AIR COOLER

E- CATALOGUE
SUMMER RANGE 2022

In the view of Godrej policy of continuous development; features, specifications and colours are subject to change
without prior notice. Images are representative only. Colours depicted are close to actual but may vary slightly.
 AIR COOLERS

Scan QR code from

your phone or click here
to visit Godrej.com &
QR code view a 360˚ product demo

GODREJ EDGE COOLBLAST

INDIA’S FIRST AIR COOLER WITH
AC WALA INVERTER TECHNOLOGY
AB CHILL BHI ZYADA BILL BHI ADHAA

AC WALA INVERTER
TECHNOLOGY

UP TO

SPEED SWING

POWER
MODE TIMER

AUTO SOAK QUICK CHILL

SAVING*

*Power saving up to 50% has been calculated basis internal energy consumption data versus publicly available energy consumption data of select brands as on 18th January 2020
 INVERTER SERIES

AC WALA INVERTER
TECHNOLOGY

99.94% MODEL CODE:

reduction in
Bacteria
&
CL EDGE CB D 107 D RITK5
Fungus*
CL EDGE CB D 87 D RITK4
CL EDGE CB D 87 R RIT4
CAPACITY (Up to Brim Level) :
87 LITRES | 67 LITRES

AUTOCOOL QUICK CHILL ICE DRIP TURBO MODE SLEEP MODE

TECHONOLOGY TECHNOLOGY TECHNOLOGY (TIMER)

MEMORY THICK 18” AERODYNAMIC REMOTE ANTI-BACTERIAL

BACKUP HONEYCOMB FAN BLADES CONTROL TANK

IONISER HUMIDITY UV-PROTECTED LOW WATER THERMAL OVERLOAD

CONTROL BODY ALARM PROTECTION

DRY RUN WIDE OPERATING COLLAPSIBLE AUTO DRAIN AUTO-FILL

PROTECTION VOLTAGE RANGE LOUVRES

24

TEMPERATURE SILENT BLDC FAN MOTOR

DISPLAY OPERATION WARRANTY *Features may vary from model to model.

Disclaimer: Claim based on the Quantitative Assessment of antimicrobial activity carried out by an independent third party testing agency as per JIS Z 2801 :2010 method,
against certain bacteria and funguses, on the plastic part of Godrej Air Cooler’s Water Tank, under standard test lab condition.
INVERTER SERIES

WINE RED DARK GREY

Units CL EDGE CB D 107 CL EDGE CB D 87 CL EDGE CB D 87

Feature
D RITK5 D RITK4 R RIT4
Water Tank Capacity -Upto Brim Level Ltrs 87 67 67
Cooling Media - Honeycomb mm 50mm 35mm 35mm

Air Delivery CMH 4100 4100 4100

Cooling Capacity -
m2 50 50 50
Cools room sizes up to
Motor Rated Input Power Watts 105W 105W 105W
Control Panel 7 Function 7 Function 5 Function

Fan Size Inches 18” 18” 18”

Dual Tone (Cladding) Yes Yes No

Net Product Dimensions (WxDxH) 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm
x 1.215 m x 1.145 m x 1.145 m
Net Weight kg 19.70 19.30 19.00
BLDC Fan Motor Warranty 2 Years 2 Years 2 Years

Comprehensive Warranty 1 Year 1 Year 1 Year

 ELECTRONIC SERIES

Scan QR code from

your phone or click here
to visit Godrej.com &
QR code view a 360˚ product demo

MODEL CODE:
CL EDGE CB D 107 D RFTJ5
CL EDGE CB D 87 D RFTJ4
CL EDGE CB D 107 D RFT5
99.94% CL EDGE CB D 87 D RFT4
reduction in
Bacteria CL EDGE CB D 87 R RFT4
&
Fungus* CL EDGE CB D 87 D QFT4
CAPACITY (Up to Brim Level) :
87 LITRES | 67 LITRES
SPEED SWING

MODE TIMER

AUTO COOL QUICK CHILL

QUICK CHILL AUTO SOAK ICE DRIP TURBO MODE SLEEP MODE
TECHNOLOGY TECHNOLOGY TECHNOLOGY (TIMER)

MEMORY THICK 18” AERODYNAMIC REMOTE ANTI-BACTERIAL

BACKUP HONEYCOMB FAN BLADES CONTROL TANK

ECO HUMIDITY UV-PROTECTED LOW WATER THERMAL OVERLOAD

MODE CONTROL BODY ALARM PROTECTION

DRY RUN WIDE OPERATING COLLAPSIBLE AUTO DRAIN AUTO-FILL

PROTECTION VOLTAGE RANGE LOUVRES

24

TEMPERATURE SILENT
DISPLAY OPERATION
*Features may vary from model to model.
Disclaimer: Claim based on the Quantitative Assessment of antimicrobial activity carried out by an independent third party testing agency as per JIS Z 2801 :2010 method,
against certain bacteria and funguses, on the plastic part of Godrej Air Cooler’s Water Tank, under standard test lab condition.
 ELECTRONIC SERIES

