Preface
My first exposure to the semiconductor industry was in 1975 at the
Microwave Diode Department of Chengdu Guoguang Electric Co. with my
middle-school classmates during a month-long “learn from workers” program
[very common for Chinese children during the chaotic period of the “Cultural
Revolution” (1966–1976)]. The silicon wafer size was 1 inch, and we were
making crystal diodes used in radar as a microwave detector. The factory had
several process bays, such as diffusion, wet clean, wafer dicing, assembly, and
final test. I watched workers push the wafers into the pyrogenic oxidation
furnace and was amazed by the barely visible bluish hydrogen flame in it. I
still remember the story of a hydrogen-leakage-induced explosion told during
safety training. I worked in final test, using a special instrument to test the
diode and determine whether it passed or needed to be thrown into the trash
bin underneath the tester.
Twenty years later, I started my career in the semiconductor industry. The
wafer size at that time was 200 mm, and the technology node was 350 nm.
When the first edition of my textbook Introduction to Semiconductor
Manufacturing Technology was published by Prentice Hall in 2000, the
technology had scaled down to 180 nm, and copper metallization was the
state-of-the-art technology.
Ten years after publication of the first edition, the wafer size increased to
300 mm, and the technology node migrated to 32 nm. New technologies that
were not mentioned in the first edition, such as immersion lithography, double
patterning, selective epitaxial growth (SEG), and atomic layer deposition
(ALD), were widely used to manufacture IC chips with high-k, metal-gate
front-end and copper, ultra-low-k back-end. It became the main driving force
for me to write the second edition of the book.
There are many new developments since I have summited the final
manuscript of the second edition in the spring of 2012. Because simply scaling
down the feature size of the planar MOSFET can no longer improve the
device performance while reducing its power consumption, scientists and
engineers have worked on scaling nanometer-scale electronic devices in the
third dimension. FinFET technology is one such proposed device architecture
that has been used to replace planar MOSFET technology. At the same

ix
x Preface

feature size, FinFETs can improve the drive current by increasing the effective
gate width at on-state while reducing standby leakage by operating with a
fully depleted regime at off-state. Theoretically, FinFETs can migrate to the
next-generation-technology node by just increasing fin height without
shrinking the feature size. Because it is easier to control the fin height of the
FinFET with the silicon thickness of the silicon-on-insulator (SOI) substrate,
it was thought that FinFETs needed a SOI wafer. Due to the high cost of SOI
wafers and the difficulties of fin height control with low-cost bulk-silicon
wafers, many people regarded FinFET technology as a high-risk approach for
the 22-nm or 20-nm technology node, even as late as 2009. In the summer of
2012, Intel announced its 22-nm FinFETs at the Symposium on VLSI
Technology. Although FinFET technology was mentioned in the second
edition published by SPIE Press at the end of 2012, it was not elaborated upon
due to the lack of credible information about its manufacturing processes.
In recent years, the manufacturing technology of non-volatile memory
(NVM), especially NAND flash memory, has developed rapidly, driven by
the demands of data storage for mobile electronics devices, such as
smartphones, tablet PCs, digital cameras/camcorders, etc. Multiple patterning
is required to manufacture the planar NAND flash-memory chips due to the
limitation of 193-nm immersion lithography. The cost of triple patterning or
quadruple patterning required by the low-teen-nm planar NAND flash will
become too high, and scientists and engineers have proposed and developed
an alternative vertical NAND or 3D-NAND technology that utilizes the gate-
all-around vertical transistors to stack multiple memory cells in the vertical
direction. In 2014, Samsung released a solid state drive (SSD) based on 3D-
NAND with 32 stacks of NVM—only seven years after Toshiba published the
concept. A SSD with 48-stack 3D-NAND is also available on the market.
With 3D-NAND architecture, one can scale to a next-generation-technology
node by increasing the number of stacks without shrinking the feature size.
The second edition of Introduction to Semiconductor Manufacturing
Technology mentions 3D-NAND in the last chapter, which discusses future
trends. The future becomes reality in a very short time.
Another technology mentioned in the second edition but not described in
detail is 3D packaging with through silicon via (TSV). By stacking multiple
chips with TSV, one can increase the device density without shrinking the
feature size, which has been limited by the capability of 193-nm immersion
lithography technology and the delayed implementation of extreme ultraviolet
(EUV) lithography. TSV has long been applied in CMOS image sensor
packaging, which forms the tiny camera assembly used in mobile phones,
tablets, and laptops. TSV wafer stacking requires very high yield for every
wafer that is to be stacked; otherwise, the combined final yield will suffer.
Although foundries are still proposing 2.5D packaging with an interposer due
Preface xi

to the high cost of TSV 3D packaging, Samsung released the first 3D TSV
technology based on DDR4 modules for enterprise servers in 2014.
Many people helped me acquire the information and knowledge needed to
write this book; many of them helped me by answering my questions, and
some of them helped by asking me questions to which I had no clear answer at
that moment, which motivated me to further study and research: Dick James,
Oliver Paterson, Hanming Wu, Jong (John) Chen, Chih-Ming Ke, David
Fried, Sandy Wen, Jay Guan, Xiaodong Wang, Victor Lim, Byoung-Ho Lee,
Ming Lei, Qiang Zhao, Kevin Huang, Jeff Zhang, Wee Teck Chia, Takuji
Tada, Jeff Barnum, Christina Wang, Paul MacDonald, Chris Mahr, Brain
Duffy, Harsh Shiha, Rohan Gosain, Arun Lobo, Neeraj Khanna, Amir
Azordegen, and Cecelia Campochiaro, just to name a few.
The image of the 3D V-NAND memory chips on the cover has been
provided by Samsung Electronics. Figures 1.10(b)–(c) and 2.48 are provided
by Coventor. Figures 3.9–3.17, used to describe the HKMG FinFET
processes, were previously published in TechDesign Forums. These images
were generated using Coventor’s SEMulator3D virtual-fabrication software
platform.
Colin Xiao, Jarry Xiao, Sameet Shriyan, and Shishir Ramprasad helped
me proofread the draft and corrected many English errors. Without the
support of my wife, Liu (Lucy) Huang, and sons, Jarry and Colin, it would
have been impossible to write and finish this book on time.
My generation grew up in China without television. Thanks to the
“Cultural Revolution,” there were very few movies for kids in China at that
time. So, hungry for movies, I watched anything that projected on the screen.
One such film I watched many times was “Mechanical Drawing,” an
educational film for college students at the Chengdu Institute of Radio
Engineering (currently the University of Electronics Science and Technology
of China), where my parents worked as professors. Even today, I can still
vividly remember this film taught me how a 3D object can be presented by a
top view, side view, and face view. The 3D concept and its presentation with a
2D drawing helped me tremendously when I took an IC design class in
graduate school. [IC layout is essentially the top view of mechanical drawing
with a microscopic scale (maybe it should be called nanoscopic scale now)].
This knowledge was really useful for me to reconstruct the 3D structures of IC
devices and figure out the manufacturing processes by correlating the top-view
images and cross-section images. I really appreciate the person who showed
the film and allowed me, an elementary schooler, to watch it with college
students.
Hong Xiao
March 2016

http://www.techdesignforums.com/practice/technique/finfet-iedm-tipsheet
Chapter 1
Manufacturing Processes
of 3D IC Devices
1.1 Introduction
The scaling of integrated circuit (IC) chips becomes more and more
challenging as IC technology pushes the feature size deep into the nanometer
(nm) technology nodes. To extend the scaling, engineers and scientists tried to
not only shrink the feature size in the x and y directions but also push IC
devices into the third dimension. It took 14 years from the first publication of
fin-shaped field effect transistors (FinFETs)1 to high-volume manufacturing
(HVM) of 22-nm FinFET IC chips in 2012.2 In 2014, the first 3D-NAND-
based solid state drive (SSD) was introduced to the market,3 only seven years
after the first publication.4,5
The same electrical performance and a significantly smaller footprint
(equivalent to feature-size scaling) can be achieved by changing the IC device
from a two-dimensional (2D) planar structure to a 3D structure. Figure 1.1
shows this effect for capacitors: Fig. 1.1(a) is a planar capacitor, and
Fig. 1.1(b) is a cylindrical capacitor with the same capacitance. It is well-
known that capacitance C ¼ kA/d. Here, k is the constant and d is the
thickness of the dielectric between the two electrodes, and A is the area of the
electrode. The top-down area of the cylindrical capacitor is much smaller on
the wafer surface than that of the planar version. Increasing the height of the
cylinder can further reduce the top-down area of the capacitor while keeping
the capacitance unchanged. This is the main reason why DRAM chips have
used cylindrical capacitors, either stacked or deep-trench, for a long time.
Figure 1.2 illustrates three types of metal-oxide semiconductor (MOS)
field effect transistors (FET, or MOSFET). Figure 1.2(a) is a 2D planar
MOSFET, Fig. 1.2(b) is a FinFET, which is a 3D device, and Fig. 1.2(c) is
another 3D device, a vertical gate-all-around (GAA) MOSFET, or a silicon
nano-wire device. The three devices have a similar gate critical dimension
(CD) with a similar footprint; however, the channel width of the planar
MOSFET is the narrowest and thus has the lowest drive current. The FinFET

1
2 Chapter 1

(a) (b)
Figure 1.1 (a) Planar capacitor and (b) 3D cylindrical capacitor.

(a) (b) (c)

Figure 1.2 (a) Planar MOSFET, (b) FinFET, (c) and vertical gate-all-around device.

channel width is two times the fin height plus the fin top CD, whereas the
GAA channel width is the circumference of the channel pillar.
This book explains the advantages of the 3D devices and their
applications in dynamic random access memory (DRAM), 3D-NAND flash,
and advanced-technology-node complementary MOS (CMOS) IC. The
development of DRAM cell transistors and storage node (SN) capacitors of
the DRAM, as well as the detail-manufacturing process flow of the most-
advanced buried word line (BWL) DRAM, are discussed in Chapter 1. The
3D-NAND flash process flow is described in detail in Chapter 2, and step-by-
step 3D FinFET CMOS IC devices are discussed in Chapter 3. Chapter 4
addresses the scaling trends of CMOS logic and memory IC before providing
a brief summary. Devices that may be used in the “post-CMOS” era are also
discussed. Other topics briefly mentioned include 3D technologies such as 3D
wafer process integration of silicon-on-inter-layer dielectric (ILD) and TSV-
based 3D packaging.
Manufacturing Processes of 3D IC Devices 3

1.2 3D Devices in the DRAM and BWL DRAM Process

After reading this chapter, you should be able to
• List the two devices in a DRAM cell and draw the circuit;
• List the three types of cell transistor that have been used in DRAM
manufacturing;
• Name the two types of storage node (SN) capacitor used in DRAM
chips;
• Explain why the planar capacitor was phased out in DRAM chips long
ago;
• Explain how DRAM capacitor technology has evolved;
• List at least two benefits of buried word line (BWL) DRAM; and
• List at least two types of high aspect ratio (HAR) structures in a DRAM
chip.
DRAM is widely used in smartphones, tablets, laptops, desktop computers,
data servers, and all computational devices. One of the major driving forces of
IC technology developments involves scaling down the DRAM feature size to
increase storage and speed while reducing power consumption. DRAM is the
first IC product that utilized 3D devices in HVM. A 3D capacitor was
implemented in DRAM HVM long before 22-nm FinFET CMOS and 3D-
NAND flash.

1.2.1 DRAM introduction

A DRAM cell has two devices: one n-channel MOSFET (NMOS) as an
access transistor, and one capacitor for data storage, as shown in Fig. 1.3(a).
DRAM was invented by Robert H. Dennard in 1967. Figure 1.3(b) portrays
the DRAM layout, and Fig. 1.3(c) shows the cross-section in Dennard’s
patent.6 For this DRAM, both the access transistor and SN capacitor are
planar devices with silicon dioxide as the gate dielectric and capacitor
dielectric.
For a DRAM cell, the capacitance C of the SN capacitor must be large
enough to hold enough charge to maintain the memory. For a planar-cell
transistor DRAM, C usually is about 35 femtofarads (fF). In order to scale
down the feature size of the capacitor while keeping the C value unchanged,
the DRAM developers initially reduced d to the reliability required leakage
limit and used silicon nitride (k  7) to replace silicon dioxide (k ¼ 3.9) for the
capacitor dielectric. Due to the stress issue of nitride, the capacitor dielectric
used oxide/nitride/oxide (ONO) for a long time.

1.2.2 3D devices in DRAM

An unchanged C and k made it very challenging to scale the feature size of a
DRAM SN capacitor while maintaining its capacitance because the electrode
surface area must be kept constant. The capacitor of the DRAM became the
4 Chapter 1

(a) Word line

Bit line Vdd

(b)

(c)

Figure 1.3 (a) DRAM circuit, (b) first DRAM layout, and (c) its cross-section. Figures (b)
and (c) reprinted from IBM patent (1968, patentimages.storage.googleapis.com/pdfs/
US3387286.pdf).

first IC device that became 3D after further scaling of the technology node,
which helped reduce the footprint of the device.
Figure 1.4 shows the evolution of the DRAM capacitor. Engineers and
scientists demonstrated a lot of creativity to scale the geometry of the SN
capacitor while keeping its capacitance unchanged. HSG in the figure stands for
“hemispherical grain,” which is polysilicon that features rough, hemispherical,
Manufacturing Processes of 3D IC Devices 5

Figure 1.4 Technology evolution of the DRAM capacitor. Image reprinted from Ref. A with
permission from InTech.

and grainy surfaces. It had been widely used in DRAM manufacturing to

increase the surface area of capacitor electrodes. When DRAM technology
scales to PHASE-III, the CD of the cylinder becomes too small to grow HSG
silicon; it has been replaced by a thinner metal-electrode (mostly TiN) layer.
Figure 1.5 illustrates the advanced SN capacitors indicated in phase III of
Fig. 1.4. Figure 1.5(a) shows a deep-trench capacitor DRAM; the dashed line
indicates that a lot of substrate depth with the same structure has been omitted
from the figure. The aspect ratio (trench depth versus trench CD) could be
higher than 30:1. Currently, only a handful of silicon-on-insulator (SOI) IC chips
use deep-trench capacitor DRAM as embedded DRAM, taking advantage of its
compatibility in the back-end-of-line (BEoL) processes with normal CMOS
processes and a lower capacitance requirement due to the SOI substrate. Most
DRAM chips in the commodity market are DRAM with a cylindrical stacked
capacitor, as shown in Fig. 1.5(b), which is described in detail in this chapter.

Question: For a cylindrical capacitor, how does the aspect ratio of a SN cylinder
p
change when the DRAM feature size scales down by a factor of 1/ 2 while C, k, and d
remain unchanged?
Answer: In order to keep C unchanged in this scaling, the height of the cylinder must be
increased to scale down its CD:

A1 = p  CD
p1  h1 = p  CDp 2  h2 ¼ A2;
CD2 = CD1/ 2, and
p thus h2 ¼ p2  h1;
AR2 = h2/CD2 = 2  h1/(CD1/ 2) = 2  h1/CD1 = 2  AR1.
If C, k, and d remain unchanged, then the aspect ratio of the SN cylinder will be
p
doubled after scaling down the SN cylinder CD by a factor of 1/ 2!
6 Chapter 1

Figure 1.5 (a) Deep-trench capacitor DRAM and (b) recessed cylinder-stacked capacitor
DRAM.

Shrinking the footprint of the SN capacitor is the biggest challenge of

DRAM scaling. Engineers and scientists are working to find new dielectric
materials with higher k values and to reduce leakage of the off-state access
NMOS to reduce the required capacitance C. When the feature size scalespto
the next generation, the scaling factor is no longer as aggressive as 1/ 2,
which means that the increased aspect ratio of the SN cylinder is still
manageable for each technology node.
When DRAM technology scaled toward the 80-nm node, short channel
effects caused higher source/drain (S/D) leakage in the access transistor and
shorter data-retention time. To overcome those issues, the DRAM access
transistor transitioned from a planar structure to a 3D structure, and the recess
gate (RG) transistor was introduced.7 Further development of the DRAM
access transistor created the buried word-line (BWL) technology, which uses
metal to form the gate electrode of the access transistor and the word line
(WL), both of which are buried under the original silicon wafer surface.8
Figure 1.6 illustrates the evolution of the DRAM access transistor,
where L is the channel length. Figure 1.6(a) shows a planar MOSFET, and
Fig. 1.6(b) illustrates a RG transistor; both use polysilicon as the gate elec-
trodes. A comparison of Figs. 1.6(a) and 1.6(b) reveals that with the same gate
critical dimension (CD), the RG transistor has a longer channel length than a
planar transistor. Figure 1.6(c) shows a buried access NMOS with a titanium
nitride (TiN) metal gate and a tungsten (W) WL buried underneath the silicon
surface.
Manufacturing Processes of 3D IC Devices 7

(a) (b) (c)

Figure 1.6 Evolution of the DRAM array cell NMOS: (a) planar, (b) RG, and (c) BWL.

Figure 1.7 3D illustration of the channel width and channel length of DRAM cell transistors:
(a) planar, (b) RG, and (c) BWL.

The channel length L and channel width W of the planar cell transistor,
RG transistor, and BWL transistor are shown in Figs. 1.7(a)–(c), respectively.
Note that L is the distance along the silicon surface between the source and
drain, the heavily n-type-doped silicon (marked N-Si in the figure). At the
same feature size, the RG transistor has the same channel width as the planar
transistor, which is the CD of the AA; however, it has a much longer channel
length. Furthermore, at the same geometry, the BWL transistor has the same
L as the RG transistor, with a larger W, because there is more silicon surface
exposed at the sides due to the deeper oxide etch in the BWL trench etch. The
edge of the P-Si channel side and its curved top in real BWL devices is not that
sharp—it is more like the shape of a saddle. Increasing the channel length can
help to reduce leakage and maintain the retention time. Increasing the channel
width can help to increase the drive current, and the BWL structure allows
increasing the channel width without increasing the feature size of the device.
Figure 1.8 shows a DRAM with a planar cell NMOS and stacked cylinder
capacitor. It represents the DRAM technology at 110 nm or earlier
technology nodes (described in detail in Chapter 14 of Xiao11), which used
three layers of aluminum metal interconnection. The so-called aluminum
metal layer in fact is a metal stack of Al-Cu (0.5% Cu) alloy bulk layers with
a Ti/TiN barrier layer underneath and a TiN anti-reflective coating (ARC) on
8 Chapter 1

Figure 1.8 (a) Planar cell transistor DRAM and (b) 3D illustration of its memory cell
structures. BL: bit line, BLC: bit-line contact, ILD: inter-layer dielectrics, MC: metal contact,
Mx: metal x (where x ¼ 1 to 3), SAC: self-aligned contact, SN: storage node, SNC: storage-
node contact, and STI: shallow-trench isolation. (b) is modified from Ref. B.
Manufacturing Processes of 3D IC Devices 9

M3

V2
ILD7

M2 M2

ILD6
V1

M1 M1

ILD5
Metal
ground
electrode ILD4

MC
High-k SN
dielectric ILD3
Metal SN
electrode

SNC
ILD2
BL
ILD1
BLC
SAC ILD0
STI
WL
RG
Array Periphery
(a)

(b)
Figure 1.9 (a) Recessed-gate cell transistor DRAM, and (b) 3D illustration of its memory
cell structures, which is modified from Ref B.

top. The W with the Ti/TiN barrier layer was used for the conducting plugs to
connect the different layers.
Figure 1.9(a) shows a DRAM with a RG transistor and partially recessed
cylinder capacitor. These images represent DRAM technology after 90-nm
10 Chapter 1

and before 3x-nm (i.e., 39-nm to 30-nm) technology nodes. Besides cell
transistors and capacitors, another major development of this period was the
introduction of copper metallization in 5x-nm DRAM. In comparison, logic
CMOS IC chips used copper metallization in interconnects since the 180-nm
technology node. There were two copper layers and one aluminum layer. The
top aluminum-alloy layer allowed the use of Al-Cu bond pads for the
standard gold wire bonding to keep the cost down. DRAM manufacturers are
very cost-sensitive, and DRAM fabrication-process technologies are cost
driven: two layers of copper can replace three layers of aluminum alloy, which
reduces the overall cost.
Figure 1.10(a) illustrates a BWL DRAM with a fully recessed cylinder
capacitor, and Fig. 1.10(b) is the 3D illustration of its memory cell structures.
Because the latter is based on the 6F2 layout, it is quite different from Figs. 1.8(b)
and 1.9(b), which are based on the 8F2 layout (these layouts are discussed in
Section 1.2.3). The BWL structure and 6F2 layout have been widely used
in 3x-nm and 2x-nm DRAM technology nodes. There are three metal
interconnect layers: two copper layers and one aluminum-alloy layer.
If DRAM can be made with these three types of cell transistors with the
same single-patterning photolithography technology and the same capacitor
materials and structure, then the planar-cell transistor DRAM requires nine
masks, as shown in Fig. 1.11. The RG transistor DRAM adds a reversed WL
mask for the silicon etch to form a RG cell transistor; thus, it needs ten masks
in the array area, as illustrated in Fig. 1.12. The BWL DRAM uses one mask
for both well implantation and S/D implantation, and one mask to form the
RG and WL at the same time, while eliminating the SAC layer; thus, it only
needs seven masks (Fig. 1.13). Fewer masks means lower cost, which is one of
the most important reasons why BWL DRAM technology is used by all major
DRAM manufacturers. Note that Figs. 1.11–1.13 only show the mask layers
for the cell transistors and capacitors of the DRAM array area; they do not
include the masks required to make CMOS devices in the peripheral areas.
Ion implantation masks in cell transistor formation and well implantation
after active-area (AA) and S/D implantation after WL have a very large CD
and require less strict control of the CD and overlay. In a DRAM chip, the
feature sizes of peripheral circuits are much larger than the feature size of cell
devices. The feature size of peripheral devices is usually two generations
behind cell transistors. Advanced-technology nodes are processed separately
to avoid loading effects caused by pattern-density and pattern-size variations
on the processes such as photolithography, etch, CMP, etc. Although access
transistors used 3D devices for multiple generations, peripheral devices still
use planar MOSFET technology. Therefore, this book focuses on the
manufacturing processes in 3D devices in array areas.
Manufacturing Processes of 3D IC Devices 11

Figure 1.10 (a) BWL DRAM with a fully recessed cylinder capacitor, two layers of copper,
and one layer of aluminum interconnect, (b) 3D illustration of its memory cell structures, and
(c) close-up of the memory cell. Both (b) and (c) are reprinted with permission from
Coventor.
12 Chapter 1

Figure 1.11 Masks for planar-access transistor DRAM in the array area.

Figure 1.12 Masks for RG transistor DRAM in the array area.

1.2.3 BWL DRAM manufacturing processes

This section discusses a generic manufacturing process of 2x-nm BWL
DRAM technology. Although all DRAM manufacturers use BWL technology,
each of them has a different design layout and different fabrication-process
Manufacturing Processes of 3D IC Devices 13

Figure 1.13 Masks for BWL DRAM in the array area.

Figure 1.14 AA (a) mask 1 and (b) mask 2.

steps. Even for the same company, 3x-nm and 2x-nm BWL DRAM processes
could be quite different.
Just like CMOS IC chip manufacturing, BWL DRAM also starts with
wafer cleaning. A pad oxide layer is then grown in a thermal furnace, and
silicon nitride is deposited, usually with a low-pressure chemical vapor
deposition (LPCVD) process. The SiN layer can be used as a hard mask
for shallow-trench isolation (STI) etch. It is also used as a STI oxide CMP
stop layer. Another hard mask layer is needed for a double-patterning
process.
Double patterning is required for a 2x-nm DRAM, and the AA can be
defined with two masks. Figure 1.14 shows the two masks of AA in a so-
called “litho–etch–litho–etch” (LELE) double-patterning process. We only
illustrate the masks in array area. Figure 1.15(a) illustrates the final
AA pattern that is formed by combining AA mask 1 and AA mask 2.
Overlay of the two masks becomes very critical. For example, the overlay
shift in the y direction can affect the overlay budget of the contact layers
later. The effects of the overlay shift in the x direction are shown in
14 Chapter 1

Figure 1.15 (a) The final AA pattern and (b) AA pattern with the AA2-to-AA1 overlay
shifted in the x direction.

Fig. 1.15(b); they cause alternating wider and narrower STI gaps between
AAs. The etch profile of narrower gaps is different from that of the wider
gaps. The narrow gaps could have trouble performing void-free gap filling
during oxide CVD. The gap aspect ratio and quality of the oxide-filled
inside will affect the BWL trench etch process later.
The AA pattern can also be formed with self-aligned double patterning
(SADP), which uses spacers on the sidewalls of the mandrel, to double the
pitch of the original patterning of the dummy layer. Figure 1.16(a) shows the
mask of the mandrel pattern. Figure 1.16(b) illustrates the mandrel formed by
etching the dummy layer with the Fig. 1.16(a) pattern. Figure 1.16(c) shows
the mandrel with a sidewall spacer, and Fig. 1.16(d) illustrates the spacer
pattern after the mandrel is removed, which doubles the pitch density of the
mandrel pattern. The cut mask and the final AA pattern are illustrated in
Figs. 1.16(e) and 1.16(f), respectively.
The AA SADP process starts with pad oxidation, a nitride hard mask,
and dummy-mandrel film deposition. The mandrel patterns are formed
after patterning and dummy film etch, as shown in Fig. 1.16(b). After
photoresist (PR) strip and clean, a conformal film is deposited on the
wafer surface, and a vertical etch back is performed to remove the film
from the top of the dummy pattern and the bottom of the gap between the
dummy patterns to form spacers on the sidewall of the mandrel, as shown
in Fig. 1.16(c). After a highly selective etch process that removes the
mandrel, the spacer pattern on top of the nitride hard mask, as shown in
Fig. 1.16(d), can be used to etch the SiN hard mask. The cut mask
illustrated in Fig. 1.16(e) can be used to cut the line-space hard mask
pattern and form the final AA pattern on the SiN hard mask. This SiN
hard mask can be used to etch the pad oxide and single-crystalline silicon
substrate to form the final AA pattern.
In comparison with LELE double patterning, SADP requires significantly
more process steps and thus has a higher cost. However, it has better CD
control and less line-edge roughness. It also significantly reduces the
requirement of a second mask overlaying the first mask and thus will not
Manufacturing Processes of 3D IC Devices 15

Figure 1.16 AA pattern formation with SADP: (a) mandrel pattern mask, (b) mandrel
pattern, (c) spacers formed on mandrel pattern, (d) spacer pattern after dummy-pattern
removal, (e) cut mask, and (f) the final AA pattern.

have the STI oxide void issue caused by the overlay error-induced gap
narrowing displayed in Fig. 1.15(b).
The patterned SiN hard mask is then used to etch trenches into silicon to
form STI. After STI etch, clean, metrology, inspection, and review, a thin
layer of silicon dioxide is thermally grown on the silicon surface in an
oxidation furnace, and an oxide layer is deposited to fill the high-aspect-ratio
(HAR) trenches. Void-free trench fill is very critical at this step because any
void between AAs will cause BWL trench etch-profile issues and kill the
access transistor in the array. Chemical mechanical polish (CMP) of silicon
oxide is performed, and the CMP process stops on the SiN hard mask layer.
Hot-phosphoric-acid wet etch is commonly used to strip the SiN hard mask,
and diluted hydrofluoric acid (HF) is commonly used to strip the pad oxide.
16 Chapter 1

Table 1.1 AA module.

Wafer clean [Fig. 1.17(a)] PR strip and clean [Fig. 1.17(d)]
Pad oxidation Etch pad oxide
SiN hard mask deposition Etch silicon trench
Amorphous silicon hard mask deposition [Fig. 1.17(b)] Wafer clean [Fig. 1.17(e)]
AA mask 1 Oxidation
Etch top hard mask STI oxide CVD to fill the trench [Fig. 1.17(f)]
PR strip/clean [Fig. 1.17(c)] STI oxide CMP, stop on nitride [Fig. 1.17(g)]
AA mask 2 Wet strip nitride and pad oxide
Etch bottom hard mask Wafer clean [Fig. 1.17(h)]

(a)

(b)

(c)

(d)

STI
(e)

STI
(f)

STI
(g)

STI
(h)
Array Periphery
Figure 1.17 The AA process module from (a) start to (b) finish.

The AA-formation process steps are summarized in Table 1.1. Figure 1.17
illustrates the AA module process steps with LELE double-patterning
techniques. The cross-section of the beginning of the wafer process
and the end of the AA module are illustrated in Figs. 1.17(a) and 1.17(h),
respectively.
Manufacturing Processes of 3D IC Devices 17

Table 1.2 Well formation.

Sacrificial oxide growth PR removal and clean [Fig. 1.18(b)]
Cell p-well mask Peripheral p-well mask
P-well implantation P-well implantation
N þ S/D implantation NMOS VT adjust implantation
PR removal and clean [Fig. 1.18(a)] Photoresist removal and clean
Peripheral n-well mask Sacrificial oxide removal and clean
N-well implantation Rapid thermal anneal [Fig. 1.18(c)]
PMOS VT adjust implantation

STI
(a)
STI
(b)
STI
(c)
Figure 1.18 Cross-section view of well formation.

There are two mask steps in Table 1.1 because this AA process is a LELE
double-patterning process. Here, a mask step indicates a photolithography
process that includes multiple steps, such as pre-bake, primer coating, wafer
cooling, PR coating, soft bake, wafer cooling, alignment and exposure, post-
bake, wafer-edge exposure, wafer cooling, development, hard bake, wafer
cooling, metrology, and inspection. If metrology and inspection find that the
process is out of specification, then the wafer can be reworked by stripping
PR/clean and then going through the entire mask procedure again.
After wafer clean, a thin layer of sacrificial oxide is grown, p-well masks
are applied, and high-energy ion implantations are used to form the p-well for
access NMOS in array areas and both p-well and n-well in the peripheral area.
Well-implantation photolithography processes are not critical mask layers;
they usually have large CDs, especially for access NMOS in the array area.
After photoresist ashing and clean, the wafer is annealed. The process steps
are listed in Table 1.2, and cross-section views of this stage are shown in
Fig. 1.18.
Figure 1.18 shows the cross-section of the BWL DRAM well and channel
ion-implantation processes. Figure 1.18(a) shows the cross-section illustration
after ion implantations in the array area, which form both well junction and
S/D junction of the access transistor of BWL DRAM. The well junctions are
formed by high-energy p-type ion implantation. The access NMOS S/D
junction is formed by high-current, low-energy n-type ion implantation.
Figure 1.18(b) shows the cross-section view after n-well ion implantation in
the peripheral area, and Fig. 1.18(c) illustrates the cross-section view after
18 Chapter 1

Figure 1.19 Buried WL mask.

p-well ion implantation. All access transistors in the array area are NMOS;
therefore, the array area only has p-well. There are both n-well and p-well in
the peripheral area. Because peripheral transistors are planar transistors, their
S/D implantations must wait until after gate formation.
After well formation, the next step forms the access transistors. For a
planar access transistor, the WL mask shown in image 3 of Fig. 1.11 is used to
pattern PR, which is then used to etch a line-space pattern on a SiN hard
mask, tungsten silicide, and polysilicon stack on the gate oxide. The RG
transistor needs two masks, the first of which is a mask in the array area, i.e., a
reversed WL mask similar to image 3 in Fig. 1.12, before the gate oxide
growth and WL film stack deposition. It only etches silicon in the AA with
little loss of silicon oxide in the STI area. After PR strip and wafer clean, gate
oxidation, and gate/WL stack deposition, a second WL mask is used to etch
line-space patterns of the gate and WL. The BWL cell transistor formation is
the most unique process of this type of DRAM, compared to the other two
types of access transistor formation of previous DRAM generations. The
process requires the BWL mask shown in Fig. 1.19 to etch trenches on both
single-crystal silicon and silicon oxide simultaneously. This etch process
requires good control of the etch rate and etch-rate uniformity in both
materials and good control of the silicon profiles inside trenches. The access-
transistor formation processes include
• BWL trench etch,
• clean,
• gate oxidation,
• TiN gate deposition,
• W CVD,
• W etch back,
• oxide CVD, and
• oxide CMP.
Figure 1.20 overlaps the BWL mask with the AA pattern. Each AA has
two word lines pass through it to form two cell transistors. The middle section
Manufacturing Processes of 3D IC Devices 19

Figure 1.20 Overlap of BLW mask and AA patterns.

