E - HOUSE LAYOUT OF LIMESTONE LUFFING STACKER

1.Interior painting and exterior Painting should be as per

customer approved specification for all Machines.
2.Fire Extinguisher make Should be follow as per issued
Approved Technical Specification
3.Next Gen should Provide Ehouse QAP for Review by Takraf
Quality Department
4. For cabin fabrication - Mechanical comments
A. All raw materials test certificates to be submitted for TIND
review at the time of inspection
B. WPS/PQR/WQT records to be submitted.
C. Fit up inspection reports to be submitted.
D. Leak and dust proof test to be done, reports to be submitted.
E. Final inspection will be carried out by TAKRAF/ End user.
F. Phone Data SHEET to be submitted

1 0 FOR INFORMATION 19/12/2024 VM MR SMK

SL.NO REV DESCRIPTION DATE PRE. BY CHKD. BY APP. BY

TITLE: END CUSTOMER M/s.ADANI

E - HOUSE LAYOUT CLIENT M/s.LNV TECHNOLOGY PVT LTD.

TIND DOC NO: POC-856-E-V-LLS-D018 CONSULTANT M/S.HOLTEC CONSULTING PVT. LTD.

ACL MARATHA LINE II CHANDRAPUR

LNVT DOC NO: MT002-LNVT-E007-292ST01-0001 PROJECT
MAHARASTHRA

REVISION: 0 OME M/S.TAKRAF INDIA PVT LIMITED

SYSTEM LIMESTONE HANDLING SYSTEM EQUIPMENT LUFFING STACKER

 1 2 3 4 5 6 7 8 9 10

•
PROJECT NAME • ACL MARATHA LINE II PROJECT
(CHANDRAPUR-MAHARASHTRA)

C
CLIENT •
• Mis. LNVT TECHNOLOGY
•
END USER • MIS. ADAN/
OEM •
• TAKRAF IND/A PVT LTD.
•
EQUIPMENT • LIMESTONE HANDLING SYSTEM
LUFFING STACKER
TITLE •
• GA & BASE DETAILS OF E-HOUSE
MACHINE •
• 292ST01
E

CLIENT: DATE NAME

PROJECT
LNVT TECHNOLOGY INDIA PVT. LTD.
ACL MARATHA LINE II PROJECT DESIGNED

--
END USER: M/s. ADAN!
z SYSTEM

I (11
OEM ELECTRICAL CONTRACTOR DRAWN
F 0 LIMESTONE HANDLING SYSTEM CHECKED
B SP 18.12.24 AS PER CLIENT COMMENTS (21.11.2024) RM RM TAKRAF
I I
MACHINE NextGen Automation Pvt. Ltd. APPROVED
LUFFING STACKER
A SP 14.11.24 1ST SUBMISSION RM RM TAKRAF DRG. NO. LNVT DOC. NO. - - -
TITLE IP olc - s s 61- El-Iv - LL s -IDl□l1ls
REV. BY DATE REVISION DESCRIPTION CHECKED APPROVED COVER PAGE FOR E-HOUSE xxxxxxxxxxxxxx REV. B SIZE A3
RELEASED FOR 1 1 mu,1mr1 i 1 1 11:r.cER I 1w�w.T11Jj I f_/ l.PPROI'• CG+.'.,l<XTl:H
SHEET 1 OF 1
Radio Modem - Cabinet for
POSITIONING CONTROLLER Please provide some safety
PANEL Size is :- space for maintenance aspect
600(W)X600(H)X210(D) of Battery bank.

1. Radio Modem 4Nos 8mm dia bolt

nut to be provided.
2. Anemometer 4 Nos 6mm dia bolt
nut to be provided.
Radio Modem - Cabinet for
POSITIONING CONTROLLER
PANEL Size is :-
600(W)X600(H)X210(D)
2 nos of Industrial
Socket Required
EOL Wiring 3.9 Ohms
Resistor Required

2nos of 7 AH
Battery Required
 Model: SS/2ZE; Qty: 1 No per E-House

System Sensor Fire Alarm Control Panel

Honeywell System Sensor Fire Alarm Control Panels have been
developed to provide a simple and reliable solution to the
demands of today’s fire detection requirements. The panels
have been designed with both installer and end user’s
requirements in mind, suited for small to medium sized
buildings like Commercial Buildings, Banking, Residential
complexes, Retail Units/Stores, Shops, Restaurants,
Healthcare, Public Offices, Schools etc.

