ECE 551

Digital Design And Synthesis

Fall ‘09
Lecture 2
• Verilog Syntax
• Structural Verilog
• Timing in Verilog
Administrative Matters
 Readings
• Chapter 4 (module and port declaration, hierarchical
naming…and you thought chapter 3 was boring?)
• Chapter 5 (structural, gate primitives, delays)
 Tutorial sessions
• Today 9/9 4:30-6:00
• Thursday 9/10 1:00-2:30
 Homework #1
• Posted and due Friday 9/18

2
Comments in Verilog
 Commenting is important
• In industry many other poor schmucks are going to read
your code
• Some poor schmuck (perhaps you 4 years later) are going
to have to reference your code when a customer discovers a
bug.
 The best comments document why you are doing
what you are doing, not what you are doing.
• Any moron who knows verilog can tell what the code is
doing.
• Comment why (motivation/thought process) you are doing
that thing.
3
Commenting in Verilog
always @(posedge clk)

begin
Sig_FF1 <= Sig // Capture value of Sig Line in FF
Sig_FF2 <= Sig_FF1; // Flop Sig_FF1 to form Sig_FF2
Sig_FF3 <= Sig_FF2; // Flow Sig_FF2 to form Sig_FF3
end

// start_bit is ~Sig_FF2 & Sig_FF3

assign start_bit = (~Sig_FF2 && Sig_FF3) ? 1’b1 : 1’b0;

(Read with sarcasm)

“Thanks for the commenting the code pal. It tells me so much more
than the verilog itself”.

4
Commenting in Verilog
always @(posedge clk)
/******************************************** Can see 2 types
* Sig is ansynchronous and has to be double flopped *
of comments.
* for meta-stability reasons prior to use ************
*********************************/
begin Comment to
Sig_FF1 <= Sig; end of line is //
Sig_FF2 <= Sig_FF1; // double flopped meta-stability free
Sig_FF3 <= Sig_FF2; // flop again for use in edge detection Multi line
end comment starts
with /* and
/**********************************************
ends with */
* Start bit in protocol initiated by falling edge of Sig line *
**********************************************/
assign start_bit = (~Sig_FF2 && Sig_FF3) ? 1’b1 : 1’b0;

 This is better commenting. It tells you why stuff was done

5
Numbers in Verilog
 General format is: <size>’<base><number>
 Examples:
• 4’b1101 // this is a 4-bit binary number equal to 13
• 10’h2e7 // this is a 10-bit wide number specified in
hex

 Available bases:
• d = decimal (please only use in test benches)
• h = hex (use this frequently)
• b = binary (use this frequently for smaller #’s)
• o = octal (who thinks in octal?, please avoid)
6
Numbers in Verilog
 Numbers can have x or z characters as values
• x = unknown, z = High Impedance
• 12’h13x // 12-bit number with lower 4-bits unknown

 If size is not specified then it depends on simulator/machine.

• Always size the number for the DUT verilog
Why create 32-bit register if you only need 5 bits?
May cause compilation errors on some compilers

 Supports negative numbers as well

• -16’h3A // this would be -3A in hex (i.e. FFC6 in 2’s complement)
• I rarely if ever use this. I prefer to work 2’s complement directly

7
Identifiers (Signal Names)
 Identifiers are the names you choose for your signals
 In a programming language you should choose
descriptive variable names. In a HDL you should
choose descriptive signal names.
• Use mixed case and/or _ to delimit descriptive names.
assign parityErr = ^serial_reg;
nxtState = returnRegister;
• Have a convention for signals that are active low
Many errors occur on the interface between blocks written by 2
different people. One assumed a signal was active low, and the
other assumed it was active high
I use _n at the end of a signal to indicate active low
rst_n = 1’b0 // assert reset
8
 Signal Values & Strength in Verilog
 Signals can have 1 of 4
values Value: Meaning:
0 Logic zero, false condition
Need high
impedance 1 Logic one, true condition
for modeling x Unknown, either uninitialized or in contention
of tri-state
busses z High impedance. Not driven, or not connected

rd_eep What value

does q have
EEPROM q
prior to any
16 16 d
positive clock
dbus[15:0]

edge?
CPU clk
rd_ram

RAM It is unknown: x
16 16 (uninitialized)
9
Resolving 4-Value Logic
S
A A A T OUT
OUT OUT
B B B