PURPLE BLUE

Also Available in Also Available in

Units CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB

Feature
D 107 D RFTJ5 D 87 D RFTJ4 D 107 D RFT5 D 87 D RFT4 D 87 R RFT4 D 87 D QFT4
Water Tank Capacity - Ltrs 87 67 87 67 67 67
Upto Brim Level
Cooling Media - Honeycomb mm 50mm 35mm 50mm 35mm 35mm 35mm

Air Delivery CMH 4100 4100 4100 4100 4100 4100

Cooling Capacity -
m2 50 50 50 50 50 50
Cools room sizes up to

Motor Rated Input Power Watts 150W 150W 150W 150W 150W 150W
Control Panel 7 Function 7 Function 5 Function 5 Function 5 Function 5 Function
Fan Size Inches 18” 18” 18” 18” 18” 18”

Dual Tone (Cladding) Yes Yes Yes Yes No Yes

Net Product Dimensions (WxDxH) 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm
x 1.215 m x 1.145 m x 1.215 m x 1.145 m x 1.145 m x 1.145 m
Net Weight kg 19.70 19.30 19.70 19.30 19.00 19.30

Comprehensive Warranty 1 Year 1 Year 1 Year 1 Year 1 Year 1 Year

 MECHANICAL SERIES

Scan QR code from

your phone or click here
to visit Godrej.com &
QR code view a 360˚ product demo

MODEL CODE:
CL EDGE CB D 107 D BFT5
99.94%
reduction in
CL EDGE CB D 87 D BFT4
Bacteria
& CL EDGE CB D 107 R BFN5
Fungus*
CL EDGE CB D 87 R BFN4
CAPACITY (Up to Brim Level) :
87 LITRES | 67 LITRES

ICE DRIP TURBO MODE THICK 18” AERODYNAMIC ANTI-BACTERIAL

TECHNOLOGY HONEYCOMB FAN BLADES TANK

HUMIDITY UV-PROTECTED THERMAL OVERLOAD WIDE OPERATING COLLAPSIBLE

CONTROL BODY PROTECTION VOLTAGE RANGE LOUVRES

AUTO DRAIN AUTO-FILL SILENT

OPERATION

*Features may vary from model to model.

Disclaimer: Claim based on the Quantitative Assessment of antimicrobial activity carried out by an independent third party testing agency as per JIS Z 2801 :2010 method,
against certain bacteria and funguses, on the plastic part of Godrej Air Cooler’s Water Tank, under standard test lab condition.
 MECHANICAL SERIES

BLUE PURPLE
Also Available in Also Available in

WINE RED LIGHT GREY

Units CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB

Feature
D 107 D BFT5 D 87 D BFT4 D 107 R BFN5 D 87 R BFN4
Water Tank Capacity - Ltrs 87 67 87 67
Upto Brim Level
Cooling Media - Honeycomb mm 50mm 35mm 50mm 35mm
Air Delivery CMH 4100 4100 3900 3900
Cooling Capacity -
m2 50 50 47 47
Cools room sizes up to
Motor Rated Input Power Watts 150W 150W 150W 150W

Control Panel 3 Knob 3 Knob 3 Knob 3 Knob

Fan Size Inches 18” 18” 18” 18”