(a) (b)
2 2
Figure 1.21 (a) 8F DRAM layout and (b) 6F DRAM layout.

is the shared S/D, which will connect to the bit line (BL) and the sections at the
two ends of the AA will connect to SN capacitors.
Figure 1.21(a) illustrates a DRAM layout that was widely used during
planar transistor and RG transistor DRAM eras. It has unit array area of 8F2,
shown as the rectangular box. Here, F is the half pitch of the densest cell
pattern. Figure 1.21(b) is the same layout as Fig. 1.20 with a rotation of
90 deg. It is a DRAM layout with unit array area of 6F2, shown in the
parallelogram box. This layout obviously has a higher cell density than the
8F2 layout and thus has been more widely used in DRAM chip manufacturing
in recent years. The cross-section of the BWL DRAM process in this section
follows the dashed line in Fig. 1.21(a). Table 1.3 lists the process steps of the
BWL module that forms access NMOS and WL in the array area.
20 Chapter 1

Table 1.3 BWL module.

Wafer clean W and TiN etch back [Fig. 1.23]
Oxidation Wafer clean
Hard-mask deposition Oxide deposition
BWL mask [Fig. 1.19] Oxide CMP
Etch hard mask Strip hard-mask
BWL trench etch Oxide deposition [Fig. 1.24]
PR strip & clean [Fig. 1.22] TiN gate electrode deposition
Oxidation W deposition

n+

p-Si SiOx

(a) (b) (c)

STI
BWL
Array Periphery
(d)
Figure 1.22 Zoomed-in cross-section of (a) BWL etch in AA, (b) a BWL DRAM layout with
BWL on top of AA layer, (c) zoomed-in BWL etch profile in STI oxide, and (d) illustration of
cross-section of BWL DRAM after BWL trench etch.

Figure 1.22(b) is a layout of BWL DRAM with BWL layer overlaps on

top of the AA layer. Figure 1.22(a) is the zoomed-in detail of the dashed box
in Fig. 1.22(d), which shows the BWL trench in AA silicon in the array area
but not in the peripheral area. Figure 1.22(c) shows a close-up of the BWL
trench-etch profile in STI silicon oxide. The etch rate in STI oxide is higher
than the etch rate in AA silicon, which helps create silicon fins inside the BWL
trenches, as shown in Fig. 1.7(c).
Figure 1.23(d) shows the cross-section of the BWL DRAM after TiN and
W deposit into the BWL trenches, and an etch-back process removes W and
TiN from the wafer surface, leaving W only inside the trenches from the WL.
Manufacturing Processes of 3D IC Devices 21

(a) (b) (c)

STI

BWL
Array Periphery
(d)
Figure 1.23 (a) Zoomed-in cross-section of a (a) BWL cell transistor, (b) BWL DRAM
layout with BWL overlaps the AA, (c) zoomed-in BWL profile in the STI oxide, and
(d) illustration of cross-section BWL DRAM after W and TiN etch back.

Figure 1.23(a) shows the detail of the cross-section of the cell transistor,
indicated in the dashed box in Fig. 1.23(d). Figure 1.23(b) shows the BWL
DRAM layout with a BWL layer on top of the AA layer. The dashed line
indicates the cross-section line in the AA silicon, and the solid line indicates
the cross-section line in the STI oxide, shown in Fig. 1.23(c).
Figure 1.24(d) shows the cross-section of BWL DRAM after ILD0
deposition. Figure 1.24(a) is the zoomed-in access transistor shown in the
dashed box of Fig. 1.24(d). The TiN forms the gate electrode of the DRAM
access NMOS, and the W in the trenches forms the WL that is buried
underneath the wafer surface.
Figure 1.25 shows the cross-section along the word line, illustrated in
Fig. 1.24(b). By allowing a higher oxide etch rate in STI than the silicon
etch rate in the AA during BWL trench etch, a device structure is created
that the TiN gate wraps around the silicon channel with gate oxide in
between along three sides, which forms a device similar to a tri-gate FinFET
for the access transistor. This process can further reduce the off-state
leakage current of the access transistor while increasing the drive current in
its on-state.
22 Chapter 1

TiN
SiOx SiOx

SiO2
n+

W
W

p-Si SiOx
SiOx

(a) (b) (c)

STI

BWL
Array Periphery
(d)
Figure 1.24 (a) Zoomed-in cross-section of cell transistor after ILD0, (b) a BWL DRAM
layout with BWL on top of the AA, (c) zoomed-in cross-section in the STI oxide, and
(d) illustration of cross-section BWL DRAM after W and TiN etch back.

ILD0
TiN BWL
W
STI
P-Si
Gate oxide
Figure 1.25 Cross-section along the word line of BWL DRAM.

ILD0 SiN ILD0

WL WL
PolySi
STI STI

P-Si P-Si
Gate oxide Gate oxide
(a) (b)
Figure 1.26 (a) Cross-section along the word line of DRAM with a RG cell transistor and
(b) DRAM with planar-cell-transistor DRAM.

Figure 1.26(a) is a cross-section along the WL of a DRAM with RG

access transistor, and Fig. 1.26(b) shows the same kind of cross-section of a
DRAM with a planar cell transistor. These two types of transistors have the
same gate width at the same feature size, whereas the BWL cell transistor has
Manufacturing Processes of 3D IC Devices 23

Figure 1.27 Bit-line contact mask.

the longest gate width because of its tri-gate structure. The gate electrodes of
planar and RG cell transistors are polysilicon, and the WL stacks comprise a
SiN hard mask, tungsten silicide, and polysilicon.
After cell transistor formation, a non-critical mask with a large CD is used
to remove oxide in the peripheral area. After wafer clean, thermal oxidation
and remote plasma nitridation are performed to form gate dielectric
(nitridized silicon oxide, or SiON) with an enhanced k value (5) for the
peripheral CMOS devices. A heavily n-type-doped polysilicon is then
deposited. A poly-dope mask that exposes the peripheral PMOS is applied.
An extremely-high-dosage p-type ion implantation is performed to counter-
dope peripheral PMOS polysilicon and convert it from heavily n-type to
heavily p-type, which is needed for PMOS threshold-voltage control. After
photoresist strip and clean, a mask is applied, and an etch process removes
polysilicon in the array area. Photoresist removal and clean prepares the wafer
for the bit-line contact (BLC) mask, shown in Fig. 1.27.
Figure 1.27 shows the BLC mask, which forms a contact between the BL
and the S/D of the DRAM access NMOS. Figure 1.28 overlaps the BLC

Figure 1.28 BLC mask overlaps with AA and BWL patterns.

24 Chapter 1

Table 1.4 BLC module.

Wafer clean Array area mask
Peripheral mask Etch polysilicon
Etch oxide PR strip/clean [Fig. 1.29(c)]
PR strip/clean [Fig. 1.29(a)] BLC mask [Fig. 1.27]
Gate oxidation and nitridation Etch oxide
Polysilicon deposition [Fig. 1.29(b)] PR strip clean [Fig. 1.29(d)]
Wafer clean Polysilicon deposition
PMOS poly-dope mask TiN and W deposition
PMOS poly implantation SiN deposition [Fig. 1.29(e)]
PR strip/clean

contact mask on the AA and BWL patterns. Note that BLC always connects
the S/D in the middle section of the three sections of the AA pattern. The BLC
mask has the lowest hole pattern density compared to other hole pattern
masks in the DRAM array area. Because the oxide film covering the AA is
very thin (usually < 30 nm) and contact hole aspect ratio is very low (1:2),
the BLC etch process is not as much a challenge as other HAR contact-hole
etch processes.
There is an alternative method to pattern BLC in a BWL DRAM array
area. After polysilicon deposition and poly-dope implantation, the BLC mask
is applied on top of the polysilicon in the array area, and BLC holes are etched
through the polysilicon and silicon oxide. After wafer clean and native oxide
removal, TiN/W/SiN stack is deposited, and the stack is patterned into BL
and peripheral gate patterns with a BL mask.10 The BLC process steps are
listed in Table 1.4.
Figure 1.29 shows the BLC process module. Because the film stack that
forms the BL in the array area is also used to form a gate stack in the
peripheral CMOS, there are several process steps of film deposition and
removal in the array area and peripheral area. Figure 1.29(a) shows the cross-
section after peripheral oxide removal; Fig. 1.29(b) shows the cross-section
after peripheral gate oxidation and polysilicon deposition; Fig. 1.29(c) shows
the removal of polysilicon in the array area; Fig. 1.29(d) illustrates the cross-
section of BWL DRAM after BLC etch, PR strip, and clean; and Fig. 1.29(e)
shows the cross-section of the BLC holes that are filled with polysilicon and
covered by TiN, W, and SiN.
After BLC formation and BL film-stack deposition, the next process is the
formation of the BL and peripheral transistors. Figure 1.30 shows the BL
mask, and in Fig. 1.31 the BL mask is overlapped with BLC, BWL, and AA
patterns. In this BWL DRAM layout, the BL is perpendicular to the WL, and
it aligns with the BLC on the middle section of the AA between two WLs. In
BWL DRAM, the BL in the array area and gate in the periphery share the
same film stack. It usually consists of several layers, such as polysilicon, TiN,
W, or tungsten silicide (WSix) and SiN. Polysilicon is the gate electrode of the
Manufacturing Processes of 3D IC Devices 25

STI
BWL
Array Periphery

(a)

STI

BWL
Array Periphery

(b)

STI

BWL
Array Periphery

(c)

STI
BLC
BWL
Array Periphery

(d)

STI
BLC
BWL
Array Periphery
(e)
Figure 1.29 BLC processes: (a) remove oxide in the periphery, (b) grow gate oxide and
deposit polysilicon, (c) remove polysilicon in the array area, (d) etch oxide and PR strip/
clean, and (e) polysilicon, TiN, W, and SiN deposition.

Figure 1.30 BL mask.

26 Chapter 1

Figure 1.31 BL mask overlaps with AA, BWL, and BLC patterns.

MOSFETs in the peripheral area that forms circuits such as address decoders,
sense amplifiers, and multiplexers. TiN serves barrier layer and glue layer for
W or WSix. Either W or WSix is the conducting layer used to reduce the
resistance of the BLs and local interconnects of the peripheral circuits. The
SiN layer is usually used as a HM layer for patterning the BL and gates of the
peripheral transistors.
One of significant challenges of BL patterning is overlay. Because the W
or WSix layer is opaque to the light, it is very hard to optically measure the
overlay between the PR BL pattern on the top hard mark above the W layer
and the BLC pattern underneath W. After BL pattern etch, photoresist strip,
and clean, the BL-to-BLC overlay can be measured by after-clean inspection
(ACI). A re-oxidation process is usually used to repair etch-induced gate oxide
damage and help to reduce gate leakage. There are then multiple masks in the
peripheral area before the next mask in the array area. There are two masks
for S/D extension (SDE) ion implantations of peripheral NMOS and PMOS. A
conformal dielectric (usually SiN) CVD and a dielectric vertical etch back form
spacers on the sidewall of the gates in the periphery and BLs in the array area.
The sidewall spacers and the SiN on top of the BL stack help to prevent
the storage node contact (SNC) plugs shorting to the BL. They have been
widely used to form SNC similar to self-aligned contact (SAC) in earlier-
generation DRAM devices. Figure 1.32 illustrates the process to form a spacer
on a sidewall of the BL and how it helps to form the SAC. Figure 1.32(a)
shows the BL stacks, and Fig. 1.32(b) illustrates the conformal dielectric film
(usually LPCVD silicon nitride) deposition. Figure 1.32(c) shows the nitride
etch-back process that forms the sidewall spacer. Figure 1.32(d) shows the
ILD oxide deposition and CMP; and Fig. 1.32(e) demonstrates the contact
etch that is self-aligned between the sidewall spacer due to the ILD etch
process, which is highly selective to oxide and etches very little on nitride.
After spacer formation, another two masks are used for high-current ion
implantation to form the heavily doped S/D of the peripheral NMOS and
PMOS. The peripheral devices are formed after rapid thermal anneal (RTA)
Manufacturing Processes of 3D IC Devices 27

(a)

(b)

(c)

(d)

(e)
Figure 1.32 (a)–(c) Sidewall spacer formation, and (d)–(e) self-aligned contact formation.

activates the dopants. Table 1.5 lists the process steps of the cell BL and
peripheral transistor formations, and Fig. 1.33 illustrates some of the steps.
After the BL and peripheral devices are built, the next mask layer in the
array area is the SNC, which creates the contact plugs between the storage
capacitors and the AA. At first, ILD1 oxide is deposited. The ILD1 film needs
to fill the gap between the BL without voids or buried keyholes. Otherwise,
after SNC etch, the SNC holes could be connected by the keyholes underneath
the ILD1, and after TiN/W CVD, SNC plugs can be shorted by the metal
deposited in the keyholes. After ILD1 deposition and CMP, an etch stop layer
is deposited, and the SNC mask illustrated in Fig. 1.34 is applied. For a 2x-nm
28 Chapter 1

Table 1.5 BL and peripheral transistor module.

Wafer clean PR strip/clean [Fig. 1.33(b)]
BL mask [Fig. 1.30] Spacer dielectric film deposition
BL and peripheral gate etch Spacer film etch back [Fig. 1.33(c)]
PR strip/clean/ACI [Fig. 1.33(a)] Peripheral NMOS SD mask
Re-oxidation Peripheral NMOS SD implantation
Peripheral NMOS SDE mask PR strip/clean
Peripheral NMOS SDE implantation Peripheral PMOS SD mask
PR strip/clean Peripheral PMOS SD implantation
Peripheral PMOS SDE mask PR strip/clean [Fig. 1.33(d)]
Peripheral PMOS SDE implantation RTA

BL
STI
BLC
BWL
Array Periphery
(a)

BL
STI
BLC
BWL
Array Periphery
(b)

BL
STI
BLC
BWL
Array Periphery
(c)

BL
STI
BLC
BWL
Array Periphery
(d)
Figure 1.33 Selected process steps of BL and peripheral transistor formation.

node, the pattern density is too high for single-photolithography

p patterning;
two masks, each with a hole pitch relaxed by a factor of 2 [as shown in
Figs. 1.35(a) and 1.35(b)], are needed to perform LELE double patterning to
form the SNC array.
An alternative double-patterning technique that can form this kind of
array hole pattern uses two masks, as shown in Fig. 1.36. In this case, two
hard mask (HM) layers are needed. The first mask shown in Fig. 1.36(a) is
used to pattern the top HM layer. The etch process forms the line-space
pattern in the top HM layer that stops at the bottom HM, as shown in
Manufacturing Processes of 3D IC Devices 29

Figure 1.34 SNC mask.

(a) (b)
Figure 1.35 Two masks that relax the SNC pitch in Fig. 1.34.

(a) (b)
Figure 1.36 Two masks that can be used to form the SNC pattern shown in Fig. 1.22.

Fig. 1.37(a). After photoresist strip, clean, and another PR coating and
baking, the second mask shown in Fig. 1.36(b) is applied. The second etch
process is highly selective to primarily etch the bottom HM while etching very
little of the top HM and the ILD1 layer; thus the bottom HM is only removed
at the cross-points of the two masks to expose the ILD1 layer underneath, as
shown in Fig. 1.37(b). The combined HM patterns can then be used to form
the SNC hole pattern, illustrated in Fig. 1.37(c). Due to the corner-rounding
effect, the final hole shape is more round than square, as shown in the
30 Chapter 1

(a) (b) (c)

Figure 1.37 (a) Patterning of the top HM layer with the mask shown in Fig. 1.24(a).
(b) Patterning the bottom HM with the mask shown in Fig. 1.24(b). (c) The combined HM is
used to etch the array hole pattern.

Figure 1.38 Overlapping the SNC mask with BL, BLC, BWL, and AA patterns.

Fig. 1.37(c). One of the advantages of the two-line-space mask for the SNC
hole pattern is that for the first mask [Fig. 1.36(a)] only the y-direction overlay
control is critical; for the second mask [Fig. 1.36(b)], only the x-direction
overlay control is critical. In contrast, both of the masks shown in Fig. 1.35
need good overlay control in the x and y directions.
Figure 1.38 shows the overlapping of a SNC mask with BL, BLC, BWL,
and AA patterns. The SNC holes go through the gaps between BLs and
connect the two ends of the AA patterns. Dielectric spacers and cap layers on
the BL allow the BLC hole to be etched in a self-aligned fashion. A thin,
conformal SiN film is deposited (usually after BLC etch and clean), and an
etch process removes the SiN film from the bottom of the SNC holes and
wafer surface. This process is very similar to the sidewall-spacer-formation
process, and the SiN film on the sidewall of the SNC hole can provide extra
protection to prevent SNC contact plugs from shorting to the BL.
For some devices the same two masks can be used to form contact holes in
the peripheral area. After Ti, TiN, and W deposition and CMP, the SNC
module in the array area is finished. Another dielectric layer, ILD2, is
deposited, and the metal 1 (M1) mask is needed to form the first
Manufacturing Processes of 3D IC Devices 31

ILD1
BL
STI
BLC
BWL
Array Periphery
(a)

SNC
ILD0
BL
STI
BLC
BWL
Array Periphery
(b)

SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(c) M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(d)
Figure 1.39 SNC, peripheral contact, and M1 process steps: (a) after ILD2 CMP, (b) after
ID2 etch and clean, (c) after SNC W/TiN/Ti CMP, and (d) after M1 W/TiN/Ti CMP.

Table 1.6 SNC, peripheral contact, and M1 process steps.

ILD1 deposition Wafer clean [Fig. 1.39(b)]
LD1 CMP [Fig. 1.39(a)] Ti/TiN/W deposition
HM deposition W/TiN/Ti CMP [Fig. 1.39(c)]
SNC mask 1 [Fig. 1.35(a)] Etch stop layer deposition
Etch HM ILD2 deposition
PR strip/clean M1 mask
SNC mask 2 [Fig. 1.35(b)] Etch ILD2
Etch HM PR strip/clean
PR strip/clean Ti/TiN/W deposition
Etch ILD1 W/TiN/Ti CMP [Fig. 1.39(d)]

metal-interconnect layer in the peripheral area. After etch, PR strip/clean, and

Ti/TiN/W deposition and CMP, the wafer is ready for the next process
module. Table 1.6 lists the process steps of SNC, peripheral contact, and M1,
which are also illustrated in Fig. 1.39.
32 Chapter 1

Figure 1.40 SN mask.

(a) (a)
Figure 1.41 Two masks that relax the SN pitch in Fig. 1.40.

The next step deposits an etch stop layer (usually silicon nitride), a thick
dielectric layer, 1.5–2.0-mm silicon oxide, and a cap layer (SiN). A SN mask
(Fig. 1.40), which is almost identical to the SNC mask in the array area, is
applied. For the SNC layer, contact hole etch, metal deposition, and metal
CMP are performed in both the array area and peripheral area. For the SN
layer, all of the processes are performed only in the array area. Because of the
high pattern density in a 2x-nm node, two masks are used to relax the
resolution requirement and help pattern the dense SN holes, as illustrated in
Fig. 1.41. The two-line-space pattern masks similar to that shown in Fig. 1.36
can also be used to form this SN pattern. In Fig. 1.42, the SN mask is
overlapped with SNC, BL, BLC, BWL, and AA. The SN mask is aligned with
the SNC mask to allow SN holes to land on the SNC plugs.
SN hole etch is one of the most challenging etch processes in IC
manufacturing. The pattern density is high, the CD is small, the hole is very
deep, and the aspect ratio is very high (50:1, possibly up to 100:1). There
are serval defects of interest (DOIs) in this etch process that could affect the
product yield, such as
• under-etch,
• bottom residue,
Manufacturing Processes of 3D IC Devices 33

• overlay shift that could cause high contact resistance or even a short
between the neighboring SN capacitors via the SNC plugs, and
• a bow-shaped etch profile that can cause a short between the neighbor-
ing SN capacitors in the middle of the cylinders, as shown in Fig. 1.43.
The SN-hole aspect ratio in the figure is 10:1, but it is much higher in
real devices.
After SN hole etch and clean, a thin TiN layer (10 nm) is deposited,
which serves as the electrode of the SN capacitor that connects to the array
transistor. A photoresist layer is applied to the wafer surface to fill the SN

Figure 1.42 Overlapping SN mask with SNC, BL, BLC, BWL, and AA patterns.
Overlay shift caused short

Bow short
Overlay shift
Under etch

SNC
BL
BLC
BWL
Figure 1.43 SN hole etch and main DOI.
34 Chapter 1

(a) (b)
Figure 1.44 (a) SiN slot mask and (b) slot mask overlaps with previous layers.

holes, with spin coating and hard bake. A photoresist etch back is
performed to expose the TiN on the top surface of the wafer. An etch
process is used to remove the TiN on the wafer surface while TiN on the
sidewall of the SN hole is protected by the photoresist. A mask [shown in
Fig. 1.44(a)] that allows the removal of SiN from all peripheral areas and
part of the array area, called slots, is applied. Figure 1.44(b) shows the SiN
slot mask in array area overlapping with SN, SNC, BL, BLC, BWL, and
AA layers. The top nitride layer is used to hold the tall TiN cylinders after
removing the thick oxide that surrounds the TiN cylinders and prevents the
cylinders from collapsing.
After SiN slot etch, hydrofluoric acid (HF) is used to remove the thick
ILD silicon oxide to expose the TiN cylinder through the opening in the
peripheral area and through the slots etched on the SiN in the array area.
The SiN cap layer functions like the plastic ring holder of a six-pack of
cans, preventing the TiN from falling down. Without the top nitride layer,
the tall TiN cylinders are likely to collapse and short to each other,
especially with the surface tension of liquids used in wet etch and clean.
After wafer cleaning of conformal, high-k dielectric layers, such as
zirconium oxide (ZrO), an aluminum oxide (AlO) stack with a total
thickness <10 nm is deposited on both the inside and outside wall of the
TiN cylinder. Another thin TiN layer, which is the electrode that connects
to the ground ( < 10 nm), is deposited with full coverage of both the inside
and outside of the cylinder to form the SN capacitor. Without an ILD
oxide recess, the capacitor can only form inside the SN hole with electrode
area p  CD  h. Here, CD is the SN hole CD, and h is the SN hole
depth. By recessing the ILD oxide and exposing the outside of the TiN
cylinder, the area of the SN capacitor is doubled, which allows scaling
down the SN cylinder CD by a factor of 2 without increasing the depth of
the SN hole. After conformal deposition of the ground electrode (usually
TiN), a conducting layer with good gap-fill capability (in many cases,
SiGe) is deposited to fill the remaining SN holes and the gaps between
Manufacturing Processes of 3D IC Devices 35

Table 1.7 SN module.

Wafer clean TiN deposition
Each stop layer (ESL) deposition PR coating
ILD deposition RP etch back
SiN deposition [Fig. 1.45(a)] TiN etch [Fig. 1.45(c)]
SN mask 1 [Fig. 1.41(a)] SiN slot mask [Fig. 1.44(a)]
Etch nitride Nitride etch
PR strip/clean PR strip/clean
SN mask 2 [Fig. 1.41(b)] ILD removal [Fig. 1.45(d)]
Etch nitride Wafer clean
PR strip/clean High-k film deposition
Etch oxide [Fig. 1.45(b)] TiN and conducting filler deposition [Fig. 1.45(e)]

cylinders, which finishes the SN module. Table 1.7 lists the process steps of
the recessed-stack cylinder capacitor.
Figure 1.45(a) shows the cross-section of the BWL DRAM after SN
dielectric-layer (etch stop nitride, thick oxide, and nitride cap layer)
deposition. Figure 1.45(b) shows the cross-section after SN hole etch, PR
strip, and clean. The insert shows the top-down cross-section view of two SN
holes in oxide. Figure 1.45(c) illustrates the cross-section after the top TiN is
removed. The PR in the SN holes protects the TiN film on the sidewall. The
inserted graph shows the hole filled with PR that protects TiN. Figure 1.45(d)
shows the cross-section after the thick ILD oxide is removed; the HAR TiN
cylinders stands on SNC plugs, holding on the SiN cap layer at the top and
the ESL/ILD2 layers at the bottom. The insert shows the TiN cylinders stand
on the wafer surface, empty both inside and outside. Some DRAM
manufacturers use two top SiN layers—one on the surface and another one
150 nm below the surface—to hold the thin and tall TiN cylinders.
Figure 1.45(e) shows the cross-section after deposition of a high-k dielectric
layer, TiN, and a conducting filler. The commonly used DRAM SN high-k
dielectric is a zirconium oxide–aluminum oxide–zirconium oxide (ZrO2/
Al2O3/ZrO2, or ZAZ) stack deposited by atomic-layer-deposition (ALD)
processes. The TiN is used as the ground electrode of the SN capacitor, and a
SiGe alloy is commonly used to fill the remaining SN holes and gaps between
the SN cylinders.
Thus ends the front-end-of-line (FEoL) processes of the advanced BWL
DRAM manufacturing process. Back-end-of-line processes occur primarily in
the peripheral area, starting with a mask layer that protects the array area and
etches away the metal layers in peripheral areas [Fig. 1.46(a)]. After PR strip
and clean, a thick ILD3 (usually silicon oxide) is deposited, and oxide CMP
planarizes the ILD3, as shown in Fig. 1.46(b). The via 1 (V1) mask is used to
etch via holes through the thick oxide layer to land on M1. Although these via
holes are very deep (2–3 mm)—even deeper than SN holes—their CDs are
usually larger than the CD of the SN hole, and their pitches are also much
36 Chapter 1

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(a)

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(b)
Figure 1.45 SN capacitor formation. After dielectric stack CVD (a); after SN hole etch,
insert is top-down view of SN holes (b); after surface TiN removal (c); after ILD oxide wet
etch (d); and after high-k dielectric and ground electrode deposition.

larger than that of the SN hole. V1 hole patterning has significantly relaxed
control of the CD, overlay, and etch profile than that of SN hole patterning.
After V1 etch and PR strip/clean, as shown in Fig. 1.46(c), Ti/TiN/W are
deposited into the V1 holes, and a CMP process removes W/TiN/Ti from the
wafer surface, leaving the conducting plug inside the ILD3, as shown in
Fig. 1.46(d).
Manufacturing Processes of 3D IC Devices 37

PR PR

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(c)

TiN TiN

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(d)
Figure 1.45 (Continued)

V1 formation is followed by metal 2 (M2), a single damascene copper (Cu)

metallization process. M2 process steps include stop-layer etch and ILD4
oxide deposition [as shown in Fig. 1.47(a)], M2 mask, M2 etch [as shown in
Fig. 1.47(b)], barrier and copper-seed layer deposition, copper electrochemi-
cal plating, copper anneal, and copper CMP (CuCMP) [as shown in
38 Chapter 1

TiN +filler

ZAZ TiN

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(e)

Figure 1.45 (Continued)

Fig. 1.47(c)]. For copper metallization, tantalum (Ta) or tantalum nitride

(TaN) is commonly used for the barrier layer, and the seed layer is
copper. Both layers are usually deposited by a physical-vapor-deposition
(PVD) process. Bulk Cu plating usually uses an electrochemical process,
with a wafer as the cathode and a pure-Cu plate as the anode. Copper
ions from the sulfate (CuSO4) in sulfuric acid will deposit on the wafer
surface that is negatively biased. Additives such as an accelerator,
suppressor, and leveler are added to the plating solution to accelerate
Cu plating at the bottom of the hole or trench, suppress the corner
deposition, and make the Cu surface flat, respectively. Table 1.8 lists the
process steps of V1-M2.
After M2 CuCMP, a dual-damascene Cu metallization process is used to
form V2 and M3. It starts with ESL, ILD5, dielectric cap, and metal HM
deposition; a M3 mask is used to etch the TiN HM. After PR strip/clean, a
V2 mask is used to etch dielectric layers and form the V2 holes and stop in
ESL. After PR strip/clean, dielectric etch forms the M3 trench and allows
the V2 to break though the ESL. Another clean process follows, and then
the metal barrier and seed layer are deposited, and finally the bulk copper is
plated, annealed, and polished. The Ta or TaN barrier and TiN HM mask
are also removed during CuCMP. After wafer clean, a cap layer deposition
finishes the V2-M3 module, as shown in Fig. 1.48; the process steps are
listed in Table 1.9.
The V3 process starts with ESL and ILD6 deposition, as shown in
Fig. 1.49(a); after the V3 mask is used to etch via holes, the PR is stripped and
Manufacturing Processes of 3D IC Devices 39

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array (a) Periphery

ILD3

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(b)
Figure 1.46 V1 process steps (a) after peripheral metal etch and clean, (b) after ILD3
CMP, (c) after V1 etch and PR strip/clean, and (d) after V1 WCMP.

wafer cleaned, as illustrated in Fig. 1.49(b). Then the Ti/TiN/W stack is

deposited and the CMP process removes all metal layers on the wafer surface
for W plugs that contact M4 to M3 (Fig. 1.49).
The last interconnect layer of this BWL DRAM manufacturing process is
the metal 4 (M4) layer. It starts with metal stack PVD, which deposits Ti/Al-
Cu/TiN, as shown in Figure 1.50(a). Here Ti is used to reduce contact
40 Chapter 1

ILD3

V1

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(c)

ILD3

V1

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(d)
Figure 1.46 (Continued)

resistance between metal stack and W plugs. Al-Cu is an aluminum alloy with
0.5% copper to increase resistance of electromigration and improve chip
reliability. The top TiN is used as an ARC to reduce the standing wave
effect during M4 patterning. The M4 mask is used to pattern and etch the
M4 metal stack, which forms the last layer of interconnects and bond pads.
After PR strip and clean [Fig. 1.50(b)], the passivation dielectric layers
(usually silicon oxide and then silicon nitride) are deposited, as shown in
Manufacturing Processes of 3D IC Devices 41

ILD4

ILD3

V1

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(a)

ILD4 ILD4

ILD3

V1

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(b)
Figure 1.47 M2 processes: (a) ESL and ILD4 deposition, (b) M2 mask ILD4 and ESL etch,
and (c) M2 CuCMP.
42 Chapter 1

ILD4 ILD4

ILD3

V1

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
(c)
Figure 1.47 (Continued)

Table 1.8 V1 and M2 process steps.

Peripheral area mask W/TiN/Ti CMP [Fig. 1.46(d)]
Etch SiGe/TiN/ZAZ ESL deposition
Photoresist strip and clean [Fig. 1.46(a)] ILD4 deposition [Fig. 1.47(a)]
ILD3 deposition M2 mask
ILD3 CMP [Fig. 1.46(b)] M2 etch
V1 mask PR strip/clean [Fig. 1.47(b)]
V1 etch [Fig. 1.46(c)] Barrier and seed-layer deposition
PR strip and clean Bulk copper plating
Ti/TiN deposition Cu anneal
W deposition CuCMP [Fig. 1.47(c)]

Table 1.9 V2 and M3 process steps.

ESL, ILD5, and dielectric cap deposition ILD 5 etch
Metal HM deposition [Fig. 1.48(a)] ESL removal [Fig. 1.48(c)]
M3 mask Clean
HM etch [Fig. 1.48(b)] Barrier and seed-layer deposition
PR strip and clean Bulk copper plating
V2 mask Cu anneal
Dielectric cap and ILD5 etch CuCMP [Fig. 1.48(d)]
PR strip and clean
Manufacturing Processes of 3D IC Devices 43

ILD5

M2 ILD4

(a)

M3

ILD5

M2 ILD4

(b)

M3

V2 ILD5

M2 ILD4

(c)

M3

V2 ILD5

M2 ILD4

(d)
Figure 1.48 V2-M3 processes: (a) ESL, ILD4, and metal HM deposition, (b) M3 mask HM
etch, (c) V2 ILD and ESL etch, and (d) M3 CuCMP.