A B OUT A B OUT S A T B OUT

0 0 0 0 0 0 0 0 z z z
0 1 1 0 1 0 0 1 z x x
1 1 1 1 1 1 0 x z 1 1
0 x X 0 x 0 0 z z 0 0
0 z X 0 z 0 1 0 0 1 x
1 x 1 1 x x 1 0 0 z 0
1 z 1 1 z x 1 1 1 z 1
1 x x z x
1 z x 0 x
OUT A 0 1 x z
A
OUT 1 0 x X

10
Signal Values & Strength in Verilog

Strength Level Meaning:

supply Strongest (like a supply VDD or VSS)

strong Strong (default if not specified)

pull Medium strength (like a pullup device)

weak Weak, like a keeper (sustainer, leaker)

highz High impedance

 Concept of drive strength supported to model

certain CMOS circuits that utilize contention.

D inv1 Q
not inv1 (Q,n1)
not (weak0,weak1) inv2 (n1,Q)
E inv2

11
Registers in Verilog
 Registers are storage nodes
• They retain their value till a new value is assigned
• Unlike a net (wire) they do not need a driver
• Can be changed in simulation by assigning a new value

 Registers are not necessarily FlipFlops

• In your DUT Verilog registers are typically FlipFlops
• Anything assigned in an always or initial block must be
assigned to a register
• You will use registers in your testbenches, but they will not
be FlipFlops

12
Vectors in Verilog
 Vectors are a collection of bits (i.e. 16-bit wide bus)
////////////////////////////////////////////////////////////////////
// Define the 16-bit busses going in and out of the ALU //
//////////////////////////////////////////////////////////////////
wire [15:0] src1_bus,src2_bus,dst_bus;

///////////////////////////////////////////////////////////////
// State machine has 8 states, need a 3-bit encoding //
/////////////////////////////////////////////////////////////
reg [2:0] state,nxt_state;

 Bus ≠ Vector (how are they different?)

13
Vectors in Verilog
 Can select parts of a vector (single bit or a range)
module lft_shift(src,shft_in,result,shft_out); src
16
input [15:0] src;
input shft_in; shft_out left shift shft_in
output [15:0] result;
16
output shft_out;
result
/////////////////////////////////////////////////////////////////////////
// Can access 15 LSB’s of src with [14:0] selector //
// { , } is a process of concatenating two vectors to form one //
//////////////////////////////////////////////////////////////////////
assign result = {src[14:0],shft_in};

assign shft_out = src[15]; // can access a single bit MSB with [15]

endmodule

14
Arrays & Memories
 Can have multi-dimentional arrays
• reg [7:0] mem[0:99][0:3]; // what is this?
addr1
 Often have to model memories addr2
RF Flash I2C