For installers, Honeywell System Sensor panels offer an out of the

box and on the wall solution. A combination of quick installation,
an enhanced feature set and advanced programming allows
installers to quickly and simply meet the demands of the user.
Equipped with configurable inputs, programmable relays, delay
setting for alarm verification, software isolation of zone and NAC
outputs, mapping of NAC to specific zones, password protections
etc provide wide variety of choice for system installers to customize
the need of an end user.

Engineered and built to the same high standard as all

Honeywell Fire Control panels, this System Sensor panel forms
an essential part of any fire detection requirement.

USER INTERFACE
Display: 16*2 Char LCD Screen
Control Keys: Silence Buzzer, Silence/Resound Alarm, Reset, Evaluate, Accept delay
Indicators: Fault, NAC Fault, Earth Fault, Fire, Power, System Fault.

KEY FEATURES

• 16*2 Char LCD Display, Aesthetically

• Fire, Fault, Configurable Relay • CE certificate.
designed Front Facia/LED's

• Certified for Safety standard

• Individual Zone Isolation • Earth Fault Monitoring
IEC 62368-1:2018
• Battery Charging/Battery Internal
• Customizable text inserts • NAC Enable/Disable facility
Resistance Monitoring
• Input for remote • Monitored NAC and Zone
• Aux output facility
reset/evacuate/alert/fire Circuit for Open/Short/Faults
• On board memory lock switch to
• Data/Time/Password
• Event Logging prevent unauthorized panel
configuration
configuration changes.
• Configurable delays to output, with
• Lamp Test Facility • One Man walk test facility
timer to fire indication
• Upto 600 cable connectivity
• Detectors/MCPs in same zone • Mechanical Keylock
per zone, Typically 20 Detectors
per zone+ 5 MCP's
 WIRING DETAILS
Mechanical Specifications

EOL
2, 4, 6 & 8
Zone 360 X 422 X 122.8 mm (Front Facia),
Dimensions (H X W X D)
Detection 360 X 380 X 92.3 mm (Back Box)
Circuits

EOL
Weight 5.8 Kg Approx. (No Battery Fitted)

Powder coated Cold Rolled STEEL

Construction
1.2mm thick
Input 1
Cable Entry 15 X 20mm Knockout

Input 2
Operating Temperature 0 to 49°C

Sounder Relative Humidity 5% to 95% Non-Condensing

EOL
Circuit 1
Electrical Specifications
Sounder
Circuit 2 EOL
230V-AC +/- 20% Output current 2A
Operating Voltage
Auxiliary maximum, Alarm Load 1A Maximum
+24 Vdc
Power output 0 Vdc
Minimum capacity 2 x 12 V 2.8Ah,
Standby Batteries
Maximum capacity 2 x 12 V 7 Ah

Fire Relay
2, 4, 6, 8 zone, Max 2mA per Detector
output Detection Circuits
Circuit

Fault Relay Input Trigger Extended closing contact

output
Sounder Outputs:
• 2 monitored outputs
Trigger External Outputs • 0.5 Amps per circuit
Programmable
Auxiliary Output:
Relay output
• 18.5 to +28.5 Vdc, 0.5 Amp. (max)

Circuit diagram*
* Number of Programmable input might vary based on panel model, minimum 1 would be supported in all varients,
check Installation Manual

COMPATIBLE DEVICES

Product Model Nos Description

2351/EC System Sensor Photo-Electric Smoke Detector
2351/TEM System Sensor Photo-Electric Smoke & Heat Detector
5351/E System Sensor Heat Detector
B/401 System Sensor Plug-in detector base
 ORDERING PART CODES

Order Codes Manufacturer Part No.

SS/2ZE System Sensor 2 Zone Fire Alarm Control Panel

SS/4ZE System Sensor 4 Zone Fire Alarm Control Panel

SS/6ZE System Sensor 6 Zone Fire Alarm Control Panel

SS/8ZE System Sensor 8 Zone Fire Alarm Control Panel

MCP2A/R470FF/01 System Sensor MCP Red W/O Back Box

MCP2A/R470SF/01 System Sensor MCP Red with Back Box

MUS4A/Y000SF/12 System Sensor MCP Yellow, Dual Pole, Flexi Element with Back Box

MUS3A/G000SF/12 System Sensor MCP Green, Single Pole, Flexi Element with Back Box

MUS3A/Y000FF/11 System Sensor MCP Yellow, Single Pole, Flexi Element, W/O Back Box