Fig. 1.50(c); the last mask, a bond pad mask, is used to pattern and etch
the passivation dielectric stack to expose the bond pads for test probing
and wire bonding. After PR strip and clean, as shown in Fig. 1.50(d), the
wafer is ready for the wafer-acceptance test (WAT). The wafer can be
shipped for packaging if it passes the WAT. The process steps of V3-M4
and passivation are listed in Table 1.10.
Figure 1.51 illustrates the cross-section of BWL DRAM with both the
array area and peripheral area. It has four metal layers: M1 is W, M2 and
M3 are Cu, and M4 is an Al-Cu alloy. The wafer has finished processing,
and it is ready for electrical test. The WAT will determine the yield data of
44 Chapter 1

ILD6

M3

V2 ILD5

M2 ILD4

(a)

ILD6
V3

M3

V2 ILD5

M2 ILD4

(b)

ILD6
V3

M3

V2 ILD5

M2 ILD4

(c)
Figure 1.49 Cross-section of via 3 process steps: (a) ESL and ILD6 deposition, (b) V3 etch
and PR strip/clean, and (c) V3 WCMP.

the wafer process; the yield is the key for the success of the wafer fab,
which is especially important for DRAM fabs because DRAM is very
cost-sensitive.

1.3 Brief Summary of DRAM

This chapter described an advanced-technology node DRAM manufacturing
processes with a BWL, recessed cylindrical capacitor, and 6F2 layout. Future
scaling of the DRAM has many challenges, such as capacitor formation,
a new device structure, new layout, and maybe new patterning processes
with EUV.
Manufacturing Processes of 3D IC Devices 45

M4

ILD6
V3

M3

V2 ILD5

M2 ILD4

(a)

M4

ILD6
V3

M3

V2 ILD5

M2 ILD4

(b)

SiN

M4
SiOx

ILD6
V3

M3

V2 ILD5

M2 ILD4

(c)
Figure 1.50 Cross-section of V3-M4 and passivation processes: (a) after M4 Ti/l-Cu/TiN
PVD, (b) after M4 etch and PR strip and clean, (c) after passivation oxide and nitride CVD,
and (d) after bond pad etch and PR strip and clean.
46 Chapter 1

SiN

M4
SiOx

ILD6
V3

M3

V2 ILD5

M2 ILD4

(d)
Figure 1.50 (Continued)

As addressed earlier, the capacitor is the most challenging part of the

DRAM scaling. When the DRAM feature size scales down deep into a 1x-nm
node, the CD and pitch of the SN cylinder holes could become too small to
allow a recessed cylinder to form a double-sided capacitor; the capacitor must
return to the single-side cylinder without recess, similar to the one shown in
Fig. 1.8, with a much higher aspect ratio. Because the aspect ratio of the
recessed cylinder capacitor is already 50:1, the aspect ratio of a cylinder
capacitor with a smaller CD and without recess could easily go higher than
200:1 if the same high-k dielectric (ZAZ) is still used. To control the aspect
ratio within 100:1, a new capacitor dielectric with a k value significantly
higher than ZAZ (k20) is needed. One such candidate is strontium titanate
(SrTiO3 or STO, k ¼ 146 in bulk material) using ALD to achieve
excellent step coverage (95%), high thickness uniformity, and good
stoichiometry.12
Figure 1.52 illustrates the DRAM array-area factor improvement in
recent years. The smallest achievable unit array area for a planar device is 4F2,

Table 1.10 V3-M4 and passivation process steps.

ESL and ILD6 deposition [Fig. 1.49(a)] M4 mask
V3 mask Etch TiN/Al-Cu/Ti stack
ILD6 and ESL etch PR strip/clean [Fig. 1.50(b)]
PR strip and clean [Fig. 1.49(b)] Passivation oxide and nitride deposition [Fig. 1.50(c)]
5Ti/TiN/W deposition Bond pad mask
W/TiN/Ti CMP [Fig. 1.49(c)] Etch nitride and oxide
Wafer clean PR strip and clean [Fig. 1.50(d)]
Ti/Al-Cu/TiN deposition [Fig. 1.50(a)]
Manufacturing Processes of 3D IC Devices 47

SiN

M4 Al-Cu
SiOx

ILD6
V3 W

M3
Cu
V2 ILD5

M2 Cu ILD4

ILD3

W
V1

M1

ILD2
SNC
ILD1
BL
STI
BLC
BWL
Array Periphery
Figure 1.51 Cross-section of BWL DRAM with four metal interconnection layers.

which has been used in planar NAND flash cell design. Theoretically, DRAM
can also achieve a unit array area of 4F2 with a vertical cell transistor and
buried bit-line design, as shown in Fig. 1.53. Figure 1.53(a) shows the 4F2
DRAM cell layout. It can be seen from Fig. 1.53(b) that the device
architecture is quite different from the previous generation. The BL is
buried, and the cell transistor is a vertical gate-all-around fully depleted
MOSFET. This type of DRAM has not yet been used in DRAM chip
production.
48 Chapter 1

16Mb
25
22-16F 2
Cell Area Factor, aF 2

64Mb
20
16-11F 2

15 256Mb
10-8F 2 1Gb
10-8F 2 2Gb
10 8-6F 2 4Gb 8Gb
6F 2 6F 2 16Gb
4F 2 ?
5

0
90 92 94 96 98 00 02 04 06 08 10 12 14 16 18
Year
Figure 1.52 DRAM array-area factor scaling, based on Ref. C.

Storage node
capacitor
SN

Gate
oxide N-type Si

2F
e
lin
d

BL
or
W

2F N-type Si

WL
Bit line

(a) (b)
Figure 1.53 (a) Layout of a 4F DRAM, and (b) 3D illustration of 4F2 DRAM.
2

1.4 Review Questions

1. How many devices are in a DRAM unit cell? What types of devices?
2. List at least three types of DRAM cell transistors.
3. What are the advantages of a 3D capacitor compared to a 2D planar
capacitor?
4. Explain how can BWL DRAM reduce three photolithography masks
from RG DRAM while forming the cell transistor/WL, contacts, and SN
capacitor?
5. What is the benefit of recessing a SN cylinder?
6. Describe the needs of high-k dielectric in DRAM manufacturing.
7. Explain why a SN capacitor is the most challenging part of DRAM
scaling.
8. Describe the benefits and challenges of scaling a DRAM cell from 8F2 to
6F2 and then 4F2.
Chapter 2
3D-NAND Flash and Its
Manufacturing Process

After reading this chapter, you should be able to

• Draw and describe a NAND flash memory cell;
• Give the minimum unit-cell size of planar NAND flash in relationship
to the technology node;
• Explain the advantages of 3D-NAND flash compared to planar NAND
flash; and
• List at least two processes in the 3D-NAND manufacturing process that
need HAR etch.

2.1 Introduction
Flash memory chips are nonvolatile memory (NVM) chips, which can keep
memory without power supply. In comparison, DRAM is volatile memory
and needs a power supply. Flash memory chips, especially NAND flash
memory chips, are commonly used in universal serial bus (USB) drives, secure
digital (SD) cards, and SSDs. These NVM devices are widely used in
electronics devices for data storage, especially in mobile electronics such as
digital cameras, smartphones, tablets, high-end laptops, etc. Compared with a
hard-drive disk (HDD), a SSD has a shorter data-access time, consumes less
power, and is more reliable because it does not have any moving parts.
The basic device structure of a flash memory cell is very similar to a
NMOS. It has a p-well and n þ S/D, but the main difference is that it has a
floating gate (FG), a control gate (CG), and inter-gate dielectrics (IGD) in
between, as illustrated in Fig. 2.1. It is a charge trap device that retains
memory by tunneling electrons from the drain through the gate oxide and
trapping them in the FG. The memory can be erased by tunneling the stored
electrons away from the FG to the CG through the IGD. Each time that

49
50 Chapter 2

Control gate
Inter-gate
dielectrics
Floating gate
Source n+ n+ Drain
p-well

p-sub

Figure 2.1 Basic structure of a floating-gate nonvolatile memory device.

electrons tunnel through the gate oxide and IGD can cause dielectric
degradation, and so a flash cell has a limited number of writes and erases
(105).
Figure 2.2 illustrates a variation of the charge-trap flash-memory device.
Instead of a polysilicon floating gate, it uses a SiN layer to trap the charge and
store the data. Most planar NAND flash memories are FG NAND flash
devices. However, a majority of 3D-NAND flash devices use memory cells
with a SiN charge-trap layer.
There are two types of flash memory, NOR and NAND, depending on
how the flash cells are connected to the bit line and source line (ground).
Figures 2.3(a) and (b) are the NOR flash circuit and its cross-section,
respectively. Figures 2.3(c) and (d) are a 64-bit string NAND flash circuit and
the corresponding cross-sections, respectively.
Every memory cell has a shared contact to the bit line and shared source
line in a NOR flash. For a NAND flash, it shares a bit line contact and a
source line contact for every string of memory cells. NOR flash is equivalent
to a 1-cell string NAND flash that does not require the select gates. NOR
flash can achieve random access of any memory cell while NAND flash

Control gate Inter-gate

dielectrics
Charge trap SiN
Source n+ n+ Drain
p-well

p-sub

Figure 2.2 Flash memory cell with a SiN charge-trap layer.

3D-NAND Flash and Its Manufacturing Process 51

Bit line

WL WL
(a)

Source line

Bit line
Control
WL0 WL
gate

(b)

Source line Floating gate

P-substrate N+

Bit line

SG0 SG1
WL0 WL1 WL63
(c)

Bit line

Source line

Control gate
(d) SG0 WL0 WL1 WL63 SG1

P-substrate N+ Floating gate

Figure 2.3 (a) NOR flash circuit, (b) NOR flash cross-section, (c) NAND flash circuit, and
(d) planar NAND flash cross-section.
52 Chapter 2

cannot. Although NOR flash has shorter reading time than NAND flash, it
has longer write time and erase time. It also costs significantly higher than
NAND flash because of its lower packing density due to the dense bit line
contacts. This is the main reason why the majority of solid state storage devices
are NAND flash based, and NOR flash only takes a small niche market.
Figure 2.4(a) shows the array area layout of the WL and AA of a planar
NAND flash memory; Figure 2.4(b) shows its cross-section along the AA
direction in both the array area and peripheral area. In the figure, CB
represents the contact with the BL, SG stands for select gate, and SL stands
for source line. The NAND flash-memory cell has the highest pattern density
of all planar IC devices. Its technology node is the half pitch of the WL

Unit cell

AA direction

WL direction
(a)

M3
ILD4
V3

M2 M2
ILD3 V2 V2
M1 BL M1
CB2 V1
ILD2
CB pad M0 SL ILD1 M0
WL63 WL0
CB1 ILD0 ILD0
SG1 SG0

P-substrate P-well P-well N-well

AA direction Periphery

(b)
Figure 2.4 (a) Array area layout of 64-bit planar NAND flash, and (b) cross-section with
both the array area and peripheral area.
3D-NAND Flash and Its Manufacturing Process 53

pattern, and its unit array area can achieve the minimum value of 4F2 [see
Fig. 2.5(a)]. Here, F is the technology node. For example, the WL pitch of a
16-nm planar NAND flash is 32 nm, which is far smaller than the minimum
achievable pitch of a high-NA 193-nm immersion photolithography process.
Without extreme-ultraviolet (EUV) lithography, 16-nm planar NAND flash
requires pitch tripling or SAQP using 193-nm immersion lithography.
Scaling planar NAND flash devices beyond the 10-nm node would need
more than quadrupling with a 193-nm immersion lithography process for at
least three critical layers, AA, WL, and BL, which would make its
manufacturing cost very expensive. To reduce the scaling cost, a different
device structure based on the idea of a vertical gate-all-around MOSFET
(GAA-FET) had been proposed. Making the NAND string in the vertical
direction can dramatically reduce the footprint and increase the packing
density. Figure 2.5 illustrates the 3D and top views of 3D-NAND flash.5 The
illustration shows the staircase contact, the lower select-gate string, four flash
memory devices, and the upper select gate.
Figure 2.5(c) is the circuit of the 3D NAND array shown in Fig. 2.5(a); it
basically puts the four-cell NAND string in the vertical direction and uses a
vertical GAA-FET for the select gate and the flash memory cell. The layout
unit area is 6F2 with four stacks, equivalent to 1.5F2. In the first high volume
manufacturing of 3D-NAND, 32 stacks are used, which can achieve 0.1875F2
with the same layout. A quick calculation can find how much a 32-stack
3D-NAND helps relax the photolithography requirement:

p
6F 23D ∕32 ¼ 4F 2P or F 3D ¼ ð8∕ 3ÞF P .

Here, F3D is the technology node of 3D-NAND, and FP is the equivalent

planar NAND flash-technology node. With 32-stack 3D-NAND, a 74-nm
technology node can achieve the same memory density as 16-nm planar
NAND flash. It is assumed here that the 16-nm planar flash uses the 4F2
layout, which may not always be true because the pitch of the AA and BL is
sometimes relaxed so they can be formed with SADP using 193-nm immersion
photolithography to reduce the manufacturing cost. Whereas a 16-nm (32-nm
WL pitch) 3D-NAND pattern needs triple patterning or SAQP, the 74-nm
(148-nm pitch) version can be achieved with a single-patterning process.
Therefore, the photolithography requirement of 3D-NAND is dramatically
relaxed, and the main challenges are the etch/clean processes that form the
HAR channel holes, isolation trench, and staircase contact holes. Another
challenge involves the conformal deposition of multiple thin film layers into
the HAR structures. The scaling of a NAND flash memory chip occurs
mainly in the z direction by stacking more layers. The trend of stacking layers
is 32, 48, 64, 96, and 128, and it has room to further scale the feature size of
3D-NAND flash memory. The aspect ratio of the 3D-NAND device structure
54 Chapter 2

(a)

2F

3F

(b)

Bit lines

Upper SG

WL3

WL2

WL1

WL0

Lower SG

(c)
Figure 2.5 (a) 3D view and (b) top view of a 3D-NAND flash memory array (source: Ref. 5,
reprinted with permission from IEEE) and (c) its circuit.
3D-NAND Flash and Its Manufacturing Process 55

will increase further in the future, and thus etch, clean, deposition, metrology,
and inspection will become even more challenging.

Question: What is the equivalent 4F2 planar NAND flash-memory technology node of a
74-nm, 6F2, 128-stack 3D-NAND flash memory chip?
p
2
Answer: 6F3D /128 ¼ 4FP2 or F P ¼ ð3∕256Þ F 3D  0.108 F 3D  8 nm

2.2 3D-NAND Flash Memory Manufacturing Processes

The manufacturing processes of 3D-NAND flash memory are quite different
from those of traditional planar NAND flash; they begin with the peripheral
CMOS devices. Array-area processes, such as multi-layer deposition and
staircase formation, follow with a channel hole module, which includes
channel hole etch, lower SG formation, and channel layer deposition. The
next module is isolation trench, which is also used to create the control gates
of the 3D-NAND, followed by the contact module. Because the contact holes
land on the staircase and peripheral circuits, the depth varies in a significantly
larger range, which poses a large challenge to the dielectric etch processes.
After that, M1 forms the local interconnect and other metal wires, M2 forms
the bit line, and M3 finishes the interconnects; after passivation dielectrics are
deposited, the last mask opens bond pads for wire bonding, and the process is
finished. This section describes these process modules in more detail.

2.2.1 Peripheral module

For planar NAND flash memory, the peripheral devices are processes at the
same time as the flash memory cells in array area. The major differences
involve peripheral devices that have a larger feature size and require a mask to
remove part of the inter-gate dielectric so that the control gate can short to the
floating gate, just like the select gates in the array area (Fig. 2.4).
For 3D-NAND flash memory, the peripheral devices are planar
MOSFETs. The feature size for peripheral devices is usually large enough
to be patterned with a single 193-nm immersion-lithography process. The
process flow is very similar to the front-end-of-line (FEoL) part of the CMOS
process described in Chapter 14 of Xiao.11
The process starts with STI formation, which includes pad oxidation,
nitride deposition, AA mask patterning, nitride etch, PR strip and clean,
silicon etch and clean, oxidation and oxide CVD, oxide CMP, and nitride and
pad oxide strip. Figure 2.6(a) shows the cross-section of the starting silicon,
and Fig. 2.6(b) shows the peripheral CMOS devices after STI formation. The
label SiOx represents silicon oxide deposited with the CVD process.
56 Chapter 2

P-Wafer

(a)
STI SiOx

P-Wafer
(b)
Figure 2.6 Cross-section of (a) the starting silicon and (b) the peripheral CMOS devices
after STI formation.

Next are well and channel implantations for both NMOS and PMOS;
Figure 2.7 shows the cross-section of peripheral CMOS after both ion
implantations. There are two photomasks in these steps: one for NMOS, and
one for PMOS. After wafer clean, gate oxidation, polysilicon, metal silicide,
and HM deposition, the gate mask is used to pattern the hard mask, and the
polysilicon/silicide gate stack is etched with the HM pattern. Figure 2.8 shows
the cross-section of the peripheral CMOS devices after polysilicon/silicide
gate-stack etch.
After wafer inspection and clean, an oxidation is performed, and two ion
implantation masks are used to form a lightly doped drain (LDD): one mask
for NMOS and another for PMOS. After wafer clean, a conformal dielectric

STI SiOx
P-Well N-Well

P-Wafer

Figure 2.7 Cross-section of the peripheral CMOS after well and channel implantation.

Hard mask Polysilicon gate Silicide

STI SiOx
P-Well N-Well

P-Wafer

Figure 2.8 Cross-section of the peripheral CMOS after polysilicon gate etch.
3D-NAND Flash and Its Manufacturing Process 57

layer is deposited and etched back only in the vertical direction to form the
sidewall spacer. Two more masks are used for the heavily doped S/D. After
wafer clean and rapid thermal annealing (RTA), the transistors of the
peripheral devices are formed. Figure 2.9 shows the cross-section of the
peripheral CMOS after S/D implantation and RTA. There are four
photomasks and at least four ion implantations in Figs. 2.8–2.9.
The last steps of the peripheral FEoL process are SiN liner deposition and
very thick (3 mm) silicon oxide deposition (Fig. 2.10); note that PMD stands

Hard mask Polysilicon gate Sidewall spacer

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Figure 2.9 Cross-section of the peripheral CMOS after S/D formation.

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Figure 2.10 Cross-section of the peripheral CMOS after the FEoL processes are finished.
58 Chapter 2

Table 2.1 Peripheral CMOS process steps.

Wafer clean [Fig. 2.6(a)] PR strip and clean
Pad oxidation Hard mask deposition
Nitride deposition Gate mask
AA mask Etch hard mask
Nitride etch PR strip and clean
PR strip/clean Etch silicide/polysilicon
Silicon etch Wafer clean (Fig. 2.8)
Wafer clean n-LDD mask
Oxidation n-LDD ion implantation
Oxide deposition PR strip and clean
Oxide CMP p-LDD mask
Strip nitride and pad oxide, and wafer clean [Fig. 2.6(b)] p-LDD ion implantation
Oxidation of sacrificial oxide PR strip and clean
n-well mask Spacer dielectric film CVD
n-well and p-channel ion implantation Dielectric etch back
PR strip and clean n-S/D mask
p-well mask n-S/D ion implantation
p-well and n-channel ion implantation PR strip and clean
PR strip and clean (Fig. 2.7) p-S/D mask
Strip sacrificial oxide and wafer clean p-S/D ion implantation
Gate oxidation PR strip and clean
Polysilicon and silicide deposition RTA (Fig. 2.9)
Poly-dope mask SiN liner deposition
Poly-dope ion implantation PMD deposition (Fig. 2.10)

for “pre-metal dielectric.” The FEoL process steps of peripheral CMOS are
listed in Table 2.1.
In a real peripheral process, there are more process steps than those listed
in Table 2.1. For example, input/output transistors differ from sensor
amplifier transistors. Their working voltages are different, and thus their gate
oxide thicknesses are different, which requires additional photomask steps. It
requires at least two gate-oxidation processes. Furthermore, their ion-
implantation processes are different due to the different junction depths and
dopant concentration requirements, which also require additional implanta-
tion mask steps.

2.2.2 Multi-layer deposition and staircase formation

The processes to build 3D-NAND memory devices in the array area start
after the FEoL processes in the peripheral area are finished. A mask that
defines the array area is applied, followed by an etch process that removes the
thick oxide and SiN liner. Because the pattern is so large, wet etch can be used
for this process; hydrofluoric acid (HF) can be used to etch silicon oxide, and
hot phosphoric acid can be used to remove SiN. Figure 2.11(a) illustrates a
portion of this mask that defines the array area. Figure 2.11(b) is a close-up of
the tiny box on the right side of Fig. 2.11(a). Figure 2.11(c) shows the cross-
section of the transition region between the array area and peripheral area
3D-NAND Flash and Its Manufacturing Process 59

Array area

Periphery area

(a)

(b)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(c)
Figure 2.11 (a) Cell mask, (b) close-up, and (c) cross-section after etch. See Fig. 2.10 for a
close-up of the right part of (c).
60 Chapter 2

after patterning, etch, PR strip, and wafer clean correlated to Fig. 2.11(b). The
features on the right of Fig. 2.11(c) are scaled from Fig. 2.10.
The wafer is then ready to deposit the multi-layers, of which there are
several types, including ONON, which stands for oxide/nitride/oxide/nitride.
Here, oxide refers to silicon oxide, and nitride refers to silicon nitride. Another
type of multi-layer is OPOP, which stands for oxide/poly/oxide/poly; poly
refers to polycrystalline silicon, or polysilicon.
This chapter discusses the ONON stack. In a CVD system, multiple pairs
of ON layers are deposited. A 32-cell stack needs at least 34 pairs of ON
because there are also two SGs, one at the bottom and one at the top. Multiple
dummy layers are needed to isolate the SGs and the memory cells to avoid
cross-talk. A reverse-engineering report shows that 32-cell 3D-NAND flash-
memory products have, in fact, 39 pairs. Figure 2.12(a) illustrates the first two
pairs of ONON deposition, and Fig. 2.12(b) shows after 34 pairs of ONON
are deposited, in both the array area and the peripheral area. There are many
challenges facing this multi-layer deposition: it needs to have uniform

PMD

n+ SiOx p+ p+
ll N-Well
N-We
W ll

P-Wa
W fe
f r
P-Wafer

(a)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(b)
Figure 2.12 Multi-layer deposition: (a) two pairs of ONON, and (b) 34 pairs of ONON.
3D-NAND Flash and Its Manufacturing Process 61

thickness and low defect density. It is also very challenging to measure the
thickness of each layer.
Staircase formation is a unique process of 3D-NAND flash. After multi-
layer deposition, a very thick photoresist layer (5–6 mm) is coated on the
wafer surface, the staircase mask is applied, and a well-controlled oxide and
nitride etch is performed, which stops after the first nitride is etched away, as
shown in Fig. 2.13(a). After the first pair of oxide and nitride is etched away, a
controlled photoresist trimming is performed and the trimmed photoresist is
used to etch the first and the second pair of oxide and nitride [Fig. 2.13(b)].
The photoresist is then trimmed again, and the first, second, and third pair of
oxide/nitride are etched, which is illustrated in Fig. 2.13(c). Here,
Oxide_N þ 1 is the cap oxide, and Oxide_N and Nitride_N are the nth pair
of the oxide and nitride stack, respectively.
The number of times that photoresist can be trimmed is limited by its
original thickness. After that limit, it must be stripped so that another thick
photoresist can be coated, and the second staircase mask is applied to repeat
the staircase etch process. Four to five staircase masks are needed for the stack
of 34 pairs of oxide/nitride. This process will repeat multiple times until it
reaches the silicon surface, as shown in Fig. 2.14. Here, Oxide_x and
Nitride_x is the xth pair of oxide/nitride. The Oxide_2 layer is thicker than
other oxide layers because it is the isolation oxide used to separate the lower
select gate from the cell devices.
Figure 2.15(a) shows a portion of a staircase mask. Figure 2.15(b) is a
close-up of the box in Fig. 2.15(a). The staircase is located in the transition
area between the array area and peripheral area, as shown in Fig. 2.15(c). The
features on the right of Fig. 2.15(c) are further scaled down from Fig. 2.10. At
this stage, the array area looks like a flattened, miniature ziggurat.
A thick layer of oxide is deposited, as shown in Fig. 2.16(a). After oxide
CMP, the wafer surface is planarized, as shown in Fig. 2.16(b). The process
steps of this module are listed in Table 2.2. Afterwards, the wafer is ready for
the next process module.

2.2.3 Channel module

The channel module process is another unique process and also one of the
most challenging processes of 3D-NAND. Figure 2.17 illustrates a six-stack
3D-NAND flash memory with strings that consist of a lower SG, an upper
SG, and a four-cell memory string between them. It looks like a final product,
with the silicon oxide between gates, around channels, and around contact
plugs removed so that the polysilicon channels, contact plugs, control gate,
and metal lines are exposed in the birds-eye view. The 3D flash-memory chip
in high-volume manufacturing has a similar structure, but it has many more
memory cells in a string. The existing products have 32 cells in a string and a
total of 39 stacks; products with 48- and 64-cell strings are in development.
62 Chapter 2

PR

SiOx Oxide_N+1
SiN Nitride_N
Oxide_N
Nitride_N-1
Oxide_N-1
Nitride_N-2
Oxide_N-2
Nitride_N-3
(a)

PR

SiOx Oxide_N+1
SiN Nitride_N
Oxide_N
Nitride_N-1
Oxide_N-1
Nitride_N-2
Oxide_N-2
Nitride_N-3
(b)

PR

SiOx Oxide_N+1
SiN Nitride_N
Oxide_N
Nitride_N-1
Oxide_N-1
Nitride_N-2
Oxide_N-2
Nitride_N-3
(c)
PR
SiOx Oxide_N+1
SiN Nitride_N
Oxide_N
Nitride_N-1
Oxide_N-1
Nitride_N-2
Oxide_N-2
Nitride_N-3

(d)
Figure 2.13 Staircase formation: (a) the first-pair, (b) the second-pair, (c) the third-pair, and
(d) the fourth pair of oxide/nitride stack etch.
3D-NAND Flash and Its Manufacturing Process 63

Nitride_4
SiOx Oxide_4
SiN Nitride_3
Oxide_3
Nitride_2

Oxide_2

Nitride_1
Oxide_1

Si

Figure 2.14 Staircase formation (note that it ends with the silicon surface).

This section explains the channel process in detail, focused on the bottom and
top of the channel because the cells in the middle of the string are almost the
same.
After wafer clean, HM layer deposition, and PR coating, the channel hole
mask is applied, and channel holes are etched first on the HM, which is
usually amorphous carbon, and then the HM pattern is used to etch through
the ONON multi-layers in one etch process. The channel hole is very deep
(usually > 3 mm), and the aspect ratio could be > 30:1. Figure 2.18(a)
illustrates a channel hole mask, Fig. 2.18(b) is the close-up of the rectangular
box in Fig. 2.18(a), and Fig. 2.18(c) shows the cross-section along the solid
line in the lower part of Fig. 2.18(b) after etch, PR strip, and clean. The scale
of the hole size and hole pitch in Figs. 2.18(a) and 2.18(b) is too large and not
proportional to the multi-layer thickness.
Channel hole etch is a very challenging process. It needs to etch multiple
silicon-oxide and silicon-nitride stacks to form a deep, straight hole with well-
controlled top and bottom CDs. The channel width of the gate-all-around
MOSFET and flash cells is determined by the circumference of the channel
hole, and thus the CD control within the hole, within the die, within the wafer,
and wafer-to-wafer are critical to keep device performance and yield
consistent. The channel hole must also etch all the way to the silicon
substrate; otherwise, the string would lose its connection to the source
(ground) and suffer yield loss.
Figures 2.19(a)–(f) are illustrations of the cross-section along the solid line
in the center of Fig. 2.18(a). Figure 2.19(a) is a top-down cross-section of the
channel hole in the cap oxide, indicated by the dashed lines next to it. This
channel hole is surrounded by oxide right after channel hole etch, PR strip,
and clean. Figure 2.19(b) is a top-down cross-section of the channel hole in the
Nitride_N-2, indicated by the dashed lines. This channel hole is surrounded by
nitride at this process stage. Figure 2.19(c) is a close-up illustration of the
cross-section at the top of the multi-layers, indicated with a circle in the upper
64 Chapter 2

Array area

Periphery area

(a)

(b)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Cell area Periphery area

(c)
Figure 2.15 (a) Staircase mask, (b) close-up, and (c) cross-section.
3D-NAND Flash and Its Manufacturing Process 65

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

(a)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area (b) Periphery area

Figure 2.16 (a) Post-staircase oxide CVD, and (b) oxide CMP.

left of Fig. 2.18(c). Figure 2.19(d) is a top-down cross-section of the channel

hole in the Nitride_3. This channel hole is surrounded by nitride. Figure 2.19(e)
is a top-down cross-section of the channel hole in Nitride_1, which is also
surrounded by nitride. This section will eventually become the lower SG, and
its later processes are quite different from other devices in other nitride layers.
Figure 2.19(f) is a close-up of the cross-section near the bottom of the multi-
layers, indicated in the lower left of Fig. 2.18(c) as a rectangular box.
Figure 2.20 illustrates the selective epitaxial growth (SEG) of silicon at
the bottom of the channel hole. Figures 2.20(a) and (b) are top-down views
of the channel at this process step in Nitride_3 and Nitride_1, respectively.
The epitaxial silicon only grows at the bottom of the channel hole, where
the single-crystalline silicon is exposed. It is very important to have the SEG
silicon within Oxide_2, which is intensively deposited thicker than other
oxide layers. If the SEG is too thin, e.g., in Nitride_1, the lower SG will not
function correctly. If it is too thick, or if the SEG silicon grows into
Nitride_2, a short will occur between the select gate and memory cell. Either
result will cause yield loss. Therefore, a pre-SEG clean process between
Figs. 2.19(f) and 2.20(c) is critical because any residue at the bottom of the
channel hole can cause issues in SEG Si and affect the product yield. It is
obvious that during SEG Si the process only affects the bottom of channel
66 Chapter 2

Table 2.2 Multi-layer-deposition and staircase-formation process step.