• RF, SRAM, ROM, Flash, Cache src1

src2
• Memories can be useful in your test bench
ALU
wire [15:0] src1,src2; // source busses to ALU
reg [15:0] reg_file[0:31]; // Register file of 32 16-bit words result
reg [4:0] addr1,addr2; // src1 and src2 address
.
.
.
src1 = reg_file[addr1]; // transfer addressed register file
// to src1 bus
15
Parameters & Define
 Parameters are useful to make your code more
generic/flexible. Read about it in text. More later…
 `define statement can make code more readable
`define idle = 2’b00; // idle state of state machine ng
t h i
`define conv = 2’b01; n lt
// in this state while A2D converting
e
m ba
`define avg = 2’b10; gn glo samples
// in this state whilesiaveraging
.
e as ruly
.
stat be t
.
f or ould
case (state)
f in e sh
`idle : if (start_conv) nxt_state`de fin=e `conv;
s e `de
else t nxt_state
U . = `idle
’ d
D on tea
`conv : if (gt)
le ins
… nxt_state = `avg;
p r s
amelseetenxt_state = `conv;
. x
E am
.Bad par
e
Us
.
16
Parameters & Define
localparam idle = 2’b00; // idle state of state machine
localparam conv = 2’b01; // in this state while A2D converting
localparam accum = 2’b10; // in this state while averaging samples
.
.
.
case (state)
idle : if (start_conv) nxt_state = conv;
else nxt_state = idlle
conv : if (gt) nxt_state = avg;
else nxt_state = conv;
.
.
.

 Read Cumming’s paper on use of define &

param. Posted on web under “supplemental”
17
Useful System Tasks
 $display  Like printf in C. Useful for testbenches
and debug
$display(“At time %t count = %h”,$time,cnt);

 $stop  Stops simulation and allows you to still

probe signals and debug
 $finish  completely stops simulation, simulator
relinquishes control of thread.
 Also useful is `include for including code from
another file (like a header file)
 Read about these features of verilog in your text
18
 Full Adder: Structural
module half_add (X, Y, S, C); module full_add (A, B, CI, S, CO) ;

input X, Y ; input A, B, CI ;
output S, C ; output S, CO ;

xor SUM (S, X, Y); wire S1, C1, C2;

and CARRY (C, X, Y);
// build full adder from 2 half-adders
endmodule half_add PARTSUM (A, B, S1, C1),
SUM (S1, CI, S, C2);

// … add an OR gate for the carry

or CARRY (CO, C2, C1);

Slide taken direct from Prof. Schulte endmodule

19
Full Adder: RTL/Dataflow

module fa_rtl (A, B, CI, S, CO) ; Data flow Verilog is

often very concise
input A, B, CI ; and still easy to read
output S, CO ;
Works great for most
// use continuous assignments boolean and even
assign S = A ^ B ^ CI; datapath descriptions
assign C0 = (A & B) | (A & CI) | (B & CI);

endmodule

20
Full Adder: Behavioral
 Circuit “reacts” to given events (for simulation)
• Actually list of signal changes that affect output
module fa_bhv (A, B, CI, S, CO) ;

Slide taken direct from Prof. Schulte

input A, B, CI;
output S, CO;
reg S, CO; // assignment made in an always block
// must be made to registers
// use procedural assignments
always@(A or B or CI)
begin
S = A ^ B ^ CI;
CO = (A & B) | (A & CI) | (B & CI);
end
endmodule 21
Full Adder: Behavioral


Slide taken direct from Prof. Schulte

IN SIMULATION
• When A, B, or C change, S and CO are recalculated
 IN REALITY
• Combinational logic – no “waiting” for the trigger
• Constantly computing - think transistors and gates!
• Same hardware created for all three types of verilog
A
S
always@(A or B or CI) B
begin CI
S = A ^ B ^ CI; majority CO
CO = (A & B) | (A & CI) | (B & CI);
end fa_bhv
22
Structural Basics: Primitives
 Build design up from the gate/flip-flop/latch level
• Structural verilog is a netlist of blocks and connectivity
 Verilog provides a set of gate primitives
• and, nand, or, nor, xor, xnor, not, buf, bufif1, etc.
• Combinational building blocks for structural design
• Known “behavior”
• Cannot access “inside” description

 Can also model at the transistor level

• Most people don’t, we won’t
23
Primitives
 No declarations - can only be instantiated
 Output port appears before input ports
 Optionally specify: instance name and/or delay
(discuss delay later)

and N25 (Z, A, B, C); // name specified

and #10 (Z, A, B, X),
(X, C, D, E); // delay specified, 2 gates
and #10 N30 (Z, A, B); // name and delay specified