MUS4A/G000SF/12 System Sensor MCP Green, Dual Pole, Flexi Element with Back Box

W1A-R470SF-K013-01 System Sensor WCP Red, Flexible Element

SYS/HS System Sensor Horn cum Strobe, Wall, Red, Standard Candela

SYS/HS/C System Sensor Horn cum Strobe, Ceiling, Red, Standard Candela

SYS/ST System Sensor Strobe, Wall, Red, Multi Candela

SYS/ST/C System Sensor Strobe, Ceiling Mount, Red, Multi Candela

MHR/1 System Sensor Red Mini Horn, Red, UL certified

For more information,

https://honeywellbuildings.in
Call: 1-800-103-0339
Email: [email protected]
SYSTEM SENSOR
Honeywell HBT India Buildings FIRE ALARM
Unitech Trade Center, 5th Floor, Sector-43, CONTROL PANEL
Block C, Sushant Lok Phase - I,
Gurgaon - 122 002

www.honeywell.com © 2020 Honeywell International Inc.

 Series 300

CONVENTIONAL-Multi Criteria Photoelectric Smoke/Thermal Detector

Model 2351/TEM

Total Qty: 3 Nos per set of E-House

Overview
Features
• Low profile design
• Low current draw
• Backward compatible with Series 100 detector range of bases
• Wide operating voltage 8 to 30VDC
• Bi-colour LED detector status indicator
• Automatic drift compensation
• Range of detector bases available
199P/03 G202018 0832-CPD-0060
• Tested and approved to EN54 – 7:2000 (Amendment 1)
EN54 – 5:2000 Class A1R; (Amendment 1) CEA4021

Description
The 2351/TEM photoelectric smoke/thermal detector forms part of the Series 300 range of
conventional detectors. This range of detectors has been produced using the latest in manufacturing
and design techniques, pushing out the boundaries of existing conventional detector technology.
The 2351/TEM photoelectric smoke/thermal detector incorporates an optical chamber and a thermal
element, which in turn are continually monitored by an on board processor by using algorithms
developed specifically for the unit. An alarm signal is only enabled in the detector once the processor
is satisfied that an incipient fire has been detected. By using a combination of inputs, the incidence of
nuisance alarms is reduced while at the same time, the response time to an actual fire is also improved.
The 2351/TEM and other detectors in the Series 300 range are backward compatible with the Series
100 detector bases, thus providing the capability to upgrade, extend and maintain existing Series 100
installations.
The 2351/TEM detector incorporates a bi-colour LED indicator. The integral LED changes colour
according to the detector’s status - Green = Normal, Red = Alarm. This benefits the user by providing
clear, instant visual indication of the detector’s condition. The Green LED can be programmed for
blink/no blink operation. ‘Drift compensation’ algorithms are one of the key features of the 2351/TEM
detector. These algorithms ensure a consistent alarm sensitivity threshold for periods between service
intervals. This provides the user with both a reduction in the frequency of nuisance alarms and
maintenance savings by extending the period before cleaning of the detector chamber is required.

Architect/Engineer Specifications
2351/TEM Photoelectric Smoke / Thermal Detector
A variety of detector bases can be used with the 2351/TEM detector, providing application flexibility
and compatibility with a wide range of Fire Alarm Control Panels. All bases are fitted with a shorting
spring to permit circuit testing prior to fitting the detector and have a tamper resistant feature, which
when activated prevents removal of the detector without the use of a tool.
All System Sensor products are covered by our extended 3 year warranty.
Electrical Specifications
Operating Voltage Range 8 to 30VDC (Nominal 12/24VDC)
Typical Standby Current @ 25ÞC 65μA @ 24VDC (LED no blink)
Maximum Alarm Current (LED On) 80mA @ 24VDC (Limited by panel)

Environmental Specifications
Application Temperature Range -30°C to +70°C
Humidity 5 to 95% Relative Humidity (non condensing)

Mechanical Information
Height 38mm (plus 9mm for B401 base)
Diameter 102mm
Weight 105g (plus 60g for B401 base)
Max Wire Gauge for Terminals 0.75mm2 to 2.5mm2
Colour Pantone Warm Grey 1C
Material Bayblend FR110

Product Range
Compatible Bases (see notes) B401 Standard Base
B401SD Standard base with schotty diode
B401R Resistor base with 470 ohm resistor
B401RSD Standard base with 470 ohm resistor and Shottky diode
B401RM Standard recess base with 470 ohm resistor
B401DG Deep base
B401DGR Deep base with 470 ohm resistor
B401DGSD Deep base with Shottky diode
B312NL 12V non-latching relay base
B312RL 12V latching relay base
B324RL 24V latching relay base
Other Devices in range 2351/EC, 4351/E, 5351/E

Notes
Bases with other resistor values are available to suit the requirements of most Fire Alarm Control Panels.