Array area mask [Fig. 2.11(a) and (b)] Photoresist trimming
Etch oxide and barrier nitride Etch Oxide_N-1/Nitride N-2 and stop on Oxide_N-2
[Fig. 2.13(c)]
PR strip and clean [Fig. 2.11(c)] Repeating trimming and O/N pair etch
CVD Oxide_1, CVD Nitride_1, and the PR strip and clean
lower SG nitride
CVD Oxide_2, CVD Ntride_2, and cell nitride Second staircase mask
[Fig. 2.12(a)]
CVD Oxide_3/Nitride_3 pairs Repeating trimming and O/N pair etch
Repeating the process until Oxide_N/Nitride_N Third staircase mask
[Fig. 2.12(b)]
CVD Oxide_N þ 1 and cap oxide Repeating trimming and O/N pair etch
First staircase mask Etch Oxide_1, stop on silicon [Fig. 2.14]
Etch Oxide_N+1/Nitride_N, stop on Oxide_N PR strip and wafer clean [Fig. 2.15(a)]
[Fig. 2.13(a)]
Photoresist trimming Oxide CVD [Fig. 2.15(b)]
Etch Oxide_N/Nitride_N-1 and stop on Oxide CMP [Fig. 2.15(c)]
Oxide_N-1 [Fig. 2.13(b)]

holes and will not affect the top layers, which is why a cross-section of the
top layers is not provided here.
After SEG Si is deposited at the bottom of the channel, a thin, conformal,
high-k dielectric layer, charge trap layer (silicon nitride), and gate oxide are
also deposited. Figure 2.21(a) shows the top-down view of the channel hole in
cap oxide. Three layers are drawn in the channel holes, gate oxide, nitride
charge trap layer, and high-k dielectric. A real product may have more layers,
depending on the requirements of the device performance, product yield, and
produce reliability. Figures 2.21(a) and 2.21(b) are top-down views of the
channel hole in cap oxide and nitride N-1, respectively. Figure 2.21(c) is the
cross-section of the channel hole near the top surface of the multi-layers after
the deposition of channel dielectric layers. Figures 2.21(d) and 2.21(e) are the

Figure 2.17 3D view of a 3D-NAND flash memory with a four-cell string and six stacks.
Source: Ref. 5, reprinted with permission from IEEE.
3D-NAND Flash and Its Manufacturing Process 67

Array area

Periphery area

(a)

(1) Channel hole (2) Multi-layers (3) WL contacts

(b)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(c)
Figure 2.18 (a) Channel mask in a cell, (b) close-up of the box in (a), and (c) cross-section
along the solid line.
68 Chapter 2

Oxide_4
Nitride_3
Oxide_N+1
Oxide_3
Nitride_N Nitride_2
(a) Oxide_N (d)
Oxide_2
Nitride_N-1
Oxide_N-1
Nitride_N-2 Nitride_1
Oxide_N-2 Oxide_1
Nitride_N-3
Si
(e)
(b) (c) (f)
Figure 2.19 (a) Top-down cross-section of a channel hole in cap oxide and (b) in
Nitride_N-2, and (c) cross-section along the channel; (d) top-down cross-section in Nitride_3
and (e) Nitride_1, and (f) the cross-section along the channel at the bottom of the channel
hole.

Oxide_4
Nitride_3
Oxide_3
Nitride_2
(a)
Oxide_2

Si Nitride_1 Si
Oxide_1
Si
(b)
(c)
Figure 2.20 SEG Si at the channel bottom: top-down view in (a) Nitride_3 and
(b) Nitride_1, and (c) cross-section along the channel.

Oxide_4
Oxide_N+1 Nitride_3
Oxide_3
Nitride_N
Nitride_2
(a) Oxide_N (d)
Nitride_N-1 Oxide_2
Oxide_N-1
Nitride_N-2
Nitride_1
Oxide_N-2
Oxide_1
Nitride_N-3
Si
(e)
(b) (c) (f)
Figure 2.21 Wafer after channel dielectric deposition: top-down view (a) in cap oxide and
(b) in nitride_N-2, and (c) cross-section along the channel near the top; (d) top-down view in
nitride_3 and (e) nitride_1, and (f) cross-section at the bottom.
3D-NAND Flash and Its Manufacturing Process 69

top-down view of channel hole in nitride_3 and nitride_1, respectively.

Figure 2.21(f) is the cross-section along the channel near the bottom.
Dielectric layers block the channel at this stage, and thus an etch process is
needed to remove the layers at the bottom to ensure the electrical connection
of the channel and substrate.
After the conformal deposition of channel dielectrics, a vertical etchback
process removes channel dielectrics from the bottom of the channel hole and
from the wafer surface. This process is very similar to the dielectric etchback
process that forms the sidewall spacer, which leaves channel dielectric films on
the sidewall of the channel holes from the middle of oxide_2 and above.
Figure 2.22 shows the cross-sections and top-down view at different layers
after etchback. A layer of polysilicon is deposited after wafer clean; this layer
is the channel of the gate-all-around flash memory cells and the channel of the
upper SG that connects to the bit line. The upper select gate will be formed in
nitride_N, as shown in Fig. 2.23(c). Near the bottom of the channel, the
polysilicon layer is connected to the SEG Si, which is the channel of the lower

Oxide_4

Oxide_N+1 Nitride_3
Oxide_3
Nitride_N
Nitride_2
(a) Oxide_N (d)
Nitride_N-1 Oxide_2
Oxide_N-1
Nitride_N-2 Nitride_1
Oxide_N-2
Oxide_1
Nitride_N-3
Si
(e)
(b) (c) (f)
Figure 2.22 Channel dielectric etch back: (a) top-down view in cap oxide, (b) in nitride_N-2,
and (c) cross-section along the channel near the top; (d) top-down view in nitride_3 and
(e) nitride_1, and (f) cross-section along channel at the bottom.

Oxide_4
Nitride_3
Oxide_N+1
Oxide

Oxide_3
Oxide

Nitride_N Nitride_2
(a) Oxide_N (d)
Nitride_N-1 Oxide_2
Oxide_N-1 Polysilicon
Nitride_N-2 Nitride_1 Si
Si
Oxide_N-2
Oxide_1
Nitride_N-3
Si
(e)
(b) (c) (f)
Figure 2.23 Top-down view (a) in cap oxide, (b) in nitride_N-2, and (c) cross-section along
the channel near the top; (d) top-down view in nitride_3 and (e) nitride_1, and (f) the cross-
section along the channel at the bottom.
70 Chapter 2

SG that connects to the source line (ground), as shown in Fig. 2.23(f). After
polysilicon-channel-layer deposition, the channel holes are filled with silicon
oxide. After oxide and polysilicon CMP (Fig. 2.23), the channel module is
finished.
After polysilicon and oxide deposition, oxide is etched back and into the
channel. The oxide etch back needs to be stopped before it reaches the
nitride_N; otherwise, the upper select gate will not be functional. After oxide
recess, polysilicon is deposited into the channel where the oxide was recessed.
After polysilicon CMP, an oxide layer is deposited to cap the channels and
prepare the next process module. Figure 2.24(a) shows the top-down view of
the polysilicon plug in oxide_N þ 1, and Fig. 2.24(b) is a top-down view of the
channel in nitride_N-2. The cross-section along the channel is shown in
Fig. 2.24(c). Because the polysilicon contact plug formation happens only at
the top of channel, the bottom portion of the channel is not shown in
Fig. 2.24. Figure 2.25 shows the cross-section of channel in the multi-layer

Oxide_N+1

Nitride_N
(a) Oxide_N
Nitride_N-1
Oxide_N-1
Nitride_N-2
Oxide_N-2
Nitride_N-3

(b) (c)
Figure 2.24 (a) Top-down view of a polysilicon plug (b) in nitride_N-2, and (c) cross-section
near the top of the channel.

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

Figure 2.25 Filled-channel strings in the multi-layers in an array area.
3D-NAND Flash and Its Manufacturing Process 71

Table 2.3 3D NAND channel formation process steps.

Channel mask [Fig. 2.18(a)] Etch back channel dielectric layers (Fig. 2.22)
Etch hard mark Wafer clean
Etch multi-layers Deposit polysilicon channel
Remove hard mask and wafer clean Deposit silicon oxide filler (Fig. 2.23)
[Figs. 2.18(b) and 2.19]
SEG Si (Fig. 2.20) Oxide recess
Deposit high-k dielectric Deposit polysilicon
Deposit charge trap nitride Polysilicon CMP
Deposit gate oxide (Fig. 2.21) Post-CMP clean (Fig. 2.24)

stacks in the array area. Figure 2.24(c) shows a detailed drawing of the box in
the upper left of Fig. 2.25. The channel module processes are listed in
Table 2.3.

2.2.4 Isolation module

In this module, isolation trenches are etched into an ONON multi-layer to
allow etchants to selectively remove silicon nitride and thus allow precursors
to reach the channel pillar and deposit the metal gate of the select gates and
flash cells. It also allows a conducting metal, such as tungsten, to fill the gaps
left by the removal of nitride in the array area to form the word line and, in
the staircase area, the word-line contact land areas. After forming the vertical
channels in the multi-layers, a thick, hard mask layer (usually a 1-mm
amorphous carbon layer) is deposited on the wafer surface. The isolation
trench mask, as shown in Fig. 2.26, is applied, and the hard mask is etched.
The main etch process etches through the ONON multi-layers, only stopping
when it reaches the silicon substrate to form the deep (3 mm) and high-
aspect-ratio (30:1) trenches. After the etch process, the hard mask is
removed, and the wafer is cleaned.
Figure 2.27(a) shows the isolation mask overlapping with the channel
mask. Figure 2.27(b) is the cross-section along the solid line in Fig. 2.27(a)
after wafer clean. Figure 2.27(c) is the cross-section along the dashed line
in Fig. 2.27(a). Three locations are featured to illustrate the process steps
for this module: the top portion indicated by the circle in Fig. 2.27(c),
the bottom portion indicated by the rectangular box in Fig. 2.27(b), and the
top portion of the staircase indicated by a rectangular box in Fig. 2.27(b).
Figure 2.28(a) is the top-down view of the channel contact plug in the cap
oxide, Fig. 2.28(b) is the top-down view of a channel cell, and Fig. 2.28(c) is
the cross-section near the top of the multi-layers, which is indicated by a circle
in Fig. 2.27(c). Figure 2.28(d) is the top-down view of the channel in nitride_3;
Fig. 2.28(e) is the top-down view of the lower SG channel, which is SEG Si, in
nitride_1; and Fig. 2.28(f) is the cross-section near the bottom of the multi-
layers, indicated by a rectangular box in Fig. 2.27(c). Figure 2.28(g) is
the cross-section near the top of the staircase, indicated in the rectangular
72 Chapter 2

Array area

Periphery area

(a)

(1) Channel hole (2) Multi-layers (3) WL contacts

(b)
Figure 2.26 (a) An isolation mask in one cell and (b) close-up of the box.

box in Fig. 2.27(b). Figure 2.28(h) is the cross-section of the whole stack
perpendicular to the isolation trench. The oval box in Fig. 2.28(h) is shown in
detail in Fig. 2.28(c), and the rectangular box in Fig. 2.28(h) is shown in detail
in Fig. 2.28(f).
3D-NAND Flash and Its Manufacturing Process 73

(1) Channel hole (2) Multi-layers (3) WL contacts

(a)

(b)

(c)
Figure 2.27 (a) Isolation mask overlapped with the channel mask; (b) cross-section along
the solid line in (a) after trench etch, hard mask removal, and wafer clean; and (c) cross-
section along the dashed line.

After wafer clean, a highly selective etch process is used to remove all
silicon nitride layers from the multi-layers with minimum loss of silicon oxide
and silicon. Etchants reach every nitride layer through the isolation trenches,
and the etch by-products can be removed from these layers through those
74 Chapter 2

(a) (d)

Si Si

Si
(e)
(b) (c) (f)

SiOx Oxide_N+1
SiN Nitride_N
Oxide_N
Nitride_N-1
Oxide_N-1
Nitride_N-2
Oxide_N-2
Nitride_N-3

(g) (h)
Figure 2.28 Top-down view (a) in cap oxide and (b) in nitride_N-2 (b); (c) cross-section
along the dashed line in Fig. 2.27(a); top-down view (d) in nitride_3 and (e) nitride_1;
(f) cross-section along the channel at the bottom; (g) close-up of the box in Fig. 2.27(b); and
(h) cross-section of the whole stack.

trenches. After nitride removal, only oxide layers are left in the array area,
which are supported by the pillar of filled channels. The array area at this
stage looks just like an unfinished skyscraper almost 40 stories tall, with an
array of pillars supporting the empty floors.
The next wafer is cleaned, and a thermal oxidation process is performed,
which forms the gate oxide around the SEG Si pillars in the gap that used to
be nitride_1. In other gaps formed after removal of the nitride layers, the
channel polysilicon is protected by charge trap nitride and high-k dielectric
layers; therefore, there is no poly oxidation of channel polysilicon in these
gaps. Figure 2.29(a) shows the top-down view of the channel contact plugs,
and Fig. 2.29(b) shows the top-down view of the channel in the gap that
used to be nitride_N-2. Figure 2.29(c) is the cross-section near the top of the
multi-layer with the channel pillars and isolation trench. Figure 2.29(d) is the
top-down view of the channel in the gap that used to be nitride_3. In the top-
down view of Fig. 2.29(e), the gate oxide is grown around the SEG Si pillar in
the gap that used to be nitride_1. Figure 2.29(f) is the cross-section near
3D-NAND Flash and Its Manufacturing Process 75

(a) (d)

Si Si

Si
(e)
(b) (c) (f)

SiOx Oxide_N+1
Nitride_N
Oxide_N
Nitride_N-1
Oxide_N-1
Nitride_N-1
Oxide_N-2
Nitride_N-2

(g) (h)
Figure 2.29 Top-down view (a) in cap oxide and (b) in nitride_N-2; (c) cross-section near
the top of the channel; top-down view (d) in nitride_3 and (e) nitride_1; (f) cross-section along
the channel at the bottom; (g) cross-section at the top of the staircase; and (h) cross-section
of the whole stack.

the bottom of the multi-layers. Figure 2.29(g) is the cross-section along the
staircase near the top surface, and the Figure 2.29(h) is the cross-section of
the whole stack perpendicular to the isolation trench. The oval box in
Fig. 2.29(h) is shown in detail in Fig. 2.29(c), and the rectangular box in
Fig. 2.29(h) is shown in detail in Fig. 2.29(f).
After lower SG oxidation, a thin and conformal TiN film is deposited
into the gaps, around the channel pillar, and covering the sidewall of the
isolation trench. The atomic layer deposition (ALD) process, which deposits
the film one atomic layer per circle and has excellent conformality and
coverage, can be used for this application. This TiN layer will be used as the
gate electrodes of the select gates and 3D-NAND cells. After TiN
deposition, the W layer is deposited to fill the gaps and cover the sidewall
of the isolation trenches; this layer will be used as the WL and WL pads in
the staircase to allow WLC plugs to land on them. Figures 2.30(a) and
2.30(b) illustrate top-down views of the channel in cap oxide and in
nitride_N-2, respectively; and Fig. 2.30(c) shows the cross-section near the
76 Chapter 2

(a) (d)

Si Si

Si
(e)
(b) (c) (f)

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3

(g) (h)
Figure 2.30 Top-down view (a) in cap oxide and (b) in nitride_N-2; (c) cross-section near
the top of the channel; top-down view in (d) nitride_3 and (e) nitride_1; (f) cross-section along
the channel at the bottom; (g) cross-section at the top of staircase; and (h) cross-section
of the whole stack.

top of the multi-layer. Figures 2.30(d) and 2.30(e) show top-down views of
the channel in nitride_3 and nitride_1, respectively; and Fig. 2.30(f) is the
cross-section at the bottom of the multi-layer. Figure 2.30(g) is the cross-
section at the top of the staircase. Figure 2.30(h) is the cross-section of
the whole stack appendicular to the isolation trench. The oval box in
Figure 2.30(h) is shown in detail in Figure 2.30(c) and the rectangular box in
Figure 2.30(h) is shown in detail in Figure 2.30(f).
It is important to control the W film thickness during W deposition. If it is
too thin, it will leave voids in the gap between layers. If it is too thick, it could
block the next metal etch process, leave W residue on the sidewall of the
isolation trench, and cause a short between the conducting layers.
In the next step, chemicals that highly select to W and TiN are used to
remove W and TiN on the sidewall of the isolation trenches, with minimum
loss of silicon oxide, as shown in Fig. 2.31. At this stage, the devices are
formed. The channel contact plugs are formed with polysilicon, surrounded
by cap oxide, as shown in Figure 2.31(a). The flash memory cell has a
3D-NAND Flash and Its Manufacturing Process 77

(a) (d)

Si Si

(e) Si

(b) (c) (f)

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3

(g) (h)
Figure 2.31 Top-down view (a) in cap oxide and (b) in nitride_N-2; (c) cross-section near
the top of the channel; top-down view (d) in nitride_3 and (e) nitride_1; (f) cross-section along
the channel at the bottom; (g) cross-section at the top of staircase; and (h) cross-section
of the whole stack.

polysilicon channel with deposited silicon oxide as the gate dielectric,

deposited silicon nitride as the charge trap layer, high-k dielectric as the
inter-gate dielectric, and TiN as the control gate surrounded by W, as shown
in Figs. 2.31(b)–(d). The lower select gate has a SEG Si channel, thermally
grown SiO2 as gate oxide, and a TiN metal gate, as shown in Figs. 2.31(e)–(f).
The upper select gate is the same as the flash memory cell: it operates at a
different voltage and utilizes the deposited oxide, nitride, and high-k dielectric
as the gate dielectric, and TiN as the gate electrode. This is one of advantages
of using a charge-trap SiN layer instead of a polysilicon floating gate. It is
very important to completely remove the W and TiN from the sidewall of the
isolation trenches; otherwise, the metals in different layers, i.e., the control
gates and WL, will short to the other layer. Figure 2.31(g) is the cross-section
at the top of the staircase. Figure 2.31(h) is the cross-section of the whole stack
appendicular to the isolation trench. The oval box in Fig. 2.31(h) is shown in
detail in Fig. 2.31(c), and the rectangular box in Fig. 2.31(h) is shown in detail
in Fig. 2.31(f).
78 Chapter 2

After wafer clean, an oxide layer is deposited into the isolation trenches to
seal the metal gates. A vertical etch process follows to remove the oxide layer
from the bottom of the isolation trenches and the wafer surface, as shown in
Fig. 2.32. This will allow the W wall in the isolation trench to contact the
ground and silicon substrate, and provide better electrical isolation between
neighboring memory arrays. Figure 2.32(g) is the cross-section at the top of
the staircase. Figure 2.32(h) is the cross-section of the whole stack
appendicular to the isolation trench. The oval box in Fig. 2.30(h) is shown
in detail in Fig. 2.32(c), and the rectangular box in Fig. 2.32(h) is shown in
detail in Fig. 2.32(f).
After wafer clean, a TiN liner is deposited into the trenches and covering
the wafer surface. A CVD W layer fills the trenches, and a WCMP process
removes W and TiN from the wafer surface and forms the W isolation walls.
An oxide layer is deposited on the wafer surface to cap the W isolation walls
(Fig. 2.33). The process steps are summarized in Table 2.4.

(a)
(d)

Si Si

(e) Si

(b) (c) (f)

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3

(g) (h)
Figure 2.32 Top-down view of a channel (a) in cap oxide and (b) in nitride_N-2; (c) cross-
section near the top of the channel; top-down view (d) in nitride_3 and (e) in nitride_1;
(f) cross-section along the channel at the bottom; (g) cross-section at the top of the
staircase; and (h) cross-section of the whole stack.
3D-NAND Flash and Its Manufacturing Process 79

(a) (d)

Si Si

Si
(e)
(b) (c) (f)

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3

(g) (h)
Figure 2.33 Top-down view (a) in cap oxide and (b) in nitride_N-2; (c) cross-section near
the top of the channel; top-down view (d) in nitride_3 and (e) nitride_1; (f) cross-section along
the channel at the bottom; (g) cross-section at the top of the staircase; and (h) cross-section
of the whole stack.

2.2.5 Contact and interconnection modules

At this point, the front-end processes are finished, and all devices in both the
peripheral and array areas are built. This section discusses the BEOL
processes—contact and interconnect—of 3D-NAND flash. First is the contact
module, in which contact holes are etched in the staircase area between the cell
and periphery; they land on the W staircases and silicon substrate, creating the
connection between the word lines in different layers and the source line in
substrate.
After hard mask deposition and photoresist coating, the contact mask is
applied [Fig. 2.34(a)]. At first the hard mask is etched and then used to etch
contact holes in oxide with etch chemistries that have high selectivity to
tungsten [so that the etch process stops whenever the contact holes reaches the
tungsten surface in the shallower holes while continuing in the deeper holes, as
80 Chapter 2

Table 2.4 Process steps for the isolation module of 3D-NAND.

Wafer clean Trench W removal
Isolation mask (Fig. 2.26) Trench TiN removal (Fig. 2.32)
Etch hard mask Wafer clean
Etch trenches in ONON multi-layers and stop on silicon Oxide deposition
Remove hard mask [Figs. 2.27(c) and 2.28] Oxide etch back (Fig. 2.32)
Remove nitride layers (Fig. 2.29) TiN deposition
Wafer clean W deposition
Oxidation of SEG (Fig. 2.30) W CMP
TiN deposition Oxide cap deposition (Fig. 2.33)
W deposition (Fig. 2.31)

shown in Fig. 2.34(b)]. Chapter 9 of Xiao11 discusses this etch chemistry used
for contact etches with different hole depths.
Because the depth of the contact holes vary between different layers, it
would be very difficult to etch all of them with almost 40 different depths in
one etch process; multiple masks would be necessary. Depending on the
process, 10 different contact-hole depths can usually be etched in one etch
process, and thus four masks and four etch processes are needed to etch all of
the contact holes in the staircase and periphery of a 32-cell-stack 3D-NAND
flash device. Figure 2.34(c) shows the cross-section after staircase contact etch
and hard-mask strip and clean.
When all of the contact holes have been etched, the wafer is cleaned to
remove the polymer residue at the bottom of the contact holes. After sput-
tering etch removes the native oxide, barrier TiN is deposited [Fig. 2.35(a)],
followed by W deposition [Fig. 2.35(b)]. A WCMP process removes W and
TiN from the surface [Fig. 2.35(c)], which completes the contact module.
Figures 2.36(a)–(c) illustrate the cross-section of TiN deposition, W
deposition and WCMP in cell, staircase and periphery areas, respectively.
Figures 2.35(a)–(c) are close-up versions of Figs. 2.36(a)–(c) at the top of the
staircases, respectively.
The next module is metal 1, which is a dual-damascene process that forms
the local interconnect. It includes two masks, via 1 (V1) and metal 1 (M1).
A layer of oxide is deposited to cap the contact W plugs. In the first via
process, a V1 mask, which is like a channel mask plus a contact mask
(Fig. 2.37), is applied first. Via holes are then etched to land on channel
polysilicon plugs and contact tungsten plugs (Fig. 2.38).
Metal 1 (M1) forms the local interconnect in the array area and peripheral
area. The pattern in the staircase area is almost the same as V1. Figure 2.39(a)
shows the M1 mask, and Fig. 2.39(b) shows the M1 overlaps with the channel,
isolation, contact, and V1.
After applying the M1 mask, an oxide etch process is performed to form
the trenches of the local interconnect. After photoresist strip and clean, a TiN
liner and W are deposited to fill the M1 trenches and V1 holes. WCMP
3D-NAND Flash and Its Manufacturing Process 81

(a)

Hard Mask

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3
(b)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(c)
Figure 2.34 (a) Staircase contact mask, (b) close-up of the top layer, and (c) cross-section
of the cell and periphery contacts.
82 Chapter 2

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3
(a)

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3
(b)

SiOx Oxide_N+1
W_N
Oxide_N
W_N-1
Oxide_N-1
W_N-2
Oxide_N-2
W_N-3
(c)
Figure 2.35 Close-up of the contact processes near the top of the staircase: (a) after TiN
deposition, (b) after W deposition, and (c) after WCMP.
3D-NAND Flash and Its Manufacturing Process 83

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

(a)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

(b)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(c)
Figure 2.36 Contact process steps: (a) after TiN deposition, (b) after W deposition, and
(c) after WCMP.

removes the W and TiN from the wafer surface and forms the W wires and
plugs that connect the channel plugs and contact plugs, as shown in Fig. 2.40.
Metal 2 forms the bit line in the array area, source line and word line wires
in the staircase area, and interconnection in the peripheral area. Because each
WL between the two isolation walls has four rows of channel holes, the bit
lines, which are perpendicular to the WL, must be split into a pitch density
four times higher than the channel hole pitches to ensure the registration of a
single cell in the string with one bit signal and one word signal. After wafer
clean and ILD deposition, there is a via 2 (V2) and metal 2 (M2) process (the
via 2 mask is illustrated in Fig. 2.41).
84 Chapter 2

(1) Channel hole (2) Multi-layers (3) WL contacts

Figure 2.37 V1 mask.

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

Figure 2.38 V1 etch in the cell, staircase, and peripheral areas.

After V2 etch, photoresist strip, and clean [as shown in Fig. 2.42(a)], a
TiN liner is deposited, followed by W deposition [shown in Fig. 2.42(b)],
and then WCMP removes the W and TiN on the surface and forms the V2
W-plugs [Fig. 2.42(c)].
After WCMP, another ILD is deposited, a M2 mask is applied, and metal
trenches are etched. Figure 2.43 illustrates the M2 mask, and Fig. 2.44(a)
shows the M2 etch. After photoresist strip and clean, a TaN barrier layer and
Cu seed layer are deposited into the M2 trenches; after copper plating and
anneal, a metal CMP process removes the Cu and TaN from the wafer surface
and forms the BL in the array area and WL and SL wires in the staircase area
[Fig. 2.44(b)].
Metal 3 (M3) is the last metal layer; it forms interconnect and bond pads.
It is usually formed by a stack of metals: a Ti barrier layer at the bottom, an
Al-Cu alloy bulk layer, and TiN ARC on top. Via 3 (V3) is a tungsten plug
that connects to M2.
3D-NAND Flash and Its Manufacturing Process 85

(1) Channel hole (2) Multi-layers (3) WL contacts

(a)

(b)
Figure 2.39 (a) M1 mask and (b) M1 overlaps (white outline) with the channel, isolation,
contact, and V1 masks.

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

Figure 2.40 V1 etch in the cell, staircase, and peripheral areas.
86 Chapter 2

Figure 2.41 V2 mask.

The process starts with dielectric deposition, followed by V3 mask.

A dielectric etch process forms via holes that stop on the M2 surface. After
photoresist strip and clean, as shown in Fig. 2.45(a), a TiN barrier liner is
deposited, followed by WCVD that fills via holes and covers the whole wafer
surface. A WCMP process removes the tungsten and TiN from the surface
and forms W-plugs of V3 [Fig. 2.45(b)].
After wafer clean, a TiN/Al-Cu/TiN metal stack is deposited on the
wafer, usually with a physical vapor deposition (PVD) process, as shown in
Fig. 2.46(a). After applying the M3 mask, a metal etch process is performed,
and photoresist is usually stripped in situ to avoid metal corrosion from
moisture absorption and reaction. Figure 2.46(b) shows the cross-section after
M3 etch, photoresist strip, and clean that forms the M3 wires.
The last process of 3D-NAND flash manufacturing in an IC fab is the
passivation and formation of bond pads. First, passivation dielectrics—
usually silicon oxide layers followed by silicon nitride—are deposited with
CVD processes. The bond pad mask is applied, and a dielectric etch process
removes the nitride and oxide on top of the metal bond pads, which finishes
the wafer process of 3D-NAND flash memory chips. Figure 2.47 illustrates
the cross-section of finished 3D-NAND flash with cell string channels in the
array area, WL/SL contacts plugs that land on the staircase, and peripheral
CMOS logic devices with W-plugs and W local interconnect. While all three
via layers are formed by TiN/W, they are all different: metal 1 is W/TiN,
metal 2 is Cu/TaN, and metal 3 is TiN/Al-Cu/TiN. Because the bond pads are
not located near the cell and peripheral areas, they are not shown in the figure.
The wafer is now ready for test and packaging. Table 2.5 lists the process steps
for the contact and interconnects.
3D-NAND Flash and Its Manufacturing Process 87

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

(a)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

(b)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(c)
Figure 2.42 V2 process steps in the cell, staircase, and peripheral areas: (a) etch, (b) TiN
and W deposition, and (c) WCMP.

2.3 3D-NAND Summary and Discussion

This chapter described the 3D-NAND process in detail. Figure 2.48 shows a
3D illustration of the 3D-NAND after channel, isolation, and contact-plug
formation.13
The 3D-NAND device described in previous sections is very similar to
that illustrated in Fig. 2.48. The cutoff shows cross-sections both parallel to
and perpendicular to the isolation trenches. It can help us visualize the
staircase, channels, isolation trenches, TiN/W layers that replaced the SiN
layer in the multi-layer stack, and W plugs that connect to the WL (W layers)
88 Chapter 2

Figure 2.43 M2 mask.

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

(a)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(b)
Figure 2.44 M2 process steps in the cell, staircase, and peripheral areas: (a) etch and
(b) CuCMP.

at the staircase. Of course, there are some differences, such as the number of
cells in a channel string; Fig. 2.48 shows 17, while the one described earlier has
32. Each WL strip has four rows of channels strings, whereas Fig. 2.48 shows
only one row. The isolation trenches in the figure are filled only with oxide,
3D-NAND Flash and Its Manufacturing Process 89

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area (a) Periphery area

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(b)
Figure 2.45 V3 process steps in the cell, staircase, and peripheral areas: (a) etch and
(b) WCMP.

those in the previous example also have grounded tungsten sheets between
oxide layers for better electrical isolation of neighboring word lines.
There are several 3D-NAND approaches. Besides the terabit cell array
transistor (TCAT) described previously, two other approaches include pipe-
shaped bit cost scalable (P-BiCS) 3D-NAND (Fig. 2.49) and vertical gate
(VG) NAND (Fig. 2.50).
In Figure 2.49(a), PC stands for pipe connection; it connects two vertical
channels to form a string twice as long. One of benefits of using a PC is that
both the source select gate and the bit select gate are on the top of the multi-
layer, making it relatively easier to form them. Of course, the pipe connection
is not easy to form, and the PC formation process is very hard to monitor.
In Figure 2.50, MLx stands for metal layer x, where x ranges from 1 to 4.
CSL stands for common source line, and GSL stands for ground select gate.
It is basically planar NAND flash stacked in N levels, with a unit cell size of
4F2/N.14
Although the majority of 3D-NAND manufacturers use flash cells with a
charge-trap layer, some still use floating-gate (FG) memory cells. A FG 3D-
NAND multi-layer consists of oxide/polysilicon/oxide/polysilicon (OPOP)
90 Chapter 2

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

(a)

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area (b) Periphery area

Figure 2.46 M3 process steps in the cell, staircase, and peripheral areas: (a) metal stack
PVD and (b) metal etch, PR strip, and clean.

stacks. After channel hole etch and the formation and protection of the Si
SEG in the bottom SG channel, the polysilicon layers in the OPOP stack are
partially recessed, and an inter-gate dielectric (IGD) layer is conformally
deposited with an ALD process. Polysilicon is deposited into the channel hole,
filling the rest pockets formed after partial polysilicon recess. An isolation etch
process removes the polysilicon on the sidewall of the channel holes and forms
the ring-shaped polysilicon FGs. After wafer clean, a gate oxide layer and a
channel polysilicon layer are deposited, followed by a vertical etch process to
remove the polysilicon, gate oxide, and protection layer at the top of the SEG
Si. CVD oxide is used to fill the channel hole. The top select gate (BL select
gate) can be formed after oxide CMP and poly, oxide, poly, and IGD wet
etch. After cap-oxide layer deposition, isolation trench patterns are etched,
and self-aligned silicide can be formed in the trench on the side wall of the
polysilicon of the OPOP stack to reduce the resistance of the word line. After
the unreacted metal is removed, the trenches are filled, and the FEOL process
of FG 3D-NAND is finished.
3D-NAND Flash and Its Manufacturing Process 91

PMD

STI n+ n+ SiOx p+ p+
P-Well N-Well

P-Wafer

Array area Periphery area

Figure 2.47 Cross-section of a finished 3D-NAND flash memory.