24
Syntax For Structural Verilog
 First declare the interface to the module
• Module keyword, module name
• Port names/types/sizes
 Next, declare any internal wires using “wire”
• wire [3:0] partialsum;
 Then instantiate the primitives/submodules
• Indicate which signal is on which port
 Example: a 4-1 mux

25
Hierarchy
 Any Verilog design you do will be a module
 This includes testbenches!

 Interface (“black box” representation)

• Module name, ports
 Definition
• Describe functionality of the block
 Instantiation
• Use the module inside another module
26
Hierarchy
 Build up a module from smaller pieces
• Primitives
• Other modules (which may contain other modules)
 Design: typically top-down
 Verification: typically bottom-up
Full Adder Hierarchy Add_full

Add_half Add_half or

xor and xor and

27
Add_half Module
Add_half

xor and

module Add_half(c_out, sum, a, b);

output sum, c_out;
input a, b;

xor sum_bit(sum, a, b);

and carry_bit(c_out, a, b);
endmodule

28
Add_full Module
Add_full

Add_half Add_half or

module Add_full(c_out, sum, a, b, c_in) ;

output sum, c_out;
input a, b, c_in;
wire w1, w2, w3;

Add_half AH1(.sum(w1), .c_out(w2), .a(a), .b(b));

Add_half AH2(.sum(sum), .c_out(w3), .a(c_in), .b(w1));
or carry_bit(c_out, w2, w3);
endmodule
29
 Can Mix Styles In Hierarchy!
module Add_half_bhv(c_out, sum, a, b);
output reg sum, c_out;
input a, b;
always @(a, b) begin
sum = a ^ b;
c_out = a & b;
module Add_full_mix(c_out, sum, a, b, c_in) ;
end
output sum, c_out;
endmodule
input a, b, c_in;
wire w1, w2, w3;
Add_half_bhv AH1(.sum(w1), .c_out(w2),
.a(a), .b(b));
Add_half_bhv AH2(.sum(sum), .c_out(w3),
.a(c_in), .b(w1));
assign c_out = w2 | w3;
endmodule
30
Hierarchy And Scope
 Parent cannot access “internal” signals of child
 If you need a signal, must make a port!

Example: module add8bit(cout, sum, a, b);

Detecting overflow output [7:0] sum;
output cout;
input [7:0] a, b;
Overflow = wire cout0, cout1,… cout6;
cout XOR cout6 FA A0(cout0, sum[0], a[0], b[0], 1’b0);
FA A1(cout1, sum[1], a[1], b[1], cout0);
Must output …
FA A7(cout, sum[7], a[7], b[7], cout6);
cout6! endmodule
31
Hierarchy And Source Code
 Can have all modules in a single file
• Module order doesn’t matter!
• Good for small designs
• Not so good for bigger ones
• Not so good for module reuse (cut & paste)
 Can break up modules into multiple files
• Helps with organization
• Lets you find a specific module easily
• Good for module reuse (add file to project)

32
Structural Verilog: Connections
 Positional or Connect by reference
• Can be okay in some situations
Designs with very few ports
Interchangeable input ports (and/or/xor gate inputs)
• Gets confusing for large #s of ports
module dec_2_4_en (A, E_n, D); wire [1:0] X;
wire W_n;
input [1:0] A; wire [3:0] word;
input E_n;
output [3:0] D; // instantiate decoder
.
. dec_2_4_en DX (X, W_n, word);
.
Partial code instatiating decoder
33
Structural Verilog: Connections
 Explicit or Connect by name method
• Helps avoid “misconnections”
• Don’t have to remember port order
• Can be easier to read
• .<port name>(<signal name>)
wire [1:0] X;
module dec_2_4_en (A, E_n, D); wire W_n;
wire [3:0] word;
input [1:0] A;
input E_n; // instantiate decoder
output [3:0] D; dec_2_4_en DX
.
.
(.A(X), .E_n(W_n), .D(word));
. Partial code instatiating decoder
34
Empty Port Connections
 Example: module dec_2_4_en(A, E_n, D);
• dec_2_4_en DX (X[1:0], , word); // E_n is high impedence (z)
• dec_2_4_en DX (X[1:0], W_n , ); // Outputs D[3:0] unused.

