remove the coloring agent before
into patient body. measurement.

No TEMP value (for ① TEMP sensor has failure. ① Replace the TEMP sensor.
T2 module)
② The connection of TEMP ② Check the connection.
sensor has failure.
③ Replace the T2 module.
③ T2 module has failure.

No TEMP value (for ① Malfunction in the ① Replace the thermometer.

TH module) thermometer.
② Check the communication
② Malfunction in the infrared wires.
ear TEMP communication
③ Replace the infrared
wires.
insulated board.
③ Malfunction in the infrared
insulated board.

- 39 -
M3A Vital Signs Monitor Service Manual Troubleshooting

No TEMP value (for ① Malfunction in the F3000 ① Replace the F3000 probe
F3000 module) probe.
② Replace the F3000
② Malfunction in the F3000 parameter board.
parameter board.
③ Replace the F3000
③ Malfunction in the F3000 insulated board.
insulated board.

- 40 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

Chapter 7 Disassembling the Monitor

WARNING
1 Only qualified service personnel can open the monitor case.
2 Switch off the monitor and remove the AC power cable before disassembling the
monitor.
3 After any repair of the monitor, perform safety tests before using the monitor again.

7.1 Tools Required

A cross-head screwdriver

A flat-head screwdriver

An M3 nut driver

A pair of pliers

7.2 Replacing Fuses

To replace the blown fuse in the following procedure:
1) Switch off the monitor and unplug it.
2) Carefully place the monitor upside down on a flat surface covered with cloth or other
protecting pad.
3) Place a flat-head screw driver in the gap of the fuse. Apply a certain amount of pressure on
the screw driver to sink the fuse for about 1 mm. Unscrew the fuse anticlockwise.

- 41 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

4) Remove the old fuse. Take out a new fuse supplied by EDAN or of the same specification:
Size: Ф5mm×20mm; Model: T1.6AL 250V.
5) Place the new fuse in the fuse socket. Press and screw it clockwise back in position.

- 42 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

7.3 Disassembling the Main Unit

7.3.1 Separating Front Housing and Rear Housing
1 Remove the four screws in rear panel with screwdriver to separate the front panel and rear
panel.

M3×25 cross recessed

pan head screw

- 43 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

2 Take apart the front panel and rear panel at the joint, then disconnect the cables and connectors
to separate the two parts.

① Cable between speaker and main control board

② Cable for nurse call

③ Cable between main control board and network board

- 44 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

① Connector for power cable between main control board and PS900K.

② Connector for control connecting cable between main control board and PS900K.

③ Connector between main control board and X2 module.

④ NIBP airway tube connector.

⑤ SpO2 sensor connector.

7.3.2 Taking out the Main Bracket

1 To separate the rear panel, firstly, you should overturn the monitor and remove the fuses as
described in section 7.2 Replacing Fuses. Then remove three screws for fixing main bracket
and rear panel.

- 45 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

M3×6 cross recessed

countersunk head
screw

Fuses

2 Remove four screws in main bracket and one screw for grounding. Then carefully take out the
main bracket from rear bracket.

M3×6 cross
recessed pan
head screw

- 46 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

M3×6 cross
recessed pan
head screw

- 47 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

7.4 Disassembling Rear Panel Assembly

7.4.1 Replacing the T2 Module
To replace T2 module, you should remove it according to the following procedure:
1. Separate front panel and rear panel assemblies according to section 7.3.1 Separating Front
Housing and Rear Housing.
2. Remove two screws for fixing T2 module on rear panel.
3. Remove connecting cable between T2 module and main control board, pull the cable out from
the hole in rear panel.
4. Slide out the block on T2 module bracket, and then uninstall the bracket from monitor. Take
care of the block when uninstalling as the following figure shows:

Screws

- 48 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

Block

Connecting
cable for T2
module and
Main control
board

Block

5. Remove four screws on T2 module, and then separate the module.

Screws

To replace the T2 module:

Install a new T2 module in a reverse procedure.

- 49 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

7.4.2 Replacing the TH Module

To replace the TH module, you should remove it according to the following procedure:
1. Separate the front and rear assemblies according to section 7.3.1 Separating Front Housing
and Rear Housing.
2. Remove the two screws securing the module on the rear panel.
3. Remove the wire linking the module and main control board; pull the wire out from the hole
in the rear panel.
4. Slide out the block on the module bracket, and then uninstall the bracket from the monitor.
Avoid damaging the block when uninstalling.

Screws

Block

Infrared ear TEMP

communication wire

- 50 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

5. Remove the five screws on the module; and then separate the module from the monitor.

Screws

To replace the TH module:

Install a new module in a reverse procedure.