One of the advantages of FG 3D-NAND is that it is ready to form a

multi-level cell (MLC) based on mature MLC techniques developed in planar
NAND technology. All planar NAND products are FG devices. In contrast,
NAND flash with a charge trap layer is usually a single-level cell (SLC). A
single-level cell can only have two charging states, 0 and 1. A two-level cell has
four charging states: 00, 01, 10, and 11; and a three-level cell has eight

Table 2.5 Process steps of the contact and interconnect module of 3D-NAND.
Wafer clean TiN deposition, WCVD and WCMP (Fig. 2.40)
First contact mask [Fig. 2.34(a)] Oxide CVD
Etch hard mask V2 mask (Fig. 2.41)
Etch shallower staircase contacts Etch oxide, PR strip, and clean [Fig. 2.42(a)]
Strip PR and wafer clean [Fig. 2.34(b)] TiN deposition, WCVD [Fig. 2.42(b)], and
WCMP [Fig. 2.42(c)]
Apply the second contact mask and etch staircase Oxide CVD
contacts
Strip PR and wafer clean M2 Mask (Fig. 2.43)
Repeating staircase contact litho, etch and clean. Etch oxide, PR strip, and clean [Fig. 2.44(a)]
Remove hard mask and wafer clean [Fig. 2.34(c)] TaN deposition, Cu seed deposition, Cu plating,
Cu anneal, and CuCMP [Fig. 2.44(b)]
TiN liner deposition [Figs. 2.35(a) and 2.36(a)] Oxide CVD
W deposition [Figs. 2.35(b) and 2.36(b)] V3 mask
WCMP [Figs. 2.35(c) and 2.36(c)] Etch oxide, PR strip, and clean [Fig. 2.45(a)]
Wafer clean TiN dep, WCVD, and WCMP [Fig. 2.45(b)]
Oxide CVD PVD TiN, PVD Al-Cu, and PVD TiN
[Fig. 2.46(a)]
V1 mask [Fig. 2.37] M3 mask
V1 etch, PR strip, and clean [Fig. 2.38] Etch TiN/W/TiN metal stack, PR strip, and clean
[Fig. 2.46(b)]
Oxide CVD Oxide CVD and nitride CVD
M1 mask [Fig. 2.39] Bond pad mask
M1 oxide trench etch, PR strip and clean Etch nitride/oxide, PR strip, and clean (Fig. 2.47)
92 Chapter 2

Figure 2.48 3D view of 3D-NAND after channel, isolation, and contact-plug formation.
Image reprinted from Ref. D with permission from Coventor.

Figure 2.49 P-BiCS 3D-NAND: (a) circuit of a string and (b) 3D view. Image reprinted from
Ref. E with permission from IEEE.
3D-NAND Flash and Its Manufacturing Process 93

Figure 2.50 3D view of VG NAND. Image reprinted from Ref. F with permission from IEEE.

charging states and can thus store 8 bits of information. For the same cell size,
a three-level cell can store four times the information of a single-level-cell
NAND flash; therefore, a MLC NAND chip is more cost effective (higher
bit/$) than a SLC NAND chip. Of course, there are always trade-offs. MLC
NAND flash is usually slower, consumes more power, and has lower write-
erase endurance than SLC NAND flash.
Figure 2.51(a) is the top-down view of a 3D-NAND cell with a polysilicon
floating gate made from an OPOP stack. Figure 2.51(b) is the side-view
Inter-gate
dielectric Polysilicon Gate oxide
floating gate
Poly Si CG

Poly Si FG

Poly Si channel
Polysilicon channel

SiOx SiOx

(a) (b)
Figure 2.51 (a) Top-down view of a 3D-NAND cell with polysilicon FG and (b) its cross-
section side view.
94 Chapter 2

Inter-gate SiN charge

Gate oxide
dielectric trap layer
TiN

Poly Si

Poly
SiOx Si
SiOx

W
W

(a) (b)
Figure 2.52 (a) Top-down view of a 3D-NAND cell with a SiN charge-trap layer and (b) its
cross-section side view.

cross-section of the 3D-NAND cell with a polysilicon floating gate. In

comparison, Figure 2.52(a) shows the top-down cross-section of a 3D-NAND
cell with a nitride charge-trap layer that consists of an ONON stack, and
Fig. 2.52(b) illustrates its cross-section from the side.
By creating the flash memory cell vertically, 3D-NAND can achieve a
high bit density while relaxing the photolithography resolution requirements.
It shifts the scaling difficulties from patterning to etch HAR structures and
deposits a conformal thin film to cover those structures. By increasing the
number of stacks, 3D-NAND flash can be scaled to the next generation
without improving the photolithography resolution. 3D-NAND flash is
becoming mainstream. This trend is unstoppable because alternative
lithography technology that might keep scaling planar NAND flash at a
cost lower than quadruple patterning of 193-nm immersion lithography, such
as nano-imprint lithography or low-cost EVU lithography, cannot be
implemented into HVM in time.

2.4 Review Questions

1. How many device(s) are in a flash memory cell?

2. What are the differences between NAND flash and NOR flash?
3. What is the minimum unit cell size of a 20-nm planar NAND flash?
4. What is the purpose of the SiN layer in Fig. 2.52?
5. Which one of the following processes does NOT etch a HAR pattern?
(a) Staircase etch
(b) Channel hole etch
3D-NAND Flash and Its Manufacturing Process 95

(c) Isolation trench etch

(d) Staircase contact etch
6. How many pairs of ONON must be deposited to form a 64-cell
3D-NAND?
7. Can one photomask be used to form 64-cell staircase landing steps?
8. What is the equivalent 4F2 planar NAND flash technology node of a 6F2
64-stack 74-nm half-pitch 3D-NAND device?
9. Describe the difference between ONON and OPOP stacks.
10. List at least two challenges facing 3D-NAND flash memory-chip
manufacturing.
11. What is the biggest advantage of 3D-NAND flash compared to planar
NAND flash?
Chapter 3
High-k, Metal-Gate FinFET
CMOS Manufacturing Process
After reading this chapter, you should be able to
• List at least two advantages of FinFET technology compared to planar
MOSFET technology;
• Explain the difference between SOI FinFET and bulk FinFETs process
steps;
• Describe the differences between the gate formation of FinFETs and
planar MOSFETs;
• Explain why a 14-nm-node fin needs pitch doubling and a 10-nm-node
fin needs pitch quadrupling;
• Give the reason W is used as the FinFET HKMG metal filler, whereas
planar HKMG MOSFET uses an Al filler; and
• Predict future FinFET scaling trends.

3.1 Introduction
In the so-called “good old days,” the IC technology-node scaling of each
generation always brought both higher device density and better device
performance. When CMOS IC developed from the 90-nm to 65-nm node, the
scaling did not improve the device performance: it only increased the device
density. The main reason for this change is the thickness of the gate oxide can
no longer be scaled down due to the leakage caused by the tunneling effect.
One of most important MOSFET device performance parameters, the
drive current ID, is proportional to m(k/tox)(W/L), or

I D ∝ mðk∕tox ÞðW ∕LÞ, (1)

where m is the carrier mobility of the channel material (for NMOS, it is

electron mobility, and for PMOS, it is hole mobility), k is the dielectric
constant of the gate dielectric, and tox is the thickness of the gate oxide. For a

97
98 Chapter 3

Gate
L W
Source Drain
Si

n+
k. t ox Depletion
Si Si region

(a) (b)
Figure 3.1 Planar MOSFET (a) in 3D and (b) 2D cross-section along the channel.

traditional gate dielectric (SiO2), kSiO2 ¼ 3.9. W is the channel width, and L is
the channel length, as shown in Fig. 3.1.
If only the feature size of a planar MOSFET scales down, then W and L
reduce at the same rate, and the drive current will not improve unless tox also
scales down. The power supply voltage and threshold voltage are also scaled
down occasionally with the gate oxide thickness to reduce leakage and power
consumption. When tox became thin and approached the leakage and
breakdown limit, scientists and engineers had to find other ways to improve
ID. One such technique uses a stress liner and selective epitaxial growth (SEG)
silicon germanium (SiGe) to create channel strain, which improves carrier
mobility m and drive current. Another technique involves doping the gate
silicon oxide with nitrogen to form SiON, which can slightly increase the k
value (between 3.9 for SiO2 and 7.5 for Si3N4, depending on the nitrogen
concentration). By replacing SiON with a high-k dielectric, such as
HfSixOyNz, the k value of the gate dielectric increased significantly. The gate
dielectric could be formed with a thinner equivalent oxide thickness (EOT),
which equals (3.9/k) tox, and further improves the drive current. When people
talk about high-k or low-k dielectric, they are comparing the k value of SiO2,
which is 3.9.
Early MOSFETs used a metal gate (usually Al), but it was replaced by
polysilicon after ion implantation and self-aligned S/D formation processes
were introduced in the mid-1970s. Because polysilicon is a semiconductor, it
always forms a depletion layer at the polysilicon and gate oxide interface
when an external electric field is applied, which can affect channel formation,
especially when the gate oxide becomes very thin. Reintroducing a metal gate
solved the polysilicon depletion issue. Metal is a conductor, and it does not
suffer from carrier depletion.
A high-k gate dielectric and metal gate were introduced in 45-nm
technology, which helped to reduce the EOT and further improve device
performance. It was a great achievement because even changing the gate
High-k, Metal-Gate FinFET CMOS Manufacturing Process 99

W
W=2H+CD

(a) (b)
Figure 3.2 (a) Planar MOSFET and (b) FinFET.

dielectric alone presented a significant challenge due to the mismatch between

the silicon and the high-k dielectric interface. The metal gate presented
another set of challenges: NMOS and PMOS need different work-function
metals to control their threshold voltages and the interface between those
metals and the high-k dielectric. There are two ways to form a HKMG
MOSFET, referred to as “gate first” and “gate last.” The gate-first approach
deposits the high-k dielectric, metal gate, and polysilicon layers first, and then
gate patterning and etch form the HKMG devices. This method has only been
used in the 32-nm / 28-nm technology node by a few IC manufacturers.
Almost all IC manufacturers working with 22-nm / 20-nm nodes and beyond
use the gate-last approach.
The next major technology development was the migration to 3D
FinFETs. Figure 3.2(a) shows a planar MOSFET, and Fig. 3.2(b) shows a
FinFET. The figures show that a FinFET could achieve the same channel
width with a smaller silicon surface area. By increasing the fin heights, the
channel width can be further increased, and therefore it can further improve
device performance without scaling the device feature size. Of course, there is
a limit to fin-height scaling. If the fin is too tall and the aspect ratio becomes
too high, it could be very difficult to etch and clean the fins without causing
them to collapse, and it could be very difficult to deposit void-free dielectric
film to fill STI between the fins.

3.2 FinFET Basics

If two MOSFETs like the one shown in Fig. 3.1 were fused together, back to
back (as shown in Fig. 3.3), the result can provide two conducting channels in
the on-state MOSFET and double the drive current without scaling the
feature size. However, the off-state leakage could also be doubled, which
means a shorter standby time if this kind of IC chip is used in a mobile device.
100 Chapter 3

Gate

Source Drain

n+
Depletion
Si region

Source Drain

Gate
Figure 3.3 Double-gate planar MOSFET.

Gate

Source Drain

n+

Si

Source Drain

Gate
Depletion region
Figure 3.4 Double-gate FD planar MOSFET.

A fully depleted (FD) double-gate MOSFET can be obtained by making

the silicon thinner than the depletion depth of the double-gate MOSFET, as
shown in Fig. 2.4(b). The on-state device still has two conducting channels,
like the partially depleted double device shown in Fig. 3.3. However, its off-
state leakage can be significantly lowered because the channel is fully
depleted, with very few carriers to conduct electrical current.
It is possible to make a double-sided FD MOSFET with a silicon-on-
insulator (SOI) wafer; however, the processes are complicated, the cost could
be high, and the bottom gate can have interference from the substrate.
Figure 3.5(a) illustrates a SOI double-sided FD MOSFET with the STI oxide
and the buried oxide removed to expose the active area, bottom gate, and
silicon substrate.
Figure 3.5(b) illustrates a part of the double-gate FD planar MOSFET
shown in Fig. 3.5(a), and Fig. 3.5(c) shows the device in Fig. 3.5(b) turned
vertically and rotated 90 deg. The device in Fig. 3.5(c) is a tri-gate FinFET, a
MOSFET with a fin-shaped active region and a channel surrounded on three
sides by the gate.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 101

Figure 3.5 (a) Double-gate FD planar MOSFET made from SOI substrate, comprising
(b)–(c) a double-gate FD planar MOSFET and a FinFET.

3.3 FinFET Process

Early versions of FinFETs were made with a SOI wafer [Fig. 3.6(a)]. The fin
height is mainly determined by the thickness of the silicon on top of the buried
oxide. At first, the silicon fin is etched with a process similar to the normal STI
silicon etch process, using buried oxide as an etch-stop layer [Fig. 3.6(b)]; after
wafer clean, the gate oxide is formed on the fin surface. Polysilicon is then
deposited and planarized [Fig. 3.6(c)]. A polysilicon etch forms the gate
electrode and local gate interconnect [Fig. 3.6(d)]. After that, ion implantation
or SEG followed by rapid thermal anneal forms the S/D junction and finishes
the FinFET device formation [Fig. 3.6(e)]. The SOI FinFET process steps are
listed in Table 3.1.

Si fin Si fin

Si
Si ly
O2 iO 2 Po
Si S O2
Si
S i Si S i

(a) (b) (c)

Si fin
Si fin

O2 O2
Si Si
Si Si

(d) (e)
Figure 3.6 3D view of SOI FinFET formation: (a) SOI substrate, (b) fin etch, (c) gate
oxidation, polysilicon deposition, and CMP, (d) polysilicon etch, and (e) fin dope.
102 Chapter 3

Table 3.1 Process steps of an n-channel FinFET on a p-type SOI wafer.

Wafer clean [Fig. 3.6(a)] Polysilicon deposition
Pad oxidation and nitride deposition Polysilicon CMP [Fig. 3.6(c)]
Fin mask Gate mask
Etch nitride/oxide Polysilicon etch
Strip PR and wafer clean Strip PR and wafer clean [Fig. 3.6(d)]
Etch silicon, stop on buried oxide Ion implantation n-type S/D
Nitride/pad oxide strip and wafer clean [Fig. 3.6(b)] Rapid thermal anneal [Fig. 3.6(e)]
Gate oxidation

A manufacturing process for FinFET devices with a bulk silicon wafer

was developed later. It started with silicon fin etch, which is similar to the STI
process, with a much narrower active area (AA) [Fig. 3.7(a)]. After wafer
clean and oxidation, an oxide layer is deposited and planarized [Fig. 3.7(b)].
The oxide is then recessed to expose the silicon fins, as shown in Fig. 3.7(c).
After wafer clean and gate oxidation, polysilicon is deposited, followed by
CMP [Fig. 3.7(d)]. Polysilicon etch forms the gate electrode, as shown in
Fig. 3.7(e), and self-aligned S/D dope and RTA finish the bulk silicon FinFET
formation, as shown in Fig. 3.7(f). The bulk wafer FinFET process steps are
listed in Table 3.2.
The FinFET process is similar to the planar MOSFET process, and
there are several major challenges. One such challenge is fin formation, which
includes fin patterning, fin etching, and STI oxide recess. In a planar

Figure 3.7 3D view of bulk silicon FinFET formation: (a) fin etch, (b) STI oxide deposition
and CMP, (c) STI oxide recess, (d) gate oxidation, (d) polysilicon deposition and CMP,
(e) polysilicon etch, and (f) fin dope.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 103

Table 3.2 Process steps of an n-channel FinFET on a p-type bulk wafer.

Wafer clean Strip nitride and pad oxide [Fig. 3.7(b)]
Pad oxidation and nitride deposition Gate oxidation
Fin mask Polysilicon deposition
Etch nitride/oxide Polysilicon CMP [Fig. 3.7(c)]
Strip PR and wafer clean Gate mask
Etch silicon Polysilicon etch
Nitride and pad-oxide strip and wafer clean [Fig. 3.7(a)] Strip PR and wafer clean [Fig. 3.7(d)]
Oxide deposition Ion implantation n-type S/D
Oxide CMP and recess RTA [Fig. 3.7(e)]

MOSFET device, the gate has the smallest pattern pitch; in a FinFET device,
the fin has the smallest pattern pitch. The fin pitch for an Intel 14-nm FinFET
is 42 nm, whereas the gate pitch is 70 nm. Self-aligned double patterning
(SADP) is needed to pattern both layers. Self-aligned quadruple patterning
(SAQP) with multiple cut masks are expected to form the fin patterns of
10-nm and 7-nm technology nodes. After hard-mask fin patterning, a silicon
fin etch process is also very challenging because the gaps between the fins are
deep and narrow, with a high aspect ratio. Oxide recess is also very
challenging after STI oxide deposition and CMP because the STI oxide recess
must stop at the right depth without an etch-stop layer. The depth of oxide
recess determines the fin height of the FinFET device, which in turn affects the
device channel width, W ¼ 2H þ CDfin. Another big challenge is polysilicon
etch, which determines the channel length. For planar MOSFET device,
polysilicon layer is deposited on a relatively flat surface, and the etch process
can use gate oxide as an endpoint. For FinFETs, polysilicon has a big step,
determined by the fin height. When the etch reaches the top of the fin, the
polysilicon below the fin still needs to be completely removed with an almost
straight profile, shown in Fig. 3.7(e). If the gate oxides on top of the fin cracks
during polysilicon etch, it will cause S/D silicon loss, or fin loss. If the etch is
incomplete, it will leave a polysilicon stringer at the bottom corner of the fin,
and causes an electrical short between neighboring gates, which kills the
devices.
A comparison of Figs. 3.6(e) and 3.7(f) shows that a FinFET built on a
SOI substrate and one built on a bulk silicon substrate are very similar. The
main difference is that the fin of a SOI FinFET is completely isolated from
silicon substrate, while the fin of a bulk silicon FinFET has a channel that
connects to substrate, thus needing some doping to form isolation junctions to
ensure good electrical isolation between the fin and substrate.
For CMOS logic devices with a 28-nm technology node and beyond, a
high-k metal gate (HKMG) is needed to meet the required performance. A
few more process steps are necessary to make the last HKMG FinFET. First,
ILD1 oxide is deposited, and then CMP is performed to planarize the oxide
surface [Fig. 3.8(a)]. Oxide CMP continues until it reaches the polysilicon
gate, as shown in Fig. 3.8(b). It is very important to completely remove all of
104 Chapter 3

Figure 3.8 3D view of bulk silicon FinFET HKMG formation: (a) ILD deposition, (b) ILD
oxide CMP, (c) polysilicon removal, (d) HKMG bulk metal deposition, and (e) metal CMP.

the oxide on top of the polysilicon gate, otherwise the remnant could affect the
next process step: polysilicon removal. Dummy polysilicon removal, as shown
in Fig. 3.8(c), is a critical step because all of the polysilicon must be removed
from inside of the trench. Polysilicon residue here could cause device failure.
Furthermore, when polysilicon is removed from the trench, the stress
variation could crack the gate oxide liner near the trench wall, which could
lead to fin loss underneath the ILD.
After dummy gate oxide removal and wafer clean, a thin layer of silicon
dioxide is grown or deposited with an ALD process. Hafnium-oxide-based
high-k dielectric is deposited with the ALD process, followed by work-
function metal deposition. For a PMOS, ALD TiN is commonly used as the
work-function metal; for NMOS, titanium aluminum nitride (TiAlN) is
typical. After thin layers of HKMG are deposited, metal filler layers (usually
an ALD TiN liner and CVD bulk W) are deposited to fill the narrow trench
[Fig. 3.8(d)]. Metal gate CMP removes the metal layers and high-k dielectric
from the wafer surface, leaving the metal gate and high-k gate dielectric inside
the trench [Fig. 3.8(e)].
For planar HKMG MOSFETs, Al is used as the filler to fill the gate
trenches after the deposition of high-k dielectric and work-function metals.
For FinFETs, because the aspect ratio of the gate trench is significantly higher
than that of planar MOSFETs, it requires better gap-fill capability. Therefore,
W is commonly used as the filler for the narrow and deep gate trenches. The
gate-last HKMG process steps are listed in Table 3.3.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 105

Table 3.3 HKMG formation process with a gate-last approach.

ILD deposition NMOS work-function metal deposition
ILD CMP [Fig. 3.8(a)] TiN deposition
ILD CMP that stops on polysilicon [Fig. 3.8(b)] W deposition
Dummy polysilicon gate removal WCMP [Fig. 3.8(d)]
Wafer clean [Fig. 3.8(c)] WCMP continues, followed by TiN CMP
High-k dielectric deposition Wafer clean [Fig. 3.8(e)]

3.4 Advanced FinFET CMOS Process

The previous section briefly explained how to build FinFET devices on a SOI
wafer and on a bulk silicon wafer. It also described the gate-last HKMG
process that replaces the polysilicon/SiON dummy gate with metal/high k.
This section discusses in detail how to use advanced process technologies, such
as SADP, ALD, etc., to form advanced HKMG FinFET CMOS devices on a
bulk silicon substrate.
The wafer is first cleaned, as shown in Fig. 3.9(a), and then a thin layer of
pad oxide is thermally grown on the silicon surface, and a silicon nitride layer
is deposited on the pad oxide. This SiN layer serves as a hard mask (HM) for
the silicon etch that forms the fins of the FinFET; it also serves as a CMP stop
layer during STI oxide polish. The fin pitch is too small to pattern an
advanced-technology node (such as 22 nm or 14 nm) with one patterning of
193-nm immersion lithography, and thus SADP is needed.
A dummy pattern layer of SADP is deposited on top of the nitride HM,
and photoresist is coated on top of the entire stack [Fig. 3.9(b)]. The material
of this layer needs to have high etch selectivity to the underlying silicon nitride
and the spacer material that will be deposited on its sidewall to half the pitch
and double the pattern density. One possible dummy/spacer-layer combina-
tion is a-Si/SiOx (amorphous silicon and silicon oxide).
After PR patterning with a line-space fin dummy pattern mask, the
dummy patterns, or mandrels, are etched with an endpoint at the SiN surface,
as shown in Fig. 3.10(a). After PR strip and clean [Fig. 3.10(b)], a conformal
dielectric layer is deposited [Fig. 3.10(c)], and then the dielectric layer is etched
back in the vertical direction to form spacers on the sidewall of the mandrels,
as shown in Fig. 3.10(d). After removal of the mandrels, the remaining spacer
patterns form the line-space patterns that double the density of the original
dummy pattern density [Fig. 3.10(e)]. If a-Si is used for the mandrels,
potassium hydroxide (KOH) can be used to remove it with very little effect on
the silicon oxide spacer and the underlying silicon nitride HM. The fin has the
smallest pattern pitch of FinFET IC devices; advanced 14-nm IC chips have a
fin pitch as small as 42 nm.
After wafer clean, photoresist is coated on the wafer surface, and cut mask
is applied to pattern the PR [Fig. 3.11(a)]. An anisotropic etch process is
applied to remove the spacer pattern in the area where no fins are designed
106 Chapter 3

Si

(a)

Photoresist

er
Lay
my
P Dum
SAD

SiN

SiO2

Si

(b)
Figure 3.9 3D view of FinFET CMOS processing: (a) wafer clean and, after pad oxidation,
(b) SiN deposition, SADP dummy layer deposition, and PR coating.

while keeping spacer patterns where the fins will be formed. This etch process
needs high selectivity to the underlying nitride HM so that it etches away
spacer patterns with minimal loss of the SiN HM. After PR strip and clean,
the remaining spacer patterns can be used to etch SiN HM, as shown in
Fig. 3.11(b). After etching away the pad oxide, the main etch process etches
the silicon fin using SiN HM patterns [Fig. 3.11(c)].
After wafer clean, an ILD layer is deposited [Fig. 3.12(a)], followed by
ILD CMP with SiN as the endpoint [Fig. 3.12(b)]. After ILD recess, the SiN
High-k, Metal-Gate FinFET CMOS Manufacturing Process 107

SiN

SiO2

Si

(a)

SiN

SiO2

Si

(b)

SiN

SiO2

Si

(c)
Figure 3.10 3D view of FinFET CMOS processing: (a) mandrel etch, (b) PR strip and
clean, (c) spacer film deposition, (d) spacer etch, and (e) mandrel removal.
108 Chapter 3

SiN

SiO2

Si

(d)

SiN

SiO2

Si

(e)
Figure 3.10 (Continued)

and pad oxide layer is stripped, as shown in Fig. 3.12(c). A sacrificial oxide
layer is grown [Fig. 3.12(d)], a well-implantation mask is applied, ion
implantation forms the isolation well between the channel and substrate, the
sacrificial oxide is stripped, and wafer is cleaned, as shown in Fig. 3.12(e).
This step finishes fin formation, which is somewhat similar to the STI
formation of the planar CMOS process. As discussed earlier, it is critical to
control the fin height because it directly affects the gate width of the FinFET
devices.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 109

SiN

SiO2

Si

(a)

SiN

SiO2

Si

(b)

SiN

SiO2

Si

(c)
Figure 3.11 3D view of FinFET CMOS processing: (a) fin cut mask patterning, (b) SiN HM
etch, and (c) Si fin etch.
110 Chapter 3

SiN

SiO2

Si

(a)

SiN

SiO2

Si

(b)

ILD0

Si

(c)
Figure 3.12 3D view of FinFET CMOS processing: (a) ILD0 deposition, (b) ILD0 CMP,
(c) strip SiN and pad oxide, (d) sacrificial oxide growth, and (e) strip sacrificial oxide.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 111

ILD0

Si

(d)

ILD0

Si

(e)
Figure 3.12 (Continued)

After fin formation, the wafer is cleaned, and a dummy gate oxide layer
is deposited, followed by polysilicon deposition and CMP, as shown in
Fig. 3.13(a). A HM layer is deposited, as shown in Fig. 3.13(b), and the gate
mask is applied to form the line-space pattern on the photoresist. Depending
on the technology node, if the gate pitch is larger than 80 nm, a single
patterning with a 193-nm immersion lithography process can be used to form
the line-space patterns. If the gate pitch is less than 80 nm, then pitch-
multiplying techniques, such as SADP and SAQP, are needed. After HM etch
and photoresist strip and clean, as shown in Fig. 3.13(c), a cut mask is applied,
and an etch process cuts the HM line patterns. After that step, photoresist
strip and clean occur, which form designed gate patterns on the HM layer
[Fig. 3.13(d)]. This HM pattern is then used to etch polysilicon and form the
dummy poly gate, as shown in Fig. 3.13(e).
112 Chapter 3

Polysilicon

ILD0

SiOx Si

(a)

Hard mask

Polysilicon

ILD0

SiOx Si

(b)

Hard mask

Polysilicon

ILD0

SiOx Si

(c)
Figure 3.13 (a) Oxide deposition, poly deposition, and CMP; (b) HM layer deposition;
(c) HM etch, and RP strip and clean; (d) cut mask etch, and PR strip and clean; and (e) poly
etch.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 113

Hard mask

Polysilicon

ILD0

SiOx Si

(d)

Hard mask

Polysilicon

ILD0

SiOx Si

(e)
Figure 3.13 (Continued)

Now the fins and dummy polysilicon gate patterns are formed. The next
processes are formation of S/D that involve spacer formation, ion implanta-
tion and selective epitaxial growth (SEG).
After wafer clean, a thin dielectric liner is deposited, followed by a thicker
dielectric layer [Fig. 3.14(a)]. A PMOS mask is applied so that the NMOS
areas are covered by PR to allow S/D formation of the PMOS [Fig. 3.14(b)].
After PMOS spacer etch and fin-spacer removal, the photoresist is stripped
and the wafer is cleaned [Fig. 3.14(c)]. Then silicon is recessed and heavily
p-type doped SiGe is grown in a SEG process, as shown in Fig. 3.14(d). This
finishes the PMOS formation.
114 Chapter 3

ILD0

SiOx Si

(a)

Photoresist

ILD0

SiOx Si

(b)

ILD0

SiOx Si

(c)
Figure 3.14 (a) Spacer dielectric deposition; (b) PMOS S/D mask; (c) PMOS spacer etch,
fin spacer removal, and RP strip and clean; and (d) silicon recess and SEG SiGe.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 115

SiGe

ILD0

SiOx Si

(d)
Figure 3.14 (Continued)

Next, NMOS S/D mask is applied, as shown in Fig. 3.15(a), NMOS

spacer is etched and spacers on NMOS fins are removed [Fig. 3.15(b)]. N-type
ion implantation is performed to heavily dope the NMOS S/D [Fig. 3.15(c)],
and the photoresist is stripped and cleaned. Mini-second anneal (MSA)
activated the dopant and finished the NMOS formation, as shown in
Fig. 3.15(d).
After the self-aligned silicide process forms silicide on the S/D, the wafer is
ready for the replacement gate or gate-last HKMG process. First, the ILD1 is
deposited, as shown in Fig. 3.16(a). Dielectric CMP removes part of the ILD1
to expose the dummy polysilicon gates [Fig. 3.16(b)]. After dummy-gate
removal and oxide strip and clean, as shown in Fig. 3.16(c), hafnium-oxide-
based high-k gate dielectric is deposited, followed by PMOS work-function
metal TiN [Fig. 3.16(d)] and barrier metal TaN, all with ALD processes
[Fig. 3.16(e)].
After wafer clean, photoresist is coated on the wafer, and a NMOS
mask is applied to protect the PMOS and expose the NMOS, as shown in
Fig. 3.17(a). An etch process removes the TaN barrier layer and TiN PMOS
work-function metal, as shown in Fig. 3.17(b). After PR strip and clean, a
NMOS work-function metal (such as TiAlN) is deposited [Fig. 3.17(c)].
A TiN adhesion layer is then deposited, followed by WCMP, which fills the
gate trenches [Fig. 3.17(d)]. WCMP removes the bulk W. All other metal
layers and the high-k dielectric layers are removed from the wafer surface in
the over-polish step, as shown in Fig. 3.17(e).
This step finishes the FEoL of HKMG FinFET CMOS devices; the
following steps are the middle-end-of-line (MEoL) processes. The processes of
116 Chapter 3

Photoresist

SiGe

ILD0

SiOx Si

(a)

Photoresist

SiGe

ILD0

SiOx Si

(b)

Photoresist

SiGe

ILD0

SiOx Si

(c)
Figure 3.15 (a) NMOS S/D mask; (b) PMOS spacer etch and fin-spacer removal;
(c) NMOS S/D implantation; and (d) PR strip, clean, and MSA.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 117

SiGe

ILD0

SiOx Si

(d)
Figure 3.15 (Continued)

a 14-nm HKMG FinFET SRAM could have two layers with a total of four
masks. One layer is the S/D contact (SDC) with two masks, and another layer
is the gate contact (GC) with two masks. After two cycles of ILD/HM
deposition, contact double patterning, contact etch, TiN and W deposition,
and WCMP, the MEoL processes are finished; the contact plugs and local
interconnection are formed, and the back-end-of-line (BEoL) processes could
be started. Figure 3.18(a) is a transmission electron microscope (TEM) image
of the cross-section of a 22-nm FinFET CMOS device with S/D contact and
gate contact. Figure 3.18(b) is Fig. 3.17(e) with dashed lines to indicate the
direction of the cross-section. The SDC contacts are not round holes but
rather elongated trenches. The next section describes the processes of the
contact module.
The BEoL processes start with wafer clean and etch-stop layer (ESL)
deposition. They are followed by depositions of ultra-low-k dielectric, a cap
oxide layer, TiN metal HM layer, dielectric HM layer, and the dummy
layer. After inspection, review, and clean, PR is coated on the wafer, the
first metal mask is applied, and mandrels are etched from the dummy layer.
A conformal dielectric layer is deposited, and an etch-back process forms
spacers on the sidewalls of the mandrels. After mandrel removal, the pitch
of the line space is halved. The cross-section along the spacer is shown in
Fig. 3.19(a). The process steps are very similar to that illustrated in
Fig. 3.10. A cut mask is applied, and the looped lines formed by the spacer
are cut into the designed pattern, as shown in Fig. 3.19(b). A dielectric layer
is deposited to fully cover the patterns, illustrated in Fig. 3.19(c). A CMP
118 Chapter 3

ILD1

SiGe

ILD0

Si

(a)

ILD1

n
ico
ysil
Pol

SiGe

ILD0

Si

(b)

ILD1

SiGe

ILD0

Si

(c)
Figure 3.16 (a) ILD1 CVD, (b) ILD1 CMP (b), dummy polysilicon gate removal (c), High-k
gate dielectric ALD (d), TiN and TaN ALD (e).
High-k, Metal-Gate FinFET CMOS Manufacturing Process 119