 General rules
• Empty input ports => high impedance state (z)
• Empty output ports => output not used
 Specify all input ports anyway!
• Z as an input is very bad…why?

 Helps if no connection to output port name but leave empty:

• dec_2_4_en DX(.A(X[3:2]), .E_n(W_n), .D());
35
Module Port List
 Multiple ways to declare the ports of a module

module Add_half(c_out, sum, a, b);

output sum, c_out;
input a, b;
…
endmodule

module Add_half(output c_out, sum,

input a, b);
…
endmodule

36
Module Port List
 Multiple ways to declare the ports of a module
(example2)

module xor_8bit(out, a, b);

output [7:0] out;
input [7:0] a, b;
…
endmodule

module xor_8bit(output [7:0] out, input [7:0] a, b);

…
endmodule

37
Basic structure of a module

38
Why Know Structural Verilog?
 Code you write to be synthesized will almost all be dataflow
or behavioral
 You will write your test bench primarily in behavioral
 What needs structural Verilog?
• Building hierarchy (instantiating blocks to form higher level functional
blocks)
• There are somethings you can’t trust to synthesis, and need to
instantiate library gates structurally and use `don’t touch directives for
synthesis.
 Intentional clock gating
 Cross coupled SR latches (used when part of core goes to sleep)
• Synthesis tools output structural verilog (gate level netlist). You need to be
able to read this output.

39
Timing Controls For Simulation
 Can put “delays” in a Verilog design
• Gates, wires, & behavioral statements
 Delays are useful for Simulation only!
• Used to approximate “real” operation while simulating
• Used to control testbench
 SYNTHESIS
• Synthesis tool IGNORES these timing controls
Cannot tell a gate to wait 1.5 nanoseconds
Delay is a result of physical properties
• Only timing (easily) controlled is on clock-cycle basis
Can tell synthesizer to attempt to meet cycle-time restriction

40
Zero Delay vs. Unit Delay
 When no timing controls specified: zero delay
• Unrealistic – even electrons take time to move
• OUT is updated same time A and/or B change:
and A0(OUT, A, B)
 Unit delay often used
• Not accurate either, but closer…
• “Depth” of circuit does affect speed!
• Easier to see how changes propagate through circuit
• OUT is updated 1 “unit” after A and/or B change:
and #1 A0(OUT, A, B);

41
Zero/Unit Delay Example
A Z
Y Zero Delay Unit Delay
B T A B C Y Z
C T A B C Y Z
0 0 1 0 x x
0 0 0 0 0 0 1 0 1 0 0 x
1 0 0 1 0 0

Slide taken direct from Prof. Schulte

Zero Delay: 2 0 1 0 0 0
2 0 1 0 0 0 3 0 1 1 0 0
Y and Z change 3 0 1 1 1 1 4 0 1 1 1 0
at same “time” 4 1 0 0 0 1 5 0 1 1 1 1
as A, B, and C! 5 1 0 1 0 1 6 1 0 0 1 1
6 1 1 0 0 1 7 1 0 0 0 1
7 1 1 1 1 1 8 1 1 1 0 1
Unit Delay: 8 0 0 0 0 0 9 1 1 1 1 1
Y changes 1 unit 9 0 0 1 0 0 10 1 0 0 1 1
after B, C 10 0 1 0 0 0 11 1 0 0 0 1
11 0 1 1 1 1 12 0 1 0 0 1
12 1 0 0 0 1 13 0 1 0 0 0
Unit Delay: 13 1 0 1 0 1 14 0 1 1 0 0
Z changes 1 unit 14 1 1 0 0 1 15 0 1 1 1 0
after A, Y 15 1 1 1 0 1 16 0 1 1 1 1
42
Types Of Delays
 Inertial Delay (Gates)
• Suppresses pulses shorter than delay amount
• In reality, gates need to have inputs held a certain time
before output is accurate
• This models that behavior
 Transport Delay (Nets)
• “Time of flight” from source to sink
• Short pulses transmitted
 Not critical for our project, however, in industry
• After APR an SDF is applied for accurate simulation
• Then corner simulations are run to ensure design robust
43
Delay Examples
 wire #5 net_1; // 5 unit transport delay