7.4.3 Replacing the F3000 Module

To replace the F3000 module, you should remove it according to the following procedure:
1. Separate the front and rear assemblies according to section 7.3.1 Separating Front Housing
and Rear Housing.
2. Remove the probe and the isolation chamber.
3. Remove the two screws securing the module on the rear panel.

- 51 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

Probe and
isolation
chamber

Screws

4. Remove the two screws on the back of the module and separate the module with hands.

Screws

- 52 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

5. Remove the four screws on the two boards and remove the two wires.

Communication wire of F3000 parameter board

Screws
Screws

Communication wire of F3000 isolation board

To replace the F3000 module:

Install a new module in a reverse procedure.

7.4.4 Replacing X2 Module

To replace X2 module, you should remove it according to the following procedure:

- 53 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

1. Separate front panel and rear panel assemblies according to section 7.3.1 Separating Front
Housing and Rear Housing.
2. Remove four screws for fixing X2 module on Rear panel.
3. Remove connecting cable, and then remove X2 module.

Screws

To replace the X2 module:

Install a new X2 module in a reverse procedure.

7.4.5 Replacing Power Module

To replace power module, you should remove it according to the following procedure:
1. Separate front panel and rear panel assemblies, and take out main bracket as described in
section 7.3 Disassembling the Main Unit.
2. Remove four screws for fixing power module on main bracket as the following figure shows:

- 54 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

Screws

To replace the power module:

Install a new power module in a reverse procedure.

7.4.6 Replacing Network Module

To replace network board in the following procedure:

1. Separate front panel and rear panel assemblies, and take out main bracket as described in
section 7.3 Disassembling the Main Unit.
2. Remove three screws for fixing network module and the interface cable, and then remove the
network module.

- 55 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

Cross recessed
pan head screw

To replace the network module:

Install a new network module in a reverse procedure.

7.4.7 Replacing Speaker

To replace the speaker in the following procedure:

1. Separate front panel and rear panel assemblies, and take out main bracket as described in
section 7.3 Disassembling the Main Unit.
2. The speaker is on rear panel. Remove two screws for fixing speaker, and then remove the
speaker.

- 56 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

Speaker

To replace the speaker:

Install a new speaker in a reverse procedure.

- 57 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

7.5 Disassembling Front Panel Assembly

7.5.1 Replacing Main Control Board
To replace main control board, you should remove it according to the following procedure:
1. Separate front panel and rear panel assemblies according to section 7.3.1 Separating Front
Housing and Rear Housing.
2. Remove the connector for LCD screen: open the clock on the connector, and then remove the
connector of LCD screen from FPC interface.

Clock

- 58 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

3. After taking off the connector for LCD screen, remove six screws for fixing module, and then
remove the main control board.

M3×8 cross
recessed screw

To replace the main control board:

Install a new main control board in a reverse procedure.

- 59 -
M3A Vital Signs Monitor Service Manual Disassembling the Monitor

7.5.2 Replacing LCD Screen

To replace LCD screen, you should remove it according to the following procedure:
1. Separate front panel and rear panel assemblies according to section 7.3.1 Separating Front
Housing and Rear Housing.
2. Remove the connector for LCD screen: open the clock on the connector, and then remove the
connector of LCD screen from FPC interface.

Clock

3. Remove four screws for fixing LCD screen, one of them is grounded.

M3×8 screws

Grounding

To replace the LCD screen:

Install a new LCD screen in a reverse procedure.

- 60 -
M3A Vital Signs Monitor Service Manual Renewal Parts

Chapter 8 Renewal Parts

WARNING
Only connect the replaceable parts supplied by EDAN to the monitor.

Parts Part Number

M3A main control board PCBA 12.03.220016
PS900K Power Board 02.03.112196
PS900K DC conversion board 02.03.112198
PS900K power control board 12.03.112200
Proportional valve of NIBP module 11.58.029016
Deflating valve 11.58.40301
Pump 11.58.40302
X2 NIBP and SpO2 module assembly 02.01.118001
Speaker 01.14.038010
M3A network interface board PCBA 02.02.112577
M3A new network interface board PCBA 12.03.451343
3.5’’ TFT LCD 01.16.045033
Recorder assembly 22.04.240405
T2 TEMP module assembly 02.01.110112
M3 infrared ear temperature holder assembly 22.01.210442
Lithium-ion battery (14.8V, 2200mAh) 21.21.064168
Lithium-ion battery (14.8V, 4400mAh) 21.21.064167
F3000 TEMP module assembly 02.01.210847
Communication wire of F3000 parameter board 01.13.036575
Communication wire of F3000 isolation board 01.13.036177
F3000 isolation board 02.03.451627
F3000 parameter board 12.03.203123

- 61 -