Dual Tone (Cladding) Yes Yes No No

Net Product Dimensions (WxDxH) 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm 68.00 cm x 54.10 cm
x 1.215 m x 1.145 m x 1.215 m x 1.145 m
Net Weight kg 19.70 19.30 19.50 19.00
Comprehensive Warranty 1 Year 1 Year 1 Year 1 Year
 INVERTER ELECTRONIC MECHANICAL
CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB CL EDGE CB
Feature
D 107 D RITK5 D 87 D RITK4 D 87 R RIT4 D 107 D RFTJ5 D 87 D RFTJ4 D 107 D RFT5 D 87 D RFT4 D 87 R RFT4 D 87 D QFT4 D 107 D BFT5 D 87 D BFT4 D 107 R BFN5 D 87 R BFN4
Cooling Media - Honeycomb (mm) 50mm 35mm 35mm 50mm 35mm 50mm 35mm 35mm 35mm 50mm 35mm 50mm 35mm
Speed Selection - L,M,H,Turbo L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H,T L,M,H L,M,H
AutoCool Technology Y Y N N N N N N N N N N N
Quick Chill Technology Y Y N Y Y N N N N N N N N
Auto Soak Technology N N N Y Y N N N N N N N N
Ice-drip Technology Y Y Y Y Y Y Y Y Y Y Y Y Y
Cooling
Ice Chamber Y Y Y Y Y Y Y Y Y Y Y Y Y
Efficiency
Air Delivery (Cubic Meter per Hour) 4100 4100 4100 4100 4100 4100 4100 4100 4100 4100 4100 3900 3900
Humidity Controller Y Y Y Y Y Y Y Y Y Y Y Y Y
Cooling Capacity - Cools room
50 50 50 50 50 50 50 50 50 50 50 47 47
sizes up to (Square meter)
Air Deflection 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way 4 Way
Wide Angle Air Throw (in Degrees) 120 120 120 120 120 120 120 120 120 120 120 120 120
Auto Swing Y Y Y Y Y Y Y Y Y Y Y Y Y
Inverter Technology Y Y Y N N N N N N N N N N
Energy
Works on Inverter Y Y Y Y Y Y Y Y Y Y Y Y Y
Efficiency
Motor Rated Input Power (W) 105W 105W 105W 150W 150W 150W 150W 150W 150W 150W 150W 150W 150W
Sleep Mode (Timer) Y Y Y Y Y Y Y Y Y N N N N
Remote Control Y Y Y Y Y Y Y Y N N N N N
Water Level Indicator Y Y Y Y Y Y Y Y N Y Y Y Y
Cord Winding Station Y Y Y Y Y Y Y Y Y Y Y Y Y
Auto Fill System Y Y Y Y Y Y Y Y Y Y Y Y Y
Convenience Auto Drain System Y Y Y Y Y Y Y Y Y Y Y Y Y
Eco Mode N N N Y Y Y Y Y Y N N N N
Low Water Alarm Y Y N Y Y N N N N N N N N
Memory Back up Y Y Y Y Y Y Y Y Y N N N N
Auto Display off function Y Y N Y Y N N N N N N N N
Castor Wheels with breaks Y Y Y Y Y Y Y Y Y Y Y Y Y
SPECIFICATION TABLE

Temperature Display Y Y N Y Y N N N N N N N N
Ionizer Y Y Y N N N N N N N N N N
Anti-Bacterial Tank Y Y Y Y Y Y Y Y Y Y Y N N
Fully Collapsible Louvres Y Y Y Y Y Y Y Y Y Y Y Y Y
Water Purification Net Y Y Y Y Y Y Y Y Y Y Y Y Y
Dry Run Protection Y Y Y Y Y Y Y Y Y N N N N
Safety & Thermal Overload (Pump/Motor) Y Y Y Y Y Y Y Y Y Y Y Y Y
Durability UV Protected Body Y Y Y Y Y Y Y Y Y Y Y N N
Comprehensive + Fan Motor
1+1 1+1 1+1 1 1 1 1 1 1 1 1 1 1
Warranty
High Voltage Protection Y Y Y Y Y Y Y Y Y Y Y Y Y
Low Voltage Startability Y Y Y Y Y Y Y Y Y Y Y Y Y
Control Panel 7 Function 7 Function 5 Function 7 Function 7 Function 5 Function 5 Function 5 Function 5 Function 3 Knob 3 Knob 3 Knob 3 Knob
Tank Capacity (Ltrs)
87 67 67 87 67 87 67 67 67 87 67 87 67
Upto Brim Level
Fan Size (Inches) 18” 18” 18” 18” 18” 18” 18” 18” 18” 18” 18” 18” 18”
No. of fan blades 3 3 3 3 3 3 3 3 3 3 3 3 3
Dual Tone (Cladding) Y Y Y Y Y Y Y N Y Y Y N N
Technical
Product Dimensions Net 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x 68.00 cm x
(WxDxH) Without Packaging 54.10cm x 1.215m 54.10 cm x 1.145m 54.10 cm x 1.145m 54.10cm x1.215m 54.10 cm x 1.145m 54.10cm x1.215m 54.10 cm x 1.145m 54.10 cm x 1.145m 54.10 cm x 1.145m 54.10cm x1.215m 54.10 cm x 1.145m 54.10cm x1.215m 54.10 cm x 1.145m
Net Weight (Kg) 19.70 19.30 19.00 19.70 19.30 19.70 19.30 19.00 19.30 19.70 19.30 19.50 19.00
Gross Weight (Kg) 24.40 23.30 23.00 24.40 23.30 24.40 23.30 23.00 23.30 24.40 23.30 24.20 23.00
Wine Wine Dark Dark Dark Light Grey Dark Wine Red Wine Red LIight Grey LIight Grey
Colour Variants Purple Purple
Red Red Grey Grey Grey Blue Grey Blue Blue Purple Purple