 and #4 (z_out, x_in, y_in); // 4 unit inertial delay

 assign #3 z_out = a & b; // 3 unit inertial delay

 wire #2 z_out; // 2 unit transport delay

 and #3 (z_out, x_in, y_in); // 3 for gate, 2 for wire

 wire #3 c; // 3 unit transport delay

 assign #5 c = a & b; // 5 for assign, 3 for
wire
44
 Combinational Logic will Generate
Pulses
A
• Have 3 Flops with a unit delay clk2q
01 • Feeds simple combinational logic
n1
1 with unit gate delays
1 out
B • A,B,C make the transitions shown
11
• What does “out” do?
C
10 clk
A
clk
B

n1

out
45
 Inertial Delay (tries to model gate
delay)
A
01

1
n1 • If we add a buffer with a 2
1 2 out unit delay to the end of this
B
circuit, now what happens?
11

C
10
• Remember the inertial gate
delay will filter any pulse
clk
shorter than the specified
delay…The pulse is eaten.

46
Gate Delay Variation (Verilog Handles This)
 Gates don’t have same delay in a rising transition vs
falling
 Gates delays are not constant
• Vary with PVT (Process, Voltage, Temperature)
• You will hear reference to PVT corners
(fff,typ,sss) = (min,typ,max)

NOR Gate:
A Z
Slow on rise
Fast on fall A NAND3 Gate:
B Roughly equal
Z B Rise/fall
C
47
Rise/Fall/Turn Off
in in Referenced to
in out out what the output
out
of the gate is
doing
Trise Tfall

not #(2,1) inv1(out,in); // not gate with 2 unit rise and 1 unit fall

in
in out
Turn Off delay =
en
Time from cntrl to
en out Z
HiZ high impedance

Toff
bufif1 #(1,1,2) tri1(out,in,en); // tri-state gate with unit rise/fall and 2 unit off

48
Min/Typ/Max Delay
 Speed, Speed, Speed ….
• If you need to ensure speed of your circuit you want to
perform your worst case analysis with the longest (max)
delays.

 Perhaps more dangerous is a min-delay case. Race

condition. If circuit has a race that is not met, it will
fail at any clock speed.
• To ensure your circuit is immune to race conditions (i.e.
clock skew) you want to perform your worst case analysis
with shortest (min) delays.
49
Min/Typ/Max
 Verilog supports different timing sets.
and #(1:2:3) g1(out,a,b); // 1 ns min, 2ns typical, 3ns max delay

 Can specify min/typ/max for rise and fall separate)

and #(2:3:4, 1:2:3) g1(out,a,b); // gate has different rise,fall for min:typ:max

 Selection of timing set can is typically done in

simulation environment

Invoke command line verilog engine

% verilog test.v +maxdelays
(like Verilog XL) selecting the
maxdelay time set.

50
 to el s
s v ile
Design Flow n
a
h le F
e te DF
o ga S
ally te ing
i n u la u s
F m n
si ai Gate Level Modified
DUT Verilog Verilog ag
Struct .v Testbenches
Code Testbenches
Verilog
Verilog Simulator
Simulator
Yes Yes
Yes Bugs?
Yes
Bugs?

Synth APR
script

Synthesis SDF Files layout

51