TiN

ILD1

SiGe

ILD0
HfOx

Si

(d)

TaN

ILD1

SiGe

ILD0
HfOx

Si

(e)
Figure 3.16 (Continued)

process planarizes the dielectric and exposes the patterns that are embedded
in the dielectric film [see Fig. 3.19(d)]. A highly selective etch process
removes the embedded patterns to form the dielectric HM etch, which
can be used to etch the TiN hard mask, as shown in Fig. 3.19(e). 3D
illustrations of this pattern reversal process are shown in Fig. 3.18(f). After
dielectric HM strip and clean, the M1 trench patterns are transferred to TiN
hard mask. Next, the V1 mask is applied, and the V1 is etched when it is
aligned with M1, as shown in Fig. 3.19(i). After the via hole reaches the
ESL, etch is stopped and PR is stripped. Trenches are etched using a TiN
120 Chapter 3

TaN

ILD1

SiGe

ILD0
HfOx

Si

(a)

HfOx

ILD1

SiGe

ILD0
HfOx

Si

(b)

AlTiN

ILD1

SiGe

ILD0
HfOx

Si

(c)
Figure 3.17 (a) NMOS mask, (b) TaN and TiN etch, (c) TiAlN ALD, (d) TiN and W
deposition, and (e) WCMP.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 121

ILD1

SiGe

ILD0
HfOx

Si

(d)

ILD1

SiGe

ILD0

Si

(e)
Figure 3.17 (Continued)

HM, and the ESL is broken through at the bottom of via holes [Fig. 3.19(j)].
After barrier TaN and seed Cu deposition, bulk Cu is plated, shown in
Fig. 3.19(k). The wafer is then cleaned and annealed. Metal CMP removes
the Cu, TaN, and TiN metal HM from the wafer surface, and self-aligned
cobalt tungsten phosphide (CoWP) is deposited on the metal surface with an
electrode-less plating process, as shown in Fig. 3.19(l). This step finishes the
dual-damascene M1 process module.
If V1 is not well aligned with M1, then the TiN hard mask could block
the V1 etch, creating a small via hole and void in the via plug after metal
deposition, as in Fig. 3.20. The small via could also be caused by the
122 Chapter 3

Figure 3.18 (a) Cross-section TEM image of FinFET CMOS with GC plug and SDC plugs;
reprinted from Ref. 16 with permission from Chipworks. (b) Fig. 3.17(e) with an indication of
the TEM sample.

pull-back of the trench pattern. Sometimes a small via cannot be etched all
the way to the previous metal layer, which causes an open circuit of the
interconnect.
The M2, M3, and Mx layers essentially repeat the M1 process steps
(x is the number of total metal layers). There are 13 metal layers for a 14-nm
FinFET CMOS chip—the most-advanced IC technology node in high-
volume manufacturing at the time of publication. The main variations are
the upper metal layers, which have a larger feature size and thus do not
require double patterning. The feature sizes of the last few metal layers
become so large that they do not require 193-nm immersion lithography;
248-nm (KrF excimer laser) or even 365-nm (i-line of a mercury lamp)
lithography could be used. Figure 3.21 shows a cross-section of a 13-metal-
layer HKMG FinFET chip.17

3.5 Advanced FinFET SRAM

Static random access memory (SRAM) is widely used in the CMOS logic IC
as cache memory due to its high speed. SRAM is usually formed by two
latched-up inverters and two pass NMOS, where one connects to a bit line and
another connects to an inverted bit line. Figure 3.22(a) shows the SRAM
 Spacer Spacer

Dielectric Metal Dielectric Metal

cap hard cap hard
ILD4 (ULK) mask ILD4 (ULK) mask
ESL ESL

W ILD3 W W ILD3 W

(a) (b)

Spacer Spacer

Dielectric Dielectric Metal

Metal
cap cap hard
hard
ILD4 (ULK) mask ILD4 (ULK) mask
ESL ESL

W ILD3 W W ILD3 W

(c) (d)

Dielectric Metal
cap hard
ILD4 (ULK) mask
ESL

W ILD3 W Spacer cut HM film CMP Spacer removal

(e) (f)

Dielectric Metal Dielectric Metal

cap hard cap hard
ILD4 (ULK) mask ILD4 (ULK) mask
ESL ESL

W ILD3 W W ILD3 W

(g) (h)

Dielectric Metal Dielectric Metal

cap hard cap hard
ILD4 (ULK) mask ILD4 (ULK) mask
ESL ESL

W ILD3 W W ILD3 W

(i) (j)

CoWP

Dielectric Cu Metal Dielectric Cu

cap hard cap
ILD4 (ULK) mask ILD4 (ULK)
ESL ESL

W ILD3 W W ILD3 W

(k) (l)
Figure 3.19 Copper metallization process: (a) SADP spacer formation; (b) spacer cut;
(c) dielectric hard mask deposition; (d) dielectric hard mask CMP; (e) spacer removal; (f) 3D
illustration of pattern reverse; (g) M1 pattern etch on the TiN hard mask; (h) dielectric hard
mask removal; (i) via etch, (j) trench etch and ESL breakthrough; (k) copper plating, and
(l) metal CMP and CoWP electrode-less plating.
124 Chapter 3

Via mask with overlay shift

Trench on metal hard mask

Photoresist

Dielectric Metal
cap hard
ILD4 (ULK) mask

ESL

W ILD3 W

(a)

Dielectric TaN Cu Metal

cap hard
ILD4 (ULK) mask

ESL

W ILD3 W

(b)
Figure 3.20 Cu void caused by via mask-overlay-induced CD variation: (a) after via etch
and (b) after Cu plating with void.

circuit with two inverters and two pass gates. Figure 3.22(b) shows the detail
of an inverter as one NMOS and one PMOS. Here, “bit” indicates a bit signal,
and “bit0 ” indicates the inverted bit signal. A SRAM cell needs six transistors,
four NMOS, and two PMOS—far more than a DRAM cell of one NMOS
and one capacitor, or a NAND flash cell of one device.
SRAM usually has the highest pattern density in a logic CMOS chip, and
it is commonly used as the test vehicle for process development of new
technology nodes. Figure 3.23(a) is the top-down TEM image of Intel 14-nm
SRAM.24 The dashed rectangular box indicates the unit cell of SRAM. Each
inverter consists of a NMOS and a PMOS with a shared gate. Figure 3.23(b) is
High-k, Metal-Gate FinFET CMOS Manufacturing Process 125

Figure 3.21 Cross-section of an Intel 14-nm chip with 13 metal layers. Image reprinted
from Ref. 17 with permission from Chipworks.

Figure 3.22 SRAM cell circuit with (a) inverters and (b) transistors.

the the SRAM design-layout drawing based on the TEM image in Fig. 3.23(a).
It has four device layers: fin, gate, S/D contact and gate contact. The fins and
gate contacts are in the vertical direction; the gates and S/D contacts are in the
horizontal direction. A SRAM unit cell consists of two inverters and two pass
gates (NMOS).
126 Chapter 3

(a)
S/D contacts

PMOS fins

Pass gate Inverter gate

NMOS fins
Inverter gate Pass gate

Gate contacts

(b)
Figure 3.23 (a) Top-down TEM image of a SRAM cell. Source: Ref. 24, reprinted with
permission from IEEE. (b) SRAM layout based on (a) with indications of the fins, gates, and
contacts.

A SRAM array image is formed by copying, pasting, and mirroring the

unit cell shown in Fig. 3.23 [see Fig. 3.24(a)]. The dashed rectangular box
indicates a unit cell. An advanced CMOS logic IC chip could have multiple
SRAM arrays with up to 256 million cells. In comparison, there are only 24
cells in the SRAM array shown in Fig. 3.24(a). Figure 3.24(b) is the design
intent based on Fig. 3.24(a). There are four patterning layers: fin, gate,
SDC, and GC. At least four doping layers are needed to form a FinFET
SRAM: n-well, p-well, n-S/D, and p-S/D. For gate-last HKMG FinFETs,
there is also a NMOS MG mask, which allows the formation of the NMOS
work-function metal gate by either removing the PMOS work-function
metal or the PMOS MG barrier layer to allow a chemical reaction that
changes the PMOS work-function metal to a NMOS work-function metal.
The design of each layer is one-dimensional (1D). The fin, doping, and GC
patterns are in the vertical direction; the gate and SDC patterns are in the
horizontal direction.
The rest of this section describes the FEoL and MEoL process steps of
14-nm FinFET SRAM from a top-down perspective, including photolithog-
raphy masks, and from a cross-sectional view, mainly in the direction along
the gate.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 127

(a)

NMOS fin PMOS fin Gate S/D contact Gate contact

(b)
Figure 3.24 Top-down view image of a 24-cell SRAM array: (a) the dashed box is a unit
cell, and (b) the design intent of the SRAM array.

After wafer clean, sacrificial oxide is grown in the diffusion furnace. An

n-well mask [shown in Fig. 3.25(a)] is applied, and high-energy ion
implantation forms a deep n-well junction. After photoresist strip and clean,
the p-well mask shown in Fig. 3.25(b) is applied and high-energy p-type ion
implantation is performed to form a deep p-well junction. After PR strip and
wafer clean, an annealing process repairs implantation-induced crystalline
damage and activates the dopant, which finishes the well formation.
128 Chapter 3

(a)

(b)

N-well
P-well P-well

(c)
Figure 3.25 (a) N-well mask and (b) p-well overlapped with the fin and gate of a SRAM
array, and (c) cross-section along the solid line after both well implantations.

A comparison of Figs. 3.25(a) and (b) shows that the n-well is for PMOS
and the p-well is for NMOS; the two masks are complementary in a SRAM
array. It is easier to form wells with ion implantation before the fin etch. The
trade-off is the etch rates of p-type doped silicon and n-type doped silicon are
different, which can cause uneven etch profile and fin heights of n-type and
High-k, Metal-Gate FinFET CMOS Manufacturing Process 129

p-type fins during the silicon fin etch process. Isolation junction for n-well
and isolation junction p-well can be co-implanted during n-well implantation
and p-well implantation, respectively. Isolation junctions are not shown in
Fig. 3.25(c).
Next, the sacrificial oxide is stripped and the wafer is cleaned [Fig. 3.25(c)].
Pad oxide is grown, followed by silicon nitride deposition. A di-
electric HM layer and dummy layer are also deposited for SADP. The
fin dummy mask [shown in Fig. 3.26(a)] is applied, and a dummy pattern is
etched. Figure 3.26(b) overlaps the fin dummy mask with the SRAM array
image to show the location of spacers that will be cut into a fin in later
processes.
After dummy etch and PR strip and clean, a conformal dielectric film is
deposited. A vertical etch-back process forms spacers on the sidewall of the
dummy patterns [Fig. 3.26(c)]. After the dummy pattern is removed, the
spacer pattern doubles the pattern density of the original fin dummy pattern.
The dielectric HM is then etched with the spacer pattern, which will later be
cut into the final fin pattern. The top-down image at this stage of the process is
shown in Fig. 3.26(d), and the cross-section along the solid line is shown in
Fig. 3.26(e).
The aforementioned SADP cannot be used for 10-nm and 7-nm nodes;
they need SAQP, with two spacer formations and two mandrel layers.
Photolithography patterns the first mandrel layers. The first spacer doubles
the pitch density of the photolithography patterns and transfers the pattern to
the second mandrel layer. The second spacer doubles the pattern density
again, after removal of the second mandrel pattern; the second spacer patterns
can be transferred to the underlying hard mask to etch the silicon fins.
Figure 3.27(a) is a fin cut mask that overlaps with the fin dummy mask
and SRAM array image. It can help us to see how the cut mask helps to form
the final fin patterns. Figure 3.27(b) is the fin cut mask. If the pattern density
of the cut mask is too high for single patterning with 193-nm immersion
lithography, then a multi-patterning process may be needed. Figures 3.27(c)
and (d) are two cut masks that are split from the cut mask in Fig. 3.27(b).
Both cut mask 1 [Fig. 3.27(c)] and cut mask 2 [Fig. 3.27(d)] have half of the
pattern density of the original.
The peripheral area needs another cut mask to remove the fins between
the NMOS and PMOS. This cut mask has a line-space pattern that parallels
the fin pattern shown in Figure 3.26(d). Some SRAM arrays are designed
with a fixed fin pitch, and the fins between the NMOS and PMOS
are removed using this mask. The benefit of this design is the standardization
of the design of both SRAM arrays and logic gates; however, the trade-
off is the pin spacing of this kind of SRAM array must be either 2 or 3 times
the fin pitch and thus may not have the best power consumption and
performance.
130 Chapter 3

(a)

(b)

N-well
P-well P-well

(c)

(d)

N-well
P-well P-well

(e)

Figure 3.26 (a) Fin dummy mask, (b) fin dummy mask overlapping with a SRAM array
image, (c) cross-section of a dummy pattern with a spacer, (d) top-down view of spacer
patterns, and (e) cross-section of spacers.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 131

(a)

(b)

(c)

(d)
N-well
P-well P-well

(e)
Figure 3.27 (a) Fin cut mask overlaps with fin dummy mask and SRAM array image,
(b) illustration of fin cut mask, (c) fin cut mask 1, (d) fin cut mask 2, and (e) cross-section
along the solid line in (a).
132 Chapter 3

(a)

(b)

(c)

(d)
Figure 3.28 (a) Final fin pattern after silicon fin etch with a silicon nitride HM; (b) cross-
section along the solid line in (a); (c) fin pattern after ILD0 recess, nitride and pad oxide strip,
and wafer clean; and (d) cross-section along the solid line in (c).

After applying the cut mask(s), the final fin pattern can be etched on the
silicon nitride layer, using the pattern formed on the dielectric HM. The
silicon fin can be etched with the silicon nitride pattern. The top-down view of
the silicon fin pattern is illustrated in Fig. 3.28(a). Figure 3.28(b) is the
High-k, Metal-Gate FinFET CMOS Manufacturing Process 133

cross-section along the solid line in Fig. 3.28(a). The etch rates of p-type
doped silicon and n-type doped silicon are different. After wafer clean, ILD0
is deposited or spun-on and cured. ILD CMP stops on the silicon nitride
surface, and after wafer clean, ILD is recessed. Silicon nitride, pad oxide strip,
and wafer clean finish the fin formation process module. The top-down view
at this process stage is illustrated in Figure 3.28(c). Figures 3.28(a) and (c) are
very similar; the difference is that Fig. 3.28(a) shows only silicon fins with a
large aspect ratio and deeper gap between the fins, whereas Fig. 3.28(c) shows
the silicon with recessed ILD0, which has a lower aspect ratio and shallower
gap between the fins. Figure 3.28(d) is the cross-section along the solid line in
Fig. 3.28(c).
After silicon nitride and pad oxide strip and wafer clean, the dummy
gate oxide and dummy gate polysilicon layers are deposited. After
polysilicon CMP and wafer clean, a HM layer and dummy patterning
layer is deposited on top of polysilicon. The gate dummy mask [shown in
Fig. 3.29(a)] is applied to pattern the dummy layer. Figure 3.29(b) is the
gate dummy mask that overlaps with the SRAM array image. The gate in
the SRAM is formed by the spacer on the sidewall of the gate dummy
pattern.
After PR strip and clean, a conformal film is deposited on the wafer
surface, and a vertical etch process forms the sidewall spacer. The gate
dummy patterns are removed, and the wafer is cleaned. The spacer pattern
doubles the pattern density of the gate dummy pattern in this SADP
process.
Next, the HM is etched using the spacer patterns; the top-down view of
a SRAM array is illustrated in Fig. 3.29(c). The polysilicon gate is etched
with the HM pattern. This etch process is very challenging because the
pattern is very small and the substrate is not flat. At the top of the fin, the
etch process must stop on the dummy gate oxide while polysilicon between
the fins is completely removed. Any remaining polysilicon between the fins
is a critical defect because it can cause an electric short between the gates. If
the dummy gate oxide on top of the fins has been broken through, the
chemical that etches polysilicon will also etch a single crystalline silicon fin
quickly, which could cause fin loss, also a killer defect. Figure 3.29(d)
illustrates the top-down view of a SRAM array after completing the gate etch.
A comparison of Figs. 3.29(c) and (d) shows that Fig. 3.29(c) only shows gate
patterns on the wafer surface, whereas Fig. 3.29(d) shows both surface gate
patterns and subsurface fin patterns. Figure 3.29(e) shows the cross-section
along the gate in a SRAM array indicated by a solid line in Fig. 3.29(d).
After wafer clean, an organic planarization layer (OPL) is applied, which
planarizes the wafer surface. A HM layer is deposited on top of the OPL.
Depending on the technology node, one or more gate cut masks are applied.
Figure 3.30(a) shows the gate cut mask, and Fig. 3.30(b) shows the gate cut
134 Chapter 3

(a)

(b)

(c)

Figure 3.29 (a) Gate dummy mask, (b) gate dummy mask overlaps with SRAM array
image, (c) wafer surface after HM etch, (d) wafer surface after polysilicon gate etch, and
(e) cross-section along the polysilicon gate indicated by a solid line in (d).
High-k, Metal-Gate FinFET CMOS Manufacturing Process 135

(d)
NMOS PMOS
NMOS

(e)
Figure 3.29 (Continued)

mask overlapping with the top-down TEM image of a 24-cell SRAM array.
Figures 3.30(c) and (d) illustrate the two gate cut masks that are split from the
single mask shown in Fig. 3.30(a).
After the gate cut mask patterns etched on the hard mask, the etch process
that is designed to etch polysilicon and OPL at the similar etch rate is applied,
which cut the polysilicon line-space patterns shown Fig. 3.29(c) into the
SRAM gate pattern shown in Figure 3.30(e). There are two types of gates in a
SRAM array: one is an inverter gate, which has a NMOS and a PMOS, and
the other is a pass gate, which only has one NMOS. In this case, the NMOS of
the inverter is a double-fin FinFET, whereas the NMOS pass gate is a single-
fin FinFET. Figures 3.31(a) and (b) illustrate the cross-sections that are
indicated by the solid line in Figure 3.30(e), before gate cut and after gate cut,
respectively.
After OPL strip and wafer clean, a thin, conformal, heavily-phosphorus-
doped silicon oxide film (commonly called phosphosilicate glass, or PSG)
is deposited. The NMOS SDE mask shown in Fig. 3.32 is applied, and the
PSG on the PMOS fins and gates is removed. After PR strip and clean, a
mini-second high-temperature anneal is performed that injects the phosphorus
into the NMOS fins to form the NMOS SDE junction.
After PSG strip and clean, a thin, conformal, heavily-boron-doped silicon
oxide (commonly called borosilicate glass, or BSG) is deposited. The PMOS
136 Chapter 3

Figure 3.30 (a) Gate cut mask, (b) gate cut mask overlapping with the SRAM array image,
(c) gate cut mask 1, (d) gate cut mask 2, and (e) top-down view of the SRAM after polysilicon
gate cut.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 137

(d)

(e)
Figure 3.30 (Continued)

SDE mask shown in Fig. 3.33 is applied, and the BSG on the NMOS fins and
gates is removed. After PR strip and clean, another mini-second high-
temperature anneal is performed that injects the boron into the PMOS fins to
form the PMOS SDE junction.
After BSG strip and clean, a conformal dielectric liner is deposited on the
wafer surface, and a NMOS S/D mask, as shown in Fig. 3.34(a), is applied.
Figure 3.34(b) is the NMOS S/D mask overlapped with the SRAM image.
The location of the dot-dash-dot line, which indicates the cross-section of the
S/D formation, is different than the previous solid line, which indicates the top
of the gate.
After PR patterning, as shown in Fig. 3.35(a), a vertical etch process is
performed, and the dielectric liner on top of the NMOS fin is removed to
138 Chapter 3

Pass gate Dummy Inverter Inverter

Poly Si Hard mask ILD0 NMOS fins fins NMOS fin PMOS fin

(a)
Inverter gate Pass gate Inverter gate Pass gate

(b)
Figure 3.31 Cross-sections along the gate: (a) before gate cut and (b) after gate cut.

Figure 3.32 NMOS SDE mask.

Figure 3.33 PMOS SDE mask.

High-k, Metal-Gate FinFET CMOS Manufacturing Process 139

(a)

(b)
Figure 3.34 (a) NMOS S/D mask and (b) NMOS S/D mask overlapped with the SRAM
array image. The dot-dash-dot line indicates the S/D cross-section drawing.

expose the silicon of the NMOS fin. Because the hard mask is still on top of
the gates, the polysilicon gates are still wrapped by dielectrics, which will
protect them while the fin silicon is recessed. Figure 3.35(b) shows the cross-
section of the silicon recess of the NMOS fin along the dot-dash-dot line in
Fig. 3.34(b). After PR strip and clean, as shown in Fig. 3.35(c), single-
crystalline silicon heavily doped with phosphorus (SiP) is grown by a selective
epitaxial growth process in areas of exposed silicon [Fig. 3.35(d)]. SiP may
have 1–2% carbon, combined with silicon recessed into the channel, to create
tensile strain of the NMOS channel, which can increase channel electron
mobility. This process forms the NMOS S/D.
After SiP SEG, the dielectric liner is stripped in a wet etch process, which
is highly selective to silicon, SiP, and silicon oxide. After the wafer is cleaned,
another dielectric liner is deposited on the wafer surface with an ALD process.
140 Chapter 3

(a) (b)

SiP
1st liner

(c) (d)
Figure 3.35 Cross-section (a) after NMOS S/D mask, (b) after liner vertical etch and Si
recess, (c) after PR strip and clean, and (d) after SEG of SiP.

SiP 2 nd liner

Figure 3.36 Cross-section of the SRAM fin area after the second liner deposition.

This liner will be used to protect the NMOS S/D during PMOS S/D
formation. Figure 3.36 shows the cross-section after the second liner is
deposited.
The PMOS S/D mask shown in Fig. 3.37(a) is then applied.
Figure 3.37(b) is the PMOS S/D mask overlapping with the SRAM array
image. Figure 3.38(a) illustrates the cross-section after PR patterning with a
PMOS S/D mask. A vertical etch process is used to remove the second liner
from the top of the PMOS fin, as shown in Fig. 3.38(b). Similar to the NMOS
S/D process, the top of gate is protected by the hard mask and sidewalls are
protected by the spacers formed by the second liner. The silicon in the PMOS
fin is recessed [Fig. 3.38(c)], and SiGe heavily doped with boron is grown by a
SEG process, as shown in Fig. 3.38(d).
After wafer clean and anneal, the FinFET SRAM has been formed. More
process steps are needed to form gate-last high-k metal gate devices. At first,
ILD1 is deposited [Fig. 3.39(b)], and a CMP process planarizes the ILD1 to
High-k, Metal-Gate FinFET CMOS Manufacturing Process 141

(a)

(b)
Figure 3.37 (a) PMOS S/D mask in a SRAM array and (b) PMOS S/D mask overlapping
with a SRAM array image. The dot-dash-dot line indicates the location of the cross-section.

expose the polysilicon dummy gate, as shown in Fig. 3.39(c). Note that the
cross-sections are along the solid line in the SRAM array image [Fig. 3.39(a)],
which is on top of the gate, whereas the dot-dash-dot line used for the cross-
section of S/D formation is on top of the fins and SDC.
After the removal of dummy polysilicon gates using a highly selective wet
etch process, the dummy gate oxide is also stripped, and the wafer is cleaned
[Fig. 3.39(d)]. It forms gate trenches with fins inside. In this SRAM array,
there are two NMOS fins and one PMOS fin in the inverter gate trenches; and
there are two NMOS fins in the pass gate trenches. After wafer clean and very
thin silicon oxidation, hafnium-oxide-based high-k dielectric is deposited with
ALD, followed by a PMOS work-function metal TiN and TaN barrier layer
(also with an ALD process), as shown in Fig. 3.39(e).
142 Chapter 3

(a) (b)

2 nd liner SiP SiGe SiP

(c) (d)
Figure 3.38 Cross-section of SRAM PMOS S/D formation: (a) PMOS S/D litho, (b) PMOS
spacer etch, (c) Si recess of PMOS fin, and (d) SEG of boron-doped SiGe.

The NMOS metal gate (MG) mask, as shown in Fig. 3.40(a), is then
applied. Figure 3.40(b) is the NMOS MG mask overlapping with the SRAM
array image.
After PR patterning [Fig. 3.41(a)], the TaN barrier layer in the NMOS
area is etched away to expose the TiN layer. After PR strip and clean
[Fig. 3.41(b)], TiAl is deposited, as illustrated in Fig. 3.41(c). With an
annealing process, it reacts with TiN to form the NMOS work-function metal
TiAlN in the NMOS areas, whereas the PMOS work-function metal TiN is
protected by a TaN barrier layer [Fig. 3.41(d)]. TiN liner ALD and bulk
WCVD fill the gate trenches, as shown in Fig. 3.41(e). MG CMP removes W,
TiN, TiAl, TaN, TiN, and HfOx from the wafer surface and finishes the gate-
last HKMG processes [Fig. 3.41(f)].
At this point the FEoL processes are finished; they are followed by MEoL
processes that create contact plugs to the source, drain and gates, and form
the local interconnects. This step is followed by post-CMP clean, ILDx, and
HM layers [Fig. 3.43(a)]. The term ILDx is used because it is a sacrificial layer
that will be removed and not in the final device. The SDC mask shown in
Fig. 3.42(a) is applied. Figure 3.42(b) is the SDC mask overlapping with the
SRAM array image. Two masks may be needed for this layer for an
advanced-technology node. Figures 3.42(c) and (d) illustrate two masks that
are split from the SDC mask in Fig. 3.42(a). The contacts are not holes but
trenches. For the SDC layers, all of the contact trenches are parallel to the
gates.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 143

(a)

ILD1
Poly Si Poly Si

(b) (c)
TaN barrier

PMOS MG

High-k

(d) (e)
Figure 3.39 SRAM HKMG process 1: (a) SRAM array image and cross-sections are along
the solid line, (b) ILD1 deposition, (c) ILD1 CMP, (d) dummy polysilicon gate removal, and
(e) high-k, PMOS metal gate, and TaN barrier layers ALD.

The photolithography-pattern PR, as shown in Fig. 3.43(b), and the HM

are etched with PR patterns [Fig. 3.40(c)]. If double patterning is needed after
PR strip and clean, followed by another cycle of litho-etch, then ILDx is
etched with HM patterns, and ESL is etched through during the over-etch
step, as shown in Fig. 3.43(d). After wafer clean, Ti thin film is deposited at
the bottom of the SDC trenches. TiN liner and W filler film are deposited, as
shown in Fig. 3.43(e). RTA forms TiSi2 at the bottom of the trenches and
reduces contact resistance. WCMP removes bulk W, TiN, and Ti from the
wafer surface, and finishes this SDC module, as shown in Fig. 3.43(f). Note
that the cross-sections in Fig. 3.43 appear along the dot-dash-dot line in
Fig. 3.42(b).
The wafer is now ready for the gate contact (GC) layer. After ESL, ILD2,
and HM deposition [Fig. 3.43(a)], a GC mask [Fig. 3.44(a)] is applied.
144 Chapter 3

(a)

(b)
Figure 3.40 (a) NMOS MG mask and (b) NMOS MG mask overlapping with the SRAM
array image.

PR

(a) (b) (c)

(d) (e) (f)

Figure 3.41 (a) NMOS MG mask PR patterning; (b) TaN etch, and PR strip and clean;
(c) TiAl ALD; (d) TiAlN formation and TiN ALD; (e) WCVD; and (f) WCMP.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 145

(a)

(b)

(c)

(d)
Figure 3.42 (a) SDC mask and (b) SDC mask overlapping with the SRAM array image;
(c) split SDC mask 1 and (d) split SDC 2.
146 Chapter 3

PR PR
ILDx ILDx ILDx
ILD1 ILD1
ILD1

ILD0 ILD0 ILD0

(a) (b) (c)

ILDx
W ILDx W
W W
ILD1 ILD1
ILD1
ILD0 ILD0
ILD0

(d) (e) (f)

Figure 3.43 SDC module: (a) ILDx and hard mask deposition; (b) SDC PR patterning;
(c) HM etch; (d) PR strip, clean, and ILD etch; (e) wafer clean, and Ti, TiN, and W CVD; and
(f) WCMP.

Figure 3.44(b) is the GC mask overlapping with the SRAM array image.
Figures 3.44(c) and (d) illustrate the two GC masks that split from
Fig. 3.44(a); they are used when a single exposure of 193-mm immersion
lithography cannot pattern the dense hole pattern and thus LELE double-
patterning processes are needed. The solid line in Fig. 3.44(b) indicates the
cross-section on top of the gates and will be used in the cross-section of the
GC process steps (Fig. 3.45).
Figure 3.45 shows the cross-sections along the solid line of Fig. 3.44(b),
which lands on top of the gates in the SRAM. After GC PR patterning
[Fig. 3.45(b)], the HM is etched, as shown in Fig. 3.45(c). After PR strip and
clean, ILD2 and the ESL are etched using HM patterns [Fig. 3.45(d)]. TiN
and W are deposited after wafer clean [Fig. 3.45(e)], and WCMP removes the
bulk W and TiN from the wafer surface, thus finishing the MEoL processes.
Because the BEoL processes have been covered multiple times already, this
will end the section.
The contact to the S/D can also be formed with a self-aligned contact
(SAC) process, which has been used in DRAM manufacturing for a long time.
To apply a SAC process, the metal gate shown in Fig. 3.41(f) must be
recessed. SiN CVD processes fill the trench formed by MG recess, and nitride
CMP removes SiN on the wafer surface, leaving SiN on top of the MG.
A trench-style mask [shown in Fig. 3.46(a)], where each trench aligns with the
S/D, is applied. Figure 3.46(b) is the SAC mask overlapping with SRAM
image, which shows that the source and drain are exposed. An etch process
with high oxide-to-nitride selectivity is applied to etch away the oxide and
High-k, Metal-Gate FinFET CMOS Manufacturing Process 147

(a)

(b)

(c)

(d)
Figure 3.44 (a) GC mask, (b) GC mask overlapping with the SRAM array image, (c) GC
mask 1, and (d) GC mask 2.
148 Chapter 3

PR PR PR PR
ILD2 ILD2 ILD2
W W ILD1 W W W W

ILD0 ILD0 ILD0

(a) (b) (c)

Inverter gate Pass gate Inverter gate Pass gate
contact contact contact plug contact plug

ILD2 ILD2 ILD2

W W ILD1 W W W W

ILD0 ILD0 ILD0

(d) (e) (f)

Figure 3.45 Gate contact module: (a) ESL, ILD2, and HM deposition; (b) GC PR
patterning; (c) HM etch; (d) PR strip, clean, and ILD2 etch; (e) wafer clean, and TiN and W
CVD; and (f) WCMP.

reach the S/D while removing very little of the SiN spacer and SiN on top of
the gate. After RP strip, wafer clean, and TiN liner and W deposition, a CMP
process removes W and TiN from the surface; W plugs connected to the S/D
are formed [Fig. 3.46(c)].