System Sensor India (Technical Services)

System Sensor and Devices Honeywell Building Technology
Sector 36, Pace City II Gurgaon, India - 122004.
Toll Free number: 1800-103-0339
email ID: [email protected]

Copyright © 2005 System Sensor. All rights reserved.

All technical data is correct at time of publication and is subject to change without notice. All trademarks acknowledged.
Installation information: in order to ensure full functionality, refer to the installation instructions as supplied. DS5351TEM-07
 MCP Indoor Manual Call Point
Total Qty: 1 No. per set of E-House

>Product Benefits
• Unique ‘Plug & Play’ installation concept
• Total ‘Flex-Ability’ in the choice of operating ating
element
element
• Anti-Tamper facility
• Enhanced aesthetics
• Fully approved to the latest standards

166b/39 & 166b/40 Pending

Product Overview
Installation efficiency, flexibility and full compliance with the latest standards are at the heart of
the new MCP Indoor Call Point range.
Installation time and ultimately cost, are of paramount importance to any fire or security
installer. The MCP range directly reflects this need by providing a unique ‘plug and play’
concept designed specifically to reduce installation time. All new MCP products utilise a
special terminal block, where all initial installation cabling is terminated. This terminal block
is then simply connected to the back of the MCP. Simple, but effective with no re-termination
required and no time wasted.
Through new standards and legislation, both break glass and re-settable operating elements
can now be used within a manual call point. To provide you with the greatest ‘flex-ability’,
the new MCP range can be configured as either a break glass or re-settable unit by simply
changing from one element to another. No other additional parts or alternative products need
to be ordered.
All MCP Indoor Call Point products also help preserve the integrity of the overall system as
illegal removal of the product lid will result in the call point operating and the system going in to
alarm.
Full compliance with the latest standards is essential and the new MCP indoor call point range
is fully approved to the latest EN54-11 standard.
All MCP2 products are supplied with an LED indicator as standard.
The MCP2A Product version is supplied with both a resistor and normally open, clean contact
electrical options. These options are simpily utilised by attaching the terminal block to the
required connection in the back of the MCP product. A variety of resistsor values are available
by request, with 470Ω offered as standard.
The MCP2B product versions are designed for connection to “savwire” systems.
MCP2
Rev. No. 3
Electrical Specification Figure .1
MCP2A-X MCP2B-X
Connection Details: See Figure .1
Cable Termination: 0.5-2.5mm2
Maximium Voltage: 30VDC
Current Rating: 2 Amps

Environmental Specification

Humidity: 0-95% non-condensing

Operating Temperature: -100C to +550C
Storage Temperature: -100C to +550C
Ingress Protection (IP) Rating: IP24D

Mechanical Specification 89mm 27.5mm 32mm

72mm
72 mm
60mm
Material: PC/ABS
Weight: 110g Flush
160g Surface
93mm

Colour: Red, Ral 3001

72mm
72 mm
Ordering Information
Model

MCP2A/R470FF/01 Conv. MCP, Red, with LED ,470 Ohm, W/O Back Box, India
MCP2A/R470SF/01 Conv. MCP, Red, with LED, 470 Ohm, with BB, India
MUS4A/Y000SF/12 Conv. MCP, Yellow , Dual Pole, Flexi Element, with BB, IndiaSurface Flexi EN54-11
MUS3A/G000SF/12 Conv. MCP, Green, Single Pole, Flexi, with BB, India Surface Glass EN54-11
MUS3A/Y000FF/11 Conv. MCP, Yellow, Single Pole, Flexi Element, W/O BB, India
MUS4A/G000SF/12 Conv. MCP, Green, Dual Pole, Flexi, with BB, India

Code Description
N\O = Normally Open Contact
SC070
SAV = Savwire system
KG1 x 5 Pack Of five Glass Elements
PS210
Accessories
PS200
Code Description
SC071
SC070 Pack
PackOf
OfTen
TenTerminal Blocks
Test Keys
KG1 x 5 Pack Of five Glass Elements
PS210 Flexible Operating Element
PS200 Plain Hinged Cover
SC071 Pack Of Ten Terminal Blocks

> System Sensor India (Technical Services)

System Sensor and Devices
Honeywell Life Safety
Sector 36, Pace City II
Gurgaon, India - 122004
Toll Free number: 1800-103-0339
email ID : [email protected]
System Sensor India (Customer Service)
System Sensor and Devices
Honeywell Life Safety
Sector 36, Pace City II
Gurgaon, India - 122004
Landline: +91 124 4752700
Fax: +91 124 4752750
 Total Qty: 1 No. per set of E-House

Selectable Output
Horns, Strobes &
Horn Strobes
System Sensor selectable output horns, strobes &
horn strobes are rich with features guaranteed to
reduce installation and maximize profits.