3.6 FinFET CMOS Scaling

The development of FinFET technology allows for IC scaling into the third
dimension. Previously, scaling always occurred in a planar (x or y) direction.
However, the z direction becomes part of the scaling strategy. Section 3.1
established that the drive current ID is proportional to the channel width: ID ∝
m(k/tox)(W/L). For FinFET technology, the channel width W ¼ 2H þ CDfin.
To make the FinFET a fully depleted device in the off state, the fin must be
very thin (CDfin ~ < 10 nm); thus, the channel width is primarily determined by
the fin height. Increasing the fin height H can increase the channel width and
improve both the drive current and device performance. Figures 3.47(a) and
(b) illustrate the FinFET scaling from 22 nm to 14 nm, respectively, in Intel
chips. Figures 3.47(c) and (d) are TEM images of a 22-nm and 14-nm
FinFET, respectively, along the metal gate.
The FinFET structure can further scale down to 7 nm (perhaps even 5 nm)
by increasing the fin height and pattern density with either EUV lithography
or SAQP with multiple cuts. New materials—such as SiGe, Ge, and III-V
materials such as InGaAs—could be used to replace silicon to form the fin
High-k, Metal-Gate FinFET CMOS Manufacturing Process 149

(a)

(b)

(c)
Figure 3.46 S/D self-aligned contact module: (a) SAC mask, (b) SAC mask overlap with
SRAM image, and (c) S/D contact formed with the SAC process.

and increase carrier mobility of the channel. Of course, whether these scaling
techniques will be developed and implemented in high-volume manufacturing
will be determined by whether the scaling could bring financial profits in the
long run.
150 Chapter 3

Figure 3.47 Intel’s FinFET scaling from 22-nm to 14-nm technology: (a) 22-nm fin height
and fin pitch, (b) 14-nm fin height and fin pitch, (c) TEM image of 22-nm FinFET, and
(d) 14-nm FinFET TEM image. Image reprinted from Ref. 18 with permission from Intel.

3.7 Review Questions

1. What are the benefits of FinFET technology compared to planar

MOSFET technology?
2. Describe the advantage and disadvantage of a SOI FinFET.
3. Compared to planar MOSFETs, what are the challenges of the FinFET
polysilicon gate etch?
4. How many NMOS and PMOS are in a basic SRAM cell?
5. Arrange the three memories (DRAM, flash memory, and SRAM) in three
ways: by speed, by cost, and by volatile/non-volatile.
High-k, Metal-Gate FinFET CMOS Manufacturing Process 151

6. What are the major changes that occur when a FinFET is scaled from the
22-nm to the 14-nm technology node?
7. Assuming that 14-nm to 10-nm scaling follows the same trends as 22-nm
to 14-nm scaling, estimate the fin pitch and fin height of the 10-nm node.
8. For a planar MOSFET, the gate pattern has the smallest pitch and highest
pattern density. Is this still true for a FinFET?
9. Why must the fin CD of a FinFET be very small ( <10 nm)?
10. Why do mobile chip designers prefer FinFET technology over planar
MOSFET technology?
Chapter 4
Summary and Future Trends
of the 3D IC Process
4.1 Scaling MOSFET Technology after 14 nm
In the so-called “good old days,” traditional scaling—which scaled the feature
size of MOSFETs, such as gate length L, gate width W, and, more
importantly, the gate oxide thickness tox—could reduce the IC manufacturing
cost, improve device performance, and reduce power consumption. Table 4.1
shows the relationship between the scaling parameters and scaling factor a.
The table shows that when W, L, tox, and V scale down by a factor of 2 (a ¼ 2),
the MOSFET can run twice as fast with only one-fourth of the power
consumption. If W, L, and tox scale down by a factor of 2 while the voltage V
stays unchanged, the device can be four times faster with half of the power
consumption.
During that era, any pattern on a photomask could be printed on the
wafer surface with a high degree of fidelity, albeit with some corner rounding.
Those “golden days” of scaling ended after the introduction of the 130-nm
technology node, when the gate oxide thickness could be scaled down no
further due to tunneling-induced leakage.
For planar MOSFET ICs, a technology node used to be defined as one-
fourth of the pitch of the contacted gate (gates with contact between them),
which had the smallest pitch in that chip. At 130 nm, because the pattern pitch
was approaching the photolithography wavelength, the proximity effect
became stronger, and what was on the mask no longer resembled what was
printed on the wafer. Optical proximity correction (OPC) started being
applied in that node.
The performance improvement from 90-nm nodes to 65-nm nodes
primarily involved the introduction of channel strain, with limited improve-
ment of carrier mobility m. Doping the gate silicon dioxide with nitrogen also
helped increase k value somewhat. Because the feature sizes in these
technology nodes started to become significantly smaller than the photoli-
thography wavelength, 193 nm, optical proximity correction (OPC) had to be

153
154 Chapter 4

Table 4.1 Scaling parameters and scaling effect on performance, based on Ref G.
Constant Field Constant Voltage Constant Voltage Scaling
Parameter Symbol Scaling Scaling with Velocity Saturation

Gate length L 1/a 1/a 1/a

Gate width W 1/a 1/a 1/a
Field  1 a a
Oxide thickness tox 1/a 1/a 1/a
Substrate doping Na a2 a2 a2
Gate capacitance CG 1/a 1/a 1/a
Oxide capacitance Cox a a a
Transit time tr 1/a2 1/a2 1/a
Transit frequency fT a a2 a
Voltage V 1/a 1 1
Current l 1/a a 1
Power P 1/a2 a 1
Power delay PDt 1/a3 1/a 1/a

applied in the mask patterns to ensure the design-intended patterns could be

printed on the wafer surface. Intel was the first to introduce a high-k metal
gate (HKMG) in the HMV of 45-nm chips, which helped continue
performance improvement. At the same time, techniques such as double
patterning and immersion lithography were developed, which helps the
feature size continue scaling with the existing 193-nm ArF photolithography
system without so-called “next-generation lithography (NGL)” techniques,
such as EUV, e-beam direct write, nano-imprint, etc.
The 3D device era arrived when FinFET technology was introduced in
22-nm and 16-nm/14-nm technology nodes, which also kept all of the
aforementioned device-performance-enhancement techniques. It continued
scaling the feature sizes; however, it improved device performance mainly by
increasing the channel width W, which is primarily determined by the fin height
W ¼ 2Hfin + CDfin. Self-aligned double patterning (SADP) with multiple cut
masks was used to pattern the fins and gates. A low-temperature ALD process
could be developed to deposit conformal dielectric film directly on the PR
patterns to form a spacer on the PR sidewall, which could eliminate a dummy
layer for mandrel formation and thus reduce the patterning cost. Figure 4.1
shows images of the SRAM cell and MOSFET cross-section TEM images of
Intel 90-nm, 65-nm, 45-nm, 32-nm, 22-nm, and 14-nm technology nodes and
their release dates.18–23
When scaling to 10 nm and 7 nm, the scale gate width W can be scaled
further by increasing the fin height. If EUV is still not ready for HVM, then
SAQP with multiple cut masks will be used to form the fin patterns and the
gate patterns. When the metal wire cross-section scales down to 20 nm wide
by 25 nm tall, the percentage of 5-nm TaN barrier layer in the metal
wire cross-section will reach 60%. In this case, the resistivity of the copper wire
(which has a cross-section of 10 nm  20 nm) will be much higher than the
bulk copper resistivity due to boundary scattering. This situation occurs
Summary and Future Trends of the 3D IC Process 155

Figure 4.1 Intel IC scaling: technology nodes, release years, SRAM cell images, and device
cross-section images. The upper- and lower-right images are from Ref. H, reprinted with
permission from IEEE. The rest of the images are from Ref. 24, reprinted with permission from
Intel.

because the electron mean free path in copper (55 nm) is significantly larger
than the copper wire width and height.26 Therefore, a combined Cu and TaN
stack is no longer the best conducting materials for a 25 nm  25 nm2 wire.
Metals that do not require a barrier layer and that have a resistivity lower
than a Cu/TaN stack could be used, especially for the first few metal layers
with tight geometry. Cobalt (Co) is a possible replacement. A Co interconnect
can be formed with selective grow, anneal, and CMP.27 A shrinking feature
size also means that the film thickness is shrinking, and more thin film layers
are deposited by ALD processes with bulk film still using CVD, PVD, and
ECP. A thin film layer (a few nanometers thick) could also be etched with an
atomic layer etch (ALE) process; STT-MRAM MTJ formation is one such
ALE application.
An air gap, which has the lowest dielectric constant, has already been
applied in planar NAND flash28 and a few of the upper metal layers of 14-nm
logic IC. More air gap is expected in the BEoL in 10-nm and 7-nm nodes to
reduce RC delay and improve device speed.
Another way to increase the channel width W is using multiple silicon
nano-wires (NWs), which is called a gate-all-around (GAA) FET. In contrast,
the current FinFET in HVM involves tri-date devices, in which the channel is
surrounded by gate along three sides. Figure 4.2(a) shows the tri-gate FinFET
with three fins, and Fig. 4.2(b) shows the GAA-FET with nine nano-wires.29,30
Figure 4.3 shows the simplified process steps of Si NW GAA-FET
manufacturing. First, alternating SiGe and Si epitaxial layers are grown on
the silicon surface of a SOI wafer, followed by silicon oxide and silicon nitride
HM deposition [Fig. 4.3(a)]. After PR patterning, a fin-shaped pattern is
etched, the PR is stripped, and the wafer is cleaned, as shown in Fig. 4.3(b).
156 Chapter 4

Figure 4.2 (a) Three-fin FinFET and (b) nine-wire GAA FET. Image reprinted from Ref. 29
with permission from Intel.

(a) (b) (c) (d) (e)

Figure 4.3 Nano-wire formation: (a) alternating SiGe and Si epitaxial growth, and pad
oxide and nitride hard mask deposition; (b) photolithography, etch, PR strip, and clean;
(c) remove SiGe and SiN; (d) oxidation, clean, oxidation, and HKMG deposition; and
(e) polysilicon deposition.

SiGe and SiN layers are removed to form silicon nano wires, as shown in
Fig. 4.3(c). After oxidation and oxide clean, which reduces the thin SOI layer
to oxide, the high-k and metal gate layers are deposited, as shown in
Fig. 4.3(d). Polysilicon deposition, CMP, and patterning finish the gate-first
HKMG Si NW GAA-FET formation, as shown in Fig. 4.3(e). Of course,
during the etch process, the silicon NW cannot be floated in mid-air, as shown
in Figs. 3.16(c) and (d). The supporting structures of the NW will be patterned
at the end of NW [Fig. 3.16(b)] at the locations where the contact plugs will
land [Fig. 3.15(b)]. The NWs are dangling between supporting structures, and
a sagging NW is a challenging defect to capture and review.
Quick drawing and calculation can help demonstrate the challenges that
NW GAA-FETs will face. Figure 4.4(a) illustrates a FinFET with a 10 nm
60 nm fin, and Fig. 4.4(b) illustrates a GAA-FET with three 10 nm  10 nm
wires with 10-nm spacing between the wires. The effective channel width of
the FinFET is 130 nm, and the effective channel width of the NW GAA-FET
Summary and Future Trends of the 3D IC Process 157

(a) (b) (c)

Figure 4.4 (a) 10 nm  60 nm FinFET, (b) GAA-FET with three 10-nm Si wires, and
(c) GAA-FET with four 10-nm Si wires.

is 120 nm! Thus, to get a higher drive current than a 10 nm  60 nm FinFET, at

least four 10 nm  10 nm NWs must be stacked with 5-nm spacing between the
wires, as shown in Fig. 4.4(c), which has an effective channel width of 160 nm.
With corner rounding, W ¼ 125.7 nm for four circular NWs with a CD of 10 nm.
However, a GAA-FET [shown in Fig. 4.4(b)] has only half of the cross-section
area of the fully depeleted channel at the off state of the FinFET shown in
Fig. 4.4(a), which allows it to significantly reduce standby leakage while
maintaining a similar drive current (an attractive trait for mobile chip designers).
Since the advent of the 90-nm technology node, channel strain has been
used to improve carrier mobility m, usually with compressive strain in the
PMOS channel and tensile strain in the NMOS channel. Analysis of the
drive current equation suggests that one thing that has not really changed in
50 years of IC scaling is carrier mobility m, which is determined by the channel
materials (silicon for all these years) with some minor improvement by
applying strain in the channel. By changing the channel materials from silicon
to high-mobility (high-m) materials, such as Ge for the PMOS channel and
III-V compound for the NMOS channel, the carrier mobility m can be
significantly increased. Table 4.2 shows the materials with different electron
and hole mobilities that could be the potential channel material for next-
generation IC chip scaling.
The material change of MOSFETs in IC manufacturing is very difficult
and full of challenges. Many new materials had been introduced over more
than 50 years of IC fabrication history, such as polysilicon in the 1970s; TiSi2,
WSi2, W, and TiN in the 1980s; CoSi2, Cu, and Ta in the 1990s; and NiSi in
the 2000s. However, the real material change of the MOSFET device itself
happened only twice. The first time was when polysilicon replaced aluminum
as the gate electrode in the 1970s after the SASD formation was introduced
158 Chapter 4

Table 4.2 Materials with different carrier mobility, band gap, and dielectric constant.
Si Ge InP GaAs In0.47Ga0.53As InSb GaSb
Electron m (cm /Vs)
2
1600 3900 5400 9200 14000 77000 1000
Hole m (cm2/Vs) 430 1900 200 400 300 850 3000
Band gap Eg (eV) 1.12 0.66 1.34 1.42 0.75 0.17 0.72
Dielectric constant k 11.8 16 12.4 13.2 13.9 16.8 15.7

using newly developed ion-implantation technology. The second time was the
introduction of HKMG in the 45-nm technology node to replace nitrogen-
doped silicon oxide as the gate dielectric and polysilicon gate electrode about
30 years later. For the MOS transistor, “M” and “O” were changed—perhaps
it is time to change “S,” the channel material.
Of course, carrier mobility is not the only thing that must be considered.
For example, the band gap Eg, which determines the device’s thermal stability
and off-state leakage current (standby power consumption), deserves consider-
ation. Most of the high-m materials in Table 4.2 have a low Eg, which makes
them undesirable for mobile devices. Unfortunately, mobile devices constitute
the main market that drives the development of IC technology and
manufacturing currently and for the foreseeable future. If Ge, SiGe, and III-
V materials were used in future FinFET or NW devices, it could be the last
major material change of MOSFET-based IC manufacturing. Figure 4.5 shows
the process that could be used for Ge, SiGE, and III-V FinFET formation.
Serval methods can be used to form Ge, SiGe, and III-V fins. One way
grows defect-free blanket Ge, SiGe, and III-V epi films on a silicon wafer and
then patterns them into fins, as shown in Fig. 4.5(a). Another way forms the
silicon fins first using fin-formation processes of the existing FinFET process.
After ILD deposition and CMP, the silicon fins are recessed, and selective
growth of a Ge, SiGe, or III-V epitaxial fin forms the silicon surface in the slot
where the silicon fin used to be; the goal is to keep the lattice mismatch-
induced crystalline defects, such as dislocation and stack fault, near the
bottom of the slot, as shown in Fig. 4.5(b).28
Figure 4.6 shows another two ways to form high-m fins proposed by the
author. Basic steps shown in Figure 4.6(a) are: deposit dielectric film, then
pattern the dielectric in reverse patterns of the fins; SEG high-m fins from the
silicon surface at the bottom of the trenches. After CMP removes high-m film
from the surface, recess ILD to expose the high-m fins to the required height.
These two processes basically skipped the silicon fin formation in Fig. 4.5(b),
thus should have lower cost. Figure 4.6(b) modified the process steps in
Fig. 4.6(a) by adding a hard mask layer on top of the ILD. After wafer clean,
the ILD and HM are deposited. After fin patterning, the HM and ILD are
etched, and after PR strip and clean, high-m SEG is performed. High-m SEG
CMP stops on the HM; after HM removal, the high-m fins are formed, with
the fin height determined by the HM thickness.
Summary and Future Trends of the 3D IC Process 159

(a) (b)
Figure 4.5 (a) Blanket high-m epi growth and fin formation, and (b) Si fin replacement with
a high-m fin formation.

(a) (b)
Figure 4.6 (a) Modified high-m fin formation steps without a HM, and (b) modified high-m fin
formation with a HM.
160 Chapter 4

Table 4.3 Summary of MOSFET scaling types and performance-enhancement factors.

Scaling type Technology node Performance improving factor in ID ∝ m(k/tox)(W/L)
Traditional $130 nm Reduction of the gate oxide thickness tox
Extension of traditional 90 nm and 65 nm Channel strain-induced higher m and nitrogen-doped
gate oxide increased k
High-k metal gate 45 nm and 32 nm Increased k and MG-induced lower EOT
3D (tri-gate FinFET) 22 nm to ≤10 nm Increased fin height: channel width W = 2Hfin þ CDfin
3D (NW GAA-FET) ≤5 nm? Increased number of nano-wires N: channel width
W = pNCDNW
High-m ≤5 nm? Increased carrier mobility m

From Figure 4.1 we can see that technology node scaling is slowing down.
It took three years from 22 nm scaled down to 14 nm, while previous
technology node scaling usually took two years. Likely 14-nm to 10-nm and
10-nm to 7-nm scaling will take at least three years or even longer. This is
because the smaller the technology node, the harder it is to pattern the
features, and the smaller the killer defect size is that has already approached
the detection limit of HVM inspection systems, and the harder it is to develop
defect-free processes for high-yield HVM. Table 4.3 summarizes the
MOSFET IC scaling.

4.2 Scaling and Development of Memory Devices

The cost and speed of different memory devices are indicated in Fig. 4.7. In a
personal computer or a mobile computing device—such as a smartphone,
tablet, or laptop—SRAM is commonly used as the cache memory of the
central processing unit (CPU) to store data that need quick access. DRAM is

Figure 4.7 Cost and speed of different memory devices.

Summary and Future Trends of the 3D IC Process 161

the main memory used to run the program and keep data for processing and
editing. Both SRAM and DRAM are volatile memory, which means that they
need a power supply to maintain the memory. A sudden power outage could
cause data to be lost if they were not saved in a non-volatile memory, such as
a NAND flash-based solid state drive (SSD) or hard disk drive (HDD). Most
mobile devices use a SSD because it is smaller, consumes less power, and is
more reliable because it does not have any moving parts. HDDs are widely
used in PCs, and they are the backbone for data storage, especially servers and
data centers, because they are cheaper than SSDs and are more cost effective
for large amounts of data storage. Magnetic tape is still used for data backup
in data centers due to its low ownership cost.
Buried WL architecture will continue be used for DRAM scaling; the
main challenge is how to scale the storage node capacitor because its aspect
ratio increases each generation of scaling. It will reach a point where it can
no longer be made cost-effectively due to issues such as under-etch, bowing-
profile-induced SN-to-SN short, and misalignment to the SNC plug at the
bottom of the SN hole. Those issues could become a roadblock for further
DRAM scaling. For NAND flash, 3D-NAND is gaining momentum, and
the scaling trend involves adding more stacks. The main challenges are
multilayer stack deposition, staircase formation, channel hole etch, bottom
select-gate Si SEG, isolation trench etch, CG/WL deposition and isolation
formation, and staircase contact etch. For multilayer deposition, not only do
the deposition rate and uniformity of the multilayers need to be well-
controlled but also the stress of the stacks. The final roadblock for 3D-
NAND is similar to DRAM, i.e., HAR channel hole etch: under-etch and
hole bowing-profile-induced device variation. Si SEG at the bottom of the
deep channel hole could be even more challenging. Furthermore, contact
hole etch on a 128-step (or more) staircase could become really difficult to
control.
In the field of memory development, scientists and engineers have been
trying to find alternatives that are as fast as DRAM and as low-cost and non-
volatile as NAND flash. Both DRAM and NAND flash are charge-based
memory, as well as SRAM. A capacitor-type device is needed for this kind of
memory to hold the charges and keep the memory of data. It is very difficult
to keep the capacitance of a planar device to hold the charge while scaling
down the feature size, which is the main reason why a DRAM SN capacitor
goes to such HAR 3D structures and NAND flash goes to 3D.
Almost all recently developed alternative NVMs are not charge-based
devices; rather, they are based on resistivity. Although these NVMs have
different working mechanisms, they all have at least two stable resistivity
states: one high-resistivity state, and one low-resistivity state. By staying in
different resistivity states, they can permanently store digital data of 1 or 0,
and they can quickly switch between the two states.
162 Chapter 4

(a)

(b)
Figure 4.8 (a) Basic structure of the resistivity-based high-speed non-volatile memories
and (b) its layout.

Figure 4.8(a) illustrates the base structure of the resistance-based high-

speed non-volatile memories. These resistivity-based memories usually have a
bottom electrode that can be connected to a select transistor. There is also a
top electrode. A metal wire connects the top electrode and bottom electrode
(normally perpendicular to each other), locating the memory device at the
cross-point of the two metal wires in the top-down view, as shown in
Fig. 4.8(b). This arrangement is why some people call this type of device
“cross-point” memory.
This type of memory can be stacked, just like multi-layer interconnects in
IC chips. Figure 4.9(a) shows a two-stack version, Fig. 4.9(b) shows a four-
stack, and Fig. 4.9(c) illustrates an eight-stack version with a 3D structure,
which can be manufactured with processes that are very similar to 3D-NAND
flash. For the stacking shown in Figs. 4.9(a) and (b), each additional stack
requires two masks, and thus the cost of stacking increases linearly with the
number of stacks. For the 3D stacking shown in Fig. 4.9(c), the number of
Summary and Future Trends of the 3D IC Process 163

(a) (b) (c)

Figure 4.9 Resistivity-based memory: (a) two-stack, (b) four-stack, and (c) 3D eight-stack
versions.

masks is not linearly related to the number of stacks. The main challenges are
film deposition, etch, and clean, just like 3D-NAND flash.
There are currently three resistivity-based NVM devices that get a lot of
attention:
• phase-change random access memory (PCRAM),
• spin-transfer-torque magnetic random access memory (STT-MRAM),
and
• resistive random access memory (ReRAM).
Figure 4.10 shows a schematic of PCRAM, which changes the state of a
chalcogenide-based material from amorphous to crystalline in order to store a
digital signal “0” or “1.” Alloys of germanium, antimony, and tellurium
(GeSbTe, or GST) are commonly used chalcogenide-based materials in
PCRAM development and manufacturing. GST can be switched between the

Figure 4.10 PCRAM with both memory states.

164 Chapter 4

crystalline phase and the amorphous phase when GST cools down from
different heating temperatures, which can be controlled by applying different
current. When GST is heated to a temperature higher than its melting point
(600˚C) and then cooled quickly, it forms an amorphous state. When it is
heated higher than its crystalline temperature (300˚C) and then cooled, it
switches to a crystalline state. The crystalline phase has low electrical
resistivity, whereas the amorphous phase has high resistivity.31,32
The right-side chalcogenide in Fig. 4.10 is in amorphous state with high-
resistance and could be registered as logic “1.” The left side illustrates the
crystalline state with low resistance and could be registered as logic “0.”
PCRAM is already being produced by several memory chip manufacturers
and serves some niche markets. The commercial PCRAM chip has a unit cell
with one access transistor and one GST, or 1T1R. However, it is possible to
stack PCRAM in a 3D structure (Fig. 4.9) without an access transistor, which
could allow people to scale PCRAM in the vertical direction to achieve HVM
of low-cost, high-speed, non-volatile memory.
STT-MRAM is another resistivity-based NVM; it also uses the 1T1R
structure, as shown in Fig. 4.11(a). The resistance-change device in STT-
MRAM is commonly called magnetic tunnel junction (MTJ). Figures 4.11(b)
and (c) show the MTJ structure. When the free-layer magnetization is parallel
to that in the fix layer, as shown in Fig. 4.11(b), the resistance between the top
electrode (TE) and the bottom electrode (BE) is low. When the free-layer
magnetization is anti-parallel to that of the fix layer, as shown in Fig. 4.11(c),
the resistance is high. Both states are stable, which gives the device the
capability to permanently store digital information, and the stored informa-
tion can be rewritten by switching the parallelism of the free-layer
magnetization.
The fix layer has a fixed magnetization orientation and is used as the
reference to identify the parallelism of the free-layer magnetization orienta-
tion. The fix layer is made with multiple thin layers of ferromagnetic

(a) (b) (c)

Figure 4.11 (a) 1T1MTJ STT-MRAM, (b) MTJ with parallel magnetization orientation, and
(c) MTJ with anti-parallel magnetization orientation.
Summary and Future Trends of the 3D IC Process 165

materials, such as multiple Co/Pd stacks, or stacks of InGa/FePt/Heusler

alloy. In that multilayer, every film is very thin (1 nm). The tunneling barrier
is usually a very thin (1–2 nm thick) dielectric layer, such as Al2O3 or, more
recently, MgO. The free layer is also called the record layer, which consists of
ferromagnetic materials so that the parallelism of its magnetization can be
modified through a spin transfer operation. The free layer can be made of
ferromagnetic materials, such as Co, Fe, Ni, or Mn. A commonly used
material is a CoFeB alloy 1–2 nm thick with a metal cap of Ta, Ru, and
TiN. One advantage of STT-MRAM is that it can have high device density:
6F2, or even 4F2 if one can use vertical GAA-FET for the access transistor,
which is very attractive to many memory IC chip manufacturers because it
could potentially replace DRAM and NAND flash. It is also very attractive
to logic IC manufacturers because embedded STT-MRAM is very fast and
has the potential to replace SRAM and embedded DRAM. The MTJ
formation is very challenging when etching a MTJ pattern with CD < 20 nm
because it etches multiple metal layers with a very thin dielectric layer
sandwiched in between and must control the MTJ profile very well. Any
conductive sidewall residue across the thin barrier layer will short the free
layer and the fix layer, causing yield loss.33,34
The third popular resistivity-based NVM is resistive random-access
memory (RRAM or ReRAM). Figure 4.12 shows the ReRAM memory cell;
it is formed with metal oxides or non-oxide metal compounds, such as metal
sulfides and metal tellurides. An example of a ReRAM memory cell is formed
by conductive tantalum oxide (TaOx) and non-conductive tantalum pentoxide
(Ta2O5-d, d is a small amount) with a Ta filament. When the top electrode is
positively biased and the bottom electrode is negatively biased, the strong
electric filed causes the oxidation of Ta filament and cuts off the metal bridge.
It is the high-resistance state, as shown in Fig. 4.12(a). When the bias is
reversed, i.e., the top electrode bias is negative and the bottom electrode bias

(a) (b)
Figure 4.12 (a) High-resistance-state ReRAM device and (b) low-resistance state with a
fully bridged channel.
166 Chapter 4

is positive, the electric field is reversed, which causes the reversion of the
aforementioned metal oxidation process; metal reduction occurs, and the
greater the reduction, the stronger the electric field accelerates the process.
A full metal bridge can be formed within a few nanoseconds. This is the low-
resistance state of ReRAM, as shown in Fig. 4.12(b). Because a conductive
bridge is formed in the low-resistance state, this type of ReRAM is also called
conductive-bridge RAM (CbRAM).
A 16-Gb ReRAM with a 27-nm lithography process with a 6F2 pattern
density has been in production since 2014. This ReRAM used the 1T1R
architecture. Its access transistor is a BWL transistor, and its resistive memory
cell consists of a TE, a copper telluride (CuTe) conductive layer, a SixOy
insulator with (0) or without (1) a fully bridged copper filament, and a BE, as
shown in Fig. 4.13.35,36
ReRAM can be stacked in a 3D structure, as illustrated in Fig. 4.9,
without the select transistor; thus, it can potentially have very high integration
density in order to achieve a low-cost, high-capacity, and high-speed non-
volatile memory device that can supplement or even replace DRAM and
NAND flash in some mobile devices.
An interesting fact about ReRAM is that it could be the fourth basic
element of a nonlinear electrical circuit, called a memristor.37,38 The other
three basic elements are well-known: resistor, capacitor, and inductor. The
word “memristor” is derived from “memory” and “resistor;” its symbol is
shown in Fig. 4.14(a), and its relationship with the other three elements is
shown in Fig. 4.14(b).
Figure 4.14(b) shows that the relationship of resistor R ¼ dV/dI is the
derivative of the famous Ohm’s law. The relationship between voltage and
magnetic flux V ¼ dF/dt is the Faraday’s law of induction. Memristor
M ¼ dF/dQ completes the fourth edge of the square with four corners of

Figure 4.13 Buried-word-line ReRAM. Based on Ref. 29.

Summary and Future Trends of the 3D IC Process 167

(a) (b)
Figure 4.14 (a) Symbol for a memristor and (b) conceptual symmetries schematic of a
resistor, capacitor, inductor, and memristor. Based on Ref. 39.

voltage, current, magnetic flux, and electric charge. If dF ¼ Vdt and dQ ¼ Idt
are substituted, then M ¼ V/I, which has the unit of resistance (Ohms). It also
illustrates that the memristor is not an independent element of a linear circuit;
it is only for nonlinear circuits.
The term “1T1R” was used earlier in this section to describe the structure of
the basic ReRAM cell, but perhaps “1T1M” would be a better description. It is
very likely that in the near future, chips with all four basic elements of a
nonlinear electrical circuit will be integrated in a single system-on-chip (SoC) IC.
Table 4.4 summarizes the different memory devices discussed in this book.
Recently, Intel and Micron jointly announced a new type of NVM, 3D
XPoint memory, that has been claimed to be 1000 times faster and more

Table 4.4 Parameters of different memory devices (based on Ref. I).

STT-
SRAM DRAM NAND Flash PCRAM ReRAM MRAM
Non-volatile No No Yes Yes Yes Yes
Cell size (F2) 50–120 6–10 5 6–12 6–10 6–20
Read time (ns) 1–100 30 50 20–50 10–50 2–20
Write/erase time (ns) 1–100 15 1.0 ms/0.1 ms 50/120 10–50 2–20
Endurance 1016 1016 105 108 108 1015
Write power Low Low Very high Low Low Low
Other power Current Refresh None None None None
consumption leakage current
High voltage No 3V 16–20 V 1.5–3.0 V 1.5–3.0 V <1.5 V
required
168 Chapter 4

durable than NAND flash.40 The table demonstrates that both PCRAM and
ReRAM can fit that claim, and the latter fits better thanks to its higher write/
erase speed.

4.3 3D Packaging
To increase device density without scaling feature size of the wafer processing,
vertically stacked IC chips, such as DRAM or flash chips are used in large
storage capacity DRAM and flash products. By stacking four DRAM chips
in a package, it is equivalent to scaling feature size of a DRAM chip by half,
which represents two full generations of scaling. Engineers and scientists have
developed technologies to stack multiple DRAM chips in a package, where
the chips on top are shifted a certain distance to expose the bond pads of the
chip below so that multiple chips can be wire-bonded together. Figure 4.15(a)
illustrates four-chip stacking with wire bonding, and Fig. 4.15(b) shows four
four-chip stacked to form a 16-chip stacked DRAM in 3D packaging.41
Another chip-stacking technique, called through silicon via (TSV),
recently received a lot of attention and traction. By making a connection
through metal (Cu or W) plugs that directly pass through the silicon substrate,
the routing distance becomes much shorter than the wire-bonding stacking,
and thus it can improve the device speed and reduce power consumption.
Because all of the bond pads are located near the edge of the die, wire-bonding
stacking can happen only after die separation, with die-to-die stacking and
wire bonding performed near the die edge. TSV stacking does not have this
constraint, so it can be more flexible with the outlet locations to allow chip
designers to optimize the routing. Another advantage of TSV stacking is that
it can perform wafer-level stacking, whereas wire-bonding stacking can only
be performed at the chip level. There are two types of TSV bonding. One is
“die-to-known-good-die,” which is a thinned good die with TSV bumps that
bonds with a good die on the handling wafer. Another one is “wafer-to-
wafer.” If the wafer yield is high enough, then wafer-to-wafer stacking with

(a)

(b)
Figure 4.15 Wire-bond 3D-DRAM: (a) four-chip stacking with wire bonding, and (b) 16-chip
3D packaging with wire bonding.
Summary and Future Trends of the 3D IC Process 169

STV will have a lower cost than both chip-to-chip wire-bonding stacking and
die-to-known-good-die chip-to-wafer bonding.
TSV 3D chip stacking has been used in CMOS image sensors for many
years.42 DRAM chips with a four-chip TSV stack has been in HVM, and the
products are available in the market.13 A 256-Gb NAND flash chip with a 16-
die stack with TSV technology has also been demonstrated recently during the
Flash Summit.43

Question: If the DRAM wafer yield is 90%, what is the yield after four-wafer stacking?

Answer: If the yield loss is caused by random defects, then the final yield is four 90%
multiplied together, which is 65.61%.