Features : Horn, Strobes & Horn Strobes

The System Sensor line of notification devices offers the most flexible and
Mounting plate included for compatibility with a wide range of
?
back box sizes, easy-to-use line of horns, strobes, and horn strobes in the industry. With
Three field selectable candela settings: 15, 75, and 115,
?
red housing, universal fire symbol and a ceiling mount accessory available
these devices can meet virtually any application. They also mount to a
Easy to use rotary dials for selection of candela and horn
?
settings, wide variety of back box sizes to offer the most flexibility in installation.
Built in synchronization feature keeps strobes in sync for up to
?
30 minutes, This line of devices features a wide variety of features that simplifies
Strobes Listed to UL 1638; Horns Listed to UL 464,
?
installations. The mounting plate allows the devices to be compatible with
a wide range of back box sizes. Settings for the strobe and horn are done
Horn settings on the horn strobe model include high and low
?
volume, continuous or temporal 3 tone, using easy to set rotary switches on the back of the device.
Synchronization is achieved without the use of additional modules; when
Round trim ring available for ceiling mount applications,
?
powered with a filtered DC source, the strobe portion is capable of self
Universal Fire symbol is language independent,
?
synchronization for 30 minutes per NFPA 72.
Trim plate allows mini horn to mount to a variety of backboxes
?
and fit aesthetically with the horn strobe and strobe.
Devices work on 24 volts DC or full wave rectified power. Three candela
options are available for the strobe. On the horn strobe model, high and
Features : Mini-Horn
low volume are options for the horn as well as a continuous tone or
12 and 24V operation,
? temporal 3 output. The mini horn model has a continuous tone output and
High and low volume settings,
? one volume setting.
Temporal and non-temporal tones,
?
Available accessories include a round trim ring to adapt the wall device for
Mounts to single gang back box,
?
ceiling mount applications. Simply install the round ring over the square
Compatible with MDL sunc module,
?
device for a perfect fit on the ceiling. An adapter plate is also available for
Mechanically and electrically compatible with PA400 series
? the mini horn. It fits to a wider range of back boxes and fits with the family
Mini-Alert TM sounders.
look of the horn strobe and strobe devices.

Agency Listing

SIGNALING

LISTED
System Sensor Specifications
Architect/Engineer Specifications
General
System Sensor strobe and horn strobes shall mount to a 2"x4", 4"x4", Single Gang, Double Gang, 4" Octagon, 3.7" x 3.7", 2" round, 2.36" x 2.36", 3.54"
x 2.6", 1.77" back box. System Sensor devices shall be powered from a non-coded notification appliance circuit output and shall operate on a nominal
24 volts. 24-volt-rated notification appliance circuit outputs shall operate between 17 and 33 volts. Devices operate between 32 and 120 degrees
Fahrenheit from a regulated DC or full-wave rectified unfiltered power supply. Strobes and horn strobes shall have field-selectable candela settings
including 15, 75 and 115 cd. The devices shall not operate on a coded power supply. Horn - strobe and strobe devices shall have built-in
synchronization capability. Upon initial power up the devices shall be synchronized for up to 30minutes.
Strobe
The strobe shall be a System Sensor Model SYS-ST or SYS-ST-C listed to UL 1638 and shall be approved for fire protective service. The strobe shall
be wired as a primary signaling notification appliance flashing at 1 Hz over the strobe’s entire operating voltage range. The strobe light shall consist of
a xenon flash tube and associated lens/reflector system.
Horn Strobe Combination
The horn strobe shall be a System Sensor Model listed to UL 1638 and UL 464 and shall be approved for fire protective service. The horn strobe shall
be wired as a primary-signaling notification appliance and comply with the Americans with Disabilities Act requirements for visible signaling
appliances, flashing at 1 Hz over the strobe’s entire operating voltage range. The strobe light shall consist of a xenon flash tube and associated
lens/reflector system. The horn shall have two audibility options and an option to switch between a temporal three-pattern and a non-temporal
(continuous) pattern. These options are set by a multiple position switch.
Mini Horn
Mini-horns shall be a System Sensor Model MHR or MHW capable of operating at nominal 12 or 24VDC and shall mount to a deep single gang back
box. Minihorn shall be listed to Underwriter’s Laboratories Standard UL464 for fire protective signaling systems. Mini-horns shall operate between 32
and 120 degrees Fahrenheit from a regulated DC, or full-wave rectified, unfiltered power supply. When used with the Sync•Circuit™ Module, 12-volt
rated notification appliance circuit outputs shall operate between nine and 17.5 volts; 24-volt rated notification appliance circuit outputs shall operate
between 17 and 33 volts.