Figure 4.16 illustrates a cross-section of a TSV-ready BWL DRAM chip.

The BWL DRAM illustrated in Fig. 1.10(a) is located at the upper-left corner
of Fig. 4.16. TSV has many approaches; this figure shows the so-called via-
middle approach, which forms the TSV after the first contact WCMP process.
In this figure, it is SNC WCMP.
The TSV has a plug CD from 1–5 mm and a depth from 10–50 mm. After
all of the interconnect processes have finished and the passivation dielectric is
etched to expose the bond pads, the wafer is taped from the front side to

Figure 4.16 Cross-section of a TSV-ready BWL DRAM.

170 Chapter 4

Figure 4.17 Cross-section of a TSV BWL DRAM after wafer thinning.

protect the circuitries already manufactured, and the wafer is thinned from the
backside of the wafer to expose the TSV Cu plugs, as shown in Fig. 4.17. A
standard 300-mm Si wafer is 775 mm thick; to expose a 50-mm TSV, at least
725 mm of Si must be removed from the backside. After dielectric-layer
deposition and removal expose the TSV plugs again with dielectric on the
surface, metal bumps are formed on top of the TSV plugs, as shown in
Fig. 4.18.
The thinned wafer with bumps then can be bonded with a handling wafer,
which is not thinned. The tape on the front surface of the thinned wafer is
removed, and the wafer is cleaned, as shown in Fig. 4.19. More of the thinned
wafer with bumps can be bonded with the wafer shown in Fig. 4.19 to achieve
multiple-wafer stacking with TSV. Figure 4.20 illustrates four DRAM wafers
stacked together with TSV.
The die layout for memory chips such as DRAM and NAND flash is the
same, and so they can be designed into a TSV 3D stacking-ready format
relatively easily, especially compared to CMOS logic devices. DRAM and
flash products are highly cost-sensitive; thus, their die yield on the product
wafer in HVM usually is very high, which is extremely important when
implementing wafer-level 3D packaging with TSV. Beyond stacking memory,
people are also working on CMOS chip stacking with TSV technology.
Figure 4.21 shows a cross-section a SEM image of an eight-die stack CMOS
Summary and Future Trends of the 3D IC Process 171

Figure 4.18 Cross-section of a TSV BWL DRAM after bump formation.

Figure 4.19 Two-wafer stacking with TSV.

172 Chapter 4

Figure 4.20 Four-wafer stacking with TSV.

Figure 4.21 Cross-section SEM image of an eight-wafer stack that contains active CMOS
and SuperContacts. From Ref. J. Reprinted with permission from Tezzaron.
Summary and Future Trends of the 3D IC Process 173

Figure 4.22 Two hybrid cubes with TSV in a package connected with an interposer.

chip.38 (It uses the term “SuperContacts” instead of TSV.) The CD of the
SuperContacts is 1.2 mm, and the depth is 6 mm. The eight dies are stacked in
alternating “face-to-face” (F2F) and “back-to-back” (B2B) bonding. Wafer 1
faces up and Wafer 2 faces down for F2F bonding, Wafers 2 and 3 are B2B
bonded with bumps formed at the tip of “SuperContacts” (Fig. 4.18). Wafers
3 and 4 are F2F bonded, etc. In comparison, the TSV stacking illustrated in
Fig. 4.20 is back-to-face, which allows all of the stacked wafers to be exactly
the same as the handling wafer.
It is also possible to stack different types of chips, such as multiple
memory chips stacked together to stack on top of a logic chip. A hybrid
memory cube (HMC) is one such concept that people are working on to
make the chip much faster by shortening the distance between memory cells
and logic circuits. It requires the memory-chip designer and logic-chip
designers to collaborate and ensure that the outlets of different chips are
well aligned so that they can be connected and bonded seamlessly with the
TSV bumps. Multiple stacked chips can also be put into one package with
an interposer to form a chip with even more functions, as shown in
Fig. 4.22.

4.4 Other 3D Devices and 3D IC Processing Techniques

There are many device architectures and 3D integration techniques currently
under research, and some of them are in development. A tunnel field effect
transistor (TFET) is one such device being researched with the potential to
replace MOSFETs in the so-called “post-CMOS” era. Figure 4.23(a)
illustrates a planar TFET. It looks similar to a planar MOSFET; however,
the source and drain are doped differently, and they are asymmetric. It is
possible to make a vertical gate all around the TFET, even with SiGe and III-
V high-m materials, to achieve a high-speed, low-power-consumption IC
circuit, such as SRAM and other logic devices, as shown in Fig. 4.23(b).45–47
174 Chapter 4

(a) (b)
Figure 4.23 (a) Planar TFET and (b) vertical TFETs with high-m channel materials, based
on Ref. 41.

Graphene is a 2D material that has a single layer of carbon atoms

arranged in a honeycomb-shape with excellent mechanical strength, high
thermal conductivity, and adjustable electrical conductivity. It has attracted
widespread attention from researchers of next-generation electronic devices
almost immediately after its discovery.48 Because it has zero band gap
(Eg ¼ 0 eV), it is unsuitable for the low-standby-power transistors that are
required for the low leakage current of mobile devices. However, it sparked
interest for researchers looking into other 2D materials (many of them metal
chalcogenides, such as MoS2, WS2, etc.) as candidate materials to replace
silicon for post-Si nano-electronic devices.49 Figure 4.24 illustrates a FET with
a 2D MoS2 channel material. It is very similar to a SOI MOSFET: it uses
mono-layer MoS2 to replace Si to form the fully depleted channel, and
graphene can be used to form the gate electrode and source–drain contact.
TSV 3D chip or wafer stacking is performed with fully manufactured
chips or wafers, after wafer thinning and backside bump formation. A
different approach of 3D IC stacking has been proposed that uses technology
very similar to the smart cut of SOI wafer manufacturing, which includes a
handling wafer (wafer B) with a silicon dioxide layer and a transfer wafer (wafer
A) implanted with hydrogen. Bonding a hydrogen-implanted transfer wafer to

Figure 4.24 MOSFET with 2D material MoS2.

Summary and Future Trends of the 3D IC Process 175

Hydrogen ions, H+

Wafer A
(a) (d)

SiO2

Wafer B

(b)
SiO2 Hydrogen rich layer

Wafer A
(e)

Wafer B

(c) (f)
Figure 4.25 Bonded SOI formation process: (a) wafer-1 hydrogen implantation, (b) wafer-2
oxidation, (c) wafer-1 and wafer-2 F2F contact, (d) thermal bonding and hydrogen out-
gassing, (e) wafer splitting, and (f) Si CMP and clean.

the SiO2 of the handling wafer can transfer a thin silicon layer to the handling
wafer at the relatively low temperature of 400°C, as shown in Fig. 4.25.50
If a fully processed wafer with a planarized silicon oxide layer on the
surface replaces the handling wafer and wafer bonding is performed with a
hydrogen-implanted transfer wafer, a thin silicon layer is transferred on top of
that device wafer. More IC devices can be manufactured on the thin layer of
silicon, just like SOI wafer processing, and the previously processed device
wafer is used as a handling wafer. A deep contact or via can be used to
connect the circuits on the thin silicon layer to the circuits on the underlying
carrier wafer. After low-temperature metal interconnect formation and a layer
of silicon oxide is deposited and planarized with a CMP process, the wafer can
be used as a handling wafer again to allow another layer of single-crystalline
silicon to be transferred on top of the planarized silicon oxide. The process can
be repeated multiple times.
Figure 4.26 shows a three-layer HKMG CMOS formed with two silicon-
on-ILD processes. Figure 4.26(a) shows the wafer with finished HKMG
CMOS devices, contacts, local interconnects, ILD (SiOx), and the first single-
crystalline silicon layer already transferred on top of the ILD. Figure 4.26(b)
shows the finished second layer of CMOS devices, i.e., fully depleted SOI
176 Chapter 4

(a)

(b)
ILD 3

(c)
Figure 4.26 A three-layer HKMG CMOS formed with two silicon-on-ILD processes.
Summary and Future Trends of the 3D IC Process 177

devices, have been finished; the contacts to the first device layer, i.e., landing
pad 1; and the deposited ILD 2, ready for the transfer of the second silicon-
crystalline layer. Figure 4.26(c) shows the finished third layer of CMOS
devices, which are also fully depleted SOI devices; contacts to the second
device layer (landing pad 2); the deposited ILD 3—the wafer is ready for the
transfer of the third silicon-crystalline layer or low-k copper interconnect. This
technique can also be applied in memory chip manufacturing and has been
demonstrated in a three-layer NAND flash chip.51,52

4.5 The End of Moore’s Law?

Since Jack Kilby created the first functional IC device in 1958, IC technology
has developed rapidly, driven by consumer electronics, personal computers, the
Internet, and mobile electronics. People joked that if airplane speeds followed
Moore’s law, they could fly around the world in less than a second today; if
vehicle prices scaled like IC chips, a new car could be purchased in pennies.
Computers used to weigh several tons and were owned only by government
labs and large corporations, but now they are pocket-sized and have more
computational power than a 20-year-old super-computer. The first generation
of mobile phones needed a suitcase, and a coiled wire connected its handset to
the system in the case; thus, its only practical use was to mount it in a car.
When mobile phones were reduced in size to about half of a brick, people
started to carry them on their belts or in their handbags, thus prompting the
mobile revolution. The size of mobile phones continued to shrink until demand
for larger screens increased, and the trend was reversed. The border between
smartphones, tablet computers, and laptop computer has become fuzzy. It is
quite possible that in 10 years one will only need a smartphone that has enough
computational power, storage, apps, and easy access to networks and other
accessories, such as a large screen, keyboard, mouse, and charger; all personal
computers, laptops, and tablets could become obsolete. If that smartphone can
project not only 3D holographic images in front of the user but also a keyboard
on the desk, who needs a laptop or tablet?
Currently, self-driving cars are being test driven on the road, and they
are expected to reach the market in the near future. For a person who has
lost the ability to drive but still prefers to live independently, a self-driving
car could be a blessing. Furthermore, self-driving vehicles can be used by
the military to send supplies to frontline troops and avoid casualties due to
enemy ambushes.
Robotic devices are used in households to vacuum the floor. Some hotels
staff robots as front-desk clerks and luggage carriers. Likely applications of
humanoid robots will be widened by intelligent ones that can not only
recognize a person’s face but also determine a person’s moods through facial
expression identification; they can not only recognize a person’s voice but also
178 Chapter 4

their emotion. Such a robot can perform household chores and provide care
for the sick or elderly. The IC chips necessary to realize these functions must
have very powerful data-processing capability with a large amount of data
storage and a short data-access time, which could drive the next round of
scaling.
According to Moore’s p law of IC scaling so far, with the IC-chip feature
size scaling by a factor of 1/ 2 every two years, a 2-nm technology node could
be reached by 2026. Even p if it is assumed that after 14 nm the scaling slows
down to a factor of 1/ 2 for every three years, the result will be a 3.5-nm
technology node. For FinFET logic IC, the minimum pattern fin pitch of
3.5 nm could be 10.5 nm, which can be formed with a 13.5-nm EUV double-
patterning process. The main issue will be cost. There was some argument that
Moore’s law ended at 28 nm, mainly because some data showed that the per
transistor cost bottomed at 28 nm [Fig. 4.27(a)]. Some companies accepted
this idea and left IC manufacturing. However, not everyone believes that
Moore’s law ended at the 28-nm node; some people believe that the law still
holds, supported by the data shown in Fig. 4.27(b). Some companies are still
heavily investing in development of sub-10-nm technology for future IC
manufacturing, which will keep scaling IC chips for the foreseeable future. Of
course, another argument is that there was never such a thing as “Moore’s
law;” it was just an observation and prediction. Rather, it has always been the
“law of more” that drives the IC technology and overlaps with Moore’s
prediction.11
No one knows exactly what the future of IC chips looks like, although
there will be chips made with 3D devices and perhaps 3D chip stacking using
TSV and an interposer. One of my favorite futuristic 3D IC devices looks like

Figure 4.27 Normalized per transistor cost: (a) chart based on data from Ref. 53, and
(b) chart based on Ref 24.
Summary and Future Trends of the 3D IC Process 179

the one shown in Fig. 4.22: a package with multiple chip stacks connected
with an interposer. Each chip stack has a logic base chip and multiple TSV
stacked memory chips on top of the base. Each logic base chip has a vertical
GAA-FET on the substrate level and multiple layers of silicon-on-ILD and
2D-on-ILD logic devices, depending on their functionality. Here 2D means
2D semiconductor materials such as MoS2. Graphene can be used as gate
electrodes and contact materials for the 2D devices, and carbon nano-tubes
can be used for the inter-device layer connection. Memory 1 can be multiple
3D-NAND or multilayer 3D cross-point chips stacked with TSV, and
memory 2 can be multiple 4F2 DRAM chips stacked with TSV. Hopefully, in
the future, people can develop the technologies needed to manufacture this
kind of chip cost-effectively.
In order to achieve this kind of within-chip and within-package 3D scaling,
scientists and engineers of different disciplines must work together to research
and develop novel materials, new process technologies, and innovative
inspection and metrology solutions. Even after the end of Moore’s law,
demand for advanced IC chips will still be strong and growing, especially with
the economic growth of China, India, and other developing countries. The
semiconductor industry and supporting industries still need many highly
trained, innovative, and hardworking scientists, engineers, technicians and
supervisors to operate multi-billion-dollar IC manufacturing fabs, troubleshoot
the manufacturing process, and maintain multi-million-dollar equipment.
References
1. D. Hisamoto, W.-C. Lee, J. Kedzierski, E. Anderson, H. Takeuchi,
K. Asano, T.-J. King, J. Bokor, and C. Hu, “A folded-channel MOSFET
for deep-sub-tenth micron era,” IEDM Tech. Digest, 1032–1034 (1998).
2. E. Karl et al., “A 4.6 Ghz, 162 Mb SRAM Design in 22 nm Tri-Gate
CMOS Technology with Integrated Active Vmin-Enhancing Assist
Circuitry,” ISSCC Dig. Tech. Papers, 230–232 (2012).
3. Samsung website, “Samsung Starts Mass Producing Industry’s First
32-Layer 3D V-NAND Flash Memory, Its 2nd Generation V-NAND
Offering,” http://www.samsung.com/semiconductor/insights/news/13481
(May 29, 2014). Last accessed on 02/06/2016.
4. Toshiba website, “Toshiba Develops New NAND Flash Technology,”
http://www.toshiba.co.jp/about/press/2007_06/pr1201.htm (June 12, 2007).
Last accessed on 02/06/2016.
5. Y. Fukuzumi et al., “Optimal Integration and Characteristics of Vertical
Array Devices for Ultra-High Density, Bit-Cost Scalable Flash Memory,”
IEDM Tech. Digest, 449–452 (2007).
6. R. H. Dennard, “Field-effect transistor memory,” U.S. Patent #3387286
(1968).
7. J. Y. Kim et al., “Transistor(RCAT) for 88-nm feature size and beyond,”
Symp. on VLSI Tech., 11–12 (2003).
8. I.-G. Kim et al., “Overcoming DRAM Scaling Limitations by Employing
Straight Recessed Channel Array Transistors with < 100 > Uni-Axial and
{100} Uni-Plane Channels,” IEDM Tech. Digest, 319–322 (2005).
9. T. Schloesser et al., “A 6F2 Buried Wordline DRAM Cell for 40 nm and
Beyond,” IEDM Tech. Digest, 809–812 (2008).
10. H. Xiao, “Method for forming memory cell transistor,” U.S. patent
#8778763 B2 (2014).
11. H. Xiao, Introduction of Semiconductor Manufacturing Technology, 2nd
ed., SPIE Press, Bellingham, WA (2012) [doi: 10.1117/3.924283].
12. S. W. Lee et al., “Atomic Layer Deposition of SrTiO3 Thin Films with
Highly Enhanced Growth Rate for Ultrahigh Density Capacitors,” Chem.
Mater. 23(8), 2227–2236 (2011).

181
182 References

13. R. Courtland, “Chipmakers Push Memory into the Third Dimension,

Samsung, Micron, and SK Hynix bet that transistor redesigns and chip
stacking will make memory smaller and faster,” http://spectrum.ieee.org/
semiconductors/design/chipmakers-push-memory-into-the-third-dimension
(Dec 23, 2013). Last accessed on 02/06/2016.
14. Solid State Technology, “Horizontal channels key to ultra-small 3D
NAND,” http://electroiq.com/blog/2012/09/horizontal-channels-key-to-
ultra-small-3d-nand. Last accessed on 02/06/2016.
15. D. Fried, “FinFET tipsheet for IEDM,” http://www.techdesignforums.
com/practice/technique/finfet-iedm-tipsheet (December 4, 2012).
16. D. James, “Intel’s 22-nm Trigate Transistors Exposed,” http://www.eet.
bme.hu/~mizsei/Montech/intel-s-22-nm-trigate-transistors-exposed.html
(2012). Last accessed on 02/06/2016.
17. D. James, “Intel’s 14-nm Parts are Finally Here!,” http://www.chipworks.
com/about-chipworks/overview/blog/intel%E2%80%99s-14-nm-parts-are-
finally-here (2014). Last accessed on 02/06/2016.
18. T. Ghani et al., “A 90 nm High Volume Manufacturing Logic
Technology Featuring Novel 45 nm Gate Length Strained Silicon CMOS
Transistors,” IEDM Tech. Digest, 197–200 (2003).
19. P. Bai et al., “A 65nm Logic Technology Featuring 35nm Gate Lengths,
Enhanced Channel Strain, 8 Cu Interconnect Layers, Low-k ILD and
0.57 mm2 SRAM Cell,” IEDM Tech. Digest, 197–200 (2004).
20. K. Mistry et al., “A 45 nm Logic Technology with High-k þ Metal Gate
Transistors, Strained Silicon, 9 Cu Interconnect Layers, 193 nm Dry
Patterning, and 100% Pb-free Packaging,” IEDM Tech. Digest, 247–250
(2007).
21. S. Natarajan et al., “A 32nm Logic Technology Featuring 2nd-
Generation High-k þ Metal-Gate Transistors, Enhanced Channel Strain
and 0.171 mm2 SRAM Cell Size in a 291 Mb Array,” IEDM Tech. Digest,
941–943 (2008).
22. C. Auth et al., “A 22nm high performance and low-power CMOS tech-
nology featuring fully-depleted tri-gate transistors, self-aligned contacts
and high density MIM capacitors,” VLSI Symp. Tech., 131–132 (2012).
23. C.-H. Jan et al., “A 22nm SoC Platform Technology Featuring 3-D Tri-
Gate and High-k/Metal Gate, Optimized for Ultra Low Power, High
Performance and High Density SoC Applications,” IEDM Tech. Digest,
44–47 (2012).
24. M. Bohr, “14 nm Process Technology: Opening New Horizons,” http://
www.intel.com/content/dam/www/public/us/en/documents/pdf/foundry/
mark-bohr-2014-idf-presentation.pdf (2014). Last accessed on 02/06/2016.
25. D. Nikonov, “Beyond CMOS computing,” https://nanohub.org/resources/
18348/download/NikonovBeyondCMOS_1_scaling.pdf (2013). Last
accessed on 02/06/2016.
References 183

26. Y. Hamaoka, K. Hinode, K. Takeda, and D. Kodama, “Increase in

Electrical Resistivity of Copper and Aluminum Fine Lines,” Mater.
Trans. 43(7), 1621–1623 (2002).
27. M. H. van der Veen et al., “Cobalt Bottom-Up Contact and Via Prefill
enabling Advanced Logic and DRAM Technologies,” Proc. IEEE IITC/
MAM, 25–28 (2015).
28. K. Prall and K. Parat, “25 nm 64Gb MLC NAND Technology and
Scaling Challenges,” IEDM Tech. Digest, 102–105 (2010).
29. K. J. Kuhn, “Technology Options for 22nm and Beyond,” http://
download.intel.com/pressroom/pdf/kkuhn/Kuhn_International_Workshop_
on_junction_technology_keynote_2010_5-1-10_slides.pdf (2010). Last
accessed on 02/06/2016.
30. T. Ernst et al., “Novel Si-based nanowire devices: Will they serve ultimate
MOSFETs scaling or ultimate hybrid integration?,” IEDM Tech. Digest,
745–748 (2008).
31. S. Lai, “Current status of the phase change memory and its future,”
IEDM Tech. Digest, 10.1.1–10.1.4 (2003).
32. X. Dong, N. Muralimanohar, N. Jouppi, R. Kaufmann, and Y. Xie,
“Leveraging 3D PCRAM Technologies to Reduce Checkpoint Overhead
for Future Exascale Systems,” http://research.hp.com/people/naveen_
muralimanohar/sc09.pdf (November 2009). Last accessed on 02/06/2016.
33. W. Boullart et al., “STT MRAM patterning challenges,” Proc. SPIE
8685, 86850F (2013) [doi: 10.1117/12.2013602].
34. W. Kim et al., “Extended scalability of perpendicular STT-MRAM
towards sub-20nm MTJ node,” IEDM Tech. Digest, 531–534 (2011).
35. J. Zahurak et al., “Process Integration of a 27nm, 16Gb Cu ReRAM,”
IEDM Tech. Digest, 140–143 (2014).
36. D. Jana, S. Roy, R. Panja, M. Dutta, S. Z. Rahaman, R. Mahapatra, and
S. Maikap, “Conductive-bridging random access memory: challenges and
opportunity for 3D architecture,” Nanoscale Res. Lett. 10(188), doi:
10.1186/s11671-015-0880-9(2015).
37. L. O. Chua, “Memristor - The Missing Circuit Element,” IEEE Trans.
Circuit Theory 18(5), 507–519 (1971).
38. D. B. Strukov, G. S. Snider, D. R. Stewart, and S. R. Williams, “The
missing memristor found,” Nature 453(7191), 80–83 (2008).
39. Wikipedia, “Memristor,” https://en.wikipedia.org/wiki/Memristor (2015).
Last accessed on 02/06/2016.
40. L. Kelion, “3D X-point memory: Faster-than-flash storage unveiled,”
http://www.bbc.com/news/technology-33675734 (July 28, 2015). Last
accessed on 02/06/2016.
41. D. James, “3D ICs in the real world,” Proc. ASMC, 113–119 (2014).
42. D. Henry et al., “Through silicon vias technology for CMOS image
sensors packaging,” Proc. ECTC, 556–562 (2008).
184 References

43. Business Wire, “Toshiba Develops World’s First 16-die Stacked NAND
Flash Memory with TSV Technology,” http://www.businesswire.com/
news/home/20150805006880/en/Toshiba-Develops-Worlds-16-die-Stacked-
NAND-Flash#. VfPJsxFVhBc (2015). Last accessed on 02/06/2016.
44. Business Wire, “Tezzaron Announces World’s First Eight-Layer Active
Wafer Stack,” http://www.businesswire.com/news/home/20150830005041/
en/Tezzaron-Announces-World%E2%80%99s-Eight-Layer-Active-Wafer-
Stack#. VfPIiBFVhBc (2015). Last accessed on 02/06/2016.
45. X. Yang and K. Mohanram, “Robust 6T Si tunneling transistor SRAM
design,” Proc. DATE, 1–6 (2011).
46. G. Zhou et al., “Vertical InGaAs/InP Tunnel FETs With Tunneling
Normal to the Gate,” IEEE Electron Device Lett. 32(11), 1516–1518
(2011).
47. A. Thean, “Challenges & Enablers of Logic CMOS Scaling In The
Next 10 Years,” IMEC Technology Forum Taiwan, http://www2.imec.be/
content/user/File/ITF2013%20Taiwan/Aaron%20Thean.pdf (2013). Last
accessed on 02/06/2016.
48. A. K. Geim and K. S. Novoselov, “The Rise of Graphene,” Nature
Mater. 6, 183–191 (2007).
49. H. Wang, L. Yu, Y.-H. Lee, W. Fang, A. Hsu, P. Herring, M. Chin, M.
Dubey, L.-J. Li, J. Kong, and T. Palacios, “Large-scale 2D Electronics
based on Single-layer MoS2 Grown by Chemical Vapor Deposition,”
IEDM Tech. Digest, 88–91 (2012).
50. H. Xiao, “Wafer Manufacturing, Epitaxy, and Substrate Engineering,”
Chapter 4 in Introduction to Semiconductor Manufacturing Technology,
2nd ed., SPIE Press, Bellingham, WA (2012) [doi: 10.1117/3.924283.ch4].
51. M. Sadaka and L. Di Cioccio, “Building blocks for wafer-level 3D
integration,” Solid State Technol. 52(10), 20 (2009).
52. S.-M. Jung et al., “Three Dimensionally Stacked NAND Flash
Memory Technology Using Stacking Single Crystal Si Layers on ILD
and TANOS Structure for Beyond 30nm Node,” IEDM Tech. Digest,
37–40 (2006).
53. B. Bailey, “Moore’s Law Tail No Longer Wagging The Dog,” http://
semiengineering.com/the-tail-of-moores-law-no-longer-wagging-the-dog
(June 26, 2014).

A. P. K. Chu, “Advances in Solid State Circuit Technologies,” http://www.

intechopen.com/books/advances-in-solid-state-circuit-technologies
B. http://blog-imgs-36-origin.fc2.com/i/s/a/isanghan/DRAM.jpg, last accessed
on 02/06/2016.
C. http://electroiq.com/chipworks_real_chips_blog/2011/01/31/samsungs-3x-
ddr3-sdram-4f2-or-6f2-you-be-the-judge/, last accessed on 02/06/2016.
D. D. Fried and S. Wen, private communications, February 2016.
References 185

E. M. Ishiduki, et al., “Optimal device structure for Pipe-shaped BiCS Flash

memory for ultra high density storage device with excellent performance
and reliability,” IEDM Tech. Digest, 625–628 (2009).
F. C.-H. Hung, et al., “Design innovations to optimize the 3D stackable
vertical gate (VG) NAND flash,” IEDM Tech. Digest, 227–230 (2012).
G. B. Van Zeghbroeck, “Principles of Electronic Devices,” http://ecee.colorado.
edu/~bart/book/book/chapter7/ch7_7.htm, last accessed on 02/06/2016.
H. S. Natarajan, et al., “A 14nm logic technology featuring 2nd-generation
FinFET, air-gapped interconnects, self-aligned double patterning and a
0.0588 mm2 SRAM cell size,” IEDM Tech. Digest, 71–73 (2014).
I. R. Bonnecaze, S. V. Sreenivasan, and J. Ekerdt, “Nanomanufacturing
Presentation for UT in Silicon Valley,” 2013, http://www.slideshare.net/
cockrellschool/nanomanufacturing-presentation-for-ut-in-silicon-valley-
2013, last accessed on 02/06/2016.
J. P. Garrou, “IFTLE 253 China Inc Seeks to Acquire GF; Tessera Acquires
Ziptronix; Tezzaron 8 layer 3DIC,” http://electroiq.com/insights-from-
leading-edge/2015/09/iftle-253-china-inc-seeks-to-acquire-gf-tessera-acquires-
ziptronix-tezzaron-8-layer-3dic/, last accessed on 02/05/2016.
Index
193-nm immersion lithography, 111 E
3D packaging, 168 effective oxide thickness (EOT), 98
4F2 layout, 47 electrochemical plating, 37
6F2 layout, 10 embedded DRAM, 165
8F2 layout, 10 endpoint, 105
etch back, 105
A etch profile, 15
air gap, 155 etch stop layer (ESL), 32, 38
aluminum oxide (AlO), 34 extreme-ultraviolet (EUV)
anti-reflective coating (ARC), 7 lithography, 53

B F
band gap, 174 ferromagnetic materials, 164
borosilicate glass (BSG), 135 fin height, 103
bottom electrode (BE), 164 flash memory, 49
buried oxide, 100 3D-NAND, 53
NAND, 50
C NOR, 50
carrier mobility, 153 floating gate (FG), 49
channel hole, 63 footprint, 6
channel length, 7 front end of line (FEoL), 55
channel width, 7 fully depleted (FD), 100
cobalt tungsten phosphide (CoWP),
121 G
contact resistance, 33 gate contact (GC), 143
control gate (CG), 49 gate first, 99
gate last, 99
d gate oxide thickness, 153
defect of interest (DOI), 32, 33 gate-all-around MOSFET
design intended, 154 (GAA-FET), 53
drive current, 7 germanium, antimony, and
dual damascene, 38 tellurium (GST), 163
dummy gate, 111 graphene, 174

187
188 Index

H oxide/nitride/oxide/nitride (ONON),
high aspect ratio (HAR), 15 60
high k, metal gate (HKMG), 142 oxide/poly/oxide/poly (OPOP), 60
high-k dielectric, 34
high-mobility materials, 157 P
hybrid memory cube (HMC), 173 partially depleted, 100
hydrofluoric acid (HF), 15 pass gate, 141
peripheral area, 23
I phase-change random access
III-V compound, 157 memory (PCRAM), 163
inter-gate dielectrics (IGD), 49 phosphosilicate glass (PSG), 135
inverter gate, 141 pitch tripling, 53
isolation trench, 71 potassium hydroxide (KOH), 105

L R
layout, 126 rapid thermal annealing (RTA), 57
leakage, 6 recess gate (RG), 6
lightly doped drain (LDD), 56 resistive random access memory
litho-etch-litho-etch (LELE), 13 (ReRAM), 163
local interconnect, 80 retention time, 7

M S
magnetic tunnel junction (MTJ), sacrificial oxide, 108
164 select gate (SG), 52
memristor, 166 selective epitaxial growth (SEG), 65,
metal chalcogenides, 174 113
metal gate (MG) recess, 146 selectivity, 79
middle end of line (MEoL), 115 self-aligned double patterning
mini-second anneal (MSA), 115 (SADP), 14, 103
Moore’s law, 177 self-aligned quadruple patterning
(SAQP), 53, 103
N silicon dioxide (SiO2), 98
nonvolatile memory (NVM), 49 silicon germanium (SiGe), 98, 113
silicon nano-wire (NW), 155
O silicon on ILD, 176
off state, 6 silicon on insulator (SOI), 5, 100
off-state leakage, 99 source/drain (S/D), 6
optical proximity correction (OPC), source/drain contact (SDC), 117
153 source/drain implantation, 57
organic planarization layer (OPL), spin-transfer-torque magnetic
133 random access memory (STT-
overlapping, 135 MRAM), 163
Index 189

static random access memory tungsten (W) deposition, 20

(SRAM), 122 tunnel field effect transistor
strontium titanate, 46 (TFET), 173
SuperContacts, 173

T U
through silicon via (TSV), 168 unit cell, 126
TiN gate electrode deposition, 20
top electrode (TE), 164 W
transmission electron microscope wafer-acceptance test (WAT), 43
(TEM), 117
tri-gate FinFET, 100
tungsten chemical mechanical Z
polishing (WCMP), 80 zirconium oxide (ZrO), 34
 Dr. Hong Xiao Xiao is an e-beam technologist at KLA-Tencor
Corp., an expert of IC chip process technologies, and one of
the top experts of applications of scanning electron micro-
scopes in IC chip manufacturing processes. Previously, he
was a technical marketing specialist at Hermes-Microvision,
Inc. and a technical manager of Hermes Epitek Corp. He
was also a consultant of semiconductor process technology,
senior process engineer for the Motorola Semiconductor
Production Sector, and an associate professor of Austin Community College
in their Semiconductor Manufacturing Technology program.

After receiving his Ph.D. in physics from the University of Texas at Austin,
Dr. Xiao worked at Applied Materials as a senior technical instructor with
expertise in dielectric thin film deposition, semiconductor process integration,
and plasma physics. Dr. Xiao has authored and coauthored over 30 journal
and conference papers. He has 21 US patents and about 10 patents in the
application process. He is the author of Introduction to Semiconductor
Manufacturing Technology, Second Edition (SPIE Press, 2012). He has been a
member of SPIE since 2005, and he is also a member of IEEE.