Physical/Electrical Specifications: Horn, Strobes & Horn Strobes

Standard Operating Temperature 32°F to 120°F (0°C to 49°C)
Humidity Range 10 to 93% non-condensing
Strobe Flash Rate 1 flash per second
Nominal Voltage Regulated or regulated 24 DC/FWR1
Operating Voltage Range2 16 to 33 V (24 V nominal)
Input Terminal Wire Gauge 14 to 18 AWG*
Strobe and horn strobes dimensions(including lens) 5.15" L x 5.0"Wx 1.5" D (131mmx 127mmx 38mm)
Ceiling trim ring dimensions (sold as a pack of 5) 6.8 " dia / 1.5" depth (173mmdia / 1.5" depth)
Mini-Horn UL Sound Output and Current Draw Data
Sounder Output (dBA)
Switch Setting Pattern Output Level 8–17.5 VDC 8–17.5 VFWR Nominal 12 VDC Nominal 12 VFWR 16–33 VDC16–33 VFWR
1 Temporal High 68 67 71 70 78 76
2 Temporal Low 66 65 69 68 76 75
3 Non-temporal High 72 71 75 74 80 79
4 Non-temporal Low 70 69 73 72 78 77
Sounder Current Draw (mA RMS)
8–17.5 Volts 16–33 Volts
Switch Position Sound Pattern Volume DC FWR DC FWR
1 Temporal High 12 10 17 15
2 Temporal Low 10 9 14 13
3 Non-temporal High 22 17 29 25
4 Non-temporal Low 17 13 21 19
Full Wave Rectified (FWR) voltage is a non-regulated, time-varying power source that is used on some power supply and panel outputs.
UL Current Draw Data
UL Max. Strobe Current Draw (mA RMS) UL Max. Current Draw Horn Strobe
16–33 Volts 16–33 Volts
Switch Position Candela DC FWR DC Input 15 15/75 30
Standard Candela Position 1 15 34 45 Temporal High 36 67 84
Range Position 2 75 63 74 Temporal Medium 34 65 82
Position 3 115 79 89 Continuous High 40 72 90
Continuous Low 37 68 85
FWR Input
Temporal High 51 77 83
Temporal Low 49 75 92
Continuous High 55 82 98
Continuous Low 50 78 94

Horn Tones and Sound Output Data

Horn Strobe Output (dBA)
24-Volt Nominal
16–33 Volts† Reverberant Anechoic
Switch Position Sound Pattern dB DC FWR DC FWR DC FWR
1 Temporal High 78 77 78 77 100 104
2 Temporal Low 74 73 74 73 103 101
3 Continuous High 82 80 82 80 100 104
4 Continuous Low 80 78 80 78 103 101
†
Minimum dB rating for Operational Voltage Range as per UL 464.
 4.960" 2.464" 2.464"
6.800" dia.

5.130"

Wall Mount Horn Strobe Product Ceiling Mount Horn Strobe

4.960"
1.725"
2.890" 1.44"

5.130"
4.600"

Mini Horn Mini Horn with Optional Trim Plate

System Sensor Ordering Information

Model Description Model Description
Wall Horn Strobes Mini Horn
S YS-HS Horn Strobe, Wall Mount MH R1 Mini-Horn, Red
S YS-HS-C Horn Strobe, Ceiling Mount S YS-MH-TP Trim Ring for use with the Mini Horn
Wall Strobes
S YS-ST Strobe, Wall Mount
SYS-ST-C Strobe, Ceiling Mount
S YS- CTP Ceiling Mount Trim Plate

Tech Support : [email protected]

©2 010 S ystem S ensor.
Sec 36- P ace C ity – II, Gurg aon, H aryana- 122004 Product specifications subject to change without notice. Visit
system sensor.com for current product information, including the latest
Phone: (0124) 4752700 • Fax: (0124) version of this data sheet.
6722700 AV-India-C L-001
